D-Link UpLink Newsletter
February 2002
>>>>>>>>>>NEW D-LINK PRODUCTS<<<<<<<<<<
D-LINK DELIVERS AFFORDABLE BROADBAND AND DIGITAL VIDEO PRODUCTS IN FEBRUARY
D-Link is the first-to-market with a Wireless Internet Video Camera and introduces an affordable and easy-
to-use Cable Modem with USB support. Read on for details…
DCS-1000W - With the D-Link DCS-1000W, you can remotely monitor your home or
office via the Internet through any Java-enabled Web browser. The DCS-1000W
provides an auto-sensing Fast Ethernet 10/100 Mbps port to connect to your network
through Ethernet cable as well as built-in 802.11b Wireless Ethernet for connection to
a Wireless network. Additional advanced features provide security, easy set up, and
flexible configuration.
DCM-200 – The DCM-200 is a two-way DOCSIS™ 1.0 CableLabs® Certified™
Ethernet 10BaseT Cable Modem. The DCM-200 provides high-speed Internet access
over a cable network and can connect to a computer via its Ethernet or USB port. For
security purposes, the DCM-200 provides 56-bit DES (Data Encryption Standard) to
encrypt data transaction for both upstream and downstream transmission plus it is
easy to install and is compatible with most operating systems.
DGE-550SX – The DGE-550SX Fiber Gigabit adapter is a high-bandwidth network
adapter, providing up to 2000Mbps full-duplex bandwidth capacity to support high-end
servers. This adapter delivers added performance to the network while working with
the existing LAN infrastructure. With advanced functions like VLAN filtering and Chip-
Level IP (CLIP) packet processing, the DGE-550SX provides added performance,
flexible configuration and secure networking in a standards-based environment.
INDOOR/OUTDOOR ANTENNA KITS - In addition to the above products D-Link is introducing an entire
suite of Antenna kits to extend the reach of Wireless LANs. These antenna kits are sold as accessories for
D-Link Wireless Access Points and include versions for both indoor and outdoor use.
• ANT24-0401 - 4dBi Ceiling Mounted Indoor Antenna
• ANT24-0500 - 5dBi Omi-Directional Indoor Antenna
• ANT24-0801 - 8.5dBi Pico Cell Patch Antenna
• ANT24-1400 - 14dBi Directional Outdoor Patch Antenna
• ANT24-1800 - 18dBi Directional Outdoor Panel Antenna
• ANT24-1801 - 18dBi Outdoor Yagi Antenna
>>>>>>>>>>PRICING UPDATES<<<<<<<<<<
NEW PRODUCTS, NEW PRICING
Check out the pricing on the new D-Link products shipping in February.
D-Link Part # Description MSRP
DCS-1000W Wireless Internet Camera 802.11b $499.99
DCM-200 Cable Modem USB/Ethernet DOCSIS 1.x $149.99
DGE-550SX Gigabit Fiber Network Adapter $329.99
ANT24-0401 4dBi Ceiling Mounted Indoor Antenna $119.99
ANT24-0500 5dBi Omi-Directional Indoor Antenna $109.99
ANT24-0801 8.5dBi Pico Cell Patch Antenna $169.99
ANT24-1400 14dBi Directional Outdoor Patch Antenna $249.99
ANT24-1800 18dBi Directional Outdoor Panel Antenna $319.99
ANT24-1801 18dBi Outdoor Yagi Antenna $319.99
D-Link UpLink Newsletter 1 February 2002

D-LINK DELIVERS SAVINGS WITH SEVERAL PRICE REDUCTIONS IN FEBRUARY
D-Link is pleased to announce price reductions on several of our popular Wireless products, Broadband
Solutions, and Digital Audio and Video products effective February 4, 2002.
