Dürr Technik SICOLAB 062 User manual

EN
Oil-free compressor station SICO-
LAB
Installation and operating instructions
0626900100L02
*0626900100L02*
2204V006

Contents
Important information
1About this document .. . . . . . . . . . . . . 3
1.1 Warnings and symbols .. . . . . . . 3
1.2 Copyright information .. . . . . . . . 3
2 Safety .. . . . . . . . . . . . . . . . . . . . . . . . . 4
2.1 Intended use .. . . . . . . . . . . . . . . 4
2.2 Improper use .. . . . . . . . . . . . . . . 4
2.3 General safety information .. . . . . 4
2.4 Specialist personnel .. . . . . . . . . 4
2.5 Electrical safety .. . . . . . . . . . . . . 4
2.6 Only use original parts .. . . . . . . . 4
2.7 Transportation and storage .. . . . 5
2.8 Disposal .. . . . . . . . . . . . . . . . . . 5
Product description
3 Overview .. . . . . . . . . . . . . . . . . . . . . . . 6
3.1 Device without a membrane-dry-
ing unit (230 V) .. . . . . . . . . . . . . 6
3.2 Device with a membrane-drying
unit (230 V) .. . . . . . . . . . . . . . . . 6
3.3 Device with membrane-drying
unit (115 V) .. . . . . . . . . . . . . . . . 6
3.4 Wear parts and replacement
parts .. . . . . . . . . . . . . . . . . . . . . 7
4Technical data .. . . . . . . . . . . . . . . . . . . 8
4.1 Device without a membrane-dry-
ing unit (230 V) .. . . . . . . . . . . . . 8
4.2 Device with a membrane-drying
unit (230 V) .. . . . . . . . . . . . . . . . 9
4.3 Device with membrane-drying
unit (115 V) .. . . . . . . . . . . . . . . . 10
4.4 Pressure vessels for 230 V units .. 11
4.5 Instructions for use – pressure
vessels for 230 V units .. . . . . . . 12
4.6 Pressure vessels for 115 V units .. 13
4.7 Instructions for use – pressure
vessels for 115 V units .. . . . . . . 13
4.8 Type plate .. . . . . . . . . . . . . . . . . 14
4.9 Declaration of conformity for
machines in accordance with the
2006/42/EC Directive .. . . . . . . . 15
5 Operation .. . . . . . . . . . . . . . . . . . . . . . 16
5.1 Unit without membrane-drying
unit .. . . . . . . . . . . . . . . . . . . . . . 17
5.2 Unit with membrane-drying unit .. 17
Assembly
6 Requirements .. . . . . . . . . . . . . . . . . . . 18
7Pressure vessel test .. . . . . . . . . . . . . . 19
8 Commissioning .. . . . . . . . . . . . . . . . . . 19
8.1 Remove the packaging .. . . . . . . 19
8.2 Installing the spacer .. . . . . . . . . . 19
8.3 Establishing the compressed air
connection .. . . . . . . . . . . . . . . . 19
8.4 Condensate .. . . . . . . . . . . . . . . . 20
8.5 Electrical installation .. . . . . . . . . 20
8.6 Motor protection .. . . . . . . . . . . . 20
8.7 Overtemperature protection .. . . 20
Usage
9Operation .. . . . . . . . . . . . . . . . . . . . . . 21
9.1 Switching the unit on/off .. . . . . . 21
9.2 Start-up cycles .. . . . . . . . . . . . . 21
9.3 Setting the pressure reducer .. . . 21
10 Maintenance .. . . . . . . . . . . . . . . . . . . . 22
10.1 Maintenance schedule .. . . . . . . . 22
10.2 Preparations when replacing a
filter .. . . . . . . . . . . . . . . . . . . . . . 23
10.3 Replace the air intake filter car-
tridge .. . . . . . . . . . . . . . . . . . . . . 23
10.4 Replacing the filter of the mem-
brane drying unit .. . . . . . . . . . . . 24
10.5 Replacing the activated carbon
filter (if fitted) .. . . . . . . . . . . . . . . 25
Contents
0626900100L02 2204V006 1
EN

