Installation Manual
Dual Fuel Pro Range
DOP36P86DLS
Install_DOP36P86DLS_DG68-01106E-00_EN+MES+CFR.indb 1 2020-07-01 오후 3:44:01

2 English
ANTITIP DEVICE
WARNING
ALL RANGES CAN TIP, RESULTING IN PERSONAL INJURY.
TIPPING RANGES CAN CAUSE BURNS FROM SPILLS,
PERSONAL INJURY, AND/OR DEATH.
INSTALL AND CHECK THE ANTI-TIP BRACKET FOLLOWING
THE INSTRUCTIONS AND TEMPLATE SUPPLIED WITH THE
BRACKET.
• To prevent accidental tipping of the range, attach an approved
anti-tip device to the oor. (See Installing the Anti-Tip Device
in the Installation Instructions.) Check for proper installation by
carefully tipping the range forward. The anti-tip device should
engage and prevent the range from tipping over.
• If the range is pulled out away from the wall for any reason,
make sure the anti-tip device is reengaged after the range has
been pushed back into place.
• Follow the installation instructions found in the Installation
Manual. Failure to follow these instructions can result in death,
serious personal injury, and / or property damage.
• DO NOT step / sit / lean on the door or drawer to prevent
accidental tipping of the range.
WARNING: If the information in this manual is not followed exactly,
a re or explosion may result causing property damage, personal
injury or death.
• DO NOT store or use gasoline or other ammable vapors and
liquids in the vicinity of this or any other appliance.
• WHAT TO DO IF YOU SMELL GAS:
-DO NOT try to light any appliance.
-DO NOT touch any electrical switch.
-DO NOT use any phone in your building.
-Immediately call your gas supplier from a neighbor’s phone.
Follow the gas supplier’s instructions.
-If you cannot reach your gas supplier, call the re
department.
• Installation and service must be performed by a qualied
installer, service agency, or the gas supplier.
Install_DOP36P86DLS_DG68-01106E-00_EN+MES+CFR.indb 2 2020-07-01 오후 3:44:01

English 3
Contents
Contents
Before you begin 4
About this manual 4
Important safety information 4
Read all instructions before using this appliance 4
Symbols used in this manual 4
California Proposition 65 Warning 5
Commonwealth of Massachusetts 5
General safety 5
Fire safety 6
Gas safety 6
Electrical and grounding safety 7
Installation safety 7
Location safety 8
Cooktop safety 8
Oven safety 9
Self-cleaning oven safety 10
Gas range components 10
Dual Fuel range specications 10
Installation requirements 12
Location requirements 12
Installation guide 13
To remove safely from the pallet 14
To avoid breakage 14
Gas requirements 15
Special gas requirements (gas models sold in Massachusetts) 16
Electrical requirements 16
Tools and materials 18
What’s in the box 18
Installation instructions 19
Installing your Dual fuel Range 19
Install_DOP36P86DLS_DG68-01106E-00_EN+MES+CFR.indb 3 2020-07-01 오후 3:44:01

4 English
Before you begin
Important safety information
Read all instructions before using this appliance
• All electrical and gas equipment with moving parts can be dangerous. Please
read the important safety instructions for this appliance in this manual. The
instructions must be followed to minimize the risk of injury, death, or property
damage.
• Save this manual. Please Do Not Discard.
Symbols used in this manual
WARNING
Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in electric shock, personal injury or
property damage
NOTE
Useful tips and instructions
These warning icons and symbols are here to prevent injury to you and others.
Please follow them explicitly. After reading this section, keep it in a safe place for
future reference.
Before you begin
About this manual
Read these instructions completely and carefully.
Important note to the installer
• Read all instructions contained in these installation instructions before
installing the range.
• Remove all packing materials from the oven compartments before connecting
the electric and gas supply to the range.
• Observe all governing codes and ordinances.
• Be sure to leave these instructions with the consumer.
• Installation of this appliance requires basic mechanical skills.
• Proper installation is the responsibility of the installer.
• Product failure due to improper installation is not covered under the Warranty.
Important note to the consumer
Keep these instructions with your user manual for future reference.
• As when using any appliance generating heat, there are certain safety
precautions you should follow.
• Be sure your range is installed and grounded properly by a qualied installer
or service technician.
• Make sure the wall coverings around the range can withstand the heat
generated by the range.
• Cabinet storage space above the surface burners should be a minimum of
30 in (76.2 cm).
Important note to the servicer
The electrical diagram is in an envelope attached to the back of the range.
Install_DOP36P86DLS_DG68-01106E-00_EN+MES+CFR.indb 4 2020-07-01 오후 3:44:01

