NVR Series Quick Start Guide
V4.0.0

i
Table of Contents
1INSTALLATION AND CONNECTIONS ....................................................1
1.1 Check Unpacked NVR.......................................................................................................1
1.2 Front Panel .........................................................................................................................1
1.2.1 NVR 6000/6064 Series..................................................................................................1
1.2.2 NVR 600 Series.............................................................................................................3
1.2.3 NVR 724 Series.............................................................................................................5
1.3 Rear Panel..........................................................................................................................7
1.3.1 NVR 6000/6064 Series..................................................................................................7
1.3.2 NVR 600 Series.............................................................................................................8
1.3.3 NVR 724 Series.............................................................................................................9
1.4 Alarm Input and Output Connection ...............................................................................10
1.4.1 Alarm Input and Output Details ..................................................................................11
1.4.2 Alarm Input Port...........................................................................................................13
1.4.3 Alarm Output Port........................................................................................................13
2OVERVIEW OF NAVIGATION AND CONTROLS..................................15
2.1 Boot up..............................................................................................................................15
2.2 Login..................................................................................................................................15
2.3Preview .............................................................................................................................16
2.4 Search & Playback...........................................................................................................17
2.5 Network.............................................................................................................................22
2.6 Remote Device.................................................................................................................24

ii
2.7 Manual Record .................................................................................................................26
2.7.1 Record Operation........................................................................................................26
2.7.2 Snapshot Operation.....................................................................................................26
2.8 RAID Manager..................................................................................................................27
2.9 Face Detect ......................................................................................................................31
2.10 Audio Detect .....................................................................................................................31
2.11 Shutdown..........................................................................................................................32
3WEB OPERATION .................................................................................34
3.1 General Introduction ........................................................................................................34
3.1.1 Preparation...................................................................................................................34
3.2 Login..................................................................................................................................34
3.3 Main Window ....................................................................................................................35
3.3.1 LAN Login.....................................................................................................................35
3.3.2 WAN Login...................................................................................................................35
APPENDIX TOXIC OR HAZARDOUS MATERIALS OR ELEMENTS ...........36

iii
Welcome
Thank you for purchasing our NVR!
This quick start guide is designed to be a reference tool for the installation and operation
of your system.
Before installation and operation please read the following safeguards and warnings
carefully!
Please keep it for future reference!

iv
Important Safeguards and Warnings
1．Electrical safety
All installation and operation here should conform to your local electrical safety codes.
The product must be grounded to reduce the risk of electric shock.
We assume no liability or responsibility for all the fires or electrical shock caused by
improper handling or installation.
2．Transportation security
Heavy stress, violent vibration or water splash are not allowed during transportation,
storage and installation.
3．Installation
Keep upwards. Handle with care.
Do not apply power to the NVR before completing installation.
Do not place objects on the NVR.
4．Qualified engineers needed
All the examination and repair work should be done by the qualified service engineers.
We are not liable for any problems caused by unauthorized modifications or attempted
repair.
5．Environment
The NVR should be installed in a cool, dry place away from direct sunlight, inflammable,
explosive substances and etc.
This series product shall be transported, storage and used in the specified environments.
6. Lithium battery
Improper battery use may result in fire, explosion, or personal injury!
When replace the battery, please make sure you are using the same model!
7. Accessories
Be sure to use all the accessories recommended by manufacturer.
Before installation, please open the package and check all the components are included.
Contact your local retailer ASAP if something is broken in your package.

1
1Installation and Connections
Note: All the installation and operations here should conform to your local electric safety
rules.
1.1 Check Unpacked NVR
When you receive the NVR from the forwarding agent, please check whether there is any
visible damage. The protective materials used for the package of the NVR can protect most
accidental clashes during transportation. Then you can open the box to check the accessories.
Please check the items in accordance with the list. Finally you can remove the protective film of
the NVR.
1.2 Front Panel
1.2.1 NVR 6000/6064 Series
For the product of LCD, the front panel is shown as below. See Figure 1-1.
Figure 1-1
Please refer to the following sheet for front panel button information.
SN
Name
Function
1
Power button
Press it once to turn on the device.
Press it for a long time to turn off the device. (Usually we do not
recommend).
Press power button for a long time or pull out the power cable may
result in device auto restart.
2
System HDD
Indicator light
The blue light flashes when system is reading or writing the system
HDD.
In the system HDD, there are device important configuration file,
factory default configuration file, and device initial boot up data.
3
Alarm indicator
light
The alarm indicator light becomes on once an alarm occurred. It
becomes on via the software detection. The alarm includes local
alarm, no disk and etc.
4
Network
The network indicator light is blue and it flashes when you connect the