Troubleshooting
11 Tips for operators and service techni-
cians .. . . . . . . . . . . . . . . . . . . . . . . . . . 26
Contact
12 Addresses .. . . . . . . . . . . . . . . . . . . . . . 28
12.1 Returns / Repairs .. . . . . . . . . . . 28
12.2 To order spare parts .. . . . . . . . . 28
12.3 Service .. . . . . . . . . . . . . . . . . . . 28
12.4 Addresses worldwide .. . . . . . . . 28
Contents
2 0626900100L02 2204V006
EN

Important information
1 About this document
These installation and operating instructions rep-
resent a part of the unit.
In the event that the instructions and
notes in these installation and operating
instructions for are not observed, Dürr
Technik accepts no warranty or liability of
any kind for the safe operation and relia-
ble function of the units.
The German version of the installation and oper-
ating instructions is the original manual. All other
languages are translations of the original manual.
1.1 Warnings and symbols
Warnings
The warnings in this document are intended to
draw your attention to possible injury to persons
or damage to machinery.
The following warning symbols are used:
General warning symbol
Warning – dangerous high voltage
Warning – hot surfaces
Warning - automatic start-up of the unit
The warnings are structured as follows:
SIGNAL WORD
Description of the type and source of
danger
Here you will find the possible conse-
quences of ignoring the warning
❯Follow these measures to avoid the
danger.
The signal word differentiates between four levels
of danger:
–DANGER
Immediate danger of severe injury or death
–WARNING
Possible danger of severe injury or death
–CAUTION
Risk of minor injuries
–NOTICE
Risk of extensive material/property damage
Other symbols
These symbols are used in the document and on
or in the unit:
Note, e.g. specific instructions regarding
efficient and cost-effective use of the unit.
Comply with the specification in the
accompanying documents.
Dispose of the unit properly and in
accordance with applicable national,
regional and local laws.
CE labelling
Disconnect all power from the unit.
1.2 Copyright information
All names of circuits, processes, names, software
programs and units used in this document are
protected by copyright.
The reprinting of the installation and operating
instructions, even in extracts, is only permitted
with the written permission of Dürr Technik.
Important information
0626900100L02 2204V006 3
EN

2 Safety
Dürr Technik has developed and constructed the
units in such a way that danger is to a large
extent excluded if the units are used as intended.
Nevertheless, residual risks can remain. You
should therefore observe the following notes.
2.1 Intended use
The unit is intended for the compression of
atmospheric air. The unit has been designed for
operation in dry, ventilated rooms. The unit must
not be operated in a damp or wet environment.
Its use in the vicinity of gases or flammable liq-
uids is prohibited. Only operate the mobile units
in an upright position.
2.2 Improper use
Any use of this appliance / these appliances
above and beyond that described in the Installa-
tion and Operating Instructions is deemed to be
incorrect usage. The manufacturer cannot be
held liable for any damage resulting from incor-
rect usage. The operator will be held liable and
bears all risks.
WARNING
Serious injury and material damage
due to improper usage
❯Conveying explosive mixtures in any
way other than that specified is not
permitted.
2.3 General safety information
❯Always comply with the specifications of all
guidelines, laws, and other rules and regula-
tions applicable at the site of operation for the
operation of this unit.
❯Check the function and condition of the unit
prior to every use.
❯Do not convert or modify the unit.
❯Comply with the specifications of the Installa-
tion and Operating Instructions.
❯The Installation and Operating Instructions
must be accessible to all operators of the unit
at all times.
2.4 Specialist personnel
Operation
Unit operating personnel must ensure safe and
correct handling based on their training and
knowledge.
❯Instruct or have every user instructed in han-
dling the unit.
Maintenance, installation and repairs
Qualified Personnel Level I
❯Always have any maintenance work, e.g. filter
change, be performed by Dürr Technik or by
qualified personnel authorised and trained by
Dürr Technik.
Qualified Personnel "Level I" are defined as
those trained by Dürr Technik, who are familiar
with the unit technology, and are aware of the
dangers presented by the unit.
Qualified Personnel Level II
❯Always have any assembly work, readjust-
ments, alterations, extensions, and repairs be
performed by Dürr Technik or by technicians
authorised and qualified by Dürr Technik.
Maintenance work (see Level I) may also be
performed by Qualified Personnel Level II.
A technician (Qualified Personnel "Level II") has
completed a technical / electrotechnical train-
ing programme, is trained by Dürr Technik, is
familiar with the unit technology, and is aware
of the dangers presented by the unit.
Service manual
See the service handbook for a descrip-
tion of service and repair work.
2.5 Electrical safety
❯Observe and comply with all the relevant elec-
trical safety regulations when working on the
unit.
❯Replace any damaged cables or plugs immedi-
ately.
2.6 Only use original parts
❯Only use accessories and special accessories
that are specified or approved by Dürr Technik.
❯Only use original working and spare parts.
Important information
4 0626900100L02 2204V006
EN

