Daintree GE Current Lumination LBU Recessed Series User manual

Lumination®LED Luminaires
LBU Recessed Series, 120-277V
BEFORE YOU BEGIN
Read these instructions completely and carefully.
WARNING / AVERTISSEMENT
RISK OF ELECTRIC SHOCK
• Turn power o before inspection, installation or removal.
• Properly ground electrical enclosure.
RISK OF FIRE
• Follow all NEC and local codes.
• Use only UL approved wire for input/output connections.
Minimum size 18 AWG (0.75mm2).
Prepare Electrical Wiring
Electrical Requirements
• he LED luminaire must be connected to the mains
supply according to its ratings on the product label.
Grounding Instructions
• The grounding and bonding of the overall system
shall be done in accordance with National Electric
Code (NEC) Article 600 and local codes.
RISQUES DE DÉCHARGES ÉLECTRIQUES
• Coupez l’alimentation avant d’’inspecter, installer ou déplacer le luminaire.
• Assurez-vous de correctement mettre à la terre le boîtier d’alimentation
électrique.
RISQUES D’INCENDIE
• Respectez tous les codes NEC et codes locaux.
• N’utilisez que des ls app ouvés par UL pour les entrées/sorties
de connexion. Taille minimum 18 AWG (0.75mm2).
Save These Instructions
Use only in the manner intended by the manufacturer.
If you have any questions, contact the manufacturer.
Installation Guide
IND553
A-1024174
22 Series
Components Supplied
• Luminaire
Tools and Components Required
• Slot or Philips screwdriver
• UL Listed conduit connections per NEC/CEC for
nominal conduit trade sizes ½” or ¾”
• UL Listed wire connectors
CAUTION / ATTENTION - RISK GROUP 2/RAYONNEMENT LUMINEUX GROUPE 2
Risk Group 2: Caution. UV Emitted from this product.
Eye or skin irritation may result from exposure.
Use appropriate shielding. Product tested against IEC62471.
Groupe de Risque 2: Attention. Ce produit émet un rayonnement UV. Une
irritation des yeux ou de la peau peut résulter de l’exposition. Utilisez les
protections appropriées. Produit testé selon IEC62471.

Carefully unpack unit from its packaging. Properly
inspect for defects before installing. Wear work
gloves to prevent dirt and oil from being
transferred to the luminaire.
1
Install the unit into the reserved hole in the ceiling.
If installing more than one luminaire per room,
follow instructions on the diuser label to maintain
consistent orientation.
2
Bend the 4 clips to secure the luminaire in place.
Install the safety cables through the holes on the clips
(per local building codes, safety cables by others).
3
WARNING/AVERTISSEMENT
Risk of electrical shock. Disconnect power before servicing or installing product.
Risque de choc électrique. Couper l’alimentation avant le dépannage ou avant l’installation du produit.
120-277V
WHITEC OMMON
NEUTRAL
BLACK UNSWITCHED
LINE
GROUND GROUND
GREY DIMMING
0-10V
DIMMING (••)
VIOLET DIMMING (+)
Exterior Wires
Recessed Troffer Module
NOTE: Two sets of leads may be provided from the recessed
troer module labeled "UV" and "WHITE." These may be
connected to the same or separate circuits depending on
customer instruction.
Installation
Bend clips
Safety cable
Electrical Connections

www.gecurrent.com
© 2019 Current Lighting Solutions, LLC. All rights reserved. GE and the GE monogram are trademarks of the
General Electric Company and are used under license. Information provided is subject to change without
notice. All values are design or typical values when measured under laboratory conditions.
IND553 (Rev 01/15/20) A-1024174 Rev 01
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer-
ence, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAN ICES-005 (A(A) NMB-005
(A)
Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
Note: CONTACT FACTORY for details and limitations when seeking to incorporate this product with an emergency system other than Battery Backup.
Remove electrical enclosure cover. Remove knock-
out for AC line input wires.
1
Install listed electrical ttings in the knockout holes for
wire protection. Connect the AC lines (UV and WHITE)
to the luminaire internal wires according to the wiring
diagrams using 18-14AWG twist-on wire connectors.
2
Installation
Install listed electrical ttings in the knockout holes
for wire protection. Connect the dimming controls
(grey and purple or purple and purple/white, one
set for UV one set for WHITE) wires of the LED
drivers using 18-14AWG twist-on wire connectors.
3
Replace electrical enclosure cover and secure it
with the screw.
4