2
indicator light
device to the network.
5
USB port
/
6
Front panel lock
/
Another front panel, it is shown as in Figure 1-2.
Figure 1-2
Please refer to the following sheet for detailed information.
SN
Name
Function
1
Power button
Press it once to turn on the device.
Press it for a long time to turn off the device (Usually we do not
recommend).
Press power button for a long time or pull out the power cable may
result in device auto restart.
2
System HDD
Indicator light
The blue light flashes when system is reading or writing the system
HDD.
In the system HDD, there are device important configuration file,
factory default configuration file, device initial boot up data.
3
Alarm indicator
light
The alarm indicator light becomes on once an alarm occurred. It
becomes on via the software detection. The alarm includes local
alarm, no disk and etc.
4
Network
indicator light
The network indicator light is blue and it flashes when you connect the
device to the network.
5
USB port
/
6
16 HDD slot
/
After you remove the front panel, you can see there are 16 HDDs. From the left to the right and
from the top to the bottom, it ranges from 1~4, 5~8, 6~12, 13~16. See Figure 1-3.
You can see there are two indicator lights on the HDD bracket.
The power indicator light is at the top. The light is yellow after you connected the device to
the power.
The read-write indicator light is at the bottom. The blue light flashes when system is
reading or writing the data.

3
Figure 1-3
1.2.2 NVR 600 Series
The front panel is shown as in Figure 1-4.
Figure 1-4
Please refer to the following sheet for detailed information.
Name
Icon
Function
Power button
Power button, press this button for three seconds to boot up or
shut down NVR.
Number button
0-9 and
etc
Input Arabic number
Switch channel
Record
REC
Manually stop/start recording, working with direction keys
or numeral keys to select the recording channel.
Input number
more than 10
-/--
If you want to input a number more than 10, please click this
button and then input.
ESC
ESC
Go to previous menu, or cancel current operation.
When playback, click it to restore real-time monitor mode.
Assistant
Fn
One-window monitor mode, click this button to display assistant
function: PTZ control and image color.
Backspace function: in numeral control or text control, press it for
1.5seconds to delete the previous character before the cursor.

4
In motion detection setup, working with Fn and direction keys to
realize setup.
In text mode, click it to switch between numeral, English
character(small/capitalized) and etc.
In HDD management interface, you can click it to switch HDD
record information and other information (Menu prompt)
Realize other special functions.
Window switch
Mult
Click it to switch one-window/multiple-window.
Shift

In textbox, click this button to switch between numeral,
English(Small/Capitalized),donation and etc.
Enable or disable tour.
Up/
Down

Activate current control, modify setup, and then move up and
down.
Increase/decrease numeral.
Assistant function such as PTZ menu.
Left/
Right

Shift current activated control, and then move left and right.
When playback, click these buttons to control playback bar.
Slow play
Multiple slow play speeds or normal playback.
Fast play

Various fast speeds and normal playback.
Play previous
In playback mode, playback the previous video.
Reverse/Pause

In normal playback or pause mode, click this button to reverse
playback
In reverse playback, click this button to pause playback.
Play Next
In playback mode, playback the next video
Play/Pause

In normal playback click this button to pause playback.
In pause mode, click this button to resume playback.
In backward playback or pause mode, click this button to resume
normal playback.
In real-time monitor mode, click this button to go to the search
menu.
Enter
ENTER
Confirm current operation
Go to default button

5
Go to menu
Shuttle(outer
ring)
In real-time monitor mode it works as left/right direction key.
Playback mode, counter clockwise to forward and clock wise to
backward.
Jog(inner dial)
Up/down direction key.
Playback mode, turn the inner dial to realized frame by frame
playback. (Only applies to some special versions.)
USB port
To connect USB storage device, USB mouse and etc.
Channel indicator
light
1-16
It becomes on when system is recording.
IR Receiver
IR
It is to receive the signal from the remote control.
Power indicator
light
POWER
Power indicator light.
Remote control
indicator light
ACT
Remote control indicator light.
Status indicator
light
STATUS
If there is Fn indicator light, current status indicator light is null.
HDD abnormal
indicator light
HDD
The indicator light is on when there is no HDD, HDD error
occurred or HDD capacity is below specified threshold value.
1.2.3 NVR 724 Series
The front panel is shown as in Figure 1-5.

