Installer reference guide
Split system air conditioner English
Installer reference guide
Split system air conditioner
FTXTA30A2V1BW

Table of contents
Installer reference guide
2
FTXTA30A2V1BW
Split system air conditioner
4P518023-6E – 2019.04
Table of contents
1 General safety precautions 2
1.1 About the documentation .......................................................... 2
1.1.1 Meaning of warnings and symbols.............................. 2
1.2 For the installer.......................................................................... 3
1.2.1 General ....................................................................... 3
1.2.2 Installation site ............................................................ 3
1.2.3 Refrigerant .................................................................. 5
1.2.4 Brine............................................................................ 5
1.2.5 Water .......................................................................... 5
1.2.6 Electrical ..................................................................... 6
2 About the documentation 6
2.1 About this document.................................................................. 6
2.2 Installer reference guide at a glance ......................................... 7
3 About the box 7
3.1 Overview: About the box ........................................................... 7
3.2 Indoor unit ................................................................................. 7
3.2.1 To unpack the indoor unit ........................................... 7
3.2.2 To remove the accessories from the indoor unit......... 7
4 About the unit 8
4.1 System layout............................................................................ 8
4.2 Operation range ........................................................................ 8
4.3 About the wireless LAN adapter................................................ 8
4.3.1 Precautions when using the wireless adapter............. 8
4.3.2 Basic parameters ........................................................ 8
4.3.3 Setting the wireless adapter........................................ 8
5 Preparation 8
5.1 Overview: Preparation............................................................... 8
5.2 Preparing the installation site .................................................... 8
5.2.1 Installation site requirements of the indoor unit .......... 9
5.3 Preparing refrigerant piping....................................................... 9
5.3.1 Refrigerant piping requirements.................................. 9
5.3.2 Refrigerant piping insulation ....................................... 9
5.4 Preparing electrical wiring ......................................................... 10
5.4.1 About preparing electrical wiring................................. 10
6 Installation 10
6.1 Overview: Installation ................................................................ 10
6.2 Opening the indoor unit ............................................................. 10
6.2.1 To open the front panel............................................... 10
6.2.2 To close the front panel .............................................. 10
6.2.3 To remove the front panel........................................... 11
6.2.4 To open the service cover........................................... 11
6.2.5 To remove the front grille ............................................ 11
6.2.6 To re-install the front grille .......................................... 12
6.2.7 To remove the electrical wiring box cover................... 12
6.3 Installing the indoor unit ............................................................ 12
6.3.1 Precautions when installing the indoor unit................. 12
6.3.2 To install the mounting plate....................................... 12
6.3.3 To drill a wall hole ....................................................... 13
6.3.4 To remove the pipe port cover.................................... 13
6.3.5 To provide drainage.................................................... 13
6.4 Connecting the refrigerant piping .............................................. 15
6.4.1 About connecting the refrigerant piping ...................... 15
6.4.2 Precautions when connecting the refrigerant piping... 15
6.4.3 Guidelines when connecting the refrigerant piping..... 15
6.4.4 Pipe bending guidelines.............................................. 16
6.4.5 To flare the pipe end................................................... 16
6.4.6 To connect the refrigerant piping to the indoor unit .... 16
6.5 Connecting the electrical wiring................................................. 16
6.5.1 About connecting the electrical wiring......................... 16
6.5.2 Precautions when connecting the electrical wiring ..... 16
6.5.3 Guidelines when connecting the electrical wiring ....... 17
6.5.4 Specifications of standard wiring components............. 17
6.5.5 To connect the electrical wiring on the indoor unit....... 17
6.5.6 To connect optional accessories (wired user
interface, central user interface, etc.)........................... 18
6.6 Finishing the indoor unit installation ........................................... 18
6.6.1 To insulate the drain piping, refrigerant piping and
interconnection cable ................................................... 18
6.6.2 To pass the pipes through the wall hole ...................... 18
6.6.3 To fix the unit on the mounting plate............................ 18
6.6.4 To install the screw covers........................................... 18
7 Configuration 18
7.1 To set a different address........................................................... 18
8 Commissioning 19
8.1 Overview: Commissioning.......................................................... 19
8.2 Checklist before commissioning................................................. 19
8.3 To perform a test run.................................................................. 19
8.3.1 To perform a test run using the user interface............. 20
9 Hand-over to the user 20
10 Disposal 20
11 Technical data 20
11.1 Wiring diagram ........................................................................... 20
11.1.1 Unified wiring diagram legend...................................... 20
12 Glossary 21
1 General safety precautions
1.1 About the documentation
▪ The original documentation is written in English. All other
languages are translations.
▪ The precautions described in this document cover very important
topics, follow them carefully.
▪ The installation of the system, and all activities described in the
installation manual and the installer reference guide MUST be
performed by an authorised installer.
1.1.1 Meaning of warnings and symbols
DANGER
Indicates a situation that results in death or serious injury.
DANGER: RISK OF ELECTROCUTION
Indicates a situation that could result in electrocution.
DANGER: RISK OF BURNING
Indicates a situation that could result in burning because of
extreme hot or cold temperatures.
DANGER: RISK OF EXPLOSION
Indicates a situation that could result in explosion.
WARNING
Indicates a situation that could result in death or serious
injury.
WARNING: FLAMMABLE MATERIAL
CAUTION
Indicates a situation that could result in minor or moderate
injury.

1 General safety precautions
Installer reference guide
3
FTXTA30A2V1BW
Split system air conditioner
4P518023-6E – 2019.04
NOTICE
Indicates a situation that could result in equipment or
property damage.
INFORMATION
Indicates useful tips or additional information.
Symbol Explanation
Before installation, read the installation and
operation manual, and the wiring instruction sheet.
Before performing maintenance and service tasks,
read the service manual.
For more information, see the installer and user
reference guide.
1.2 For the installer
1.2.1 General
If you are NOT sure how to install or operate the unit, contact your
dealer.
NOTICE
Improper installation or attachment of equipment or
accessories could result in electric shock, short-circuit,
leaks, fire or other damage to the equipment. Only use
accessories, optional equipment and spare parts made or
approved by Daikin.
WARNING
Make sure installation, testing and applied materials
comply with applicable legislation (on top of the
instructions described in the Daikin documentation).
CAUTION
Wear adequate personal protective equipment (protective
gloves, safety glasses,…) when installing, maintaining or
servicing the system.
WARNING
Tear apart and throw away plastic packaging bags so that
nobody, especially children, can play with them. Possible
risk: suffocation.
DANGER: RISK OF BURNING
▪ Do NOT touch the refrigerant piping, water piping or
internal parts during and immediately after operation. It
could be too hot or too cold. Give it time to return to
normal temperature. If you must touch it, wear
protective gloves.
▪ Do NOT touch any accidental leaking refrigerant.
WARNING
Provide adequate measures to prevent that the unit can be
used as a shelter by small animals. Small animals that
make contact with electrical parts can cause malfunctions,
smoke or fire.
CAUTION
Do NOT touch the air inlet or aluminium fins of the unit.
NOTICE
▪ Do NOT place any objects or equipment on top of the
unit.
▪ Do NOT sit, climb or stand on the unit.
NOTICE
Works executed on the outdoor unit are best done under
dry weather conditions to avoid water ingress.
In accordance with the applicable legislation, it might be necessary
to provide a logbook with the product containing at least: information
on maintenance, repair work, results of tests, stand-by periods,…
Also, at least, following information MUST be provided at an
accessible place at the product:
▪ Instructions for shutting down the system in case of an emergency
▪ Name and address of fire department, police and hospital
▪ Name, address and day and night telephone numbers for
obtaining service
In Europe, EN378 provides the necessary guidance for this logbook.
1.2.2 Installation site
▪ Provide sufficient space around the unit for servicing and air
circulation.
▪ Make sure the installation site withstands the weight and vibration
of the unit.
▪ Make sure the area is well ventilated. Do NOT block any
ventilation openings.
▪ Make sure the unit is level.
Do NOT install the unit in the following places:
▪ In potentially explosive atmospheres.
▪ In places where there is machinery that emits electromagnetic
waves. Electromagnetic waves may disturb the control system,
and cause malfunction of the equipment.
▪ In places where there is a risk of fire due to the leakage of
flammable gases (example: thinner or gasoline), carbon fibre,
ignitable dust.
▪ In places where corrosive gas (example: sulphurous acid gas) is
produced. Corrosion of copper pipes or soldered parts may cause
the refrigerant to leak.
▪ In bathrooms.
Instructions for equipment using R32 refrigerant
If applicable.
WARNING
▪ Do NOT pierce or burn.
▪ Do NOT use means to accelerate the defrosting
process or to clean the equipment, other than those
recommended by the manufacturer.
▪ Be aware that R32 refrigerant does NOT contain an
odour.
WARNING
The appliance shall be stored so as to prevent mechanical
damage and in a well-ventilated room without continuously
operating ignition sources (example: open flames, an
operating gas appliance or an operating electric heater)
and have a room size as specified below.
NOTICE
▪ Do NOT re-use joints which have been used already.
▪ Joints made in installation between parts of refrigerant
system shall be accessible for maintenance purposes.

