Daikin FFQ25C Instruction manual

Air Conditioning
Technical Data
Fully flat cassette
EEDEN15-100
FFQ-C

• Split - Sky Air • FFQ-C 1
• Indoor Unit • FFQ-C
TABLE OF CONTENTS
FFQ-C
1Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2 Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3 Safety device settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
5 Dimensional drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6 Centre of gravity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
7 Piping diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
8 Wiring diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Wiring Diagrams - Single Phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
9 External connection diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
10 Sound data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Sound Pressure Spectrum - Cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Sound Pressure Spectrum - Heating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
11 Air flow patterns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Air Flow Pattern - Cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Air Flow Pattern - Heating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

• Indoor Unit • FFQ-C
1
• Split - Sky Air • FFQ-C
2
1 Features
IndoorUnit Split-Sk FFQ-CFullyflat Unique design in the market that integrates fully flat into the ceiling
• Fully flat integration instandard architectural ceiling tiles, leaving only
8mm
• Remarkable blend of iconic design and engineering excellence with
an elegant finish in white or a combination of silver and white
• Two optional intelligent sensors improve energy efficiency and
comfort. The presence sensor adjusts the set point if no one is
detected in the room. It also automatically directs air flow away from
any person to avoid draught. The infrared floor sensor detects the
averagefloor temperatureand ensureseven temperaturedistribution
between ceiling and floor to prevent cold feet.
• Reduced energy consumption thanks to specially developed small
tube heat exchanger, DC fan motor and drain pump
• Fresh air intake integrated in the same system thus reducing
installation cost as no additional ventilation is required
• Standard drain pump with 850mm lift increases flexibility and
installation speed
• No optional adapter needed for DIII-connection, link your unit into the
wider building management system.
Inverter Presence &
floor sensor Home leave operation Fan only Draught prevention Auto cooling- heating
changeover
Whisper quiet Ceiling soiling
prevention Individual flap control
Vertical auto
swing Fan speed steps Dry programme Air filter Weekly timer Infraredremote control Wired remote control Auto-restart Self diagnosis
Drain pump kit Twin/triple/
double twin
application
Multi model
application VRV for residential
application

3
2
• Split - Sky Air • FFQ-C 3
• Indoor Unit • FFQ-C
2 Specifications
2-1 Technical Specifications FFQ25C FFQ35C FFQ50C FFQ60C
Casing Material Galvanised steel plate
Dimensions Unit Height/Width/
Depth mm 260/575/575
Packed unit Height/Width/
Depth mm 270/780/616
Weight Unit kg 16 17.5
Packed unit kg 19 20.5
Decoration panel Model BYFQ60CW
Colour White (N9.5)
Dimensions Height/Width/
Depth mm 46/620/620
Weight kg 2.8
Decoration panel 2 Model BYFQ60CS
Colour White (N9.5) + Silver
Dimensions Height/Width/
Depth mm 46/620/620
Weight kg 2.8
Decoration panel 3 Model BYFQ60B3W1
Colour White (RAL9010)
Dimensions Height/Width/
Depth mm 55/700/700
Weight kg 2.7
Heat exchanger Inside length mm 1,295 1,248
Outside length mm 1,342
Rows Quantity 2 3
Fin pitch mm 1.2
Passes Quantity 5 7
Face area m² 0.290 0.300
Stages Quantity 12 16
Empty tubeplate
hole Quantity 0
Fin Type Cross fin coil (multi slit fins and hi-XA tubes)
Air filter Type Resin net with mold resistance
Fan Type Turbo fan
Quantity 1
Air flow rate Cooling High m³/min 9 10 12 14.5
Nom. m³/min 8 8.5 10 12.5
Low m³/min 6.5 7.5 9.5
Heating High m³/min 9 10 12 14.5
Nom. m³/min 8 8.5 10 12.5
Low m³/min 6.5 7.5 9.5
Fan motor Model QTS32D15M
Speed Steps 3
Output High W 50
Sound power level Cooling dBA 48 51 56 60
Heating dBA -
Sound pressure level Cooling High/Nom./Low dBA 31/28.5/25 34/30.5/25 39/34/27 43/40/32
Heating High/Nom./Low dBA 31/28.5/25 34/30.5/25 39/34/27 43/40/32
Control systems Infrared remote control BRC7EB530 (standard panel) / BRC7F530W (white panel) / BRC7F530S (grey panel)
Wired remote control BRC1D52 / BRC1E52A/B
Refrigerant Type R-410A
Piping connections Sound absorbing insulation Foamed Polyurethane
Liquid Type/OD mm Flare connection/6.35
Gas Type/OD mm Flare connection/9.52 Flare connection/12.7
Drain VP20 (I.D. 20/O.D. 26)
Heat insulation Foamed polystyrene/polyethylene

• Indoor Unit • FFQ-C
2
• Split - Sky Air • FFQ-C
4
2 Specifications
Standard Accessories : Operation manual; Quantity : 1;
Standard Accessories : Installation manual; Quantity : 1;
Standard Accessories : Drain hose; Quantity : 1;
Standard Accessories : Metal clamp for drain hose; Quantity : 1;
Standard Accessories : Washer for hanger bracket; Quantity : 8;
Standard Accessories : Screws; Quantity : 4;
Standard Accessories : Paper pattern for installation; Quantity : 1;
Standard Accessories : Insulation for fitting; Quantity : 2;
Standard Accessories : Sealing pad; Quantity : 4;
Standard Accessories : Clamps; Quantity : 7;
Notes
Dimensions do not include control box
The sound power level is an absolute value indicating the power which a sound source generates.
2-2 Electrical Specifications FFQ25C FFQ35C FFQ50C FFQ60C
Power supply Name VE
Phase 1~
Frequency Hz 50
Voltage V 220-240

