D-Link DWR-922 User manual

Version 1.00 | 08/15/2014
User Manual
DWR-922
4G LTE Router

iD-Link DWR-922 User Manual
D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any
person or organization of such revisions or changes.
Manual Revisions
Trademarks
D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United
States or other countries. All other company or product names mentioned herein are trademarks or registered trademarks of
their respective companies.
Copyright © 2014 by D-Link Corporation.
All rights reserved. This publication may not be reproduced, in whole or in part, without prior expressed written permission
from D-Link Corporation.
Revision Date Description
1.00 August 15, 2014 • Initial release
Preface

iiD-Link DWR-922 User Manual
Table of Contents
Product Overview.............................................................. 1
Package Contents......................................................................... 1
System Requirements................................................................. 1
Introduction ................................................................................... 2
Hardware Overview..................................................................... 3
Front View................................................................................ 3
Back View................................................................................. 4
Installation ......................................................................... 5
Before You Begin........................................................................... 5
Wireless Installation Considerations...................................... 6
Conguration..................................................................... 7
Getting Started.............................................................................. 7
Internet............................................................................................. 8
WAN Service ........................................................................... 8
LTE/3G .................................................................................. 8
Ethernet WAN..................................................................10
PIN Conguration...............................................................15
Wi-Fi.................................................................................................16
Wireless Setup......................................................................16
Wireless Security ............................................................17
Add Wireless Device with WPS..................................18
WLAN MAC Filter.................................................................19
WLAN Performance............................................................20
LAN ..................................................................................................21
LAN Setup..............................................................................21
DHCP .......................................................................................22
Advanced ......................................................................................23
DNS ..........................................................................................23
Dynamic DNS .......................................................................24
Applications..........................................................................25
DMZ (Exposed Host)..........................................................26
Virtual Server........................................................................27
QoS...........................................................................................28
Parental Control ..................................................................29
Security...................................................................................30
Firewall...............................................................................30
DDoS & SPI .......................................................................31
Mac Filter ..........................................................................31
IGMP ........................................................................................32
SMS ..........................................................................................33
Voice........................................................................................34
Lines and Accounts .......................................................34
Phones and Devices......................................................37
Incoming Call Rules.......................................................39
Country Code ..................................................................40
Routing...................................................................................41
Samba.....................................................................................42
UPnP........................................................................................43
TR069 ......................................................................................44
System ............................................................................................46
Time Settings .......................................................................46
Table of Contents

iiiD-Link DWR-922 User Manual
Table of Contents
Administration.....................................................................47
System Settings...................................................................48
Firmware Update ................................................................49
System Log............................................................................50
Device Info ............................................................................51
Log Info ..................................................................................52
Statistics .................................................................................53
ARP Table Info ......................................................................54
Routing Table Info ..............................................................55
Connect a Wireless Client to your Router ......................56
WPS Button...................................................................................56
Windows® 8...................................................................................57
WPA/WPA2 ............................................................................57
Windows® 7...................................................................................59
WPA/WPA2 ............................................................................59
WPS..........................................................................................62
Windows Vista®............................................................................66
WPA/WPA2 ............................................................................67
Windows® XP................................................................................69
WPA/WPA2 ............................................................................70
Troubleshooting ..............................................................72
Wireless Basics .................................................................76
What is Wireless?.........................................................................77
Tips...................................................................................................79
Wireless Modes............................................................................80
Networking Basics...........................................................81
Check your IP address...............................................................81
Statically Assign an IP address...............................................82
Wireless Security ............................................................83
What is WPA? ...................................................................83
Technical Specications..................................................84

1D-Link DWR-922 User Manual
Section 1 - Product Overview
Product Overview
Package Contents
If any of the above items are missing, please contact your reseller.
System Requirements
* Subject to services and service terms available from your carrier.
• A compatible (U)SIM card with service.*
• Computer with Windows, Mac OS, or Linux-based operating system with an installed
Ethernet adapter
• Java-enabled browser such as Internet Explorer 6, Safari 4.0, Chrome 20.0, or Firefox 7
or above (for conguration)
Power Adapter
DWR-922 4G LTE Router
3G/4G Antennas
RJ-45 and RJ-11 Cables

2D-Link DWR-922 User Manual
Section 1 - Product Overview
Introduction
The D-Link 4G LTE Router allows users to access worldwide mobile broadband networks. Once connected, users can transfer
data, stream media, and send SMS messages. Simply insert your 3G / 4G SIM card, and share your 3G / 4G Internet connec-
tion through a secure 802.11n wireless network or using any of the four 10/100/1000 Ethernet ports.
Keep your wireless network safe with WPA/WPA2 wireless encryption. The DWR-922 utilizes dual-active rewalls (SPI and
NAT) to prevent potential attacks across the Internet, and includes MAC address ltering to control access to your network.
The 4G LTE Router can be installed quickly and easily almost anywhere. This router is great for situations where an impromp-
tu wireless network must be set up, or wherever conventional network access is unavailable.

