Daikin ERLQ-CV3 Instruction manual

Heating
Technical Data
Daikin Altherma low temperature split
EEDEN13-725
ERLQ-CV3

• Heating • Daikin Altherma low temperature split 1
• • Daikin Altherma low temperature split • ERLQ-CV3
TABLE OF CONTENTS
ERLQ-CV3
1Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2 Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Nominal Capacity And Nominal Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3 Capacity tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Heating Capacity Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Cooling Capacity Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Certification Programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4 Dimensional drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Dimensional Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5 Centre of gravity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Centre of Gravity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
6 Piping diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Piping Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
7 Wiring diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Wiring Diagrams - Single Phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
8 Sound data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Sound Power Spectrum Quiet Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Sound Pressure Spectrum - Heating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Sound Pressure Spectrum - Cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
9 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Installation Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
10 Operation range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Operation Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

• Daikin Altherma low temperature split • ERLQ-CV3
1
1
• Heating • Daikin Altherma low temperature split
2
1 Features
HeatingERLQ-CV3DaikinAlth • Perfect fit for new built as well as for low energy houses • Best seasonal efficiencies, providing the highest savings on running
costs

3
1
2
• Heating • Daikin Altherma low temperature split 3
• Daikin Altherma low temperature split • ERLQ-CV3
2 Specifications
Notes
(1) Condition 1: cooling Ta 35ºC - LWE 18ºC (DT = 5ºC); heating Ta DB/WB 7ºC/6ºC - LWC 35ºC (DT = 5ºC)
(2) Condition 2: cooling Ta 35ºC - LWE 7ºC ( DT = 5ºC); heating Ta DB/WB 7ºC/6ºC - LWC 45ºC ( DT = 5ºC )
(3) DB/WB 7ºC/6ºC - LWC 35ºC (DT=5ºC)
(4) DB/WB 7ºC/6ºC - LWC 45ºC (Dt=5ºC)
(5) Condition 3: heating Ta DB -7ºC (RH85%) - LWC 35ºC
(6) Condition 4: heating Ta DB -7ºC (RH85%) - LWC 45ºC
CONNECTABLE INDOOR UNITS
2-1 Nominal Capacity And Nominal Input EHBH04C3V/