3
3
• Split - Sky Air • FFQ-C 5
• Indoor Unit • FFQ-C
3 Safety device settings
3 - 1 Safety Device Settings

• Indoor Unit • FFQ-C
4
• Split - Sky Air • FFQ-C
6
4 Options
4 - 1 Options
FFQ-C
Description BYFQ60B2W1
BYFQ60B3W1 BYFQ60C2W1W BYFQ60C2W1S model name
Decoration panel (current) - - - BYFQ60B2W1
Decoration panel (current) - - - BYFQ60B3W1
New decoration panel (white) - - - BYFQ60C2W1W
New decoration panel (silver) - - - BYFQ60C2W1S
Sensor kit (white) No Yes No BRYQ60A2W (*3)
Sensor kit (silver) No No Yes BRYQ60A2S (*3)
Sealing member of air discharge outlet Yes Yes Yes BDBHQ44C60
Panel spacer Yes No No KDBQ44B60
5HSODFHPHQWORQJOLIH¿OWHU Yes Yes Yes KAFQ441BA60
Fresh air intake kit Yes Yes Yes KDDQ44XA60
Infrared remote control (H/P) Yes No No BRC7EB530W (*1,2)
Infrared remote control (H/P) (white) No Yes No BRC7F530W (*1,2)
Infrared remote control (H/P) (silver) No No Yes BRC7F530S (*1,2)
Wired remote control Yes Yes Yes BRC1D528 (*2)
Wired remote control Yes Yes Yes BRC1E52A7 + B7 (*4)
6LPSOL¿HGUHPRWHFRQWUROZLWKRSHUDWLRQPRGHVHOHFWRUEXWWRQ Yes Yes Yes BRC2E52C (*5)
6LPSOL¿HGUHPRWHFRQWUROZLWKRXWRSHUDWLRQPRGHVHOHFWRUEXWWRQ Yes Yes Yes BRC3E52C (*5)
Central remote control Yes Yes Yes DCS302B51
8QL¿HGRQRIIFRQWURO Yes Yes Yes DCS301B51
Schedule timer Yes Yes Yes DST301B51
Wiring adapter for electrical appendices Yes Yes Yes KRP1B57
Wiring adapter for electrical appendices Yes Yes Yes -
Wiring adapter for electrical appendices Yes Yes Yes KRP4A53
Wiring adapter (hour meter) Yes Yes Yes EKRP1B2
Installation box for adapter PCB Yes Yes Yes KRP1B101, KRP1BA101
Remote sensor Yes Yes Yes KRCS01-4B
Option PCB for Multi tenant Yes Yes Yes -
I-touch controller Yes Yes Yes DCS601C51
Digital input adapter Yes Yes Yes BRP7A53
NOTES
1. Sensing function not available.
2. ,QGHSHQGHQWO\FRQWUROODEOHÀDSVIXQFWLRQQRWDYDLODEOH
3. Sensor kit option not applicable with RR and RQ models
4. ,QGHSHQGHQWO\FRQWUROODEOHÀDSVIXQFWLRQQRWDYDLODEOHLQFRPELQDWLRQZLWK55DQG54PRGHOV
5. Included languages are:
Language pack 1: English, German, French, Dutch, Spanish, Italian and Portuguese.
With PC cable EKPCCAB3 in combination with the Updater PC software, you can additionally change the language to:
Language pack 2: English, Bulgarian, Croatian, Czech, Hungarian, Romanian and Slovenian.
Language pack 3: English, Greek, Polish, Russian, Serbian, Slovak and Turkish.
6. 2QO\SRVVLEOHLQFRPELQDWLRQZLWKVLPSOL¿HGUHPRWHFRQWURO%5&(&
7. Requires installation box for adapter PCB. 3D082559C

3
5
• Split - Sky Air • FFQ-C 7
• Indoor Unit • FFQ-C
5 Dimensional drawings
5 - 1 Dimensional Drawings

• Indoor Unit • FFQ-C
5
• Split - Sky Air • FFQ-C
8
5 Dimensional drawings
5 - 1 Dimensional Drawings

3
6
• Split - Sky Air • FFQ-C 9
• Indoor Unit • FFQ-C
6 Centre of gravity
6 - 1 Centre of Gravity

• Indoor Unit • FFQ-C
7
• Split - Sky Air • FFQ-C
10
7 Piping diagrams
7 - 1 Piping Diagrams

3
8
• Split - Sky Air • FFQ-C 11
• Indoor Unit • FFQ-C
8 Wiring diagrams
8 - 1 Wiring Diagrams - Single Phase

• Indoor Unit • FFQ-C
9
• Split - Sky Air • FFQ-C
12
9 External connection diagrams
9 - 1 External Connection Diagrams

3
10
• Split - Sky Air • FFQ-C 13
• Indoor Unit • FFQ-C
10 Sound data
10 - 1 Sound Pressure Spectrum - Cooling

• Indoor Unit • FFQ-C
10
• Split - Sky Air • FFQ-C
14
10 Sound data
10 - 2 Sound Pressure Spectrum - Heating

3
11
• Split - Sky Air • FFQ-C 15
• Indoor Unit • FFQ-C
11 Air flow patterns
11 - 1 Air Flow Pattern - Cooling

• Indoor Unit • FFQ-C
11
• Split - Sky Air • FFQ-C
16
11 Air flow patterns
11 - 1 Air Flow Pattern - Cooling

3
11
• Split - Sky Air • FFQ-C 17
• Indoor Unit • FFQ-C
11 Air flow patterns
11 - 1 Air Flow Pattern - Cooling

• Indoor Unit • FFQ-C
11
• Split - Sky Air • FFQ-C
18
11 Air flow patterns
11 - 1 Air Flow Pattern - Cooling
