Daikin FWB Series User manual

INSTALLATION AND OPERATION MANUAL
Installation and operation manual
Ducted fan coil units
English
Installations- und Bedienungsanleitung
Kanal-Ventilator-Konvektoren
Deutsch
Manuel d'installation et d'utilisation
Ventilo-convecteurs canalisés
Français
Montagehandleiding en gebruiksaanwijzing
Ventilator-convectoren met kanaalaansluiting
Nederlands
Manual de instalación y operación
Fan coils de conductos
Español
Manuale d'installazione e d'uso
Unità fan coil canalizzata
Italiano
∂Á¯ÂÈÚ›‰ÈÔ ÂÁηٿÛÙ·Û˘ Î·È ÏÂÈÙÔ˘ÚÁ›·˜
∫ÏÈÌ·ÙÈÛÙÈΤ˜ ÌÔÓ¿‰Â˜ Ì ·ÂÚ·ÁˆÁÔ‡˜
EÏÏËÓÈο
Manual de instalação e de funcionamento
Ventilo-convectores de conduta
Portugues
Инструкция по монтажу и эксплуатации
Канальные фанкойлы
русский
FWB
Ducted fan coil units
1D_I+OM_4PW24344-1.book Page 1 Wednesday, October 5, 2005 10:08 AM

239
93.5
158.5
96.5
147.5
189
C
36
69
66.5
40
10.5
608.5 A
23.5
85155269.5
16.516.5
B
A
A
FWB02~04
FWB05~07
FWB08~10
709
814
1039
1
6
2
4
3 5
7 8
1
2
3
5
4
OUT
IN
236
10
10
1
2+5
3+4
1
2+5
3+4
66
1 8
2
3
54x 6 78
4
M
1~
RD
BN
GN
BU
YE
GY
BK
WH
4
7
6
5
3
VC
L
N
1
2
VH
3/7
VH
VC
V3
V2
V1
L
N
N
N
RE
V
RM
RM
EX
EX
SW
PE
SA
ECFWER6
RM
RM
EXT
CRHC
ECFWER6
L
ILF
230 V 1~ 50 Hz
N
RHC
RM
RM
ECFWER6
N
IL
F230 V 1~ 50 Hz
L
1D_I+OM_4PW24344-1.book Page 1 Wednesday, October 5, 2005 10:08 AM

Zandvoordestraat 300, B-8400 Oostende, Belgium
Daikin Europe N.V.
EN60335-1, EN60335-2-30, EN60204-1, EN55014-1, EN55014-2, EN61000-3-2, EN61000-3-3, EN61000-4-2, EN61000-4-4, EN61000-4-5, EN61000-4-11
Toshitaka Tsubouchi Director, General Manager Sales Division Ostend, 1st of September 2005
CE - DECLARATION-OF-CONFORMITY CE - KONFORMITÄTSERKLÄRUNG CE - DECLARATION-DE-CONFORMITE CE - CONFORMITEITSVERKLARING
CE - DECLARACION-DE-CONFORMIDAD CE - DICHIARAZIONE-DI-CONFORMITA
CE - ¢H§ø™H ™YMMOPºø™H™
CE - DECLARAÇÃO-DE-CONFORMIDADE СЕ - ЗАЯВЛЕНИЕ-О-СООТВЕТСТВИИ CE - OPFYLDELSESERKLÆRING CE - FÖRSÄKRAN-OM-ÖVERENSTÄMMELSE
CE - ERKLÆRING OM-SAMSVAR CE - ILMOITUS-YHDENMUKAISUUDESTA CE -
PROHLÁŠENÍ-O-SHODĚ
CE -
IZJAVA-O-USKLAĐENOSTI
CE - MEGFELELŐSÉGI-NYILATKOZAT
CE -
DEKLARACJA-ZGODNOŚCI
CE -
DECLARAŢIE-DE-CONFORMITATE
CE - I
ZJAVA O SKLADNOSTI
CE -
VASTAVUSDEKLARATSIOON
CE -
ДЕКЛАРАЦИЯ-ЗА-СЪОТВЕТСТВИЕ
CE -
ATITIKTIES-DEKLARACIJA
CE -
ATBILSTĪBAS-DEKLARĀCIJA
CE -
VYHLÁSENIE-ZHODY
CE - UYUMLULUK-BİLDİRİSİ
01
declares under its sole responsibility that the air conditioning models to which this declar ation relates:
02
erklärt auf seine alleinige Verantwortung daß die Modelle der Klimageräte für die diese Erklärung bestimmt ist:
03
déclare sous sa seule responsabilité que les appareils d'air conditionné visés par la présente déclar ation:
04
verklaart hierbij op eigen exclusieve verantwoordelijkheid dat de airconditioning units waarop deze verklaring betrekking heeft:
05
declara baja su única responsabilidad que los modelos de aire acondicionado a los cuales hace referencia la declaración:
06
dichiara sotto sua responsabilità che i condizionatori modello a cui è riferita questa dichiarazione:
07
