Daewoo Dreamz HEA1931 User manual

1
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Heated Throw Blanket
Model No. HEA1931
User Manual
User Manual

2
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Heated Throw Blanket
Model No. HEA1931
User Manual
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should
always be followed.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
•Read and familiarise yourself with all operating
instructions before using this Heated Throw Blanket.
•Before plugging your unit into the mains, visually check
that the unit is intact and has not suffered any transit
damage.
•DO NOT use this blanket folded or rucked.
•DO NOT insert pins into this blanket.
•This appliance can be used by children aged from 8 years
old and above and persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved.
•Children shall not play with the appliance.
•Cleaning and user maintenance shall not be made by
children without supervision.
•The appliance can be used by children older than 3 years
and younger than 8 years under supervision and with the

3
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Heated Throw Blanket
Model No. HEA1931
User Manual
controller always set to the minimum (1) temperature
setting.
•Not to be used by very young children (0-3 years).
•This appliance is not to be used by young children over the
age of three unless the controls have been pre-set by a
parent or guardian, or unless the child has been
adequately instructed on how to operate the controls
safely.
•Children under the age of three are not to use this
appliance due to their inability to react to overheating.
•If sleeping for long periods of time, use the low heat
setting (1) to avoid overheating and discomfort.
•Avoid using the blanket with the higher heat settings
(2&3) whilst sleeping as this may increase the risk of skin
burns and heat stroke.
•Only use the Controller marked on the rating label with
this blanket.
•Whilst storing the blanket, allow it to fully cool then fold
neatly but not tightly or roll loosely avoiding sharp bends
in the heating element.
•DO NOT crease the appliance by placing other items on
top of the blanket.
•Examine the appliance frequently for signs of wear or
damage. If there are such signs, if the appliance has been
misused or does not work return it to the supplier before
switching it on again.
•This blanket is for domestic use only and is not intended
for commercial use or for use in hospitals.
•DO NOT use if damp or wet.
•This appliance must not be used by persons insensitive to
heat and other very vulnerable persons who are unable to
react to overheating.

4
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Heated Throw Blanket
Model No. HEA1931
User Manual
•The appliance should not be used on an adjustable bed.
•When in use ensure the blanket & mains lead do not get
trapped.
•The cable and control unit of the appliance can give rise to
risks of entanglement, strangulation, tripping or treading if
not correctly arranged. The user shall make sure that
excess ties and electric cords shall be arranged in a safe
way.
•The blanket is for use only as an underblanket to be fitted
directly on top of the mattress underneath the bedding
and fitted as described in the manual.
•Arrange the blanket so it is not positioned beneath
bolsters or pillows.
•DO NOT dry clean this Heated Blanket, for cleaning follow
the instructions supplied.
•There are no user serviceable parts, the blanket should
only be repaired or serviced by a qualified service
engineer.
•It is recommended this Heated Blanket is used in
conjunction with a residual current device (RCD) with a
rated residual operating current not greater than 30mA.
•This blanket is only for use by humans and shouldn’t be
used for pets.
•When in use the control unit must not be placed near
open windows or inside the bed covers.
•Be sure the blanket is only connected to an electrical
supply as specified in the instructions.
•Switch off the power and remove the plug from the socket
outlet when not in use.
•It is recommended that this appliance should not be used
whilst sleeping.

5
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Heated Throw Blanket
Model No. HEA1931
User Manual
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with this symbol conform to applicable provisions
of the European Economic Area.
Products labelled with UK Conformity Assessment identifies products
conforming to UK statutory requirements.
This symbol indicates that the heater is double insulated and
therefore does not require an Earth connection.
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken to
a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk enter
your postcode to find out your nearest recycling site.
This symbol provides useful additional information on the use of this
product.
This symbol indicates that the supply uses an alternating current
mains supply.
WARNING!
This designates a hazard with moderate risk, which may result
in severe injury if not adhered to.

