AirPremier® N 2.4GHz High Power Access Point
DAP-2310
The DAP-2310 AirPremier N 2.4GHz High Power Access Point is a Single Band 802.11n
access point ideal for any small or medium business that requires reliable wireless
performance coupled with robust security in a cost eective and easy to deploy package.
With transfer rates of up to 300 Mbps in the 2.4 GHz N frequency range, users are able
to connect with legacy 802.11b/g adapters in addition to the latest 802.11n adapters to
enjoy faster downloads and instant communication.
Versatile Access Point
The DAP-2310 allows network administrators to deploy a highly manageable and
extremely robust 802.11n wireless network. The included antennas are detachable
and provide optimal wireless coverage in the 2.4 GHz (802.11g and 802.11n) band
using a high power radio design to reduce dead spots and increase capacity. For
advanced installations, this high-speed access point has integrated 802.3af Power
over Ethernet (PoE), making installation easy in areas where power outlets are not
readily available.
Enhanced Performance
The DAP-2310 delivers fast reliable wireless performance with maximum wireless signal
rates of up to 300 Mbps this coupled with support for Wi-Fi Multimedia (WMM™) Quality
of Service features, makes it an ideal access point for audio, video, and voice applications.
Additionally, the DAP-2310 supports load balancing features to ensure maximum
performance by limiting the maximum number of users per Access Point.
Features
Security Features:
• WPA2™ - Enterprise/Personal
• WPA™ - Enterprise/Personal
• WPA2™ - PSK/AES over WDS
• 64/128 -bit WEP Encryption
• MAC Address Filtering
• 802.1X
Easy Management:
• Web Browser (HTTP/HTTPS)
• Telnet
• SNMP v1, v2c, and v3
• AP Manager II
• SSH
• D-View 5.1 and 6.0
• AP Array
For Small Business-Class Environments
2.4GHz 802.11n connectivity for increased network
capacity, high power radio design and ideal for indoor
deployments.
Multiple Operation Modes
Access Point, Wireless Distribution System (WDS)/
Bridge, Point-to-Point, Point-to-Multiple-Points, WDS
with AP and Wireless Client modes.
High Performance Connectivity
IEEE 802.11n Wireless, Up to 300 Mbps transfer rates
and 1 10/100/1000 Gigabit PoE port.
Product Highlights

DAP-2310 AirPremier® N 2.4GHz High Power Access Point
Security
To help maintain a secure wireless network, the DAP-2310 provides the latest in
wireless security technologies including:
• Personal and Enterprise WPA and WPA2 (802.11i) Support
• RADIUS Authentication, MAC Address Filtering, Rogue AP Detection
• Wireless LAN segmentation with support for up to eight VLANs
• Disable SSID Broadcast and Wireless Broadcast Scheduling
• Wireless client isolation limiting direct client-to-client communication
Multiple Operation Modes
To maximize return on investment, the DAP-2310 can be congured to optimize
network performance based on any one of its multiple operation modes:
• Access Point, Wireless Client
• Wireless Distribution System (WDS)
• WDS with Access Point
With WDS support, network administrators can set up multiple DAP-2310 access
points throughout a facility and congure them to bridge with one another while
providing network access to individual clients. Advanced features such as Load
Balancing, optimizes high network trac volume with redundancy for fail-safe
wireless connectivity.
Network Management
Network administrators have multiple options for managing the DAP-2310,
including; internal Web interface (HTTP/HTTPS), Secure Sockets Layer (SSL),
Secure Shell (SSH) and Telnet. For advanced network management, administrators
can use the D-Link AP Manager II or D-View SNMPv3 management module
to congure and manage multiple access points from a single location. In
addition to a streamlined management process, the AP Manager II and D-View
software provides network administrators with the means to verify and
conduct regular maintenance checks remotely, eliminating the need to send
personnel out to physically verify proper operation.
With up to 300 Mbps 2.4 GHz N band functionality, extensive management
options, versatile operation modes, and Enterprise level security, the D-Link
DAP-2310 AirPremier N 2.4GHz High Power Access Point provides SMB and
SME environments with a powerful business-class wireless solution.
Front Back
Technical Specications
Standards
Standards • IEEE 802.11n
• IEEE 802.11g
• IEEE 802.3ab
• IEEE 802.3af
• IEEE 802.3u
• IEEE 802.3
Network Connectivity • 10/100/1000 Gigabit
Network Management/Service • Telnet - Secure (SSH) Telnet
• Web Browser Interface
• HTTP - Secure HTTP (HTTPS)
• SNMP Support
• D-View Module - Private MIB
• AP Manager II
• AP ArrayS
Security • WPA™ - Personal
• WPA2™ - Enterprise
• WPA2™ - Personal
• WPA2™ - Enterprise
• 64/128-bit WEP
• SSID Broadcast Disable
• MAC Address Access Control
• Rogue AP Detection
VLAN/SSID Support • 802.1q/Multiple SSID support up to 8
Quality of Service (QoS) • 4 Priority Queues • WMM Wireless Priority
Wireless Frequency Range • 2.4 GHz to 2.4835 GHz
Operating Modes • Access Point (AP)
• WDS with AP
• WDS/Bridge (No AP Broadcast)
• Wireless Client

Building Networks for People
©2012 D-Link Corporation/D-Link Systems, Inc. All rights reserved. D-Link, the D-Link logo, and D-ViewCam are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States and/or other countries. Other
trademarks or registered trademarks are the property of their respective owners. Visit www.dlink.com for more details.
D-Link Systems, Inc. | 17595 Mt. Herrmann Street | Fountain Valley, CA 92708 | 800.326.1688 | dlink.com
For more information
DAP-2310 AirPremier® N 2.4GHz High Power Access Point
1 Limited Lifetime Warranty available only in the USA and Canada. All references to speed are for comparison purposes only. Product specications, size and shape are subject to change without notice, and actual product appearance
may dier from that depicted herein.
Updated 02/02/12
Dipole Antenna Gain • 2 dBi @ 2.4 GHz
Maximum Transmit Output Power • FCC : 25 dBm
LEDs • Power
• LAN
• WLAN
General Specications
Max. Power Consumption • 9 watts
Operating Voltage • 5 V/2 A or PoE
Operating Temperature • 32 to 104 °F (0 to 40 °C)
Storage Temperature • -4° to 149° F (-20° to 65° C)
Operating Humidity • 10% to 90% non-condensing
Storage Humidity • 5% to 95% non-condensing
Weight • 0.525lbs (238 grams)
Certifications • FCC (Class B)
• CE
• WiFi®
Dimensions • Length: 4.4” (111mm)
• Width: 5.8” (148mm)
• Heigth: 1.1” (28mm)
Warranty
Warranty Limited Lifetime1
Order Information
Part Number Description
DAP-2310 DAP-2310 AirPremier® N 2.4GHz High Power Access Point