1 General safety precautions
Installer reference guide
4
FTXTA30A2V1BW
Split system air conditioner
4P518023-6E – 2019.04
WARNING
Make sure installation, servicing, maintenance and repair
comply with instructions from Daikin and with applicable
legislation (for example national gas regulation) and are
executed only by authorised persons.
Installation space requirements
NOTICE
▪ Pipework shall be protected from physical damage.
▪ Installation of pipework shall be kept to a minimum.
WARNING
If appliances contain R32 refrigerant, the floor area of the
room in which the appliances are installed, operated and
stored MUST be larger than the minimum floor area
defined in table below A (m2). This applies to:
▪ Indoor units without a refrigerant leakage sensor; in
case of indoor units with refrigerant leakage sensor,
consult the installation manual
▪ Outdoor units installed or stored indoors (e.g. winter
garden, garage, machinery room)
▪ Pipework in unventilated spaces
To determine the minimum floor area
1Determine the total refrigerant charge in the system (= factory
refrigerant charge + additional refrigerant amount
charged).
Contains fluorinated greenhouse gases
2
11
1
2
2kg
tCO
2
eq
1000
GWP × kg
=
=
+
kg
=
kg
=
GWP: xxx
R32
2Determine which graph or table to use.
▪ For indoor units: Is the unit ceiling-mounted, wall-mounted or
floor-standing?
▪ For outdoor units installed or stored indoors, and field piping
in unventilated spaces, this depends on the installation
height:
If the installation height is… Then use the graph or table for…
<1.8m Floor-standing units
1.8≤x<2.2m Wall-mounted units
≥2.2m Ceiling-mounted units
3Use the graph or table to determine the minimum floor area.
0
10
20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170
180
190
200
210
220
230
240
250
260
270
280
290
300
310
320
330
340
350
360
370
380
390
400
410
420
430
440
450
460
470
480
490
500
510
520
530
540
550
1.8
2
2.2
2.4
2.6
2.8
3
3.2
3.4
3.6
3.8
4
4.2
4.4
4.6
4.8
5
5.2
5.4
5.6
5.8
6
6.2
6.4
6.6
6.8
7
7.2
7.4
7.6
7.8
1.843 7.956
8.0
Amin (m2)
Floor-standing unit
(c)
Wall-mounted unit
(b)
Ceiling-mounted unit
(a)
m (kg)
Ceiling-mounted
unit(a)
4.6 13.4 4.6 180
4.8 14.6 4.8 196
5.0 15.8 5.0 213
≤1.842 —
5.2 17.1
≤1.842 —
5.2 230
1.843 3.64
5.4 18.5
1.843 28.9
5.4 248
2.0 3.95
5.6 19.9
2.0 34.0
5.6 267
2.2 4.34
5.8 21.3
2.2 41.2
5.8 286
2.4 4.74
6.0 22.8
2.4 49.0
6.0 306
2.6 5.13
6.2 24.3
2.6 57.5
6.2 327
2.8 5.53
6.4 25.9
2.8 66.7
6.4 349
3.0 5.92
6.6 27.6
3.0 76.6
6.6 371
3.2 6.48
6.8 29.3
3.2 87.2
6.8 394
3.4 7.32
7.0 31.0
3.4 98.4
7.0 417
3.6 8.20
7.2 32.8
3.6 110
7.2 441
3.8 9.14
7.4 34.7
3.8 123
7.4 466
4.0 10.1
7.6 36.6
4.0 136
7.6 492
4.2 11.2
7.8 38.5
4.2 150
7.8 518
4.4 12.3
7.956 40.1
4.4 165
7.956 539
m (kg) Amin (m2)
4.6 20.0
4.8 21.8
5.0 23.6
≤1.842 —
5.2 25.6
1.843 4.45
5.4 27.6
2.0 4.83
5.6 29.7
2.2 5.31
5.8 31.8
2.4 5.79
6.0 34.0
2.6 6.39
6.2 36.4
2.8 7.41
6.4 38.7
3.0 8.51
6.6 41.2
3.2 9.68
6.8 43.7
3.4 10.9
7.0 46.3
3.6 12.3
7.2 49.0
3.8 13.7
7.4 51.8
4.0 15.1
7.6 54.6
4.2 16.7
7.8 57.5
4.4 18.3
7.956 59.9
Wall-mounted
unit(b)
m (kg) Amin (m2)
Floor-standing
unit(c)
m (kg) Amin (m2)
mTotal refrigerant charge in the system
Amin Minimum floor area
(a) Ceiling-mounted unit (= Ceiling-mounted unit)
(b) Wall-mounted unit (= Wall-mounted unit)

