• Thank you for purchasing this air purier.
• Please read the operation manual carefully and follow it for correct use.
• Please read the “Safety Precautions” section before use.
• Please keep the operation manual in a safe place for later reference.
• English/Indonesian/Thai/Vietnamese
►
Page 3 ~ 7

FEATURES
1. Controlling PM2.5
2. PM2.5 sensor and air quality indicator
Equipped with PM2.5 sensor enables quick detection of
ultrane particles, easy display and smart operation.
DUST indicator : Large house dust (approx.2.5μm and above)
PM2.5 indicator : Ultrane particles (approx. 2.5μm and smaller)
3. Powerful suction in three directions
Bottom suction is close to oor so it can take in harmful
substances close to the oor.
4. 3-stage ltration system
3-stage ltration system of pre-lter, deodorising lter
and dust collection lter(electrostatic HEPA lter) ensures
thorough and rapid purication.
Elimination of 99% of 0.1-2.5μm particles (*1).
• Does not take into account inow of new particles from outdoors owing to
ventilation etc.
• PM2.5 is a generic term for particulate matter that is 2.5μm or less in size.
• Elimination of particulate matter that is less than 0.1μm in size by this air purier
has not been veried.
This product cannot eliminate all airborne toxic substances.
(*1) Test methodology: The Japan Electrical Manufacturers’Association standard
(JEM1467)
Decision criteria: Elimination of 99% of 0.1-2.5μm particulate matter in a 32m³
airtight space in 90 minutes or less. Equivalent value for 32m³ test space.
These results were obtained in a 32m³ airtight space. They are not
demonstrable eects in customer environments.

2
1
DAIKIN
CONTENTS
 PLEASE STORE THE USER MANUAL WHERE IT CAN BE EASILY RETRIEVED OR FOUND. 
FEATURES / CONTENTS
FOR INFORMATION HOWTO USE
OTHERS
MAINTENANCE
| 03 | SAFETY PRECAUTIONS
| 07 | PRECAUTIONS DURING USE
| 08 | NAMES OF PARTS
| 09 | AIR PURIFICATION PROCESS
| 10 | PREPARATION BEFORE
OPERATION
| 12 | OPERATING/
INDICATOR PANEL
| 13 | OPERATION
| 15 | SETTING DUST/PM2.5
SENSOR SENSITIVITY
| 19 | TROUBLESHOOTING
| 20 | SPECIFICATIONS
| 16 | CLEANING METHOD
| 18 | REPLACINGTHE FILTERS

■ Concerning the power supply plug and cord
• Do not unplug while the unit is in operation. (Fire or an electric shock may
result from heating)
• Do not plug or unplug with wet hands. (An electric shock may result)
• Do not use in such a way that the ratings of the power socket or wiring
appliances are exceeded or use a voltage outside of the range AC220-240V.
(Fire may result from heating if the ratings of multi-socket power adapters, etc.,
are exceeded)
• Do not pull on the power supply cord when unplugging. (Heating or fire may
result from wire breakage)
• Do not subject to acts that might damage them.
- Such acts include damaging, modifying, forcibly bending, pulling, twisting,
bundling up, placing heavy objects on, etc., the power supply plug or cord.
If the power supply plug or cord is damaged, it must be replaced by the
manufacturer, its service agent, or a similar qualified person in order to avoid a
hazard. (An electric shock, short circuiting, or fire may result from use while
damaged)
SAFETY PRECAUTIONS
■
Observe these precautions in order to prevent property damage or injury.
■ The consequences of incorrect use are categorised as follows.
■ Precautions to be observed are categorised using symbols.
WARNING CAUTION
Failure to follow these instructions properly may
result in personal injury or loss of life.
Failure to follow these instructions properly may
result in property damage or personal injury, which
may be serious depending on the circumstances.
Never attempt. Be sure to follow the instructions.
WARNING : Observe in order to prevent res, electric shocks or
severe injury.

