daewon DIB-N800 Series User manual

User’s Manual
DIB-N800 Series
DIB-N810 / DIB-N830 / DIB-N850
DIB-N810R / DIB-N830R / DIB-N850R
This manual contains the warranty card.
Please read this manual carefully before use.
c
o

Please save this manual and place in easily accessible location.
Do not attempt to service this appliance yourself.
Doing so will void warranty.
Table of Contents
Safety Information - Warning
Before Installation
General operation
Maintenance
4
14
19
28
6
15
24
30
8
17
31
32
33
10
18
34
Safety Information - Caution
Product Installation
Expert Mode
Error code
Product Features
Remote Installation
Specications
Product parts
Trial Operation
Comparison Chart
Dimensions
Warranty
General Information
Installation
Operation
Technical Information
01
02
03
04
02 03

Safety Features Safety Information
Risk of electric shock, fire, personal injury, property damage or products damage when
violating the instructions.
Risk of electric shock, re, personal injury, property damage or products damage when
violating the instructions.
04 05
Warning
Do not stand on the top of or place any heavy objects onto the seat cover.
Do not open/close the lid/seat with excessive force.
Do not lean against the lid when opening with excessive force.
Do not press the buttons using excessive force.
Do not use thinner, benzene, acidic chemicals, chloride, or hydrochloric acid detergent on or
near the product, This may result in corrosion to the metal parts or discoloration, breakage or
scratches to the bidet body.
Do not use any aerosol(spray) products near by. This may result in discoloration of the
bidet body.
Do not pull out the bidet hose using excessive force.
Be cautious of the low-temperature burn.
For children and seniors who may have diculties with adjusting temperatures or those
with sensitive skin or impaired heat sensitivity, set the temperature of the wash spray and
seat to “low” or “o” to prevent burning.
If the unit will not be used for a long period of time, unplug the power cord, and close the
main water supply valve.
Do not use the unit if it is not working properly.
Make sure the unit is installed(mounted) on the installation bracket thoroughly.
After the installation, make sure to check all water supply connections for leaks. Rubber
washers should be in place for the water connection hoses and T-valve
Do not store or place the unit upside down.
Children should be supervised to ensure that they do not play with the unit.
Caution
Do not disassemble, modify or repair the product yourself.
Do not plug or touch the power plug with wet hands.
Do not pour excessive water onto the products or power plug.
Do not use the damaged power plug, cord and outlet.
This products should be used with a grounded outlet.
Insert the power plug correctly in proper voltage outlet.
Do not place cigarettes or ammables near the product. Do not litter into the product.
Do not use industrial water, or gray water for the supply
Do not plug in until the unit is completely installed
The unit should be serviced by an authorized or qualied technician if it has a damaged
power cord.
Make sure that drying opening area is not blocked.
Unplug rst before cleaning the unit.
Do not use the product in locations exposed to excessive moisture.
Do not use the product if it has fallen into water. Unplug the unit immediately and call the
service center.
This unit is not intended for use by persons (including children and seniors) with reduced
physical, sensory, or mental capabilities, or lack of experience and knowledge.

06 07
Safety Features Safety Information
Water lter
In the case of a use environment where tap water has rust, it may cause internal
contamination and leakage of the product. Be sure to use a genuine water lter.
Instant heating
Instant ceramic heating system provides an endless water washes. However, when
using in a very cold area with high water pressure, the hot water may not reach the
set temperature, and this is not a malfunction. If you lower the water pressure during
use, you can use warmer washes.
Warm air dryer
The dryer eect will be improved if moisture is lightly wiped out before the dry operation.
The temperature of hot air drying may vary depending on the surrounding temperature
even with the same setting.
Toilet bowl atness
This product is designed to be placed on the toilet well regardless of toilet atness, but
sometimes the rear of the seat may lift from the toilet if the surface of the toilet bowl is
seriously not at.
This may cause excessive strain on the toilet seat and bidet body, and may cause damage
such as external cracks. Please contact the dealer or manufacturer for additional supports.
TURBO
Remove the water in the rectum after using Turbo function, or you may feel bloated or
uncomfortable.
If you have hemorrhoids or anal disease, be sure to consult with your doctor before use.
Excessive use may worsen bowel function.
2X MODE
When using 2X mode, intake water temperature may aect the water spray temperature.
Be sure to consult your doctor before use if you have hemorrhoids or anal disease.
Excessive use is not recommended.
Cleaning the bidet body
Do not use thinner, benzene, acidic chemicals, chloride, or hydrochloric acid detergent on or
near the product, This may result in corrosion to the metal parts or discoloration, breakage
or scratches to the bidet body.
Do not use any aerosol(spray) products nearby. And do not sit on the seat after applying
excessive body lotion. This may result in discoloration of the bidet body.
Water supply hose and power cord
Be careful not to drop any chemical detergents of the toilet cleaner on the water supply
hose or power cord.
If exposed to the chemical detergent, remove it immediately.
The new water hose with the appliance should be used and the old hose is not
recommended to be reused.
Risk of electric shock, fire, personal injury, property damage or products damage when
violating the instructions.
Risk of electric shock, re, personal injury, property damage or products damage when
violating the instructions.
Warning Caution

