D-Link DES-1228 - Web Smart Switch User manual

Table of Contents D-Link Web Smart Switch User Manual
Table of Contents
Table of Contents ............................................................................................................................................. i
About This Guide............................................................................................................................................. 1
Terms/Usage.................................................................................................................................................. 1
Copyright and Trademarks ............................................................................................................................ 1
Product Introduction....................................................................................................................................... 2
DES-1228....................................................................................................................................................... 3
Front Panel................................................................................................................................................. 3
Rear Panel.................................................................................................................................................. 3
Hardware Installation ...................................................................................................................................... 4
Step 1: Unpacking.......................................................................................................................................... 4
Step 2: Switch Installation.............................................................................................................................. 4
Desktop or Shelf Installation....................................................................................................................... 4
Rack Installation......................................................................................................................................... 4
Step 3 – Plugging in the AC Power Cord....................................................................................................... 5
Power Failure ............................................................................................................................................. 6
Getting Started................................................................................................................................................. 7
Management Options..................................................................................................................................... 7
Using Web-based Management .................................................................................................................... 7
Supported Web Browsers .......................................................................................................................... 7
Connecting to the Switch............................................................................................................................ 7
Login Web-based Management................................................................................................................. 8
Smart Wizard ................................................................................................................................................. 8
Web-based Management............................................................................................................................... 8
SmartConsole Utility....................................................................................................................................... 8
SmartConsole Utility ..................................................................................................................................... 10
SmartConsole Settings ................................................................................................................................ 10
Utility Settings........................................................................................................................................... 10
Log............................................................................................................................................................ 11
Trap.......................................................................................................................................................... 11
File............................................................................................................................................................ 11
Help.......................................................................................................................................................... 12
Device Configuration.................................................................................................................................... 13
Add(+), Delete(-) and Discover the device............................................................................................... 15
Device List.................................................................................................................................................... 15
Configuration................................................................................................................................................. 17
Smart Wizard Configuration......................................................................................................................... 17
Password Settings.................................................................................................................................... 17
SNMP Settings......................................................................................................................................... 18
System Settings........................................................................................................................................ 19
Web-based Management............................................................................................................................. 20
Tool Bar > Save Menu................................................................................................................................. 21
Save Configuration................................................................................................................................... 21
Save Log .................................................................................................................................................. 21
Tool Bar > Tool Menu .................................................................................................................................. 21
Reset ........................................................................................................................................................ 21
Reset System........................................................................................................................................... 21
Reboot Device.......................................................................................................................................... 22
i
i

