technical data
Split
Sky Air
air conditioning systems
RZQS71-140C7V1B
EEDEN08-100

• Split Sky Air • Outdoor Units 4
• Outdoor Units • R-410A • RZQS71-140C7V1B
TABLE OF CONTENTS
RZQS71-140C7V1B
1Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Nominal Capacity and Nominal Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3 Electrical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5 Capacity tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Combination table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Cooling capacity tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Heating capacity tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6 Dimensional drawing & centre of gravity . . . . . . . . . . . . . . . . . . . . . . . 27
Dimensional drawing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Centre of gravity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
7 Piping diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
8 Wiring diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Wiring diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
9 Sound data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Sound pressure spectrum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Sound power spectrum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
10 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Installation method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
11 Operation range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

• Outdoor Units • R-410A • RZQS71-140C7V1B
1
1
• Split Sky Air • Outdoor Units
5
1 Features
OutdoorUni SplitSky RZQS71-140C7V R-410A • Outdoor units for pair, twin, triple, double twin application
• The Sky Air Inverter is developed for use in shops, restaurants and
small offices. This innovative Daikin unit provides a more
comfortable environment and offers great savings in energy
consumption to shop and office owners.
• The use of inverter type outdoor units results in an air conditioning
system with a high energy efficiency and very low sound level
• An inverter driven compressor allows the capacity to be adjusted
precisely to match variations in room and outside temperatures.
• During start up, the room can be cooled down or heated very quickly.
Once the temperature in the room has reached its set point, the low
power operation starts to save energy.
• Daikin outdoor units are neat and sturdy and can be mounted easily
on a roof or terrace or simply placed against an outside wall.
• Outdoor units are fitted with either a swing or scroll compressor,
renowned for low noise and high energy efficiency
• A special acryl precoated fin for anti-corrosion treatment on the heat
exchanger ensures greater resistance against severe weather
conditions

3
1
2
• Split Sky Air • Outdoor Units 6
• Outdoor Units • R-410A • RZQS71-140C7V1B
2 Specifications
2-1 NOMINAL CAPACITY AND
NOMINAL INPUT RZQS71C7V1B RZQS100C7V1B RZQS125C7V1B RZQS140C7V1B
For
combination
indoor units +
outdoor units
Indoor Units FCHQ71C7VEB FCHQ100C7VEB FCHQ125C7VEB FCHQ140C7VEB
Cooling capacity Standard kW 7.1 10.0 12.5 14.0
Heating capacity Standard kW 8.0 11.2 14.0 16.0
Power Input Cooling Standard kW 2.36 3.56 3.88 4.98
Heating Standard kW 2.34 3.28 4.11 4.98
For
combination
indoor units +
outdoor units
EER Nominal 3.01 2.81 3.22 2.81
COP Nominal 3.41 3.41 3.41 3.21
Energy Label Cooling B C A C
HeatingBBBC
Annualenergyconsumption kWh 1,180 1,780 1,940 2,490
Indoor Units FCQ71C7VEB FCQ100C7VEB FCQ125C7VEB FCQ140C7VEB
Cooling capacity Standard kW 7.1 10.0 12.5 14.0
Heating capacity Standard kW 8.0 11.2 14.0 16.0
Power Input Cooling Standard kW 2.46 3.83 4.14 5.36
Heating Standard kW 2.61 3.47 4.52 5.69
For
combination
indoor units +
outdoor units
EER Nominal 2.89 2.61 3.02 2.61
COP Nominal 3.07 3.23 3.1 2.81
Energy Label Cooling C D B D
HeatingDCDD
Annualenergyconsumption kWh 1,230 1,915 2,070 2,680
Indoor Units FBQ71B8V3B FBQ100B8V3B FBQ125B8V3B FBQ140B8V3B
Cooling capacity Standard kW 7.1 10.0 12.5 13.4
Heating capacity Standard kW 8.0 11.2 14.0 15.5
Power Input Cooling Standard kW 2.52 3.83 4.4 4.97
Heating Standard kW 2.40 3.47 4.24 4.99
For
combination
indoor units +
outdoor units
EER Nominal 2.82 2.61 2.84 2.70
COP Nominal 3.33 3.23 3.3 3.11
Energy Label Cooling C D C D
HeatingCCCD
Annualenergyconsumption kWh 1,260 1,915 2,200 2,485
Indoor Units FHQ71BVV1B FHQ100BVV1B FHQ125BVV1B
Cooling capacity Standard kW 7.1 10.0 12.5
Heating capacity Standard kW 8.0 11.2 14.0
Power Input Cooling Standard kW 2.53 4.15 4.58
Heating Standard kW 2.85 3.99 4.96
For
combination
indoor units +
outdoor units
EER Nominal 2.81 2.41 2.73
COP Nominal 2.81 2.81 2.82
Energy Label Cooling C E D
HeatingCDD
Annualenergyconsumption kWh 1,265 2,075 2,290
Indoor Units FAQ71BVV1B FAQ100BVV1B FDQ125B8V3B
Cooling capacity Standard kW 7.1 10.0 12.5
Heating capacity Standard kW 8.0 11.2 14.0
Power Input Cooling Standard kW 2.53 4.08 4.45
Heating Standard kW 2.61 3.73 4.08
For
combination
indoor units +
outdoor units
EER Nominal 2.81 2.45 2.81
COP Nominal 3.07 3.00 3.43
Energy Label Cooling C F C
Heating D D B
Annualenergyconsumption kWh 1,265 2,040 2,225
Indoor Units FVQ71BV1B FVQ100BV1B FVQ125BV1B
Cooling capacity Standard kW 7.1 10.0 12.5
Heating capacity Standard kW 8.0 11.2 14.0
Power Input Cooling Standard kW 2.53 4.02 4.45
Heating Standard kW 2.49 3.99 4.36

