Sunbeam Select-a-Cycle DAT100 User manual

uttbe m
Select a Cycle Heating Pad
Model: DAT100
RA.PID INTERVAL WAVE
MANUAl.
iii I1-0' 0 HOH
A. Heat Intensity Meter
B.Preprogrammed
Settings
C. Standard Heat
Settings
D. Power/Selection
Button

IMPORTANT SAFETY
INSTRUCTIONS
DO NOT DESTROY
DAN GER - TO REDUCE THE RISK OF BURNS, ELECTRIC SHOCK
AND FIRE, THIS PRODUCT MUST BE USED IN ACCORDANCE WITH THE
FOLLOWING INSTRUCTIONS:
1. REAO ALL INSTRUCTIONS.
2. DO NOT USE WHILE SLEEPING.
3. DO NOT USE ON AN INFANT OR ON AN ANIMAL.
4. THIS PAD IS NOnO BE USED ON OR BY AN INVALID, SLEEPING,
HELPLESS OR UNCONSCIOUS PERSON, A PERSON WITH DIABETES, A
PERSON WITH POOR BLOOD CIRCULATION OR INSENSITIVITY TO HEAT.
5. THIS APPLIANCE IS NOT TO BE USED BY CHILDREN. CLOSE
SUPERVISION IS NECESSARY WHEN ANY APPLIANCE IS USED NEAR
CHILDREN. CHILDREN SHOULD NOT PLAY WITH THE APPLIANCE.
6. DO NOT USE ON AREAS OF INSENSITIVE SKIN.
7. BURNS CAN OCCUR REGARDLESS OF CONTROL SETTING, CHECK SKIN
UNDER PAD FREQUENTLY.
8. IF PROVIDED WITH A REMOVABLE COVER, NEVER USE PAD WITHOUT
COVER IN PLACE.
9. DO NOT USE IN AN OXYGEN ATMOSPHERE.
10. DO NOT USE PINS OR OTHER METALLIC MEANS TO FASTEN THIS PAD IN
PLACE.
11. DO NOT SIT ON, AGAINST, OR CRUSH PAD - AVOID SHARP FOLDS. PLACE
PAD ON TOP OF AND NOT UNDER THE PART OF BODY NEEDING HEAT.
12. UNPLUG WHEN NOT IN USE. NEVER LEAVE APPLIANCE UNATTENDED,
ESPECIALLY IF CHILDREN ARE PRESENT.
13. NEVER PULL THIS PAD BYTHE SUPPLY CORD. DO NOT USE THE CORD
AS A HANDLE. DO NOT PINCH CORD.
14. DO NOT TUCK IN, TRAP, FOLD, CROSS, PINCH OR WRAP CONTROL OR

CORD WITH HEATING PAD DURING USE.
15.CAREFULLY EXAMINE PAD, COVER, CORD AND CONTROLLER BEFORE
EACH USE. DISCARD THE PAD IF ANY SIGN OF DETERIORATION, WEAR OR
DAMAGE. DO NOT TAMPER WITH THIS PAD IN ANY WAY. THERE ARE NO
USER SERVICEABLE PARTS. IF PAD DOES NOT FUNCTION SATISFACTORILY,
SEE WARRANTY FOR CUSTOMER CONTACT INFORMATION.
16. LOOP CORD LOOSELY WHEN STORING, TIGHT WRAPPING MAY DAMAGE
CORD AND INTERNAL PARTS.ALLOW TO COOL BEFORE STORING AND
DO NOT CREASE BY PLACING ITEMS ON TOP OF IT. STORE IN THE
ORIGINAL PACKAGING, IN A COOL, DARK,DRY PLACE.
17. IF PROVIDED WITH A DETACHABLE CONTROLLER, USE ONLY WITH THE
PROVIDED CONTROLLER.
18.USE THIS PAD ONLY AT RATED VOLTAGE, AS MARKED ON THE PRODUCT.