Dürr Technik accepts no liability for dam-
age resulting from the use of non-
approved accessories, special accesso-
ries or any working parts or spare parts
other than original parts.
2.7 Transportation and storage
The original packaging provides optimum protec-
tion for the unit during transport.
Dürr Technik will not accept any responsi-
bility or liability for damage occurring dur-
ing transport due to the use of incorrect
packaging, even where the unit is still
under guarantee.
– Only transport the unit in its original packaging.
– Keep the packing materials out of the reach of
children.
WARNING
Risk of explosion of the pressure ves-
sel and pressure hoses
Serious personal injury and material
damage
❯The pressure vessel and the pressure
hoses must be vented before they are
stored or transported.
❯Protect the unit from moisture during
transportation.
❯Always transport the unit in an upright
position.
❯Only transport the unit using the trans-
port handles provided.
The unit may be stored in its original packaging
– in warm, dry and dust-free rooms;
– protected from contaminants.
If possible, retain the packaging material.
Ambient conditions during storage and
transport
Temperature °C -25 to +55
Relative
humidity
% 10% to 90%
2.8 Disposal
Unit
Dispose of the unit properly and in
accordance with applicable national,
regional and local laws.
Packaging
Dispose of the packaging material in an
environmentally responsible manner.
– Note current disposal routes.
– Keep the packing materials out of the reach of
children.
Important information
0626900100L02 2204V006 5
EN

Product description
3 Overview
3.1 Device without a membrane-drying unit (230 V)
Description Article no. Air intake filter
SICOLAB 062 0626 1100 l
SICOLAB 100 0626 2100 l
SICOLAB 200 0626 3100 l2x
LPresent
¾Not present
3.2 Device with a membrane-drying unit (230 V)
Name Article no. Intake
filter
Sinter fil-
ter
Fine filter
3 mm
Fine fil-
ter 0.01
mm
Activated
carbon fil-
ter
SICOLAB 062M 0626 1200 l l l ¾ ¾
SICOLAB 100M 0626 2200 l l l ¾ ¾
SICOLAB 200M 0626 3200 l2x l l ¾ ¾
SICOLAB 062MFA 0626 1220 l l ¾l l
SICOLAB 100MFA 0626 2220 l l ¾l l
SICOLAB 200MFA 0626 3220 l2x l¾l l
lpresent
¾not present
3.3 Device with membrane-drying unit (115 V)
Description Article no. Air intake
filter
Sintered
filter 3 mm fine
filter
0.01 mm
fine filter
Activated
carbon fil-
ter
SICOLAB 062M 0626 6200 lll¾ ¾
SICOLAB 100M 0626 7200 lll¾ ¾
LPresent
¾Not present
Product description
6 0626900100L02 2204V006
EN