• Outdoor Units • R-410A • RZQS71-140C7V1B
1
2
• Split Sky Air • Outdoor Units
7
2 Specifications
For
combination
indoor units +
outdoor units
EER Nominal 2.81 2.49 2.81
COP Nominal 3.21 2.81 3.21
Energy Label Cooling C E C
Heating C D C
Annualenergyconsumption kWh 1,265 2,010 2,225
2-2 TECHNICAL SPECIFICATIONS RZQS71C7V1B RZQS100C7V1B RZQS125C7V1B RZQS140C7V1B
Casing Colour Ivory White
Material Painted galvanised steel
Dimensions Unit Height mm 770 700 1,170 1170
Width mm 900 900 900 900
Depth mm 320 320 320 320
Packing Height mm 900 900 1,349 1349
Width mm 980 980 980 980
Depth mm 420 420 420 420
Weight Unit kg 68 68 103 103
Packed Unit kg 72 72 114 114
Heat
Exchanger Dimensions Length mm 857 857 857 857
Nr of Rows 2 2 2 2
Fin Pitch mm 1.4 1.4 1.4 1.4
Nr of Passes 8 8 10 10
Face Area m² 0.641 0.641 0.98 0.98
Nr of Stages 34 34 52 52
Tube type Hi-XSS(8)
Fin Type WF fin
Treatment Anti-corrosion treatment (PE)
Fan Type Propeller
Discharge direction Horizontal
Quantity 1122
Air Flow Rate
(nominal at
230V)
Cooling m³/min 52 61.3 100 97
Heating m³/min 52 63.5 88 88
Motor Quantity 1 1 2 2
Model KFD-325-70-8A KFD-325-70-8A Brushless DC Motor
Motor Speed
(nominal) Steps 8 8 10 10
Cooling
(Standard)
rpm 800 920 850 830
Heating
(Standard)
rpm 745 950 740 740
Fan Motor Output W 70 70 70 70
CompressorQuantity 1111
Motor Model 2YC63DXD 2YC63DXD JT100G-VD JT100G-VD
Type Hermetically sealed swing compressor Hermetically sealed scroll compressor
Motor
Output W 1,700 2,400 2,200 2,200
Crankcase
Heater W3333
Starting Method Inverter driven
Operation
Range Cooling Min °CDB -5 -5 -5 -5
Max °CDB 46 46 46 46
Heating Min °CWB -15 -15 -15 -15
Max °CWB 15.5 15.5 15.5 15.5
2-1 NOMINAL CAPACITY AND
NOMINAL INPUT RZQS71C7V1B RZQS100C7V1B RZQS125C7V1B RZQS140C7V1B

3
1
2
• Split Sky Air • Outdoor Units 8
• Outdoor Units • R-410A • RZQS71-140C7V1B
2 Specifications
Sound Level
(nominal) Cooling Sound Power dBA65676768
Sound
Pressure
(Standard)
dBA49515152
Heating
Sound
Pressure
(Standard)
dBA51555354
Sound Level
(Night quiet) SoundPressure dBA 47 49 49 50
Refrigerant Type R-410A
Charge kg 2.75 2.75 3.7 3.7
Control Expansion valve (electronic type)
Nr of Circuits 1 1 1 1
Refrigerant Oil Type FVC50K FVC50K Daphne FVC68D Daphne FVC68D
Charged Volume l 0.75 0.75 1.0 1.0
Piping
connections Liquid (OD) Quantity 1 1 1 1
Type Flare connection
Diameter
(OD) mm 9.52 9.52 9.52 9.52
Gas Quantity 1 1 1 1
Type Flare connection
Diameter
(OD) mm 15.9 15.9 15.9 15.9
Drain Quantity 3 3 3 3
Type Hole
Diameter
(OD) mm 26 26 26 26
Piping Length Minimum m 5 5 5 5
Maximum m 30 50 50 50
Equivalent m40707070
Chargeless m30303030
Additional Refrigerant Charge kg/m see installation manual 4PW40416-1 see installation manual 4PW34874-1
Installation
height
difference
Maximum m 15 30 30.0 30.0
Max. internunit level
difference m 0.5 0.5 0.5 0.5
Heat Insulation Both liquid and gas pipes
Defrost Method Pressure equalising
Defrost Control Temperature Sensor for outdoor heat exchanger temperature
Capacity Control Method Inverter controlled
Safety Devices High pressure switch
Fan motor thermal protector
Fuse
Standard
Accessories Item Tie-wraps
Quantity 2 2 2 2
Item Installation manual
Quantity 1 1 1 1
Notes Nominalcooling capacitiesare basedon: indoor temperature: 27°CDB,19°CWB, outdoortemperature: 35°CDB,
equivalent refrigerant piping : 5m, level difference : 0m.
Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB,
equivalent refrigerant piping : 5m, level difference : 0m
2-2 TECHNICAL SPECIFICATIONS RZQS71C7V1B RZQS100C7V1B RZQS125C7V1B RZQS140C7V1B