DO NOT USE WITH GENERATORS, POWER CONVERTERS, OR INVERTERS.
19. DO NOT USE THIS PAD WITH LINIMENT, SALVE OR OINTMENT
PREPARATIONS.SKIN BURNS COULD RESULT.
20. IF PAD IS PROVIDED WITH MAGNETIC CLOSURES: DO NOT USE
IF YOU HAVE A PACEMAKER,ICD (IMPLANTABLE CARDIOVERTER
DEFIBRILLATOR), INTERNAL INSULIN PUMP OR OTHER MEDICAL
DEVICES SENSIlIVE TO MAGNETS.
21. THIS APPLIANCE IS NOT INTENDED FOR MEDICAL USE IN HOSPITALS .
.22. MODELS WITH A MASSAGE FUNCTION: DO NOT MASSAGE ABDOMEN
WHEN PAIN IS PRESENT, OR AREAS THAT ARE SWOLLEN, INFLAMED,
COVERED WITH SKIN ERUPTIONS OR UNEXPLAINED PAIN. CONSULT A
PHYSICIAN BEFORE USING ANY EQUIPMENT OF THIS TYPE.
23. SOME MODELS MAY CONTAIN FILLING MATERIAL (PELLETS OR BEADS),
MADE FROM EITHER ABS PLASTIC (NON-MICROWAVABLE MODELS)
OR SILICON DIOXIDE (MICROWAVABLE MODELS). IF FILLING MATERIAL
IS RELEASED DUE TO PRODUCT DAMAGE, DISCONTINUE USE OF
PRODUCT. DO NOT INGEST FILLING MATERIAL. IF FILLING MATERIAL IS
INGESTED, SEEK MEDICAL ATIENTION.
24. SAVE THESE INSTRUCTIONS.
HOUSEHOLD USE ONLY

NORTH AMERICAN MODELS WITH POLARIZED PLUGS:
POLARIZED PLUG
~
THIS APPLIANCE HAS A POLARIZED PLUG, (ONE BLADE
.IS WIDER THAN THE OTHER).AS A SAFETY FEATURE
. TO REDUCE THE RISK OFELECTRICAL SHOCK, THIS
PLUG IS INTENDED TO FIT INA POLARIZED OUTLET
ONLY ONE WAY. IFTHE PLUG DOES NOT FIT FULLY IN THE OUTLET,
REVERSETHE PLUG. IF ITSTILLDOES NOT FIT, CONTACT A QUALIFIED
ELECTRICIAN.DO NOT ATIEMPT TO DEFEAT THIS SAFETY FEATURE
OR MODIFY THE PLUG IN ANY WAY. IFTHE PLUG FITSLOOSELY INTO
THEAC OUTLET OR IFTHE AC OUTLETFEELS WARM DO NOT USE
THAT OUTLET
HOW TO USE YOUR HEATING PAD
Make sure ControlConnectoris securely attached to the Pad Connector
(Figure 1). Push both parts together fora tight fit
NOTE: Control mustbe connected to heating pad before plugging unit into
outlet
1. After control is connected to pad,pluginto 120V AC electrical outlet
Your Sunbeant Select-a-Cycle heating pad features a unique
4-in-7 functionality, with 3 preprogrammed settings and the standard
High-Med-Low heat settings.
2. Toturn the pad on, press the Power Button. Then select from 3 preprogrammed
settings and 3 standard heat options byscrolling to the desired setting with the
Power button.TheLED associated WITheach setting will illuminate as you scroll throughthe settings.
3.To turn the pad OFF,press Ihe Power Button until all of the lights are turned off.
WARNINGS:
1.DO NOT SIT ON OR AGAINST OR CRUSH PAD - AVOID FOLDING DURING USE.
2.DO NOT USEWHILE SLEEPING.