3.4 Wear parts and replacement parts
Wearing parts for units without membrane drying system
The following wearing parts must be replaced at the specified maintenance intervals (see "10.1 Mainte-
nance schedule").
Spare parts for SICOLAB
062 / 100 / 200
Intake filter cartridge Standard Filter car-
tridge
0714200025
Wearing parts for units with membrane drying system
The following wearing parts must be replaced at the specified maintenance intervals (see "10.1 Mainte-
nance schedule").
Spare parts SICOLAB
062M /
100M /
200M
SICOLAB
062MFA /
100MFA /
200MFA
Intake filter cartridge Standard Filter car-
tridge
0714200025 0714200025
Fine filter 3 mm (for membrane drying unit) Filter car-
tridge
1610-121-00 ¾
Fine filter 0.01 mm (for membrane drying
unit)
Filter car-
tridge
¾9000-416-0035ET
Sinter filter (for membrane drying unit) Filter car-
tridge
1650100065 1650100065
Activated carbon filter (cartridge) Filter car-
tridge
¾0626100080
Spare parts and accessories
Turn lock key .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0626 0071
Fuse (mains fuse) 4.0 A .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1015200027
Fuse (mains fuse) 8.0 A .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1015200028
Fuse (mains fuse) 10.0 A .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1015200030
Fuse (mains fuse) 15.0 A .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1015200031
Compressed air pistol with hose .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0654 0720
Condensate container with outlet valve .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1650100130
Fuses, see "4 Technical data"
Product description
0626900100L02 2204V006 7
EN

4 Technical data
4.1 Device without a membrane-drying unit (230 V)
Electrical data SICOLAB
062
SICOLAB
100
SICOLAB
200
Electrical frequency Hz 50 50 50
Nominal voltage V 230 230 230
Rated power kW 0.47 0.96 1.41
Nominal current A 2.3 5.3 6.5
Mains fusing A 4 8 10
General data
Pressure vessel volume L 25 25 25
Delivery at 50 Hz and 5 bar
(0.5 MPa)
l/min 37 70 145
Delivery at 50 Hz and 7 bar
(0.7 MPa)
l/min 35 59 121
Duty cycle % 100 (S1) 100 (S1) 100 (S1)
Switch-on/cut-off pressure bar
(MPa)
6 - 8
(0.6 - 0.8)
6 - 8
(0.6 - 0.8)
6 - 8
(0.6 - 0.8)
Safety valve, maximum permis-
sible operating pressure
bar (MPa)
10 (1) 10 (1) 10 (1)
Dimensions (L x W x H) mm 510 x 580 x
653
510 x 580 x
653
510 x 580 x
653
Weight kg 66 76 93
Noise level dB(A) 48 52 54
Ambient conditions during operation
temperature °C +5 to +40 +5 to +40 +5 to +35
Relative humidity % Max. 95 Max. 95 Max. 95
Ambient conditions during storage and transport
Temperature °C -25 to +55
Relative humidity % 10% to 90%
Product description
8 0626900100L02 2204V006
EN

4.2 Device with a membrane-drying unit (230 V)
Electrical data |SICOLAB
062M/
062MFA
|SICOLAB
100M/
100MFA
|SICOLAB
200M/
200MFA
Mains frequency Hz 50 50 50
Nominal voltage V 230 230 230
Rated power kW 0.47 0.96 1.41
Nominal current A 2.3 5.3 6.5
Mains fuse A 4 8 10
General data
Pressure vessel volume L 25 25 25
Delivery at 50 Hz and 5 bar
(0.5 MPa)
l/min 37 59 122
Delivery at 50 Hz and 7 bar
(0.7 MPa)
l/min 31 47 97
Duty cycle % 100 (S1) 100 (S1) 100 (S1)
Switch-on/cut-off pressure bar
(MPa)
6 - 8
(0.6 - 0.8)
6 - 8
(0.6 - 0.8)
6 - 8
(0.6 - 0.8)
Safety valve, maximum permis-
sible operating pressure
bar (MPa)
10 (1) 10 (1) 10 (1)
Pressure dew point (according
to DIN ISO 8573-1)
Class
344
Dimensions (L x W x H) mm 510 x 580 x
653
510 x 580 x
653
510 x 580 x
653
Weight kg 68 78 95
Noise level dB(A) 48 52 54
Ambient conditions during operation
temperature °C +5 to +40 +5 to +40 +5 to +35
Relative humidity % Max. 95 Max. 95 Max. 95
Ambient conditions during storage and transport
Temperature °C -25 to +55
Relative humidity % 10% to 90%
Product description
0626900100L02 2204V006 9
EN