1 General safety precautions
Installer reference guide
5
FTXTA30A2V1BW
Split system air conditioner
4P518023-6E – 2019.04
(c) Floor-standing unit (= Floor-standing unit)
1.2.3 Refrigerant
If applicable. See the installation manual or installer reference guide
of your application for more information.
NOTICE
Make sure refrigerant piping installation complies with
applicable legislation. In Europe, EN378 is the applicable
standard.
NOTICE
Make sure the field piping and connections are NOT
subjected to stress.
WARNING
During tests, NEVER pressurize the product with a
pressure higher than the maximum allowable pressure (as
indicated on the nameplate of the unit).
WARNING
Take sufficient precautions in case of refrigerant leakage. If
refrigerant gas leaks, ventilate the area immediately.
Possible risks:
▪ Excessive refrigerant concentrations in a closed room
can lead to oxygen deficiency.
▪ Toxic gas may be produced if refrigerant gas comes
into contact with fire.
DANGER: RISK OF EXPLOSION
Pump down – Refrigerant leakage. If you want to pump
down the system, and there is a leak in the refrigerant
circuit:
▪ Do NOT use the unit's automatic pump down function,
with which you can collect all refrigerant from the
system into the outdoor unit. Possible consequence:
Self-combustion and explosion of the compressor
because of air going into the operating compressor.
▪ Use a separate recovery system so that the unit's
compressor does NOT have to operate.
WARNING
ALWAYS recover the refrigerant. Do NOT release them
directly into the environment. Use a vacuum pump to
evacuate the installation.
NOTICE
After all the piping has been connected, make sure there is
no gas leak. Use nitrogen to perform a gas leak detection.
NOTICE
▪ To avoid compressor breakdown, do NOT charge more
than the specified amount of refrigerant.
▪ When the refrigerant system is to be opened,
refrigerant MUST be treated according to the applicable
legislation.
WARNING
Make sure there is no oxygen in the system. Refrigerant
may only be charged after performing the leak test and the
vacuum drying.
▪ In case recharge is required, see the nameplate of the unit. It
states the type of refrigerant and necessary amount.
▪ The unit is factory charged with refrigerant and depending on pipe
sizes and pipe lengths some systems require additional charging
of refrigerant.
▪ Only use tools exclusively for the refrigerant type used in the
system, this to ensure pressure resistance and prevent foreign
materials from entering into the system.
▪ Charge the liquid refrigerant as follows:
If Then
A siphon tube is present
(i.e., the cylinder is marked with
"Liquid filling siphon attached")
Charge with the cylinder upright.
A siphon tube is NOT present Charge with the cylinder upside
down.
▪ Open refrigerant cylinders slowly.
▪ Charge the refrigerant in liquid form. Adding it in gas form may
prevent normal operation.
CAUTION
When the refrigerant charging procedure is done or when
pausing, close the valve of the refrigerant tank
immediately. If the valve is NOT closed immediately,
remaining pressure might charge additional refrigerant.
Possible consequence: Incorrect refrigerant amount.
1.2.4 Brine
If applicable. See the installation manual or installer reference guide
of your application for more information.
WARNING
The selection of the brine MUST be in accordance with the
applicable legislation.
WARNING
Take sufficient precautions in case of brine leakage. If
brine leaks, ventilate the area immediately and contact
your local dealer.
WARNING
The ambient temperature inside the unit can get much
higher than that of the room, e.g. 70°C. In case of a brine
leak, hot parts inside the unit can create a hazardous
situation.
WARNING
The use and installation of the application MUST comply
with the safety and environmental precautions specified in
the applicable legislation.
1.2.5 Water
If applicable. See the installation manual or installer reference guide
of your application for more information.
NOTICE
Make sure water quality complies with EU directive
98/83EC.

2 About the documentation
Installer reference guide
6
FTXTA30A2V1BW
Split system air conditioner
4P518023-6E – 2019.04
1.2.6 Electrical
DANGER: RISK OF ELECTROCUTION
▪ Turn OFF all power supply before removing the
switch box cover, connecting electrical wiring or
touching electrical parts.
▪ Disconnect the power supply for more than 1 minute,
and measure the voltage at the terminals of main circuit
capacitors or electrical components before servicing.
The voltage MUST be less than 50 V DC before you
can touch electrical components. For the location of the
terminals, see the wiring diagram.
▪ Do NOT touch electrical components with wet hands.
▪ Do NOT leave the unit unattended when the service
cover is removed.
WARNING
If NOT factory installed, a main switch or other means for
disconnection, having a contact separation in all poles
providing full disconnection under overvoltage category III
condition, MUST be installed in the fixed wiring.
WARNING
▪ ONLY use copper wires.
▪ Make sure the field wiring complies with the applicable
legislation.
▪ All field wiring MUST be performed in accordance with
the wiring diagram supplied with the product.
▪ NEVER squeeze bundled cables and make sure they
do NOT come in contact with the piping and sharp
edges. Make sure no external pressure is applied to the
terminal connections.
▪ Make sure to install earth wiring. Do NOT earth the unit
to a utility pipe, surge absorber, or telephone earth.
Incomplete earth may cause electrical shock.
▪ Make sure to use a dedicated power circuit. NEVER
use a power supply shared by another appliance.
▪ Make sure to install the required fuses or circuit
breakers.
▪ Make sure to install an earth leakage protector. Failure
to do so may cause electric shock or fire.
▪ When installing the earth leakage protector, make sure
it is compatible with the inverter (resistant to high
frequency electric noise) to avoid unnecessary opening
of the earth leakage protector.
CAUTION
When connecting the power supply, the earth connection
must be made before the current-carrying connections are
established. When disconnecting the power supply, the
current-carrying connections must be separated before the
earth connection is. The length of the conductors between
the power supply stress relief and the terminal block itself
must be as such that the current-carrying wires are
tautened before the earth wire is in case the power supply
is pulled loose from the stress relief.
NOTICE
Precautions when laying power wiring:
▪ Do NOT connect wiring of different thicknesses to the
power terminal block (slack in the power wiring may
cause abnormal heat).
▪ When connecting wiring which is the same thickness,
do as shown in the figure above.
▪ For wiring, use the designated power wire and connect
firmly, then secure to prevent outside pressure being
exerted on the terminal board.
▪ Use an appropriate screwdriver for tightening the
terminal screws. A screwdriver with a small head will
damage the head and make proper tightening
impossible.
▪ Over-tightening the terminal screws may break them.
WARNING
▪ After finishing the electrical work, confirm that each
electrical component and terminal inside the electrical
components box is connected securely.
▪ Make sure all covers are closed before starting up the
unit.
NOTICE
Only applicable if the power supply is three‑phase, and the
compressor has an ON/OFF starting method.
If there exists the possibility of reversed phase after a
momentary black out and the power goes on and off while
the product is operating, attach a reversed phase
protection circuit locally. Running the product in reversed
phase can break the compressor and other parts.
2 About the documentation
2.1 About this document
INFORMATION
Make sure that the user has the printed documentation and
ask him/her to keep it for future reference.
Target audience
Authorised installers
INFORMATION
This appliance is intended to be used by expert or trained
users in shops, in light industry, and on farms, or for
commercial and household use by lay persons.
WARNING
Make sure installation, servicing, maintenance, repair and
applied materials follow the instructions from Daikin and, in
addition, comply with applicable legislation and are
performed by qualified persons only. In Europe and areas
where IEC standards apply, EN/IEC 60335-2-40 is the
applicable standard.
Documentation set
This document is part of a documentation set. The complete set
consists of:

3 About the box
Installer reference guide
7
FTXTA30A2V1BW
Split system air conditioner
4P518023-6E – 2019.04
▪General safety precautions:
▪ Safety instructions that you MUST read before installing
▪ Format: Paper (in the box of the indoor unit)
▪Indoor unit installation manual:
▪ Installation instructions
▪ Format: Paper (in the box of the indoor unit)
▪Installer reference guide:
▪ Preparation of the installation, good practices, reference data,…
▪ Format: Digital files on http://www.daikineurope.com/support-
and-manuals/product-information/
Latest revisions of the supplied documentation may be available on
the regional Daikin website or via your dealer.
The original documentation is written in English. All other languages
are translations.
Technical engineering data
▪ A subset of the latest technical data is available on the regional
Daikin website (publicly accessible).
▪ The full set of latest technical data is available on the Daikin
extranet (authentication required).
2.2 Installer reference guide at a
glance
Chapter Description
General safety
precautions
Safety instructions that you MUST read
before installing
About the documentation What documentation exists for the
installer
About the box How to unpack the units and remove
their accessories
About the unit ▪ System layout
▪ Operation range
▪ About the wireless adapter
Preparation What to do and know before going
on‑site
Installation What to do and know to install the
system
Configuration What to do and know to configure the
system after it is installed
Commissioning What to do and know to commission the
system after it is configured
Hand‑over to the user What to give and explain to the user
Disposal How to dispose of the system
Technical data Specifications of the system
Glossary Definition of terms
3 About the box
3.1 Overview: About the box
This chapter describes what you have to do after the box with the
indoor unit is delivered on-site.
Keep the following in mind:
▪ At delivery, the unit MUST be checked for damage. Any damage
MUST be reported immediately to the claims agent of the carrier.
▪ Bring the packed unit as close as possible to its final installation
position to prevent damage during transport.
▪ When handling the unit, take into account the following:
Fragile, handle the unit with care.
Keep the unit upright in order to avoid damage.
▪ Prepare the path along which you want to bring the unit inside in
advance.
3.2 Indoor unit
3.2.1 To unpack the indoor unit
3.2.2 To remove the accessories from the
indoor unit
1
2
2
3
1×2× 2× 2×1× 1× 1×1× 1× 1×
edba c f g
2×
j kh i
aInstallation manual
bOperation manual
cGeneral safety precautions
dTitanium apatite deodorizing filter and silver particle filter
(Ag-ion filter)
eIndoor unit fixing screw (M4×12L). Refer to "6.6.3To fix the
unit on the mounting plate"on page18.
fDry battery AAA.LR03 (alkaline) for user interface
gUser interface holder
hUser interface
iMounting plate
jScrew cover
kSpare SSID sticker with release paper (attached to the
unit)

