D-Link DSL-514 User manual

1
1. If you purchased this Router to share your high-speed Internet connection with other
computers, you must have either an Ethernet-based Cable or a DSL Router with an
established Internet account from an Internet Service Provider (ISP).
2. It’s best to use the same computer that is connected to your router for configuring the DSL-
514 ADSL Router. The DSL-514 acts as a DHCP server and will assign all the necessary IP
address information on your network. See at the Quick Installation Guide or the Manual on the
CD-ROM for setting each network adapter to automatically obtain an IP address.
Check Your Package Contents
These are the items included with your DSL-514 purchase:
If any of the above items are missing, please contact your reseller.
©2003 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective
holders. Software and specifications subject to change without notice. DSL-514.ADSL Router
This product can be set up using any
current web browser, i.e., Internet
Explorer 6.x, Netscape Navigator 7.x. DSL-514
ADSL Route
r
Before Your Begin
Using a power
supply with a
different voltage rating
will damage and void
the warranty for this
product.
• DSL-514 ADSL Router
• CD-ROM (containing Manual and Warranty)
• Ethernet Cable
• 9V AC, 1A Power Adapter
•ADSL Cable (standard telephone cable)

2
Connecting The DSL-514 ADSL
Router To Your Network
A. First, connect the power adapter to the receptor at the back panel of
the DSL-514 and then plug the other end of the power adapter to a
wall outlet or power strip. The Power LED will turn ON to indicate
proper operation.
B. Insert one end of an Ethernet cable to the LAN port on the back panel
of the DSL-514. The LAN LED light will illuminate to indicate proper
connection.
C. Use the twisted-pair ADSL cable (standard telephone cable) included
with the Router to connect it to the telephone wall socket. Plug one
end of the cable into the ADSL port on the rear panel of the Router
and insert the other end into the wall socket.
D. Use standard telephone cable with standard RJ-11 connectors
included with the Router to connect it to telephone or other telephone
device.
Reset Button
Pressing this button
restores the router to
its original factory
default settings.
A.Receptor for
Power Adapter
B.LAN Port
These are the connections for
Ethernet cables to your Ethernet-
enabled computers.
C.This is the
connection for
ADSL Cable
to DSL
Provider.
D. This is the
connection for
Phone Cable
to Telephone.

3
Connecting Additional Computers To
The DSL-514 ADSL Router
Using additional Ethernet (CAT5 UTP) cables, connect your Ethernet-
equipped computers to the DSL-514 LAN ports on the back panel of the
DSL-514.
When you have completed the steps in this Quick Installation Guide,
your connected network should look similar to this:

4
Configure IP Settings
For Microsoft Windows XP
To connect to the network, make sure the network adapter in your
computer is configured properly. Here’s how to configure the network
adapter to obtain an IP address automatically for the DSL-514 ADSL
Router.
Go to Start > select
Setting > click the
Control Panel >
Double-click on the
Network
Connections icon
Double-Click on the
Network Connections
Right-click the Local
Area Connection
icon, and then select
Properties.
Select Properties

5
Click Internet Protocol (TCP/IP)
Select Obtain an IP address
automatically
Click Properties
Click OK
The dialog box displays with a
list of currently installed network
items.
Select you can get IP settings
assigned automatically.

6
For Microsoft Windows 2000
Go to Start > select
Setting > click the
Control Panel >
Double-click on the
Network Connection
and Dial-Up
Connections icon
Double-Click on the
Network Connection and
Dial-Up Connections
Select Properties
Right-click the Local
Area Connection
icon, and then select
Properties.

7
Click Internet Protocol (TCP/IP)
Click Properties
Select Obtain an IP address
automatically
Restart your
computer
Click OK
The dialog box displays with a
list of currently installed network
items.
Select you can get IP settings
assigned automatically.

8
For Microsoft Windows ME
Go to Start > select
Setting > click the
Control Panel >
Double-click on the
Network icon
Double-Click on
the Network
Select the listing associated with
your network card or adapter
Click Properties
The Network dialog box
displays with a list of currently
installed network components.

9
Select Obtain an IP address
automatically
Click OK
Restart your
computer
Select you can get IP settings
assigned automatically.

10
For Microsoft Windows 98SE
Go to Start > select
Setting > click the
Control Panel >
Double-click on the
Network icon
Double-Click on
the Network
Select the listing associated with
your network card or adapter
Click Properties
The Network dialog box
displays with a list of currently
installed network components.

11
Select Obtain an IP address
automatically
Click OK
Restart your
computer
Select you can get IP settings
assigned automatically.

12
Logging into The DSL-514
Open your Web
browser and type
“http://192.168.0.2”
into the URL address
box. Then press Enter
or Return key.
Click OK
The logon pop-up
screen will appear.
When you first log in, your
user name and password will
be following:
User name: “admin”
Password: “514admin”

13
Once you have logged
in, the Home screen
will appear.

14
Using The Setup Wizard
Configuring for Dynamic IP Address
Check your ISP information,
If you configure for Dynamic IP Address, refer to page 14-18.
If you configure for Static IP Address, refer to page 19-22.
If you configure for PPP type, refer to page 23-26.
If you configure for Bridge Mode, refer to page 27-32.
Click
Run Wizard

15
Click Next
You will see the
following screen.
Click Next
Set up your new
password. You have
the option to establish
an 8~30 characters
password.

16
Select Dynamic
IP Address
If you are unsure of which setting to
select, please contact your Internet
Service Provider.
Click Next
Select one of these
setting.
Choose your time
zone.
Click Next

17
If your ISP requires
a Dynamic IP
Address, then this
screen will appear:
Enter all values and
select connection
type of this screen.
Refer those data
from your ISP or
phone company.
Click Next
Do not use the numbers
displayed in these fields.
They are only showed as an
exam
p
le.
Click Restart
Your Setup is
completed.

18
You will be returned
to Home tab.
Click Close

19
Configuring for Static IP Address
Click
Run Wizard
Click Next
You will see the
following screen.

20
Click Next
Set up your new
password. You have
the option to establish
an 8~30 characters
password.
Choose your time
zone.
Click Next
