Daikin FXAQ20P Instruction manual

FXAQ-P
EEDEN11-204
Air Conditioners
Wall mounted unit
Technical Data
Daikin VRV järjestelmät toimittaa ja asentaa Jäähdytinpalvelu RefGroup Oy

FXAQ-P
EEDEN11-204
Air Conditioners
Wall mounted unit
Technical Data
Daikin VRV järjestelmät toimittaa ja asentaa Jäähdytinpalvelu RefGroup Oy

•VRV
®Systems • Indoor Unit 1
• Indoor Unit • Wall mounted unit • FXAQ-P
TABLE OF CONTENTS
FXAQ-P
1 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2 Safety device settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety Device Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4 Capacity tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Cooling Capacity Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Heating Capacity Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5 Dimensional drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Dimensional Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6 Piping diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Piping Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7 Wiring diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Wiring Diagrams - Single Phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
8 Sound data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Sound Pressure Spectrum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
9 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Drainage Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Service Space . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Daikin VRV järjestelmät toimittaa ja asentaa Jäähdytinpalvelu RefGroup Oy

• Indoor Unit • Wall mounted unit • FXAQ-P
•VRV
®Systems • Indoor Unit
2
1 Specifications
IndoorUnit VRV
®
Systems FXAQ-PWallmounte
Standard Accessories : Screws;
Standard Accessories : Clamps;
Standard Accessories : Insulation tape;
Standard Accessories : Paper pattern for installation;
Standard Accessories : Installation panel;
Standard Accessories : Installation and operation manual;
1-1 Technical Specifications FXAQ20P FXAQ25P FXAQ32P FXAQ40P FXAQ50P FXAQ63P
Cooling capacity Nom. kW 2.2 (1) 2.8 (1) 3.6 (1) 4.5 (1) 5.6 (1) 7.1 (1)
Heating capacity Nom. kW 2.5 (2) 3.2 (2) 4.0 (2) 5.0 (2) 6.3 (2) 8.0 (2)
Power input -
50Hz
Cooling Nom. kW 0.019 (1) 0.028 (1) 0.030 (1) 0.020 (1) 0.033 (1) 0.050 (1)
Heating Nom. kW 0.029 (2) 0.034 (2) 0.035 (2) 0.020 (2) 0.039 (2) 0.060 (2)
Casing Colour White (3.0Y8.5/0.5)
Dimensions Unit Height mm 290
Width mm 795 1,050
Depth mm 238
Weight Unit kg 11 14
Heat
exchanger
Rows Quantity 2
Fin pitch mm 1.4
Face area m² 0.161 0.213
Stages Quantity 14
Fan Type Cross flow fan
Air flow rate -
50Hz
Cooling High
m³/min 7.5 8 8.5 12 15 19
Low
m³/min 4.555.591214
Fan motor Model QCL9661M QCL9686M
Output High W 40 43
Drive Direct drive
Sound
pressure level
Cooling High dBA 35.0 36.0 37.0 39.0 42.0 46.0
Low dBA 29.0 34.0 36.0 39.0
Refrigerant Type R-410A
Control Electronic expansion valve
Piping
connections
Liquid Type Flare connection
OD mm 6.35 9.52
Gas Type Flare connection
OD mm 12.7 15.9
Drain VP13 (I.D. 13/O.D. 18)
Heat insulation Foamed polystyrene/polyethylene
Sound absorbing insulation Foamed polystyrene / polyethylene
Temperature control Microprocessor thermostat for cooling and heating
Air filter Washable resin net
Safety devices Item 01 Fuse
Daikin VRV järjestelmät toimittaa ja asentaa Jäähdytinpalvelu RefGroup Oy

•VRV
®Systems • Indoor Unit 3
• Indoor Unit • Wall mounted unit • FXAQ-P
1 Specifications
Notes
(1) Cooling: indoor temp. 27ºCDB, 19.0ºCWB; outdoor temp. 35ºCDB; equivalent piping length: 5m (horizontal)
(2) Heating: indoor temp. 20ºCDB; outdoor temp. 7ºCDB, 6ºCWB; equivalent refrigerant piping: 5m (horizontal)
(3) Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
(4) Voltage range: units are suitable for use on electrical systems where voltage supplied to unit terminal is not below or above listed range limits.
(5) Maximum allowable voltage range variation between phases is 2%.
(6) MCA/MFA: MCA = 1.25 x FLA
(7) MFA ≤4 x FLA
(8) Next lower standard fuse rating minimum 16A
(9) Select wire size based on the value of MCA
(10) Use a circuit breaker instead of a fuse.
1-2 Electrical Specifications FXAQ20P FXAQ25P FXAQ32P FXAQ40P FXAQ50P FXAQ63P
Power supply Name V1
Phase 1~
Frequency Hz 50
Voltage V 220-240
Voltage range Min. % -10
Max. % 10
Current - 50Hz Minimum circuit amps (MCA) A 0.3 0.4 0.5 0.6
Maximum fuse amps (MFA) A 16
Full load
amps (FLA)
Total A 0.2 0.3 0.4 0.5
Daikin VRV järjestelmät toimittaa ja asentaa Jäähdytinpalvelu RefGroup Oy

• Indoor Unit • Wall mounted unit • FXAQ-P
•VRV
®Systems • Indoor Unit
4
2 Safety device settings
2 - 1 Safety Device Settings
FXAQ20-63P
4D034906K
Safety devices 20 25 32 40 50 63
FXAQ~P PC board fuse 250V 3.15A
Daikin VRV järjestelmät toimittaa ja asentaa Jäähdytinpalvelu RefGroup Oy