4.3 Device with membrane-drying unit (115 V)
Electrical data SICOLAB 062M SICOLAB 100M
Mains frequency Hz 60 60
Nominal voltage V 115 115
Rated power kW 0.56 1.15
Nominal current A 5.6 11.8
Mains fuse A 8 15.0
General data
Volume of pressure vessel l 25 25
Flow rate at 60 Hz and 5 bar
(0.5 MPa)
l/min 36 67
Flow rate at 60 Hz and 7 bar
(0.7 MPa)
l/min 30 54
Duty cycle % 100 (S1) 100 (S1)
Cut-in/cut-off pressure bar
(MPa)
6 - 8
(0.6 - 0.8)
6 - 8
(0.6 - 0.8)
Safety valve, max. permissible
operating pressure
bar (MPa)
10 (1) 10 (1)
Pressure dew point (according
to DIN ISO 8573-1)
Class
3 4
Dimensions (L x W x H) mm 510 x 580 x 653 510 x 580 x 653
Weight kg 77 89
Noise level dB(A) 49 53
Ambient conditions during operation
Temperature °C +5 to +40 +5 to +40
Relative humidity % max. 95 max. 95
Ambient conditions during storage and transport
Temperature °C -25 to +55
Relative humidity % 10% to 90%
Product description
10 0626900100L02 2204V006
EN

4.4 Pressure vessels for 230 V units
Pressure vessels from Behälter-Werk Burgau GmbH are installed in the unit.
The instructions for use given below apply to the following pressure vessel type:
Type Pressure1) Vessel2) APP3) c4) Remark5)
316054 / 5110-200-0051 PS 10 bars V 25 L B c = 0 mm 1; 6
For serial number and build year refer to the labelling on the vessel.
1)Pressure Maximum operating pressure PS in bar
2)Vessel Vessel volume V in litres
3)Application (APP) B = Pressure vessel for stationary systems
4)Corrosion allowance c in mm
Maximum tempera-
ture
+100 °C
Minimum temperature -10 °C
Medium Air/nitrogen
5)Remark 1:
The vessel is capable of sustained operation within a pressure fluctuation
range of
1.0 bar (10% PS).
6:
The condensate must be drained at internal pressure in accordance with the
operating instructions.
Applied standards EN 286-1:1998
Product description
0626900100L02 2204V006 11
EN

4.5 Instructions for use – pressure vessels for 230 V units
The pressure vessel shall only be used for the application specified above and in accordance with the
technical specifications. Safety reasons prohibit any other application. The pressure vessel has been
designed according to Directive 2014/29/EU as a single component without any safety equipment for
the above-mentioned application. Before putting the vessel into service, it shall be equipped with the
necessary safety devices, such as a pressure test gauge, safety devices for protection against exces-
sive pressure, etc. Such components are not part of our schedule of delivery. No welding or heat treat-
ment of any kind is permitted to those vessel walls which are exposed to pressure. It must be ensured
that the internal pressure will not permanently exceed the maximum working pressure „PS“ stipulated
on the vessel nameplate; however, it may momentarily do so by up 10 %. Suitable measures are to be
taken to prevent both, stress by vibrations and pulsating pressure as well as corrosion.
The pressure vessel shall be assembled in such a manner that sufficient safety is guaranteed during
operation of the vessel (for instance no rigid connection to the floor or to the machine base frame with-
out any vibration damper).
The detailed user’s guide provided by the equipment supplier shall contain in consideration of the equip-
ment parts:
Die vom Ausrüster zu erstellende Betriebsanweisung muss unter Berücksichtigung der Ausrüstungsteile
enthalten:
– a) instructions for condensation draining,
– b) specifications for maintenance, in order to ensure the operational safety.
Furthermore, the equipment supplier shall specify whether the pressure vessel ready for operation shall
be subjected to an inspection prior to its initial operation. The equipment supplier / operator shall
observe currently valid laws and regulations for the operation of pressure vessels in the particular coun-
try.
The design is based on predominantly stationary internal pressure, covering the following operating
parameters.
1000 load cycles from 0 to PS and resistant to a fatigue strength at a pressure variation range of 1,0 bar
(10% PS)
see"4.4 Pressure vessels for 230 V units" Remarks.
Product description
12 0626900100L02 2204V006
EN