English 5
Important safety information
• Remove all packaging materials from the range before operating to prevent
ignition of these materials. Keep all packaging materials out of children’s
reach. Properly dispose the packaging materials after the range is unpacked.
• Do not store any object of interest to children on the cooktop or backguard
of the range. Children climbing on the range to reach items could be killed or
seriously injured.
• Do not operate the range if the range or any part of the range is damaged,
malfunctioning, or missing parts.
• Do not use the range as a space heater. This range is to be used for cooking
purposes only.
• Do not use oven cleaners or oven liners in or around any part of the oven.
• Use only dry pot holders.
• Do not use the range to heat unopened food containers.
• Do not strike the oven glass.
• When disposing of the range, cut off the power cord and remove the door.
• Unplug or disconnect power before servicing.
• Make sure all meat and poultry is cooked thoroughly. Meat should always be
cooked to an internal temperature of 160 °F (71 °C). Poultry should always be
cooked to an internal temperature of 180 °F (82 °C).
California Proposition 65 Warning
WARNING
Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
Commonwealth of Massachusetts
This product must be installed by a licensed plumber or gas tter qualied or
licensed by the State of Massachusetts. When using ball-type gas shut-off valves,
you must use the T-handle type. Multiple exible gas lines must not be connected
in series.
General safety
WARNING
To reduce the risk of re, electric shock, personal injuries, and/or death, obey the
following precautions.
• Do not touch any part of the range,
including but not limited to, oven
burners, surface burners, or interior
surfaces during or immediately after
cooking.
• Know the location of the gas shut-
off valve and how to shut it off.
• Make sure the anti-tip device is properly installed on the range. See the
installation instructions for more information.
• Do not let children near, in, or on the range. Do not let children play with the
range or any part(s) of the range. Do not leave children unattended in an area
where the range is in use. For children’s safety, we recommend utilizing the
control/door lockout feature.
Install_DOP36P86DLS_DG68-01106E-00_EN+MES+CFR.indb 5 2020-07-01 오후 3:44:02

6 English
Important safety information
Important safety information
Gas safety
WARNING
To reduce the risk of re, electric shock, personal injuries, and/or death, obey the
following precautions.
If you smell gas:
• Close the valve and do not use the
range.
• Do not light a match, candle, or
cigarette.
• Do not turn on any gas or electric
appliances.
• Do not touch any electrical switches
or plug a power cord into an outlet.
• Do not use any phone in your building.
• Evacuate the room, building, or area of all occupants.
• Immediately call your gas supplier from a neighbor’s phone. Follow the gas
supplier’s instructions.
• If you cannot reach your gas supplier, call the re department.
Checking for gas leaks
• Leak testing of the appliance shall be conducted according to the
manufacturer’s instructions. Do not use a ame to check for gas leaks. Use a
brush to spread a soapy water mixture around the area you are checking. If
there is a gas leak, you will see small bubbles in the soapy water mixture at
the leak point.
Fire safety
WARNING
To reduce the risk of re, electric shock, personal injuries, and/or death, obey the
following precautions.
• Do not store, place, or use ammable
or combustible materials such as
charcoal, paper, plastic, pot holders,
linens, curtains, gasoline or other
ammable vapors or liquids near or
inside the range.
• Do not wear loose tting or hanging
garments while using the range.
• To avoid grease buildup, regularly clean the vents.
• Do not let pot holders or other ammable materials touch a heating element.
Do not use a towel or other bulky cloths in place of a pot holder.
• Do not use water on a grease re. To put out a grease re, turn off the heat
source and smother the re with a tight-tting lid or use a multipurpose dry
chemical or foam-type re extinguisher.
• If a grease re should occur in the oven, turn off the oven by rotating the
mode selector knob to the OFF position. Keep the oven door closed until the
re goes out. If necessary, use a multipurpose dry chemical or foam-type re
extinguisher.
• Do not heat unopened food containers - buildup of pressure may cause
container to burst and result in injury.
Install_DOP36P86DLS_DG68-01106E-00_EN+MES+CFR.indb 6 2020-07-01 오후 3:44:02