Table of Contents D-Link Web Smart Switch User Manual
Configuration Backup & Restore.............................................................................................................. 22
Firmware Backup and Upload.................................................................................................................. 22
Tool Bar > Smart Wizard.............................................................................................................................. 23
Tool Bar > Online Help................................................................................................................................. 23
Function Tree............................................................................................................................................... 24
Device Information.................................................................................................................................... 24
System > System Settings ....................................................................................................................... 25
System > Trap Settings (For SmartConsole)........................................................................................... 26
System > Port Settings............................................................................................................................. 26
System > SNMP Settings......................................................................................................................... 27
System > Password Access Control........................................................................................................ 28
System > System Log Settings ................................................................................................................ 28
Configuration > 802.1Q VLAN.................................................................................................................. 29
Configuration > 802.1Q VLAN (Asymmetric VLAN)................................................................................. 30
Configuration > 802.1Q Management VLAN............................................................................................ 32
Configuration > Voice VLAN > Voice VLAN Setting.................................................................................32
Configuration > Voice VLAN > Voice VLAN OUI Setting ......................................................................... 33
Configuration > Link Aggregation > Port Trunking................................................................................... 34
Configuration > Link Aggregation > LACP Port Settings.......................................................................... 34
Configuration > IGMP Snooping .............................................................................................................. 35
Configuration > Port Mirroring.................................................................................................................. 36
Configuration > Loopback Detection........................................................................................................ 37
Configuration > SNTP Settings > Time Settings...................................................................................... 38
Configuration > SNTP Settings > TimeZone Settings..............................................................................38
Configuration > Spanning Tree > STP Global Settings............................................................................39
Configuration > Spanning Tree > STP Port Settings ...............................................................................40
QoS > Storm Control................................................................................................................................ 42
QoS > Bandwidth Control......................................................................................................................... 42
QoS > 802.1p/DSCP Priority Settings...................................................................................................... 43
Security > Trusted Host............................................................................................................................ 44
Security > Safeguard Engine.................................................................................................................... 45
Security > Port Security............................................................................................................................ 45
Security > 802.1X > 802.1X Settings ....................................................................................................... 45
Security > MAC Address Table > Static MAC.......................................................................................... 47
Security > MAC Address Table > Dynamic Forwarding Table................................................................. 47
Monitoring > Statistics.............................................................................................................................. 48
Monitoring > Cable Diagnostics ............................................................................................................... 50
Monitoring > System Log.......................................................................................................................... 50
ACL > ACL Configuration Wizard............................................................................................................. 51
ACL > ACL Profile List.............................................................................................................................. 52
ACL > ACL Finder.................................................................................................................................... 55
Command Line Interface............................................................................................................................... 56
To connect a switch via TELNET:................................................................................................................ 56
Logging on to the Command Line Interface:................................................................................................ 56
CLI Commands:........................................................................................................................................... 56
Download.................................................................................................................................................. 56
Upload...................................................................................................................................................... 57
Config ipif system..................................................................................................................................... 57
Logout....................................................................................................................................................... 58
i
ii i

Table of Contents D-Link Web Smart Switch User Manual
iii
Ping .......................................................................................................................................................... 58
Reboot...................................................................................................................................................... 58
Reset ........................................................................................................................................................ 58
Show ipif................................................................................................................................................... 59
Show switch.............................................................................................................................................. 59
Config account admin password.............................................................................................................. 59
Save ......................................................................................................................................................... 60
Appendix A - Ethernet Technology.............................................................................................................. 61
Gigabit Ethernet Technology ....................................................................................................................... 61
Fast Ethernet Technology............................................................................................................................ 61
Switching Technology.................................................................................................................................. 61
Appendix B - Technical Specifications ....................................................................................................... 62
Hardware Specifications .............................................................................................................................. 62
Key Components / Performance.............................................................................................................. 62
Port Functions .......................................................................................................................................... 62
Physical & Environment ........................................................................................................................... 62
Emission (EMI) Certifications................................................................................................................... 62
Safety Certifications.................................................................................................................................. 62
Features....................................................................................................................................................... 62
L2 Features .............................................................................................................................................. 62
VLAN........................................................................................................................................................ 62
QoS (Quality of Service)........................................................................................................................... 62
Security..................................................................................................................................................... 62
Management............................................................................................................................................. 63
Appendix C – Rack mount Instructions ...................................................................................................... 64

About This Guide D-Link Web Smart Switch User Manual
About This Guide
This guide provides instructions to install the D-Link Fast Ethernet Web Smart Switch DES-1228, how to use
the SmartConsole Utility, and to configure Web-based Management step-by-step.
Note: The model you have purchased may
appear slightly different from the illustrations
shown in the document. Refer to the Product
Instruction and Technical Specification sections
for detailed information about your switch, its
components, network connections, and technical
specifications.
This guide is mainly divided into four parts:
1. Hardware Installation: Step-by-step hardware installation procedures.
2. Getting Started: A startup guide for basic switch installation and settings.
3. Smart Console Utility: An introduction to the central management system.
4. Configuration: Information about the function descriptions and configuration settings.
Terms/Usage
In this guide, the term “Switch” (first letter capitalized) refers to the Smart Switch, and “switch” (first letter
lower case) refers to other Ethernet switches. Some technologies refer to terms “switch”, “bridge” and
“switching hubs” interchangeably, and both are commonly accepted for Ethernet switches.
A NOTE indicates important information that
helps a better use of the device.
A CAUTION indicates potential property damage
or personal injury.
Copyright and Trademarks
Information in this document is subjected to change without notice.
© 2010 D-Link Corporation. All rights reserved.
Reproduction in any manner whatsoever without the written permission of D-Link Corporation is strictly
forbidden.
Trademarks used in this text: D-Link and the D-LINK logo are trademarks of D-Link Corporation; Microsoft
and Windows are registered trademarks of Microsoft Corporation.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the
marks and names or their products. D-Link Corporation disclaims any proprietary interest in trademarks and
trade names other than its own.
1

