D-Link 5000 Series Instruction Manual

Draft 1.2.1

5000 Series Layer 2/3 Managed Data Center Switch CLI Reference Guide
i
Table of Contents
About This Guide................................................................................................................................................................. 1
Objective and Audience .................................................................................................................................................. 1
Acronyms and Abbreviations .......................................................................................................................................... 1
Guide Conventions.......................................................................................................................................................... 5
1. About D-LINK OS Software.............................................................................................................................................7
About D-LINK OS Software.................................................................................................................................................. 7
Product Concept ............................................................................................................................................................. 7
2. Using the Command-Line ...............................................................................................................................................8
Command Syntax ................................................................................................................................................................ 8
Command Conventions....................................................................................................................................................... 8
Common Parameter Values ................................................................................................................................................ 9
Slot/Port Naming Convention............................................................................................................................................. 9
Using the No Form of a Command.................................................................................................................................... 10
Executing Show Commands.............................................................................................................................................. 11
CLI Output Filtering ........................................................................................................................................................... 11
3. D-LINK OS Modules......................................................................................................................................................12
Command Modes.............................................................................................................................................................. 12
Command Completion and Abbreviation ......................................................................................................................... 15
CLI Error Messages............................................................................................................................................................ 16
CLI Line-Editing Conventions............................................................................................................................................. 16
Using CLI Help ................................................................................................................................................................... 17
Accessing the CLI............................................................................................................................................................... 18
4. Management Commands..............................................................................................................................................19
Network Interface Commands.......................................................................................................................................... 19
IPv6 Management Commands.......................................................................................................................................... 26
Console Port Access Commands ....................................................................................................................................... 41
Telnet Commands ............................................................................................................................................................. 44
Secure Shell Commands.................................................................................................................................................... 48
Management Security Commands.................................................................................................................................... 51
Access Commands............................................................................................................................................................. 52
AAA Commands ................................................................................................................................................................ 54
User Account and Password Commands .......................................................................................................................... 67
SNMP Commands ............................................................................................................................................................. 83

5000 Series Layer 2/3 Managed Data Center Switch CLI Reference Guide
ii
RADIUS Commands ......................................................................................................................................................... 105
TACACS+ Commands....................................................................................................................................................... 122
Configuration Scripting Commands ................................................................................................................................ 127
Pre-login Banner, System Prompt, and Host Name Commands..................................................................................... 130
Front Panel TAP Interfaces.............................................................................................................................................. 133
5. Utility Commands........................................................................................................................................................136
Application Commands................................................................................................................................................... 137
CLI Output Filtering Commands...................................................................................................................................... 140
System Information and Statistics Commands ............................................................................................................... 142
Logging Commands......................................................................................................................................................... 183
Email Alerting and Mail Server Commands .................................................................................................................... 195
System Utility and Clear Commands............................................................................................................................... 205
IP Address Conflict Commands ....................................................................................................................................... 216
Serviceability Packet Tracing Commands ....................................................................................................................... 218
sFlow Commands ............................................................................................................................................................ 272
Switch Database Management Template Commands.................................................................................................... 282
SFP Transceiver Commands ............................................................................................................................................ 284
Remote Monitoring Commands ..................................................................................................................................... 287
Spanning Tree Protocol Commands................................................................................................................................ 309
VLAN Commands............................................................................................................................................................. 340
Switch Ports .................................................................................................................................................................... 352
Double VLAN Commands................................................................................................................................................ 357
Provisioning (IEEE 802.1p) Commands ........................................................................................................................... 360
Protected Ports Commands............................................................................................................................................ 361
Port-Based Network Access Control Commands............................................................................................................ 363
802.1X Supplicant Commands ........................................................................................................................................ 377
Task-based Authorization ............................................................................................................................................... 379
Asymmetric Flow Control Commands ............................................................................................................................ 387
Storm-Control Commands .............................................................................................................................................. 388
Link Dependency Commands.......................................................................................................................................... 397
MVR Commands ............................................................................................................................................................. 403
Port-Channel/LAG (802.3ad) Commands........................................................................................................................ 411
VPC Commands............................................................................................................................................................... 431
Port Mirroring ................................................................................................................................................................. 448
Static MAC Filtering......................................................................................................................................................... 455