ERLQ004CV3 EHBH08C3V/ ERLQ006CV3 EHBH08C9W/ ERLQ006CV3 EHBH08C3V/ ERLQ008CV3 EHBH08C9W/ ERLQ008CV3
Heating capacity Min. kW 1.80 (1) / 1.80 (2)
Nom. kW 4.40 (1) / 4.03 (2) 6.00 (1) / 5.67 (2) 7.40 (1) / 6.89 (2)
Max. kW 5.12 (1) / 4.90 (2) 8.35 (1) / 7.95 (2) 10.02 (1) / 9.35 (2)
Power input Heating Nom. kW 0.87 (1) / 1.13 (2) 1.27 (1) / 1.59 (2) 1.66 (1) / 2.01 (2)
COP 5.04 (1) / 3.58 (2) 4.74 (1) / 3.56 (2) 4.45 (1) / 3.42 (2)
Pump Nominal ESP unit Heating kPa 55 (3) / 59 (4) 48 (3) / 51 (4) 37 (3) / 41 (4)
Water side Heat exchanger Water flow rate Heating Nom. l/min 12.6 (3) / 11.6 (4) 17.2 (3) / 16.3 (4) 21.2 (3) / 19.8 (4)
CONNECTABLE INDOOR UNITS
2-2 Nominal Capacity And Nominal Input EHBH16C3V/
ERLQ011CV3 EHBH16C9W/ ERLQ011CV3 EHBH16C3V/ ERLQ014CV3 EHBH16C9W/ ERLQ014CV3 EHBH16C3V/ ERLQ016CV3 EHBH16C9W/ ERLQ016CV3
Heating capacity Min. kW - -
Nom. kW 11.20 (1) / 10.98 (2) 11.20(1)/10.98(2) 14.50 (1) / 13.60 (2) 16.00 (1) / 15.20 (2)
Max. kW 8.81 (3) / 8.16 (4) 8.81 (3) / 8.16 (4) 11.65 (3) / 10.96 (4) 12.30 (3) / 11.35 (4)
Power input Heating Nom. kW 2.56 (1) / 3.19 (2) 2.56 (1) / 3.19 (2) 3.42 (1) / 4.13 (2) 3.81 (1) / 4.66 (2)
Max. kW 3.52 (3) / 4.14 (4) 3.52 (3) / 4.14 (4) 4.95 (3) / 5.66 (4) 5.49 (3) / 6.43 (4)
COP 4.38 (1) / 2.50 (3) /
3.44 (2) / 1.97 (4) 4.38(1)/ 2.50 (3) / 3.44 (2) / 1.97 (4) 4.24 (1) / 2.35 (3) / 3.29 (2) / 1.94 (4) 4.20 (1) / 2.24 (3) / 3.26 (2) / 1.79 (4)
Pump Nominal ESP unit Heating kPa 86 (1) / 88 (2) 86 (1) / 88 (2) 47 (1) / 59 (2) 26 (1) / 38 (2)
Water side Heat
exchanger Water flow rate Heating Nom. l/min 32.1 (1) / 31.5 (2) 32.1 (1) / 31.5 (2) 41.6 (1) / 39 (2) 45.9 (1) / 43.6 (2)
CONNECTABLE INDOOR UNITS
2-3 Nominal Capacity And Nominal Input EHBX04C3V/
ERLQ004CV3 EHBX08C3V/ ERLQ006CV3 EHBX08C9W/ ERLQ006CV3 EHBX08C3V/ ERLQ008CV3 EHBX08C9W/ ERLQ008CV3
Heating capacity Min. kW 1.80 (1) / 1.80 (2)
Nom. kW 4.40 (1) / 4.03 (2) 6.00 (1) / 5.67 (2) 7.40 (1) / 6.89 (2)
Max. kW 5.12 (1) / 4.90 (2) 8.35 (1) / 7.95 (2) 10.02 (1) / 9.53 (2)
Cooling capacity Min. kW 2.00 (1) / 2.00 (2) 2.50 (1) / 2.50 (2)
Nom. kW 5.00 (1) / 4.17 (2) 6.76 (1) / 4.84 (2) 6.86 (1) / 5.3 (2)
Power input Heating Nom. kW 0.87 (1) / 1.13 (2) 1.27 (1) / 1.59 (2) 1.66 (1) / 2.01 (2)
Max. kW -
Cooling Nom. kW 1.48 (1) / 1.80 (2) 1.96 (1) / 2.07 (2) 2.01 (1) / 2.34 (2)
COP 5.04 (1) / 3.58 (2) 4.74 (1) / 3.56 (2) 4.45 (1) / 3.42 (2)
EER 3.37 (1) / 2.32 (2) 3.45 (1) / 2.34 (2) 3.42 (1) / 2.29 (2)
Pump Nominal ESP unit Cooling kPa 57 (3) / 47 (4) 58 (3) / 42 (4) 54 (3) / 41 (4)
Heating kPa 55 (5) / 59 (6) 48 (5) / 51 (6) 37 (5) / 41 (6)
Water side Heat
exchanger Water flow rate Cooling Nom. l/min 12.0 (3) / 14.3 (4) 13.9 (3) / 19.4 (4) 15.4 (3) / 19.7 (4)
Heating Nom. l/min 12.6 (5) / 11.6 (6) 17.2 (5) / 16.3 (6) 21.2 (5) / 19.8 (6)