1 Product Introduction D-Link Web Smart Switch User Manual
1 Product Introduction
Thank you and congratulations on your purchase of D-Link Web Smart Switch Products.
D-Link's next generation Web Smart Ethernet switch series blends plug-and-play simplicity with exceptional
value and reliability for small and medium-sized business (SMB) networking. All models are housed in a new
style rack-mount metal case with easy-to-view front panel diagnostic LEDs, and provides advance features
including two combo 1000BASE-T/SFP and two additional Gigabit uplinks, network security, traffic
segmentation, QoS and versatile management.
Flexible Port Configuration. The DES-1228 provides flexible port configuration for different applications. 24
10/100M Ethernet ports that support auto MDI/MDIX feature which bring inexpensive and easy Ethernet
connection to the desktops. Each switch provides 4 Gigabit uplinks connection to a Gigabit backbone or
servers. Two of the Gigabit ports are SFP combo ports which support both 1000M and 100M fiber
connections.
Extensive Layer 2 Features. Implemented as complete Layer 2 devices, these switches include functions
such as IGMP Snooping, Port Mirroring, Spanning Tree, 802.3ad LACP and Loopback Detection to enhance
performance and network resiliency.
Traffic Segmentation and QoS. The switches support 802.1Q VLAN tagging to enhance network security
and performance. The switches also support 802.1p priority queues, enabling users to run bandwidth-
sensitive applications such as multimedia streaming by prioritizing traffic in network. These functions allow
switches to work seamlessly with VLAN and 802.1p traffic in the network. Auto Voice VLAN automatically
places the voice traffic from IP phone to an assigned VLAN with higher priority, separating from normal traffic.
Asymmetric VLAN is implemented in these switches for a more efficient use of shared resources such as
server or gateway devices.
Network Security. D-Link’s innovative Safeguard Engine function protects the switches against traffic
flooding caused by virus attacks. Additional feature like 802.1X port-based authentication provides access
control of the network with external RADIUS servers. ACL is a powerful tool to screen unwanted IP or MAC
traffic. Storm Control keeps the network from being overwhelmed by abnormal traffic. Port Security is
another simple but useful authentication method to maintain the integrity of the network device.
Versatile Management. The new generation of D-Link Web Smart Switches provides growing businesses
simple and easy management of their network. The SmartConsole utility or Web-Based management
interface allows administrators to remotely control their network down to the port level. The intuitive
SmartConsole easily allows customers to discover multiple D-Link web smart switches in the same L2
network segment. With this utility, users do not need to change the IP address of PC and provides easy
initial setting of smart switches. The switches within the same L2 network segment connected to user’s local
PC are displayed on the screen for instant access. It allows extensive switch configuration setting, and basic
configuration of discovered devices such as a password change or firmware upgrade.
Users can also access the Switch via Telnet. Basic tasks such as changing the Switch IP address, resetting
the settings to factory defaults, setting the administrator password, rebooting the Switch, or upgrading the
Switch firmware can be performed using the Command Line Interface (CLI).
In addition, users can utilize the SNMP MIB (Management Information Base) to poll switches for information
about the status, or send out traps of abnormal events. SNMP support allows users to integrate the switches
with other third-party devices for management in an SNMP-enabled environment. D-Link Web Smart
Switches also come with the D-View plug-in module that works with D-View 6, SNMP Management Software
which provides easy-to-use graphic interface and facilitates the operation efficiency.
2