Product Features
08 09
Ceramic water heating technology
Products Features
Instant ceramic heating system provides an endless water washes.
2 Nozzle Cleansing modes
Oers 2 dierent nozzle cleansing modes to enhance the hygiene.
2 Energy Saving modes
Oers 2 dierent energy-saving modes to maximize the electricity saving.
Nozzle/Dry Protection Cover
Prevents a nozzle and dry outlet from any contaminations with a protection cover for
easy cleaning and maintenance.
Intensive Nozzle Care
Provides a more hygienic environment for use by intensively cleaning only the
contaminated nozzle tip.
Quiet Pump
Available powerful water ow with low noise pumping operation sound by applying the
new wave control technology.
Enhanced Dry Airow
Enhanced dry fan motor and specially designed outlet structure oer quick drying.
Automatic Leveling Seat
Minimizes seat damage due to the uneven surface of the toilet bowl by an applying
automatically adjustable leveling seat system.
Radio Frequency Remote
Perfect remote control without interference in bathroom structure and other lights by
applying radio frequency remote.
Aerated wash
A specially designed nozzle tip structure generates an air bubble wash spray for better
cleansing performance.
Stainless steel nozzle
A fully stainless steel nozzle resists rusting and contamination for better hygiene.
Multicolored, illuminating nightlight
Choose a preferred nightlight to provide enough brightness to nd a toilet without turning on
the light at night.
Rear/Front wash
Adjustable temperature, position, pressure, pulsation and oscillation settings.
Enema(Turbo)
Specialized water spray in Turbo(enema) helps relieve constipation and fecal stasis.
2X mode
For users who prefer the stronger water pressure, 2X mode oers double-power water
spray.
c
o
IPX5 Waterproof
Bidet main unit is designed with IPX5 waterproofness level for safety.
Touch control panel
By applying the touch control panel with perfect waterproofness equivalent to IPX8, this
can be used conveniently without worrying about malfunction even in high temperature
and high humidity environments. (limited to side arm models)
User Preset
Set water temperature, seat temperature, water pressure, nozzle position, dry
temperature, oscillation, and pulsation for two users.

10 11
5
1
24
3
9
10
8
7
6
11
Lid
Release lever Deodorizing cover and air outlet
Control panel Nozzle
Seat
Intake deodorizing hole
Night light Power cord
Catch plate Water inlet
1
4
7
10 11
2
5
8
3
6
9
Turbo (enema)
Child wash
Stop
Engergy saving
Water temperature control
Nozzle cleansing
User presets
Seat temperature control
Dry
Pulsation
Rear wash
Rear wash oscillation
2X rear wash mode
Front wash
Front wash oscillation
2X front wash mode
Product parts Control panel
Select once Select once again Select and hold for 3 seconds
Installation parts
T-valveMetal
bolts
Rubber
anchor
bolts
Bidet hose
Deodorizing lterDeodorizing cover
Brackets Mounting bracket Water lter
(Optional)
Nozzle position control
Water pressure/
Dry temperature control

12
Product parts
1
4
2
3
68
9
10
7
11
5
8
13
CR2032 CR2032
Remote control Remote control bracket CR2032 battery X 2
Parts for remote control
Control panel
Turbo (enema) Child wash
Stop
Engergy saving
Water temperature control
Nozzle cleansing
User presets
Seat temperature control
Dry
Pulsation
Rear wash
Rear wash oscillation
2X rear wash mode
Front wash
Front wash oscillation
2X front wash mode
Nozzle position control Water pressure/
Dry temperature control
Lid
Release lever Deodorizing cover and air outlet
Auxiliary panel Nozzle
Seat
Intake deodorizing hole
Night light Power cord
Catch plate Water inlet
1
4
7
10 11
2
5
8
3
6
9
Installation parts
T-valveMetal
bolts
Rubber
anchor
bolts
Bidet hose
Deodorizing lterDeodorizing cover
Brackets Mounting bracket Water lter
(Optional)
Select once Select once again Select and hold for 3 seconds