4 About the unit
Installer reference guide
8
FTXTA30A2V1BW
Split system air conditioner
4P518023-6E – 2019.04
▪Spare SSID sticker. Do NOT throw away the spare sticker. Keep
it in a safe place in case it is needed in future (e.g. in case the
front grille was replaced attach it to the new front grille).
4 About the unit
WARNING: FLAMMABLE MATERIAL
The refrigerant inside this unit is mildly flammable.
4.1 System layout
g
f
h
i
d
e
b
c
a
aFront panel
bService cover
cSSID sticker
dAir filter
eIntelligent eye sensor
fCaulk pipe hole gap with putty
gRefrigerant piping, drain hose and interconnection cable
hInsulation tape
iTitanium apatite deodorizing filter and silver particle filter
(Ag-ion filter)
4.2 Operation range
Use the system in the following temperature and humidity ranges for
safe and effective operation.
Operation mode Operation range
Cooling(a)(b) ▪ Outdoor temperature: –10~46°C DB
▪ Indoor temperature: 18~32°C DB
▪ Indoor humidity: ≤80%
Heating(a) ▪ Outdoor temperature: –25~24°C DB
▪ Indoor temperature: 10~30°C DB
Drying(a) ▪ Outdoor temperature: –10~46°C DB
▪ Indoor temperature: 18~32°C DB
▪ Indoor humidity: ≤80%
If operated outside the operation range:
(a) A safety device might stop the operation of the system.
(b) Condensation might occur on the indoor unit and drip.
DB Dry bulb
4.3 About the wireless LAN adapter
For detailed specifications, installation instructions, setting methods,
FAQ, declaration of conformity and the latest version of this manual,
visit http://www.onlinecontroller.daikineurope.com.
INFORMATION
▪ Daikin Industries Czech Republic s.r.o. declares that
the radio equipment type inside of this unit is in
compliance with Directive 2014/53/EU.
▪ This unit is considered as combined equipment
according to the definition of Directive 2014/53/EU.
4.3.1 Precautions when using the wireless
adapter
Do NOT use near:
▪Medical equipment. E.g. persons using cardiac pacemakers or
defibrillators. This product may cause electromagnetic
interference.
▪Auto-control equipment. E.g. automatic doors or fire alarm
equipment. This product may cause faulty behaviour of the
equipment.
▪Microwave oven. It may affect wireless LAN communications.
4.3.2 Basic parameters
Parameter Value
Frequency range 2400MHz~2483.5MHz
Radio protocol IEEE 802.11b/g/n
Radio frequency channel 1~11
Output power 0dBm~18dBm
Effective radiated power 17dBm (11b) / 13dBm (11g) /
12dBm (11n)
Power supply DC 3.3 V / 500 mA
4.3.3 Setting the wireless adapter
The customer is responsible for providing:
▪ Smartphone or tablet with minimum supported version of Android
or iOS, specified on http://www.onlinecontroller.daikineurope.com
▪ Internet line and communicating device such as modem, router
etc.
▪ Wireless LAN access point.
▪ Installed free Daikin Online Controller application.
To install the Daikin Online Controller application
1Open:
▪ Google Play for appliances using Android.
▪ App Store for appliances using iOS.
2Search for Daikin Online Controller.
3Follow the directions on the screen to install.
5 Preparation
5.1 Overview: Preparation
This chapter describes what you have to do and know before going
on-site.
It contains information about:
▪ Preparing the installation site
▪ Preparing the refrigerant piping
▪ Preparing the electrical wiring
5.2 Preparing the installation site
Do NOT install the unit in places often used as work place. In case
of construction works (e.g. grinding works) where a lot of dust is
created, the unit MUST be covered.
Choose an installation location with sufficient space for carrying the
unit in and out of the site.

5 Preparation
Installer reference guide
9
FTXTA30A2V1BW
Split system air conditioner
4P518023-6E – 2019.04
WARNING
The appliance shall be stored so as to prevent mechanical
damage and in a well-ventilated room without continuously
operating ignition sources (e.g. open flames, an operating
gas appliance, or an operating electric heater). The room
size shall be as specified in the General safety precaution.
5.2.1 Installation site requirements of the
indoor unit
INFORMATION
Also read the precautions and requirements in the
"General safety precautions" chapter.
INFORMATION
The sound pressure level is less than 70dBA.
▪Air flow. Make sure nothing blocks the air flow.
▪Drainage. Make sure condensation water can be evacuated
properly.
▪Wall insulation. When conditions in the wall exceed 30°C and a
relative humidity of 80%, or when fresh air is inducted into the
wall, then additional insulation is required (minimum 10 mm
thickness, polyethylene foam).
▪Wall strength. Check whether the wall or the floor is strong
enough to support the weight of the unit. If there is a risk, reinforce
the wall or the floor before installing the unit.
Install power cables at least 1metre away from televisions or radios
to prevent interference. Depending on the radio waves, a distance of
3metres may NOT be sufficient.
▪ Choose a location where the hot/cold air discharged from the unit
or the operation noise, will NOT disturb anyone.
▪Fluorescent lights. When installing a wireless user interface in a
room with fluorescent lights, mind the following to avoid
interference:
▪ Install the wireless user interface as close as possible to the
indoor unit.
▪ Install the indoor unit as far as possible from the fluorescent
lights.
It is NOT recommended to install the unit in the following places
because it may shorten the life of the unit:
▪ Where the voltage fluctuates a lot
▪ In vehicles or vessels
▪ Where acidic or alkaline vapour is present
▪ In places where a mineral oil mist, spray or vapour may be
present in the atmosphere. Plastic parts may deteriorate and fall
off or cause water leakage.
▪ In places where the unit would be in the path of direct sunlight.
▪ In bathrooms.
▪ Sound sensitive areas (e.g. near a bedroom), so that the
operation noise will cause no trouble.
WARNING
Do NOT place objects below the indoor and/or outdoor unit
that may get wet. Otherwise condensation on the unit or
refrigerant pipes, air filter dirt or drain blockage may cause
dripping, and objects under the unit may get dirty or
damaged.
▪Spacing. Install the unit at least 1.8m from the floor and keep the
following requirements in mind for distances from the walls and
the ceiling:
≥50 ≥50
≥30
(mm)
Note: Make sure that there are no obstacles within 500mm under
the signal receiver. They may influence reception performance of the
user interface.
5.3 Preparing refrigerant piping
5.3.1 Refrigerant piping requirements
INFORMATION
Also read the precautions and requirements in the
"General safety precautions" chapter.
NOTICE
The piping and other pressure-containing parts shall be
suitable for refrigerant. Use phosphoric acid deoxidised
seamless copper for refrigerant.
▪ Foreign materials inside pipes (including oils for fabrication) must
be ≤30mg/10m.
Refrigerant piping diameter
Use the same diameters as the connections on the outdoor units:
L1 liquid piping Ø6.4mm
L1 gas piping Ø9.5mm
Refrigerant piping material
▪Piping material: Phosphoric acid deoxidised seamless copper.
▪Flare connections: Only use annealed material.
▪Piping temper grade and thickness:
Outer diameter
(Ø)
Temper grade Thickness (t)(a)
6.4mm (1/4") Annealed (O) ≥0.8mm
t
Ø
9.5mm (3/8") Annealed (O)
(a) Depending on the applicable legislation and the unit's
maximum working pressure (see "PS High" on the unit
name plate), larger piping thickness might be required.
5.3.2 Refrigerant piping insulation
▪ Use polyethylene foam as insulation material:
▪ with a heat transfer rate between 0.041 and 0.052W/mK (0.035
and 0.045kcal/mh°C)
▪ with a heat resistance of at least 120°C
▪ Insulation thickness
Pipe outer diameter
(Øp)
Insulation inner
diameter (Øi)
Insulation thickness
(t)
6.4mm (1/4") 8~10mm ≥10mm
9.5mm (3/8") 12~15mm
Ø
i
Ø
i
t
Ø
p
Ø
p