D-Link
Part # Description New Price
DWL-120 Wireless USB Adapter 802.11b
DCF-650W Wireless CompactFlash PDA Adapter Type II 802.11b
DI-713P Wireless Cable/DSL Router, Access Point, 3-Port Switch, Print Server
DI-714 Wireless Cable/DSL Router, Access Point, 4-Port Switch
DWL-905 Wireless Network Kit – 1 AP + 2 PC Cards 802.11b
DWL-910 Wireless USB Kit – 1 AP + 1 USB Adapter 802.11b
DWL-920 Wireless USB Kit – 1 AP + 2 USB Adapter 802.11b
DCM-100 Cable Modem Ethernet DOCSIS 1.x
DI-707 Cable/DSL Router w/7-Port Switch
DCF-560M 56K V.90 CompactFlash PDA Modem w/RJ11 Port
DP-101P+ 10Base-T Print Server 1-Parallel Port
DSB-C100 USB Digital Video Camera
DMP-210 Roq-it USB Portable MP3 Player w/32MB + Smart Media Slot
Please contact
your Distributor
for revised
pricing.
D-LINK ADJUSTS THE PRICE ON OUR PORTABLE HARD DRIVE/MP3 PLAYER
Due to unforeseen circumstances, D-Link regrettably will be increasing the price on our DMP-HD610
Portable Hard Drive/MP3 player effective February 4, 2002.
D-Link
Part # Description New Price
DMP-HD610 Roq-it Portable 10GB Hard Drive/MP3 Player Please contact your Distributor
for revised pricing.
>>>>>>>>>>DISCONTINUED PRODUCTS<<<<<<<<<<
KEEP UP-TO-DATE ON CURRENT D-LINK PRODUCTS
In an ongoing effort to provide our partners and customers with the most current networking solutions, D-
Link has discontinued the following products (includes recommended replacement products):
D-Link
Part # Description
Recommended
Replacement
DSH-5 5-Port 10/100 Dual Speed Hub with Switch DSS-5+
DSH-8 8-Port 10/100 Dual Speed Hub with Switch DSS-8+
DSH-16 16-Port 10/100 Dual Speed Hub with Switch DSS-16+
DE-528CT Ethernet Combo PCI NIC, 32-bit, Bus Slave DFE-530TX+
DGE-500SX Gigabit Fiber Network Adapter DGE-550SX
DSC-350 Digital Camera w/8MB Memory DSC-350F
DMP-CD100 Portable MP3 Based CD Player DMP-CD200
>>>>>>>>>>PROMOTIONS<<<<<<<<<<
ANNOUNCING UNBELIEVABLE OFFERS ON D-LINK HIGH END SWITCHING SOLUTIONS
D-Link has a complete line of high end switching solutions that include modular, chassis-based switches,
Layer 3 switches, and high-speed gigabit over copper switches. Plus, for a limited-time, D-Link is running
several promotions on our switch line that can save users hundreds of dollars! Additional information on
these promotions follows below.
D-Link UpLink Newsletter 2 February 2002

Buy a D-Link DGS or DES Series Switch, Get a Secure-Link Lifetime Warranty Free!
D-Link is an award-winning developer of networking solutions and our innovative manufacturing process
allows us to bring high quality networking hardware to market at an affordable price. We stand behind our
commitment to quality and are pleased to offer, for a limited time, a free Secure-Link Lifetime Warranty with
the purchase of all our DGS and DES Series switches. The Secure-Link Lifetime Warranty extends the
original product warranty to lifetime and includes benefits like advance hardware replacement, priority
technical support, and convenient access to software and firmware updates.
A sample of the switches that are part of this offer include:
•DES-6000 – 10/100/1000 8 Open Slot Chassis Switch
•DES-3326 - 24-Port 10/100, Layer 3, Managed Switch w/Opt. 2-port GBIC
•DES-3225G – 24-Port 10/100, Standalone, Layer 2, Managed Switch
•DGS-3208TG – 6-Port Copper Gigabit Switch w/2-Port GBIC
Below is a sample of your savings with this special offer:
Part # Description MSRP
DES-6000-LW Secure-Link Lifetime Warranty for DES-6000 $840.00
DES-3326-LW Secure-Link Lifetime Warranty for DES-3326 $840.00
DES-3225G-LW Secure-Link Lifetime Warranty for DES-3325G $378.00
DGS-3208TG-LW Secure-Link Lifetime Warranty for DES-3208TG $982.50
Buy a D-Link DGS-1008T Gigabit Switch, Get a DGE-500T Gigabit Ethernet Adapter Free!