3D-Link DWR-922 User Manual
Section 1 - Product Overview
Hardware Overview
Front View
1 Reset Button Press this button with an unfolded paperclip and hold for ten seconds to reset the device.
2 WAN LED Will be lit if an Internet connection is established, and will blink when data is being transferred.
3 LAN LEDs 1-4 Will be lit if an Ethernet connection is established, and will blink when data is being transferred.
4 WPS Button Press this button to initiate a newWPS connection. See AddWireless Device withWPS on page 18 for details.
5 Signal Strength LED Will blink red if there is no SIM card / signal. Solid red/amber/green indicates the signal strength.
6 VoIP LED Will be lit if a VoIP connection is active.
7 3G LED Will be lit if a 3G connection is established, and will blink when data is being transferred.
8 4G LED Will be lit if a 4G LTE connection is established, and will blink when data is being transferred.
9 SMS LED Will be solid green if the SMS inbox is full, or blinking if there is an unread new SMS message.
10 WLAN LED Will be lit if the wireless function is enabled, and will blink when wireless data is being transferred.
2 31 4
5 6 7 8 109

4D-Link DWR-922 User Manual
Section 1 - Product Overview
1 Ethernet LAN Ports For connection to a network-enabled desktop or notebook computer.
2Ethernet WAN Port For connection to a DSL/cable modem or router
3 SIM Card Slot Accepts a standard (U)SIM card for 3G/4G LTE connectivity.
4 Power Connector Connects to the included power adapter.
5 Power Button Turns the device on or o.
6 Phone Port For connection to a phone handset.
Back View
1 4 52 3 6

5D-Link DWR-922 User Manual
Section 2 - Installation
Before You Begin
Installation
This section will guide you through the installation process. Placement of the router is very important. Do not place the router in an enclosed area
such as a closet, cabinet, or in an attic or garage.
1. Ensure that your DWR-922 4G LTE Router is disconnected and powered o.
2. Insert a standard (U)SIM card into the SIM card slot on the back of the router as indicated by the SIM card logo next to the slot.The gold contacts
should face downwards.
Caution: Always unplug/power down the router before installing or removing the SIM card. Never insert or remove the SIM card while the router
is in use.
3. Insert your Internet/WAN network cable into the WAN port on the back of the router.
Note: The 3G/4G connection can also be used as a backup WAN. Once a backup is congured, the router will automatically use 3G / 4G for the
Internet connection if the Ethernet WAN is not available.
4. Insert the Ethernet cable into the LAN Port 1 on the back panel of the DWR-922 4G LTE Router and an available Ethernet port on the network
adapter in the computer you will use to congure the router.
Note: The DWR-922 4G LTE Router LAN Ports are Auto-MDI/MDIX, so both patch and crossover Ethernet cables can be used.
5. If you have a telephone handset and wish to use the DWR-922 to make VoIP calls, connect one end of the RJ-11 cable to your handset and the
other end to the phone port on the back panel of the DWR-922.
Note: Do not directly connect the DWR-922 to a telecommunication network or a building’s telephone socket.
6. Connect the power adapter to the socket on the back panel of your DWR-922 4G LTE Router. Plug the other end of the power adapter into a
wall outlet or power strip and turn the device on.
a. The Status LED will light up to indicate that power has been supplied to the router.
b. The LEDs on the front panel will ash on and o as the DWR-922 4G LTE Router performs initialization and Internet connection processes.
c. After a few moments, if a connection has been established, the following LEDs will turn solid green: Power, Status, WAN, WLAN, and any LAN
Port LEDs that are connected computers or other devices.