6 Installation
Installer reference guide
10
FTXTA30A2V1BW
Split system air conditioner
4P518023-6E – 2019.04
If the temperature is higher than 30°C and the humidity is higher
than RH80%, the thickness of the insulation materials should be at
least 20 mm to prevent condensation on the surface of the
insulation.
5.4 Preparing electrical wiring
5.4.1 About preparing electrical wiring
INFORMATION
Also read the precautions and requirements in the
"General safety precautions" chapter.
WARNING
▪ If the power supply has a missing or wrong N-phase,
equipment might break down.
▪ Establish proper earthing. Do NOT earth the unit to a
utility pipe, surge absorber, or telephone earth.
Incomplete earthing may cause electrical shock.
▪ Install the required fuses or circuit breakers.
▪ Secure the electrical wiring with cable ties so that the
cables do NOT come in contact with sharp edges or
piping, particularly on the high-pressure side.
▪ Do NOT use taped wires, stranded conductor wires,
extension cords, or connections from a star system.
They can cause overheating, electrical shock or fire.
▪ Do NOT install a phase advancing capacitor, because
this unit is equipped with an inverter. A phase
advancing capacitor will reduce performance and may
cause accidents.
WARNING
▪ All wiring MUST be performed by an authorised
electrician and MUST comply with the applicable
legislation.
▪ Make electrical connections to the fixed wiring.
▪ All components procured on-site and all electrical
construction MUST comply with the applicable
legislation.
WARNING
ALWAYS use multicore cable for power supply cables.
6 Installation
WARNING
Installation shall be done by an installer, the choice of
materials and installation shall comply with the applicable
legislation. In Europe, EN378 is the applicable standard.
6.1 Overview: Installation
This chapter describes what you have to do and know on-site to
install the system.
Typical workflow
Installation typically consists of the following stages:
1 Mounting the outdoor unit.
2 Installing the indoor unit.
3 Connecting the refrigerant piping.
4 Checking the refrigerant piping.
5 Charging refrigerant.
6 Connecting the electrical wiring.
7 Finishing the outdoor installation.
8 Finishing the indoor installation.
INFORMATION
For installation of the outdoor unit (mounting the outdoor
unit, connecting the refrigerant piping to the outdoor unit,
charging refrigerant, connecting the electrical wiring to the
outdoor unit …), see the installation manual of the outdoor
unit.
6.2 Opening the indoor unit
6.2.1 To open the front panel
1Hold the front panel on both sides and open it.
2Pull down both locks on the back of the front panel.
3Open the front panel until the support fits into the fixing tab.
ad
c
b
aLock (1 on each side)
bBackside of the front panel
cFixing tab
dSupport
6.2.2 To close the front panel
1Lift the front panel slightly and remove the support from the
fixing tab.
a
b
c
aBackside of the front panel
bFixing tab
cSupport
2Close the front panel.

6 Installation
Installer reference guide
11
FTXTA30A2V1BW
Split system air conditioner
4P518023-6E – 2019.04
3Gently press the front panel down until it clicks.
6.2.3 To remove the front panel
INFORMATION
Remove the front panel only in case it MUST be replaced.
1Open the front panel. See "6.2.1 To open the front panel" on
page10.
2Open the panel locks located on the back side of the panel
(1on each side).
a a
aPanel lock
3Push the right arm lightly to the right to disconnect the shaft
from the shaft slot on the right side.
a
c
b
aArm
bShaft
cShaft slot
4Disconnect the front panel shaft from the shaft slot on the left
side.
a
c
b
aArm
bShaft slot
cShaft
5Remove the front panel.
6To re-install the front panel perform the steps in the opposite
order.
6.2.4 To open the service cover
1Remove 1 screw from the service cover.
2Pull out the service cover horizontally away from the unit.
a
b
aService cover screw
bService cover
NOTICE
When closing the service cover, make sure that the
tightening torque does NOT exceed 1.4(±0.2)N•m.
6.2.5 To remove the front grille
CAUTION
Wear protective gloves.
1Open the front panel. Refer to "6.2.1 To open the front
panel"on page10.
2Remove the service cover. Refer to "6.2.4To open the service
cover"on page11.
3Remove the wire harness from the wire clamp and the
connector.
4Remove the flap by pushing it to the left side and towards you.
5Remove the 2 screw covers using a long flat plate such as a
ruler wrapped in a cloth and remove 2 screws.
c
d
b
a
aConnector
bWire clamp
cScrew cover
dLong flat plate wrapped in a cloth
6Push the front grille up and then towards the mounting plate to
remove the front grille from the 3 hooks.
a
aHook
Prerequisite: If working space is limited.
7Insert a flat screwdriver next to the hooks.
8Pull the front grille up using the flat screwdriver and push
towards the mounting plate.

6 Installation
Installer reference guide
12
FTXTA30A2V1BW
Split system air conditioner
4P518023-6E – 2019.04
b
a
aHook
bFlat screwdriver
6.2.6 To re-install the front grille
1Install the front grille and firmly engage the 3 upper hooks.
2Tighten the 2 screws and put the 2 screw covers back.
3Re-install the flap.
4Insert the wire harness back into the connector and secure it
with the wire clamp.
5Close the front panel. Refer to "6.2.2 To close the front
panel"on page10.
6.2.7 To remove the electrical wiring box cover
1Remove the front grille.
2Remove 1 screw from the electrical wiring box.
3Open the electrical wiring box cover by pulling it to the front.
4Remove the electrical wiring box cover from the 2 rear hooks.
1
2
b
a
c
c
aScrew
bElectrical wiring box
cRear hook
5To re-install the cover, first attach the electrical wiring box to the
hooks, close the electrical wiring box, and re-install the screw.
NOTICE
When closing the electrical wiring box cover, make sure
that the tightening torque does NOT exceed
2.0(±0.2)N•m.
6.3 Installing the indoor unit
6.3.1 Precautions when installing the indoor
unit
INFORMATION
Also read the precautions and requirements in the
following chapters:
▪ General safety precautions
▪ Preparation
6.3.2 To install the mounting plate
1Install the mounting plate temporarily.
2Level the mounting plate.
3Mark the centres of the drilling points on the wall using a tape
measure. Position the end of tape measure at symbol " ".
4Finish the installation by securing the mounting plate on the wall
using M4×25L screws (field supply).
INFORMATION
The removed pipe port cover can be kept in the mounting
plate pocket.