5000 Series Layer 2/3 Managed Data Center Switch CLI Reference Guide
iii
DHCP L2 Relay Agent Commands ................................................................................................................................... 460
DHCP Client Commands.................................................................................................................................................. 466
DHCP Snooping Configuration Commands ..................................................................................................................... 468
Dynamic ARP Inspection Commands .............................................................................................................................. 481
IGMP Snooping Configuration Commands ..................................................................................................................... 489
IGMP Snooping Querier Commands ............................................................................................................................... 499
MLD Snooping Commands.............................................................................................................................................. 503
MLD Snooping Querier Commands ................................................................................................................................ 513
Port Security Commands................................................................................................................................................. 517
LLDP (802.1AB) Commands............................................................................................................................................. 525
LLDP-MED Commands .................................................................................................................................................... 539
Denial of Service Commands .......................................................................................................................................... 547
MAC Database Commands ............................................................................................................................................. 557
ISDP Commands .............................................................................................................................................................. 561
Unidirectional Link Detection Commands ...................................................................................................................... 568
Interface Error Disable and Auto Recovery .................................................................................................................... 573
6. Data Center Commands .............................................................................................................................................576
Data Center Bridging Exchange Protocol Commands..................................................................................................... 576
Quantized Congestion Notification Commands.............................................................................................................. 581
FIP Snooping Commands ................................................................................................................................................ 591
Priority-Based Flow Control Commands ......................................................................................................................... 596
OpenFlow Commands..................................................................................................................................................... 600
NVGRE/VXLAN Commands ............................................................................................................................................. 612
7. IPv4 Routing Commands............................................................................................................................................630
Address Resolution Protocol Commands........................................................................................................................ 630
IP Routing Commands..................................................................................................................................................... 638
IP Event Dampening Commands..................................................................................................................................... 672
Routing Policy Commands .............................................................................................................................................. 674
Router Discovery Protocol Commands ........................................................................................................................... 697
Virtual Router Commands............................................................................................................................................... 702
Virtual LAN Routing Commands...................................................................................................................................... 706
Virtual Router Redundancy Protocol Commands ........................................................................................................... 709
DHCP and BOOTP Relay Commands ............................................................................................................................... 720
IP Helper Commands....................................................................................................................................................... 723
Open Shortest Path First Commands.............................................................................................................................. 730

5000 Series Layer 2/3 Managed Data Center Switch CLI Reference Guide
iv
General OSPF Commands ........................................................................................................................................... 730
OSPF Interface Commands.......................................................................................................................................... 756
OSPF Graceful Restart Commands.............................................................................................................................. 763
OSPFv2 Stub Router Commands ................................................................................................................................. 765
OSPF Show Commands ............................................................................................................................................... 767
ICMP Throttling Commands............................................................................................................................................ 794
Bidirectional Forwarding Detection Commands............................................................................................................. 796
8. IPv6 Routing Commands............................................................................................................................................804
Loopback Interface Commands ...................................................................................................................................... 804
Tunnel Interface Commands........................................................................................................................................... 805
IPv6 Routing Commands ................................................................................................................................................. 808
OSPFv3 Commands ......................................................................................................................................................... 851
Global OSPFv3 Commands.......................................................................................................................................... 851
OSPFv3 Interface Commands...................................................................................................................................... 872
OSPFV3 Graceful Restart Commands.......................................................................................................................... 878
OSPFv3 Stub Router Commands ................................................................................................................................. 880
OSPFv3 Show Commands ........................................................................................................................................... 882
DHCPv6 Commands ........................................................................................................................................................ 901
DHCPv6 Snooping Configuration Commands ................................................................................................................. 916
9. IP Multicast Commands ..............................................................................................................................................931
Multicast Commands ...................................................................................................................................................... 931
DVMRP Commands ......................................................................................................................................................... 944
PIM Commands............................................................................................................................................................... 951
Internet Group Message Protocol Commands ............................................................................................................... 970
IGMP Proxy Commands .................................................................................................................................................. 980
10. IPv6 Multicast Commands........................................................................................................................................987
IPv6 Multicast Forwarder................................................................................................................................................ 987
IPv6 PIM Commands ....................................................................................................................................................... 992
IPv6 MLD Commands .................................................................................................................................................... 1007
IPv6 MLD-Proxy Commands..........................................................................................................................................1016
11. Border Gateway Protocol Commands....................................................................................................................1023
BGP Commands......................................................................................................................................................... 1023
Routing Policy Commands ............................................................................................................................................1139
12. Quality of Service Commands................................................................................................................................1145
Class of Service Commands........................................................................................................................................... 1145

