Daewoo SDA2100 User manual

1
750W Food Processor
Model No. SDA2100
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

2
750W Food Processor
Model No. SDA2100
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety
instructions. Failure to do so may result in personal injury or
damage to the product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should always
be followed.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
•Read and familiarise yourself with all operating
instructions before using this Food Processor.
•Before plugging your unit into the mains, visually check
that the unit is intact and has not suffered any transit
damage.
•DO NOT use this Food Processor with an extension cable.
•Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
•Close supervision is required when using this appliance
near children.
•Never leave this appliance within reach of children.
•This appliance shall not be used by children.
•Keep the appliance and its cord out of reach of children.
•Appliances can be used by persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved.

3
750W Food Processor
Model No. SDA2100
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
•Children shall not play with the appliance.
•Children less than 3 years should be kept away unless
continuously supervised.
•DO NOT immerse the appliance or its cord in water or any
other liquids.
•DO NOT leave the appliance unattended during use.
•DO NOT leave the appliance unattended whilst connected
to the mains supply.
•Always use this appliance on a solid, level, non-flammable
surface.
•DO NOT use this appliance outdoors.
•It is imperative to unplug the power cord after the
appliance has been used, before it is cleaned and whilst
being repaired.
•Repairs to electrical appliances should only be performed
by qualified personnel. Improper repairs may place user at
serious risk.
•DO NOT operate this appliance with a damaged plug or
cord, after a malfunction or after being dropped or
damaged in any way.
•Regular, periodic checks should be carried out on the
power cord to ensure no damage is evident. Should there
be any signs of damage the appliance should not be used.
•If the power cord is damaged, it should only be replaced
by the manufacturer or a suitable qualified after-sales-
service in order to avoid a hazard.
•DO NOT allow the power cord to hang over sharp edges or
come in contact with hot surfaces.
•Allow the unit to cool before storage.
•Always disconnect the blender from the supply if it is left
unattended and before assembling, disassembling or
cleaning.

4
750W Food Processor
Model No. SDA2100
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
•This appliance is intended for household use only and
should not be used for industrial purposes.
•DO NOT use any accessories or attachments with this
appliance other than those supplied or recommended by
the supplier.
•DO NOT use this appliance for anything other than its
intended use.
•DO NOT push objects into any openings as damage to the
appliance and/or electric shock may occur.
•Switch off the appliance and disconnect from the supply
before changing accessories or approaching parts that
move in use.
•Grasp the plug, not the cord.
•DO NOT touch the blades whilst the blender is connected
to the mains.
•Wash the blades in warm soapy water, rinse and dry
thoroughly.
•CAUTION: the blades on this Food Processor are very
sharp; extreme caution should be taken when cleaning.
Additional Safety Information
•PLEASE NOTE: Before use, ensure that the Food Processor is
used in an open, well ventilated area well away from other
appliances and other obstructions.
•Do not use the Food Processor in front of, near or below
combustible materials such as plastics, curtains or cupboards,
etc.
•Leave at least 10cm minimum free space between the
appliance and any other surfaces.
•Do not place anything on top of the appliance.

5
750W Food Processor
Model No. SDA2100
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
You should now recycle your waste electrical goods and in
doing so help the environment. This symbol means waste
electrical products at the end of their useful life should not be
disposed of with normal household waste. Please ensure it is
taken to a suitable facility for disposal. Check with your Local
Authority or retailer for recycling advice or visit www.recycle-
more.co.uk to find your nearest recycling point.
WARNING!
This symbol provides useful additional information on the
use of this product.
This symbol indicates that the supply uses an alternating current
mains supply.
This designates a hazard with moderate risk, which may result
in severe injury if not adhered to.

6
750W Food Processor
Model No. SDA2100
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
1. Feeding Hole Lid
2. Blender Jug Lid
3. Blender Jug
4. Blender Blade (not
removable)
5. Processing Bowl
6. Processing Bowl Lid
7. Funnel
8. Pusher
9. Drive Shaft
10.Housing Unit
11.Non-slip Feet
12.Control Dial
Description of Parts
Description of Parts - Accessories
B
E
F
A. Driver
B. Grating Blade
C. Blade Adaptor
D. Slicing Blade
E. Blade Holder
F. Chopper Blade
G. Serrated Blade
D
G
C
6
7
8
5
12
9
10
11
3
4
2
1
A