6 Installation
Installer reference guide
13
FTXTA30A2V1BW
Split system air conditioner
4P518023-6E – 2019.04
(mm)
44.5
605
17
110
798
150
155
44.5
Ø65
Ø65
d
gg
a
e
d
a
f
f
bca a
a
a
a
a
h
± 610
± 605
± 555
kji
aRecommended mounting plate fixing spots
bPocket for the pipe port cover
cUse tape measure as shown
dTabs for placing a spirit level
eUnit center
fHole for embedded piping Ø65mm
gValue for tape measure
hPosition the end of tape measure at symbol " "
iDrain hose
jLiquid pipe
kGas pipe
6.3.3 To drill a wall hole
CAUTION
For walls containing a metal frame or a metal board, use a
wall embedded pipe and wall cover in the feed-through
hole to prevent possible heat, electrical shock, or fire.
NOTICE
Be sure to seal the gaps around the pipes with sealing
material (field supply), in order to prevent water leakage.
1Bore a 65 mm large feed-through hole in the wall with a
downward slope towards the outside.
2Insert a wall embedded pipe into the hole.
3Insert a wall cover into the wall pipe.
Ø65
ab
c
aWall embedded pipe
bPutty
cWall hole cover
4After completing wiring, refrigerant piping and drain piping, do
NOT forget to seal the gap with putty.
6.3.4 To remove the pipe port cover
To connect the piping on right-side, right-bottom, left-side or left-
bottom, the pipe port cover MUST be removed.
1Cut off the pipe port cover from inside the front grille using a
coping saw.
2Remove any burrs along the cut section using a half round
needle file.
NOTICE
Do NOT use nippers to remove the pipe port cover, as this
would damage the front grille.
6.3.5 To provide drainage
Make sure condensation water can be evacuated properly. This
involves:
▪ General guidelines
▪ Connecting the drain piping to the indoor unit
▪ Checking for water leaks

6 Installation
Installer reference guide
14
FTXTA30A2V1BW
Split system air conditioner
4P518023-6E – 2019.04
General guidelines
▪Pipe length. Keep drain piping as short as possible.
▪Pipe size. If drain hose extension or embedded drain piping is
required, use appropriate parts that match the hose front end.
Ø16
Ø18
NOTICE
▪ Install the drain hose with a downward slope.
▪ Traps are NOT permitted.
▪ Do NOT put the end of the hose in water.
▪Drain hose extension. To extend the drain hose, use a field
supplied hose with inner Ø16 mm. Do NOT forget to use a heat
insulation tube on the indoor section of the extension hose.
aab c
Ø16
Ø16
aDrain hose supplied with the indoor unit
bHeat insulation tube (field supply)
cExtension drain hose
▪Rigid polyvinyl chloride pipe. When connecting a rigid polyvinyl
chloride pipe (nominal Ø13mm) directly to the drain hose as with
embedded piping work, use a field supplied drain socket (nominal
Ø13mm).
a b c
Ø18
aDrain hose supplied with the indoor unit
bDrain socket with nominal Ø13mm (field supply)
cRigid polyvinyl chloride pipe (field supply)
▪Condensation. Take measures against condensation. Insulate
the complete drain piping in the building.
1Insert the drain hose in the drain pipe as shown in the following
figure, so it will NOT be pulled out of the drain pipe.
≥50
mm
To connect the piping on right side, right-back, or
right-bottom
INFORMATION
The factory default is right-side piping. For left-side piping,
remove the piping from the right side and install it on the
left side.
1Attach the drain hose with adhesive vinyl tape to the bottom of
the refrigerant pipes.
2Wrap the drain hose and the refrigerant pipes together using
insulation tape.
A
B
C
ab
ARight-side piping
BRight-bottom piping
CRight-back piping
aRemove the pipe port cover here for right-side piping.
bRemove the pipe port cover here for right-bottom piping.
To connect the piping on left side, left-back, or
left-bottom
INFORMATION
The factory default is right-side piping. For left-side piping,
remove the piping from the right side and install it on the
left side.
1Remove the insulation fixing screw on the right side and
remove the drain hose.
2Remove the drain plug on the left side and attach it to the right
side.
NOTICE
Do NOT apply lubricating oil (refrigerant oil) to the drain
plug when inserting it. The drain plug may deteriorate and
cause drain leakage from the plug.
a
a4mm hexagonal wrench
3Insert the drain hose on the left side and do not forget to tighten
it with the fixing screw; otherwise water leakage may occur.
a
b
a
b
aInsulation fixing screw
bDrain hose
4Attach the drain hose to the refrigerant pipes bottom side using
adhesive vinyl tape.
A
B
C
b
a

6 Installation
Installer reference guide
15
FTXTA30A2V1BW
Split system air conditioner
4P518023-6E – 2019.04
ALeft-side piping
BLeft-back piping
CLeft-bottom piping
aRemove the pipe port cover here for left-side piping.
bRemove the pipe port cover here for left-bottom piping.
To check for water leaks
1Remove the air filters.
2Gradually pour approximately 1l of water in the drain pan, and
check for water leaks.
6.4 Connecting the refrigerant piping
6.4.1 About connecting the refrigerant piping
Before connecting the refrigerant piping
Make sure the outdoor and indoor unit are mounted.
Typical workflow
Connecting the refrigerant piping involves:
▪ Connecting the refrigerant piping to the indoor unit
▪ Connecting the refrigerant piping to the outdoor unit
▪ Insulating the refrigerant piping
▪ Keeping in mind the guidelines for:
▪ Pipe bending
▪ Flaring pipe ends
▪ Using the stop valves
6.4.2 Precautions when connecting the
refrigerant piping
INFORMATION
Also read the precautions and requirements in the
following chapters:
▪ General safety precautions
▪ Preparation
DANGER: RISK OF BURNING
CAUTION
▪ Use the flare nut fixed to the unit.
▪ To prevent gas leakage, apply refrigeration oil only to
the inside of the flare. Use refrigeration oil for R32.
▪ Do NOT reuse joints.
CAUTION
▪ Do NOT use mineral oil on flared part.
▪ NEVER install a drier to this R32 unit to guarantee its
lifetime. The drying material may dissolve and damage
the system.
NOTICE
Take the following precautions on refrigerant piping into
account:
▪ Avoid anything but the designated refrigerant to get
mixed into the refrigerant cycle (e.g. air).
▪ Only use R32 when adding refrigerant.
▪ Only use installation tools (e.g. manifold gauge set) that
are exclusively used for R32 installations to withstand
the pressure and to prevent foreign materials (e.g.
mineral oils and moisture) from mixing into the system.
▪ Install the piping so that the flare is NOT subjected to
mechanical stress.
▪ Protect the piping as described in the following table to
prevent dirt, liquid or dust from entering the piping.
▪ Use caution when passing copper tubes through walls
(see figure below).
Unit Installation period Protection method
Outdoor unit >1month Pinch the pipe
<1month Pinch or tape the pipe
Indoor unit Regardless of the
period
INFORMATION
Do NOT open the refrigerant stop valve before checking
the refrigerant piping. When you need to charge additional
refrigerant it is recommended to open the refrigerant stop
valve after charging.
6.4.3 Guidelines when connecting the
refrigerant piping
Take the following guidelines into account when connecting pipes:
▪ Coat the flare inner surface with ether oil or ester oil when
connecting a flare nut. Tighten 3 or 4 turns by hand, before
tightening firmly.
▪ ALWAYS use 2 wrenches together when loosening a flare nut.
▪ ALWAYS use a spanner and torque wrench together to tighten the
flare nut when connecting the piping. This to prevent nut cracking
and leaks.
a
b
c
d
aTorque wrench
bSpanner
cPiping union
dFlare nut