3. PLACE PAD ON TOP OFAND NOT UNDER THE PART OFTHE BODY NEEDING HEAT.
NOTE:See additional warnings under the SAFEGUARDS section.
B. Pad Connector
o~ it.
•ill
OML ,<
A. Control Connector
Figure 1
PREPROGRAMMED SETTINGS
Rapid:This setting will cycle through 5 minutes on high heat and 8 minutes onmediumfor2 hours untilAuto
Off activales.
Interval: This setting will cycle through 20 minutes on high heat and 7 minutes on low heat for 2 hours until
Auto Off activates.
Wave: This setting will cycle Ihrough 8minutes on high heat and 20 minutes on low heatfor two hours until
Auto Off activales.

AUTO-OFF FEATURE
Yourheating pad controller includes an Auto-Off feature. For each setting,Auto Off will activate after 2 hours
of use.
USING MOIST HEAT THERAPY
In some cases,you mayfind that moist heat therapy provides more comfort and
relief. When using moist heat therapy, you should protect furniture and clothing
from becoming damp.
Dampen eITherside of the heating pad wIThwater by patting the surface wITha wet
sponge or cloth or use a spray bottle to apply a fine mist.Do not thoroughly soak pad.
DO NOT SPRAY OR DAMPEN THE PAD CONNECTOR. (Figure 2)
DANGER:Do not immerse the pad or winng in water or place under running water.
Failure to comply mayresult in product failure and/or personalinjury.
CAUTION:The electricalpad connector must be thoroughly dry before establishing
electrical connection.
-
" \
".. ~
" 'i
~.~.
r ~
a
, \ ..
, , .
-
Figure 2
WASHING INSTRUCTIONS
CAUTION: 00 NOT DRY CLEAN DO NOT BLEACH DO NOT USE WRINGER
1. Disconnect pad from outlet.
2.Detach Pad Connector from the Control Connector.
3.Wash byhand or as follows in an automatic washer using slowagitation and normal spin speed:
Fill washer with warm water Add minimum amount of all-purpose detergent, agitate to dissolve,
measure heating pad before washing. Add heating pad and soak five minutes. Agitate two
minutes. Spin Fill for cool rinse, agitate one minute then spin. Dry in automatic dryer on high
heat,five minutes only, or line dry Remove damp heating pad from dryer, block to original size,
and drape to finish drymg. Do not iron your heating pad.
4. Do not plug in pad and pad connector untiltheyare completely dry.
FCC CERTIFIED
This devicecomplieswith part 15 of the FCC Rules.Operationis subject to the following two conditions:
(1) This devicemay notcause harmful interterence, and (2) this device must accept any interterence
received, including interference thatmay cause undesiredoperation.
Note: This product has been tested and found tocomply with thelimitsfor a Class B digitaldevice,
pursuant to part 15 01the FCC Rules. These limitsare deSigned to provide reasonable protectionagainst
harmful interterencein a residential installation. This product generates, uses and can radiate radio
frequency energy and,If not installed and used in accordancewith the instructions, maycause harmful
interferenceto radio communications.However, there is no guarantee that interference will not occur in
a particular installation.If thisproduct does cause harmful interferenceto radio or television reception,
which can be determined by turning the product off and on, the userISencouraged to try to correct the
interference by oneormore ofthefollowing measures:
• Reorient or relocate the receivingantenna.
• Increase the separation betweenthe product and receiver.
•Connect the productinto an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radiofTV technician for help.
Changes or modifications not expressly approvedbytheparty responsible for compliance couldvoidthe
user's authority to operate the equipment

ICES CERTIFIED
This product complies with CAN ICES-3 (B)/NMB-3(B).
PLEASEDO NOT REllJRNTHIS PRODUCT TO ANY OF THESE ADDRESSES OR TO THE PLACE OFPURCHASE.