• Daikin Altherma low temperature split • ERLQ-CV3
1
2
• Heating • Daikin Altherma low temperature split
4
2 Specifications
Notes
(1) Condition 1: cooling Ta 35ºC - LWE 18ºC (DT = 5ºC); heating Ta DB/WB 7ºC/6ºC - LWC 35ºC (DT = 5ºC)
(2) Condition 2: cooling Ta 35ºC - LWE 7ºC ( DT = 5ºC); heating Ta DB/WB 7ºC/6ºC - LWC 45ºC ( DT = 5ºC )
(3) Tamb 35ºC - LWE 7ºC (DT=5ºC)
(4) Tamb 35ºC - LWE 18ºC (DT=5ºC)
(5) DB/WB 7ºC/6ºC - LWC 35ºC (DT=5ºC)
(6) DB/WB 7ºC/6ºC - LWC 45ºC (Dt=5ºC)
(7) Condition 3: heating Ta DB -7ºC (RH85%) - LWC 35ºC
(8) Condition 4: heating Ta DB -7ºC (RH85%) - LWC 45ºC
CONNECTABLE INDOOR UNITS
2-4 Nominal Capacity And Nominal Input EHBX16C9W/
ERLQ011CV3 EHBX16C3V/ ERLQ011CV3 EHBX16C3V/ ERLQ014CV3 EHBX16C9W/ ERLQ014CV3 EHBX16C3V/ ERLQ016CV3 EHBX16C9W/ ERLQ016CV3
Heating capacity Min. kW - -
Nom. kW 11.20 (1) / 10.98 (2) 11.20 (1)/ 10.98 (2) 14.50 (1) / 13.60 (2) 16.00 (1) / 15.20 (2)
Max. kW 8.81 (3) / 8.16 (4) 8.81 (3) / 8.16 (4) 11.65 (3) / 10.96 (4) 12.30 (3) / 11.35 (4)
Cooling capacity Min. kW - -
Nom. kW 15.05 (1) / 11.72 (2) 15.05 (1)/ 11.72 (2) 16.06 (1) / 12.55 (2) 16.76 (1) / 13.12 (2)
Power input Heating Nom. kW 2.56 (1) / 3.19 (2) 2.56 (1) / 3.19 (2) 3.42 (1) / 4.13 (2) 3.81 (1) / 4.66 (2)
Max. kW 3.52 (3) / 4.14 (4) 3.52 (3) / 4.14 (4) 4.95 (3) / 5.66 (4) 5.49 (3) / 6.34 (4)
Cooling Nom. kW 4.53 (1) / 4.31 (2) 4.53 (1) / 4.31 (2) 5.43 (1) / 5.08 (2) 5.16 (1) / 5.73 (2)
COP 4.38 (1) / 2.50 (3) /
3.44 (2) / 1.97 (4) 4.38 (1) / 2.50 (3) / 3.44 (2) / 1.97 (4) 4.24 (1) / 2.35 (3) / 3.29 (2) / 1.94 (4) 4.20(1)/ 2.24 (3)/3.26(2)/ 1.79 (4)
EER 3.32 (1) / 2.72 (2) 3.32 (1) / 2.72 (2) 2.96 (1) / 2.47 (2) 2.72 (1) / 2.29 (2)
Pump NominalESP unit Cooling kPa 80 (2) / 40 (1) 80 (2) / 40 (1) 71 (2) / 26 (1) 65 (2) / 16 (1)
Heating kPa 86 (1) / 88 (2) 86 (1) / 88 (2) 47 (1) / 59 (2) 26 (1) / 38 (2)
Water side Heat
exchanger Water flow rate Cooling Nom. l/min 33.6 (2) / 43.1 (1) 33.6 (2) / 43.1 (1) 36.0 (2) / 46.0 (1) 37.6 (2) / 48.0 (1)