6 Installation
Installer reference guide
16
FTXTA30A2V1BW
Split system air conditioner
4P518023-6E – 2019.04
Piping size
(mm)
Tightening
torque (N•m)
Flare
dimensions (A)
(mm)
Flare shape
(mm)
Ø6.4 15~17 8.7~9.1
R=
0.4~0.8
±2
45°
90°±2
A
Ø9.5 33~39 12.8~13.2
6.4.4 Pipe bending guidelines
Use a pipe bender for bending. All pipe bends should be as gentle
as possible (bending radius should be 30~40mm or larger).
6.4.5 To flare the pipe end
CAUTION
▪ Incomplete flaring may cause refrigerant gas leakage.
▪ Do NOT re-use flares. Use new flares to prevent
refrigerant gas leakage.
▪ Use flare nuts that are included with the unit. Using
different flare nuts may cause refrigerant gas leakage.
1Cut the pipe end with a pipe cutter.
2Remove burrs with the cut surface facing down so that the
chips do NOT enter the pipe.
a b
aCut exactly at right angles.
bRemove burrs.
3Remove the flare nut from the stop valve and put the flare nut
on the pipe.
4Flare the pipe. Set exactly at the position as shown in the
following figure.
A
Flare tool for R32
(clutch type)
Conventional flare tool
Clutch type
(Ridgid-type)
Wing nut type
(Imperial-type)
A 0~0.5mm 1.0~1.5mm 1.5~2.0mm
5Check that the flaring is properly made.
a b
c
aFlare’s inner surface MUST be flawless.
bThe pipe end MUST be evenly flared in a perfect circle.
cMake sure the flare nut is fitted.
6.4.6 To connect the refrigerant piping to the
indoor unit
▪Pipe length. Keep refrigerant piping as short as possible.
▪Flare connections. Connect refrigerant piping to the unit using
flare connections.
▪Insulation. Insulate the refrigerant piping, interconnection cable
and drain hose on the indoor unit as follows:
c
a
b
f
d
g
e
aGas pipe
bGas pipe insulation
cInterconnection cable
dLiquid pipe
eLiquid pipe insulation
fFinishing tape
gDrain hose
NOTICE
Make sure to insulate all refrigerant piping. Any exposed
piping might cause condensation.
6.5 Connecting the electrical wiring
6.5.1 About connecting the electrical wiring
Typical workflow
Connecting the electrical wiring typically consists of the following
stages:
1 Making sure the power supply system complies with the
electrical specifications of the units.
2 Connecting the electrical wiring to the outdoor unit.
3 Connecting the electrical wiring to the indoor unit.
4 Connecting the main power supply.
6.5.2 Precautions when connecting the
electrical wiring
INFORMATION
Also read the precautions and requirements in the
following chapters:
▪ General safety precautions
▪ Preparation
DANGER: RISK OF ELECTROCUTION
WARNING
ALWAYS use multicore cable for power supply cables.
WARNING
Use an all-pole disconnection type breaker with at least
3 mm between the contact point gaps that provide full
disconnection under overvoltage category III.
WARNING
If the supply cord is damaged, it MUST be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
WARNING
Do NOT connect the power supply to the indoor unit. This
could result in electrical shock or fire.
WARNING
▪ Do NOT use locally purchased electrical parts inside
the product.
▪ Do NOT branch the power supply for the drain pump,
etc. from the terminal block. This could result in
electrical shock or fire.

6 Installation
Installer reference guide
17
FTXTA30A2V1BW
Split system air conditioner
4P518023-6E – 2019.04
WARNING
Keep the interconnection wiring away from copper pipes
without thermal insulation as such pipes will be very hot.
6.5.3 Guidelines when connecting the electrical
wiring
Keep the following in mind:
▪ If stranded conductor wires are used, install a round crimp-style
terminal on the end of the wire. Place the round crimp-style
terminal on the wire up to the covered part and fasten the terminal
with the appropriate tool.
b a
aStranded conductor wire
bRound crimp-style terminal
▪ Use the following methods for installing wires:
Wire type Installation method
Single-core wire
c b
c
aa
A
AA´
A´
a Curled single-core wire
b Screw
c Flat washer
Stranded conductor
wire with round
crimp-style terminal
c b ba c
a
B
B
a Terminal
b Screw
c Flat washer
O Allowed
X NOT allowed
▪ If single-core wires are used, be sure to curl the end of the lead.
Improper work may cause heat or fire.
▪ The earth wire between the wire retainer and the terminal must be
longer than the other wires.
1-3
6.5.4 Specifications of standard wiring
components
Component
Interconnection cable
(indoor↔outdoor)
4-core cable
1.5mm²~2.5mm²
andapplicable for
220~240V
H05RN-F (60245 IEC 57)
6.5.5 To connect the electrical wiring on the
indoor unit
Electrical work should be carried out in accordance with the
installation manual and the national electrical wiring rules or code of
practice.
1Set the indoor unit on the mounting plate hooks. Use the " "
marks as a guide.
c
a
b
d
aMounting plate (accessory)
bPiece of packing material
cInterconnection cable
dWire guide
INFORMATION
Support the unit using a piece of packing material.
2Open the front panel, and then the service cover. Refer to
"6.2Opening the indoor unit"on page10.
3Pass the interconnection cable from the outdoor unit through
the feed-through wall hole, through the back of the indoor unit
and through the front side.
Note: In case the interconnection cable was stripped in advance,
cover the ends with insulating tape.
4Bend the end of the cable up.
NOTICE
▪ Be sure to keep the power line and transmission line
apart from each other. Transmission wiring and power
supply wiring may cross, but may NOT run parallel.
▪ In order to avoid any electrical interference the distance
between both wirings should ALWAYS be at least
50mm.
WARNING
Provide adequate measures to prevent that the unit can be
used as a shelter by small animals. Small animals that
make contact with electrical parts can cause malfunctions,
smoke or fire.
a
b
c
aTerminal block
bElectrical component block
cWire retainer
5Strip the wire ends approximately 15mm.
6Match wire colours with terminal numbers on the indoor unit
terminal blocks and firmly screw the wires to the corresponding
terminals.
7Connect the earth wire to the corresponding terminal.
8Firmly fix the wires with the terminal screws.
9Pull the wires to make sure that they are securely attached,
then retain the wires with the wire retainer.
10 Shape the wires so that the service cover fits securely, then
close the service cover.