English 7
Important safety information
Installation safety
WARNING
To reduce the risk of re, electric shock, personal injuries, and/or death, obey the
following precautions.
∗
• Have your range installed and
properly grounded by a qualied
installer, in accordance with the
installation instructions. Any
adjustment and service should
be performed only by qualied
gas range installers or service
technicians.
• Do not attempt to service, modify, or replace your range or any part of your
range unless it is specically recommended in this manual. All other service
should be referred to a qualied technician.
• Always use new exible connectors when installing a gas appliance. Do not
use old exible connectors.
• Make sure the anti-tip device is properly installed on the range. See the
installation instructions for more information.
• Due to the size and weight of the range, have two or more people move the
range.
• Remove all tape and packaging materials.
• Remove all accessories from the cooktop and oven. Grates are heavy. Use
caution when handling them.
• Make sure no parts came loose during shipping.
Electrical and grounding safety
WARNING
To reduce the risk of re, electric shock, personal injuries, and/or death, obey the
following precautions.
• Plug into a grounded 3-prong outlet.
• Do not remove the ground prong.
• Do not use an adapter or an
extension cord.
• Do not use a damaged power plug,
power cord, or loose power outlet.
• Do not modify the power plug,
power cord, or power outlet in any
way.
• Do not put a fuse in a neutral or ground circuit.
• Use a dedicated 240-volt, 60-Hz, 40-amp, AC, fused electrical circuit for this
range. A time-delay fuse or circuit breaker is recommended. Do not plug more
than one appliance into this circuit.
• Do not connect the ground wire to plastic plumbing lines, gas lines, or hot
water pipes.
• This range must be Earth grounded. In the event of a malfunction or
breakdown, grounding will reduce the risk of electrical shock by providing
a path for the electric current. This range is equipped with a cord having
a grounding plug. The plug must be rmly plugged into an outlet that is
properly installed and grounded in accordance with the local codes and
ordinances. If you are unsure whether your electrical outlet is properly
grounded, have it checked by a licensed electrician.
• Electrical service to the range must conform to local codes. Barring local
codes, it should meet the latest ANSI/NFPA No. 70 – Latest Revision (for the
U.S.) or the Canadian Electrical Code CSA C22.1 – Latest Revisions.
• It is the personal responsibility of the range owner to provide the correct
electrical service for this range.
Install_DOP36P86DLS_DG68-01106E-00_EN+MES+CFR.indb 7 2020-07-01 오후 3:44:02

8 English
Important safety information
Important safety information
• Select a location where a grounded, 3- prong outlet is easily accessible.
• If the range is located near a window, do not hang long curtains or paper
blinds on that window.
• For the range to ventilate properly, make sure the range’s vents are not
blocked or covered, and that there is enough clearance at the top, back, sides,
and underneath the range. The vents allow the necessary exhaust for the range
to operate properly with correct combustion and get the good cooking result.
• Make sure the wall coverings around the range can withstand heat up to
194 °F (90 °C) generated by the range.
• Cabinet storage above the surface of the range should be avoided. If cabinet
storage above the range is necessary: allow a minimum clearance of 30 inches
(76.2 cm) between the cooking surface and the bottom of cabinets. For detail
information, please refer to the Minimum dimensions section on page 13.
Cooktop safety
WARNING
To reduce the risk of re, electric shock, personal injuries, and/or death, obey the
following precautions.
• Make sure all burners are off when not
in use.
• Do not use aluminium foil to line the
grates or any part of the cooktop.
• Do not leave burners unattended on
medium or high heat settings.
• Before igniting, make sure all burner
caps are properly in place and all
burners are level.
• Always use the Lite ( )position when igniting the burners and make sure the
burners have ignited. If ignition fails, turn the knob to OFF and wait until the
gas has dissipated.
• When you set a burner to simmer, do not turn the knob quickly. Make sure the
ame stays on.
• Do not place any objects other than cookware on the cooktop.
• This cooktop is designed to cook with a wok or wok ring attachment. If foods
are amed, they should only be amed under a ventilation hood that is on.
• Make sure your range is correctly installed and adjusted by a qualied service
technician or installer for the type of gas (natural or LP) you will use. For
your range to utilize LP gas. The installer must replace the 6 surface burner
orices with the provided LP orice set. And reverse the GPR adapter. These
adjustments must be made by a qualied service technician in accordance
with the manufacturer’s instructions and all codes and requirements of the
authority having jurisdiction. The qualied agency performing this work
assumes the gas conversion responsibility.
• Installation of this range must conform with local codes or, in the absence of
local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA.54, latest
edition. In Canada, installation must conform with the current Natural Gas
Installation Code, CAN/CGA-B149.1, or the current Propane Installation Code,
CAN/CGA-B149.2, and with local codes where applicable. This range has been
design-certied by ETL according to ANSI Z21.1, latest edition, and Canadian
Gas Association according to CAN/CGA-1.1, latest edition.
Location safety
WARNING
To reduce the risk of re, electric shock, personal injuries, and/or death, obey the
following precautions.
• This range is for indoor, household use
only. Do not install the range in areas
exposed to the weather and/or water.
• Do not install the range in a place
which is exposed to a strong draft.
• Select a level, well-constructed oor that can support the range’s weight.
Synthetic ooring, such as linoleum, must withstand 180 °F (82 °C)
temperatures without shrinking, warping, or discoloring. Do not install
the range directly over interior kitchen carpeting unless a sheet of ¼ inch
plywood or a similar insulator is placed between the range and carpeting.
Install_DOP36P86DLS_DG68-01106E-00_EN+MES+CFR.indb 8 2020-07-01 오후 3:44:02

