D-Link DCS-4603 User manual

This document will guide you through the
basic installation process for your new
D-Link Network Camera.
DCS-4603
Documentation also available on
CD and via the D-Link Website
Quick Installation Guide
Vigilance Full HD PoE Dome Camera
Quick Installation Guide
Installationsanleitung
Guide d’installation
Guía de instalación
Guida di Installazione
Краткое руководство по установке
Guia de Instalação Rápida
快速安裝指南
Petunjuk Pemasangan Cepat

D-Link DCS-4603 Quick Installation Guide 1
ENGLISH
Quick Installation Guide
This installation guide provides basic instructions for installing the Network
Camera on your network. For additional information about how to use the
camera, please see the User Manual which is available on the CD included in
this package or from the D-Link support website.
Package Contents
DCS-4603 Vigilance Full HD PoE Dome Camera
Mounting Kit
Manual and Software on CD-ROM
Quick Installation Guide
If any of the above items are missing, please contact your reseller.
Safety Notice:
Installation and servicing should be done by certified technicians so as to
conform to all local codes and prevent voiding your warranty.

D-Link DCS-4603 Quick Installation Guide
2
ENGLISH
Hardware Overview
IR LEDs
Provide illumination for
low-light environments
Camera Lens
Reset Button
Resets camera back
to the factory default
settings
Ethernet Jack
RJ-45 connector for Ethernet which can also be used
to power the camera using Power over Ethernet (PoE)
Power Connector
Connects to an optional 12 V / 1.5 A
power adapter (not included)
Camera Cover Cover Screws
The three screws can
be removed with the
included wrench
Tilt Adjustment Screw
Can be loosened to
adjust camera angle
Inner Cover

D-Link DCS-4603 Quick Installation Guide 3
ENGLISH
Conguring the Camera
Insert the DCS-4603 CD into your computer's CD-ROM drive to begin the
installation. If the Autorun function on your computer is disabled, or if the
D-Link Launcher fails to start automatically, click the Start button and type D:\
autorun.exe (where D: represents the drive letter of your CD-ROM drive) and
press Enter.
Click on the D-Link Setup Wizard SE icon that
was created in your Windows Start menu (Start >
D-Link > Setup Wizard SE).
The Setup Wizard will appear and display the MAC
address and IP address of your camera(s). If you
have a DHCP server on your network, a valid IP
Address will be displayed. If your network does not
use a DHCP server, the network camera's default
static IP 192.168.0.20 will be displayed.
Select your camera, then click the Wizard button to
continue.
Click Setup Wizard and follow the instructions to
install the Setup Wizard.
Enter the Admin ID and password. When logging in
for the first time, the default Admin ID is admin with
the password left blank.
Click the checkboxes if you wish to change the
admin ID and password for the camera, and enter
the new ID and password you wish to use.
Click Next to continue.
Select DHCP if your camera obtains an IP address
automatically from a DHCP server such as a router.
Select Static IP if you want to manually enter the IP
settings for the camera.
Click Next to continue.

D-Link DCS-4603 Quick Installation Guide
4
ENGLISH
Viewing Your Camera via Web Browser
Click on the D-Link Setup Wizard SE icon that
was created in your Windows Start menu (Start >
D-Link > Setup Wizard SE).
Select the camera and click Link to access the web
configuration.
The Setup Wizard will automatically open your web
browser to the IP address of the camera.
This section displays your camera’s live video. You
can select your video profile and view or operate
the camera. For additional information about web
configuration, please refer to the user manual,
which is available on the D-Link website.
Enter admin as the default username and leave the
password blank. Click OK to continue.
Take a moment to confirm your settings and click
Restart.

D-Link DCS-4603 Quick Installation Guide 5
ENGLISH
Mounting Instructions
It is highly recommended that you configure and test your camera before
mounting it.
Place the mounting sticker where you want to
position the camera.
Use a 6 mm drill bit to make the required holes
approximately 25 mm deep, then insert the wall
anchors into the holes.
If you are running the camera cables through
the wall, drill a hole in the center and pull the
cables through the hole.
Use the included wrench to loosen the 3 screws on
the top of the camera, then lift the camera cover off.
Use the screws provided to mount the camera to
the wall.
If you are running the camera cables out the
side of the camera, guide the camera cables
through the cable channel on the base.

D-Link DCS-4603 Quick Installation Guide
6
ENGLISH
Connect the power and Ethernet cables, or just the
Ethernet cable if you are using a PoE connection.
Reattach the camera cover.
To adjust the camera's angle, pull the black inner
cover and remove it from the camera.
Loosen the adjustment screw on the side of the
camera, then retighten it after moving the camera to
the desired angle. You can also rotate the camera
by grasping the camera and turning it left or right.
When you are done adjusting the camera's angle,
put the inner cover back into place.
Note: The camera has a limited range of motion; if
it stops when you are adjusting it, do not attempt to
rotate or tilt the camera any further in that direction.
60
O
340
O
340
O

D-Link DCS-4603 Quick Installation Guide 7
ENGLISH
Using the DCS-37-1 Mount (optional)
Use the provided screws to mount the DCS-37-1 to
the wall.
Place the DCS-37-1 mounting sticker in the
desired location, then use a 6 mm drill bit to drill
the required holes 25 mm deep and insert the wall
anchors into the holes. If you plan to pass cables
through the wall, you will also need to drill a hole for
the cable channel.
Remove the cover from the camera.
Pass the camera connectors through the back
or bottom cable channel on the DCS-37-1. Use
the provided screws to mount the camera to
the DCS-37-1 using the set of mounting holes
marked A.
Remove the inner cover and adjust the angle and
rotation of the camera as desired, then put the inner
cover back in place.
Attach the camera cover.
If you are passing the camera cables through the
wall, place the rubber stopper into the bottom cable
channel to seal it.

D-Link DCS-4603 Quick Installation Guide
8
ENGLISH
Using the DCS-37-2 Mount (optional)
Use the provided screws to mount the DCS-37-2 to the wall
using the inner mounting holes.
Place the DCS-37-2 mounting sticker in the desired location,
then use a 6 mm drill bit to drill the required holes 25 mm
deep and insert the wall anchors into the holes. If you plan to
pass cables through the wall, you will also need to drill a hole
for the cable channel.
Remove the cover from the camera.
Pass the camera connectors through the back or side cable
channel on the DCS-37-2. Use the provided screws to mount
the camera to the DCS-37-2 using the set of mounting holes
marked A.
Remove the inner cover and adjust the angle and rotation
of the camera as desired, then put the inner cover back in
place.
Attach the camera cover.
If you are passing the camera cables through the wall, place
the rubber stopper into the bottom cable channel to seal it.
Additional Information
Additional help and product information is available online
at http://www.dlink.com.
Warranty Information
Please visit http://warranty.dlink.com/ for warranty
information for your region.
