D-Link DSS-24+ User manual

The D-Link DSS-24+ is a high performance unmanaged
Layer 2 Switch that provides users with 24 10/100Mbps
Fast Ethernet ports and optional fiber uplinks for distant
connections. The DSS-24+ is designed to increase cable
connectivity to distant servers or backbones, targeted for
both small offices and small business environments.
High Performance Wire-speed Architecture
The DSS-24+ delivers superior performance and outstanding
value. With a switching capacity of up to 5.2Gbps and
full-duplex wire-speed forwarding, the DSS-24+ is an ideal
solution for the most demanding environment. It can be
used as a cost-effective wiring closet solution or a high
performance backbone aggregation device.
Easy to Install and Maintain
The auto features of this switch make installation plug
& play and hassle-free. No configuration is required.
Auto-MDI/MDI-X crossover on all ports eliminates the
need for crossover cables for connection to another
switch or hub. Auto-negotiation on each port senses the
link speed of a network device (either 10 or 100Mbps)
and intelligently adjusts for compatibility and optimal
performance. It also features diagnostic LEDs which
display status and activity, allowing you to quickly detect
and correct problems on the network. The DSS-24+ has no
fans and is suitable for an office environment.
Optional Fiber Uplinks to Protect Investment
The DSS-24+ has an optional slot that supports a 2-port
100BASE-FX MMF module that can connect to distant
backbones up to two kilometers away.
24-Port Switch with optional 2 port 100BASE-FX uplinks
DSS-24+ Unmanaged Fast Ethernet Switch
High Performance Wire-speed
Architecture:
+ 5.2Gbps Switching Capacity
+ Non-blocking Architecture
+ 4K MAC Address Table
Operational Simplicity:
+ True Plug & Play
+ Auto-sensing
+ Auto Cable Detection
+ Auto-configuration
+ Clear, At-a-Glance per Port LEDs
indicators
+ Rack Mountable or Desktop
+ Fanless for Quiet Operation
Investment Protection:
+ Support for Industry Standards
+ Limited Lifetime Warranty1

24-Port Switch with optional 2 port 100BASE-FX uplinks
Technical Specifications
Product/Performance Specifications
DSS-24+ Unmanaged 24-Port 10/100BASE-TX Switch with optional 2 port 100BASE-FX module
MAC Address Table Size 4K
Switch Fabric 5.2Gbps Forwarding Capacity
Transmission Method Store-and-forward
Diagnostic LEDs Per Unit: Power
Per Port: Activity/Link, Speed
Packet Buffer Memory On chip 1.5Mb Buffer Memory per device
Max Power Consumption 13.3 Watts Maximum
Heat Dissipation 45.38 BTU/hr
Interface Options
RJ-45 10BASE-T, 100BASE-TX
SC 100BASE-FX, (with DES-102F only)
Network Protocol and Standards
IEEE 802.3 Ethernet, 802.3u Fast Ethernet, 802.3x Flow Control
Electrical & Emissions Summary
Emissions CE Mark A, FCC Class A
Power Supply 100- 240VAC, 50/60Hz Internal Universal Power
Safety Agency Certifications and Environmental
Safety CSA + NRTL/C
Environmental RoHS
Temperature Operating: 32° to 104°F (0° to 40°C)
Storage: -40° to 158°F (-40° to 70°C)
Humidity Operating: 5% ~ 95% RH & Non-Condensing
Physical Specifications
Dimensions (W x D x H) 17.36in x 1.73in x 8.15in (441mm x 207mm x 43mm)
Weight 4.8 lbs (2.2Kg)
Warranty and Support Information
Warranty1Limited Lifetime1
Ordering Information
Part Number Description
DSS-24+ Unmanaged 24-Port 10/100BASE-TX Switch with Optional 2 Port 100BASE-FX Uplinks
DES-102F 2-Port 100BASE-FX MMF Module
D-Link Systems, Inc. 17595 Mt. Herrmann Street Fountain Valley CA 92708 www.dlink.com
©2005-2010 D-Link Corporation/D-Link Systems, Inc. All rights reserved. D-Link and
the D-Link logo are registered trademarks of D-Link Corporation or its subsidiaries
in the United States and other countries. Other trademarks or registered trademarks
are the property of their respective owners. Visit www.dlink.com for more details.
1 Limited Lifetime Warranty available only in the U.S.A and Canada if purchased on or after June 1, 2010. Visit www.dlink.com for warranty details.
All references to speed are for comparison purposes only. Product specifications, size and shape are subject to change without notice, and actual product
appearance may differ from that depicted herein. Specifications contained herein are based on Hardware version D1/D2
Hardware v. D1/D2
DSS-24+ Unmanaged Fast Ethernet Switch