English 9
Important safety information
Oven safety
WARNING
To reduce the risk of re, electric shock, personal injuries, and/or death, obey the
following precautions.
• Do not use the oven for non-cooking
purposes such as drying clothes or
storage. Use the oven for cooking
purposes only.
• Make sure the inner portion of the split
oven-rack is in the proper position
within the outer rack.
• Make sure the oven racks are placed on the same level on each side.
• Do not damage, move, or clean the door gasket.
• Do not spray water on the oven glass while the oven is on or just after you
have turned it off.
• Do not use aluminium foil or foil liners anywhere in the oven. Do not use
aluminium foil or like material to cover any holes or passages in the oven
bottom or to cover an oven rack.
• Stand away from the oven when opening the oven door.
• Keep the oven free from grease buildup.
• When repositioning the oven racks, make sure the oven is completely cool.
• To avoid damaging the burner control knobs, always bake and/or broil with
the oven door closed.
• Do not broil meat too close to the burner ame(or heater). Trim excess fat
from meat before cooking.
• When using cooking or roasting bags in the oven, follow the manufacturer’s
directions.
• Before removing or changing cookware, turn off the burners.
• Remove food and cookware immediately after cooking.
• Before removing any parts of the burner for cleaning, make sure the range is
off and completely cool.
• After cleaning the burner spreader, make sure it is completely dry before re-
assembling.
• Make sure the spark mark on the dual burner spreader is placed beside the
electrode when it is assembled.
• To avoid carbon monoxide poisoning, do not pour water into the cooktop well
while cleaning.
• Select cookware that is designed for top-range cooking. Use cookware that is
large enough to cover the burner grates. Adjust the burner ames so that the
ames do not extend beyond the bottom of the cookware.
• To avoid cookware discoloration, deformity, and/or carbon monoxide
poisoning, do not use cookware that is exceedingly larger than the grate.
• Make sure cookware handles are turned to the side or rear of the cooktop, but
not over other surface burners.
• Stand away from the range while frying.
• Always heat frying oils slowly, and watch as they heat. If you are frying foods
at high heat, carefully watch during the cooking process. If a combination of
fats or oils is to be used during frying, mix them together before heating.
• Use a deep-fryer thermometer whenever possible. This prevents overheating
the fryer beyond the smoking point.
• Use a minimum amount of oil when shallow pan-frying or deep-frying. Avoid
cooking unthawed food or food with excessive amounts of ice.
• Before moving cookware full of fats or oils, make sure it has completely
cooled.
• To prevent delayed eruptive boiling, always allow heated liquids to stand at
least 20 seconds after you have turned off the burner so that the temperature
in the liquid can stabilize. In the event of scalding, follow these rst aid
instructions:
1. Immerse the scaled area in cool or lukewarm water for at least
10 minutes.
2. Do not apply any creams, oils, or lotions.
3. Cover with a clean, dry cloth.
Install_DOP36P86DLS_DG68-01106E-00_EN+MES+CFR.indb 9 2020-07-01 오후 3:44:03