• Insert the power supply plug firmly all the way in.
- Do not use a damaged power supply plug or a loosely fitted power socket.
(An electric shock or fire, due to heating or short circuiting, may result if the
power supply plug is not firmly inserted)
• Periodically wipe dust off the power supply plug with a dry cloth.
- If the unit is not to be used for an extended period of time, unplug the
power supply plug.
(Fire or overheating may be caused by defective insulation resulting from
moisture etc.)
• When performing maintenance, inspecting, moving the unit, make sure to
turn off and unplug the appliance. (An electric shock or injury could result)
■ Do not use in the following places
• Places where oil or flammable gases are used or may leak.
(Fire or smoke may result from ignition or suction toward the unit, or injury may
result from degradation or cracking of plastic)
• Places where there is corrosive gas or metal dust particles.
(Fire or smoke may result from ignition or suction toward the unit)
• Places where temperature and humidity levels are high or water may scatter,
such as a bathroom. (Fire or an electric shock may result from electrical leakage)
• Places accessible to small children. (An electric shock or injury may result)
• Places where the oor is unstable.
(Fire or an electric shock may result if the unit topples over)
■ During Use
• Do not use chlorinated or acidic detergents. (Injury may result from the
degradation or cracking of plastic, or harm may be caused to health from
the production of toxic gases)
• Keep burning cigarettes or incense sticks away from the unit.
(Fire or smoke may result from ignition or suction toward the unit)
• Do not attempt to disassemble, reconstruct or repair the unit yourself. (Fire,
an
electric shock, or injury may result) For repairs, please contact the authorized
distributor or retailer.
4
3
SAFETY PRECAUTIONS
For Information

■ During Use
• Do not insert ngers, sticks, or any other item, into the air inlets or air outlet.
(An electric shock, injury, or damage may result)
• Do not pour water on to the air outlet or the unit.
(Fire or an electric shock may result)
• Do not use flammable substances (hair spray, insecticide, etc.) near the unit.
• Do not wipe the unit with benzine or thinner.
(An electric shock, fire, or cracking may result)
■
Immediately turn o and unplug the unit if there are any signs of abnormality
or damage. Examples of abnormality or damage.
• The unit does not operate even if the switch is turned on.
• Current passes through the cord only sometimes if the cord is moved.
• There are abnormal sounds or vibrations during operation.
• The casing of the unit has deformed or is abnormally hot.
• There is a burnt smell. (Malfunctioning, an electric shock, smoke, fire,
etc., may result if the abnormality is not addressed and the unit
continues to be used) Contact the authorized distributor or retailer.
SAFETY PRECAUTIONS
CAUTION : Observe in order to prevent short circuiting,
injury or property damage.
■During use
• Small children or immobile persons (due to illness or injury) should not
operate the unit by themselves. This appliance is not intended for use by
persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
- Children should be supervised to ensure that they do not play with
the appliance.

6
5
SAFETY PRECAUTIONS
For Information
- Cleaning and user maintenance shall not be made by children without
supervison.
- Persons who are heavily intoxicated or have taken sleep medication
should not operate the unit.
(An electric shock, injury or poor health may result)
• Do not use products, such as cosmetics, that contain ne powder, near the
unit. (An electric shock or malfunctioning may result)
• Do not operate the unit when fumigating insecticide is in use.
- After using insecticide, make sure to suciently ventilate the room before
operating the unit.
(Harm may be caused to health from an outow of accumulated chemical
compounds from the outlet)
• Do not use near a smoke detector.
- If out owing air ows in the direction of a smoke detector, the response
of the smoke detector may be delayed or it may fail to detect smoke.
• Frequently ventilate the room when using the unit together with combustion-
based heating devices.
- Usage of this product is not a substitute for ventilation. (Potential cause
of carbon monoxide poisoning) This product cannot eliminate carbon
monoxide.
• If the unit is placed within reach of a pet, be careful that the pet does not
urinate on the unit or chew on the power supply cord. (Fire, an electric
shock, or injury may result)
■Concerning the unit body
• Do not obstruct the air inlets or air outlet with laundry, cloth, curtains, etc.
(Overheating or re may result from poor circulation)
• Do not climb, sit or lean on the unit. (Injury may result from falling or toppling)
• Do not place the unit on its side.

