Specifications EDUS391437-F15
4FXUQ-PVJU
4-Way Blow Ceiling-Suspended Type
Notes:
+1. Nominal cooling capacities are based on the following conditions:
Return air temperature: 80.0°FDB (26.7°CDB), 67.0°FWB (19.4°CWB)
Outdoor temperature: 95.0°FDB (35.0°CDB)
Equivalent ref. piping length: 25ft (7.6m) (Horizontal)
+2. Nominal heating capacities are based on the following conditions:
Return air temperature: 70.0°FDB (21.1°CDB).
Outdoor temperature: 47.0°FDB (8.3°CDB), 43.0°FWB (6.1°CWB)
Equivalent ref. piping length: 25ft (7.6m) (Horizontal)
+3. Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
+4. Anechoic chamber conversion value, measured under JIS conditions. During actual operation,
these values may be higher as a result of installation conditions.
5. Refer to Electric Characteristics for the power input.
Model FXUQ30PVJU FXUQ36PVJU
Power supply 1 phase, 60Hz, 208/230V 1 phase, 60Hz, 208/230V
+1 +3 Cooling capacity Btu/h
(kW) 30,000 (8.8) 36,000 (10.6)
+2 +3 Heating capacity Btu/h
(kW) 34,000 (10.0) 40,000 (11.7)
Casing / Color Resin/Fresh White Resin/Fresh White
Dimensions: (H×W×D) in.
(mm) 7-13/16×37-3/8×37-3/8
(198×950×950) 7-13/16×37-3/8×37-3/8
(198×950×950)
Coil (Cross
fin coil)
Rows×Stages×FPI 3×10×21 3×10×21
Face area ft2(m2) 3.55 (0.330) 3.55 (0.330)
Fan
Model QTS48D11M QTS48D11M
Type Turbo fan Turbo fan
Motor output W 106 106
Airflow rate (H/M/L) cfm
(m
3
/min)
1,095/918/742 (31.0/26.0/21.0) 1,095/918/742 (31.0/26.0/21.0)
Drive Direct drive Direct drive
Temperature control Microprocessor thermostat
for cooling and heating Microprocessor thermostat
for cooling and heating
Sound absorbing thermal insulation material Polyethylene foam Polyethylene foam
Weight lbs (kg) 60 (27) 60 (27)
+4 Sound pressure level (H/M/L)
(Reference data) dB (A) 47/44/40 47/44/40
+4 Sound power level (H/M/L)
(Reference data) dB (A) 65/62/58 65/62/58
Piping
connections
Liquid pipes in.
(mm) φ3/8 (9.5) (Flare connection) φ3/8 (9.5) (Flare connection)
Gas pipes in.
(mm) φ5/8 (15.9) (Flare connection) φ5/8 (15.9) (Flare connection)
Drain pipe in.
(mm)
VP20
External dia. 1 (26)
Internal dia. 13/16 (20)
VP20
External dia. 1 (26)
Internal dia. 13/16 (20)
Safety devices Fuse Fuse
Refrigerant control Electronic expansion valve Electronic expansion valve
Connectable outdoor unit R410A VRV series R410A VRV series
Standard accessories
Operation manual, Installation manual, Paper pattern for
installation, Drain hose, Sealing pads, Clamps, Washers,
Screws, Insulation for fitting, Clamp metal, Conduit mounting
plate
Operation manual, Installation manual, Paper pattern for
installation, Drain hose, Sealing pads, Clamps, Washers,
Screws, Insulation for fitting, Clamp metal, Conduit mounting
plate
Drawing No. C: 3D090219A C: 3D090219A