6
Figure 1-5
SN
Icon
Name
Function
1
Front panel
lock
/
2
USB port
/
3
Network
indicator light
The network indicator light is blue and it flashes when
you connect the device to the network.
4
Alarm
indicator light
The alarm indicator light becomes on once an alarm
occurred. It becomes on via the software detection.
The alarm includes local alarm, no disk and etc.
5
System HDD
Indicator light
The blue light flashes when system is reading or
writing the system HDD.
In the system HDD, there are device important
configuration file, factory default configuration file,
device initial boot up data.
6
Power button
Press it once to turn on the device.
Press it for a long time to turn off the device (Usually
we do not recommend).
Press power button for a long time or pull out the
power cable may result in device auto restart.
After you remove the front panel, you can see there are 24 HDDs. From the left to the right and
from the top to the bottom, it ranges from 1~4, 5~8, 9~12, 13~16, 17～20, 21～24. See Figure
1-6.
You can see there are two indicator lights on the HDD bracket.

7
: The power indicator light is at the top. The light is yellow after you connected the
device to the power.
: The read-write indicator light is at the bottom. The blue light flashes when system is
reading or writing the data.
Figure 1-6
1.3 Rear Panel
1.3.1 NVR 6000/6064 Series
The general series rear panel is shown as in Figure 1-7.
Figure 1-7
The redundant power series rear panel is shown as in Figure 1-8.

8
Figure 1-8
Please refer to the following sheet for rear detailed information.
SN
Function
SN
Function
1
Power socket
6
Video VGA output
2
Audio Input
7
eSATA port
3
Audio output
8
USB port
4
Bidirectional talk input
9
HDMI port
5
Network port
10
Alarm input, alarm output, RS485 port.
Important
Right now, system does not support audio input port. System supports HDMI1/HDMI2
port by default. You need to purchase HDMI interface board if you want to use
HDMI3-HDMI6 port.
1.3.2 NVR 600 Series
The NVR608 general series rear panel is shown as in Figure 1-9.
Figure 1-9
The NVR608 redundant power series rear panel is shown as in Figure 1-10.

9
Figure 1-10
Please refer to the following sheet for detailed information.
SN
Function
SN
Function
1
Power socket
7
Ethernet port
2
Alarm input, alarm
output, RS485 port.
8
HDMI port
3
RS232 port
9
USB 2.0 port
4
Audio output
10
USB 3.0 port
5
Audio input
11
eSATA port
6
VGA port
1.3.3 NVR 724 Series
The general rear panel is shown as in Figure 1-11.
Figure 1-11
The redundant power series rear panel is shown as in Figure 1-12.

10
Figure 1-12
Please refer to the following sheet for detailed information.
SN
Name
SN
Name
1
Alarm input/alarm output
2
HDMI port（Reserved port. Right now
system does not support HD decode
card.）
3
Power port
4
HDMI port
5
eSATA port
6
USB port
7
SAS port
8
Video VGA output
9
Network port
10
RS485 port
11
RS232（RS422）port
12
Audio input port
13
Audio output port
1.4 Alarm Input and Output Connection
Please refer to the following sheet for alarm input and output connection.
There are two alarm input types for you to select: normal open (NO) and normal close (NC).
1. Alarm input
a. Please make sure alarm input mode is grounding alarm input.
b. Grounding signal is needed for alarm input.