1. Remove the seat from the existing toilet
Release the nuts and then remove the seat and cover.
Keep the removed seat, cover and nuts in a a proper
place in case of using them again.
2. Shut the supply o, and empty the tank completely
Connect with the cold water supply only.
Failure to do may result in ooding, leaking or damage
to the product when the hose is disconnected.
3. Disconnect the toilet hose and install the T-valve
You may use the bucket to catch the residual water
from the hose.
Check and ensure the rubber washer sits at inside of
the T-valve.
4. Install the catch plate
Wet the rubber anchor bolts with water and firmly
insert them all the way down into the mounting holes
on the top of the toilet.
Place the mounting plate over the rubber anchor bolts
on the toilet.
Place the brackets flat side down on the mounting
plate over the rubber anchor bolts. Insert metal
mounting bolts through the holders and rubber anchor
bolts; use a screwdriver to screw in the mounting bolts
and tighten.
If the toilet bowl is not suitable to use mounting
anchor bolts, contact the local dealer where you
bought your product for more assistance.
Before installation Product Installation
Do not plug the product in until the unit is completely installed.
Caution
Read the manual rst before installation.
Check whether the toilet to be installed is suitable for the installation
Toilet size, mounting hole spread, shuto valve installed, Space for T-valve, exible hose
installed, etc. For this, contact the local dealer where you purchase your bidet seat for
special assistance.
Prepare the standard screwdriver and wrench in advance.
Teon tape may be needed between plumbing connections
Every product is tested with pure water during production to ensure the highest quality
and performance. It is normal to nd a small amount of residual water drops or moisture
on the product.
14 15
Insert the deodorizer lter into the cartridge hole.
5. Insert the deodorizer lter
※ Applicable models only

16
Product Installation
6. Attach the bidet seat to the catch plate
7. Connect the bidet hose to the bidet seat
Adjust the seat and front part of the toilet back and
forth so that they can correspond before fastening
the bolts.
Set the bidet seat at on the toilet bowl and push it
in until it clicks into place and is secure. Failure to
do may cause the seat to come apart.
Rotate the water inlet backward and hand-tighten
to secure. Make sure the hose is not twisted,
excessively bend it, or strip the plastic threads when
screwing the hose onto the bidet seat.
After connection, rotate the inlet back to the normal
position.
Connect the other end of the hose to the T-valve.
Check and ensure the rubber washer is not twisted
when fastening.
※ Bidet Filter Installation
※ Caution for pairing
Customers with hard water, well water, and rust
water can extend the life of their bidet seat by
installing an inline water lter.
Install the lter between T-valve and bidet hose.
The bidet filter should be replaced every
4~6months.
Failure to replace the filter on time may result in
water contamination, supply congestion, or filter
breakage.
Be sure to proceed in the order of pairing method. If the order is reversed during
pairing, remove the remote control batteries and product power cord, wait tens of
seconds, and start again from the beginning.
To automatically pair the remote to the seat, install the batteries into the remote within
5 minutes of plugging the seat into the power outlet.
This product is an RF-type remote control with its own unique number assigned to each
product. There is little chance of confusion if two or more remote control bidet seats are
installed at the same place. In this case, contact the local dealer where you purchase
your seat for more assistance.
17
CR2032 CR2032
비데 설치방법
1. Find a place visible and reachable from the
toilet and clean the space thoroughly before
attaching the bracket.
2. Peel the adhesive protection lm and attach
the bracket on the wall.
3. Insert the batteries deeply inside first and
press the outside all the way down to
complete the insertion. Be sure to fasten the
bolt for children’s safety.
4. Gently insert the remote control into the
bracket.
5. If the automatic pairing is failed, follow the
below instructions.
Plug in the bidet seat.
The nozzle comes forward and goes backward, then
melody plays.
Insert the batteries.
Press any buttons to complete the pairing. Melody is
played to identify pairing completion.
6. Replace all batteries at the same time. Do not
mix old and new batteries.
Keep the battery out of reach of infants and toddlers
and watch out them not to swallow it. If a battery is
swallowed, immediately consult a doctor.
Remote Installation