Keep out of
direct sunlight
Do not obstruct air
inlets or air outlet
Do not expose to
direct airow
Keep TVs and radios at
least 2m away
PRECAUTIONS DURING USE
• Positions from where out owing air ows directly at a wall, furniture,
curtains, etc. (Staining or deformation may result)
• Places exposed to direct sunlight
• Places exposed to outdoor air (e.g. near windows, etc.) or direct airow
from air conditioners, etc.
• Positions near combustion-based heating devices or exposed to direct
airow from heating appliances (Deformation may result)
• Places where chemicals and pharmaceuticals are used such as hospitals,
factories, laboratories, beauty salons, and photographic laboratories
(Volatilised chemicals and solvents may degrade mechanical parts)
• Places with high levels of electromagnetic waves such as near an
electromagnetic cooker, speakers, etc.
(The unit may not function correctly.)
• Places exposed to soot (conductive dust) released by candles, aromatic
candles, etc. The performance of the lters may be impaired, causing
the room to become dirty due to the build-up of dust that is not
captured.
• Do not use cosmetics etc., containing silicone*near the unit.
*Hair care products (split ends coating agents, hair mousse, hair
treatment agents etc.), cosmetics, antiperspirants, antistatic agents,
waterproof sprays, lustering agents, glass cleaners, chemical wiping
cloths, wax, etc.
- If an insulator such as silicone adheres to the needle of the streamer
unit, the streamer discharge may not be generated.
- The dust collection lter may become clogged up resulting in reduced
air purifying capacity.
• Do not use an ultrasonic
humidier or similar appliance
near the unit.
The dust collection lter may
become clogged up resulting in
reduced air purifying capacity.
■Do not use in the following places

8
7
PRECAUTIONS DURING USE / NAMES OF PARTS
For Information
NAMES OF PARTS
Front view/Rear view
Accessories
Operation manual
Model
MC30VVM-A
MC30VVM-H
OPERATION MANUAL
AirPurier
• Thank you for purchasing this air purier.
• Please read the operation manual carefully and follow it for correct use.
• Please read the “Safety Precautions” section before use.
Please keep the operation manual in a safe place for later reference.
Air Purier
►
Page 3, 4
Air inlets
(Right/left sides,
bottom)
Power cord
Grip
Operating/
Indicator panel
Air outlet
Dust/
PM2.5
sensor

AIR PURIFICATION PROCESS
■ Pre-lter
It removes relatively large dust and mold, human hair, pet hair, and so on.
■ Deodorising lter
Features a granular active carbon, which is particularly eective at trapping odors and harmful
gases to keep your home smelling fresh.
■ Dust collection lter (electrostatic HEPA lter)
The high-performance HEPA lter eectively removes ne dust and cigarette smoke up to
99.97%* down to 0.3 microns in size. It reduces airborne bacteria, mold spores and particles that
carry viruses.
∗ Removal eciency of HEPA lter (tested individually). The eciency of air purier is dierent.
2. Deodorising filter 3. Dust collection filter
(Electrostatic HEPA filter)
1. Pre-filter
▶ ▶
This product cannot eliminate the toxic substances in tobacco smoke (carbon monoxide etc.)

10
9
AIR PURIFICATION PROCESS / PREPARATION BEFORE OPERATION
For Information
PREPARATION BEFORE OPERATION
Please check before use
This product is for 220V~240V, 50Hz or 60Hz only.
Make sure to connect the power plug to a grounded electric outlet
(220V~240V, 50Hz or 60Hz) dedicated to the product.
- Always remove lter wrapping before installation.
- The unit is for residential use and thus for indoor only.
- Remove power plug from the socket when not in use.
- Check front part of the lter when installing unit.
How to install lter
Tips
1. Open the front cover by pulling
the lower part of it.
2. Take out the lter by pressing down on the top clip of the pre-lter, and remove its packing sheet.
3. Install lters according to the following
order. Dust collection lter (electrostatic
HEPA lter) Deodorising lter Pre lter
(Check the insert direction of lters and
make the hooks xed into the unit.).
4. Fit the front cover back to the product.
▶
▶
▶