‰ËÏÒÓÂÈ Ì ·ÔÎÏÂÈÛÙÈ΋ Ù˘ ¢ı‡ÓË fiÙÈ Ù· ÌÔÓ٤Ϸ ÙˆÓ ÎÏÈÌ·ÙÈÛÙÈÎÒÓ Û˘Û΢ÒÓ ÛÙ· ÔÔ›· ·Ó·Ê¤ÚÂÙ·È Ë ·ÚÔ‡Û· ‰‹ÏˆÛË:
08
declara sob sua exclusiva responsabilidade que os modelos de ar condicionado a que esta declaração se refere:
09
заявляет, исключительно под свою ответственность, что модели кондиционеров воздуха, к которым относится настоящее заявление:
10
erklærer under eneansvar, at klimaanlægmodellerne, som denne deklaration vedrører:
11
deklarerar i egenskap av huvudansvarig, att luftkonditioneringsmodellerna som berörs av denna deklaration innebär att:
12
erklærer et fullstendig ansvar for at de luftkondisjoneringsmodeller som berøres av denne deklarasjon innebærer at:
13
ilmoittaa yksinomaan omalla vastuullaan, että tämän ilmoituksen tarkoittamat ilmastointilaitteiden mallit:
14
prohlašuje ve své plné odpovědnosti, že modely klimatizace, k nimž se toto prohlášení vztahuje:
15
izjavljuje pod isključivo vlastitom odgovornošću da su modeli klima uređaja na koje se ova izjava odnosi:
16
teljes felelőssége tudatában kijelenti, hogy a klímaberendezés modellek, melyekre e nyilatkozat vonatkozik:
17
deklaruje na własną i wyłączną odpowiedzialność, że modele klimatyzatorów, których dotyczy niniejsza deklaracja:
18
declară pe proprie răspundere că aparatele de aer condiţionat la care se referă această declaraţie:
19
z vso odgovornostjo izjavlja, da so modeli klimatskih naprav, na katere se izjava nanaša:
20
kinnitab oma täielikul vastutusel, et käesoleva deklaratsiooni alla kuuluvad kliimaseadmete mudelid:
21
декларира на своя отговорност, че моделите климатична инсталация, за които се отнася тази декларация:
22
visiška savo atsakomybe skelbia, kad oro kondicionavimo prietaisų modeliai, kuriems yra taikoma ši deklaracija:
23
ar pilnu atbildību apliecina, ka tālāk uzskaitīto modeĮu gaisa kondicionētāji, uz kuriem attiecas šī deklarācija:
24
vyhlasuje na vlastnú zodpovednosť, že tieto klimatizačné modely, na ktoré sa vzťahuje toto vyhlásenie:
25
tamamen kendi sorumluluğunda olmak üzere bu bildirinin ilgili olduğu klima modellerinin aşağıdaki gibi olduğunu beyan eder:
01
are in conformity with the following standard(s) or other normative document(s), provided that these are used in accordance with our instructions:
02
der/den folgenden Norm(en) oder einem anderen Normdokument oder -dokumenten entspricht/entsprechen, unter der Voraussetzung, daß sie gemäß unseren Anweisungen eingesetzt werden:
03
sont conformes à la/aux norme(s) ou autre(s) document(s) normatif(s), pour autant qu'ils soient utilisés conformément à nos instructions:
04
conform de volgende norm(en) of één of meer andere bindende documenten zijn, op voorwaarde dat ze worden gebruikt overeenkomstig onze instructies:
05
están en conformidad con la(s) siguiente(s) norma(s) u otro(s) documento(s) normativo(s), siempre que sean utilizados de acuerdo con nuestras instrucciones:
06
sono conformi al(i) seguente(i) standard(s) o altro(i) documento(i) a carattere normativo, a patto che vengano usati in conformità alle nostre istruzioni:
07