6D-Link DWR-922 User Manual
Section 2 - Installation
Wireless Installation Considerations
The DWR-922 can be accessed using a wireless connection from anywhere within the operating range of your wireless network. Keep in mind that
the quantity, thickness, and location of walls, ceilings, or other objects that the wireless signals must pass through may limit the range of the wireless
signal. Ranges vary depending on the types of materials and background RF (radio frequency) noise in your home or oce. The key to maximizing
the wireless range is to follow these basic guidelines:
1. Minimize the number of walls and ceilings between the D-Link router and other network devices. Each wall or ceiling can reduce your adapter’s
range from 3 to 90 feet (1 to 30 meters).
2. Be aware of the direct line between network devices. A wall that is 1.5 feet thick (0.5 meters), at a 45-degree angle appears to be almost 3 feet
(1 meter) thick. At a 2-degree angle it looks over 42 feet (14 meters) thick. Position devices so that the signal will travel straight through a wall
or ceiling (instead of at an angle) for better reception.
3. Try to position access points, wireless routers, and computers so that the signal passes through open doorways and drywall. Materials such as
glass, metal, brick, insulation, concrete, and water can aect wireless performance. Large objects such as sh tanks, mirrors, le cabinets, metal
doors, and aluminum studs may also have a negative eect on range.
4. If you are using 2.4 GHz cordless phones, make sure that the 2.4 GHz phone base is as far away from your wireless device as possible. The base
transmits a signal even if the phone is not in use. In some cases, cordless phones, X-10 wireless devices, and electronic equipment such as ceiling
fans, uorescent lights, and home security systems may dramatically degrade wireless connectivity.

7D-Link DWR-922 User Manual
Section 3 - Conguration
Conguration
To access the conguration utility, open a web-browser such as Internet Explorer and
enter the address of the router (http://dlinkrouter.local./or 192.168.1.1 by default).
To log in to the conguration utility, enter admin as the username, and then enter
the password. By default, the password is admin.
If you get a Page Cannot be Displayed error, please refer to the Troubleshooting
section for assistance.
Once you have successfully logged in, you will see the Home page. On this page
you can view information about your Internet connection, the wireless/LAN status,
and system information.
At the top of the page is a menu. Clicking on one of these icons will take you to the
appropriate conguration section.
On each page, ll out the desired settings and click Apply when you are done or
Reset to revert to the old settings.
Getting Started

8D-Link DWR-922 User Manual
Section 3 - Conguration
Internet
Select your Internet connection type: LTE/3G or Ethernet WAN.Layer2 WAN
Connection:
WAN Service
On this page you can congure your Internet connection. If you are not sure which settings to use, please contact your Internet Service Provider
(ISP).
LTE/3G
If Auto-Detection does not work, then try selecting Manual and
lling out the information (supplied by your LTE/3G ISP).
Select PAP, CHAP, or AUTO detection. The default authentication
method is AUTO.
Check the box to enable international LTE / 3G roaming.
Select either Always On, Connect on Demand, or Manual.
Enter a maximum idle time during which the Internet connection
is maintained during inactivity (if you selected Always On above,
this setting will have no eect).
Select Disable or Use Ping depending on the settings required
by your ISP. If you select Use Ping, set the ping interval and the IP
address to ping.
Dial-Up Prole:
Authentication:
Roaming:
Reconnect
Mode:
Maximum Idle
Time:
Keep Alive:

9D-Link DWR-922 User Manual
Section 3 - Conguration
Maximum Transmission Unit - you may need to change the MTU
for optimal performance with your ISP. The default value is 1500.
Check the box to enable Network Address Translation (NAT).
MTU:
NAT:

10D-Link DWR-922 User Manual
Section 3 - Conguration
Ethernet WAN
The hostname is optional but may be required by some ISPs. Leave
it blank if you are not sure.
Maximum Transmission Unit - you may need to change the MTU
for optimal performance with your ISP. The default value is 1500.
Check the box to enable Network Address Translation (NAT).
Check the box to enable IGMP proxy.
Check the box to enable PPPoE passthrough.
Check the box to enable IPv6 passthrough.
Check the box to clone your client’s MAC address to the WAN port.
If your ISP provided DNS server addresses to use, select Manual
DNS and enter the primary and (if applicable) secondary
addresses. Otherwise, select Auto DNS to automatically assign a
DNS server, or DNS Disabled to disable DNS.
Hostname:
MTU:
NAT:
IGMP Proxy:
Enable PPPoE
Passthrough:
Enable IPv6
Passthrough:
Clone MAC:
DNS Mode:
Select your Internet connection type from the list of options. This information cab
be obtained from your ISP. The page will update with the appropriate options for
the selection connection type.
Dynamic IP Address