10 English
Gas range components
Important safety information
Self-cleaning oven safety
WARNING
To reduce the risk of re, electric shock, personal injuries, and/or death, obey the
following precautions.
• The self-cleaning feature operates the
oven at temperatures high enough
to burn away food soils in the oven.
The range is extremely hot during a
self-cleaning cycle. Do not touch any
surfaces of the range during a self-
cleaning cycle.
• Keep children away from the oven during a self-cleaning cycle.
• Before starting a self-cleaning cycle, remove all racks, cookware, and utensils
from the oven. Only porcelain-coated oven racks may be left in the oven.
• Before starting a self-cleaning cycle, wipe grease and food soils from the
oven.
• When opening the door after a self-cleaning cycle, stand away from the oven.
• If the self-cleaning cycle malfunctions, turn off the oven, disconnect the power
supply, and contact a qualied service technician.
Gas range components
Dual Fuel range specications
MODEL DOP36P86DLS
Description Dual fuel Range
Overall dimensions 35 ⅞ in (W) × 37 ¼ in (H) × 29 ½ in (D)
911 mm (W) × 946 mm (H) × 750 mm (D)
Electrical Refer to the rating label.
Gas, NG (natural gas) 5–13 in WC
Gas, LP (liquid propane) 10–13 in WC
Surface burners (NG) (LF)–22,000 BTU / (LR)–16,000 BTU
(RF)–22,000 BTU / (RR)–16,000 BTU
(CF)–16,000 BTU / (CR)–16,000 BTU
Surface burners (LP) (LF)–16,500 BTU / (LR)–14,500 BTU
(RF)–16,500 BTU / (RR)–14,500 BTU
(CF)–14,500 BTU / (CR)–14,500 BTU
Oven heater Bake - 3000 W
Broil - 4400 W
Install_DOP36P86DLS_DG68-01106E-00_EN+MES+CFR.indb 10 2020-07-01 오후 3:44:03

English 11
Gas range components
With grate
37
3/8
" (94.9 cm) Min.
38
5/8
" (98.1 cm) Max.
Without grate
36" (91.4 cm) Min.
37 ¼ " (94.6 cm) Max.
35 ⅞ "
(91.1 cm)
27
⅝
"
(70.0 cm)
49"
(124.7 cm)
28
¾
"
(73.0 cm)
29
½
" (75.0 cm)
With handle
29
7
/
8
’’ (75.8 cm)
With knobs
Install_DOP36P86DLS_DG68-01106E-00_EN+MES+CFR.indb 11 2020-07-01 오후 3:44:03

12 English
Installation requirements
Installation requirements
13 in (33 cm)
Overhead
Cabinet Depth
0 in (0 cm)
22.6 in
(573.5 mm)
24 in
(61 cm) Lower
Cabinet Depth
6 in*
(15.2 cm)
6 in*
(15.2 cm)
37 ⁄ in
(953 mm)
36 in
(914 mm)
18 in
(45.7 cm)
30 in (76.2 cm)
30 in (76.2 cm)
0 in (0 cm)
Clearance Below
Cooking Top
and at Rear and
Sides of Range
48 in
(121.9 cm)
Minimum to
combustibles
(Installation
without a
hood)
* Side clearance above cooking surface to any objects, i.e., wall.
Installation requirements
Location requirements
Clearances and dimensions
NOTE
• For OTR over Gas Stove, please follow local GAS CODE.
• BEFORE YOU BEGIN to install this appliance, refer to the following information,
dimensions, and clearances. Do not locate the range where it may be subject
to strong drafts. Provide adequate clearances between the range and adjacent
combustible surfaces. These dimensions must be met for safe use of the range.
The location of the electrical outlet and gas piping may be adjusted to meet
the following dimensions and clearances.
• For installation in Canada, a free-standing range is not to be installed closer
than 4.7 in (12 cm) from any adjacent surface.
• Installations without a hood require 48" minimum to combustibles. A custom
hood installation with exposed horizontal combustible surfaces must have
an Auto-On feature. Refer to hood installation instructions for specic hood
clearances.
CAUTION
This range has been designed to comply with the maximum allowable wood
cabinet temperature of 194 °F (90 °C). Make sure the wall covering, countertops,
and cabinets around the range can withstand the heat (up to 194 °F [90 °C])
generated by the range. If not, discoloration, delamination, or melting may occur.
Install_DOP36P86DLS_DG68-01106E-00_EN+MES+CFR.indb 12 2020-07-01 오후 3:44:03