4.6 Pressure vessels for 115 V units
Pressure vessels from Behälter-Werk Burgau GmbH are installed in the unit.
The instructions for use given below apply to the following pressure vessel type:
Type Pressure1) Vessel2) APP3) c4) Remark
316205 / 5110-200-0052 PS 10 bar V 25 l B c = 0 mm -
For serial number and build year refer to the labelling on the vessel.
1)Pressure Maximum operating pressure PS in bar
2)Vessel Vessel volume V in litres
3)Application (APP) B = Pressure vessel for stationary systems
4)Corrosion allowance c in mm
Maximum tempera-
ture
+100 °C
Minimum temperature -10 °C
Medium Air/nitrogen
Applied standards ASME Code, Section VIII Div. 1
4.7 Instructions for use – pressure vessels for 115 V units
The pressure vessel has been manufactured as a single component without safety equipment. The
pressure vessel must only be used in accordance with the aforementioned intended purpose and in
accordance with the specified technical data. Other forms of use are not permitted for reasons of safety.
It has been designed for predominantly static internal pressure loads.
Before commissioning, the vessel must be fitted with the necessary safety equipment such as a pres-
sure gauge and safety equipment designed to protect against overpressure, etc. These parts are not
included in our scope of delivery.
No welding work or heat treatment may be carried out on the pressure-retaining walls of the vessel.
Vibration stress that would be damaging for the pressure vessel and corrosion on the vessel must be
prevented using appropriate measures.
The pressure vessel must be assembled and installed in such a way that it remains safe to use (e.g. no
rigid connections to the floor or machine base frame without suitable vibration dampers).
The operating instructions to be provided by the equipment supplier must include the following informa-
tion in accordance with the equipment fitted:
– a) Instructions for draining the condensate
– b) Instructions and information about maintenance to ensure safety of use
The supplier must also specify whether the pressure vessel, when fully equipped for operation, has to
undergo an acceptance test before commissioning. The supplier/owner must observe the laws and reg-
ulations regarding the operation of the pressure vessel that apply in the country of operation.
Notes: None.
Product description
0626900100L02 2204V006 13
EN

4.8 Type plate
The type plate is located on the rear of the unit.
REF Order number
SN Serial number
This information is also required when order-
ing spare parts.
Product description
14 0626900100L02 2204V006
EN

4.9 Declaration of conformity for machines in accordance with the
2006/42/EC Directive
We hereby declare that the unit described below conforms to all requirements of the machine directive
2006/42/EC.
The unit named below fulfills the requirements of the following directives:
– Electromagnetic Compatibility (EMC) Directive 2014/30/EU
– Simple pressure vessel directive 2014/29/EU
– RoHS directive 2011/65/EU
Manufacturer's name: Dürr Technik GmbH & Co. KG
Manufacturer's address: Pleidelsheimer Straße 30
D-74321 Bietigheim-Bissingen
Reference number: 0626
Article designation: SICOLAB
From the serial number: H400000
We hereby declare that the unit may only be commissioned once it has been established that the
machine into which this unit is to be installed complies with the provisions as set out in Machinery Direc-
tive 2006/42/EC.
The following harmonised standards and other standards have been applied:
DIN EN 1012-1:2011-02
DIN EN 60034-1:2011-02
DIN EN 60034-5:2007-09
DIN EN 60335-1:2014-11
DIN EN 61000-6-2:2011-06
DIN EN 61000-6-3:2012-11
DIN EN 60204-1:2019-06
DIN EN ISO 12100:2013-08
Bietigheim-Bissingen, 20/04/2016
Andreas Ripsam Proof of signature in the
Executive Board of Dürr Technik Original document held by Dürr Technik
Product description
0626900100L02 2204V006 15
EN

