INSTALLATION
INSTRUCTIONS
Preference™Handle Kit,
PN AFP36H2
REFRIGERATOR MODELS: EF36LNFSS and EF36RNFSS
Installation Preparation:
STEP 1: Using a T20 Torx driver, remove the four (4)
handle mounting studs from the front of the
refrigerator. Retain the mounting screws and
studs.
Handle Mounting
Stud Locations
Existing handle
mounting screw
(keep)
Existing mounting
stud (keep)
Part No. 106238 Rev. A
Parts Included Preference Style Handles (1 large, 1 small)
Plastic Washers (4)
Tools Required
3/32” Allen wrench (not supplied)•
T20 Torx driver (EF36BNFSS Only)•
Model EF36RNFSS shown

Page 2
Refrigerator Handle Kit Installation Instructions
STEP 2: Reinstall the the screws and studs removed in step 1, inserting the provided plastic wash-
ers between the base of the studs and the refrigerator doors as shown.
Handle Mounting
Stud Locations
Mounting Stud
Plastic Washer
Screw
Handle Mounting
Studs
Set Screw Holes
Bottom (Freezer) Handle Installation
STEP 3: Find the smallest of the two handles in the kit
box.
STEP 4: Mount the handle to the bottom drawer by
sliding the holes on the back over the handle
mounting studs on the refrigerator. Make sure
the set screw holes on the handle are facing
toward the bottom. You may need to loosen
the set screws using a 3/32” Allen wrench to
allow the handle to slide into place.
STEP 5: Carefully tighten the set screws into place us-
ing the 3/32” Allen wrench. Be careful not to
scratchthenish.
STEP 6: Checktomakesurethehandleisrmly
attached.
Model EF36RNFSS
shown

Refrigerator Handle Kit Installation Instructions
Page 3
Top Handle Installation
STEP 7: Mount the handle to the top door
by sliding the holes on the back
over the handle mounting studs on
the right door. Make sure the set
screw holes face away from the
center of the refrigerator. Loosen
the set screws if necessary to al-
low the handle to slide into place.
STEP 8: Carefully tighten the set screws
into place using the 3/32” Allen
wrench. Be careful not to scratch
thenish.
STEP 9: Check to make sure the handle is
rmlyattached.
Handle Mounting
Studs
Set Screw
Holes
NOTE: Refrigerator with right
door swing shown. On models
with hinges on left, mount the
handle to the opposite side.