5000 Series Layer 2/3 Managed Data Center Switch CLI Reference Guide
v
Differentiated Services Commands ..............................................................................................................................1155
DiffServ Class Commands.............................................................................................................................................. 1156
DiffServ Policy Commands ............................................................................................................................................ 1169
DiffServ Service Commands .......................................................................................................................................... 1179
DiffServ Show Commands............................................................................................................................................. 1180
MAC Access Control List Commands ............................................................................................................................1187
IP Access Control List Commands ................................................................................................................................. 1196
IPv6 Access Control List Commands ............................................................................................................................. 1209
Management Access Control and Administration List..................................................................................................1217
Time Range Commands for Time-Based ACLs .............................................................................................................. 1221
13. D-LINK OS Log Messages.....................................................................................................................................1226
Core............................................................................................................................................................................... 1226
Utilities .......................................................................................................................................................................... 1227
Management................................................................................................................................................................. 1231
Switching....................................................................................................................................................................... 1233
QoS................................................................................................................................................................................ 1239
Routing/IPv6 Routing ....................................................................................................................................................1240
Multicast ....................................................................................................................................................................... 1243
Technologies .................................................................................................................................................................1248
O/S Support................................................................................................................................................................... 1250
14. Switch Management...............................................................................................................................................1252
D-Link OS First Instance ................................................................................................................................................1252
Upgrade D-Link OS ........................................................................................................................................................ 1253
Install Other OS or D-Link OS ........................................................................................................................................1254
SNTP Configuration for x86 D-Link OS .......................................................................................................................... 1256
NTP Configuration for x86 D-Link OS ............................................................................................................................1256

5000 Series Layer 2/3 Managed Data Center Switch CLI Reference Guide
1
About This Guide
Objective and Audience
The Command Line Interface (CLI) used to view and configure D-LINK OS software is explained in this
guide. The CLI can be accessed through the use of a direct connection to the serial port or by using telnet
or SSH via a remote network connection.
The intended audience for this guide includes system administrators who use D-LINK OS software to
configure and operate the systems they administer. The guide provides a comprehensive explanation of
the configuration options for the D-LINK OS software.
It is assumed that readers of this guide will have an understanding of the D-LINK OS software base and
will have read the appropriate specifications for the relevant networking device platform. It is further
assumed that readers will have basic knowledge of Ethernet and networking concepts.
Acronyms and Abbreviations
The acronyms and abbreviations used in this guide are, in most cases, defined at their first use.
Acronym Expansion
ACE access control entry
ACL access control list
AP access point
API application programming interface
APPL application
ASIC application-specific integrated circuit
ATM Asynchronous Transfer Mode
BGP Border Gateway Protocol
C2W WAN C2Wire
CAMP Cooperative Asymmetric Multiprocessing
CAPI card application program interface
CMOS Complementary Metal Oxide Semiconductor
CPP Control Plane Policing
CPU central processing unit
CRC cyclic redundancy check
CSG Content Services Gateway
CWAN Constellation WAN
CWPA Constellation WAN port adapter
CWSLC Constellation WAN SiByte Line Card1
CWTLC Constellation WAN Toaster Line Card1
DBUS data bus
DCM Digital Clock Managers

5000 Series Layer 2/3 Managed Data Center Switch CLI Reference Guide
2
Acronym Expansion
DDR dial-on-demand routing
DF designated forwarder
DFC Distributed Forwarding Card
DHCP Dynamic Host Configuration Protocol
DIAG diagnostic
DIP Dual In-Line Package
dLFI Distributed Link Fragmentation and Interleaving
dLFIoATM Distributed Link Fragmentation and Interleaving over ATM
dLFIoFR Distributed Link Fragmentation and Interleaving over Frame Relay
DMA direct memory access
DOT1X IEEE 802.1X
EAP Extensible Authentication Protocol
EARL Enhanced Address Recognition Logic
ECC error checking and correction
EFC Extended Flow Control
EM Event Manager
EMD Error Message Decoder
ENVM environmental monitoring
EOBC Ethernet out-of-band channel
EoMPLS Ethernet over Multiprotocol Label Switching
EOU Extensible Authentication Protocol over UDP
EPLD Erasable Programmable Logic Device
ESF Express Services Forwarding
FIB Forwarding Information Base
FIFO first-in, first-out
FM Feature Manager
FPD field-programmable device
FPGA field-programmable gate array
GEMAC Gigabit Ethernet Media Access Control
GEWAN Gigabit Ethernet WAN
GSR Gigabit Switch Router
HA high availability
HSRP Hot Standby Router Protocol
I/O input/output
ICDM Inter-CPU Data Mover

