D.T. System ULTRA MIN-E 2090 User manual

1
No-Bark Dog Training Device
Owner’s Manual
Ultra
Ultra
Ultra
Small
Powerful
Control
D.T. Systems, Inc.
Ultra
TM
No-Bark Training Collar
Min-e2090

2
Congratulations and thank you for purchasing our
Ultra Min-e-2090TM No-Bark training collar. It is the
smallest, most compact No-Bark trainer in the world.
Please read this owners manual entirely before operating this
unit. Should you have any questions about our collars or their
operation please contact our Customer Service department.
(See last page for address and phone number information).
Table of Contents
• Ultra Min-e2090TM
No-Bark Training Collar Overview ....................... 3
• Main Features ........................................................ 3
• Operating Instructions............................................ 4
• Choosing the Correct Electrodes............................ 5
• Adjusting and Positioning Your Collar
for Proper Fit.......................................................... 6
• How to Change Battery.......................................... 7
• Battery Information & Energy Saving Tips........... 8
• How to Test Your Collar........................................ 9
• Important Notice
Read Before Using Collar...................................... 10
• Warranty and Repair .............................................. 11
• Contact Information ............................................... 12
IMPORTANT NOTE:

3
Min-e 2090TM
No-Bark Training Collar Overview
The Ultra Min-e-2090TM is the smallest and most versatile
No-Bark training collar in the world. The adjustable collar allows
this unit to fit the smallest of breeds to the largest (size can be
adjusted from 6 1/2 to 24 inches).
The Min-e-2090TM has been specially designed for the prevention
of excessive barking by automatically sending out an electrical
stimulation whenever problem barking occurs. This training system
is ideal for all dog temperaments from the most stubborn to the
meekest.
The collar is very compact, lightweight and waterproof. The eight
adjustable stimulation levels can be easily changed with the magnet
embedded right in the belt. This gives handlers the option of training
their dogs using the lowest electrical stimulation level possible.
Main Features
•Collar is compact, lightweight, and waterproof. It measures
approximately 1 1/4” x 1 7/8” and weighs just under 4
ounces.
•Patent pending magnetic on/off system with built in magnet
on collar clip. No more lost Magnets like other brands.
•Adjustable collar fits dog’s neck sizes from 6 1/2” to 24”.
•8 intensity levels (digital memory remembers last level
used).
•Microcomputer technology to maximize power and reliabil-
ity.
•Vibration Sensor only picks up vocal cord vibrations
eliminating unnecessary “shock” from extraneous noises or
dog’s tags.
•Automatic three second safety delay.
•Replaceable 6-volt alkaline or lithium battery.
•Stimulation tester, longer contacts and sensor, and first
battery are included.

4
Changing the Intensity Level
beeps. (The number of beeps and/or flashes indicates which
intensity level the unit is set on). Do not move the magnet until the
long beep stops. The unit is now on.
Turning the unit OFF
To turn the unit off, you simply reverse the procedure. Hold one of
the magnets directly up against the small letter “M”. You will hear a
long two-second beep immediately followed by a shorter beep and
the LED light will again flash with the beeping. Do not move the
magnet until the long beep stops. The unit is now off.
Ultra Min-e-2090TM
Once the unit is ON, you can change the Intensity level by
using one of the magnets. Slowly and steadily pass the magnet over
the small letter “M” on the collar. The unit will emit a series of
quick beeps to indicate the current intensity level. The LED light
will also flash the number of the level. For instance if the unit is on
level 3 you will hear 3 beeps and see 3 flashes, if the unit is on level
8 you will hear 8 beeps and see 3 flashes. There are eight levels.
After level Eight the unit will cycle back to level One.
Turning the unit ON
To turn on the unit you can
use either the key ring
magnet or the magnet in
the collar clasp. Hold one
of the magnets directly up
against the small letter
“M” on the front of the
Collar. You will hear a
long two-second beep
immediately followed by a
series of quick beeps. The
LED light beside the letter
“M” will flash with the

5
Even at low levels, dogs may yelp when stimulation is introduced
because it surprises them or it startles them and not because it is
hurting them. Do not make the mistake of rushing up and petting or
hugging the dog because you think that you hurt them. If you do
this the dog will learn that every time they feel the tingle they just
have to yelp and the tingle will stop and you will hug and pet them.
At low levels the dog feels a tickle. This tickle is the negative
response that the dog will associate with the problem barking. Low
level stimulation is a more effective way to train a dog. Low level
stimulation is less painful than swatting with a newspaper, spanking
with your hand or yelling at your dog. When done properly, low
level stimulation training is more humane, effective and mentally, a
better way to train your dog. For more information on how to train
with electronic No-Bark collars consult a professional trainer or buy
a “how to train” video or book on this subject from your local pet or
sporting goods retailer.
Basic Information on Use
IMPORTANT
When screwing in the electrodes and sensors, tighten by hand only.
Hand tightening will allow the electrodes to vibrate for maximum
stimulation. Never use a wrench.
Choosing the Correct Electrodes
The proper set of electrodes you should use is determined by which
set is long enough to make good contact with the dog’s skin. Good
contact is essential for the proper operation of the unit. Longer
haired dog’s will usually require the 1/2” contacts, and shorter
haired dogs the 3/8”.