•VRV
®Systems • Indoor Unit 5
• Indoor Unit • Wall mounted unit • FXAQ-P
3 Options
3 - 1 Options
FXAQ20-63P
3D023974N
NOTES
1. Installation box (no. 7) is necessary for each adapter marked *.
2. Up to 2 adapters can be fixed for each installation box.
3. Only one installation box can be installed for each indoor unit.
4. Up to 2 installation boxes can be installed for each indoor unit.
5. Installation box (no. 7) is necessary for second adapter.
6. Installation box (no. 7) is necessary for each adapter.
7. For DAME only
8. For residential use only. Cannot be used with other centralised control equipment.
No. Type
Item FXAQ~P
1 Remote control
Infrared H/P BRC7E618
C/O BRC7E619
Wired BRC1E51A / BRC1D62 (note7)
-
2 Simplified remote control -
3 Remote control for hotel use -
4 Adapter for wiring -
5-1 Wiring adapter for electrical appendices (1) * KRP2A51
5-1 Wiring adapter for electrical appendices (2) * KRP4A51
6 Remote sensor KRCS01-1
7 Installation box for adapter PCB KRP4A93 (Note 2,3)
8 Central remote control DCS302C51
DCS302C61 (note 7)
8-1 Electrical box with earth terminal (3 blocks) KJB311A
9 Unified on/off controller DCS301B51
DCS301B61 (note 7)
9-1 Electrical box with earth terminal (2 blocks) KJB212A
9-2 Noise filter (for electromagnetic interface use only) KEK26-1
10 Schedule timer DST301B51
DST301B61 (note 7)
11 External control adapter for outdoor unit (must be installed on indoor units) * DTA104A51
12 Adapter for multi tenant DTA114A61
13 Residential central remote control DCS303A51 (Note 7,8)
Daikin VRV järjestelmät toimittaa ja asentaa Jäähdytinpalvelu RefGroup Oy

• Indoor Unit • Wall mounted unit • FXAQ-P
•VRV
®Systems • Indoor Unit
6
4 Capacity tables
4 - 1 Cooling Capacity Tables
FXAQ-
TC: Total capacity;kW – SHC: Sensible capacity;kW
Unit size Nominal
capacity
Outdoor
air temp.
Indoor air temperature
14.0WB 16.0WB 18.0WB 19.0WB 20.0WB 22.0WB 24.0WB
20.0DB 23.0DB 26.0DB 27.0DB 28.0DB 30.0DB 32.0DB
°CDB TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
20 2.2 10.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.3 1.9 2.6 2.0 2.9 1.9
12.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.3 1.9 2.6 2.0 2.9 1.9
14.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.3 1.9 2.6 2.0 2.8 1.9
16.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.3 1.9 2.6 2.0 2.8 1.9
18.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.3 1.9 2.6 2.0 2.7 1.9
20.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.3 1.9 2.6 2.0 2.7 1.9
21.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.3 1.9 2.6 2.0 2.7 1.9
23.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.3 1.9 2.6 1.9 2.6 1.9
25.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.3 1.9 2.6 1.9 2.6 1.9
27.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.3 1.9 2.5 1.9 2.6 1.8
29.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.3 1.9 2.5 1.9 2.5 1.8
31.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.3 1.9 2.4 1.9 2.5 1.8
33.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.3 1.9 2.4 1.9 2.5 1.8
35.0 1.5 1.5 1.8 1.8 2.1 1.9 2.21.92.31.92.41.92.41.8
37.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.3 1.9 2.3 1.8 2.4 1.7
39.0 1.5 1.5 1.8 1.8 2.1 1.9 2.2 1.9 2.2 1.9 2.3 1.8 2.3 1.7
25 2.8 10.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 3.0 2.2 3.4 2.3 3.7 2.3
12.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 3.0 2.2 3.4 2.3 3.6 2.2
14.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 3.0 2.2 3.4 2.3 3.6 2.3
16.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 3.0 2.2 3.4 2.3 3.5 2.2
18.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 3.0 2.2 3.4 2.3 3.5 2.2
20.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 3.0 2.2 3.4 2.3 3.4 2.2
21.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 3.0 2.2 3.4 2.3 3.4 2.2
23.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 3.0 2.2 3.3 2.3 3.4 2.2
25.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 3.0 2.2 3.3 2.2 3.3 2.2
27.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 3.0 2.2 3.2 2.2 3.3 2.1
29.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 3.0 2.2 3.2 2.2 3.2 2.1
31.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 3.0 2.2 3.1 2.2 3.2 2.1
33.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 3.0 2.2 3.1 2.2 3.1 2.1
35.0 1.9 1.8 2.3 2.0 2.6 2.2 2.82.23.02.23.02.23.12.1
37.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 2.9 2.2 3.0 2.1 3.0 2.0
39.0 1.9 1.8 2.3 2.0 2.6 2.2 2.8 2.2 2.9 2.2 2.9 2.1 3.0 2.0
32 3.6 10.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.8 2.7 4.3 2.8 4.7 2.8
12.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.8 2.7 4.3 2.8 4.7 2.8
14.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.8 2.7 4.3 2.8 4.6 2.8
16.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.8 2.7 4.3 2.8 4.6 2.8
18.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.8 2.7 4.3 2.8 4.5 2.7
20.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.8 2.7 4.3 2.8 4.4 2.7
21.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.8 2.7 4.3 2.8 4.4 2.7
23.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.8 2.7 4.2 2.8 4.3 2.7
25.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.8 2.7 4.2 2.8 4.3 2.6
27.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.8 2.7 4.1 2.7 4.2 2.6
29.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.8 2.7 4.1 2.7 4.2 2.6
31.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.8 2.7 4.0 2.7 4.1 2.6
33.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.8 2.7 3.9 2.6 4.0 2.5
35.0 2.4 2.2 2.9 2.4 3.4 2.6 3.62.73.82.73.92.64.02.5
37.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.7 2.6 3.8 2.6 3.9 2.5
39.0 2.4 2.2 2.9 2.4 3.4 2.6 3.6 2.7 3.7 2.6 3.8 2.6 3.8 2.5
40 4.5 10.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.8 3.6 5.4 3.6 5.9 3.6
12.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.8 3.6 5.4 3.6 5.8 3.5
14.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.8 3.6 5.4 3.6 5.8 3.5
16.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.8 3.6 5.4 3.6 5.7 3.5
18.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.8 3.6 5.4 3.6 5.6 3.4
20.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.8 3.6 5.4 3.6 5.5 3.4
21.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.8 3.6 5.4 3.6 5.5 3.4
23.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.8 3.6 5.3 3.6 5.4 3.3
25.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.8 3.6 5.2 3.6 5.3 3.3
27.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.8 3.6 5.2 3.5 5.3 3.3
29.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.8 3.6 5.1 3.5 5.2 3.2
31.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.8 3.6 5.0 3.4 5.1 3.2
33.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.8 3.6 4.9 3.4 5.0 3.1
35.0 3.0 2.9 3.6 3.3 4.2 3.7 4.53.54.73.64.93.45.03.1
37.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.7 3.5 4.8 3.3 4.9 3.1
39.0 3.0 2.9 3.6 3.3 4.2 3.7 4.5 3.5 4.6 3.5 4.7 3.3 4.8 3.0
P
Daikin VRV järjestelmät toimittaa ja asentaa Jäähdytinpalvelu RefGroup Oy