• Outdoor Units • R-410A • RZQS71-140C7V1B
1
2
• Split Sky Air • Outdoor Units
9
2 Specifications
2-3 ELECTRICAL SPECIFICATIONS RZQS71C7V1B RZQS100C7V1B RZQS125C7V1B RZQS140C7V1B
Power Supply Name V1
Phase 1~
Frequency Hz 50 50 50 50
Voltage V 220-240
Voltage range Minimum V 198 198 198 198
Maximum V 264 264 264 264
Current Rsce/Sse -/kVA Equipment complying with EN 61000-3-12
Recomendedfuses A 20 20 32 32
Wiring
connections
ForPower Supply Remark see installation manual 4PW40416-1 see installation manual 4PW34874-1
For connection
with indoor Remark see installation manual 4PW40416-1 see installation manual 4PW34874-1
Power Supply Intake Outdoor unit only
Notes See separate drawings for electrical data
Power supply to the FDQ
indoor unit is separate

3
1
3
• Split Sky Air • Outdoor Units 10
• Outdoor Units • R-410A • RZQS71-140C7V1B
3 Electrical data
3D059191A
SYMBOLS
MCA : Min. Circuit Amps (A)
TOCA : Total Over Current Amps (A)
MFA : Max. Fuse Amps (A) (See note 7)
MSC : MSC means the max. current during the
starting of compressor. (A)
RLA : Rated Load Amps (A)
OFM : Outdoor Fan Motor (A)
IFM : Indoor Fan Motor
FLA : Full Load Amps
kW : Fan Motor Rated Output (kW)
NOTES
1 RLA is based on the following conditions:
Power supply: 50Hz - 230V
Cooling
Indoor temperature 27°CDB/19°CWB
Outdoor temperature 35°CDB
Heating
Indoor temperature 20.0°CDB
Outdoor temperature 7.0°CDB/6.0°CWB
2 TOCA means the total value of each OC set
3 Voltage range
Units are suitable for use on electrical systems where voltage supplied to unit terminals is not below or
above listed operation range limits
4 Maximum allowable voltage unbalance between phases is 2%
5 MCA represents maximum input current., MFA represents capacity which may accept MCA
(next lower standard fuse rating, min.15A)
6 Select wire size based on the larger value of MCA or TOCA
7 MFA is used to select the circuit breaker and the ground fault circuit interrupter (earth leakage circuit breaker)
Max. 50Hz 264V
Min. 50Hz 198V
Max. 50Hz 264V
Min. 50Hz 198V
RZQ(S)71-100C
Unit combination Power supply Comp. OFM IFM
Indoor unit Outdoor unit Hz-volts Voltage range MCA TOCA MFA MSC RLA kW FLA kW FLA
Max. 50Hz 264V
Min. 50Hz 198V

• Outdoor Units • R-410A • RZQS71-140C7V1B
1
3
• Split Sky Air • Outdoor Units
11
3 Electrical data
3D057296C
SYMBOLS
MCA : Min. Circuit Amps (A)
TOCA : Total Over Current Amps (A)
MFA : Max. Fuse Amps (A) (See note 7)
MSC : MSC means the max. current during the
starting of compressor. (A)
RLA : Rated Load Amps (A)
OFM : Outdoor Fan Motor (A)
IFM : Indoor Fan Motor
FLA : Full Load Amps
kW : Fan Motor Rated Output (kW)
Max. 50Hz 264V
Min. 50Hz 198V
Max. 50Hz 264V
Min. 50Hz 198V
RZQS125-140C
Unit combination Power supply Comp. OFM IFM
Indoor unit Outdoor unit Hz-volts Voltage range MCA TOCA MFA MSC RLA kW FLA kW FLA
NOTES
1 RLA is based on the following conditions:
Power supply: 50Hz - 230V
Cooling
Indoor temperature 27°CDB/19°CWB
Outdoor temperature 35°CDB
Heating
Indoor temperature 20.0°CDB
Outdoor temperature 7.0°CDB/6.0°CWB
2 TOCA means the total value of each OC set
3 Voltage range
Units are suitable for use on electrical systems where voltage supplied to unit terminals is not below or
above listed operation range limits
4 Maximum allowable voltage unbalance between phases is 2%
5 MCA represents maximum input current., MFA represents capacity which may accept MCA
(next lower standard fuse rating, min.15A)
6 Select wire size based on the larger value of MCA or TOCA
7 MFA is used to select the circuit breaker and the ground fault circuit interrupter (earth leakage circuit breaker)