7 Configuration
Installer reference guide
18
FTXTA30A2V1BW
Split system air conditioner
4P518023-6E – 2019.04
6.5.6 To connect optional accessories (wired
user interface, central user interface, etc.)
1Remove the electrical wiring box cover (refer to "6.2.7 To
remove the electrical wiring box cover"on page12).
2Attach the connection cable to the S21 connector and pull the
wire harness as shown in the following figure.
a
aS21 connector
3Put the electrical wiring box cover back and pull the wire
harness around it as shown in the figure above.
6.6 Finishing the indoor unit
installation
6.6.1 To insulate the drain piping, refrigerant
piping and interconnection cable
1After the drain piping, refrigerant piping and the electrical wiring
are finished. Wrap refrigerant pipes, interconnection cable and
drain hose together using insulation tape. Overlap at least half
the width of the tape with each turn.
d
e
c
b
f
a
2×
aDrain hose
bInterconnection cable
cMounting plate (accessory)
dRefrigerant pipes
eIndoor unit fixing screw M4×12L (accessory)
fBottom frame
6.6.2 To pass the pipes through the wall hole
1Shape the refrigerant pipes along the pipe path marking on the
mounting plate.
ccde
a
b
aDrain hose
bCaulk this hole with putty or caulking material.
cAdhesive vinyl tape
dInsulation tape
eMounting plate (accessory)
NOTICE
▪ Do NOT bend refrigerant pipes.
▪ Do NOT push the refrigerant pipes onto the bottom
frame or the front grille.
2Pass the drain hose and refrigerant pipes through the wall hole.
6.6.3 To fix the unit on the mounting plate
1Set the indoor unit on the mounting plate hooks. Use the " "
marks as a guide.
2Press the bottom frame of the unit with both hands to set it on
the bottom hooks of the mounting plate. Make sure that the
wires do NOT get squeezed anywhere.
Note: Take care that the interconnection cable does NOT get
caught in the indoor unit.
3Press the bottom edge of the indoor unit with both hands until it
is firmly caught by the mounting plate hooks.
4Secure the indoor unit to the mounting plate using 2 indoor unit
fixing screws M4×12L (accessory).
6.6.4 To install the screw covers
1Open the front panel and turn the flap up.
2Install both screw covers (1 on each side).
1
2
3Return flap to its original position and close the front panel.
7 Configuration
7.1 To set a different address
In case 2 indoor units are installed in 1 room, different addresses for
2 user interfaces can be set.
1Remove the cover and the batteries from the user interface.
2Cut the address jumper J4.

8 Commissioning
Installer reference guide
19
FTXTA30A2V1BW
Split system air conditioner
4P518023-6E – 2019.04
a
aAddress jumper J4
NOTICE
Be careful NOT to damage any of the surrounding parts
when cutting the address jumper.
3Turn the power supply on.
4Press and simultaneously.
5Press , select and press .
Result: The operation lamp will start to blink.
a
aIndoor unit ON/OFF switch and operation lamp
6Press the indoor unit ON/OFF switch while the operation lamp
is blinking.
Address jumper Address
Factory setting 1
After cutting with nippers 2
INFORMATION
If the setting could NOT be completed while the operation
lamp was blinking, repeat the setting process from the
beginning.
7When the setting is complete, keep pressed for at least
5seconds.
Result: The user interface will return to the previous screen.
8 Commissioning
8.1 Overview: Commissioning
This chapter describes what you have to do and know to
commission the system after it is installed.
Typical workflow
Commissioning typically consists of the following stages:
1 Checking the "Checklist before commissioning".
2 Performing a test run for the system.
8.2 Checklist before commissioning
After the installation of the unit, first check the following items. Once
all below checks are fulfilled, the unit MUST be closed, ONLY then
can the unit be powered up.
You read the complete installation instructions, as
described in the installer reference guide.
The indoor units are properly mounted.
The outdoor unit is properly mounted.
Air inlet/outlet
Check that the air inlet and outlet of the unit is NOT
obstructed by paper sheets, cardboard, or any other
material.
There are NO missing phases or reversed phases.
The refrigerant pipes (gas and liquid) are thermally
insulated.
Drainage
Make sure drainage flows smoothly.
Possible consequence: Condensate water might drip.
The system is properly earthed and the earth terminals
are tightened.
The fuses or locally installed protection devices are
installed according to this document, and have NOT been
bypassed.
The power supply voltage matches the voltage on the
identification label of the unit.
The specified wires are used for the interconnection
cable.
The indoor unit receives the signals of the user interface.
There are NO loose connections or damaged electrical
components in the switchbox.
The insulation resistance of the compressor is OK.
There are NO damaged components or squeezed
pipes on the inside of the indoor and outdoor units.
There are NO refrigerant leaks.
The correct pipe size is installed and the pipes are
properly insulated.
The stop valves (gas and liquid) on the outdoor unit are
fully open.
8.3 To perform a test run
Prerequisite: Power supply MUST be in the specified range.
Prerequisite: Test run may be performed in cooling or heating
mode.
Prerequisite: Test run should be performed in accordance with the
operation manual of the indoor unit to make sure that all functions
and parts are working properly.
1In cooling mode, select the lowest programmable temperature.
In heating mode, select the highest programmable temperature.
Test run can be disabled if necessary.
2When the test run is finished, set the temperature to a normal
level. In cooling mode: 26~28°C, in heating mode: 20~24°C.
3The system stops operating 3 minutes after the unit is turned
OFF.

9 Hand-over to the user
Installer reference guide
20
FTXTA30A2V1BW
Split system air conditioner
4P518023-6E – 2019.04
8.3.1 To perform a test run using the user
interface
1Press to switch the system on.
2Press and simultaneously.
3Press , select and press .
Result: Test run operation will stop automatically after about
30minutes.
4To stop operation sooner, press .
9 Hand-over to the user
Once the test run is finished and the unit operates properly, please
make sure the following is clear for the user:
▪ Make sure that the user has the printed documentation and ask
him/her to keep it for future reference. Inform the user that he can
find the complete documentation at the URL mentioned earlier in
this manual.
▪ Explain the user how to properly operate the system and what to
do in case of problems.
▪ Show the user what to do for the maintenance of the unit.
10 Disposal
NOTICE
Do NOT try to dismantle the system yourself: dismantling
of the system, treatment of the refrigerant, oil and other
parts MUST comply with applicable legislation. Units
MUST be treated at a specialised treatment facility for
reuse, recycling and recovery.
11 Technical data
A subset of the latest technical data is available on the regional Daikin website (publicly accessible). The full set of latest technical data is
available on the Daikin Business Portal (authentication required).
11.1 Wiring diagram
The wiring diagram is delivered with the unit, located inside of the outdoor unit (bottom side of the top plate).
11.1.1 Unified wiring diagram legend
For applied parts and numbering, refer to the wiring diagram on the
unit. Part numbering is by Arabic numbers in ascending order for
each part and is represented in the overview below symbol "*" in the
part code.
Symbol Meaning Symbol Meaning
Circuit breaker Protective earth
Connection Protective earth
(screw)
,
Connector
A
Rectifier
Earth Relay connector
Field wiring Short-circuit
connector
Fuse Terminal
INDOOR
Indoor unit Terminal strip
OUTDOOR
Outdoor unit Wire clamp
Symbol Colour Symbol Colour
BLK Black ORG Orange
BLU Blue PNK Pink
BRN Brown PRP, PPL Purple
GRN Green RED Red
GRY Grey WHT White
YLW Yellow
Symbol Meaning
A*P Printed circuit board
BS* Pushbutton ON/OFF, operation
switch
BZ, H*C Buzzer
C* Capacitor
Symbol Meaning
AC*, CN*, E*, HA*, HE*, HL*,
HN*, HR*, MR*_A, MR*_B, S*, U,
V, W, X*A, K*R_*
Connection, connector
D*, V*D Diode
DB* Diode bridge
DS* DIP switch
E*H Heater
FU*, F*U, (for characteristics,
refer to PCB inside your unit)
Fuse
FG* Connector (frame ground)
H* Harness
H*P, LED*, V*L Pilot lamp, light emitting diode
HAP Light emitting diode (service
monitor green)
HIGH VOLTAGE High voltage
IES Intelligent eye sensor
IPM* Intelligent power module
K*R, KCR, KFR, KHuR, K*M Magnetic relay
L Live
L* Coil
L*R Reactor
M* Stepper motor
M*C Compressor motor
M*F Fan motor
M*P Drain pump motor
M*S Swing motor
MR*, MRCW*, MRM*, MRN* Magnetic relay
N Neutral
n=*, N=* Number of passes through ferrite
core
PAM Pulse-amplitude modulation
PCB* Printed circuit board