6
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Heated Throw Blanket
Model No. HEA1931
User Manual
Before first use of Your Heated Throw Blanket
Remove all packing materials and discard responsibly.
Description of Parts
Using Your Heated Throw Blanket
1.Ensure the Mains Plug (4) is not plugged into the socket.
2.Insert the Receptacle Connector (5)
into the Plug Connector (1).
3.Ensure the ON/OFF Switch (3) is in the
‘off’ position.
2
3
1. Plug Connector (Female Connector)
2. Display
3. ON/OFF Switch
4. Mains Plug
5. Receptacle Connector (Male Connector)
6. Heat Button
7. Timer Button
1
4
5
6
7
2
1
5

7
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Heated Throw Blanket
Model No. HEA1931
User Manual
4. Insert the Mains Plug (4) into the nearest socket.
5. Move the ON/OFF Switch (3) to the ‘on’
position.
6. Press the Heat Button (6) to power up the
Heated Throw Blanket.
WARNING! This Heated Throw Blanket is only to be used with the controller
supplied.
Setting the ‘on’ Time
1.Set the length of time you desire the Throw to be on
by repeatedly pressing the Timer Button (7).
2.Each press of the Timer Button (7) will set the ‘on’
time for 1, 2 or 10 hours, which will be shown on the
Display (2) right:

8
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Heated Throw Blanket
Model No. HEA1931
User Manual
Setting the Heat level
Choose the desired Heat level by repeatedly pressing the Heat Button (6) from
Lowest 1 to the Highest 9, which will be shown on Display (2) as below:
During the first few minutes of initial use, you may notice a slight odour.
This is normal and will quickly disappear, It is the coating applied to the heating
elements to prevent any corrosion during transit.
This Heated Throw Blanket should never be used whilst folded or rucked as this
will cause overheating and the operation of the thermal safety device and stop the
product working.
Detaching the Controller
Before removing ensure the controller is set to ‘0’(OFF) position and remove the
mains plug from the wall socket.
Lift the locking tab up and pull the controller socket directly out as shown below.
Do not pull the controller cable and Do Not try and pull the controller socket out
without lifting the locking tab as the socket may be damaged.

9
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Heated Throw Blanket
Model No. HEA1931
User Manual
Care and Maintenance
•Machine wash at a maximum temperature of 30°C
•Do not bleach.
•Do not tumble dry
•Do not iron.
•Do not dry clean.
•Line dry.
•Do not use folded or rucked.
•Do not insert pins into heated pad.
•Do not use the heated pad if wet or moist.
•Do not use with a helpless person, an infant or a person insensitive to heat.
•Not to be used by very young children (0-3 years)
Spot cleaning
Sponge the affected area using a lukewarm neutral detergent or a mild soap
solution. Follow this by sponging using clean water. Remove any excess water by
compressing the wet area between absorbent towels.
Washing the Heated Throw Blanket
WARNING!
•BEFORE WASHING, DISCONNECT THE CONTROLLER FROM THE HEATED THROW
BLANKET AS DESCRIBED ABOVE.
•DO NOT ALLOW THE CONTROLLER, ITS MAINS CABLE OR PLUG TO COME INTO
CONTACT WITH WATER OR ANY OTHER LIQUIDS.
Hand Washing
Immerse the blanket only in a lukewarm neutral detergent or soap solution.
Soak for five minutes then remove from the solution and gently squeeze the
solution through the blanket, rinse in clean water.
After washing, lay the blanket flat or drape the blanket over a clothesline to dry,
DO NOT use clothes pegs to secure it to the line.
DO NOT wring the blanket.

10
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Heated Throw Blanket
Model No. HEA1931
User Manual
Machine Washing
Disconnect the controller and place the blanket in a net bag and seal it. Use a
small amount of detergent and set the washing machine to a “Delicate Wash” with
a maximum temperature of 30°.
After washing, lay the blanket flat or drape the blanket over a clothesline to dry,
DO NOT use clothes pegs to secure it to the line.
DO NOT wring the blanket.
Technical Specification
Model Number
HEA1931
Rated Voltage
230V AC ~ 50Hz
Rated Power
110W
Dimensions
160cm x 120cm approx.
Protection Class
II
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse needed replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). Never use a plug with the fuse cover
missing. If in doubt, consult a qualified electrician.
If you need to remove the plug -DISCONNECT FROM THE MAINS- and then cut it
off the mains lead and immediately dispose of it safely. Never attempt to reuse
the plug or insert it into a socket outlet as there is a danger of electric shock.
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken
to a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk enter
your postcode to find out your nearest recycling site.

11
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Heated Throw Blanket
Model No. HEA1931
User Manual

12
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Heated Throw Blanket
Model No. HEA1931
User Manual
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof of
purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the discretion
of the retailer.
The guarantee is subject to the following provisions:
• The product must becorrectly installed and operated in accordance with the requirements
contained in the instruction manual.
• The product must beused solely for domestic purposes.
• It does not cover general wear and tear, damage, misuse or any consumable parts.
• The guarantee will berendered invalid if the product is re-sold or has been damaged through
inexpert repair.
• The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and covers
the main body and housing). If you do not register your product within 28 days of the original
purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28 days
of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