Occupied seat sensor (getting started)
Rear wash / Front wash / Turbo wash / Oscillation
Operations
Sit on the seat to ensure skin contact on the seat
sensor.
Clothes or other materials except for skin contact on
the sensor may interrupt the bidet seat operation.
Once the contact is made the water pressure
indicator lights will turn on.
Leaving the seat during use will stop the operation.
Select once to initiate a rear/front/turbo wash.
The nozzle will be self-cleaned before/after wash
operation. (Turbo wash is not available with the
auxiliary panel.)
Select once again to initiate nozzle oscillation. To
stop the oscillation, choose again.
The oscillation at Turbo wash is not available for
safety.
Do not use a Turbo wash excessively and consult
with a doctor first if you have any anal disease or
you are sensitive.
For water temperature when using in a cold
environment, refer to the cautions in this manual.
Swipe nger toward the front to initiate a front wash.
Swipe finger toward the front again to initiate an
oscillation. (Auxiliary panel only)
Swipe nger toward the rear to initiate a rear wash.
Swipe finger toward the rear again to initiate an
oscillation. To cancel the oscillation, swipe the same
direction again. (Auxiliary panel only)
18
Trial Operation
1. Turn on the water supply
2. Check all connections for leaks, including T-valve and hose connections
3. Plug in
4. Check the initial operation
Make sure the ush tank is lled up with water.
In case of leakage, check the tightening of the nut and whether the rubber washer
is missing or twisted, and Teon tape may be required depending on the installation
environment.
Do not touch the plug with wet hands.
The night light blinks while the nozzle extracts and retracts.
19
Stop
Stops all wash and dry functions currently operating
(Side arm/Remote control)
Gently touch for a second any parts of the dotted
area to stop the wash cycle. (Auxiliary panel)
Side arm/Remote control
Side arm/Remote control
Auxiliary panel
Auxiliary panel
Oscillation

20 21
Operations
Nozzle position
Select ◀/▶during a wash cycle to adjust the nozzle
position forward and backward.
The 5 LED indicator lights will indicate dierent positions
selected.
Settings will be saved for the next use.
Child wash (automatic wash)
Select a Child wash button to initiate an child wash that
oers from the wash until the drying function for children
and seniors.
Rear wash 20 seconds → Rear wash oscillation 20
seconds → Rear wash oscillation with pulsation for 20
seconds → Dry for 2 minutes will consecutively work.
Seat temperature
Water temperature
Deodorizer
Select a water temperature button to adjust the seat
temperature to 1 of 4 settings.
Room temperature/off → low/green(34°C/93.2°F) →
medium/yellow(37°C/98.6°F) → high/red(40°C/104°F)
Settings will be saved for the next use.
This bidet seat is an instant heating system with the
latest technology applied, and it does not consume any
electricity for the water heating in standby mode, saving
electricity.
If the bidet seat is used in a very cold area with high
water pressure, the warm water may not reach the set
temperature. Refer to the precaution in this manual.
The deodorizer starts automatically when a user sits on
the seat. It continues to run for one minute after the
seat has been vacated.
The deodorizing cartridge is semi-permanent but needs
to be cleaned regularly with a brush.
Water pressure
Select a rear/front/turbo wash button to adjust water
pressure by +/- button. (5 levels)
If you feel that the water pressure is weaker than
usual, there may be small debris stuck in the water
supply screen lter or inline lter. Refer to maintenance
instructions in this manual.
Pulsation
Select a pulsation button to initiate pulsation while
rear/front/turbo is running that enables the water
to repeatedly increase and decrease in pressure in a
pulsating pattern.
To cancel pulsation, select the pulsation button again.
Operations
Select a seat temperature button to adjust the seat
temperature to 1 of 4 settings.
Room temperature/off → low/green(34°C/93.2°F) →
medium/yellow(37°C/98.6°F) → high/red(40°C/104°F)
Settings will be saved for the next use.
If the seat is used 15 minutes consecutively when the
seat temperature is set at medium and high, the seat
temperature will be lowered automatically down to
35°C/95°F by 1°C/1.8°F every 5 minutes.
For safety, this bidet seat uses a low voltage for a heated
seat. It may take a little while to be heated at the
beginning.
※ Applicable models only
Dry
Select a dry button to initiate a 3 minutes air dryer cycle.
Dryer air temperature can be adjusted by +/- button. (5
levels)
For dryer air temperature when using in a cold
environment, refer to the cautions in this manual.
※ Applicable models only
If the stronger water pressure is preferred while a rear/
front wash, select and hold a button for 3 seconds
to change to 2X mode. 2X mode starts from Level 3
regardless previous setting.
Select and hold a rear/front wash button for 3 seconds
to initiate 2X mode rear/front wash.
Select once again to initiate nozzle oscillation. To cancel
the oscillation, select again.
To cancel 2X mode, select and hold a rear/front wash
button for 3 seconds.
Do not use 2X mode wash excessively and consult with a
doctor rst if you have any anal disease or are sensitive.
For warm water temperature when using in a cold
environment, refer to the cautions in this manual.
2X mode
3 seconds
low medium high
low medium high