7
750W Food Processor
Model No. SDA2100
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Before Using Your Food Processor
•Remove all packing materials and discard responsibly.
•Check that all parts are present –see Description of Parts above.
•Before using the blender for the first time, it is recommended to wash all parts
except the motor housing in warm soapy water, rinse and dry thoroughly.
•Never immerse the motor housing unit in water or other liquids.
CAUTION: the blades inside the jug are not removable and are very sharp;
extreme caution should be taken whilst cleaning the inside of the jug.
The blade attachments are very sharp –care must be taken whilst cleaning the
blades.
CAUTION: NEVER BLEND OR PROCESS HOT OR WARM FOODSTUFFS OR
LIQUIDS.
Safety Lock System
This appliance is equipped with a safety lock system which will prevent the
motor starting without correct installation of the bowl and its lid.
CAUTION: DO NOT connect to the mains supply until the food processor is fully
assembled.
To activate the food processor, follow the below instructions:
1.Place the Housing Unit (10) on solid, level, non-flammable
surface.
2.Place the Lid (6) onto the Processing Bowl (5) and
turn the Processing Bowl Lid (6) clockwise until it
clicks into place.
The lid has an activator to trigger the safety lock
system and must be fitted and locked into place onto
the Processing Bowl (5), before placing onto the
Housing Unit (10).
3. Insert the Driver (A) into the Housing Unit (10).
4. Place the Processing Bowl (5) with Lid (6) over the
Driver (A) and position onto the Housing Unit (10) with
the handle to the right, turn clockwise until it clicks
into place.
If the Processing Bowl (5) and Lid (6) are not
correctly locked into place, the food processor will
not operate.
6
5
A
10

8
750W Food Processor
Model No. SDA2100
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Fitting the Processor Bowl & Attachments
Note: All attachments must be securely attached to the blade adaptor.
WARNING! The Blades are sharp so great care should be taken, always
handle blades by the central plastic section.
•Place the Blade Adaptor (C) onto the Drive Shaft (9). See Fig 1 below.
•Grating and slicing blade - Use to grate or slice cheese, vegetables, fruit for
example. Insert either the Grating Blade (B) or the Slicing Blade (D) into the
Blade Holder (E). Fit the Blade Holder (E) onto the top of the Blade Adaptor
(C). The Blade Holder (E) is secured in place when the lid is locked into place.
See Fig 2 below.
•Chopper blade - Use to chop meat, nuts, vegetables, bread crumbs, puree
foods and so on. Place the Chopper Blade (F) onto the Blade Adaptor (C) and
push down until the blade is securely in place at the base of the Blade Adaptor
(C). See Fig 3 below.
Using Your Food Processor
Grating and slicing blade
1. Carefully insert the required blade into the blade holder and fit the Blade
Holder (E) as detailed in Fig 1 and Fig 2 above.
WARNING! The Blades are sharp so great care should be taken.
2. Place the Lid (6) onto the Processing Bowl (5) and insert the Pusher (8), turn
clockwise until its locks into place.
3. Put the Processing Bowl (5) onto the Housing Unit (10), and turn clockwise
until it clicks into place.
4. Connect the mains plug to the power socket and switch the socket on.
5. Turn the Control Dial (12) to choose a processing speed.
6. Feed the ingredients to be grated or sliced down the Funnel (7) using the
Pusher (8).
IMPORTANT: Always use the pusher when feeding food into the funnel, never
push with your fingers.
7. When processing is complete, turn the Control Dial (12) to ‘0’.
8. Hold the Housing Unit (10) and grasp the bowl handle, turn anti-clockwise and
lift to release it.
�
Fig 1
Fig 2
Fig 3
9
C
C
C
F
E

9
750W Food Processor
Model No. SDA2100
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
9. Remove the lid by turning anti-clockwise and carefully remove the Blade
Holder (E) before removing the ingredients.
Chopper blade
1.Fit the chopper blade as detailed in Fig 1 and Fig 3.
2.Place the ingredients into the Processing Bowl (5).
3.Place the Lid (6) onto the Processing Bowl (5) and insert the Pusher (8), turn
clockwise until its locks into place.
4.Put the Processing Bowl (5) onto the Housing Unit (10), and turn clockwise until
it clicks into place.
5.Connect the mains plug to the power socket and switch the socket on.
6.Turn the Control Dial (12) to choose a processing speed.
7.Further ingredients can be added whilst processing by removing the Pusher (8)
and feeding down the Funnel (7).
IMPORTANT: Always use the pusher when feeding food into the funnel,
never push with your fingers.
8.When processing is complete, turn the Control Dial (12) to ‘0’.
9.Hold the Housing Unit (10) and grasp the bowl handle, turn anti-clockwise and
lift to release it.
10.Remove the lid by turning anti-clockwise and carefully remove the Chopper
Blade (F) before removing the ingredients.
Function
Attachment
Ingredient
Max
Qty
Max Times
Slicing
Grating
Slicing and Grating
Potato
400g
50s
30s
Carrot
500g
50s
30s
Chopping
Chopping
blade
Meat
300g
30s
Ham
300g
30s
Onions
100g
30s
Cheese
100g
20s
Almonds
100g
20s
Hazelnuts
100g
20s
Walnuts
100g
20s
Maximum Speed Setting: 2
Do not operate for more than 40 seconds and allow the blender to rest for 1
minute between cycles. Repeat until the desired results
are reached, to finish blending turn the Control Dial (12) to ‘0’.