•VRV
®Systems • Indoor Unit 7
• Indoor Unit • Wall mounted unit • FXAQ-P
4 Capacity tables
4 - 1 Cooling Capacity Tables
FXAQ-
TC: Total capacity;kW – SHC: Sensible capacity;kW
Unit size Nominal
capacity
Outdoor
air temp.
Indoor air temperature
14.0WB 16.0WB 18.0WB 19.0WB 20.0WB 22.0WB 24.0WB
20.0DB 23.0DB 26.0DB 27.0DB 28.0DB 30.0DB 32.0DB
°CDB TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
50 5.6 10.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 6.0 4.3 6.7 4.4 7.4 4.4
12.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 6.0 4.3 6.7 4.4 7.3 4.3
14.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 6.0 4.3 6.7 4.4 7.2 4.3
16.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 6.0 4.3 6.7 4.4 7.1 4.3
18.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 6.0 4.3 6.7 4.4 7.0 4.2
20.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 6.0 4.3 6.7 4.4 6.9 4.2
21.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 6.0 4.3 6.7 4.4 6.8 4.2
23.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 6.0 4.3 6.6 4.4 6.7 4.1
25.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 6.0 4.3 6.5 4.3 6.6 4.1
27.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 6.0 4.3 6.4 4.3 6.6 4.0
29.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 6.0 4.3 6.3 4.2 6.5 4.0
31.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 6.0 4.3 6.2 4.2 6.4 3.9
33.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 6.0 4.3 6.1 4.2 6.3 3.9
35.0 3.8 3.2 4.5 3.7 5.2 4.1 5.64.25.94.36.04.16.23.8
37.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 5.8 4.3 5.9 4.1 6.1 3.8
39.0 3.8 3.2 4.5 3.7 5.2 4.1 5.6 4.2 5.7 4.2 5.8 4.0 6.0 3.8
63 7.1 10.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.6 5.4 8.5 5.6 9.3 5.3
12.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.6 5.4 8.5 5.6 9.2 5.3
14.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.6 5.4 8.5 5.6 9.1 5.2
16.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.6 5.4 8.5 5.6 9.0 5.2
18.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.6 5.4 8.5 5.6 8.8 5.2
20.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.6 5.4 8.5 5.6 8.7 5.1
21.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.6 5.4 8.5 5.6 8.7 5.1
23.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.6 5.4 8.4 5.5 8.5 5.0
25.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.6 5.4 8.3 5.5 8.4 5.0
27.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.6 5.4 8.1 5.4 8.3 4.9
29.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.6 5.4 8.0 5.4 8.2 4.9
31.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.6 5.4 7.9 5.3 8.1 4.8
33.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.6 5.4 7.8 5.2 7.9 4.8
35.0 4.8 4.1 5.7 4.6 6.6 5.1 7.15.37.55.47.75.27.84.7
37.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.4 5.3 7.5 5.1 7.7 4.7
39.0 4.8 4.1 5.7 4.6 6.6 5.1 7.1 5.3 7.2 5.3 7.4 5.1 7.6 4.6
P
Daikin VRV järjestelmät toimittaa ja asentaa Jäähdytinpalvelu RefGroup Oy