22 23
Operations
Energy saving
Select the Energy saving button once to initiate the Energy
saving mode 1. Select it again to initiate the Energy saving
mode 2. To cancel the Energy saving mode, select it once
again after the Energy saving mode 2.
No energy saving (o) → Energy saving mode 1 (green)
→ Energy saving mode 2 (red)
Energy saving mode 1 (regular saving)
Seat temperature is lowered as below and goes back to
the previous set temperature automatically as soon as the
seat is occupied.
- Low temperature (34°C/93°F) → (28°C/82°F)
- Medium temperature (37°C/99°F) → (30°C/86°F)
- High temperature (40°C/104°F) → (32°C/90°F)
Energy saving mode 2 (powerful saving)
Seat heating is turned o regardless of the current temperature setting and goes back
to the previous set temperature automatically as soon as the seat is occupied. After a
seat is unoccupied, it returns to Energy-saving mode.
The night light dims during the Energy saving mode 2 and when a user sits on the
seat, it becomes bright and dims back after leaving the seat.
Operations
There are two ways to initiate nozzle cleaning.
Nozzle cleaning
Nozzle cleaning 1 (nozzle body care)
Select Nozzle cleaning for a second while not seated.
Nozzle extends toward and self-clean 3 times with cold
water. It retracts when nished. Pressing Stop at any time
to cancel the nozzle cleaning process.
Nozzle cleaning 2 (Nozzle tip intensive care)
Select and hold the Nozzle cleaning button for 3 seconds
while not seated. Nozzle extends toward and nozzle tip will
be self-cleaned for 40 seconds with hot water.
It stays extracted for user’s manual cleaning for 5 minutes
and retracts automatically.
Select the Nozzle cleaning button again to retract the
nozzle if the cleaning process is nished earlier.
Select the Nozzle cleaning button while the nozzle tip
is being self-cleaned, and self cleaning is canceled and
extracts promptly for user’s manual cleaning.
You can program your preferred settings for two users.
Follow the steps below to program and use the memory
function.
Water temperature, seat temperature, water pressure,
nozzle position, and dry temperature can be stored.
Use the bidet seat with your preferred settings first and
select and hold one of the user preset buttons for 3 seconds.
Settings will be saved with 1 beep.
Settings can be overwritten on the current presets. In this
case, old settings are deleted and new settings are saved.
Select the user preset 1. 2 LEDs(green/red) of Energy saving
light on and only green LED blinks once altering you that
user memory 1 is activated.
Select the user preset 2. 2 LEDs(green/red) of Energy saving
light on and only green LED blinks twice altering you that
user memory 2 is activated.
User preset
To reset the bidet seat back to its factory default
settings, select the stop button 4 times within 2 seconds
to clear all current settings.
A factory reset can only be performed when the seat is
not occupied.
A tone will be heard to conrm that the bidet seat has
been initialized.
Factory default reset
Multicolored night light
Select a nozzle cleaning button repeatedly to change
the color of the night light 1 of 7 colors while the seat is
occupied.
The default color is white and can be changed in the
following order.
Pure white → Sky blue → Pretty yellow → Princess pink
→ Hot red → Sea blue → Forest green → O
The night light dims during the Energy saving mode 2
and when a user sits on the seat, it becomes bright and
dims back after leaving the seat.
Sleep mode
Select and hold Energy-saving for 3 seconds to enter Sleep
mode regardless of the seat sensor occupation. Select
Energy-saving again for a second to cancel the sleep
mode.
4 times!
3 seconds
3 seconds
3 seconds