English 13
Installation requirements
Minimum dimensions
CAUTION
• If overhead cabinets are installed, a range hood should also be installed
and project horizontally a minimum of 5" (12.7 cm) beyond the front of the
cabinets. Hood is necessary to dissipate any heat buildup in the overhead
cabinets to prevent possibility of re, personal injury and/or death. The
ventilating hood must be constructed of sheet metal not less than 0.0122"
thick and installed above the cooktop with a clearance of not less than ¼"
between the hood and the underside of the combustible material or metal
cabinet. The hood must be at least as wide as the appliance and centered over
the appliance. Clearance between the cooking surface and the ventilation hood
surface must never be less than 24".
• Exception 1 : Installation of a listed microwave oven or cooking appliance
over the cooktop shall conform to the installation manual provided with the
appliance.
-30" (76.2 cm) minimum clearance between the top of the cooking
surface and the bottom of an unprotected wood or metal cabinet; or If
30" (76.2 cm) clearance is not possible, minimum of 24" (61 cm) can be
used when the bottom of the wood or metal cabinet is protected by not
less than ¼" (0.64 cm) ame-retardant millboard covered with not less
than no. 28 MSG sheet steel, 0.015" (0.038 cm) stainless steel, 0.024"
(0.061 cm) aluminum, or 0.020" (0.051 cm) copper.
-18" (45.7 cm) of minimum clearance between the countertop and the
adjacent cabinet bottom.
• Exception 2 : For island installation, maintain 2½" minimum from cutout
to back edge of countertop and 4" minimum from cutout to side edges of
countertop.
Installation guide
Recommended locations for gas piping and electrical outlets
A
B
Recommended
position for Gas stub
Recommended
position for
Electrical outlet
Model DOP36P86DLS
AElectrical outlet
9 ⅞”(W) X 6 ⅞”(H) (25.1 cm x 17.5 cm)
BGas piping
17 15/16" (W) X 5 3/8''(H) (45.5 cm x 13.8 cm)
Install_DOP36P86DLS_DG68-01106E-00_EN+MES+CFR.indb 13 2020-07-01 오후 3:44:03

14 English
Installation requirements
Installation requirements
To remove safely from the pallet
1. Remove the screws from the bottom
bracket on either side of the unit.
2. Press the bracket on either side to pull
out.
3. Have two persons hold both bottom
sides of the unit and lift up to remove
from the pallet. Use caution not to hold
the door handle.
To avoid breakage
CAUTION
• Please DO NOT push the unit strongly
when you install. These actions can
cause the damage to the unit.
• Hold the upper left/right area of the
door (not the door handle) with both
hands and push the unit in. Do not grab
the door handle.
Install_DOP36P86DLS_DG68-01106E-00_EN+MES+CFR.indb 14 2020-07-01 오후 3:44:04

English 15
Installation requirements
Fig. 1
C1
C2
C3 C4
1. The counter top around the cut-out
should be at and leveled (see hatched
area on Fig. 1).
2. Before installing the unit, measure the
heights of the two cabinet sides (C1–
C4), front and back (See Fig. 1) from the
oor to the top of the counter.
3. Level the range using the four leveling
legs so that the height from the oor
to the top of the cooktop frame is level
with a countertop.
4. Slide the unit into the cabinet (DO NOT
PUSH THE UNIT HARD). Make sure the
center of the unit aligns with the center
of the cabinet cut-out.
Gas requirements
Provide adequate gas supply
This range is designed to operate at a pressure of 5 in (13 cm) of water column on
natural gas or 10 in (25 cm) of water column on LP gas (propane or butane).
Make sure you are supplying your range with the type of gas for which it is
designed.
Do not attempt to convert the appliance from the gas specied in this manual to a
different gas without consulting the gas supplier.
This range is convertible for use on natural or propane gas. If you decide to use
this range on LP gas, conversion must be made by a qualied LP installer before
attempting to operate the range.
For proper operation, the pressure of natural gas supplied to the regulator must be
between 6 in and 13 in (13 cm and 33 cm) of water column.
For LP gas, the pressure supplied must be between 11 in and 13 in (25 cm and
33 cm) of water column.
When checking for proper operation of the regulator, the inlet pressure must be at
least 1 in (2.5 cm) greater than the operating (manifold) pressure as given.
The pressure regulator located at the inlet of the range manifold must remain in
the supply line regardless of whether natural or LP gas is being used.
A exible-metal appliance connector used to connect the range to the gas supply
line should have an I.D. of 0.5 in (1.3 cm) and be 5 ft (152 cm) in length for ease of
installation. In Canada, exible connectors must be single-wall metal connectors no
longer than 6 ft (183 cm) in length.
Do not kink or damage the exible metal tubing when moving the range.
Install_DOP36P86DLS_DG68-01106E-00_EN+MES+CFR.indb 15 2020-07-01 오후 3:44:04