• Indoor Unit • Wall mounted unit • FXAQ-P
•VRV
®Systems • Indoor Unit
8
4 Capacity tables
4 - 2 Heating Capacity Tables
FXAQ-
Unit Size Nominal capacity Outdoor
air temperature
Indoor air temperature °CDB
16.0 18.0 20.0 21.0 22.0 24.0
°CDB °CWBkWkWkWkWkWkW
20 2.5 -19.8 -20.0 1.5 1.5 1.5 1.5 1.5 1.5
-18.8 -19.0 1.5 1.5 1.5 1.5 1.5 1.5
-16.7 -17.0 1.6 1.6 1.6 1.6 1.6 1.6
-14.7 -15.0 1.7 1.7 1.7 1.7 1.7 1.7
-12.6 -13.0 1.8 1.8 1.8 1.8 1.8 1.8
-10.5 -11.0 1.9 1.9 1.9 1.9 1.9 1.9
-9.5 -10.0 1.9 1.9 1.9 1.9 1.9 1.9
-8.5 -9.1 2.0 2.0 1.9 1.9 1.9 1.9
-7.0 -7.6 2.0 2.0 2.0 2.0 2.0 2.0
-5.0 -5.6 2.1 2.1 2.1 2.1 2.1 2.1
-3.0 -3.7 2.2 2.2 2.2 2.2 2.2 2.2
0.0 -0.7 2.3 2.3 2.3 2.3 2.3 2.2
3.0 2.2 2.5 2.5 2.4 2.4 2.3 2.2
5.0 4.1 2.5 2.5 2.5 2.4 2.3 2.2
7.0 6.0 2.6 2.6 2.5 2.4 2.3 2.2
9.0 7.9 2.7 2.7 2.5 2.4 2.3 2.2
11.0 9.8 2.8 2.7 2.5 2.4 2.3 2.2
13.0 11.8 2.8 2.7 2.5 2.4 2.3 2.2
15.0 13.7 2.8 2.7 2.5 2.4 2.3 2.2
25 3.2 -19.8 -20.0 1.9 1.9 1.9 1.9 1.9 1.9
-18.8 -19.0 1.9 1.9 1.9 1.9 1.9 1.9
-16.7 -17.0 2.1 2.1 2.0 2.0 2.0 2.0
-14.7 -15.0 2.2 2.2 2.2 2.2 2.2 2.1
-12.6 -13.0 2.3 2.3 2.3 2.3 2.3 2.3
-10.5 -11.0 2.4 2.4 2.4 2.4 2.4 2.4
-9.5 -10.0 2.5 2.4 2.4 2.4 2.4 2.4
-8.5 -9.1 2.5 2.5 2.5 2.5 2.5 2.5
-7.0 -7.6 2.6 2.6 2.6 2.6 2.6 2.6
-5.0 -5.6 2.7 2.7 2.7 2.7 2.7 2.7
-3.0 -3.7 2.8 2.8 2.8 2.8 2.8 2.8
0.0 -0.7 3.0 3.0 3.0 3.0 3.0 2.8
3.0 2.2 3.1 3.1 3.1 3.1 3.0 2.8
5.0 4.1 3.3 3.2 3.2 3.1 3.0 2.8
7.0 6.0 3.4 3.4 3.2 3.1 3.0 2.8
9.0 7.9 3.5 3.4 3.2 3.1 3.0 2.8
11.0 9.8 3.6 3.4 3.2 3.1 3.0 2.8
13.0 11.8 3.6 3.4 3.2 3.1 3.0 2.8
15.0 13.7 3.6 3.4 3.2 3.1 3.0 2.8
32 4.0 -19.8 -20.0 2.4 2.4 2.3 2.3 2.3 2.3
-18.8 -19.0 2.4 2.4 2.4 2.4 2.4 2.4
-16.7 -17.0 2.6 2.6 2.6 2.6 2.6 2.5
-14.7 -15.0 2.7 2.7 2.7 2.7 2.7 2.7
-12.6 -13.0 2.9 2.8 2.8 2.8 2.8 2.8
-10.5 -11.0 3.0 3.0 3.0 3.0 3.0 3.0
-9.5 -10.0 3.1 3.1 3.1 3.1 3.0 3.0
-8.5 -9.1 3.1 3.1 3.1 3.1 3.1 3.1
-7.0 -7.6 3.2 3.2 3.2 3.2 3.2 3.2
-5.0 -5.6 3.4 3.4 3.4 3.4 3.4 3.4
-3.0 -3.7 3.5 3.5 3.5 3.5 3.5 3.5
0.0 -0.7 3.7 3.7 3.7 3.7 3.7 3.5
3.0 2.2 3.9 3.9 3.9 3.9 3.7 3.5
5.0 4.1 4.1 4.1 4.0 3.9 3.7 3.5
7.0 6.0 4.2 4.2 4.0 3.9 3.7 3.5
9.0 7.9 4.3 4.3 4.0 3.9 3.7 3.5
11.0 9.8 4.5 4.3 4.0 3.9 3.7 3.5
13.0 11.8 4.5 4.3 4.0 3.9 3.7 3.5
15.0 13.7 4.5 4.3 4.0 3.9 3.7 3.5
40 5.0 -19.8 -20.0 3.0 2.9 2.9 2.9 2.9 2.9
-18.8 -19.0 3.0 3.0 3.0 3.0 3.0 3.0
-16.7 -17.0 3.2 3.2 3.2 3.2 3.2 3.2
-14.7 -15.0 3.4 3.4 3.4 3.4 3.4 3.4
-12.6 -13.0 3.6 3.6 3.6 3.5 3.5 3.5
-10.5 -11.0 3.7 3.7 3.7 3.7 3.7 3.7
-9.5 -10.0 3.8 3.8 3.8 3.8 3.8 3.8
-8.5 -9.1 3.9 3.9 3.9 3.9 3.9 3.9
-7.0 -7.6 4.0 4.0 4.0 4.0 4.0 4.0
-5.0 -5.6 4.2 4.2 4.2 4.2 4.2 4.2
-3.0 -3.7 4.4 4.4 4.4 4.4 4.4 4.4
0.0 -0.7 4.7 4.6 4.6 4.6 4.6 4.4
3.0 2.2 4.9 4.9 4.9 4.8 4.7 4.4
5.0 4.1 5.1 5.1 5.0 4.8 4.7 4.4
7.0 6.0 5.2 5.2 5.0 4.8 4.7 4.4
9.0 7.9 5.4 5.3 5.0 4.8 4.7 4.4
11.0 9.8 5.6 5.3 5.0 4.8 4.7 4.4
13.0 11.8 5.6 5.3 5.0 4.8 4.7 4.4
15.0 13.7 5.6 5.3 5.0 4.8 4.7 4.4
P
Daikin VRV järjestelmät toimittaa ja asentaa Jäähdytinpalvelu RefGroup Oy

•VRV
®Systems • Indoor Unit 9
• Indoor Unit • Wall mounted unit • FXAQ-P
4 Capacity tables
4 - 2 Heating Capacity Tables
FXAQ-
Unit Size Nominal capacity Outdoor
air temperature
Indoor air temperature °CDB
16.0 18.0 20.0 21.0 22.0 24.0
°CDB °CWBkWkWkWkWkWkW
50 6.3 -19.8 -20.0 3.7 3.7 3.7 3.7 3.7 3.7
-18.8 -19.0 3.8 3.8 3.8 3.8 3.8 3.8
-16.7 -17.0 4.1 4.0 4.0 4.0 4.0 4.0
-14.7 -15.0 4.3 4.3 4.3 4.2 4.2 4.2
-12.6 -13.0 4.5 4.5 4.5 4.5 4.5 4.5
-10.5 -11.0 4.7 4.7 4.7 4.7 4.7 4.7
-9.5 -10.0 4.8 4.8 4.8 4.8 4.8 4.8
-8.5 -9.1 4.9 4.9 4.9 4.9 4.9 4.9
-7.0 -7.6 5.1 5.1 5.1 5.1 5.1 5.1
-5.0 -5.6 5.3 5.3 5.3 5.3 5.3 5.3
-3.0 -3.7 5.5 5.5 5.5 5.5 5.5 5.5
0.0 -0.7 5.9 5.9 5.8 5.8 5.8 5.5
3.0 2.2 6.2 6.2 6.2 6.1 5.9 5.5
5.0 4.1 6.4 6.4 6.3 6.1 5.9 5.5
7.0 6.0 6.6 6.6 6.3 6.1 5.9 5.5
9.0 7.9 6.8 6.7 6.3 6.1 5.9 5.5
11.0 9.8 7.0 6.7 6.3 6.1 5.9 5.5
13.0 11.8 7.1 6.7 6.3 6.1 5.9 5.5
15.0 13.7 7.1 6.7 6.3 6.1 5.9 5.5
63 8.0 -19.8 -20.0 4.7 4.7 4.7 4.7 4.7 4.7
-18.8 -19.0 4.9 4.9 4.8 4.8 4.8 4.8
-16.7 -17.0 5.1 5.1 5.1 5.1 5.1 5.1
-14.7 -15.0 5.4 5.4 5.4 5.4 5.4 5.4
-12.6 -13.0 5.7 5.7 5.7 5.7 5.7 5.7
-10.5 -11.0 6.0 6.0 6.0 6.0 6.0 5.9
-9.5 -10.0 6.1 6.1 6.1 6.1 6.1 6.1
-8.5 -9.1 6.3 6.3 6.2 6.2 6.2 6.2
-7.0 -7.6 6.5 6.5 6.4 6.4 6.4 6.4
-5.0 -5.6 6.8 6.7 6.7 6.7 6.7 6.7
-3.0 -3.7 7.0 7.0 7.0 7.0 7.0 7.0
0.0 -0.7 7.5 7.4 7.4 7.4 7.4 7.0
3.0 2.2 7.9 7.8 7.8 7.7 7.5 7.0
5.0 4.1 8.1 8.1 8.0 7.7 7.5 7.0
7.0 6.0 8.4 8.4 8.0 7.7 7.5 7.0
9.0 7.9 8.7 8.5 8.0 7.7 7.5 7.0
11.0 9.8 8.9 8.5 8.0 7.7 7.5 7.0
13.0 11.8 9.0 8.5 8.0 7.7 7.5 7.0
15.0 13.7 9.0 8.5 8.0 7.7 7.5 7.0
P
Daikin VRV järjestelmät toimittaa ja asentaa Jäähdytinpalvelu RefGroup Oy