6
Proper collar tightness is extremely
important. If the collar is too loose, it will
not function properly, and if the collar is too
tight, the
dog will
have
difficulty
breathing.
Adjusting and Positioning Your Collar
for Proper Fit
Proper collar tightness and position are very important to insure
safety and correct functioning every time you use the collar.
•All electronic collars need to be very snug to work properly. They
must be just tight enough to allow the “prongs” or electrodes to
make good skin contact.
•If your collar is too loose, the stimulation may not work properly
because good skin contact is not being achieved. This can directly
affect the stimulation performance and whether or not the dog will
receive the stimulation. Always check for good “prong” contact if
it appears that your dog is not responding to the stimulation.
•A loose collar can promote skin irritation when the collar moves or
rubs too much on a dog’s neck. The proper snug fit will help
prevent this from occurring.
•Proper fit of the collar is important. It should be just tight enough
on the dog’s neck to make good skin contact and allow the dog to
breath normally. The collar should never be so tight on the dog’s
neck that it restricts the dog’s normal breathing pattern.
•For proper positioning of your collar box, it should be placed on
the center of the dog’s neck. (see picture below).
•For how to adjust the collar strap see picture below.
To adjust the tightness & position of the collar

7
Never attach a leash or tie-out to the electronic No-Bark training
collar. This can cause excessive rubbing of the electrodes on the
dog’s neck which could create chafing, rash, hair loss or even
sores on the dog’s neck. Always remove the collar after each
training session. The collar should not be worn for more than
twelve continuous hours without removing or repositioning on
the dog’s neck. Always remove your collar and let the dog’s
neck rest. Some dogs have sensitive skin. Should signs of
irritation, redness, sores or chafing appear on the skin, remove
collar and do not use until the skin has completely cleared up.
CAUTION
How to Change the Battery
Step 1 : Unscrew A and B
Step 2 : Replace 6 Volt alkaline or lithium battery as
shown below.
NOTE
Watch “+” “-” while installing. If battery is installed
backward it may prevent the unit from working.

8
The Ultra Min-e-2090TM collar is the smallest, most innovative
and versatile dog training collar in the world. In order to make this
collar as small as possible, we designed it to be used with
replaceable/disposable batteries, instead of the larger bulkier
rechargeable type.
As a courtesy to our customers we have provided the first
battery for you. Replacements can be purchased at most retail
outlets where batteries are sold or directly from us.
A standard alkaline battery will give approximately one and a half
weeks of regular use. Using a 6 volt lithium battery instead of the
alkaline type can increase usage times by up to 300% approxi-
mately one month under normal testing conditions).
Battery Information and Energy Saving Tips
Some Helpful Hints and Tips to Maximize Battery Life:
• Always turn the unit off after each training session. Leaving the
collar turned on slowly drains the battery and lessens it’s life.
• Check your collar before storing to ensure that the unit is off.
• Whenever the collar is off of the dog’s neck make sure that the
collar is clipped together. This will help prevent the collar mag-
net from accidentally touching the magnetic switch on the re-
ceiver and turning the unit on.
• Hang your collar on a door or wall hook or a key ring rack
whenever it is not in use. This will not only prevent accidental
activation but will also give you easy access to the collar when
you need it.
• If you store your collar in a drawer or on a shelf or other flat
surface, keep your key ring magnet separated and away from the
collar receiver to help prevent accidental activation. Occasion-
ally check your collar, when not in use or stored, to ensure that it
has not been activated.

9
• If you store your collar in a drawer or on a shelf or other flat
surface, keep your key ring magnet separated and away from the
collar receiver to help prevent accidental activation. Occasion-
ally check your collar, when not in use or stored, to ensure that it
has not been activated.
• As with any electronic device which uses replaceable/disposable
type batteries it is always recommended that you keep an extra
set of batteries on hand. This will prevent any training delays
when the batteries need to be replaced.
How to Test Your Collar
A) Place the contact terminals of the
test lamp firmly onto the
electrodes of the receiver.
B) Set the stimulation to level 5 or 6.
C) Use the serrated edge of the test
light and gently rub it across the
sensor.
D) A red light on the test light should
light up.
NOTE
When rubbing the serrated edge of the test light across
the sensor do not press down hard. Instead run the tester
all the way from one end to the other with a quick motion
using a very light amount of downward pressure. Do not
be discouraged if it takes a few tries to get the hang of it.

10
Important Notice -Read Before Using Collar
•To prevent accidental stimulation never touch the metal
electrode when handling the collar.
•To minimize accidental stimulation to the dog never leave your
dog unattended while wearing an electronic device.
•Never allow anyone to handle or use your collar on a dog unless
they have fully read and understand this manual. Proper use of
the collar is extremely important.
•Allows check with your veterinarian to assure that your dog has
no physical health problems or genetic defects which would
make the use of an electronic training device unsafe.
•If you have never used an electronic training collar before,
consult a professional trainer, read books or watch videos on
training with electronic devices to assure that you fully
understand the proper use of and correct training methods to use
with your new electronic collar.
•For best results, always train at the lowest possible stimulation
level that will make the correction in your dog’s behavior. This
level may change in different training situations, and from dog to
dog.
•This is an authorized training device to help correct and change
unwanted behavior in dogs and other domestic animals. Any
other unauthorized use is strictly prohibited.
•Our electronic training devices, when used correctly, are very
humane and effective. They can help train obedience and build a
positive bond between a dog owner and their dog.
•If you have any questions in regards to our products, please con-
tact our Customer Service department. (See last page for address
and phone number information).

11
Warranty and Repair
All Ultra Min-e-2090TM No-Bark training collars have a
one year Parts and Labor Warranty, effective from the
original date of purchase. (A copy of the original sales
receipt is required to validate the date of purchase).
NOTE
Ultra Min-e-2090TM batteries are replaceable/disposable
and are not covered under the warranty.
Damage by user, abuse or loss of parts, and
attempted repair damage by the user or his
agent are not covered by warranty. All
repairs, whether warranted or not, should be
sent to the address on the last page of this
manual.

12
D.T. Systems, Inc.
2872 Walnut Hill Lane
Dallas, Texas 75229
Tel: [phone], (888) LUV-U-DOG
Fax: [phone]
Website: http://www.dtsystems.com
E-mail: [email protected]