Â›Ó·È Û‡Ìʈӷ Ì ÙÔ(·) ·ÎfiÏÔ˘ıÔ(·) ÚfiÙ˘Ô(·) ‹ ¿ÏÏÔ ¤ÁÁÚ·ÊÔ(·) ηÓÔÓÈÛÌÒÓ, ˘fi ÙËÓ ÚÔ¸fiıÂÛË fiÙÈ ¯ÚËÛÈÌÔÔÈÔ‡ÓÙ·È Û‡Ìʈӷ Ì ÙȘ Ô‰ËÁ›Â˜ Ì·˜:
08
estão em conformidade com a(s) seguinte(s) norma(s) ou outro(s) documento(s) normativo(s), desde que estes sejam utilizados de acordo com as nossas instruções:
09
соответствуют следующим стандартам или другим нормативным документам, при условии их использования согласно нашим инструкциям:
10
overholder følgende standard(er) eller andet/andre retningsgivende dokument(er), forudsat at disse anvendes i henhold til vore instrukser:
11
respektive utrustning är utförd i överensstämmelse med och följer följande standard(er) eller andra normgivande dokument, under förutsättning att användning sker i överensstämmelse med våra instruktioner:
12
respektive utstyr er i overensstemmelse med følgende standard(er) eller andre normgivende dokument(er), under forutssetning av at disse brukes i henhold til våre instrukser:
13
vastaavat seuraavien standardien ja muiden ohjeellisten dokumenttien vaatimuksia edellyttäen, että niitä käytetään ohjeidemme mukaisesti:
14
za předpokladu, že jsou využívány v souladu s našimi pokyny, odpovídají následujícím normám nebo normativním dokumentům:
15
u skladu sa slijedećim standardom(ima) ili drugim normativnim dokumentom(ima), uz uvjet da se oni koriste u skladu s našim uputama:
16
megfelelnek az alábbi szabvány(ok)nak vagy egyéb irányadó dokumentum(ok)nak, ha azokat előírás szerint használják:
17
spełniają wymogi następujących norm i innych dokumentów normalizacyjnych, pod warunkiem że używane są zgodnie z naszymi instrukcjami:
18
sunt în conformitate cu următorul (următoarele) standard(e) sau alt(e) document(e) normativ(e), cu condiţia ca acestea să fie utilizate în conformitate cu instrucţiunile noastre
19
skladni z naslednjimi standardi in drugimi normativi, pod pogojem, da se uporabljajo v skladu z našimi navodili:
20
on vastavuses järgmis(t)e standardi(te)ga või teiste normatiivsete dokumentidega, kui neid kasutatakse vastavalt meie juhenditele:
21
съответстват на следните стандарти или други нормативни документи, при условие, че се използват съгласно нашите инструкции:
22
atitinka žemiau nurodytus standartus ir (arba) kitus norminius dokumentus su sąlyga, kad yra naudojami pagal mūsų nurodymus:
23
tad, ja lietoti atbilstoši ražotāja norādījumiem, atbilst sekojošiem standartiem un citiem normatīviem dokumentiem:
24
sú v zhode s nasledovnou(ými) normou(ami) alebo iným(i) normatívnym(i) dokumentom(ami), za predpokladu, že sa používajú v súlade s našim návodom:
25
ürünün, talimatlarımıza göre kullanılması koşuluyla aşağıdaki standartlar ve norm belirten belgelerle uyumludur:
01
Directives, as amended.
02
Direktiven, gemäß Änderung.
03
Directives, telles que modifiées.
04
Richtlijnen, zoals geamendeerd.
05
Directivas, según lo enmendado.
06
Direttive, come da modifica.
07
√‰ËÁÈÒv, fiˆ˜ ¤¯Ô˘Ó ÙÚÔÔÔÈËı›.
08
Directivas, conforme alteração em.
09
Директив со всеми поправками.
10
Direktiver, med senere ændringer.
11
Direktiv, med företagna ändringar.