3
1
4
• Split Sky Air • Outdoor Units 12
• Outdoor Units • R-410A • RZQS71-140C7V1B
4 Options
Available options for RZQS100-140C7V1B
Name of option Kit name
RZQS125C7V1B RZQS140C7V1B
Central drain pan kit KKPJ5F180
Refrigerant branch piping Twin KHRQ22M20TA
Triple KHRQ127H
Double twin KHRQ22M20TA (3x)
Demand adaptor KRP58M51
3TW26739-1E

• Outdoor Units • R-410A • RZQS71-140C7V1B
1
5
• Split Sky Air • Outdoor Units
13
5 Capacity tables
5 - 1 Combination table
3TW30469-1
NOTES
1 See main specifications table about MAX cooling capacity & heating capacity.
2 Combinations are possible regardingless type of I/U. (e.g. RZQS100 can be combined with FFQ50 + FBQ50)
3 Individual indoor capacities are not given because the combinations are for simultaneous operation (=indoor units installed in same room).
4 When different indoor models are used in combination, designate the infrared remote controller that is equipped with the most functions as the main unit.
In table above are the indoor units mentioned in order of the possible function (most functions are on FCQ, less functions are on FAQ).
5 Refnet kits that are necessary to install the combinations:
Twin: KHRQ22M20TA
Triple: KHRQ127H
P = Pair 71 100
2 = Twin 35+35 50+50
3 = Triple 35+35+35
Model name
Hi casette
2x2 cassette
Thin cassette
Duct (medium ESP)
4way ceiling
Ceiling suspended
Outdoor unit
Wall mounted
Refrigerant R410A

3
1
5
• Split Sky Air • Outdoor Units 14
• Outdoor Units • R-410A • RZQS71-140C7V1B
5 Capacity tables
5 - 1 Combination table
Possible indoor combination
Simultaneous operation
Outdoor models
Twin Triple Double twin
RZQS125C7V1B 60-60
(KHRQ22M20TA)
50-50-50
(KHRQ127H)
35-35-35-35
(3x KHRQ22M20TA)
RZQS140C7V1B 71-71
(KHRQ22M20TA)
50-50-50
(KHRQ127H)
35-35-35-35
(3x KHRQ22M20TA)
3TW29169-3
NOTES
1 Possible indoor units:FCQH71C, FCQ35-71C, FFQ35-60BV, FHQ35-71B, FBQ35-71B, FAQ71B
2 Individual indoor capacities are not given because the combinations are for simultaneous operation (=indoor units installed in same room).
3 When different indoor models are used in combination, designate the infrared remote controller that is equipped with the most functions as the
main unit.In note 1 are the indoor units mentioned in order of the possible function (most functions are on FCQ, less functions are on FAQ).
4 Between brackets are the required Refnet kits mentioned, that are necessary to install the combination.
Out
In In
Out
In
In In
RZQS 125-140C
Possible combinations and standard capacity for twin, triple and double twin operation
In
In In
Out
In