11D-Link DWR-922 User Manual
Section 3 - Conguration
Enter the IP address provided by your ISP.
Enter the subnet mask provided by your ISP.
Enter the gateway address provided by your ISP.
Maximum Transmission Unit - you may need to change the MTU
for optimal performance with your ISP. The default value is 1500.
Check the box to enable Network Address Translation (NAT).
Check the box to enable IGMP proxy.
Check the box to enable PPPoE passthrough.
Check the box to enable IPv6 passthrough.
Check the box to clone your client’s MAC address to the WAN port.
If your ISP provided DNS server addresses to use, select Manual
DNS and enter the primary and (if applicable) secondary
addresses. Otherwise, select Auto DNS to automatically assign a
DNS server, or DNS Disabled to disable DNS.
IP Address:
Subnet Mask:
Gateway
Address:
MTU:
NAT:
IGMP Proxy:
Enable PPPoE
Passthrough:
Enable IPv6
Passthrough:
Clone MAC:
DNS Mode:
Static IP Address

12D-Link DWR-922 User Manual
Section 3 - Conguration
Enter the PPPoE username provided by your ISP.
Enter the PPPoE password provided by your ISP.
Enter the PPPoE service name provided by your ISP if applicable.
Enter the PPPoE access concentrator (AC) name provided by your
ISP if applicable.
If your ISP provided a static IP address, select Static IP Address,
otherwise leave this setting at the default, Dynamic IP Address.
If you selected Static IP Address above, enter the address
provided by your ISP here.
Maximum Transmission Unit - you may need to change the MTU
for optimal performance with your ISP. The default value is 1500.
Check the box to enable Network Address Translation (NAT).
Check the box to enable IGMP proxy.
Check the box to enable PPPoE passthrough.
Check the box to enable IPv6 passthrough.
Select either Always On, Connect on Demand, or Manual.
Username:
Password:
PPPoE Service
Name:
AC Name:
IP Control:
Static IP
Address:
MTU:
NAT:
IGMP Proxy:
Enable PPPoE
Passthrough:
Enable IPv6
Passthrough:
Connect Mode
Select:
PPPoE

13D-Link DWR-922 User Manual
Section 3 - Conguration
Enter a maximum idle time during which the Internet connection
is maintained during inactivity (if you selected Always On above,
this setting will have no eect).
Check the box to clone your client’s MAC address to the WAN port.
If your ISP provided DNS server addresses to use, select Manual
DNS and enter the primary and (if applicable) secondary
addresses. Otherwise, select Auto DNS to automatically assign a
DNS server, or DNS Disabled to disable DNS.
Maximum Idle
Time:
Clone MAC:
DNS Mode:

14D-Link DWR-922 User Manual
Section 3 - Conguration
If you selected Bridge Mode, there are no further settings to congure.
Bridge Mode

15D-Link DWR-922 User Manual
Section 3 - Conguration
PIN Conguration
On this page you can congure your SIM card’s PIN.
To change your SIM’s PIN, enter the new PIN in the PIN text eld. If you also wish
to enable or disable PIN protection, check Enable PIN protection. This will mean
that you have to input your PIN whenever a device using your SIM card is switched
on.
Click Apply when you are done.

16D-Link DWR-922 User Manual
Section 3 - Conguration
Wi-Fi
Check the box to enable the router’s wireless functionality.
Check Enable to enable Wi-Fi Protected Setup (WPS).
Displays the current WPS PIN. Click Generate New PIN to generate
a new WPS PIN, or Reset PIN to default to reset the WPS PIN to its
default value.
Displays the conguration status of WPS. If you want to revert to
uncongured status, select Reset to Uncongured.
Click this button to connect a wireless device using WPS. See
below for details.
Create a name for your wireless network using up to 32 characters.
Check the box if you do not want to broadcast the SSID of your
wireless network.
Select your country from the drop-down menu.
Wireless
Function Enable:
Wi-Fi Protected
Setup:
Current PIN:
Wi-Fi Protected
Status:
Add Wireless
Device with
WPS:
SSID:
Hide SSID:
Country:
Wireless Setup
On this page you can congure your wireless settings.