12
Direktiver, med foretatte endringer.
13
Direktiivejä, sellaisina kuin ne ovat muutettuina.
14
v platném znění.
15
Smjernice, kako je izmijenjeno.
16
irányelv(ek) és módosításaik rendelkezéseit.
17
z późniejszymi poprawkami.
18
Directivelor, cu amendamentele respective.
19
Direktive z vsemi spremembami.
20
Direktiivid koos muudatustega.
21
Директиви, с техните изменения.
22
Direktyvose su papildymais.
23
Direktīvās un to papildinājumos.
24
Smernice, v platnom znení.
25
Değiştirilmiş halleriyle Yönetmelikler.
01
following the provisions of:
02
gemäß den Vorschriften der:
03
conformément aux stipulations des:
04
overeenkomstig de bepalingen van:
05
siguiendo las disposiciones de:
06
secondo le prescrizioni per:
07
Ì ًÚËÛË Ùˆv ‰È·Ù¿Íˆv Ùˆv:
08
de acordo com o previsto em:
09
в соответствии с положениями:
10
under iagttagelse af bestemmelserne i:
11
enligt villkoren i:
12
gitt i henhold til bestemmelsene i:
13
noudattaen määräyksiä:
14
za dodržení ustanovení předpisu:
15
prema odredbama:
16
követi a(z):
17
zgodnie z postanowieniami Dyrektyw:
18
în urma prevederilor:
19
ob upoštevanju določb:
20
vastavalt nõuetele:
21
следвайки клаузите на:
22
laikantis nuostatų, pateikiamų:
23
ievērojot prasības, kas noteiktas:
24
održiavajúc ustanovenia:
25
bunun koşullarına uygun olarak:
01 Note
judged positively by
NEMKO AFLAB
according to
the
Certificate
SAF2210-1/02, SAF2210-5/02, SAF2210-2/02, EMC2210-3/02, EMC2210-3A/02, EMC2210-7/02
.
02 Hinweis
wie von
NEMKO AFLAB
positiv ausgezeichnet gemäß
Zertifikat
SAF2210-1/02, SAF2210-5/02, SAF2210-2/02, EMC2210-3/02, EMC2210-3A/02, EMC2210-7/02
.
03 Remarque
tel que jugé positivement par
NEMKO AFLAB
conformément
au
Certificat
SAF2210-1/02, SAF2210-5/02, SAF2210-2/02, EMC2210-3/02, EMC2210-3A/02, EMC2210-7/02
.
04 Bemerk
zoals in orde bevonden door
NEMKO AFLAB
overeenkomstig
Certificaat SAF2210-1/02, SAF2210-5/02, SAF2210-2/02, EMC2210-3/02, EMC2210-3A/02, EMC2210-7/02
.
05 Nota
tal como juzgado positivamente por
NEMKO AFLAB
según
el
Certificado SAF2210-1/02, SAF2210-5/02, SAF2210-2/02, EMC2210-3/02, EMC2210-3A/02, EMC2210-7/02
.
06 Nota
como giudicato positivamente da
NEMKO AFLAB
secondo
il
Certificato
SAF2210-1/02, SAF2210-5/02, SAF2210-2/02, EMC2210-3/02, EMC2210-3A/02, EMC2210-7/02
.
07
™ËÌ›ˆÛË
Ì ÙË ıÂÙÈ΋ ÎÚ›ÔË Ù˘
NEMKO AFLAB
Û‡Ìʈӷ Ì ÙÔ
¶ÈÛÙÔÔÈËÙÈÎfi
SAF2210-1/02, SAF2210-5/02, SAF2210-2/02,
EMC2210-3/02, EMC2210-3A/02, EMC2210-7/02
.
08 Nota
com o parecer positivo de
NEMKO AFLAB
de acordo com o
Certificado
SAF2210-1/02, SAF2210-5/02, SAF2210-2/02,
EMC2210-3/02, EMC2210-3A/02, EMC2210-7/02
.
09 Примечание
в соответствии с положительным решением
NEMKO AFLAB
согласно
Свидетельству
SAF2210-1/02, SAF2210-5/02,
SAF2210-2/02, EMC2210-3/02, EMC2210-3A/02, EMC2210-7/02
.