• Outdoor Units • R-410A • RZQS71-140C7V1B
1
5
• Split Sky Air • Outdoor Units
15
5 Capacity tables
5 - 2 Cooling capacity tables
RZQS71C
Cooling
Cooling capacity
Indoor Outdoor temp. (°CDB)
EWB EDB 25 30 35 40
(°C) (°C) TC
(kW)
SHC
(kW)
CPI
(-)
TC
(kW)
SHC
(kW)
CPI
(-)
TC
(kW)
SHC
(kW)
CPI
(-)
TC
(kW)
SHC
(kW)
CPI
(-)
16.0 22 6.47 4.39 0.76 6.46 4.43 0.89 6.66 4.62 0.99 6.39 4.49 1.09
18.0 25 7.43 4.82 0.83 7.20 4.72 0.91 6.95 4.61 1.00 6.67 4.47 1.10
19.0 27 7.58 4.80 0.84 7.35 4.71 0.91 7.10 4.60 1.00 6.82 4.46 1.10
19.5 27 7.6 4.79 0.84 7.43 4.70 0.91 7.17 4.59 1.00 6.86 4.46 1.10
22.0 30 8.05 4.73 0.85 7.81 4.64 0.92 7.55 4.54 1.01 7.26 4.41 1.11
24.0 32 8.37 4.66 0.85 8.12 4.58 0.93 7.85 4.48 1.02 7.55 4.35 1.12
3D059189A
SYMBOLS
AFR: Air flow rate (m
3
/min)
BF: Bypass factor
EWB: Entering wet bulb temp. (°CWB)
EDB: Entering dry bulb temp. (°CDB)
TC: Total cooling/heating capacity (kW)
SHC: Sensible heating capacity (kW)
PI: Power input (kW)
(comp.+indoor+outdoor fan motor)
CPI: Coefficient of power input. (-)
Caution:
TC and SHC are shown by kW
NOTES
1. Ratings shown are net capacities which include a deduction for indoor fan motor heat
2. On the figure the mark jshow the max. at standard conditions.
On the figure the mark Qshow rated capacity and rated coefficient of power input.
However the max. capacity is not guaranteed, except at standard condition.
3. On the tables Qshow rated capacity and rated coefficient of power input.
4. SHC is based on each EWB and EDB
SHC* = SHC correction for other dry bulb
SHC* = 0.02 x AFR (m
3
/min.) x (1−BF) x (DB*−EDB)
Add SHC* to SHC.
5. Capacities are based on following conditions:
Outdoor air : 85 % RH. however, the condition on nominal capacity is 7° CDB/6° CWB (heating)
Corresponding refrigerant piping length : 5.0 m
Level difference : 0 m
6. Coefficient of power input is the percentage when the rated valve is defined as 1.00.
7. The value contains less than 5% error acording to indoor unit type.
8. Heating capacity include the drop of frost formation.
9. Air flow rate and BF are tabulated below.
(Pair)
Model FCQH71C FCQ71C FBQ71 FHQ71 FAQ71 FVQ71
AFR
(BF)
20
(0.17)
15.5
(0.19)
19
(0.11)
17
(0.10)
19
(0.08)
18
(0.16)
(Multi)
Model FCQ35Cx2 FFQ35x2 FBQ35x2 FHQ35x2
AFR
(BF)
10.5x2
(0.28x2)
10x2
(0.25x2)
11.5x2
(0.15x2)
13x2
(0.2x2)
10. Rated power input of each model is tabulated below.
(Pair)
Model FCQH71C FCQ71C FBQ71 FHQ71 FAQ71 FVQ71
Cooling 2.36 2.46 2.52 2.53 2.53 2.53
Heating 2.34 2.61 2.40 2.85 2.61 2.49
(Multi)
Model FCQ35Cx2 FFQ35x2 FBQ35x2 FHQ35x2
Cooling 2.59 2.61 2.57 2.66
Heating 2.75 2.70 2.47 2.85
Capacity range Rated point
Cooling capacity (kW)
Coefficient of power input. (-)

3
1
5
• Split Sky Air • Outdoor Units 16
• Outdoor Units • R-410A • RZQS71-140C7V1B
5 Capacity tables
5 - 2 Cooling capacity tables
RZQS100C
Cooling
Cooling capacity
Indoor Outdoor temp. (°CDB)
EWB EDB 25 30 35 40
(°C) (°C) TC
(kW)
SHC
(kW)
CPI
(-)
TC
(kW)
SHC
(kW)
CPI
(-)
TC
(kW)
SHC
(kW)
CPI
(-)
TC
(kW)
SHC
(kW)
CPI
(-)
16.0 22 9.12 6.19 0.76 9.10 6.25 0.89 9.38 6.51 0.99 9.00 6.32 1.09
18.0 25 10.5 6.78 0.83 10.1 6.65 0.91 9.79 6.49 1.00 9.40 6.30 1.10
19.0 27 10.7 6.76 0.84 10.4 6.63 0.91 10.0 6.48 1.00 9.60 6.29 1.10
19.5 27 10.8 6.75 0.84 10.5 6.62 0.91 10.1 6.47 1.00 9.71 6.28 1.10
22.0 30 11.3 6.66 0.85 11.0 6.54 0.92 10.6 6.39 1.01 10.2 6.21 1.11
24.0 32 11.8 6.57 0.85 11.4 6.45 0.93 11.1 6.30 1.02 10.6 6.13 1.12
3D059188A
SYMBOLS
AFR: Air flow rate (m
3
/min)
BF: Bypass factor
EWB: Entering wet bulb temp. (°CWB)
EDB: Entering dry bulb temp. (°CDB)
TC: Total cooling/heating capacity (kW)
SHC: Sensible heating capacity (kW)
PI: Power input (kW)
(comp.+indoor+outdoor fan motor)
CPI: Coefficient of power input. (-)
Caution:
TC and SHC are shown by kW
NOTES
1. Ratings shown are net capacities which include a deduction for indoor fan motor heat
2. On the figure the mark jshow the max. at standard conditions.
On the figure the mark Qshow rated capacity and rated coefficient of power input.
However the max. capacity is not guaranteed, except at standard condition.
3. On the tables Qshow rated capacity and rated coefficient of power input.
4. SHC is based on each EWB and EDB
SHC* = SHC correction for other dry bulb
SHC* = 0.02 x AFR (m
3
/min.) x (1−BF) x (DB*−EDB)
Add SHC* to SHC.
5. Capacities are based on following conditions:
Outdoor air : 85 % RH. however, the condition on nominal capacity is 7° CDB/6° CWB (heating)
Corresponding refrigerant piping length : 5.0 m
Level difference : 0 m
6. Coefficient of power input is the percentage when the rated valve is defined as 1.00.
7. The value contains less than 5% error acording to indoor unit type.
8. Heating capacity include the drop of frost formation.
9. Air flow rate and BF are tabulated below.
(Pair)
Model FCQH100C FCQ100C FBQ100 FHQ100 FAQ100 FVQ100
AFR
(BF)
32.5
(0.17)
23.5
(0.16)
27
(0.20)
24
(0.14)
23
(0.10)
28
(0.19)
(Twin)
Model FCQ35Cx2 FFQ35x2 FBQ35x2 FHQ35x2
AFR
(BF)
10.5x2
(0.28x2)
10x2
(0.25x2)
11.5x2
(0.15x2)
13x2
(0.2x2)
(Triple)
Model FCQ35Cx3 FFQ35x3 FBQ35x3 FHQ35x3
AFR
(BF)
10.5x3
(0.28x3)
10x3
(0.25x3)
11.5x3
(0.15x3)
13x3
(0.2x3)
Capacity range Rated point
Cooling capacity (kW)
Coefficient of power input. (-)
10. Rated power input of each model is tabulated below.
(Pair)
Model FCQH100C FCQ100C FBQ100 FHQ100 FAQ100 FVQ100
Cooling 3.56 3.83 3.83 4.15 4.08 4.02
Heating 3.28 3.47 3.47 3.99 3.73 3.99
(Twin)
Model FCQ50Cx2 FFQ50x2 FBQ50x2 FHQ50x2
Cooling 3.83 3.83 3.83 4.15
Heating 3.65 3.54 3.58 3.99
(Triple)
Model FCQ50Cx3 FFQ50x3 FBQ50x3 FHQ50x3
Cooling 3.83 3.83 3.83 4.15
Heating 3.65 3.54 3.58 3.99