16 English
Installation requirements
Installation requirements
Special gas requirements (gas models sold in Massachusetts)
COMMONWEALTH OF MASSACHUSETTS REQUIREMENTS:
WARNING
• Gas leaks may occur in your system, creating a dangerous situation.
-Gas leaks may not be detected by smell alone.
-Gas suppliers recommend you purchase and install a UL-approved
gas detector. Gas detector should be installed in accordance with the
manufacturers instructions.
• Range must be installed by a qualied plumber or gas tter by the State of
Massachusetts.
• A T-handle manual gas valve MUST be installed in the gas supply line to your
range.
• If a exible gas connector is used to install your range, multiple exible gas
lines must not be connected in series.
Electrical requirements
WARNING
To reduce the risk of re, electric shock, or personal injury:
All ranges
• Do not use an extension cord or adapter plug with this range.
• This range must be properly grounded.
• Check with a qualied electrician if you are in doubt as to whether your range
is properly grounded.
• Do not modify the plug provided with your range—if it doesn’t t the outlet,
have a proper outlet installed by a qualied electrician.
• All wiring and grounding must be done in accordance with local codes or, in
the absence of local codes, with the National Electrical Code, ANSI/NFPA No.
70 – Latest Revision (for the U.S.) or the Canadian Electrical Code CSA C22.1 –
Latest Revisions and local codes and ordinances.
• Wiring diagram is located on the back of the range. (Inside of the cover back
wire)
• This range is equipped with an electronic ignition system that will not operate
if plugged into an outlet that is not properly polarized.
Dual fuel models
• Canada models are equipped with a power cord with an equipment-grounding
conductor and a grounding plug.
(The power cord is not provided in US model.)
• A 240-Volt, 60-Hz, AC, approved electrical service with 40-amp circuit breaker
or time-delay fuse is required for all U.S. and Canadian models.
• Check for ¾-in (1.9-cm) UL-listed strain relief where the power cord comes out
of the range cabinet.
• Do not reuse a power supply cord from an old range or other appliance.
• The power cord electric supply wiring must be retained at the range cabinet
with a suitable UL-listed strain relief.
• A time-delay fuse or circuit breaker is also recommended.
Install_DOP36P86DLS_DG68-01106E-00_EN+MES+CFR.indb 16 2020-07-01 오후 3:44:04

English 17
Installation requirements
Usage situations where appliance power cord will be disconnected frequently
Do not use an adapter plug in these situations because disconnecting of the power
cord places under strain on the adapter and leads to eventual failure of the adapter
ground terminal. 240 V plug have 3 or 4 prongs and are not supplied with a unit.
Additional installation requirements for mobile homes
The installation of appliances designed for mobile home installation must conform
with the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part
3280 (formerly the Federal Standard for Mobile Home Construction and Safety,
Title 24, HUD, Part 280) or, when such standard is not applicable, the Standard
for Manufactured Home Installations, latest edition (Manufactured Home Sites,
Communities and Set-Ups), ANSI A225.1, latest edition, or with local codes. In
Canada, mobile home installation must be in accordance with the current CAN/CSA
Z240/MH Mobile Home Installation Code.
Power cord location
The power cord for this appliance is located
on the back of the range, near the bottom
left corner.
Grounding
• All ranges must be grounded for personal safety.
• All gas models have a power cord with an equipment-grounding conductor
and a grounding plug.
• The plug must be rmly plugged into a 3-prong or 4-prong outlet that is
properly installed and grounded in accordance with all local codes and
ordinances. In the event of a malfunction or breakdown, grounding will
decrease the risk of electrical shock by providing a path for the electric
current.
• Do not use a damaged power plug or loose wall outlet.
• Do not use an extension cord or adapter with this appliance.
• Do not, under any circumstances, cut, modify, remove, or otherwise defeat the
grounding if quipped. If the plug and the outlet do not match or you have any
doubt, have a qualied electrician install the proper outlet.
The customer should have the wall receptacle and circuit checked by a
qualied electrician to make sure the receptacle is properly grounded.
Ground Fault Circuit Interrupters(GFCIs) are not required or recommended for
range receptacles.
• NEVER connect ground wire to plastic plumbing lines, gas lines, or water
pipes.
CAUTION
Failure to follow these instructions can result in death, re, or electrical shock.
Install_DOP36P86DLS_DG68-01106E-00_EN+MES+CFR.indb 17 2020-07-01 오후 3:44:04

18 English
Tools and materials
Tools and materials
NOTE
• Make sure you have received all of the supplied parts shown above.
• If your range was damaged during shipping or you do not have all of the
supplied parts, contact your local retailer.
Parts needed
4-wire cord or
3-wire cord
Gas line
shut-off valve
Flexible metal
appliance connector
½" (ID) x 5 ft
Flare union adapter
¾" or ½" (NPT) x ½" (ID)
Flare union adapter
½" (NPT) x ½" (ID)
135-degree elbow
(optional)
Lag bolt or ½" (OD)
sleeve anchor
Tools needed
Flat-blade
screwdriver
Phillips
screwdriver
Open-end or
adjustable wrench Pipe wrench (2)
Pencil and ruler Level Pipe joint compound Nut driver
Utility knife Soapy water solution
Tools and materials
What’s in the box
Parts supplied
Surface burner grates (3) Burner heads (6) and Burner caps(6)
Flat rack (1) Anti-tip bracket kit
Wok ring (1) Gliding rack (2)
Temp. Probe (1) Front leg covers (2)
Brass burner caps (6) Convection lter (2)
Install_DOP36P86DLS_DG68-01106E-00_EN+MES+CFR.indb 18 2020-07-01 오후 3:44:07