기본기능
Expert mode
24 25
Expert mode
Expert mode allows the user to program the operations. It may be complicated for regular
users.
Select and hold Nozzle Cleaning for 2 seconds while
Stop is selected and held to enter/cancel the expert
mode.
Nozzle Cleaning LED blinks to indicate Expert mode
has been entered.
The seat sensor is automatically overridden and, if the
overriding is not canceled forcibly, it is canceled after
20 minutes automatically.
Entering & canceling Expert mode
Dry cycle change
Deactivate the seat sensor override.
Select Seat temperature while Child wash is selected
and held.
Color of Seat temperature LED is changed
sequentially.30sec (off) → 1min (low/Green blinks)
→ 2min (medium/yellow blinks) → 3min (high/red
blinks).
Default cycle is 2 minutes.
Dry cycle change at Child wash
Deactivate the seat sensor override.
Select Water temperature while Rear wash is selected
and held.
Color of Water temperature LED is changed
sequentially.1min (off) → 2min (low/Green blinks) →
3min (medium/yellow blinks) → 5min (high/red blinks).
Cycle of front wash and Turbo wash can be changed in
the same way.
Default cycle is 2 minutes.
Wash cycle change
After entering Expert mode, touch a seat sensor area
to deactivate the seat sensor override. 5 LEDs of water
pressure/nozzle position are turned o to indicate that
the seat sensor override is deactivated.
Touch the seat sensor again to activate the seat sensor
override. 5 LEDs of water pressure/nozzle position turn
on to indicate that the seat sensor override is activated.
Seat occupy sensor overriding and canceling
Child wash cycle change
Deactivate the seat sensor override.
Select Water temperature while Child wash is selected
and held.
Color of Water temperature LED is changed
sequentially.30sec (o) → 60sec (low/Green blinks) →
120sec (medium/yellow blinks) → 180sec (high/red
blinks)
30sec (o) : 10sec front wash → 10sec front oscillating
wash → 10sec front oscillating/pulsating wash
60sec (o) : 20sec front wash → 20sec front oscillating
wash → 20sec front oscillating/pulsating wash
120sec (o) : 40sec front wash → 40sec front oscillating
wash → 40sec front oscillating/pulsating wash
180sec (o) : 60sec front wash → 60sec front oscillating
wash → 60sec front oscillating/pulsating wash
Default cycle is 60 seconds.
Activate the seat sensor override.
Select Water temperature while Dry is selected and
held.
Color of Water temperature LED is changed
sequentially.1min (off) → 2min (low/Green blinks)
→ 3min (medium/yellow blinks) → 5min (high/red
blinks).
Default cycle is 3 minutes.
2 seconds

26 27
기본기능
Expert modeExpert mode
simultaneously
simultaneously
Silence mode on/o
Select water pressure “-”while Stop is selected and
held to lower the volume of the beep sound.
The volume of the beep sound will be lowered after
getting out of Expert mode.
Deactivate the seat sensor override.
Select water pressure +/- simultaneously to enter
automatic pulsation wash setting mode.
Select and hold Rear wash for 3 seconds to initiate/
cancel automatic oscillation rear wash. 2 LEDs(green/
red) of the energy saving blink with 1 beep when it
is activated and only 1 LED (red) blinks with 2 beeps
when it is deactivated. Front wash, Turbo wash and
Child wash can be set in the same way.
In the case of Child wash, Child pulsation wash is
deactivated rst instead of being activated as it is set
basically.
20sec front wash → 20sec front oscillating wash →
20sec front oscillating/pulsating wash.
Automatic pulsation wash on/o
Select nozzle position ◀▶simultaneously to enter
automatic oscillation wash setting mode.
Select and hold Rear wash for 3 seconds to
initiate/cancel automatic oscillation rear wash. 2
LEDs(green/red) of the energy saving blink with 1
beep when it is activated and only 1 LED (green)
blinks with 2 beeps when it is deactivated. Front
wash and Child wash can be set in the same way.
In the case of Child wash, Child oscillation wash is
deactivated first instead of being activated as it is
set basically.
20sec front wash → 20sec front oscillating wash →
20sec front oscillating/pulsating wash
Automatic oscillation wash on/o
This feature can be set regardless seat sensor override.
Select Water temperature while Stop is selected and
held to initiate/cancel the automatic deodorize.
2 LEDs(green/red) of the energy saving blink with 1
beep when it is activated and only 1 LED (red) blinks
with 2 beeps when it is deactivated.
Automatic deodorize on/o Water pressure and nozzle position change
Activate the seat sensor override
Basically, the water pressure and nozzle position are
stored and are maintained from the previous user's
settings, but these can be ignored and automatically
be changed to the presets as soon as the seat is
unoccupied.
Adjust the nozzle position and water pressure and
select and held Rear wash for 3 seconds.
2 LEDs(green/red) of the energy saving blink with 1
beep when it is activated and only 1 LED (red) blinks
with 2 beeps when it is deactivated. Front wash, Turbo
wash and Child wash can be set in the same way.
Adjust the dryer temperature and select and held Dry
for 3 seconds.
2 LEDs(green/red) of the energy saving blink with 1
beep when it is activated and only 1 LED (red) blinks
with 2 beeps when it is deactivated.
3 seconds

