Installation Guide
ARCH015
Lumination®LED Luminaire
93013528, 93013522, 93013523, 93013524
(Tetra®PowerGrid Series - Gen 3)
BEFORE YOU BEGIN
Read these instructions completely and carefully.
WARNING / AVERTISSEMENT
RISK OF ELECTRIC SHOCK
• Disconnect power before servicing or installing product.
RISQUES DE DÉCHARGES ÉLECTRIQUES
• Couper l’alimentation avant le dépannage ou avant l’installation
du produit.
Save These Instructions
This product is intended solely for the use of nonresidential architecture lighting and is not intended for
use in any other applications.
LED System Features
• Certied to UL 2108
• Low-Voltage Luminaire (24 VDC)
• IP54, dry or damp location rated.
• Compatible with 24 Volt GE LED Drivers
• Dimmable with Current 0-10V Dimming LED Driver or
Current Dimming Module and compatible dimming
controller
Electrical Requirements
• Do not use in wet locations.
• The grounding and bonding of the LED Driver shall
be done in accordance with National Electric Code
(NEC) Article 600.
• Follow all National Electric Codes (NEC) and
local codes.
Prepare Electrical Wiring
Save These Instructions
This product is intended solely for the use of
nonresidential architecture lighting and is not intended
for use in any other applications.
For use in the following applications
• Backlighting
• Illuminated Walls or Ceilings

Lumination®(Tetra® PowerGrid - Series) Installation Guide
Determine Layout
2
Determine total number of modules needed to populate the application
area based on width and height. Refer to estimating charts below.
NOTE:
For optimal light uniformity, application depth should be a minimum of
3 inches (76 mm). A mock-up using the PowerGrid module and panel to
be illuminated is highly recommended.
1
B
A
Total number of modules required based on height and width:
Horizontal width in FEET (B)
Vertical height in FEET (A)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
3 6 9 12 15 18 21 24 27 30 33 36 39 42 45 48 51 54 57 60 63 66
4 8 12 16 20 24 28 32 36 40 44 48 52 56 60 64 68 72 76 80 84 88
6 12 18 24 30 36 42 48 54 60 66 72 78 84 90 96 102 108 114 120 126 132
7 14 21 28 35 42 49 56 63 70 77 84 91 98 105 112 119 126 133 140 147 154
9 18 27 36 45 54 63 72 81 90 99 108 117 126 135 144 153 162 171 180 189 198
10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220
12 24 36 48 60 72 84 96 108 120 132 144 156 168 180 192 204 216 228 240 252 264
13 26 39 52 65 78 91 104 117 130 143 156 169 182 195 208 221 234 247 260 273 286
15 30 45 60 75 90 105 120 135 150 165 180 195 210 225 240 255 270 285 300 315 330
16 32 48 64 80 96 112 128 144 160 176 192 208 224 240 256 272 288 304 320 336 352
18 35 54 72 90 108 126 144 162 180 198 216 234 252 270 288 306 324 342 360 375 396
1
2
3
4
5
6
7
8
9
10
11
12
Vertical height in METERS (A)
Horizontal width in METERS (B)
0.25 0.50 0.75 1.00 1.25 1.50 1.75 2.00 2.25 2.50 2.75 3.00 3.25 3.50 3.75 4.00 4.25 4.50 4.75 5.00
1 1 2 3 4 5 5 6 7 8 9 10 11 11 12 13 14 14 15 16
2 2 4 6 8 10 10 12 14 16 18 20 20 22 24 26 28 28 30 32
4 44 8 12 16 20 20 24 28 32 36 40 40 44 48 52 56 56 60 64
5 5 10 15 20 25 25 30 35 40 45 50 50 55 60 65 70 70 75 80
6 6 12 18 24 30 30 36 42 48 54 60 60 66 72 78 84 84 90 96
7 7 14 21 28 35 35 42 49 56 63 70 70 77 84 91 98 98 105 112
8 8 16 24 32 40 40 48 56 64 72 80 80 88 96 104 112 112 120 128
10 10 20 30 40 50 50 60 70 80 90 100 100 110 120 130 140 140 150 160
11 11 22 33 44 55 55 66 77 88 99 119 119 121 132 143 154 154 165 176
12 12 24 36 48 60 60 72 84 96 108 120 120 132 144 156 168 168 180 192
13 13 26 39 52 65 65 78 91 104 117 130 130 143 156 169 182 182 195 208
15 15 30 45 60 75 75 90 105 120 135 150 150 165 180 195 210 210 225 240
0.25
0.50
0.75
1.00
1.25
1.50
1.75
2.00
2.25
2.50
2.75
3.00