English 19
Installation instructions
Installation instructions
Installing your Dual fuel Range
NOTE
• IMPORTANT: Please read the following instructions, as well as the Important
Safety Instructions section at the front of this manual, completely and
carefully BEFORE installing and/or operating the gas range. Improper
installation, adjustment, service, or maintenance can cause personal injury or
property damage.
• To order parts or accessories, contact
your local retailer or refer to the last
page.
• To ensure proper installation, we
strongly recommend that you hire a
professional installer.
Step 1. Unpack the range
Remove all packaging materials. Failure to remove packaging materials could
result in damage to the appliance.
Inventory all loose parts against the 'Parts supplied' overview on page 18.
Check for shipping damage and/or missing parts. Any damage and/or missing
parts should be reported to your local retailer.
Step 2. Meeting electrical connection requirements
CAUTION
For personal safety, do not use an extension cord with this appliance. Remove
house fuse or open circuit breaker before beginning installation.
This appliance must be supplied with the proper voltage and frequency, and
connected to an individual properly grounded branch circuit, protected by a circuit
breaker or fuse having amperage as specied on the rating plate. The rating plate
is located above the drawer on the oven frame.
We recommend you have the electrical wiring and hookup of your range
connected by a qualied electrician. After installation, have the electrician show
you where your main range disconnect is located.
Check with your local utilities for electrical codes which apply in your area. Failure
to wire your oven according to governing codes could result in a hazardous
condition.
If there are no local codes, your range must be wired and fused to meet the
requirements of the National Electrical Code, ANSI/NFPA No. 70–Latest Edition.
You can get a copy by writing:
National Fire Protection Association
Batterymarch Park
Quincy, MA 02269
Effective January 1, 1996, the National Electrical Code requires that new
construction (not existing) utilize a 4-conductor connection to an electric range.
When installing an electric range in new construction, follow Steps 2 and 3 for
4-wire connection.
You must use a 3-wire or 4-wire, single-phase A.C. 208Y/120 Volt or 240/120 Volt,
60 hertz electrical system.
If the electrical service provided does not meet the above specications, have a
licensed electrician install an approved outlet.
Use only a 3-conductor or a 4-conductor UL-listed range cord. These cords may be
provided with ring terminals on wire and a strain relief device.
A range cord rated at 40 amps with 125/250 minimum volt range is required.
Install_DOP36P86DLS_DG68-01106E-00_EN+MES+CFR.indb 19 2020-07-01 오후 3:44:08

20 English
Installation instructions
Installation instructions
Specied power-supply-cord kit rating
Range rating, watts Specied rating
of power-supply-
cord kit, amperes
Diameter (inches) of range
connection opening
120/240
volts 3-wire
120/208
volts 3-wire Power cord Conduit
8750 - 16500 7801 - 12500 40 or 50 A 1⅜" 1⅛"
Step 4. Installing the power cord
For power cord installations, hook the strain relief over the power cord hole (1⅜")
located below the rear of the drawer body. Insert the power cord through the
strain relief and tighten the device.
• You must install the power cord with a strain relief.
• Attach the strain relief to the 1⅜" opening in conduit connection plate.
A 50 amp range cord is not recommended but if used, it should be marked for
use with nominal 1⅜" diameter connection openings. Care should be taken to
center the cable and strain relief within the knockout hole to keep the edge from
damaging the cable.
Because range terminals are not accessible after range is in position, exible
service conduit or cord must be used.
NOTE
If conduit is being used, go to Step 5 on pages 22–23.
ALL NEW BRANCH-CIRCUIT CONSTRUCTIONS, MOBILE HOMES,
RECREATIONAL VEHICLES AND INSTALLATIONS WHERE LOCAL
CODES DO NOT ALLOW GROUNDING THROUGH NEUTRAL, REQUIRE A
4-CONDUCTOR UL-LISTED RANGE CORD.
Step 3. Accessing the power cord connection
Remove the rear access cover and loosen the screw with a screwdriver. The
terminal block will then be accessible.
Terminal block
Access cover
Install_DOP36P86DLS_DG68-01106E-00_EN+MES+CFR.indb 20 2020-07-01 오후 3:44:08