1 Product Introduction D-Link Web Smart Switch User Manual
DES-1228
24-Port 10/100Mpbs with 4-Port 10/100/1000Mbps Copper and 2 Combo SFP Web Smart Switch
Front Panel
Figure 1 – DES-1228 Front Panel
Power LED :The Power LED lights up when the Switch is connected to a power source.
Port Link/Act/Speed LED (1-24): The Link/Act/Speed LED flashes which indicates a network link through
the corresponding port. Blinking indicates that the Switch is either sending or receiving data to the port.
When a port has amber light indicates that port is running on 10M. When it has a green light it is running on
100M.
Port Link/Act/Speed LED (25F, 26F, 25T, 26T, 27, 28): The Link/Act/Speed LED flashes which indicates a
network link through the corresponding port. Blinking indicates that the Switch is either sending or receiving
data to the port. When a port has amber light indicates that port is running on 10M or 100M. When it has a
green light it is running on 1000M.
NOTE: On DES-1228, the MiniGBIC ports are
shared with normal RJ-45 ports 25 and 26. When
MiniGBIC port is used, the RJ-45 port cannot be
used.
CAUTION: The MiniGBIC ports should use UL
listed Optical Transceiver product, Rated Laser
Class I. 3.3Vdc.
Reset: By pressing the Reset button the Switch will change back to the default configuration and all changes
will be lost.
Rear Panel
Figure 2 – DES-1228 Rear Panel
Power: The power port is where to connect the AC power cord.
3
3

2 Hardware Installation D-Link Web Smart Switch User Manual
2 Hardware Installation
This chapter provides unpacking and installation information for the D-Link Web-Smart Switch.
Step 1: Unpacking
Open the shipping carton and carefully unpack its contents. Please consult the packing list located in the
User Manual to make sure all items are present and undamaged. If any item is missing or damaged, please
contact your local D-Link reseller for replacement.
One D-Link Web-Smart Switch
One AC power cord
Four rubber feet
Screws and two mounting brackets
One Multi-lingual Getting Started Guide
One CD with User Manual, SmartConsole Utility program, and D-View Module
If any item is found missing or damaged, please contact the local reseller for replacement.
Step 2: Switch Installation
For safe switch installation and operation, it is recommended that you:
Visually inspect the power cord to see that it is secured fully to the AC power connector.
Make sure that there is proper heat dissipation and adequate ventilation around the switch.
Do not place heavy objects on the switch.
Desktop or Shelf Installation
When installing the switch on a desktop or shelf, the rubber feet included with the device must be attached
on the bottom at each corner of the device’s base. Allow enough ventilation space between the device and
the objects around it.
Figure 3 – Attach the adhesive rubber pads to the bottom
Rack Installation
The switch can be mounted in an EIA standard size 19-inch rack, which can be placed in a wiring closet with
other equipment. To install, attach the mounting brackets to the switch’s side panels (one on each side) and
secure them with the screws provided (please note that these brackets are not designed for palm size
switches).
Figure 4 – Attach the mounting brackets to the Switch
4

2 Hardware Installation D-Link Web Smart Switch User Manual
Then, use the screws provided with the equipment rack to mount the switch in the rack.
Figure 5 – Mount the Switch in the rack or chassis
Please be aware of following safety Instructions when installing:
A) Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly, the operating ambient
temperature of the rack environment may be greater than room ambient. Therefore, consideration should be
given to installing the equipment in an environment compatible with the maximum ambient temperature (Tma)
specified by the manufacturer.
B) Reduced Air Flow - Installation of the equipment in a rack should be such that the amount of air flow
required for safe operation of the equipment is not compromised.
C) Mechanical Loading - Mounting of the equipment in the rack should be such that a hazardous condition is
not achieved due to uneven mechanical loading.
D) Circuit Overloading - Consideration should be given to the connection of the equipment to the supply
circuit and the effect that overloading of the circuits might have on overcurrent protection and supply wiring.
Appropriate consideration of equipment nameplate ratings should be used when addressing this concern.
E) Reliable Earthing - Reliable earthing of rack-mounted equipment should be maintained. Particular
attention should be given to supply connections other than direct connections to the branch circuit (e.g. use
of power strips)."
Step 3 – Plugging in the AC Power Cord
Users may now connect the AC power cord into the rear of the switch and to an electrical outlet (preferably
one that is grounded and surge protected).
5
5