기본기능
Maintenance
Cleaning the bottom and toilet bowl
Unplug and shut the water supply off, then flush
toilet and hold down dandle to completely empty
tank.
Disconnect water supply hose from the bidet seat.
You use a bucket to catch any dripping water from
the bidet and hose.
Press the bidet release lever and gently pull inward
to remove the bidet seat.
Use a soft, damp cloth and mild/neutral cleanser
(such as dish soap) to wipe down the bidet body and
remove the cleanser completely.
In case of cleaning the toilet, remove the catch plate
rst. Make sure there is no cleanser left on the toilet
after cleaning. Cleanser residue may damage the
bidet body.
Product storage
Keep the unit plugged in to prevent freezing if the
bidet seat is installed in a cold place.
When the bidet seat is not used for an extended
period of time, unplug. When it is reused after it is
stored in a cold place, keep the unit in a warm place
for a while before plugging in.
Maintenance
※ Dual protection (dryer inner cover and closed nozzle cover) protects the
bidet seat from contamination and water damage.
Turn off the water supply and hold the toilet flush
lever down to empty the tank completely.
Unplug the bidet seat, remove from the toilet and
disconnect the bidet hose. You may use the bucket
to catch any dripping water from the hose and bidet
seat.
Remove the screen lter from the water inlet with a
long-nosed pliers.
Clean the filter with a toothbrush and re-install it
correctly.
Reconnect the bidet hose and place the bidet seat
back, Plug the power cord back and turn the water
supply back on. Check for leaks.
Cleaning the screen lter
Do not use thinner, benzene, acidic chemicals,
chloride, or hydrochloric acid detergent.
Do not scrub or use harsh, abrasive products to
clean the seat.
Use a soft, damp cloth and mild cleanser and do not
spray water excessively onto the bidet seat.
If the contamination is serious, use the mild
detergent (such as dish soap) only and make sure
there is no residue after cleaning.
Do not use any aerosol(spray) products nearby. This
may result in discoloration of the bidet body.
Unplug first before cleansing, and be aware of not
wetting the power plug.
Be careful of not to drop any chemical detergents
of toilet cleanser on the water supply hose or power
plug.
Cleaning bidet seat body
28 29

※ In the event of an abnormality, please refer to the error code table below and inform
us at the time of receiving repair service, so that the action may be easier.
31
30
Error code Specication
Item
DIB-N810/DIB-N830/
DIB-N850
DIB-N810R/DIB-N830R/
DIB-N850R
Power voltage
Max power consumption
Power cord
Supply water connection
Supply water pressure
Volume
Pressure control
Temperature control
Max heater power
consumption
Max heater power
consumption
Safety devices
Temperature control
Temperature control
Heater capacity
Safety devices
Safety device
Incoming water temperature tolerance range
Usage room temperature tolerance range
Product
dimensions
Elongated
Round
Frequency band
Antenna type
Modulation type
Wireless type
Product weight
Rear wash
Front wash
Turbo(enema)
Wash
Heated seat
Dry
Deodorizer
AC 220V / 60Hz
1,430W
1.8M
650±50cc/min (850±50cc/min at 2X mode)
760±50cc/min
4 levels (O, low, middle, high)
Thermal sensor, Thermal fuse, Thermal switch
38W
5 levels
Thermal fuse
650±50cc/min (800±50cc/min at 2X mode)
Rear/Front wash (10 levels incl. 2X mode)
Turbo(enema) 5 levels
1,400W
4 levels (O, low, middle, high)
Thermal sensor, Thermal fuse
Catalyst Carbon deodorization lter (replaceable)
400W
3 ~ 35℃ (12 ~ 35℃ recommended)
3 ~ 40℃ (10 ~ 35℃ recommended)
3 ~ 40℃ (10 ~ 35℃ recommended)
3 ~ 40℃ (10 ~ 35℃ recommended)
449mm X 528mm X 112mm 380mm X 528mm X 112mm
449mm X 500mm X 112mm 380mm X 500mm X 112mm
2440 Mhz
Internal antenna
OQPSK
Zigbee
4~4.5kg(6.5~7kg)
Directly connects to the water pipe
0.068 ~ 0.735 MPa
Common display
Side arm model
No.
No.
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
13
14
14
Energy saving
“Green” and “Red”
LED sequentially
Blink, and
Night light “Red”
blinks
Energy saving
“Green” and “Red”
LED sequentially
Blink, and
Night light “Red”
blinks
Left Right
Left Right
Seat temperature “Green” LED blinks
Seat temperature “Green” LED blinks
Disconnected or not inserted seat temperature sensor
Disconnected or not inserted seat temperature sensor
Low voltage
Low voltage
Seat temperature “RED” LED blinks
Seat temperature “RED” LED blinks
Short or overheated seat temperature sensor
Short or overheated seat temperature sensor
Solenoid valve overcurrent
Solenoid valve overcurrent
Water temperature “Green” LED blinks
Water temperature “Green” LED blinks
Disconnected or not inserted intake water temperature sensor
Disconnected or not inserted intake water temperature sensor
Solenoid valve disconnection
Solenoid valve disconnection
Water temperature “Green” and Yellow” sequentially blink
Water temperature “Green” and Yellow” simultaneously blink
Short or overheated intake water temperature sensor
Short or overheated intake water temperature sensor
Drying fan motor disconnection or overcurrent
Drying fan motor disconnection or overcurrent
Water temperature “RED” blinks
Water temperature “RED” blinks
Disconnected or not inserted outlet water temperature sensor
Disconnected or not inserted outlet water temperature sensor
Deodorizing fan motor overcurrent
Deodorizing fan motor overcurrent
Flow meter disconnection or abnormality
Flow meter disconnection or abnormality
Water temperature “Yellow” and “Red” sequentially blink
Water temperature “Yellow” and “Red” simultaneously blink
Short or overheated outlet water temperature sensor
Short or overheated outlet water temperature sensor
Pump motor overcurrent
Pump motor overcurrent
Overvoltage
Overvoltage
○ ○ ○○
○ ○ ○
○ ○ ○○
○ ○ ○
○ ○ ○○
○ ○ ○
○ ○
○ ○ ○○
●
●
●
●
●
●
● ●
●
●
● ● ●
○ ○ ○○
○ ○ ○
○ ○ ○○
○ ○ ○
○ ○ ○○
○ ○ ○
○ ○
○ ○ ○○
●
●
●
●
●
●
● ●
●
●
● ● ●
Remote model
Side arm model
Error code display priority
Error code display is divided into two sections, 1 to 6 and 7 to 14. Error with a smaller number is displayed only.
For example, if No. 1, No. 6, No. 8, and No. 14 occur simultaneously, only No. 1 and No. 8 are displayed. If 1 is
solved, only 6 and 8 will be displayed, if 8 is solved, 6 and 14 will be displayed.