5000 Series Layer 2/3 Managed Data Center Switch CLI Reference Guide
3
Acronym Expansion
IDB interface description block
IDPROM identification programmable read-only memory
IGMP Internet Group Management Protocol
IOS Internet Operating System
IP Internet Protocol
IPC InterProcessor Communication
IPNAT IP Network Address Translation
KPA keepalive
L2 Layer 2
L3 Layer 3
L3MM Layer 3 Mobility Manager
LAN local-area network
LI Lawful Intercept
LTL Local Target Logic
MAC Media Access Control
MCAST Multicast
MD5 message digest 5
MET Multicast Expansion Table
MFIB Multicast Forwarding Information Base
MIB Management Information Base
MII media-independent interface
MLD message loading device
MLS Multilayer Switching
MLSM multi-layer switching for multicast
MMI Modem Management Interface
MMLS Multicast Multilayer Switching
MN mobile node
MPPE Microsoft Point-to-Point Encryption
MRIB Multicast Routing Information Base
MSFC Multilayer Switch Feature Card
MTU maximum transmission unit
NAT Network Address Translation
OAL Optimized ACL Logging
OIF output interface
OIR online insertion and removal

5000 Series Layer 2/3 Managed Data Center Switch CLI Reference Guide
4
Acronym Expansion
OSM Optical Services Module
PBI Programmable Binary Image
PCI Peripheral Component Interconnect
PFC Policy Feature Card
PFINIT platform initialization
PFREDUN platform redundancy
PIM Protocol Independent Multicast
PIMSN Protocol Independent Multicast Snooping
PISA Programmable Intelligent Services Accelerator
PLIM Physical Layer Interface Module
PM port manager
PoS Packet over SONET
POSLC Packet over SONET Line Card1
PVLAN private VLAN
PXF Parallel Express Forwarding
QDR Quad Data Rate
QinQ IEEE 802.1Q in 802.1Q
QM quality of service management
QoS quality of service
RACL router access control list
RADIUS Remote Authentication Dial-In User Service
RF redundancy feature
ROM read-only memory
ROMMON read-only memory monitor
RP route processor
RPC Remote Procedure Call
RPF Reverse Path Forwarding
RPR route processor redundancy
RTC Real-Time Clock
SCP Switch-Module Configuration Protocol
SIP SPA Interface Processor
SMbus system management bus
SMSC short message service center
SP switch processor
SPA Shared Port Adapter

5000 Series Layer 2/3 Managed Data Center Switch CLI Reference Guide
5
Acronym Expansion
SPAN Switched Port Analyzer
SRP Spatial Reuse Protocol
SSA Super Santa Ana ASIC
SSO Stateful Switchover
SSP State Synchronization Protocol Manager
SSRAM synchronous static RAM
STAPL Standard Test and Programming Language
SVI switched virtual interface
SW software
TBI Ten Bit Interface
TCAM ternary content addressable memory
TCP Transmission Control Protocol
TFIB Tag Forwarding Information Base
ToS type of service
UDP User Datagram Protocol
URLF URL Filtering
VACL VLAN access control list
VC virtual circuit
VCD virtual circuit descriptor
VLAN Virtual LAN
VLOU Virtual Logic Operation Unit
VPLS Virtual Private LAN Service
VPN Virtual Private Network
VPNSM Virtual Private Network Services Module
VRF VPN routing and forwarding
VSA vendor-specific attribute
VTMS Versatile Traffic Management and Shaping
VTP VLAN Trunking Protocol
VTT voltage termination
WAN wide-area network
WCCP Web Cache Communication Protocol
Guide Conventions
This guide makes use of the following conventions:

5000 Series Layer 2/3 Managed Data Center Switch CLI Reference Guide
6
Convention Description
Bold Indicates user inputs and actions: for example, type exit, click OK, press
Alt+C
Monospace Indicates code: for example, #include <iostream>
Indicates command-line commands and command outputs: for example,
(Routing)# show sysinfo
Monospace italic Indicates command variables: for example,
interface vlan
vLan-id
{ } Indicates mutually exclusive command line parameters: for example, network
protocol {none I bootp I dhcp}
[ ] Indicates optional command-line parameters: for example, write memory
[confirm]