Heating Nom. l/min 32.1 (1) / 31.5 (2) 32.1 (1) / 31.5 (2) 41.6 (1) / 39.0 (2) 45.9 (1) / 43.6 (2)
CONNECTABLE INDOOR UNITS
2-5 Nominal Capacity And Nominal Input EHVH04S18C3V/
ERLQ004CV3 EHVH08S18C3V/ ERLQ006CV3 EHVH08S26C9W/ ERLQ006CV3 EHVH08S18C3V/ ERLQ008CV3 EHVH08S26C9W/ ERLQ008CV3
Heating capacity Min. kW 1.80 (1) / 1.80 (2)
Nom. kW 4.40 (1) / 4.03 (2) 6.00 (1) / 5.67 (2) 7.40 (1) / 6.89 (2)
Max. kW 5.12 (1) / 4.90 (2) 8.35 (1) / 7.95 (2) 10.02 (1) / 9.35 (2)
Power input Heating Nom. kW 0.87 (1) / 1.13 (2) 1.27 (1) / 1.59 (2) 1.66 (1) / 2.01 (2)
Max. kW -
COP 5.04 (1) / 3.58 (2) 4.74 (1) / 3.56 (2) 4.45 (1) / 3.42 (2)
Pump Nominal ESP unit Heating kPa 52 (3) / 55 (4) 49 (3) / 51 (4) 37 (3) / 41 (4)
Water side Heat
exchanger Water flow rate Heating Nom. l/min 12.6 (3) / 11.6 (4) 17.2 (3) / 16 (4) 21.2 (3) / 19.8 (4)
CONNECTABLE INDOOR UNITS
2-6 Nominal Capacity And Nominal Input EHVH16S18C3V/
ERLQ011CV3 EHVH16S26C9W/ ERLQ011CV3 EHVH16S18C3V /ERLQ014CV3 EHVH16S26C9 W/ERLQ014CV3 EHVH16S18C3V /ERLQ016CV3 EHVH16S26C9 W/ERLQ016CV3
Heating capacity Min. kW - -
Nom. kW 11.20 (1) / 10.98
(2) 11.20 (1) / 10.98 (2) 14.50 (1) / 13.60 (2) 16.00 (1) / 15.20 (2)
Max. kW 8.81 (3) / 8.16 (4) 8.81 (3) / 8.16 (4) 11.65 (3) / 10.96 (4) 12.30 (3) / 11.35 (4)
Power input Heating Nom. kW 2.56 (1) / 3.19 (2) 2.56 (1) / 3.19 (2) 3.42 (1) / 4.13 (2) 3.81 (1) / 4.66 (2)
Max. kW 3.52 (3) / 4.14 (4) 3.52 (3) / 4.14 (4) 4.95 (3) / 5.66 (4) 5.49 (3) / 6.43 (4)
COP 4.38(1)/2.50(3)/
3.44 (2) / 1.97 (4) 4.38(1)/2.50(3)/ 3.44 (2) / 1.97 (4) 4.24(1)/2.35(3)/3.29(2)/1.94 (4) 4.20(1)/2.24(3)/3.26(2)/1.79 (4)
Pump Nominal ESP unit Heating kPa 83.6 (1) / 85.8 (2) 83.6 (1) / 85.8 (2) 44.1 (1) / 55.9 (2) 23.1 (1) / 34.6 (2)
Water side Heat exchanger Water flow rate Heating Nom. l/min 32.1 (1) / 31.5 (2) 32.1 (1) / 31.5 (2) 41.6 (1) / 39.0 (2) 45.9 (1) / 43.6 (2)