Lumination®(Tetra® PowerGrid - Series) Installation Guide
3
Install Modules
2” (51 mm)
from edge
2.77” (70 mm)
between columns
Lay modules into the application at least 2 inches (51 mm)
from the edges.
Fasten down each module with at least one screw
in the center hole or two opposing sides.
1
Start another row with 2.77-inch (70 mm) spacing between
the module strings.
Continue this process until the entire application is
populated with modules.
2
Using the diagram below as an estimation guide, begin cutting strings of modules to create 8-inch (203 mm) tall
rows and 12-inch (305 mm) wide columns.
Modules should be 2 inches (51 mm) from the edge of the application with 2.77 inches (70 mm) between
each column.
2
Typical layout
12” (305 mm)
wide columns
2” (51 mm)
from edge
2” (51 mm)
from edge
8” (203 mm)
tall rows
2.77” (70 mm)
between
columns
2” (51 mm)
from edge
2.77” (70 mm)
between columns

www.gecurrent.com
© 2021 Current Lighting Solutions, LLC. All rights reserved. GE and the GE monogram are trademarks of the
General Electric Company and are used under license. Information provided is subject to change without
notice. All values are design or typical values when measured under laboratory conditions.
ARCH015 (Rev 04/02/2021)
Lumination®(Tetra® PowerGrid - Series) Installation Guide
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that may cause undesired operation. This Class [A] RFLD complies with the
Canadian standard ICES-003. Ce DEFR de la classe [ A ] est conforme á la NMB-003 du Canada.
Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference
to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required
to correct the interference at his own expense.
Troubleshooting
Symptom Solution
Row of modules does not light • Check wire connections to LED Driver to ensure red-to-red and white-to-white connections.
• Check row-to-row polarity connections.
All modules do not light • Check input voltage and check LED Driver input/output connections.
Individual modules do not light • Check wire connection attachment and polarity of wires.
Modules are dim
• Ensure the overall length of modules does not exceed the maximum load for the LED Driver.
• Ensure the length of the supply wire is equal to or below the recommended remote mounting distance
(see remote mounting distance chart above).
Loading Chart
LED Driver Minimum Loading Maximum Loading
79045 (GE080/MV/D24T1-A) 1 Module 30 Modules/20 ft. (6.1m)
67825 (GEPS24-100UGL-IP) 1 Module 36 Modules/24 ft. (7.3m)
62189 (GE180/MV/V24T1-C) 1 Module 33 Modules/22 ft. (6.7m) per Bank; 66 Modules/44 ft. (13.4m) per Driver
Remote Mounting Distance
LED Driver 18 AWG (0.82mm2)
Supply Wire
16 AWG (1.31mm2)
Supply Wire
14 AWG (2.08mm2)
Supply Wire
12 AWG (3.31mm2)
Supply Wire
79045 (GE080/MV/D24T1-A)
1-30 ft. (0.3-9.1m) 1-50 ft. (0.3-15.2m) 1-80 ft. (0.3-24.4m) 1-120 ft. (0.3-36.6m)67825 (GEPS24-100UGL-IP)
62189 (GE180/MV/V24T1-C)
Electrical Connections
LED Driver Wire connections Cap all unused wires
Strip the ends of the wire 1/2-inch (13 mm) on the modules
(white and red) of adjacent columns that you want to connect.
1
Use UL approved wire connectors (twist-on or in-line connectors)
and 18 AWG (0.82 mm2) wire to connect the corresponding wires.
2
Strip the end of the wire 1/2-inch (13 mm) on the rst column
of modules and connect to the output of the LED Driver. Output
connections must be red-to-red and white-to-black.
3
Refer to the LED Driver Installation Instructions for
more information on connecting the LED Driver.
4
