D-Link DIR-615 - Wireless N Router User manual

WIRELESS N 300 ROUTER
DIR - 615
QUICK
INSTALLATION
GUIDE

DIR-615
2
ENGLISH
CONTENTS OF
PACKAGING
CONTENTS
WIRELESS N 300 ROUTER
DIR-615
POWER ADAPTER
12V 0.5A
ETHERNET CABLE (CAT5 UTP)
CONNECT THE ROUTER TO YOUR PC DURING SET-UP
If any of these items are missing from your packaging, contact
your reseller.

DIR-615 3
ENGLISH
PRODUCT SETUP
WEB-BASED SETUP
Step 1
Position your DIR-615 near your Internet-connected modem and
PC. Keep the router in an open area for better wireless coverage.
Step 4
Open a browser on the connected computer. If you are not
automatically directed to the D-Link Setup Wizard, go to
‘http://192.168.0.1’ and follow the onscreen instructions to congure
your DIR-615. Use username ‘Admin’ and password ‘#@t#w@y’ to
congure manually.
Step 2
Unplug the modem Ethernet cable connected to your computer and
plug it into the port labeled ‘INTERNET’ on the router.
Connect the supplied power adapter to the router and a power
outlet, then verify that the power LED is on.
Step 3
Plug one end of the supplied Ethernet cable into the port labeled ‘1’
on the back of the router, and the other end into the Ethernet port on
your computer.
Modem
Router
PC
Modem
PC Modem
Internet
Save
Router
Router

DIR-615
4
ENGLISH
PRODUCT SETUP
REPEATER MODE
Step 1
Connect the supplied power adapter
to the router and a power outlet, then
verify that the power LED is on.
Step 4
From your laptop or mobile device
go to your wireless utility to display
the available wireless networks and
select the network that you previously
connected to in Step 3 for internet
access.
Step 2
Open a web browser and type
'http://192.168.0.1' . Go to
Wireless>Wireless Repeater page
and enable Repeater mode. Click
the Site Survey button and select
the Wi-Fi network(SSID) you would
like the DIR-615 to connect to
wirelessly.
Step 3
Enter the Wi-Fi Password(Pre-shared
Key) and click Next. Click the Finish
button to save the conguration.
Note: You may need to change the
IP address of DIR-615 to avoid IP
Address conicts with root router.
(ex. If root router’s IP address is
192.168.0.1, you can modify IP
address of DIR-615 to 192.168.0.2)
Internet Modem Router In Repeater mode

DIR-615 5
ENGLISH
TROUBLESHOOTING
SETUP AND CONFIGURATION PROBLEMS
1. HOW DO I CONFIGURE MY DIR-615 ROUTER MANUALLY?
- Connect your PC to the router using an Ethernet cable.
- Open a web browser and enter the address ‘http://192.168.0.1’ .
- The default username is ‘Admin’ and the default password is ‘#@t#w@y’. ”
- If you have changed the password and can not remember it, you will need to reset the router to
return to an empty password eld.
2. HOW DO I RESET MY DIR-615 ROUTER TO FACTORY DEFAULT SETTINGS?
- Ensure the router is powered on.
- Press and hold the reset button at the bottom of the device for 10 seconds.
Note: Resetting the router to factory default will erase the current conguration settings.
To re-congure your settings, log into the router as outlined in question 1, then run the Setup Wizard.
3. HOW DO I ADD A NEW WIRELESS CLIENT OR PC IF I HAVE FORGOTTEN MY
WI-FI NAME (SSID) OR WI-FI PASSWORD?
- For every PC that needs to connect to the router wirelessly, you will need to ensure you use the
correct Wi-Fi Name (SSID) and Wi-Fi password.
- Use the web-based user interface (as described in question 1 above) to check or choose your
wireless settings.
- Make sure you write down these settings so that you can enter them for each wirelessly
connected PC. The back of this document features an area to record this important information.
4. WHY CAN'T I GET AN INTERNET CONNECTION?
- For ADSL users, please contact your ISP to make sure the service has been enabled/connected
by your ISP and that your ISP username and password is correct.

DIR-615
6
ENGLISH
TECHNICAL SUPPORT
India:
Tel: [phone]
Toll Free 1800-233-0000
Web: www.dlink.co.in
E-Mail: [email protected]
You can nd software updates and user documentation on the D-Link website.
Tech Support for customers in

DIR-615 7
ENGLISH
NOTES

WIRELESS NETWORK REMINDER
Wireless Network Name (SSID)
Wireless Network Password
Ver. 20.00(HW)_130x183 2016/01/27