3
1
2
• Heating • Daikin Altherma low temperature split 5
• Daikin Altherma low temperature split • ERLQ-CV3
2 Specifications
Notes
(1) Condition 1: cooling Ta 35ºC - LWE 18ºC (DT = 5ºC); heating Ta DB/WB 7ºC/6ºC - LWC 35ºC (DT = 5ºC)
(2) Condition 2: cooling Ta 35ºC - LWE 7ºC ( DT = 5ºC); heating Ta DB/WB 7ºC/6ºC - LWC 45ºC ( DT = 5ºC )
(3) DB/WB 7ºC/6ºC - LWC 35ºC (DT=5ºC)
(4) DB/WB 7ºC/6ºC - LWC 45ºC (Dt=5ºC)
(5) Condition 3: heating Ta DB -7ºC (RH85%) - LWC 35ºC
(6) Condition 4: heating Ta DB -7ºC (RH85%) - LWC 45ºC
Notes
(1) Condition 1: cooling Ta 35ºC - LWE 18ºC (DT = 5ºC); heating Ta DB/WB 7ºC/6ºC - LWC 35ºC (DT = 5ºC)
(2) Condition 2: cooling Ta 35ºC - LWE 7ºC ( DT = 5ºC); heating Ta DB/WB 7ºC/6ºC - LWC 45ºC ( DT = 5ºC )
(3) Tamb 35ºC - LWE 7ºC (DT=5ºC)
(4) Tamb 35ºC - LWE 18ºC (DT=5ºC)
(5) DB/WB 7ºC/6ºC - LWC 35ºC (DT=5ºC)
(6) DB/WB 7ºC/6ºC - LWC 45ºC (Dt=5ºC)
(7) Condition 3: heating Ta DB -7ºC (RH85%) - LWC 35ºC
(8) Condition 4: heating Ta DB -7ºC (RH85%) - LWC 45ºC
CONNECTABLE INDOOR UNITS
2-7 Nominal Capacity And Nominal Input EHVX04S18C3V/
ERLQ004CV3 EHVX08S18C3V/ ERLQ006CV3 EHVX08S26C9W/ ERLQ006CV3 EHVX08S18C3V/ ERLQ008CV3 EHVX08S26C9W/ ERLQ008CV3
Heating capacity Min. kW 1.80 (1) / 1.80 (2)
Nom. kW 4.40 (1) / 4.03 (2) 6.00 (1) / 5.67 (2) 7.40 (1) / 6.89 (2)
Max. kW 5.12 (1) / 4.90 (2) 8.35 (1) / 7.95 (2) 10.02 (1) / 9.53 (2)
Cooling capacity Min. kW 2.00 (1) / 2.00 (2) 2.50 (1) / 2.50 (2)
Nom. kW 5.00 (1) / 4.17 (2) 6.76 (1) / 4.84 (2) 6.86 (1) / 5.36 (2)
Power input Heating Nom. kW 0.87 (1) / 1.13 (2) 1.27 (1) / 1.59 (2) 1.66 (1) / 2.01 (2)
Max. kW -
Cooling Nom. kW 1.48 (1) / 1.80 (2) 1.96 (1) / 2.07 (2) 2.01 (1) / 2.34 (2)
COP 5.04 (1) / 3.58 (2) 4.74 (1) / 3.56 (2) 4.45 (1) / 3.42 (2)
EER 3.37 (1) / 2.32 (2) 3.45 (1) / 2.34 (2) 3.42 (1) / 2.29 (2)
Pump Nominal ESP unit Cooling kPa 54 (3) / 45 (4) 57 (3) / 42 (4) 54 (3) / 41 (4)
Heating kPa 52 (5) / 55 (6) 49 (5) / 51 (6) 37 (5) / 41 (6)
Water side Heat
exchanger Water flow rate Cooling Nom. l/min 12.0 (3) / 14.3 (4) 13.9 (3) / 19.4 (4) 15.4 (3) / 19.7 (4)
Heating Nom. l/min 12.6 (5) / 11.6 (6) 17.2 (5) / 16.3 (6) 21.2 (5) / 19.8 (6)
CONNECTABLE INDOOR UNITS
2-8 Nominal Capacity And Nominal Input EHVX16S18C3V/
ERLQ011CV3 EHVX16S26C9W/ ERLQ011CV3 EHVX16S18C3V/ ERLQ014CV3 EHVX16S26C9W/ ERLQ014CV3 EHVX16S18C3V/ ERLQ016CV3 EHVX16S26C9W/ ERLQ016CV3
Heating capacity Min. kW - -
Nom. kW 11.20 (1) / 10.98
(2) 11.20 (1) / 10.98 (2) 14.50 (1) / 13.60 (2) 16.00 (1) / 15.20 (2)
Max. kW 8.81 (3) / 8.16 (4) 8.81 (3) / 8.16 (4) 11.65 (3) / 10.96 (4) 12.30 (3) / 11.35 (4)
Cooling capacity Min. kW - -
Nom. kW 15.05 (1) / 11.72
(2) 15.05 (1) / 11.72 (2) 16.06 (1) / 12.55 (2) 16.76 (1) / 13.12 (2)
Power input Heating Nom. kW 2.56 (1) / 3.19 (2) 2.56 (1) / 3.19 (2) 3.42 (1) / 4.13 (2) 3.81 (1) / 4.66 (2)
Max. kW 3.52 (3) / 4.14 (4) 3.52 (3) / 4.14 (4) 4.95 (3) / 5.66 (4) 5.49 (3) / 6.34 (4)
Cooling Nom. kW 4.53 (1) / 4.31 (2) 4.53 (1) / 4.31 (2) 5.43 (1) / 5.08 (2) 5.16 (1) / 5.73 (2)
COP 4.38(1)/2.50(3)/
3.44 (2) / 1.97 (4) 4.38(1)/2.50 (3)/ 3.44 (2) / 1.97 (4) 4.24 (1) / 2.35 (3) / 3.29 (2) / 1.94 (4) 4.20 (1) / 2.24 (3) / 3.26 (2) / 1.79 (4)
EER 3.32 (1) / 2.72 (2) 3.32 (1) / 2.72 (2) 2.96 (1) / 2.47 (2) 2.72 (1) / 2.29 (2)
Pump Nominal ESP
unit Cooling kPa 78.0 (2) / 37.0 (1) 78.0 (2) / 37.0 (1) 68.6 (2) / 22.5 (1) 61.9 (2) / 12.1 (1)
Heating kPa 83.6 (1) / 85.8 (2) 83.6 (1) / 85.8 (2) 44.1 (1) / 55.9 (2) 23.1 (1) / 34.6 (2)
Water side Heat
exchanger Waterflowrate Cooling Nom. l/min 33.6 (2) / 43.1 (1) 33.6 (2) / 43.1 (1) 36.0 (2) / 46.0 (1) 37.6 (2) / 48.0 (1)
Heating Nom. l/min 32.1 (1) / 31.5 (2) 32.1 (1) / 31.5 (2) 41.6 (1) / 39.0 (2) 45.9 (1) / 43.6 (2)