• Indoor Unit • Wall mounted unit • FXAQ-P
•VRV
®Systems • Indoor Unit
10
5 Dimensional drawings
5 - 1 Dimensional Drawings
);$43
'
127(6
 /RFDWLRQRIXQLW¶VRI1DPH3ODWH5LJKWVLGHVXUIDFHRIFDVLQJ
 ,QFDVHRIXVLQJLQIUDUHGUHPRWHFRQWUROWKLVSRVLWLRQZLOOEHDVLJQDOUHFHLYHU5HIHUWRWKHGUDZLQJRI
LQIUDUHGUHPRWHFRQWUROLQGHWDLO
$SSUR[
1U 1DPH 'HVFULSWLRQ
 )URQWSDQHO
 )URQWJULOO
 $LURXWOHW
 *DVSLSH PP)ODUHFRQQHFWLRQ
 /LTXLGSLSH PP)ODUHFRQQHFWLRQ
 'UDLQKRVH 93([WHUQDOGLD
 *URXQGLQJWHUPLQDO 0
 5LJKWVLGHSLSHFRQQHFWLRQKROH
 /HIWVLGHSLSHFRQQHFWLRQKROH
'LPHQVLRQVIRU
IXOORSHQIURQWSDQHO
RUPRUH RUPRUH
5HTXLUHGVSDFH 5HTXLUHGVSDFH
3LSLQJGLUHFWLRQ 3LSLQJGLUHFWLRQ
1DPHSODWH1RWH
3LSLQJGLUHFWLRQ
RUOHVV
RUPRUH
)RULQVWDOODWLRQ
LQKLJKVSDFHV
RUPRUH 5HTXLUHGVSDFH
RUPRUH 5HTXLUHGVSDFH
$SSUR[
$SSUR[
)LOWHUSDUW
)LOWHUSDUW
$SSUR[
$SSUR[
)OH[LEOHWXEHSDUW
KROH
KROH
3LSLQJDQG
:LULQJLQWDNH
0RXQWLQJORFDWLRQ
2XWVLGHOLQH
);$43
'
127(6
 /RFDWLRQRIXQLW¶VRI1DPH3ODWH5LJKWVLGHVXUIDFHRIFDVLQJ
 ,QFDVHRIXVLQJLQIUDUHGUHPRWHFRQWUROWKLVSRVLWLRQZLOOEHDVLJQDOUHFHLYHU5HIHUWRWKHGUDZLQJRI
LQIUDUHGUHPRWHFRQWUROLQGHWDLO
$SSUR[
1U 1DPH 'HVFULSWLRQ
 )URQWSDQHO
 )URQWJULOO
 $LURXWOHW
 *DVSLSH PP)ODUHFRQQHFWLRQ
 /LTXLGSLSH PP)ODUHFRQQHFWLRQ
 'UDLQKRVH 93([WHUQDOGLD
 *URXQGLQJWHUPLQDO 0
 5LJKWVLGHSLSHFRQQHFWLRQKROH
 /HIWVLGHSLSHFRQQHFWLRQKROH
'LPHQVLRQVIRU
IXOORSHQIURQWSDQHO
RUPRUH RUPRUH
5HTXLUHGVSDFH 5HTXLUHGVSDFH
3LSLQJGLUHFWLRQ 3LSLQJGLUHFWLRQ
1DPHSODWH1RWH
3LSLQJGLUHFWLRQ
RUOHVV
RUPRUH
)RULQVWDOODWLRQ
LQKLJKVSDFHV
RUPRUH 5HTXLUHGVSDFH
RUPRUH 5HTXLUHGVSDFH
$SSUR[
$SSUR[
)LOWHUSDUW
)LOWHUSDUW
$SSUR[
$SSUR[
)OH[LEOHWXEHSDUW
KROH
KROH
3LSLQJDQG
:LULQJLQWDNH
0RXQWLQJORFDWLRQ
2XWVLGHOLQH
Daikin VRV järjestelmät toimittaa ja asentaa Jäähdytinpalvelu RefGroup Oy