2 Hardware Installation D-Link Web Smart Switch User Manual
Figure 6 –Plugging the switch into an outlet
Power Failure
As a precaution, the switch should be unplugged in case of power failure. When power is resumed, plug the
switch back in.
6

3 Getting Started D-Link Web Smart Switch User Manual
3 Getting Started
This chapter introduces the management interface of D-Link Web-Smart Switch.
Management Options
The D-Link Web Smart Switch can be managed through any port on the device by using the Web-based
Management or through any PC using the SmartConsole Utility.
Each switch must be assigned its own IP Address, which is used for communication with Web-Based
Management or a SNMP network manager. The PC should have an IP address in the same range as the
switch. Each switch can allow up to four users to access to the Web-Based Management concurrently.
However, if you want to manage multiple D-Link Web Smart Switches, the SmartConsole Utility is a more
convenient choice. By using the SmartConsole Utility, you do not need to change the IP address of your PC
and it is easier to initialize multiple Smart Switches.
Please refer to the following installation instructions for the Web-based Management and the SmartConsole
Utility.
Using Web-based Management
After a successful physical installation, you can configure the Switch, monitor the network status, and display
statistics using a web browser.
Supported Web Browsers
The embedded Web-based Management currently supports the following web browsers:
Internet Explorer 6 or higher
Netscape 8 or higher
Mozilla
Firefox 1.5/2.0 or higher
Connecting to the Switch
You will need the following equipment to begin the web configuration of your device:
1. A PC with a RJ-45 Ethernet connection
2. A standard Ethernet cable
Connect the Ethernet cable to any of the ports on the front panel of the switch and to the Ethernet port on the
PC.
Figure 7 –Connected Ethernet cable
7
7

3 Getting Started D-Link Web Smart Switch User Manual
Login Web-based Management
In order to login and configure the switch via an Ethernet connection, the PC must have an IP address in the
same subnet as the switch. For example, if the switch has an IP address of 192.168.0.1, the PC should have
an IP address of 192.168.0.x (where x is a number between 2 and 253), and a subnet mask of
255.255.255.0. There are two ways to login the Web-based Management Utility, you may click the Web
Access button at the top of the SmartConsole Utility or open your web browser and enter 192.168.0.1 (the
factory-default IP address) in the address box. Then press <Enter>
Figure 8 –Enter the IP address 10.90.90.90 in the web browser
NOTE: The switch's factory default IP address is
192.168.0.1 with a subnet mask of
255.255.255.0 and a default gateway of
192.168.0.254.
The web configuration can also be accessed through the SmartConsole Utility. Open the SmartConsole
Utility and double-click the switch as it appears in the Monitor List. This will automatically load the web
configuration in your web browser.
When the following login box appears, enter the password then press OK to entering the Web-based
Management Utility. The default password is Admin.
Figure 9 – Logon Dialog Box
Smart Wizard
After a successful login, the Smart Wizard will guide you through essential settings of the D-Link Web Smart
Switch. Please refer to Smart Wizard Configuration section for details.
Web-based Management
By clicking the Exit button in Smart Wizard, you will enter the Web-based Management interface. Please
refer to Chapter 5 Configuration for detailed instructions.
SmartConsole Utility
The SmartConsole Utility included in the installation CD is a program for discovering D-Link Smart Switches
within the same L2 network segment connected to your PC. This tool is only for computers running Windows
2000, Windows XP, or Windows Vista x64/86 operating systems. There are two options for the installation of
the SmartConsole Utility; one is through the autorun program on the installation CD and the other is manual
installation.
NOTE: Please be sure to uninstall any existing
SmartConsole Utility from your PC before
installing the latest SmartConsole Utility.
8