10
750W Food Processor
Model No. SDA2100
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Fitting the Jug Blender
This appliance is equipped with a safety lock system which will prevent the motor
starting without correct installation of the blender jug and its lid.
WARNING! : Do not connect to the mains supply until the blender is
fully assembled.
Do not operate for more than 40 seconds and allow
the blender to rest for 1 minute between cycles.
Repeat until the desired results are reached, to
finish blending turn the control dial (12) to ‘O’.
To activate the blender follow the below
instructions:
1. Place the Housing Unit (10) facing you on a dry,
level surface.
2. Place the Blender Jug (3) onto the Housing Unit
(10) with the handle to the right, turn clockwise
until it clicks into place.
3. Fit the Lid (2) onto the Blender Jug (3) ensuring
the feeding Lid (1) is place and turn clockwise
until it locks into place.
The jug lid has an activator to trigger the safety lock system and must be
fitted and locked into place onto the blender jug to operate.
Using Your Jug Blender
•Pre-cut solid ingredients into smaller pieces (1.5cm) before you blend them.
•If you have a large amount of ingredients to blend, divide into small quantities
instead of a large quantity at once.
•When blending soup, use cooked ingredients that have been allowed to cool
first.
WARNING! NEVER BLEND HOT INGREDIENTS.
To start blending:
Dsad
1. Place the ingredients into the Blender Jug (3), add the required amount of
liquid, never exceed the max level.
2. Place the ingredients into the Blender Jug (3), add the required amount of
liquid, never exceed the max level.
3. Place the Lid (2) onto the Blender Jug (3) and turn clockwise until it locks.
4. Place the Feeding Hole Lid (1) into the hole in the Lid (2), and turn until secure.
1
2
3
10

11
750W Food Processor
Model No. SDA2100
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
5. Make sure the control dial is set to ‘0’ position and insert the mains plug into
the socket.
6. Turn the Control Dial (12) to choose a blending speed.
7. For an extra control the pulse setting can be used during the blending.
8. Further ingredients can be added whilst blending by removing the feed hole lid.
9. When blending is complete, turn the Control Dial (12) to ‘0’.
10.Hold the Housing Unit (10) and grasp the bowl handle, turn anti-clockwise and
lift to release it.
Food
Max Qty
Max Times
Apples
250g
30s
Oranges
300g
30s
Grapes
250g
30s
Strawberries
250g
30s
Maximum capacity 1200ml
WARNING!
1. NEVER blend boiling liquids or hot ingredients. Allow them to cool before
placing in the jug.
2. Do not operate without liquid
3. Do not crush ice or dried fruit.
4. Do not fill the jug above the Max level, some mixtures increase in volume
during blending and create pressure in the jug.
5. Do not operate for more than 30 seconds and allow the blender to rest for 1
minute between cycles. Repeat until the desired results are reached, to finish
blending turn the Control Dial (12) to ‘0’.
6. Do not allow the blender to work with thick mixtures or heavy foods which will
not let the motor run freely. If the motor does not run freely, stop the blender
and add liquid or reduce the contents of the jug.
Cleaning and Maintenance of Your Food Processor
Always disconnect the food processor from the mains power supply
before cleaning.
Wash the jug, processing bowl and blade attachments in warm soapy water only.
WARNING! The blades inside the jug attachment are not removable and are
very sharp; extreme caution should be taken whilst cleaning the inside of the jug
and attachment.
Clean the outside of the housing unit with a clean damp cloth. Never clean with
harsh or abrasive cleaners.
Do not submerge the housing unit in water or any other liquids.

12
750W Food Processor
Model No. SDA2100
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Troubleshooting Guide
Problem
Possible Cause
Possible Fix
The unit is not
operating
No power to the
unit
Ensure the Mains plug is inserted and
the socket on (if applicable)
The unit is
assembled
incorrectly
Check that the unit is assembled
correctly so that the safety lock
system is activated
Unit stops running
during use
Bowl lid may have
come loose during
processing.
Ensure the bowl lid is correctly fitted.
Motor is running
but the unit is not
processing food.
Driver not installed
correctly.
Ensure the Driver is installed
correctly.
Food is not blended
well
Too lower
processing speed.
Increase the speed setting on the
Control Dial.
Technical Specification
Model Number
SDA2100
Rated Voltage
220-240V~ 50/60Hz
Rated Power
750W
Capacity –Blender
1800ml
Capacity –Processing Bowl
1200ml
Protection Class
II
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse need replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). If in doubt, consult a qualified
electrician. Never use a mains plug with the fuse cover missing.
If you need to remove the plug –DISCONNECT FROM THE MAINS –and then cut
it off the mains lead and immediately dispose of it safely. Never attempt to reuse
the plug or insert it into a socket outlet as there is a danger of electric shock.
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.

13
750W Food Processor
Model No. SDA2100
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Disposal of the Product
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste. Please ensure it is taken to a
suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk to
find your nearest recycling point.

14
750W Food Processor
Model No. SDA2100
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
• The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
• The product must beused solely for domestic purposes.
• It does not cover general wear and tear, damage, misuse or any consumable parts.
• The guarantee will berendered invalid if the product is re-sold or has been damaged through
inexpert repair.
• The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to
the conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