5000 Series Layer 2/3 Managed Data Center Switch CLI Reference Guide
7
1. About D-LINK OS Software
About D-LINK OS Software
The two primary purposes of the D-Link OS are as follows:
•To support the attached hardware in switching frames according to the Layer 2, 3, or 4
information contained in the frames.
•To provide network administrators with a complete device management portfolio.
Product Concept
The evolution of fast Ethernet and Gigabit Ethernet switching from high-end backbone applications to
desktop switching applications is ongoing. At the same time, the cost of this technology continues to fall,
even as its performance and feature sets continue to be enhanced. Relatedly, there is an increasing
demand for devices that can switch Layers 2, 3, and 4, and D-LINK OS software offers a highly adaptable
solution for these constantly increasing demands.
For each networking device on which the D-LINK OS software base runs, the exact functionality provided
by the device will vary according to the platform used and the requirements of the D-LINK OS software.
The D-LINK OS software comes equipped with a comprehensive set of management functions that can
be used to manage both the D-LINK OS software itself and the network. More specifically, the D-LINK OS
software can be managed via either of the following methods:
•Command-Line Interface (CLI)
•Simple Network Management Protocol (SNMP)
Both of these D-LINK OS management options allow the user to control, configure, and otherwise
manage the software locally or using in-band or out-of-band mechanisms. The management is standards-
based, with a private MIB and specific configuration parameters allowing for control of functions not
completely specified in the MlBs.

5000 Series Layer 2/3 Managed Data Center Switch CLI Reference Guide
8
2. Using the Command-Line
The command-line interface (CLI) constitutes a text-based means by which to monitor and manage the
system. The CLI can be accessed by the use of a direct serial connection or through the used of a remote
logical connection via telnet or SSH.
Command Syntax
A command consists of one or more words. A given command may or may not be followed by one or
more parameters, as parameters may be required or optional depending on the command being used.
For example, the commands network and clear vlan do not require parameters, whereas other
commands, such as network parms, require that a value is included after the command. Such
parameter values must be typed in a specific order, with any optional parameters following any required
parameters. The following example illustrates the command syntax for the network parms command:
network parms ipaddr netmask [gateway]
•The term network parms is the name of the command itself.
•The terms ipaddr and netmask are parameters and are examples of required values that must
be entered after the command itself are entered.
•The term [gateway] is an optional parameter, meaning that it is not required that a value be
entered in place of the parameter.
Each command is listed by the command name in the CLI Command Reference, which also provides a
brief description of each command.
The command keywords and the associated required and optional parameters are shown under Format.
The command mode used must be in to access the command is indicated under Mode.
The default value for a configurable setting on the device, if any, is indicated by Default.
Furthermore, the information that a given command shows is described by the show command.
Command Conventions
For a given command, the parameters used may include mandatory values, optional values, or keyword
choices. Such parameters follow a prescribed order. Table 1explains the conventions used in this guide
to distinguish between value types.
Table 1: Parameter Conventions
Symbol Example Description
[] Brackets
[value]
Denotes an optional parameter.
Italic font in a parameter value or [value] Denotes a variable value. You must
substitute the italicized text and brackets
with an appropriate value, such as a name
or number.
{} Braces
{choice1 | choice2}
Indicates a parameter selection option.
| Vertical bars
choice1 | choice2
Separates mutually exclusive choices.
[{}] Braces within brackets
[{choicel | choice2}]
Denotes a choice within an optional