3 Getting Started D-Link Web Smart Switch User Manual
Option 1: Follow these steps to install the SmartConsole Utility via the autorun program on the installation
CD.
1. Insert the Utility CD into your CD-Rom/DVD-Rom Drive.
2. The autorun program will appear automatically.
3. Click on the ”Install SmartConsole Utility” button and an installation wizard will guide you through the
process.
4. After successfully installing the SmartConsole Utility, you can open the utility by clicking Start >
Programs > D-Link SmartConsole Utility.
5. Connect the Smart Switch to the same L2 network segment of your PC and use the SmartConsole
Utility to discover the Smart Switches.
Option 2: Follow these steps to install the SmartConsole Utility manually.
1. Insert the Utility CD into your CD-Rom/DVD-Rom Drive.
2. From the Start menu on the Windows desktop, click Run.
3. In the Run dialog box, type D:\D-Link SmartConsole Utility\setup.exe (where D:\ represents the drive
letter of your CD-Rom or DVD-Rom) and click OK.
4. Follow the on-screen instructions to install the utility.
5. Upon completion, go to Start > Programs > D-Link SmartConsole Utility and open the SmartConsole
Utility.
6. Connect the Smart Switch to the same L2 network segment of your PC and use the SmartConsole
Utility to discover the Smart Switches.
For detailed explanations of SmartConsole’s functions, please refer to Chapter 4 SmartConsole Utility
9
9

4 SmartConsole Utility D-Link Web Smart Switch User Manual
4 SmartConsole Utility
The D-Link SmartConsole Utility allows the administrator to quickly discover all D-Link smart switches which
are in the same domain of the PC, collect traps and log messages, and quick access to basic configurations
of the switch.
The SmartConsole Utility consists of three parts, Device Configurations at the top, Device List as the main
body, and SmartConsole Settings at the left. Device Configuration
Settings
SmartConsole
Device List
Figure 10 – SmartConsole Utility
SmartConsole Settings
The SmartConsole Settings at the left has five icons, Utility Settings, Log, Trap, File, and Help.
Utility Settings
Click this icon to launch the Utility Settings window. Refresh time refreshes the devices which were selected
as monitored device in the Device List. Choices include 15 secs, 30 secs, 1mins, 2mins, and 5 mins for
selecting the monitoring time intervals. Utility Group Interval establishes the intervals (in seconds) that the
Switch will be discovered in the SmartConsole Device List.
Figure 11 – SmartConsole Utility Settings
NOTE: If the Group Interval is set to 0, IGMP
Snooping must be disabled in the Switch or the
Web-Smart Switch will not be discovered.
10

4 SmartConsole Utility D-Link Web Smart Switch User Manual
Log
Click this icon to launch the Log window. Click View Log to show the events of the SmartConsole Utility and
the device. Date/Time indicates when the message was received, IP denotes where it comes from and
Status shows the content of this log message. Click Clear Log to clear all log entries. Click OK to exit.
Figure 12 – SmartConsole Log
Trap
Click this icon to launch the Trap window. Click View Trap to show the events of the SmartConsole Utility
and the device. Date/Time indicates when the trap message was received, IP denotes where it comes from
and Status shows the content of this trap message. Click Clear Trap to clear all entries. Click OK to exit
Figure 13 – SmartConsole Trap
The trap icon in the SmartConsole Settings will change while receiving new trap messages. Please see
below for detailed description.
Icon Description
No new traps
New traps was received
File
By clicking on this icon you will see below options:
1
11 1

4 SmartConsole Utility D-Link Web Smart Switch User Manual
Figure 14 – SmartConsole File
Monitor Save: Records the setting of the Device List as default for the next time the SmartConsole Utility is
used.
Monitor Save As: Records the setting of the Device List in an appointed filename and file path.
Monitor Load: Manually load a Device List setting file.
Help
Click this icon to launch the SmartConsole Info window.
Figure 15 – SmartConsole Help
12

