Dacor DOC30M977 Technical manual

Planning Guide
Combination Speed Oven
DOC30M977
DACOR MOERNIST

UNIT
CONTROL
Flat aluminum
(Graphite or SILVER)
HANDLE
Flat aluminum
(Graphite or SILVER)
GLASS
Smog glass, Black printing with silver logo
(Transparency 33%)

PLANNING CHECK PROCESS
PLANNING CHECK PROCESS
①Combi oven configuration
②Plan the cutout Width and Depth
· depending on install method
(Standard or Flush install)
③Plan the cutout Height
· depending on install method
and configuration
(Combi Speed Oven)
④Check for interference with
other appliances
· Allow a min. 22” for clearance
when door is open
⑤Check proper location for
the electrical outlet ⑥Procure the proper
installation materials

Configuration
MW Combi Double Oven
Width 30”(Lower oven)
Control Panel Silver or Graphite Aluminum
Handle Silver or Graphite Aluminum
MW Combi Double Oven
①Combi oven configuration
DOC30M977DS (Silver)
DOC30M977DM (Graphite)

②Plan the cutout Width and Depth
· depending on install method
(Standard or Flush install)
③Plan the cutout Height
· depending on install method and
configuration
It is important to observe the specified dimensions of the installation cutout for a trouble-
free installation of the appliance.
- The appliance can be installed two ways, STANDARD INSTALL or FLUSH INSTALL, Note:
cabinet cut out dimensions are different for each method.
- Standard install needs recessed dimensions and Flush install needs overall dimensions.
-Detailed install dimensions can be confirmed by reviewing the Installation Instructions.
-Install the COMBI OVEN at least 12"(30cm) away from other appliances.
Appliance dimensions
TOP VIEW SIDE VIEW
STANDARD
INSTALL
(Refer to
the recessed
dimensions)
FLUSH
INSTALL
(Refer to
the overall
dimensions)
2812
⁄
”
2934
⁄
”
42”
43 916
⁄
”

④Check for interference with
other appliances
· Allow a min. 22” for clearance
when door is open
Cabinet dimensions
⑤Check proper location for
the electrical outlet
■Combi Speed Oven_Standard

■Combi Speed Oven_Flush
Cabinet dimensions

ELECTRICAL SPECIFICATIONS
Electrical specification

⑥Procure the proper
installation materials
Preparation for install

30-Inch MW Combi Speed Double Oven
Total Capacity (cu. ft.)
Product Width
Product Height
Product Depth
1.9 + 4.8
29 3/4"
43 9/16"
23 1/8"
Cutout Width
Cutout Height
Cutout Depth
30 1/4"
43 11/16"
24 7/8"
Watts(W)
Electrical Supply
Power Cord
Net Weight (lbs.)
8.9 KW
240VAC/50A/60Hz
Fixed Connection
(No Plug Type)
302.9 lbs. (137.4Kg)
DOC30M977DS / DOC30M977DM
General
(Upper : MWO)
Oven Color Silver STSS / Graphite STSS
Installation Type Flush
Handle Fixed Bar Type
Cooking
Mode
(12ea)
Manual
(5)
Microwave, Broil, Speed Broil
Convection Sear, Speed Conv. Sear
Auto
(7)
Sensor Cook , Con.Sear Autocook
Healty Fry, Defrost, Healty Choice
Auto Cook(69 Programs), Soften/Melt (8 Programs)
Oven Rack 2 Rack (Low, High)
Rack Position -
Interior Lights 2 LED
Hidden Hinge Door ●
Cleaning Method -
Control
Display 7” Touch LCD
Electronic Clock ●
Child Lock ●
Oven Performance
(Upper : MWO)
MWO Output 950W (@ 120V )
Bake element -
Broil element 1,650W
Convection Heater 3,250W
Smart Wi-Fi (LTE) Module ●
Bluetooth -
※Cutout Dimensions are for Flush Cabinet
Product Specification
※Lower Oven Spec .is same with Single Wall Oven