5000 Series Layer 2/3 Managed Data Center Switch CLI Reference Guide
9
Symbol Example Description
element.
Common Parameter Values
The values for parameters might be names (strings) or numbers. Enclose the name value in double
quotes in order to use spaces as part of a name parameter. For example, using the expression “System
Name with Spaces” requires the system to accept the spaces, while the use of empty strings (“”) is not
valid for user-defined strings. Table 2 explains common parameter values and value formatting.
Table 2: Parameter Descriptions
Parameter Description
ipaddr This parameter constitutes a valid lP address. The IP address can be entered
in the following formats:
a (32 bits)
a.b (8.24 bits)
a.b.c (8.8.16 bits)
a.b.c.d (8.8.8.8)
Besides these formats, the CLI also accepts decimal, hexadecimal, and octal
formats in the following input formats (where nconsists of any valid
hexadecimal, octal, or decimal number):
0xn (CLI assumes hexadecimal format.)
0x (CLI assumes octal format with leading zeros.)
n (CLI assumes decimal format.)
Interface or
slot/port
Used to indicate a valid slot and port number separated by a forward slash.
For example, 0/1 denotes slot number 0 and port number 1.
Logical Interface Indicates a logical slot and port number. This applies in the case of a port-
channel (LAG). The logical slot/port can be used to configure the port-channel.
Character strings Double quotation marks are used to identify character strings, e.g., “System
Name with Spaces”. An empty string (“”) will not be considered valid.
Slot/Port Naming Convention
In referencing physical entities such as cards and ports, the D-LINK OS software uses a slot/port naming
convention. This convention is also used by the software to identify certain logical entities, such as Port-
Channel interfaces.
There are two uses for the slot number. With respect to physical ports, it indicates the card containing the
ports. With respect to logical and CPU ports, it also indicates the type of interface or port.
Table 3: Types of Slot Numbers
Slot Type Description
Physical slot numbers Physical slot numbers start with zero, and are assinged up to the maximum
number of physical slots.

5000 Series Layer 2/3 Managed Data Center Switch CLI Reference Guide
10
Slot Type Description
Logical slot numbers Logical slots numbers are given immediately after physical slot numbers and
identify port-channel (LAG) or router interfaces. The values for logical slot
numbers are dependent upon the type of logical interface and can differ from
platform to platform.
CPU slot numbers The CPU slot numbers are given immediately after the logical slot numbers.
For a given slot, the port refers to the specific physical port or logical interface being managed on the slot.
Table 4: Types of Ports
Port Type Description
Physical Ports Starting from zero, the physical ports for each slot are numbered in sequence.
Logical Interfaces Port-channel or Link Aggregation Group (LAG) interfaces consist of logical
interfaces that are used for bridging functions only.
VLAN routing interfaces consist of logical interfaces that are used for routing
functions only.
Loopback interfaces consist of logical interfaces that are constantly up.
Tunnel interfaces consist of logical point-to-point links in which encapsulated
packets are carried.
CPU ports CPU ports consist of ports that are handled by the driver and are physical
entities that are located in physical slots.
Note: In the CLI itself, the slot/port format is not used for loopback interfaces. Use the loopback ID
instead to specify a loopback interface.
Using the No Form of a Command
The no keyword is used to form the negative form of an existing command and is not a new or distinct
command itself. A no form exists for almost every configuration command. in general, the no form of a
command is used to reverse the action of the command or to reset a given value back to its default. For
example, the no shutdown configuration command is used to reverse the shutdown of an interface.
Alternatively, a given command can be used without the no keyword to reenable a previously disabled
feature or to enable a feature that is disabled by default. The no form is only available for the
configuration commands.

5000 Series Layer 2/3 Managed Data Center Switch CLI Reference Guide
11
Executing Show Commands
Any mode (Global Config, VLAN Config, etc.) can be used to issue all show commands. These
commands are used to obtain information about the system and its feature-specific configuration, status,
and statistics.
CLI Output Filtering
In many cases, CLI show commands will cause a considerable amount of content to be displayed to the
user. Such large amounts of content can be confusing and cumbersome to parse through to locate the
desired information. However, by using the CLI Output Filtering feature, the user can, when executing CLI
show display commands, optionally specify arguments in order to filter the CLI output so that only the
desired information is displayed. The displayed information will thus be simplified, making it easier for the
user to find the desired information.
The primary functions of the CLI Output Filtering feature are as follows:
•Pagination Control
oFor all show CLI commands, supports the enabling/disabling of paginated output. When
disabled, the requested output is displayed in its entirety. When enabled, the requested
output is displayed in a page-by-page manner such that the display does not scroll
beyond the end of the screen until the user presses a key to continue. The options --
More-- or (q)uit are displayed at the end of each page.
oIf pagination is enabled, pressing the return key will advance the display by a single line,
pressing q or Q will cause the pagination to stop, and pressing any other key will advance
the display by a whole page. No other configuring of these keys is possible.
Note: Although pagination is already supported by some D-LINK OS show commands, its
implementation is unique per command rather than being generic to all commands.
•Output Filtering
o“Grep”-like control used to modify the displayed output to show only the user-desired
content.
Filter the displayed output to include only those lines containing a specified string
match.
Filter the displayed output to omit only those lines containing a specified string
match.
Filter the displayed output to include only those lines including and following a
specified string match.
Filter the displayed output to include only a specified section of the content (e.g.,
“interface 0/1”) using a configurable end-of-section delimiter.
String matching should be case insensitive.
When enable, pagination also applies to filtered output.
Example
The following provides some examples of the extensions made to the CLI show.
show running-show config ?
<cr> Press enter to execute the command.
| Output filter options.
<scriptname> Script file name for writing active configuration.
all Show all the running configuration on the switch.
interface Display the running config for specified interface on
the switch.