•VRV
®Systems • Indoor Unit 11
• Indoor Unit • Wall mounted unit • FXAQ-P
5 Dimensional drawings
5 - 1 Dimensional Drawings
);$43
'
127(6
 /RFDWLRQRIXQLW¶VRI1DPH3ODWH5LJKWVLGHVXUIDFHRIFDVLQJ
 ,QFDVHRIXVLQJLQIUDUHGUHPRWHFRQWUROWKLVSRVLWLRQZLOOEHDVLJQDOUHFHLYHU5HIHUWRWKHGUDZLQJRI
LQIUDUHGUHPRWHFRQWUROLQGHWDLO
$SSUR[
1U 1DPH 'HVFULSWLRQ
 )URQWSDQHO
 )URQWJULOO
 $LURXWOHW
 *DVSLSH PP)ODUHFRQQHFWLRQ
 /LTXLGSLSH PP)ODUHFRQQHFWLRQ
 'UDLQKRVH 93([WHUQDOGLD
 *URXQGLQJWHUPLQDO 0
 5LJKWVLGHSLSHFRQQHFWLRQKROH
 /HIWVLGHSLSHFRQQHFWLRQKROH
'LPHQVLRQVIRU
IXOORSHQ
IURQWSDQHO
RUPRUH RUPRUH
5HTXLUHGVSDFH 5HTXLUHGVSDFH
3LSLQJGLUHFWLRQ 3LSLQJGLUHFWLRQ1DPHSODWH1RWH
3LSLQJGLUHFWLRQ
RUOHVV
RUPRUH
)RULQVWDOODWLRQ
LQKLJKVSDFHV
RUPRUH 5HTXLUHGVSDFH
RUPRUH 5HTXLUHGVSDFH
$SSUR[
$SSUR[
)LOWHUSDUW
)LOWHUSDUW $SSUR[
KROH
KROH
3LSLQJDQG
:LULQJLQWDNH
0RXQWLQJORFDWLRQ
2XWVLGHOLQH
Daikin VRV järjestelmät toimittaa ja asentaa Jäähdytinpalvelu RefGroup Oy

• Indoor Unit • Wall mounted unit • FXAQ-P
•VRV
®Systems • Indoor Unit
12
6 Piping diagrams
6 - 1 Piping Diagrams
);$43
''
+HDWH[FKDQJHU
*DVSLSH
FRQQHFWLRQSRUW
/LTXLGSLSH
FRQQHFWLRQSRUW
(OHFWURQLF
H[SDQVLRQYDOYH
)LOWHU )LOWHU
)DQ
$33/,&$%/(02'(/
);&);0);/);1);+);.);6)-63&%;/6);63);&3)=63)=63);13
)-13)+4);$
Daikin VRV järjestelmät toimittaa ja asentaa Jäähdytinpalvelu RefGroup Oy

•VRV
®Systems • Indoor Unit 13
• Indoor Unit • Wall mounted unit • FXAQ-P
7 Wiring diagrams
7 - 1 Wiring Diagrams - Single Phase
);$43
'$
127(6
 WHUPLQDO FRQQHFWRU
WHUPLQDO FRQQHFWRU
 ,QFDVHXVLQJFHQWUDOUHPRWHFRQWUROFRQQHFWLWWRWKHXQLWLQDFFRUGDQFHZLWKWKHDWWDFKHGLQVWDOODWLRQPDQXDO
 6\PEROVVKRZVDVIROORZV5('UHG:+7ZKLWH*51JUHHQ31.SLQN</:\HOORZ%/.EODFN25*RUDQJH%/8EOXH
 6KRZVVKRUWFLUFXLWFRQQHFWRU
 :KHQFRQQHFWLQJWKHLQSXWZLUHVIURPRXWVLGHIRUFHGRIIRURQRIIFRQWURORSHUDWLRQFDQEHVHOHFWHGE\UHPRWHFRQWURO,QGHWDLOVUHIHUWRWKHLQVWDOODWLRQPDQXDODWWDFKHGWKHXQLW
 5HPRWHFRQWUROPRGHOYDULHVDFFRUGLQJWRWKHFRPELQDWLRQV\VWHPFRQILUPHQJLQHHULQJGDWDDQGFDWDORJVHWFEHIRUHFRQQHFWLQJ
 &RQILUPWKHPHWKRGRIVHWWLQJWKHVHOHFWRUVZLWFK6666RIZLUHGUHPRWHFRQWURODQGZLUHOHVVUHPRWHFRQWUROE\LQVWDOODWLRQPDQXDODQGHQJLQHHULQJGDWDHWF
 ;$;$;$DQG;$DUHFRQQHFWHGZKHQWKHRSWLRQDODFFHVVRULHVDUHEHLQJXVHG
,1'22581,7 %6 3XVKEXWWRQRQRII
$3 3ULQWHGFLUFXLWERDUG +3 /LJKWHPLWWLQJGLRGHRQUHG
)8 )XVHW$+9 +3 /LJKWHPLWWLQJGLRGHWLPHUJUHHQ
+$3 /LJKWHPLWWLQJGLRGHVHUYLFHPRWRUJUHHQ +3 /LJKWHPLWWLQJGLRGHILOWHUVLJQUHG
0) 0RWRULQGRRUIDQ +3 /LJKWHPLWWLQJGLRGHGHIURVWRUDQJH
06 0RWRUVZLQJIODS 66 6HOHFWRUVZLWFKPDLQVXE
57 7KHUPLVWRUDLU 66 6HOHFWRUVZLWFKZLUHOHVVDGGUHVVVHW
57 7KHUPLVWRUFRLOOLTXLGSLSH :,5('5(027(&2152/
57 7KHUPLVWRUFRLOJDVSLSH 57 7KHUPLVWRUDLU
;0 7HUPLQDOEORFNFRQWURO 66 6HOHFWRUVZLWFKPDLQVXE
;0 7HUPLQDOEORFNSRZHU &211(&725)25237,21$/3$576
<( (OHFWURQLFH[SDQVLRQYDOYH ;$ &RQQHFWRUIORDWVZLWFK
3& 3RZHUFLUFXLW ;$ &RQQHFWRULQIUDUHGUHPRWHFRQWURO
5(&(,9(5',63/$<81,7$77$&+('72,1)5$5('5(027(&21752/ ;$ &RQQHFWRUJURXSFRQWURODGDSWHU
$3 3ULQWHGFLUFXLWERDUG ;$ &RQQHFWRUDGDSWRUIRUPXOWLWHQDQW
$3 3ULQWHGFLUFXLWERDUG
32:(56833/<
6,'(
)5217
&21752/%2;
,1'22581,7
:,5('5(027(
&21752/
5(&(,9(5',63/$<81,7
,QIUDUHGUHPRWHFRQWURO
1RWH
1RWH 1RWH
1RWH
,1387)5202876,'(
7UDQVPLVVLRQZLULQJ
&HQWUDOUHPRWHFRQWURO
1RWH
1RWH
1RWH
Daikin VRV järjestelmät toimittaa ja asentaa Jäähdytinpalvelu RefGroup Oy