The DGS-1008T is a high performance 8-Port 10/10/1000 Gigabit
Switch. Designed as a seamless migration of Ethernet and Fast
Ethernet networks, the DGS-1008T provides gigabit speeds at an
affordable price. Now the DGS-1008T is an even better deal
because for a limited-time, D-Link is pleased to offer the DGE-500T
Gigabit Ethernet Adapter Free with purchase.
Part # Description Free Adapter
DGS-1008T 10/10/1000 8-Port Gigabit
Switch
DGE-500T – 10/100/1000 Gigabit Ethernet
Adapter
Dramatically Increase the Performance Of Your Network With the D-Link Gigabit Bundle
D-Link has several Gigabit Ethernet Solutions designed to meet your need for additional network
bandwidth. We want to provide affordable Gigabit Ethernet solutions so for a limited-time, D-Link is offering
a special Gigabit Bundle providing you three key tools for a high-speed network at one very low price.
The D-Link Gigabit Ethernet Bundle includes:
•DGS-3208TG – 6-Port 1000BASE-T Gigabit Over Copper Layer 2,
Managed Switch w/Optional 2-Port GBIC
•DES-1009G - 8-Port 10/100 Mbps Ethernet Switch with 1000Base-T
Copper Uplink
•DGE-500T – 32-bit 10/100/1000 Gigabit Ethernet Adapter
D-Link UpLink Newsletter 3 February 2002

Purchase Two D-Link DES-5224TX Switches For One Low Price – An Estimated Savings of $1299!
The DES-5224TX is a high performance modular switch designed for
departmental connection. This switch offers high density of auto-sensing
10/100 Mbps ports for reliable server connection, and advanced functions
for network management. With 1000 Mbps Gigabit options, the switch
can also connect to high-speed enterprise or campus backbones linking
departments together. D-Link is now providing a perfect opportunity to
upgrade your network infrastructure with two of the D-Link DES-5224TX
switches for the price of one. This special offer can save you over $1200!
MAIL-IN REBATE OFFERS ON OUR TOP SELLING PRODUCTS CONTINUE IN FEBRUARY
D-Link is continuing to provide our partners with the best offers possible on D-Link products. To help you
sell even more of our Networking and USB products, D-Link is offering mail-in-rebates on several top selling
items during the first quarter of 2002. See the following promotion descriptions for additional information.
D-Link Makes Wireless Networking Affordable
D-Link makes Wireless Networking easy – and affordable! Starting January 1, 2002 D-Link is offering mail-
in rebates on our top-selling Wireless Networking products like our Wireless PC Card Adapter, Wireless
USB Adapter, and the innovative Wireless Cable/DSL Router with Print Server. Or save on our Wireless
Access Point – a PC Magazine Editors’ Choice. The rebates on these products follow below:
D-Link Part # Description Mail-in Rebate
DWL-650 Wireless PC Card Adapter $10.00
DWL-500 Wireless PC Card w/ PCI Adapter $10.00
DWL-520 Wireless PCI Adapter – NEW! $10.00
DWL-120 Wireless USB Adapter $10.00
DWL-1000AP Wireless Access Point $20.00
DI-713P Wireless Cable/DSL Router w/Print Server $20.00
Share a Broadband Connection, Get $20
D-Link is pleased to offer a $20 Mail-in rebate on two of our popular Residential Gateway products (DI-704
and DI-704P). These products meet the needs of a growing number of users that want to share a
Broadband connection as well as provide a secure connection to the Internet. The rebates on these
products follow below:
D-Link Part # Description Mail-in Rebate
DI-704 Cable/DSL Router w/4-port Switch $20.00
DI-704P Cable/DSL Router w/4-port Switch + Print Server $20.00
“Our Award, Your Reward” Mail-in Rebate Promotion
Our Award, your reward! To celebrate our PC Magazine Editors’ Choice Award