11
c. Alarm input needs the low level voltage signal.
d.Alarm input mode can be either NC (normal Open) or NO (Normal Close)
e. When you are connecting two NVRs or you are connecting one NVR and one other device,
please use a relay to separate them.
2. Alarm output
The alarm output port should not be connected to high power load directly (It shall be less than
1A) to avoid high current which may result in relay damage. Please use the co contactor to
realize the connection between the alarm output port and the load.
3. Please make sure the front-end device has soundly earthed.
Improper grounding may result in chip damage.
1.4.1 Alarm Input and Output Details
1.4.1.1 NVR 6000/6064 Series
You can refer to the following sheet Xfor alarm input and output information. See Figure 1-13.
Figure 1-13
Icon
Note
1，2，3，4，5，6，
7，8，9，10，11，
12，13，14，15，16
ALARM 1 to ALARM 16. The alarm becomes active in low voltage.
1-ON C，2-ON C，
3-ON C，4-ON C，
5-ON C，6-ON C，
7-ON C，8-ON C
Eight groups of normal open activation output (on/off button)
G
GND cable.
A/B
The A/B cable to control the RS485 devices. It is to connect to
control decoder such as the recorder.
Tx and Rx
RS232 port. Tx is the data output cable and the Rx is the data input
cable.
1.4.1.2 NVR 608 Series
You can refer to the following sheet Xfor alarm input and output information. See Figure 1-14.

12
Figure 1-14
Icon
Note
1，2，3，4，5，6，
7，8，9，10，11，
12，13，14，15，16
ALARM 1 to ALARM 16. The alarm becomes active in low voltage.
1-ON C，2-ON C，
3-ON C，4-ON C，
5-ON C，6-ON C，
7-ON C，8-ON C
Eight groups of normal open activation output (on/off button)
GND cable.
A/B
The A/B cable to control the RS485 devices. It is to connect to
control decoder such as the recorder.
1.4.1.3 NVR 724 Series
You can refer to the following sheet Xfor alarm input and output information. See Figure 1-15.
Figure 1-15

13
Icon
Note
1～4
ALARM 1 to ALARM 4. The alarm becomes active in low
voltage.
NO1 C1，NO2 C2，NO3 C3，NO4
C4
Four groups of normal open activation output (on/off
button)
GND
1.4.2 Alarm Input Port
Please refer to the following sheet for more information.
Grounding alarm inputs. Normal open or Normal close type)
Please parallel connect COM end and GND end of the alarm detector (Provide external
power to the alarm detector).
Please parallel connect the Ground of the NVR and the ground of the alarm detector.
Please connect the NC port of the alarm sensor to the NVR alarm input(ALARM)
Use the same ground with that of NVR if you use external power to the alarm device.
Figure 1-16
1.4.3 Alarm Output Port
Provide power to peripheral alarm device.
To avoid overloading, please read the following relay parameters sheet carefully.
RS485 A/B cable is for the A/B cable of the PTZ decoder.
Relay Specification
Model:
JRC-27F
Material of the
touch
Silver
Rating（Resistance
Load）
Rated switch capacity
30VDC 2A, 125VAC 1A
Maximum switch power
125VA 160W
Maximum switch voltage
250VAC, 220VDC
Maximum switch currency
1A
Insulation
Between touches with same
polarity
1000VAC 1minute

14
Between touches with different
polarity
1000VAC 1minute
Between touch and winding
1000VAC 1minute
Surge voltage
Between touches with same
polarity
1500V (10×160us)
Length of open
time
3ms max
Length of close
time
3ms max
Longevity
Mechanical
50×106 times (3Hz)
Electrical
200×103 times (0.5Hz)
Temperature
-40℃~+70℃

15
2Overview of Navigation and Controls
2.1 Boot up
Before operation, please make sure:
You have properly installed HDD and all the cable connections.
The provided input power and the device power are matched.
Always use the stable current, if necessary UPS is a best alternative measure.
Please follow the steps listed below to boot up the device.
Connect the device to the monitor and then connect a mouse.
Connect power cable.
Click the power button at the front or rear panel and then boot up the device. After device
booted up, the system is in multiple-channel display mode by default.
2.2 Login
After system booted up, system pops up the startup wizard interface. See Figure 2-1.
Please refer to the user’s manual for detailed startup wizard operation information.
Tips
Check the box Startup button here, system goes to startup wizard again when it boots up the
next time.
Cancel the Startup button, system goes to the login interface directly when it boots up the next
time.
Figure 2-1
The system login interface is shown as in Figure 2-2.
System consists of four accounts:
