Dahua Network Camera Web 3.0 User manual

Dahua Network Camera Web 3.0 Operation Manual
i
Dahua Network Camera Web3.0 Operation Manual
Version 2.0.0
Zhejiang Dahua Vision Technology CO., LTD

Dahua Network Camera Web 3.0 Operation Manual
ii
Table of Contents
1Product Overview........................................................................................................................1
2Initial Config.................................................................................................................................2
2.1 Device Initialization.......................................................................................................2
2.2 Login and Logout..........................................................................................................4
2.2.1 Log in WEB Interface...............................................................................................4
2.2.2 Logout.......................................................................................................................6
2.3 Reset Password............................................................................................................6
3Live................................................................................................................................................9
3.1 Preview Interface Introduction ....................................................................................9
3.2 Video Window Function Option................................................................................10
3.3 Video Window Setup..................................................................................................12
3.3.1 Image Adjustment...................................................................................................12
3.3.2 Window Display Mode...........................................................................................13
3.3.3 Fluency Adjustment................................................................................................13
3.3.4 Rules Info ...............................................................................................................13
3.3.5 Zoom and Focus .....................................................................................................13
3.3.6 Face Recognition/Comparison ...............................................................................15
4Playback.....................................................................................................................................17
4.1 Playback.......................................................................................................................17
4.1.1 Function of Play......................................................................................................18
4.1.2 Playback File ..........................................................................................................19
4.1.3 Playback Cut...........................................................................................................21
4.1.4 Record Type ...........................................................................................................21
4.1.5 Progress Bar............................................................................................................21
4.1.6 Assistant Function ..................................................................................................22
4.2 Picture Playback .........................................................................................................22
4.2.1 Play.........................................................................................................................23
4.2.2 Playback File ..........................................................................................................23
4.2.3 Snapshot Type ........................................................................................................25
5Setting.........................................................................................................................................27
5.1 Camera.........................................................................................................................27
5.1.1 Conditions...............................................................................................................27
5.1.2 Video ......................................................................................................................37
5.1.3 Audio ......................................................................................................................50
5.2 Network.........................................................................................................................51
5.2.1 TCP/IP ....................................................................................................................51
5.2.2 Connection..............................................................................................................54

Dahua Network Camera Web 3.0 Operation Manual
iii
5.2.3 PPPoE.....................................................................................................................56
5.2.4 DDNS .....................................................................................................................57
5.2.5 IP filter....................................................................................................................59
5.2.6 SMTP （e-mail).....................................................................................................59
5.2.7 UPnP.......................................................................................................................61
5.2.8 SNMP .....................................................................................................................62
5.2.9 Bonjour...................................................................................................................64
5.2.10 Multicast.................................................................................................................65
5.2.11 802.1x .....................................................................................................................66
5.2.12 QoS.........................................................................................................................66
5.2.13 HTTPs.....................................................................................................................67
5.3 Event.............................................................................................................................77
5.3.1 Video detection.......................................................................................................77
5.3.2 Audio Detection......................................................................................................84
5.3.3 Smart Plan...............................................................................................................86
5.3.4 Intelligence Behavior Analytics .............................................................................86
5.3.5 Face Recognition....................................................................................................94
5.3.6 People Counting ...................................................................................................104
5.3.7 Heat Map ..............................................................................................................106
5.3.8 Alarm....................................................................................................................109
5.3.9 Abnormity.............................................................................................................112
5.4 Storage Management...............................................................................................115
5.4.1 Schedule................................................................................................................115
5.4.2 Destination............................................................................................................119
5.4.3 Record control ......................................................................................................122
5.5 System........................................................................................................................122
5.5.1 General..................................................................................................................122
5.5.2 Account.................................................................................................................124
5.5.3 Default ..................................................................................................................129
5.5.4 Import/Export .......................................................................................................129
5.5.6 Remote control ........................................................................................................130
5.5.5 Auto Maintenance.................................................................................................130
5.5.6 Upgrade ................................................................................................................131
5.6 Information.................................................................................................................131
5.6.1 Version..................................................................................................................131
5.6.2 Log........................................................................................................................132
5.6.3 Online User...........................................................................................................132
6Alarm.........................................................................................................................................134
7Log out......................................................................................................................................136

Dahua Network Camera Web 3.0 Operation Manual
iv
Important
The following functions are for reference only. Some series products may not support all the functions
listed below.
Cybersecurity Recommendations
1. Change Passwords and Use Strong Passwords
The number one reason systems get “hacked” is due to having weak or default passwords. It is
recommended to change default passwords immediately and choose a strong password whenever
possible. A strong password should be made up of at least 8 characters and a combination of special
characters, numbers, and upper and lower case letters.
2. Update Firmware
As is standard procedure in the tech-industry, we recommend keeping NVR, DVR, and IP camera
firmware up-to-date to ensure the system is current with the latest security patches and fixes.
“Nice to have” recommendations to improve your network security
1. Change Passwords Regularly
Regularly change the credentials to your devices to help ensure that only authorized users are able to
access the system.
2. Change Default HTTP and TCP Ports:
● Change default HTTP and TCP ports for systems. These are the two ports used to communicate and
to view video feeds remotely.
● These ports can be changed to any set of numbers between 1025-65535. Avoiding the default ports
reduces the risk of outsiders being able to guess which ports you are using.
3. Enable HTTPS/SSL:
Set up an SSL Certificate to enable HTTPS. This will encrypt all communication between your devices
and recorder.
4. Enable IP Filter:
Enabling your IP filter will prevent everyone, except those with specified IP addresses, from accessing
the system.
5. Change ONVIF Password:

Dahua Network Camera Web 3.0 Operation Manual
v
On older IP Camera firmware, the ONVIF password does not change when you change the system’s
credentials. You will need to either update the camera’s firmware to the latest revision or manually
change the ONVIF password.
6. Forward Only Ports You Need:
● Only forward the HTTP and TCP ports that you need to use. Do not forward a huge range of numbers
to the device. Do not DMZ the device's IP address.
● You do not need to forward any ports for individual cameras if they are all connected to a recorder on
site; just the NVR is needed.
7. Disable Auto-Login on SmartPSS:
Those using SmartPSS to view their system and on a computer that is used by multiple people should
disable auto-login. This adds a layer of security to prevent users without the appropriate credentials
from accessing the system.
8. Use a Different Username and Password for SmartPSS:
In the event that your social media, bank, email, etc. account is compromised, you would not want
someone collecting those passwords and trying them out on your video surveillance system. Using a
different username and password for your security system will make it more difficult for someone to
guess their way into your system.
9. Limit Features of Guest Accounts:
If your system is set up for multiple users, ensure that each user only has rights to features and
functions they need to use to perform their job.
10. UPnP:
● UPnP will automatically try to forward ports in your router or modem. Normally this would be a good
thing. However, if your system automatically forwards the ports and you leave the credentials defaulted,
you may end up with unwanted visitors.
● If you manually forwarded the HTTP and TCP ports in your router/modem, this feature should be
turned off regardless. Disabling UPnP is recommended when the function is not used in real
applications.
11. SNMP:
Disable SNMP if you are not using it. If you are using SNMP, you should do so only temporarily, for
tracing and testing purposes only.

Dahua Network Camera Web 3.0 Operation Manual
vi
12. Multicast:
Multicast is used to share video streams between two recorders. Currently there are no known issues
involving Multicast, but if you are not using this feature, deactivation can enhance your network security.
13. Check the Log:
If you suspect that someone has gained unauthorized access to your system, you can check the system
log. The system log will show you which IP addresses were used to login to your system and what was
accessed.
14. Physically Lock Down the Device:
Ideally, you want to prevent any unauthorized physical access to your system. The best way to achieve
this is to install the recorder in a lockbox, locking server rack, or in a room that is behind a lock and key.
15. Connect IP Cameras to the PoE Ports on the Back of an NVR:
Cameras connected to the PoE ports on the back of an NVR are isolated from the outside world and
cannot be accessed directly.
16. Isolate NVR and IP Camera Network
The network your NVR and IP camera resides on should not be the same network as your public
computer network. This will prevent any visitors or unwanted guests from getting access to the same
network the security system needs in order to function properly.
Electrical safety
All installation and operation should conform to your local electrical safety codes.
The power source shall conform to the requirement of the Safety Extra Low Voltage (SELV)
standard, and supply power with voltage rated by DC 12 V or AC 24 V according to the Limited
power Source requirement of IEC60950-1. Please note that the power supply requirement is
subject to the device label.
Make sure the power supply is correct before operating the device.
A readily accessible disconnect device shall be incorporated in the building installation wiring
Prevent the power cable from being trampled or pressed, especially the plug, power socket and the
junction extruded from the device.
We assume no liability or responsibility for all the fires or electrical shock caused by improper
handling or installation.
Environment

Dahua Network Camera Web 3.0 Operation Manual
vii
Do not aim the device at strong light to focus, such as lamp light and sun light, otherwise it might
cause over brightness or light marks, which are not the device malfunction, and affect the longevity
of Charge Coupled Device (CCD) or Complementary Metal-Oxide Semiconductor (CMOS).
Do not place the device in a damp or dusty environment, extremely hot or cold temperatures, or the
locations with strong electromagnetic radiation or unstable lighting.
Keep the camera away from water or other liquid to avoid damages to the internal components.
Keep the indoor device away from rain or damp to avoid fire or lightning.
Keep sound ventilation to avoid heat accumulation.
Transport, use and store the device within the range of allowed humidity and temperature.
Heavy stress, violent vibration or water splash are not allowed during transportation, storage and
installation.
Pack the device with standard factory packaging or the equivalent material when transporting the
device.
Privacy Protection Notice
As the device user or data controller, you might collect personal data of others' such as face,
fingerprints, car plate number, Email address, phone number, GPS and so on. You need to be in
compliance with the local privacy protection laws and regulations to protect the legitimate rights
and interests of other people by implementing measures include but not limited to: providing clear
and visible identification to inform data subject the existence of surveillance area and providing
related contact.
About the Manual
The Manual is for reference only. If there is inconsistency between the Manual and the actual product, the
actual product shall govern.
We are not liable for any loss caused by the operations that do not comply with the Manual.
The Manual would be updated according to the latest laws and regulations of related regions. For detailed
information, see the paper User's Manual, CD-ROM, QR code or our official website. If there is
inconsistency between paper User's Manual and the electronic version, the electronic version shall prevail.
All the designs and software are subject to change without prior written notice. The product updates might
cause some differences between the actual product and the Manual. Please contact the customer service for
the latest program and supplementary documentation.
There still might be deviation in technical data, functions and operations description, or errors in print. If
there is any doubt or dispute, please refer to our final explanation.
Upgrade the reader software or try other mainstream reader software if the Guide (in PDF format) cannot be
opened.
All trademarks, registered trademarks and the company names in the Manual are the properties of their

Dahua Network Camera Web 3.0 Operation Manual
viii
respective owners.
Please visit our website, contact the supplier or customer service if there is any problem occurred when using
the device.
If there is any uncertainty or controversy, please refer to our final explanation.

Dahua Network Camera Web 3.0 Operation Manual
1
1 Product Overview
The common networking mode for IPC is to connect IPC to PC via switch or router. The common
network mode is shown in Figure 1-1.
Figure 1-1
Before you have access to network camera via the Internet, you need to acquire its IP address. Users
can search IP address of network camera via Quick Config Tool.

Dahua Network Camera Web 3.0 Operation Manual
2
2 Initial Config
In this chapter it is to introduce the device initial config operation, which includes device initialization,
login device, log out WEB interface and password reset.
2.1 Device Initialization
It needs to implement device initialization when you use the device for the first time. Here it is to take
WEB operation as an example to introduce device initialization. You can also initialize device via Quick
Config Tool, NVR and platform etc.
Note
In order to guarantee device safety, please keep admin login password properly after device
initialization, and modify the password regularly.
Step 1
Open IE browser, input camera IP address in the address bar and click Enter.
The system will display the interface of Device Initialization after it is connected successfully, which is
shown in Figure 2-1.
Note
The default IP address is 192.168.1.108.
Figure 2-1
Step 2
It is to set admin login password, please refer to Table 2-1 for more details.

Dahua Network Camera Web 3.0 Operation Manual
3
Parameter
Note
User name
The default user name is admin
Password
The password ranges from 8 to 32 digitals. It can contain letters, numbers
and special characters (excluding “'”,“"”,“;”,“:”,“&”) . The password shall
contain at least two categories. Usually we recommend the strong
password.
Confirm
password
Email
Input an email address for reset password purpose. In case you forgot
password in the future, input the security code you got on the assigned
email to reset the password of admin.
Table 2-1
Step 3
Click Save.
The system will display the interface of End-User License Agreement, which is shown in Figure 2-2.
Figure 2-2
Step 4
Select I have read and agree to all terms and click Next.
The system will display the interface of Easy4iP, which is shown in Figure 2-3.

Dahua Network Camera Web 3.0 Operation Manual
4
Figure 2-3
Step 5
Click Save and device initialization is completed.
2.2 Login and Logout
Here it is to introduce device login and WEB interface logout via browser, it is to take IE Explorer 8 as
an example to make introduction.
2.2.1 Log in WEB Interface
Users can make operations such as live, playback and config upon the device after logging in device
WEB interface via browser.
Note
It can log in WEB interface after device initialization is completed.
It will prompt to install plug-in when logging in the system for the first time, please download and
install plug-in according to prompt.
Step 1
Open IE browser, input camera IP address in the address bar and click Enter button.
The system will display the Login interface after it is successfully connected, which is shown in Figure
2-4.

Dahua Network Camera Web 3.0 Operation Manual
5
Figure 2-4
Step 2
Input the password of admin user.
Step 3
Click Login.
It will display the Live interface after it logged in successfully, which is shown in Figure 2-5.
Note
Different devices have different functions with different interface display; please refer to the actual
interface for more details.

Dahua Network Camera Web 3.0 Operation Manual
6
Figure 2-5
2.2.2 Logout
Click Logout and return to WEB login interface. After logging in the device WEB, the system will
hibernate automatically if it fails to operate the device for a period of time. It can recover to normal
working status quickly after entering password.
2.3 Reset Password
Users can reset password via reserved email when you forget the password of admin user.
Step 1
Open IE browser, input camera IP address in the address bar and click Enter button.
The system will display the Login interface after it is successfully connected, which is shown in Figure
2-6.

Dahua Network Camera Web 3.0 Operation Manual
7
Figure 2-6
Step 2
Click Forgot password?
The system will display the interface of Reset Password, which is shown in Figure 2-7.
Figure 2-7
Step 3
Reset login password.
Scan the QR code according to the interface prompt and acquire security code, then input the security
code which is received via your reserved email.
Caution

Dahua Network Camera Web 3.0 Operation Manual
8
Please use the security code to reset the password within 24 hours after you received the security
code via your reserved email. Otherwise the security code will be invalid.
If you fail to use security code for twice continuously, then the system will prompt that it fails to
acquire security code for the third time. It needs hardware to restore device default setting or wait
for 24 hours and acquire it again if it needs to use the device normally.
Step 4
Click next.
The system will display the interface where you can set the new password, which is shown in Figure 2-8.
Figure 2-8
Step 5
Reset Password and Confirm Password.
The password ranges from 8 to 32 digitals. It can contain letters, numbers and special characters
(excluding “'”,“"”,“;”,“:”,“&”) . The password shall contain at least two categories. Usually we recommend
the strong password.
Step 6
Click Save and complete password reset.
The system will display the Login interface.

Dahua Network Camera Web 3.0 Operation Manual
9
3 Live
3.1 Preview Interface Introduction
After you logged in, you can see the live monitor window. See Figure 3-1.
Figure 3-1
The preview interface of WEB client includes four function columns; please refer to Table 3-1 for more
details.
SN
Function
Note
1
System menu
Click the icon on the system menu to enter corresponding
function interface.

Dahua Network Camera Web 3.0 Operation Manual
10
SN
Function
Note
2
Encode setting
It includes following four items:
Main stream: stream value is much bigger, image definition is
higher, but it takes bigger bandwidth, which is applied to
storage and surveillance.
Sub stream 1: stream value is comparatively smaller than main
stream, the image is fluent and it takes small bandwidth, which
is applied to the surveillance instead of main stream when
network bandwidth is not enough.
Sub stream 2: stream value is comparatively smaller than main
stream, the image is fluent and it takes small bandwidth, which
is applied to the surveillance instead of main stream when
network bandwidth is not enough.
Protocol: network transmission protocol type, it supports TCP,
UDP and multicast.
3
Video window
function option
Video window function and operation.
4
Video window
adjustment
Video window supports local WEB video image adjustment,
display mode and fluency adjustment etc.
Table 3-1
3.2 Video Window Function Option
It is to introduce the supported functions when checking realtime video, including relay out, digital zoom,
snapshot, triple snapshot, record, easy focus, audio, talk and so on.
The interface is shown as below. See Figure 3-2.
Figure 3-2
Please refer to Table 3-2 for detailed information.
Icon
Parameter
Function
Relay-out
It shows if there is any alarm output, status description is as
follows:
Red: means there is alarm output.
Grey: means alarm is over.
Click on the button to force alarm to be on or off.

Dahua Network Camera Web 3.0 Operation Manual
11
Digital
Zoom
When the video is in the original status, click it you can
select any zone to zoom in. In the non-original status,
you can drag the zoom-in zone in specified range. Right
click mouse to restore previous status.
Click it; you can use the middle button of the mouse to
zoom in/out the video size.
Snapshot
Click on the button to take snapshot, save the picture to the
path which has been set.
Note
Please refer to 5.4.2.1 path for checking or setting storage
path.
Triple
Snapshot
Click it to take snapshot upon the video at the frequency of
one picture per second. All images are saved to path which
has been set.
Note
Please refer to 5.4.2.1 path for checking or setting storage
path.
Record
Click it to record the video. All videos are saved to path which
has been set.
Note
Please refer to 5.4.2.1 path for checking or setting storage
path.
Easy focus
Click it, you can see there are two parameters on the preview
video：AF Peak and AF Max.
AF Peak: It is to display the video definition during the focus
process.
AF Max: It is the most suitable value for the video definition.
The closer the AF Peak and AF Max is, the better the focus
effect is.
Note
Easy focus will be disabled automatically after it is enabled for
five minutes.
Audio
Click the icon to enable or disable audio output.
Note
It is only supported by devices with audio function.
Talk
Click it to start or end bidirectional talk.
Note
It is only supported by devices with audio function.
Help
Click it to open help file.
Note
It is only supported by some models.
Table 3-2

Dahua Network Camera Web 3.0 Operation Manual
12
3.3 Video Window Setup
The interface is shown as in Figure 3-3.
Figure 3-3
3.3.1 Image Adjustment
See Figure 3-4 for image adjustment.
Figure 3-4
Click this button to display/hide image control interface. Click it to open picture setup interface. This
interface is on the top right pane.
Please refer to Table 3-3 for detailed information.
Parameter
Function
Video
setup
It is to adjust monitor
video brightness.
Note:
All the operations here apply
to WEB end only.
Please go to Setup-
>Camera->Conditions to
adjust corresponding items.
It is to adjust monitor
video contrastness.
It is to adjust monitor
video hue.
It is to adjust monitor
video saturation.