33
Remote control Specications
Frequency band
Antenna type
Modulation type
Power supply
Product size
Wireless type
Product weight
Product name
Model name
2440 Mhz
Internal antenna
OQPSK
DC 3V (CR2032 Battery 2EA)
66mm X 155mm X 10mm
Zigbee
105 g
RF remote control for an electronic bidet seat
DIB-LT1-RF
32
Comparison Chart
Rear wash
Front wash
Turbo (Enema)
Convenient
feature
Safety
feature
Child wash
Pulsation
Oscillation
Instant heating
Aerated wash
Built in pump
Drying
Deodorizing
Heated seat
User preset
Soft closing
Quick removal
Low burn protection
Night light
Nozzle cleansing(2 modes)
Energy saving(2 modes)
Feature DIB-N810 DIB-N830 DIB-N850 DIB-N810R DIB-N830R DIB-N850R
Wash
-
Dry

WARRANTY
35
Dimension
Side arm model
Remote model
34
380mm
200mm
449mm
300mm
528mm
380mm
200mm
449mm
280mm
500mm
380mm
155mm
66mm
10mm
200mm
300mm
528mm
380mm
200mm
99mm 112mm
99mm 112mm
280mm
500mm
[ Elongated ]
[ Elongated ]
[ Round ]
[ Round ]

This device complies with FCC Rules Part 15. Operation is subject to the following two
conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a class B digital
device, pursuant to Part 15 of the Federal Communications Commission (FCC) rules.
These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment o and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CE marking for devices with wireless
This equipment complies with the requirements of Directive 2014/53/EU of the European
Parliament and Commission from 16 April 2014 governing Radio Equipment of conformity.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. To maintain compliance with FCC RF exposure compliance requirements,
please avoid direct contact to the transmitting antenna during transmitting. End users must
follow the specic operating instructions for satisfying RF exposure compliance.
This equipment complies with IC radiation exposure limits set forth for an uncontrolled
environment.
To maintain compliance with IC RF exposure compliance requirements, please avoid direct
contact to the transmitting antenna during transmitting. End users must follow the specic
operating instructions for satisfying RF exposure compliance.
Operation is subject to the following two conditions:
• This device may not cause interference and
• This device must accept any interference, including interference that may cause undesired
operation of the device.
To prevent radio interference to the licensed service (i.e. co-channel Mobile Satellite
systems) this device is intended to be operated indoors and away from windows to provide
maximum shielding.
Equipment (or its transmit antenna) that is installed outdoors is subject to licensing.
Federal Communications Commission Statement CE Marking
FCC Radio Frequency (RF) Exposure Caution Statement
IC Radiation Exposure Statement for Canada
3736

www.lsdaewon.co.kr
ver.2207