10 Bemærk
som vurderet positivt af
NEMKO AFLAB
i henhold til
Certifikat SAF2210-1/02, SAF2210-5/02, SAF2210-2/02, EMC2210-3/02, EMC2210-3A/02, EMC2210-7/02
.
11 Information
som av
NEMKO AFLAB
bedömts uppfylla
Certifikat
SAF2210-1/02, SAF2210-5/02, SAF2210-2/02, EMC2210-3/02, EMC2210-
3A/02, EMC2210-7/02
.
12 Merk
gjennom positiv bedømmelse av
NEMKO AFLAB
ifølge
Sertifikat SAF2210-1/02, SAF2210-5/02, SAF2210-2/02, EMC2210-3/
02, EMC2210-3A/02, EMC2210-7/02
.
13 Huom
jotka
NEMKO AFLAB
on hyväksynyt
Sertifikaatin
SAF2210-1/02, SAF2210-5/02, SAF2210-2/02, EMC2210-3/02, EMC2210-3A/02, EMC2210-7/02
mukaisesti.
14 Poznámka
jak bylo pozitivně zjištěno
NEMKO AFLAB
v souladu s
osvědčením
SAF2210-1/02, SAF2210-5/02, SAF2210-2/02, EMC2210-3/02, EMC2210-3A/02, EMC2210-7/02
.
15 Napomena
kako je pozitivno ocijenjeno od strane
NEMKO AFLAB
prema
Certifikatu
SAF2210-1/02, SAF2210-5/02, SAF2210-2/02,
EMC2210-3/02, EMC2210-3A/02, EMC2210-7/02
.
16 Megjegyzés
a megfelelést a(z)
NEMKO AFLAB
igazolta a(z)
SAF2210-1/02, SAF2210-5/02, SAF2210-2/02, EMC2210-3/02, EMC2210-3A/02, EMC2210-7/02
tanúsítvány
szerint.
17 Uwaga
zgodnie z pozytywnà opinià
NEMKO AFLAB
i
Świadectwem
SAF2210-1/02, SAF2210-5/02, SAF2210-2/02, EMC2210-3/02, EMC2210-3A/02, EMC2210-7/02
.
18
Notă
apreciate pozitiv de
NEMKO AFLAB
în conformitate
cu
Certificatul
SAF2210-1/02, SAF2210-5/02, SAF2210-2/02, EMC2210-3/02, EMC2210-3A/02, EMC2210-7/02
.
19 Opomba
ki jo je odobril
NEMKO AFLAB
v skladu s
certifikatom
SAF2210-1/02, SAF2210-5/02, SAF2210-2/02, EMC2210-3/02,
EMC2210-3A/02, EMC2210-7/02
.
20 Märkus
nagu on heaks kiidetud
NEMKO AFLAB
järgi vastavalt
sertifikaadile
SAF2210-1/02, SAF2210-5/02, SAF2210-2/02, EMC2210-3/02, EMC2210-3A/02, EMC2210-7/02
.
21 Забележка
според положителната оценка на
NEMKO AFLAB
съгласно
Сертификат
SAF2210-1/02, SAF2210-5/02, SAF2210-2/02,
EMC2210-3/02, EMC2210-3A/02, EMC2210-7/02
.
22 Pastaba
kaip patvirtino
NEMKO AFLAB
pagal
pažymėjimą
SAF2210-1/02, SAF2210-5/02, SAF2210-2/02, EMC2210-3/02, EMC2210-3A/02, EMC2210-7/02
.
23 Piezīmes
atbilstoši
NEMKO AFLAB
pozitīvajam lēmumam ko apliecina
sertifikāts
SAF2210-1/02, SAF2210-5/02, SAF2210-2/02, EMC2210-3/02, EMC2210-3A/02, EMC2210-7/02
.
24 Poznámka
ako je to kladne posúdené
NEMKO AFLAB
podľa
Certifikátu
SAF2210-1/02, SAF2210-5/02, SAF2210-2/02, EMC2210-3/02, EMC2210-3A/02, EMC2210-7/02
.
25
Not
SAF2210-1/02, SAF2210-5/02, SAF2210-2/02, EMC2210-3/02, EMC2210-3A/02, EMC2210-7/02
sertifikasına
göre
NEMKO
AFLAB
tarafından olumlu olarak değerlendirilmiştir.