Pointers for good positioning
Positioning the unit
At least 100cm
away from ceiling
At least 30cm
away from wall
Air ow
At least 10cm
away from wall
At least 30cm
away from wall
• Choose a position from where airow can reach all areas
of the room.
• Place on a stable surface. If the unit is placed on an
unstable surface, vibrations from the unit may be
amplied.
• If you nd that interference from the power circuit
inside the unit or cables causes interference on your TV
screen or static noise to be emitted from nearby radios
or stereos, move the unit to at least 2m away from the
device. Keep cordless phones and radio-controlled
clocks away from the unit also.
- To avoid staining of walls, position the unit in accordance with the positioning measurements in
the illustration. However, note that since this unit draws in dirty air, certain types of wall may be
stained even if the measurements are adhered to.
In such cases, make sure to maintain sucient distance between the unit and the wall.
- When used for a long period of time in the same location, the oor and surrounding walls may get
stained as air is drawn into air inlets near the base of the unit. It is recommended to clean the unit
periodically.
TIPS
PREPARATION BEFORE OPERATION

12
11
PREPARATION BEFORE OPERATION / OPERATING/INDICATOR PANEL
How to Use
Indicators Buttons
OPERATING/INDICATOR PANEL
4
MODE lamps [green]
5
FAN lamp [green]
6
Dust/PM2.5 sensor lamp
3
ON/OFF lamp [green]
1
ON/OFF Button
2
FAN/MODE Button
1ON/OFF button
Press to turn the power ON or OFF.
3ON/OFF lamp [green]
Lamp will light up when the power
is ON.
5FAN lamp [green]
Indicates the active FAN setting
(4 settings: Quiet, Low, Standard,Turbo).
▶ About the FAN symbols
2FAN/MODE button
Press to cycle between FAN
settings and MODEs.
4MODE lamps [green]
Indicates the MODE in operation.
6Dust/PM2.5 sensor lamp
Indicates the volume of ambient dust in 3 colours:
green, orange, red.
∗Green indicates that the air is clean.
∗The dust/PM2.5 sensor lamp can detect small (approx.1.0-
2.5μm) and large (approx. 2.5μm and above) dust particles.
The“PM2.5”lamp lights in response to small particles and the
DUST lamp lights in response to large dust particles.
Symbol
Setting Quiet
* * *
Low Standard Turbo
FAN
Green Orange Red
Few Many
Lamp colour
Dust
About the dust/PM2.5 sensor lamp
-After operation is started, the lamp will light green for the rst minute (approx.) regardless of air impurity level.
-If the responsiveness of the dust/PM2.5 sensor is poor, change the sensitivity setting of the sensor. ►Page14
- The responsiveness of the dust/PM2.5 sensor may be poor during FAN setting “Turbo” or when airow is high in
AUTO FAN MODE. The strong airow causes dust to be drawn into the air inlets before it can be detected by the
dust/PM2.5 sensor. This is normal (not a malfunction).
Dust/PM2.5 sensor detection range
-Detectable matter : house dust, tobacco smoke, pollen, mites, pet hairs,diesel particulate matter
-Sometimes detectable : steam, oil smoke
TIPS
∗ The size of the symbols varies in accordance with
the airow rate setting.

■Turning operation ON/OFF
Press ON/OFF button to turn ON.
- ON/OFF lamp lights up.
- Press again to turn OFF.
∗ At the time of purchase, the unit is set to AUTO FAN MODE.
∗ When the unit is unplugged or turned OFF, it will operate with the settings
last used the next time it is turned ON.
∗Operation settings cannot be changed for about 2 seconds immediately
after the power supply plug is inserted.
■Changing the Air ow Rate and Mode
Press FAN/MODE button to select the desired FAN setting.
- Each press cycles between the FAN lamps and MODE lamps.
About FAN settings
OPERATION
FAN
(Quiet) (Low) (Standard) (Turbo)
MODE
ECONO
POLLEN AUTO
Quiet
A gentle breeze is emitted. Recommended for use during sleep hours.
To quickly eliminate odour from a room, it is recommended that the FAN setting be
set to Standard or above otherwise deodorising capacity is reduced.
Turbo The ambient air is quickly purified using a large airflow. Recommended for use while
you are cleaning up a room.