4 SmartConsole Utility D-Link Web Smart Switch User Manual
Device Configuration
The Device Configuration in the SmartConsole Utility has five icons:
Device Settings
Device Password Manager
Multi Firmware Upgrade
DHCP Refresh
Web Access
and the , , device buttons for the Device List.
Device Settings
Select a switch from the Device List. Click on this icon to launch the Device Settings window. Here you can
configure the Product Name, IP Address, Gateway, Subnet Mask, System Name, Location, Trap Host IP,
Switch Group Interval, and DHCP Client Setting of the Switch.
To apply the configuration, insert the correct device password in the Confirm Password box and then click
OK
Figure 16 – SmartConsole Device Settings
1
13 3

4 SmartConsole Utility D-Link Web Smart Switch User Manual
Device Password Manager
Select a switch from the Device List. Click on this icon to launch the Device Password Manager window.
Here you can enter a new password and confirm it.
Figure 17 – SmartConsole Device Password Manager
Multi Firmware Upgrade
Select one or many switches of same model name from the Device List. Click on this icon to launch the
Firmware Upgrade window. Specify the Firmware Path (or Browse for one) that you are going to use. Input
the correct password of device, and then click Upgrade. The state will show "OK" after completion, and “Fail”
is firmware upgrade fails or cannot be completed for any reason.
Figure 18 – Firmware Upgrade
CAUTION: Do not disconnect the PC or remove
the power cord from device until upgrade
completes. The software may be corrupted
because the incomplete firmware upgrade.
DHCP Refresh:
If a DHCP-client enabled switch in the Device List shows the default IP is still used, it means the device did
not receive an IP address from the DHCP server successfully. Select that switch and click the DHCP refresh
icon. Enter the correct Device Password and then click OK. The device will renew the IP address from the
DHCP server.
14

4 SmartConsole Utility D-Link Web Smart Switch User Manual
Figure 19 – DHCP Refresh
Web Access
Select a switch from the Device List. Click this icon to launch your internet browser (eg. The Internet
Explorer). Here you can configure the Switch through the Web-based Management utility. You may also get
into the Web-based Management by double-clicking the device in the device list.
Add(+), Delete(-) and Discover the device
Click the Discovery button to display all the Web-Smart devices located in the same domain with the
management PC.
Click the +and insert a device IP address to add a device into Discover List, or select a device and click
the –button to remove it.
Figure 20 – SmartConsole Add device
Figure 21 – SmartConsole Delete device
Device List
This list displays all discovered Web-Smart devices on the network.
Figure 22 – SmartConsole Device List
1
15 5

4 SmartConsole Utility D-Link Web Smart Switch User Manual
Definitions of the Device List features:
Monitor: Check the Monitor box and the SmartConsole will collect the trap and log data from the device. The
in the monitor means the device was discovered by SmartConsole. Click the icon to have the device keep
updating the information such as system log or trap to the SmartConsole Utility. The icon will become .
When the device was detected as not reachable, the icon will change to . Please check if the power or
the cable of this device is disconnected.
IP Address: Displays the current IP addresses of devices.
MAC Address: Displays the device MAC Addresses.
Protocol version: Displays the software version of the Utility.
Product Name: Displays the device product name.
System Name: Displays the appointed device system name.
DHCP: Specify if the device gets the IP address from a DHCP server.
Location: Displays where the appointed device location.
Trap IP: Displays the IP address of host where the Trap information will be sent to.
Subnet Mask: Displays the Subnet Mask setting of the device.
Gateway: Displays the Gateway setting of the device.
Device Group Interval: Displays the intervals (in seconds) that the Switch will be discovered in the
SmartConsole Device List
Firmware version: Displays the current Firmware version of this device.
LLDP: Displays the LLDP (Link Layer Discovery Protocol)status of the device. (Only for PoE model)
SNMP: Displays the SNMP status of the device.
NOTE: If the devices marked as red in the device
list, it means the devices require to upgrade
firmware again.