• Indoor Unit • Wall mounted unit • FXAQ-P
•VRV
®Systems • Indoor Unit
14
8 Sound data
8 - 1 Sound Pressure Spectrum
);$43
'
127(6
1 Over All (dB):
(B,G,N is already rectified)
2 Operating conditions:
• Power source: 220-240V 50Hz
• Cooling: Return air temperature: 27°CDB, 19°CWB
Outdoor temperature: 35°CDB, 24°CWB
• Heating: Return air temperature: 20°CDB, 15°CWB
Outdoor temperature: 7°CDB, 6°CWB
3 Measuring place: Anechoic chamber.
4 Operation noise differs with operation and ambient conditions.
Location of microphone.
Octave band sound pressure level dB (0dB = 0.002bar)
Octave band sound frequency (Hz)
Approximate
threshold hearing
for continuous
noise
Microphone
Scale MODE
HL
A 36.0 31.0
C 40.1 36.3
5
);$43
'
127(6
1 Over All (dB):
(B,G,N is already rectified)
2 Operating conditions:
• Power source: 220-240V 50Hz
• Cooling: Return air temperature: 27°CDB, 19°CWB
Outdoor temperature: 35°CDB, 24°CWB
• Heating: Return air temperature: 20°CDB, 15°CWB
Outdoor temperature: 7°CDB, 6°CWB
3 Measuring place: Anechoic chamber.
4 Operation noise differs with operation and ambient conditions.
Location of microphone.
Octave band sound pressure level dB (0dB = 0.002bar)
Octave band sound frequency (Hz)
Approximate
threshold hearing
for continuous
noise
Microphone
Scale MODE
HL
A 37.0 31.0
C 41.5 35.9
5
);$43
'
127(6
1 Over All (dB):
(B,G,N is already rectified)
2 Operating conditions:
• Power source: 220-240V 50Hz
• Cooling: Return air temperature: 27°CDB, 19°CWB
Outdoor temperature: 35°CDB, 24°CWB
• Heating: Return air temperature: 20°CDB, 15°CWB
Outdoor temperature: 7°CDB, 6°CWB
3 Measuring place: Anechoic chamber.
4 Operation noise differs with operation and ambient conditions.
Location of microphone.
Octave band sound pressure level dB (0dB = 0.002bar)
Octave band sound frequency (Hz)
Approximate
threshold hearing
for continuous
noise
Microphone
Scale MODE
HL
A 38.0 31.0
C 41.9 36.6
5
);$43
'
127(6
1 Over All (dB):
(B,G,N is already rectified)
2 Operating conditions:
• Power source: 220-240V 50Hz
• Cooling: Return air temperature: 27°CDB, 19°CWB
Outdoor temperature: 35°CDB, 24°CWB
• Heating: Return air temperature: 20°CDB, 15°CWB
Outdoor temperature: 7°CDB, 6°CWB
3 Measuring place: Anechoic chamber.
4 Operation noise differs with operation and ambient conditions.
Location of microphone.
Octave band sound pressure level dB (0dB = 0.002bar)
Octave band sound frequency (Hz)
Approximate
threshold hearing
for continuous
noise
Microphone
Scale MODE
HL
A 40.0 36.0
C 43.6 40.6
5
Daikin VRV järjestelmät toimittaa ja asentaa Jäähdytinpalvelu RefGroup Oy

•VRV
®Systems • Indoor Unit 15
• Indoor Unit • Wall mounted unit • FXAQ-P
8 Sound data
8 - 1 Sound Pressure Spectrum
);$43
'
127(6
1 Over All (dB):
(B,G,N is already rectified)
2 Operating conditions:
• Power source: 220-240V 50Hz
• Cooling: Return air temperature: 27°CDB, 19°CWB
Outdoor temperature: 35°CDB, 24°CWB
• Heating: Return air temperature: 20°CDB, 15°CWB
Outdoor temperature: 7°CDB, 6°CWB
3 Measuring place: Anechoic chamber.
4 Operation noise differs with operation and ambient conditions.
Location of microphone.
Octave band sound pressure level dB (0dB = 0.002bar)
Octave band sound frequency (Hz)
Approximate
threshold hearing
for continuous
noise
Microphone
Scale MODE
HL
A 43.0 38.0
C 46.3 41.7
5
);$43
'
127(6
1 Over All (dB):
(B,G,N is already rectified)
2 Operating conditions:
• Power source: 220-240V 50Hz
• Cooling: Return air temperature: 27°CDB, 19°CWB
Outdoor temperature: 35°CDB, 24°CWB
• Heating: Return air temperature: 20°CDB, 15°CWB
Outdoor temperature: 7°CDB, 6°CWB
3 Measuring place: Anechoic chamber.
4 Operation noise differs with operation and ambient conditions.
6 Location of microphone.
Octave band sound pressure level dB (0dB = 0.002bar)
Octave band sound frequency (Hz)
Approximate
threshold hearing
for continuous
noise
Microphone
Scale MODE
HL
A 47.0 41.0
C 49.8 44.3
Daikin VRV järjestelmät toimittaa ja asentaa Jäähdytinpalvelu RefGroup Oy

• Indoor Unit • Wall mounted unit • FXAQ-P
•VRV
®Systems • Indoor Unit
16
9 Installation
9 - 1 Drainage Instructions
Install the drain piping
• The drain pipe should be short with a downward slope and should prevent the formation of air pockets.
• When extending the drain hose, use a commercially available drain extension hose, and be sure to insulate the extended section of the drain hose which is indoors.
• Make sure the diameter of the piping is the same as the piping (hard vinyl chloride, nominal diameter 13mm) or bigger.
• When directly connecting a hard vinyl chloride pipe joint (nominal diameter 13mm) to the drain hose connected to the indoor unit (i.e. for embedded piping,
etc.), use a commercially available hard vinyl chloride pipe joint (nominal diameter 13mm).
Make sure the drain hose is at a
downward slope.
Make sure the tip does not go
underwater even when water is added.
Drain hose
(Downward slope)
Drain hose
Insulating tape (accessory)
Insulating tube (locally procured)
Indoor unit drain hose
Extension drain piping (locally procured)
Drain hose connected to the indoor unit Commercially available hard vinyl chloride pipe joint
(nominal diameter 13mm)
Commercially available hard vinyl chloride pipe (nominal
diameter 13mm)
Daikin VRV järjestelmät toimittaa ja asentaa Jäähdytinpalvelu RefGroup Oy