5-YEAR LIMITED WARRANTY
SUnbeam Pnxlucts,Inc.do1ng business as Jarden Consumer SolutiollS or if in Canada, Sunbeam Corporatioo (Canada) Umiled doing business as
Jarclen Consumer Solutions (collectively·JCS") warrants ltJat for a period offive years from 1M date of purchase, this product will be free from
defects in material and wor1<manship.JCS, alits option, will repair or replace this product or any component of the product fClUnd to be defective
during the warranty period.Replacement will be made with a new or remanufactured product or component Ithe prodoct is no longer available,
replacement may be made with a similar product ofeQual orgreatervalue.This is yourexdusive warrnnty.Do NOT attempt to repair or adjust any
electricalor mechanicallunctions on this product. Doing so willvoid this warranty. Thiswarranty is valid lor the original retail purchaser from the
date of initial retail purchase and is not translerable. Keep the originalsales rKeip . Proof of purchase is required to obtain warranty performance
JCS dealers, sef'lice centers, or retail stores selling JCS products do not havethe right to alter. modify or anyway change the terms and conditions
of this warranty. This warranty does not cover normal wear of parts or damageresultillg from any of the 10Howing: negligent use or misuse 01 the
product,use on improper voltage or current, use contrary to the operating instructions, disassembly, repair or alteration by anyoneotller than JCS
or an authorized JCS sef'lk:e center. Further, thewarranty does not cover:Acts of God, such as fire, flood, hurricanes and tornadoes.
Whatare the limits on JCS'sliability?
JCS shall not be liable for M1y incidentalor consequential damages caused by the breach of any express, implied or statutory warranty or cOllditiorl.
Except to the extent prohibited by applicable law, any implied warranty or condition ofmerchantability or fitness for a particular purpose is limited
in duration to the duration of the above warranty.
JCS disclaims all other warranties, conditions or representations,express, implied,statutory or otherwise. JCS shall 1101be liable forany damages of
any kind resutting from the purchase,use or misuse of, or inability to use the product including incidental,special, consequential or similar damages
or loss of profits, or for any breaclt of contract, fundamental or otheJWlse, or for any claim brought against purchaser by any other party. Some
provinces,states orjurisdictions do not allow the exclusion Of limitation 01 incidentalor consequential damages or limitations on how long animplied
warranty lasts, so the above limitations orexdusion may not apply to you. This warranty givesyou specific legal rights, and you may also have other
riglrts that vary from province to province,state to state or jurisdicti<ln to jurisdiction.
How toObtainWarranty Sel1llce
In theU.S.A. - If you ha~ any Question regarding this warranty or would like to Gbtain warranty sef'lice, please call 1-800-435-1250 and a
convenient servicecenter address will tie provided to you.
In canada, -II y()U have any Question regarding this warranty or would liketo obtain warranty service,please call 1·800-667-8623 and a convenient
sef'lice center address will be provided to you.
In the U.S.A., this warranty is offered by Sunbeam Products,loc.doing bosiness as Jarden Coosumer Solutions located inBoca Raton, FkXida
33431. In canada, this warranty is offered by Sunbeam Corporation (canada) Limited ooing business as JardenConsumerSolutions, located at 20
8 Hereford Street, 8rampton, Ontario L6Y OM1.lf you have any otherproblem or daim in connection with this product, please write our Consumer
Service Department.
or inquiries regarcllngrecyclingand proper disfJ()Sal ofthis product, please contactyourlocal waste mllmlg8ment facilily.
www.sunbeam.com
C2011 Sunbeam Products, Inc. doing busirl'lss as Jilrden I))nsumer SoIutioIllI. An rigllts reser<ed. DistrIbuted bySunbeam Products. IOC.doing business as
. arden I))nsumerSolutions. Boca Raton. Florida 33431. SIlnbeam Prodocts.lrn.:. is a subsld~ry of HewellBrarHJsInc.(NVSE:NWL).
Printed inChIna. DATHXU7EMl CSH-JC0317 ·SUN52376 PIt 183061·1