on the DSS-24+ - our 24-port Fast Ethernet Switch – D-Link is offering mail-in
rebates on all of our DSS-series switches including the 5-port, 8-port and 16-port
versions. End users save a $1 per port after mail-in rebate! The rebates on
these products follow below:
D-Link Part # Description Mail-in Rebate
DSS-5+ 5-Port Desktop Switch $5.00
DSS-8+ 8-Port Desktop Switch $8.00
DSS-16+ 16-Port Desktop Switch $16.00
DSS-24+ 24-Port Fast Ethernet Switch $24.00
D-Link UpLink Newsletter 4 February 2002

Spend Less to Get More USB Ports from D-Link
Digital cameras, printers, scanners, keyboards, and storage devices. The more peripherals we add, the
fewer USB ports become available. D-Link has the answer with our DSB-H4 and DSB-H7 Hubs. And for a
limited time these Hubs are even more cost-effective with a $10 mail-in rebate on the DSB-H4 (4-port USB
Hub) and a $20 Mail-in rebate on the DSB-H7 (7-port USB Hub). Specific information on these products
follows below:
D-Link Part # Description Mail-in Rebate
DSB-H4 USB 4-port Hub $10.00
DSB-H7 USB 7-port Hub $20.00
>>>>>>>>>>SELLING TIPS AND TOOLS<<<<<<<<<<
HELP FOR THE NETWORKING NOVICE WITH THE “D-LINK NETWORK CONFIGURATOR”
Cable, DSL, Wireless, Switches, NICs… How do they all fit together? D-Link now has the answer with the
D-Link Network Configurator – a Web-based, interactive tool that walks the end user through the process of
building a home network. The Configurator takes into account a user’s needs and environment and
recommends a D-Link solution based on this information. This tool is also available for use by D-Link’
reseller partners so if you would like more information on this innovative tool please contact your D-Link
Account Representative.
The D-Link Network Configurator can be found at: www.d-linkshop.com
ATTENTION RESELLER PARTNERS: GET D-LINK PRODUCTS AT A DISCOUNT
D-Link is happy to offer our valued partners a way to purchase select D-Link products at a significant
discount for evaluation purposes and/or for personal use. These products are not for resale, and orders are
restricted only to eligible D-Link partners. Eligible partners may only purchase limited quantities of select D-
Link products.
For more information on the D-Link Partner Purchase Program please contact your D-Link Account
Representative.
>>>>>>>>>>RECENT PRESS AND AWARDS<<<<<<<<<<
CNET EDITORS’ MAKE D-LINK A TOP FIVE PICK
The D-Link DI-714 Wireless Cable/DSL Router is Number 2 on the CNET “Editors’ Top 5” List in the
Networking category. The editors praised the DI-714 saying “if you want to share broadband Internet
access, the DI-714 wireless router provides one of the best solutions we've seen for SOHO hybrid wireless-
Ethernet networks.”
The complete review can be found at:
http://computers.cnet.com/hardware/0-7052-404-5606139.html?tag=topfive
D-LINK RECEIVES SIGNIFICANT PRESS COVERAGE IN THE LATEST ISSUE OF PC MAGAZINE
In the February 12 issue of PC Magazine D-Link received tremendous coverage on key products including
the DI-704P and DI-714. Some quotes from the issue include:
“The D-Link DI-704P is a complete and well-conceived product.” “The browser-based configuration
interface helps get new users started quickly.”
“The DI-714…includes an excellent setup wizard.” “(The DI-714) comes with an above-average manual
and a CD-ROM with a helpful video geared to first-time networkers.”
That’s all for February! For more information on D-Link products visit our Web site at
www.dlink.com or contact your D-Link representative at 800-326-1688.
D-Link UpLink Newsletter 5 February 2002