.
73/23/EEC
89/336/EEC 89/392/EEC 91/368/EEC
93/44/EEC 93/68/EEC 98/37/EEC
FWB*AATN6V3 *
= 02, 03, 04, 05, 06, 07, 08, 09, 10
1D_I+OM_4PW24344-1.book Page 1 Wednesday, October 5, 2005 10:08 AM

Installation and operation manual
1
FWB
Ducted fan coil units
4PW24344-1
B
EFORE INSTALLATION
Installation and maintenance should be carried out by technical
personnel qualified for this type of machine, in compliance with
current safety regulations.
When receiving the unit please check its state, verifying if any
damage occurred during transport.
Refer to the relevant technical sheets for installation and use of
possible accessories.
Identify model and version of the unit from the indications stated on
the carton package.
U
SE AND OPERATING LIMITS
Daikin shall not be held liable
- if the unit has been installed by non-qualified personnel,
- if the unit has been used improperly,
- if the unit has been used under conditions that are not permitted,
- if maintenance operations specified in this manual have not been
carried out,
- if non original spare parts have been used.
Keep the unit in its packaging until it is ready to be installed, to
prevent dust getting inside.
Air sucked by the unit must always be filtered. Always use the
supplied air filter.
If the unit is not used during winter, drain the water from the system
to prevent damage caused by the formation of ice. If antifreeze
solutions are used, check the freezing point.
Do not change the internal wiring or other parts of the unit.
Operating limits are shown here below; all other uses are considered
improper:
■ thermal carrier: water/glycol
■ water temperature: 5°C~95°C
■ maximum operating pressure: 10 bar
■ air temperature: –20°C~40°C
■ voltage tolerance: ±10%
Selection of location:
■ do not install the unit in rooms where inflammable gases are
present
■ do not let water spray directly on the unit;
■ install the unit on ceilings that bear its weight. Leave enough
space all around for proper operation and maintenance of the
unit, taking into account all installed optional accessories.
■ never place the heating unit immediately under an electric plug-
socket.
D ESCRIPTION OF THE EQUIPMENT
The FWB range of air conditioning and hot-air heating units has been
implemented for conditioning rooms that require the installation of
ducted units.
Main components
■ Load bearing structure made of galvanized steel sheet of
suitable thickness, duly insulated with noise-proof/anti-
condensing material, self-extinguishing in class 1. The unit is
equipped with 4 anti-vibration isolators.
■ Fan unit with single, dual or triple fan wheel, dual intake
centrifugal type, with statically and dynamically balanced
impellers, coupled directly to the 7-speed electric motor,
equipped with permanently fit condenser and thermal safety
device
■ Switch box located at the side of the hydraulic connections in
order to reduce the service space. Electric connection by means
of screw terminal strip .
■ High efficiency 3, 4 or 6 row heat exchanger , made of copper
tube and aluminium fins secured to the tubes by mechanical
expansion. They are fit with brass manifolds and contain air
valves. The heat exchanger, normally supplied with left-hand
attachments, may be turned 180°.
■ System for collecting and discharging condensate ,
extending beyond the hydraulic connections, enabling collection
of condensate from regulating valves eventually. The off-centre
position considerably reduces the required installation space.
■ Air filter made of acrylic material, self-extinguishing in class 1,
with filtering class EU 2. The removable cassette-type filter is
positioned on the air suction inlet and can be pulled out from
below like a drawer.
■ Straight duct connectors on both the air intake and air outlet.
D
IMENSIONS
■ Standard unit (See figure 1)
■ Air filter (See figure 2)
FWB
Ducted fan coil units
Installation and
operation manual
Read this manual attentively before starting up the unit. Do
not throw it away. Keep it in your files for future reference.
Improper installation or attachment of equipment or
accessories could result in electric chock, short-circuit,
leaks, fire or other damage to the equipment. Be sure only
to use accessories made by Daikin which are specifically
designed for the use with the equipment and have them
installed by a professional.
If unsure of installation procedures or use, always contact
your Daikin dealer for advice and information.