• Daikin Altherma low temperature split • ERLQ-CV3
1
2
• Heating • Daikin Altherma low temperature split
6
2 Specifications
2-9 Technical Specifications ERLQ004CV3 ERLQ006CV3 ERLQ008CV3 ERLQ011CV3 ERLQ014CV3 ERLQ016CV3
Capacity control Method Inverter controlled
Casing Colour Ivory white
Material Polyester paintedgalvanised steel plate Painted galvanized steel plate
Dimensions Unit Height mm 735 1,345
Width mm 832 900
Depth mm 307 320
Packed unit Height mm 797 1,524
Width mm 990 980
Depth mm 390 420
Weight Unit kg 54 56 113
Packed unit kg 57 59 128
Packing Material EPS / Carton Wood / EPS / Carton / PE (Straps)
Weight kg 3 15
Heat exchanger Length mm 845 857
Rows Quantity 2
Fin pitch mm 1.8 1.4
Passes Quantity - 7
Face area m² - 1.131
Stages Quantity 32 60
Empty tubeplate hole Quantity - 0
Tube type ø8 Hi-XA ø8 Hi-XSS
Fin Type WF fin
Treatment Anti-corrosion treatment (PE)
Fan Type Propeller fan
Quantity 1 2
Air flow rate Heating High m³/min 45 47 -
Cooling High m³/min 52.5 -
Discharge direction Horizontal
Fan motor Quantity 1 2
Model - Brushless DC motor
Output W 53 70
Drive - Direct drive
Speed Steps - 8
Heating Nom. rpm - 740 750 760
Cooling Nom. rpm - 780
Compressor Quantity 1
Model 2YC36BXD#
C2YC45DXD#C JT100G-VD (B2)
Type Hermetically sealed swing compressor Hermetically sealed scroll compressor
Output W - 2,200
Starting method - Inverter driven
Motor Crankcase heater Output W - 33
Operation range Heating Min. ºCWB -25
Max. ºCWB 25 35
Cooling Min. ºCDB 10
Max. ºCDB 43 46.0
Domestic hot water Min. ºCDB -25 -20
Max. ºCDB 35
Refrigerant Type R-410A
Charge kg 1.45 1.60 3.4
Control Expansion valve (electronic type)
Circuits Quantity 1
Refrigerant oil Type FVC50K Daphne FVC68D
Charged volume l 0.75 1.5