5 Operation
4
5
6
12
3
7
4a
Fig. 1: SICOLAB 0626 3220 top view (without
unit cover)
1 Pressure vessel
2 Safety Valve
3 Pressure switch
4 Air intake filter
4a Air intake filter*
5 Membrane-drying unit (optional)
6 Activated carbon filter (optional)
7 Operating time counter
*only with the following unit versions:
SICOLAB 200/200M/200MF/200MFA
8
9
10
11
12 13
14
15
16
17
Fig. 2: SICOLAB 0626 3220 front view
8 Quick-release coupling (choked)
9 On/Off switch
10 Green LED – "Unit ready for operation"
11 Green LED – "Compressor running"
12 Red LED – "Temperature too high"
13 Unit cover lock
14 Unit cover
15 Pressure gauge
16 Carry handle
17 Pressure reducer
18
19
Fig. 3: SICOLAB 0626 3220 rear view
18 Compressed air connection (plug-in con-
nection Æ10 mm) (unchoked)
19 Power plug with fuses
Product description
16 0626900100L02 2204V006
EN

5.1 Unit without membrane-dry-
ing unit
The unit draws in atmospheric air and com-
presses it. It transports the oil-free compressed
air via the cooler to the pressure vessel. The oil-
free and filtered air is made available to the con-
sumers in the pressure vessel.
If compressed air is removed for a consumer, the
pressure in the vessel drops. When the switch-on
pressure is reached, the unit is automatically
switched on again via the pressure switch. When
the cut-off pressure is reached, the unit is auto-
matically switched off. A safety valve prevents the
maximum permissible vessel pressure from being
exceeded.
5.2 Unit with membrane-drying
unit
The unit draws in atmospheric air and com-
presses it. It transports the oil-free compressed
air to the membrane-drying unit. The cooler and
the membrane-dryer extract moisture from the
compressed air. The oil-free, hygienic and dry air
is stored in the pressure vessel ready for the con-
sumers.
If compressed air is removed for a consumer, the
pressure in the vessel drops. When the switch-on
pressure is reached, the unit is automatically
switched on again via the pressure switch. When
the cut-off pressure is reached, the unit is auto-
matically switched off. A safety valve prevents the
maximum permissible vessel pressure from being
exceeded.
Product description
0626900100L02 2204V006 17
EN

Assembly
6 Requirements
The room chosen for set up has to meet the fol-
lowing requirements:
– Closed, dry, well-ventilated room
– It should not be a room made for another pur-
pose (e.g. boiler room or wet cell)
– Set up the device on a clean, level, sufficiently
stable surface (minding the weight of the
device).
– Set up or install the device properly such that
the rating plate is easy to read and the device
is easily accessible for operation and mainte-
nance.
– Set up the device properly such that the outlet
to which the device is connected is easily
accessible.
– Room temperature: +5 °C to +40 °C (for
SICOLAB 062/062M/062MFA/100/100M/
100MFA).
– Room temperature: +5 °C to +35 °C (for
SICOLAB 200/200M/200MFA).
– Keep a sufficient distance from the wall to
allow air to freely flow in and out.
The air is filtered during intake. The air
composition remains unchanged. There-
fore, keep the intake air free of hazardous
substances (e.g. do not aspirate air from
an underground car park or right next to a
suction machine).
NOTICE
Risk of overheating due to insufficient
ventilation
The units generates heat. Possibility of
heat damage and/or reduced service life
of the unit.
❯Do not cover the unit.
❯Air must be able to flow in and out
unobstructed.
❯Ventilation openings must be suffi-
ciently large.
❯Installed units may require an inde-
pendent ventilation system in unfavour-
able cases.
The unit must only be operated on a stable, even
base. The unit must not be used as a climbing
aid. Danger of breakage!
Assembly
18 0626900100L02 2204V006
EN