14
13
OPERATION
■Mode : Usage and Function
AUTO
Automatic airflow rate adjustment
FAN setting (Quiet, Low, Standard, High, Turbo) is automatically adjusted
according to the degree of air impurity.
Purifying capacity increases as airflow rate rises.
ECONO
Saving energy
In Power saving mode within ECONO MODE, the FAN setting automatically
switches between Quiet, Low and Standard only. Power consumption and
operating sounds are minimized.
Recommended for use during sleep hours.
- As the FAN setting is limited to Quiet, Low and Standard, air purifying capacity
is reduced.
- FAN setting is adjusted automatically. Airow cannot be adjusted manually.
POLLEN
Reducing pollen levels
A gentle air current is created by switching every 5 minutes between the FAN
setting Standard and Low so that pollen can be drawn in and caught before it
reaches the floor.
- FAN setting is adjusted automatically. Airow cannot be adjusted manually.
How to Use

1. Hold down FAN/MODE button and ON/OFF
button for about 3 seconds.
2. Release both buttons when a short beep sounds.
One of the FAN lamps(Low,Standard,Turbo) will blink for about 5 seconds and then the lamp
corresponding to the currently set sensitivity will light up.
3. Press FAN/MODE button to change the sensitivity setting.
Each press cycles between the FAN lamps allowing you to change the sensitivity.
Setting is indicated using the FAN lamps. If the FAN lamps do not change, unplug the unit, wait
at least 5 seconds, then reinsert the power supply plug and repeat the above procedure from the
beginning.
4. After selecting the new setting, hold down FAN/MODE button and ON/
OFF button for 3 seconds. The unit will return to regular operation.
∗ The new setting will also be applied if no button is input for 10 seconds.
∗ Settings are remembered even if the unit is unplugged.
SETTING DUST / PM2.5 SENSOR SENSITIVITY
The sensor is
highly receptive.
Setting at time
of purchase
The sensor is
slightly receptive.
(Standard)
(Turbo)
(Low)
High
Normal
Low
To set sensitivity High
Select the FAN lamp Turbo.
To set sensitivity Low
Select the FAN lamp Low.
When the product is shipped out, the air quality sensor is set to normal sensitivity. If the
sensitivity of the dust/PM2.5 sensor does not meet your preferences, you can adjust the
sensitivity of sensor as follows.
TIPS
In order to start setting sensor sensitivity, the air purier should be turned on.
Press ON/OFF button to turn ON.

16
15
SETTING DUST / PM2.5 SENSOR SENSITIVITY / CLEANING METHOD
Maintenance
CLEANING METHOD
■Cleaning the Dust / PM2.5 sensor
(Every 2 months)
1. Open the air quality sensor cover on the right
hand side of the product. Clean the air inlet and
outlet vent and then the air quality sensor with
a soft brush or vacuum cleaner.
2. Wet a cotton swab lightly and clean the lens, dust inlet, and dust outlet.
Clean them with a dry cotton swab to remove remaining moisture.
∗ Without regular cleaning, the performance of the pollution sensor
deteriorates.
∗The cleaning cycle diers depending on the operation environment. When
using the product in a dusty environment, clean the sensor more often.
▶Avoid touching the lens(internal part) of Dust/PM2.5 sensor with
ngers or other things. It may aects the sensing performance.
■ Cleaning the air inlet and outlet (When dirt becomes an issue)
Clean the air inlet and outlet with a soft brush.
∗ Exercise caution not to have dust fall inside the air purier.
∗ If covered in dust, run the air purier in manual mode for 10 minutes to
blow the dust o the vent. You may then continue with normal use.
■Cleaning the front cover (When dirt becomes an issue)
Separate the front cover from the product and remove the dust attached to
the surface with a soft dry brush or cloth.
∗Use lightly wet cloth if the contamination is serious but do not use abrasives.
■ Cleaning the product body (When dirt becomes an issue)
Use a soft dry cloth to clean the product body.
∗Use a damp cloth if the contamination is serious, however, do not use abrasives.
TIPS
- Always unplug the unit before cleaning it.
- Do not use detergent that contains organic solvents (solvent, thinner, etc), bleach,
chlorine, or abrasives.
- Do not put the unit into water or spray water on it.
▶
Air outlet
Air inlet
Dust outlet
Dust inlet