3
1
2
• Heating • Daikin Altherma low temperature split 7
• Daikin Altherma low temperature split • ERLQ-CV3
2 Specifications
Notes
(1) Operation range heating (outdoor unit): range increase by support back-up heater
(2) See operation range drawing: range increase by support booster heater or backup heater
(3) The sound pressure level is measured via a microphone at a certain distance from the unit. It is a relative value depending on the distance and acoustic environment. Refer to
sound spectrum drawing for more information.
(4) Minimum Ssc value: Equipment complying with EN/IEC 61000-3-12: European/International Technical Standard setting the limits for harmonic currents produced by equipment
connected to public low-voltage systems with input current \>16A and 75A per phase
(5) PED unit category: excluded from scope of PED due to article 1, item 3.6 of 97/23/EC
Piping
connections Liquid Quantity - 1
Type Flare connection
OD mm 6.35 9.52
Gas Quantity - 1
Type Flare connection
OD mm 15.9
Drain Quantity 2 3
Type Hole
OD mm 1x ø15 + 1x ø20 26
Drain 2 Quantity - 1
Type - Hole
OD mm - 18
Piping length OU - IU Max. m 30 50
System Equivalent m- 70
Chargeless m- 10
Additional refrigerant charge kg/m - See installation manual
Level difference IU - OU Max. m 20 30
Heat insulation - Both liquid and gas pipes
Sound power
level Heating Nom. dBA 61 62 64 66
Cooling Nom. dBA 63 64 66 69
Sound pressure
level Heating Nom. dBA 48 (3) 49 (3) 51 52
Cooling Nom. dBA 48 (3) 49 (3) 50 (3) 50 52 54
Night quiet mode Heating dBA - 42 43
Cooling dBA - 45 46
Defrost method Reversed cycle Pressure equalising
Defrost control Sensor for outdoor heat exchanger temperature
Safety devices Item 01 - High pressure switch
02 - Fan motor thermal protection
03 - Fuse
PED Category Category I -
2-10 Electrical Specifications ERLQ004CV3 ERLQ006CV3 ERLQ008CV3 ERLQ011CV3 ERLQ014CV3 ERLQ016CV3
Power supply Name V3
Phase 1~
Frequency Hz 50
Voltage V 230
Voltage range Min. % 10 -10
Max. % 10
Current Zmax Text - 0.22
Minimum Ssc value kVa - 525
Starting current Heating A 18 -
Cooling A 18 -
Maximum running
current Heating A - 34.2
Cooling A - 34.2
Recommended fuses A 20 40
Wiring connections For power supply Quantity 3 -
Remark - See installation manual outdoor unit
For connection with
indoor Quantity 3 -
Remark No earth wiring See installation manual outdoor unit
Power supply intake - Outdoor unit only
2-9 Technical Specifications ERLQ004CV3 ERLQ006CV3 ERLQ008CV3 ERLQ011CV3 ERLQ014CV3 ERLQ016CV3