5000 Series Layer 2/3 Managed Data Center Switch CLI Reference Guide
12
3. D-LINK OS Modules
The D-LINK OS software is composed of flexible modules that can be utilized in a variety of combinations
in order to support advanced Layer 2/3/4 products. The installed modules determine the commands and
command modes available on your switch. Additionally, please note that the output fields for some show
commands might change depending upon the modules included in the D-LINK OS software.
The following modules are included in the D-LINK OS software suite:
•Switching (Layer 2)
•Data Center
•Routing (Layer 3)
•IPv6 Routing (Layer 3)
•Multicast
•BGP-4
•Quality of Service
•Management (CLI and SNMP)
Command Modes
Commands are grouped by the CLI into modes according to the command function, with specific D-LINK
OS software commands being supported by each of the command modes. As such, the commands for a
given mode are not available until the user switches to that particular mode, with the exception of the
commands for the User EXEC mode. The User EXEC mode commands can also be executed in the
Privileged EXEC mode.
To help the user identify the current mode, the command prompt changes for each different command
mode. The command modes and the prompts for each mode are shown in Table 5.
Note: The installed sotware modules determine which command modes are available on your switch. For
example, if a switch does not support the BGPV4 module, then the BGPv4 Router Command Mode will
not be available.
Table 5: CLI Command Modes
Command
Mode Prompt Mode Description
User EXEC Switch> Allows a limited set of commands used to
view basic system information.
Privileged EXEC Switch# Allows the user to issue any EXEC
command, to enter the VLAN mode, or to
enter the Global Configuration mode.
Global Config Switch (Config)# Groups general setup commands and
permits modifications to be made to the
running configuration.
VLAN Config
Switch (V1an)#
Groups all the VLAN commands.
Interface Config Switch (Interface slot/port)#
Switch (Interface vlan vlan-
id)#
Switch (Interface lag vlan-
id)#
Used to manage the operation of an
interface by providing access to the router
interface configuration commands.
This mode can be used to set up a
physical port for a specific logical
connection operation.

5000 Series Layer 2/3 Managed Data Center Switch CLI Reference Guide
13
Command
Mode Prompt Mode Description
Switch (Interface Loopback
id)#
Switch (Interface tunnel id)#
Switch (Interface slot/port
(startrange - slot/port
(endrange)
)#
This mode can also be used to manage
the operation of a range of interfaces. For
example, for the range of interfaces from
ports 0/2 to 0/4, the prompt is displayed as
follows:
(Routing) (Interface 0/2-0/4)#
Line Console Switch (config-line)# Includes commands that can be used to
configure outbound telnet settings and
console login/enable authentication, as
well as to configure console interface
settings.
Line SSH Switch (config-ssh)# Includes commands that can be used to
configure SSH login/enable authentication.
Line Telnet Switch (config-telnet)# Includes commands that can be used to
configure telnet login/enable
authentication.
AAA IAS User
Config Switch (config-IAS-User)# Includes commands that can be used to configure a password for a user in the IAS
database.
Mail Server Switch (Mail-Server)# Includes commands that can be used to
configure the e-mail server.
Class Map
Config Switch (config-class-map)# Includes the commands for QoS class map configuration for IPv4.
Router OSPF
Config Switch (config-router)# Includes the commands for OSPF configuration.
BGP Router
Config Switch (config-router)# Includes the commands for BGP4 configuration.
IPv6 Address
Family Switch (config-router-af)# Includes the commands for IPv6 address family configuration.
Radius Dynamic
Authorization
Config
Switch (config-radius-da)# Includes the commands for Radius
Dynamic Authorization.
MAC Access-list
Config Switch (Config-mac-access-
list)# Includes the commands for creating a
MAC Access-List and allows the user to
enter the mode containing the MAC
Access-List configuration commands.