• Outdoor Units • R-410A • RZQS71-140C7V1B
1
5
• Split Sky Air • Outdoor Units
17
5 Capacity tables
5 - 2 Cooling capacity tables
RZQS125C
Cooling
Cooling capacity
Indoor Outdoor temp. (°CDB)
EWB EDB 25 30 35 40
(°C) (°C) TC
(kW)
SHC
(kW)
CPI
(-)
TC
(kW)
SHC
(kW)
CPI
(-)
TC
(kW)
SHC
(kW)
CPI
(-)
TC
(kW)
SHC
(kW)
CPI
(-)
16.0 22 11.4 7.73 0.76 11.4 7.81 0.89 11.7 8.14 0.99 11.3 7.90 1.09
18.0 25 13.1 8.48 0.83 12.7 8.32 0.91 12.2 8.12 1.00 11.8 7.88 1.10
19.0 27 13.3 8.45 0.84 12.9 8.29 0.91 12.5 8.09 1.00 12.0 7.86 1.10
19.5 27 13.5 8.44 0.84 13.1 8.28 0.91 12.6 8.08 1.00 12.1 7.85 1.10
22.0 30 14.2 8.33 0.85 13.8 8.18 0.92 13.3 7.99 1.01 12.8 7.76 1.11
24.0 32 14.7 8.21 0.85 14.3 8.06 0.93 13.8 7.88 1.02 13.3 7.67 1.12
3D057300A
SYMBOLS
AFR: Air flow rate (m
3
/min)
BF: Bypass factor
EWB: Entering wet bulb temp. (°CWB)
EDB: Entering dry bulb temp. (°CDB)
TC: Total cooling/heating capacity (kW)
SHC: Sensible heating capacity (kW)
PI: Power input (kW)
(comp.+indoor+outdoor fan motor)
CPI: Coefficient of power input. (-)
Caution:
TC and SHC are shown by kW
NOTES
1. Ratings shown are net capacities which include a deduction for indoor fan motor heat
2. On the figure the mark jshow the max. at standard conditions.
On the figure the mark Qshow rated capacity and rated coefficient of power input.
However the max. capacity is not guaranteed, except at standard condition.
3. On the tables Qshow rated capacity and rated coefficient of power input.
4. SHC is based on each EWB and EDB
SHC* = SHC correction for other dry bulb
SHC* = 0.02 x AFR (m
3
/min.) x (1−BF) x (DB*−EDB)
Add SHC* to SHC.
5. Capacities are based on following conditions:
Outdoor air : 85 % RH. however, the condition on nominal capacity is 7° CDB/6° CWB (heating)
Corresponding refrigerant piping length : 5.0 m
Level difference : 0 m
6. Coefficient of power input is the percentage when the rated valve is defined as 1.00.
7. The value contains less than 5% error acording to indoor unit type.
8. Heating capacity include the drop of frost formation.
9. Air flow rate and BF are tabulated below.
(Pair)
Model FCQH125C FCQ125C FBQ125 FHQ125 FAQ125 FVQ125
AFR
(BF)
32.5
(0.19)
27.5
(0.19)
35
(0.14)
30
(0.13)
45
(0.25)
32
(0.16)
(Twin)
Model FCQ60Cx2 FFQ60x2 FBQ60x2 FHQ60x2
AFR
(BF)
13.5x2
(0.21x2)
15x2
(0.11x2)
19x2
(0.11x2)
17x2
(0.2x2)
(Triple)
Model FCQ50Cx3 FFQ50x3 FBQ50x3 FHQ50x3
AFR
(BF)
12.5x3
(0.21x3)
12x3
(0.16x3)
14x3
(0.15x3)
13x3
(0.1x3)
(Double twin)
Model FCQ35Cx4 FFQ35x4 FBQ35x4 FHQ35x4
AFR
(BF)
10.5x4
(0.28x4)
10x4
(0.25x4)
11.5x4
(0.15x4)
13x4
(0.2x4)
Capacity range Rated point
Cooling capacity (kW)
Coefficient of power input. (-)
10. Rated power input of each model is tabulated below.
(Pair)
Model FCQH125C FCQ125C FBQ125 FHQ125 FAQ125 FVQ125
Cooling 3.88 4.14 4.40 4.58 4.45 4.45
Heating 4.11 4.52 4.24 4.96 4.08 4.36
(Twin)
Model FCQ60Cx2 FFQ60x2 FBQ60x2 FHQ60x2
Cooling 4.36 4.41 4.48 4.76
Heating 4.76 4.42 4.42 4.92
(Triple)
Model FCQ50Cx3 FFQ50x3 FBQ50x3 FHQ50x3
Cooling 4.36 4.41 4.48 4.76
Heating 4.76 4.42 4.42 4.92
(Double twin)
Model FCQ35Cx4 FFQ35x4 FBQ35x4 FHQ35x4
Cooling 4.36 4.41 4.48 4.76
Heating 4.76 4.42 4.42 4.92