• Daikin Altherma low temperature split • ERLQ-CV3
1
2
• Heating • Daikin Altherma low temperature split
8
2 Specifications
(6) Condition: Ta DB/WB 7ºC/6ºC - LWC 35ºC (DT = 5ºC)
(7) Condition: Ta 35ºC - LWE 7ºC ( DT = 5ºC)
(8) Operation range domestic hot water (outdoor unit): range increase by support booster heater
(9) See separate drawing for operation range
(10) In accordance with EN/IEC 61000-3-11, respectively EN/IEC 61000-3-12, it may be necessary to consult the distribution network operator to ensure that the equipment is
connected only to a supply with Zsys Zmax, respectively Ssc minimum Ssc value.
(11) Minimum Ssc (=Short-circuit power) value: Equipment complying with EN/IEC61000-3-12: European/International Technical Standard setting the limits for harmonic currents
produced by equipment connected to public low-voltage systems with input current \>16A and 75A per phase
(12) EN/IEC 61000-3-11: European/international technical standard setting the limits for voltage changes, voltage fluctuations and flicker in public low-voltage supply systems for
equipment with rated 75A
(13) Zsys: system impedance

• Daikin Altherma low temperature split • ERLQ-CV3
1
3
• Heating • Daikin Altherma low temperature split
9
3 Capacity tables
3 - 1 Heating Capacity Tables
∼

3
1
3
• Heating • Daikin Altherma low temperature split 10
• Daikin Altherma low temperature split • ERLQ-CV3
3 Capacity tables
3 - 1 Heating Capacity Tables

• Daikin Altherma low temperature split • ERLQ-CV3
1
3
• Heating • Daikin Altherma low temperature split
11
3 Capacity tables
3 - 1 Heating Capacity Tables
ERLQ011-016C
3TW60332-5A
Capacity in function of field piping length for inverter
Field piping length (m)
Cooling
Heating
Capacity (%)
NOTE
Capacity drop is at nominal capacity

3
1
3
• Heating • Daikin Altherma low temperature split 12
• Daikin Altherma low temperature split • ERLQ-CV3
3 Capacity tables
3 - 2 Cooling Capacity Tables
∼

• Daikin Altherma low temperature split • ERLQ-CV3
1
3
• Heating • Daikin Altherma low temperature split
13
3 Capacity tables
3 - 2 Cooling Capacity Tables

3
1
3
• Heating • Daikin Altherma low temperature split 14
• Daikin Altherma low temperature split • ERLQ-CV3
3 Capacity tables
3 - 3 Certification Programs

• Daikin Altherma low temperature split • ERLQ-CV3
1
3
• Heating • Daikin Altherma low temperature split
15
3 Capacity tables
3 - 3 Certification Programs

3
1
4
• Heating • Daikin Altherma low temperature split 16
• Daikin Altherma low temperature split • ERLQ-CV3
4 Dimensional drawings
4 - 1 Dimensional Drawings
ERLQ011-016CV3
3TW60334-2
Hole for anchor 1 Gas pipe connection Ø15.9 flare
2 Liquid connection pipe Ø9.5 flare
3 Service port (in the unit)
4 Electronic connection and grounding terminal M5 (in switchbox)
5 Refrigerant piping intake
6 Power supply wiring intake (knock hole Ø34)
7 Control wiring intake (knock hole Ø27)
8 Drain outlet

• Daikin Altherma low temperature split • ERLQ-CV3
1
5
• Heating • Daikin Altherma low temperature split
17
5 Centre of gravity
5 - 1 Centre of Gravity
ERLQ011-016CV3
4TW31729-4

3
1
6
• Heating • Daikin Altherma low temperature split 18
• Daikin Altherma low temperature split • ERLQ-CV3
6 Piping diagrams
6 - 1 Piping Diagrams
″