1 Water outlet, 3/4" female gas
2 Water inlet, 3/4" female gas
3 Switch box
4 Power supply cable intake holders
5 Condensate drain connection Ø17 mm
1D_I+OM_4PW24344-1.book Page 1 Wednesday, October 5, 2005 10:08 AM

FWB
Ducted fan coil units
4PW24344-1
Installation and operation manual
2
INSTALLATION
Exploded view of the unit (See figure 3)
Configuration of the unit
The heat exchanger connections can be switched over to the
opposite side by carrying out the following procedure. (See figure 4)
Installing the unit
Insert the supplied anti-vibration isolators in the 4 slots indicated for
ceiling installation. Fix the standard unit to the ceiling or wall using at
least 4 of the 8 slots;
■For installation it is advised to use M8 threaded bars, screw
anchors suitable for the unit's weight and to arrange for the
positioning of the unit using 3 M8 bolts (2 in the lower part, and 1
in the upper part as shown in figure 5) and 2 washers the
diameter of which is suitable for inserting the slot and for then
fixing the unit.
Before tightening the lock nut, adjust the closing of the main nut
so that the unit will slant correctly, i.e. for facilitating the
discharging of the condensate (see figure 6).
The correct slant is achieved by tilting the inlet downwards as
compared to the outlet until a difference in level of about 10 mm
is obtained from one end to the other. Make the hydraulic
connections with the heat exchanger and, for cooling operations,
with the condensate discharge. Use one of the 2 drains of the
drip tray, visible on the outside of the unit's side panels.
■To connect the unit to the condensate discharge line, use a
flexible rubber tube and fix it to the chosen discharge tube (Ø3/8")
by means of a metal clamp (use the discharge that is located on the
hydraulic attachments side).
To assist the draining of the condensate, slant the discharge
tube downwards by at least 30 mm/m making sure that its entire
route is clear and free from bendsor blockages.
A few rules to follow
■Purge the air from the heat exchanger, with pumps stopped,
by means of the air valves located adjacent to the
attachments of the heat exchanger itself.
■The ducting, especially the outlet duct, must be insulated
with anti-condensation material.
■Provide an inspection panel adjacent to the equipment for
the maintenance and cleaning operations.
■Install the control panel on the wall. Choose a position that is
easy to access for the setting of the functions and for
detecting of the temperature. Try to avoid positions that are
directly exposed to sun rays, or positions subject to direct hot
or cold air currents. Do not place obstacles in the way that
would prevent the correct reading of the temperature.
FIELD WIRING
Carry out the electrical wiring after having turned the power off. For
options, refer to the appropriate manual.
Check that the power supply corresponds to the nominal power
supply stated on the unit nameplate.
Each unit requires a switch (IL) on the power supply with a distance
of at least 3 mm between the opening contacts and a suitable safety
fuse (F).
Power consumption is shown on the data plate fixed to the unit.
Make sure to carefully execute the wiring in function of the
combination unit/controller and this according to the correct wiring
diagram delivered with every accessory.
In order to make the electrical connections you must remove the
panel covering the switch box (see figure 3) to access the terminal
strip.
The power cables (power supply and control) must be routed to the
terminal strip through the pwer supply cable intake holders on the
side of the switch box.
Wiring diagrams
The motors of the units run at 7 speeds.
The FWB air conditioning and hot-air heating units, the
circuit breaker (IL) and/or the remote control must be
installed out of reach of persons who may be taking a bath
or shower.
1Water drip tray
2Heat exchanger module
3Switch box
4Ter minal strip
5Anti-vibration isolator
67-speed electric motor
7Fan drive assembly
8Straight duct connector
1Remove the straight duct connector.
2Remove the drip tray.
3Remove the heat exchanger module by unscrewing the holding
screws (2 on each side + 3 on the upper side and 2 on the lower
part).
4Turn the heat exchanger module over 180° (vertical axis) and screw
the module back onto the fan module.
5Adjust the position of the drip tray so that the sticking-out part
extends below the hydraulic connections and fix it in place again.
6Screw the straight duct connector back to the heat exchanger
module.
All field wiring and components must be installed by a
licensed electrician and must comply with relevant local
and national regulations.
figure 8 FWB + controller ECFWER6 (FWB02~07)
figure 9 FWB + controller ECFWER6 + power interface EPIA6
(FWB08~10)
figure 10 FWB + controller ECFWER6 + master/slave interface EPIMSA6
The common wire of the motor is the white one (WH).
