Access Point
802.11g/2.4GHz Wireless
DWL-G700AP
Add Wireless Access to Your Network
D-Link, an industry leader in networking, introduces
the new D-Link AirPlus® G DWL-G700AP Access
Point. With the ability to achieve a maximum wireless
signal rate of up to 54Mbps,1 the DWL-G700AP gives
you high-speed wireless access for your home or office.
The DWL-G700AP is Wi-Fi IEEE 802.11g compliant,
meaning that it can connect and interoperate with other
802.11g compatible wireless routers, access points, and
adapters. The DWL-G700AP is also backwards
compatible with 802.11b networks and devices.
With its web-based setup wizard, the DWL-G700AP
ensures that you will be up and running on a wireless
network in just a matter of minutes. The DWL-G700AP
802.11g Wireless Technology
Up to 54Mbps1
WPA for Enhanced Wireless
Security
Quickly Add Wireless Access
to Your Network
Easy Web-based Configuration
and Management
also includes an embedded DHCP server that can
automatically assign IP addresses to wireless clients.
The DWL-G700AP features Wi-Fi Protected Access
(WPA) and 64/128-bit WEP Encryption to provide
an enhanced level of security for wireless data
communications. The DWL-G700AP also includes
additional security features to keep your wireless
connection safe from unauthorized access.
With easy-to-use Web-based management, the
DWL-G700AP is the right choice for setting up your
first wireless network or extending the range of an
existing wireless network.

Access Point
802.11g/2.4GHz Wireless
DWL-G700AP
The DWL-G700AP provides you with a simple
way to add wireless connectiviy to your home or
office network.
Standards
• IEEE 802.11b
• IEEE 802.11g
• IEEE 802.3
• IEEE 802.3u
Device Management
• Web-based — Internet Explorer v6 or
later; Netscape Navigator v6 or later; or
other Java-enabled browsers.
Data Rate1
For 802.11g:
• 54, 48, 36, 24, 18, 12, 9, and 6Mbps
For 802.11b:
• 11, 5.5, 2, and 1Mbps
Security
• 64/128-bit WEP
• WPA (Wi-Fi Protected Access)
• MAC address filtering
• SSID Broadcast Disable function
Wireless Frequency Range
• 2.412GHz to 2.462GHz
Wireless Operating Range2
• Indoors: Up to 328ft (100 meters)
• Outdoors: Up to 1312ft (400 meters)
Modulation Technology
• Orthogonal Frequency Division
Multiplexing (OFDM)
• Complementary Code Keying (CCK)
• BPSK
• QPSK
Receiver Sensitivity
IEEE 802.11g
• -65dBm @ PER10% in 54M 64QAM
• -66dBm @ PER10% in 48M 64QAM
• -70dBm @ PER10% in 36M 16QAM
• -74dBm @ PER10% in 24M 16QAM
• -77dBm @ PER10% in 18M QPSK
• -79dBm @ PER10% in 12M QPSK
• -81dBm @ PER10% in 9M BPSK
• -82dBm @ PER10% in 6M BPSK
IEEE 802.11b
• -82dBm @ PER8% in 11M CCK
• -85dBm @ PER8% in 5.5M CCK
• -87dBm @ PER8% in 2M QBSK
• -87dBm @ PER8% in 1M BPSK
Wireless Transmit Power
• 15dBm (32mW)±2dB
External Antenna Type
• Detachable dual antennas with 2dB gain
LEDs
• Power
• WLAN
• LAN (10/100)
Power
• External Power Supply: DC 5V/2A
• AC Adapter: 100V~120V
Temperature
• Operating: 32ºF to 131ºF (0ºC to 55ºC)
• Storing: -4ºF to 149ºF (-20ºC to 65ºC)
Humidity
• 5%~95% non-condensing
Certifications
• FCC part 15 class B & C
• Wi-Fi
Dimensions
• L = 5.59 inches (142mm)
• W = 4.29 inches (109mm)
• H = 1.22 inches (31mm)
Weight
• ~0.44lb (200g)
Warranty
• 1 Year
1 Maximum wireless signal rate based on IEEE Standard 802.11g
specifications. Actual data throughput will vary. Network conditions
and environmental factors, including volume of network traffic, building
materials and construction, and network overhead lower actual data
throughput rate.
2 Environmental conditions may adversely affect wireless signal range.