3
1
5
• Split Sky Air • Outdoor Units 18
• Outdoor Units • R-410A • RZQS71-140C7V1B
5 Capacity tables
5 - 2 Cooling capacity tables
RZQS140C (Pair + twin/triple/double twin)
Cooling
Cooling capacity
Indoor Outdoor temp. (°CDB)
EWB EDB 25 30 35 40
(°C) (°C) TC
(kW)
SHC
(kW)
CPI
(-)
TC
(kW)
SHC
(kW)
CPI
(-)
TC
(kW)
SHC
(kW)
CPI
(-)
TC
(kW)
SHC
(kW)
CPI
(-)
16.0 22 12.8 8.66 0.76 12.7 8.74 0.89 13.1 9.12 0.99 12.6 8.84 1.09
18.0 25 14.6 9.50 0.83 14.2 9.31 0.91 13.7 9.09 1.00 13.2 8.82 1.10
19.0 27 15.0 9.47 0.84 14.5 9.29 0.91 14.0 9.07 1.00 13.4 8.80 1.10
19.5 27 15.1 9.45 0.84 14.7 9.27 0.91 14.1 9.05 1.00 13.6 8.79 1.10
22.0 30 15.9 9.33 0.85 15.4 9.16 0.92 14.9 8.95 1.01 14.3 8.69 1.11
24.0 32 16.5 9.20 0.85 16.0 9.03 0.93 15.5 8.83 1.02 14.9 8.59 1.12
3D057301
SYMBOLS
AFR: Air flow rate (m
3
/min)
BF: Bypass factor
EWB: Entering wet bulb temp. (°CWB)
EDB: Entering dry bulb temp. (°CDB)
TC: Total cooling/heating capacity (kW)
SHC: Sensible heating capacity (kW)
PI: Power input (kW)
(comp.+indoor+outdoor fan motor)
CPI: Coefficient of power input. (-)
Caution:
TC and SHC are shown by kW
NOTES
1. Ratings shown are net capacities which include a deduction for indoor fan motor heat
2. On the figure the mark jshow the max. at standard conditions.
On the figure the mark Qshow rated capacity and rated coefficient of power input.
However the max. capacity is not guaranteed, except at standard condition.
3. On the tables Qshow rated capacity and rated coefficient of power input.
4. SHC is based on each EWB and EDB
SHC* = SHC correction for other dry bulb
SHC* = 0.02 x AFR (m
3
/min.) x (1−BF) x (DB*−EDB)
Add SHC* to SHC.
5. Capacities are based on following conditions:
Outdoor air : 85 % RH. however, the condition on nominal capacity is 7° CDB/6° CWB (heating)
Corresponding refrigerant piping length : 5.0 m
Level difference : 0 m
6. Coefficient of power input is the percentage when the rated valve is defined as 1.00.
7. The value contains less than 5% error acording to indoor unit type.
8. Heating capacity include the drop of frost formation.
9. Air flow rate and BF are tabulated below.
(Pair)
Model FCQH140C FCQ140C
AFR
(BF)
32.5
(0.20)
27.5
(0.22)
(Triple)
Model FCQ50Cx3 FFQ50x3 FBQ50x3 FHQ50x3
AFR
(BF)
12.5x3
(0.21x3)
12x3
(0.16x3)
14x3
(0.15x3)
13x3
(0.1x3)
10. Rated power input of each model is tabulated below.
(Pair)
Model FCQH140C FCQ140C
Cooling 4.98 5.36
Heating 4.98 5.69
(Triple)
Model FCQ50Cx3 FFQ50x3 FBQ50x3 FHQ50x3
Cooling 5.36 5.12 5.21 5.25
Heating 5.55 5.70 5.64 5.70
Capacity range Rated point
Cooling capacity (kW)
Coefficient of power input. (-)
(Twin)
Model FCQ71Cx2 FBQ71x2 FHQ71x2 FAQ71x2
AFR
(BF)
15.5x2
(0.19x2)
19x2
(0.11x2)
17x2
(0.1x2)
19x2
(0.08x2)
(Double twin)
Model FCQ35Cx4 FFQ35x4 FBQ35x4 FHQ35x4
AFR
(BF)
10.5x4
(0.28x4)
10x4
(0.25x4)
11.5x4
(0.15x4)
13x4
(0.2x4)
(Twin)
Model FCQ71Cx2 FBQ71x2 FHQ71x2 FAQ71x2
Cooling 5.36 5.21 5.25 5.25
Heating 5.55 5.64 5.70 5.63
(Double twin)
Model FCQ35Cx4 FFQ35x4 FBQ35x4 FHQ35x4
Cooling 5.36 5.12 5.21 5.25
Heating 5.55 5.70 5.64 5.70

