D-Link DGE-530T User manual

2D-Link DGE-530T Quick Install Guide
System Requirements
• Acomputerwithanavailable32-bitPCIbusmasterslotoperating
at33MHz
• Windows®2000,2003,2008,XP,Vista®,7,Linux2.4.xandabove,
orMacOS10.2.xandabove
• 150MHzprocessorandatleast32MBofRAM
• 32MBfreeharddrivespace
• CD-ROMDrive
Package Contents
•D-LinkDGE-530TEthernetDesktopAdapter
•ManualandSoftwareonCD
•StandardandLowProleBrackets
•QuickInstallGuide
System Requirements
If any of the above items are missing, please contact your reseller.

2
3 D-Link DGE-530T Quick Install Guide
Installation
Package Contents
System Requirements
If any of the above items are missing, please contact your reseller.
Installation
Note: Install the drivers before installing the adapter into your
computer.
TurnonyourcomputerandInserttheD-LinkDGE-530TDriverCD
intheCD-ROMdrive.Thestep-by-stepinstructionsthatfolloware
showninWindows®XP.Thestepsandscreensaresimilarforthe
otherWindowsoperatingsystems.
IftheCDAutorunfunctiondoesnotautomaticallystartonyour
computer, go to Start>Run. In the run command box type
“D:\DGE530T.exe”(whereD:representsthedriveletterofyour
CD-ROMdrive).
Drivers for non-Windows operating systems are located on the
D-LinkCD.
When the autorun screen appears, click Install Drivers (this will
launch the Network Utility program and install the drivers). An
Installation Wizard will guide you through the process, no matter
whichoperatingyouarerunning.YourDGE-530Twillbeinstalled
successfullyinjustafewmoments,allowingyoutoenjoythemany
advantagesofjoininganEthernetLAN.

4D-Link DGE-530T Quick Install Guide
Installation
Once your computer is turned off, remove the power cable from
thecomputer.OpenthecaseandinserttheD-Linkadapterintoan
availablePCIslot.
Note: Write down the serial number and hardware revision (e.g. B1)
before installing the adapter. If you contact technical support, you will
need this information.
Oncetheinstallationiscomplete,clickOKtonish.
Shutdownyourcomputer.GotoStart>Shut Down>selectShut
DownandclickOK.
Replace the case, plug in the power cable, and power on your
computer.

4
5 D-Link DGE-530T Quick Install Guide
Installation
Onceyou bootyour computer,Windows®willautomaticallyinstall
thedrivers.
Windows XP users:YouwillreceiveabubblestatingthatWindows
foundtheDGE-530Tadapter.
Windows® 7/Vista® users:YouwillreceiveabubblestatingWindows
hasnishedinstallingtheDGE-530Tadapter.

6D-Link DGE-530T Quick Install Guide
Verify Installation
Configure your Adapter
Toverifythatthedriversareinstalled,youmayviewDeviceManager.
Toviewthedevicemanager,pleasefollowthestepsbelow:
Step 1:
Windows®2000:Clickon Start > Settings > Control Panel
WindowsXP:Clickon Start > Control Panel
Windows®7/Vista®:Clickon Start > Control Panel
Step 2:
Windows®2000/XP:Clickonthe System icon.Clickthe Hardware
tab andthenclick Device Manager.
WindowsVista®:Clickonthe System and Maintenance iconand
thenclickon Device Manager.
Windows7®:Clickonthe System and Security iconandthenclick
on Device Manager underSystem.
Step 3:
Scrolldownandclicktheplus(+)signnextto Network Adapters. The
D-Link DGE-530T Gigabit Ethernet Adapter (rev.B) willbelisted.
Verify Installation

6
7 D-Link DGE-530T Quick Install Guide
Configure your Adapter
Configure your Adapter
After you install your new D-Link adapter, by default, the TCP/IP
settingsshouldbesettoobtainanIPaddressfromaDHCPserver
(i.erouter)automatically.ToverifyyourIPaddress,pleaseseethe
followingstepsbelow.
Windows®2000/2003/XP:ClickonStart > Run.Intherunboxtype
cmdandclickOK.
Windows®7/Vista®:ClickonStart > All Programs > Accessories
> Command Prompt.
Attheprompt,typeipconfigandpressEnter.
ThiswilldisplaytheIPaddress,subnetmask,andthedefaultgateway
ofyouradapter.
If the address is 0.0.0.0, check your adapter installation, security
settings, and the settings on your router. Some rewall software
programsmayblockaDHCPrequestonnewlyinstalledadapters.

8D-Link DGE-530T Quick Install Guide
Configure your Adapter
IfyouarenotusingaDHCPcapablegateway/router,oryouneedto
assignastaticIPaddress,pleasefollowthestepsbelow.
Step 1:
Windows® 2000: Click on Start>Settings>Control Panel >
Network Connections
Windows® XP: Click on Start>Control Panel > Network
Connections
Windows Vista®: Click on Start > Control Panel > Network and
Internet > Network and Sharing Center > Manage network
connections
Windows®7:ClickonStart>Control Panel > Network and Internet
> Network and Sharing Center > Change Adapter Settings
Step 2:
Right-clickontheLocal Area Connection,whichrepresentsyour
D-Linknetworkadapter,andselectProperties.
Step 3:
HighlightInternet Protocol (TCP/IP)andclickProperties.
Step 4:
ClickUse the following IP addressandenteranIPaddressthat
isonthesamesubnetasyournetworkortheLANIPaddresson
yourrouter.
Example:Iftherouter’sLANIPaddressis192.168.0.1,makeyour
IPaddress192.168.0.X where X isa number between 2and99.
Makesurethatthenumberyouchooseisnotinuseonthenetwork.
SetDefaultGatewaythesameastheLANIPaddressofyourrouter
(192.168.0.1).

8
9 D-Link DGE-530T Quick Install Guide
Configure your Adapter
SetPrimaryDNSthesameastheLANIPaddressofyourrouter
(192.168.0.1).TheSecondaryDNSisnotneededoryoumayenter
aDNSserverfromyourISP.
Step 5:
ClickOKtwicetosaveyoursettings.

10D-Link DGE-530T Quick Install Guide
Notes
Notes

10
11 D-Link DGE-530T Quick Install Guide
Notes
Notes

12D-Link DGE-530T Quick Install Guide
Technical Support
D-Link’swebsitecontainsthelatestuserdocumentationandsoftware
updatesforD-Linkproducts.
U.S.andCanadiancustomerscancontactD-LinkTechnicalSupport
throughourwebsiteorbyphone.
United States
Telephone
(877)453-5465
World Wide Web
http://support.dlink.com
Canada
Telephone
(800)361-5265
World Wide Web
http://support.dlink.ca
Version2.6
March12,2010
6DGE530TQB04G