CLEANING METHOD
■Cleaning the Pre-Filter (Every 2 – 4 weeks)
1. Open the front cover by pulling the
lower part of it.
2. Press down on the top clip of the pre-lter and pull it out.
∗To prevent dust from falling o, remove the lter carefully without exerting
a shock.
3. Clean the pre-lter with a vacuum cleaner or with water depending on
the level of contamination.
∗ Remove the deodorization lter before cleaning the Pre-lter.
4. Install the pre-lter after removing the moisture completely. Fit the front cover back to the product.
TIPS
- Always unplug the product before cleaning the lter.
- The pre-lter is reusable by removing dust or cleaning it with water.
- If the pre-lter is not cleaned for a long time, the product performance may deteriorate.
- Deodorising lter and dust collecting lter cannot be cleaned and reused. Never clean them with water.
▶
∗When retting the pre-lter to the
product, t it in the hook correctly
∗Press the center of both sides of
pre-lter until you hear a click.
∗When installing the front cover to
the product, hook the top left and
right corners correctly rst, and then
press the bottom.

18
17
CLEANING METHOD / REPLACING THE FILTERS
Maintenance
■How to replace the lters
■Filter cleaning and replacement times
Filter Cycles Method
Pre-lter Every 2 – 4 weeks Cleaning
Deodorization lter *Every 3 months Replacement
Dust collection lter *
(Electrostatic HEPA lter) Every 2 years Replacement
∗Calculation based on testing method of the Japan Electrical Manufacturers' Association standard (JEM 1467).
The recommended lter replacement cycles may dier depending on the operating environment.
■Replacement Filter (Available for purchase)
- Check that the‘front’sides of lters are in the correct direction.
- To maintain optimal performance of the product, use original replacement lters.
- Always unplug the air cleaner before replacing lters.
REPLACING THE FILTERS
Dust collection lter (Electrostatic HEPA lter) (1 piece)
Model: BAFP001AE
Deodorising lter (4 pieces)
Model: BADP001AE
· Replace about every 2 years · Replace about every 3 months.
(1 set of 4 pieces is for 1 year.)

TROUBLESHOOTING
■Before making an inquiry or a request for repair, please check the following.
If the problem persists, contact the authorized distributor or retailer.
■In the event of malfunction during operation
If the indicator lamps light up abnormally, or become inoperable, due to a lightning strike etc., re-
move the power supply plug, wait at least 5 seconds then reinsert the power supply plug and turn
the unit on again.
Symptom Check Countermeasures
No air is blowing.
• Is the power cord connected? Connect the power cord to an electric
outlet for 220~240 V, 50/60 Hz .
• Is the display part all turned o? Press the ON/OFF button and then
select the desired function. ▶page 13
• Isn’t the power gone out? Use the air purier after the power is on again.
• Is the front cover installed to the product
correctly? Install the front cover correctly. ▶page 17
• Is the air outlet or an air inlet blocked?
Remove the obstructing things and check the
right position of the unit. ▶Page 6,9
If they are not blocked, the fan motor is faulty.
Contact the authorized distributor or retailer.
The airow speed
does not change.
• Is the air purier operating in manual
mode? Set the desired operating mode. ▶page 13
The airow speed is
signicantly weaker
than before.
• Isn’t the lter cleaning or replacement
time passed?
Check the lter cleaning and replacement
cycle and then clean or replace the lter(s) if
necessary. ▶page 17-18
Bad odor form outlet. • Isn’t the lter cleaning or replacement
time passed?
Check the lter cleaning and replacement
cycles and then clean or replace the lter(s)
if necessary. ▶page 17-18
The color of the dust/
PM2.5 indicator al-
ways stays the same.
• Isn’t there dust on the dust/PM2.5
sensor’s lens?
Clean the lens of the air quality sensor.
▶page 16
• Does the air quality level keep indicating
a bad level(many dust)
Adjust the sensitivity of the dust/PM2.5 sen-
sor to Low or Normal. ▶page 15
• Does the air quality level keep indicating
a good level(few dust)?
Adjust the sensitivity of the dust/PM2.5 sen-
sor to igh or Normal. ▶page 15.
All lamps blink 2 times This is not a defect but a normal operation when the electric power gets restored after
blackout or any other power failure, except an instantaneous interruption.
The air quality indica-
tor blinks. • Contact the authorized distributor or retailer.
When other
functional problems
are detected.
• Check the symptoms, unplug the product, and then contact Contact the authorized
distributor or retailer.