•VRV
®Systems • Indoor Unit 17
• Indoor Unit • Wall mounted unit • FXAQ-P
9 Installation
9 - 2 Service Space
);$43
38
 6HOHFWDQLQVWDOODWLRQVLWHZKHUHWKHIROORZLQJFRQGLWLRQVDUHIXOILOOHGDQGWKDWPHHWVZLWK\RXUFXVWRPHU¶VDSSURYDO
,QWKHXSSHUVSDFHLQFOXGLQJWKHEDFNRIWKHFHLOLQJRIWKHLQGRRUXQLWZKHUHWKHUHLVQRSRVVLEOHGULSSLQJRIZDWHUIURPWKH
UHIULJHUDQWSLSHGUDLQSLSHZDWHUSLSHHWF
:KHUHWKHZDOOLVVWURQJHQRXJKWREHDUWKHLQGRRUXQLWZHLJKW
:KHUHVXIILFLHQWFOHDUDQFHIRULQVWDOODWLRQDQGPDLQWHQDQFHFDQEHHQVXUHG
5HIHUWR)LJDQG)LJ
:KHUHRSWLPXPDLUGLVWULEXWLRQFDQEHHQVXUHG
:KHUHQRWKLQJEORFNVWKHDLUSDVVDJH
:KHUHFRQGHQVDWHFDQEHSURSHUO\GUDLQHG
:KHUHWKHZDOOLVQRWVLJQLILFDQWO\WLOWHG
:KHUHQRWH[SRVHGWRFRPEXVWLEOHJDVHV
:KHUHSLSHEHWZHHQLQGRRUDQGRXWGRRUXQLWVLVSRVVLEOHZLWKLQWKHDOORZDEOHOLPLW5HIHUWRWKHLQVWDOODWLRQPDQXDORIWKH
RXWGRRUXQLW
,QVWDOOWKHLQGRRUDQGRXWGRRUXQLWVSRZHUFDEOHDQGWUDQVPLVVLRQZLULQJDWOHDVWPIURP79VDQGUDGLRVWRSUHYHQW
GLVWRUWHGSLFWXUHVDQGVWDWLF'HSHQGLQJRQWKHW\SHDQGVRXUFHRIWKHHOHFWULFDOZDYHVVWDWLFPD\EHKHDUGHYHQZKHQ
PRUHWKDQPDZD\
,QVWDOOWKHLQGRRUXQLWQROHVVWKDQPDERYHWKHIORRU:KHUHXQDYRLGDEO\ORZHUWDNHZKDWPHDVXUHVDUHQHFHVVDU\WR
NHHSKDQGVRXWRIWKHDLULQOHW
:KHUHWKHFRROZDUPDLUUHDFKHVDOODFURVVWKHURRP
 &RQVLGHUZKHWKHUWKHSODFHZKHUHWKHXQLWZLOOEHLQVWDOOHGFDQVXSSRUWWKHIXOOZHLJKWRIWKHXQLWDQGUHLQIRUFHLWZLWK
ERDUGVDQGEHDPVHWFLIQHHGHGEHIRUHSURFHHGLQJZLWKWKHLQVWDOODWLRQ$OVRUHLQIRUFHWKHSODFHWRSUHYHQWYLEUD
WLRQDQGQRLVHEHIRUHLQVWDOOLQJ7KHLQVWDOODWLRQSLWFKFDQEHIRXQGRQWKHSDSHUSDWWHUQIRULQVWDOODWLRQVRUHIHU
WRLWZKHQFRQVLGHULQJWKHQHFHVVLW\IRUUHLQIRUFLQJWKHORFDWLRQ
 7KHLQGRRUXQLWPD\QRWEHGLUHFWO\LQVWDOOHGRQWKHZDOO8VHWKHDWWDFKHGLQVWDOODWLRQSDQHOEHIRUHLQVWDOOLQJWKH
XQLW
>6SDFHUHTXLUHGIRULQVWDOODWLRQPP@
)LJ
)LJ
 



2EVWUXFWLRQ
IURPIORRU
)RULQVWDOODWLRQLQ
KLJKSODFHV
Daikin VRV järjestelmät toimittaa ja asentaa Jäähdytinpalvelu RefGroup Oy

Naamloze Vennootschap - Zandvoordestraat 300, B-8400 Oostende - Belgium - www.daikin.eu - BE 0412 120 336 - RPR OostendeNaamloze Vennootschap - Zandvoordestraat 300, B-8400 Oostende - Belgium - www.daikin.eu - BE 0412 120 336 - RPR Oostende EEDEN11-204 • CD • 06/11 • Copyright Daikin The present publication supersedes EEDEN10-204 Printed in Belgium by Lannoo (www.lannooprint.be), a company whose concern for the environment is set in the EMAS and ISO 14001 systems. Responsible Editor: Daikin Europe N.V., Zandvoordestraat 300, B-8400 Oostende
Daikin’s unique position as a manufacturer of air
conditioning equipment, compressors and refrigerants
has led to its close involvement in environmental issues.
For several years Daikin has had the intention to become
a leader in the provision of products that have limited
impact on the environment. This challenge demands the
eco design and development of a wide range of products
and an energy management system, resulting in energy
conservation and a reduction of waste.
Daikin products are distributed by:
VRV® products are not within the scope of the
Eurovent certification programme.
The present publication is drawn up by way of information only and does not
constitute an offer binding upon Daikin Europe N.V.. Daikin Europe N.V. has
compiled the content of this publication to the best of its knowledge. No express
or implied warranty is given for the completeness, accuracy, reliability or fitness
for particular purpose of its content and the products and services presented
therein. Specifications are subject to change without prior notice. Daikin Europe
N.V. explicitly rejects any liability for any direct or indirect damage, in the broadest
sense, arising from or related to the use and/or interpretation of this publication.
All content is copyrighted by Daikin Europe N.V..
Daikin VRV järjestelmät toimittaa ja asentaa Jäähdytinpalvelu RefGroup Oy