If the common wire is not connected correctly, the motor
would be damaged irreparably.
1D_I+OM_4PW24344-1.book Page 2 Wednesday, October 5, 2005 10:08 AM

Installation and operation manual
3FWB
Ducted fan coil units
4PW24344-1
Wiring parts table (See figure 8, 9, 10)
BK ................... Black = maximum speed
BU ................... Blue
BN ................... Brown
GY ................... Grey
GN................... Green
YE ................... Yellow
RD ................... Red = minimum speed
WH .................. White = common wire
- - - - ................ Field wiring
F ...................... Fuse (field supply)
IL ..................... Line switch (field supply)
M ..................... Motor
3/7 ................... 3 out of 7 speeds
EPIMSA6......... Master/Slave interface for control of up to 4 FWB
units in parallel
EPIA6.............. Power interface
EXT ................. External auxiliary contact
RHC ................ Remote cooling/heating selector switch (centralised)
VC ................... Cold water valve (230 V ON-OFF)
VH ................... Hot water valve (230 V ON-OFF)
TEST RUN
Check that the equipment has been installed so that it guarantees the
required slant.
Check that the condensate discharge is not clogged (by rubble
deposits, etc.).
Check the seal of the hydraulic connections.
Check that the electrical wiring is perfectly tight (perform this check
with voltage OFF).
Be sure that the air purge of the heat exchanger has been carried out
correctly.
Turn on the power supply and check the unit running.
USE
To use the unit, refer to the instructions in the installation and
operation manual of the controller. Dedicated controllers are
available as accessory.
MAINTENANCE AND CLEANING
For safety reasons before carrying out any maintenance or cleaning
operation, turn off the unit and cut the voltage by turning the line
switch to OFF.
Maintenance
The maintenance operations for the FWB air conditioner and hot-air
heating units are limited to the periodic cleaning of the air filter and
the heat exchanger, and the checking of the working efficiency of the
condensate discharge.
Only skilled personnel may perform the maintenance.
Pay utmost attention during the maintenance operations: accidentally
coming into contact with some of the metallic parts might cause
injuries, therefore use safety work gloves.
Every time the units are started after a long idle period, make sure
that air is NOT present in the heat exchanger.
The motor is maintenance-free since it is equipped with self-
lubricating bearings.
Cleaning the air filter
Cut voltage to the unit by turning the line switch to OFF.
For cleaning the air filter proceed as follows:
■Access the equipment through the inspection panel and remove
the air filter as shown in figure 7 by unscrewing the fixing knobs.
■Wash the filter with lukewarm water or, for dry powders, with
compressed air.
■Reassemble the filter after having it dried up.
Cleaning the heat exchanger
It is advisable to check the condition of the heat exchanger before the
start of the summer season. Also check if the fins are not clogged by
impurities.
To access the heat exchanger, remove the delivery panel and the
condensate tank. Upon having accessed the heat exchanger, clean
with compressed air or low pressure steam, without damaging the
fins of the heat exchanger.
Before operating it in the summer, check the condensate discharges
regularly.
DISPOSAL REQUIREMENTS
Dismantling of the unit should be done in accordance with the
relevant local and national legislation.
TROUBLESHOOTING
If the unit does not work properly first check the points reported in the
table below before requesting service.
If the problem cannot be solved contact your dealer or service centre.
Symptom 1:The unit does not run at all
Symptom 2: Poor cooling or heating performance
Symptom 3:The unit leaks
NOTE Adequate and regular maintenance and cleaning
means energy conservation and cost saving.
POSSIBLE CAUSES CORRECTIVE ACTION
Power failure Restore power
The automatic circuit breaker tripped Contact service centre
The switch is on STOP ("O") position Turn ON the unit, select "I"
POSSIBLE CAUSES CORRECTIVE ACTION
Dirty or clogged air filter Clean the air filter
Obstacle near the air inlet or outlet Remove the obstacle
Air inside the heat exchanger Contact the installer
Doors and windows are open Close doors and windows
The unit is running at low speed Select medium or high fan speed
POSSIBLE CAUSES CORRECTIVE ACTION
The unit is not installed with the
correct inclination Contact the installer
The condensate discharge is
clogged Contact the installer