• Outdoor Units • R-410A • RZQS71-140C7V1B
1
5
• Split Sky Air • Outdoor Units
19
5 Capacity tables
5 - 2 Cooling capacity tables
RZQS140C (Pair)
Cooling
Cooling capacity
Indoor Outdoor temp. (°CDB)
EWB EDB 25 30 35 40
(°C) (°C) TC
(kW)
SHC
(kW)
CPI
(-)
TC
(kW)
SHC
(kW)
CPI
(-)
TC
(kW)
SHC
(kW)
CPI
(-)
TC
(kW)
SHC
(kW)
CPI
(-)
16.0 22 12.3 8.29 0.76 12.2 8.37 0.89 12.5 8.73 0.99 12.1 8.46 1.09
18.0 25 14.0 9.09 0.83 13.6 8.91 0.91 13.1 8.70 1.00 12.6 8.44 1.10
19.0 27 14.4 9.06 0.84 13.9 8.89 0.91 13.4 8.68 1.00 12.8 8.42 1.10
19.5 27 14.5 9.05 0.84 14.1 8.87 0.91 13.5 8.66 1.00 13.0 8.41 1.10
22.0 30 15.2 8.93 0.85 14.7 8.77 0.92 14.3 8.57 1.01 13.7 8.32 1.11
24.0 32 15.8 8.81 0.85 15.3 8.64 0.93 14.8 8.45 1.02 14.3 8.22 1.12
3TW28149-1
SYMBOLS
AFR: Air flow rate (m
3
/min)
BF: Bypass factor
EWB: Entering wet bulb temp. (°CWB)
EDB: Entering dry bulb temp. (°CDB)
TC: Total cooling/heating capacity (kW)
SHC: Sensible heating capacity (kW)
PI: Power input (kW)
(comp.+indoor+outdoor fan motor)
CPI: Coefficient of power input. (-)
Caution:
TC and SHC are shown by kW
NOTES
1. Ratings shown are net capacities which include a deduction for indoor fan motor heat
2. On the figure the mark jshow the max. at standard conditions.
On the figure the mark Qshow rated capacity and rated coefficient of power input.
However the max. capacity is not guaranteed, except at standard condition.
3. On the tables Qshow rated capacity and rated coefficient of power input.
4. SHC is based on each EWB and EDB
SHC* = SHC correction for other dry bulb
SHC* = 0.02 x AFR (m
3
/min.) x (1−BF) x (DB*−EDB)
Add SHC* to SHC.
5. Capacities are based on following conditions:
Outdoor air : 85 % RH. however, the condition on nominal capacity is 7° CDB/6° CWB (heating)
Corresponding refrigerant piping length : 7.5 m
Level difference : 0 m
6. Coefficient of power input is the percentage when the rated valve is defined as 1.00.
7. The value contains less than 5% error acording to indoor unit type.
8. Heating capacity include the drop of frost formation.
9. Air flow rate and BF are tabulated below.
(Pair)
FBQ140
AFR
(BF)
35
(0.14)
10. Rated power input of each model is tabulated below.
(Pair)
Outdoor RZQS140C7
Indoor FBQ140B8
Cooling 4.97kW
Heating 4.99kW
Capacity range
Rated point
Cooling capacity (kW)
Coefficient of power input. (-)

3
1
5
• Split Sky Air • Outdoor Units 20
• Outdoor Units • R-410A • RZQS71-140C7V1B
5 Capacity tables
5 - 2 Cooling capacity tables
3TW29069-3
RZQS71-100C7V1B
Capacity (%)
Field piping length (m)
Cooling
Heating
Capacity in function of field piping length for non-inverter
