Lumination® LIB
Lumination®Linear
In-Bay Lighting
(LIB)
Installation Guide
A-1026549
Save These Instructions Prepare Electrical Wiring
Materials Supplied With Luminaire
Use only in the manner intended by the
manufacturer. If you have any questions,
contact the manufacturer. The LED xture must be supplied with 120VAC,
50/60 Hz and connected to an individual properly
grounded branch circuit, protected by a circuit
breaker. Use min. 75 C supply conductor.
The grounding and bonding of the overall system
shall be done in accordance with the National
Electric Code (NEC) Article 600 and local codes
Electrical Requirements
Electrical Requirements
LIB Series Luminaire
BEFORE YOU BEGIN
Read these instructions completely
and carefully.
WARNING / ADVERTISSEMENT
CAUTION / ATTENTION
RISK OF FIRE OR ELECTRIC SHOCK
• Turn power off before inspection, installation or removal.
• Installation requires a person familiar with the construction and operation of
the luminaire’s electrical system and the hazard involved. If not qualied, do
not attempt installation. Contact a qualied electrician.
• To prevent wiring damage or abrasion, do not expose wiring to edges of
sheet metal or other sharp objects.
• Follow all NEC and local codes.
• Fixture may fall down if not installed properly, follow installation instructions
• Wear safety glasses and proper aid during installation and maintenance
• Le luminaire peut tomber s’il nest pas installe correctement, suivre les
instructions d’installation.
• Porter des lunettes de securite et les aides appropriees lors de !’installation
et de l’entretien.
• Coupez l’alimentation avant d’inspecter, installer ou deplacer le luminaire.
• Risque d’incendie ou d’electrocution. N’ installer cette trousse que sur des
luminaires qui ont les caracteristiques de construction et les dimensions
telles que montrees sur les photographies et dessins presentes.
• Pour prevenir les dommages ou !’abrasion de ls electriques, ne pas
exposer les ls aux aretes de piece de t61erie ou n’importe quels autres
objets tranchant
• Respectez tous les codes NEC et codes locaux
RISQUES D’INCENDIE OU DE DECHARGES ELECTRIQUES
STOP
Mounting Hardware
Multiple-Length Power Supply Cords

Lumination® LIB Installation Guide
Single Fixture Installation
Provided Components Optional Accessories
1
A
C
B
D E
Attach the mounting clips to the desired surface
in a straight line using the provided screws. The
distance between the two clips is determined
by the length of the xture, as noted in the
chart below.
Install the protective cap on
the female connector of the
xture.
g. 1A
Fixture Length 2ft 3ft 4ft
Mounting Width 12-16in
~300-400mm
16-24in
~400-600mm
24-36in
~600-900mm
Mounting
Bracket
Magnetic
Mounting
U-Shape
Channel
Power Linking Cords
(4” & /1/2/6/10/12ft)
Center the length of the xture within the
installed mounting clips. Press and snap the
xture into the mounting clips, with the male
power connector facing the power supply drop.
Plug the power cord into a
120VAC supplied outlet.
(The maximum distance to
the receptacle is determined
by the length of cord
provided.)
Power Cords
(1/2/6/10/12ft)
Protective
Cap
Fastener
Remove the protective lm on
the diffuser. Connect the power
cord to the male connector.
peeling off the film
Note: When using magnetic mounting clips, two installed
clips need to support at least 4 times the weight of the fixture
(0.5Kg per fixture).

Lumination® LIB Installation Guide
Continuous Run Installation
2
A
D
B
E
C
F
Repeat step A of the “Single
Fixture Installation” process.
Do not provide a power source
to the luminaire. Do not
remove protective lm.
Snap the second xture into
the correlating mounting
brackets. Align the mating
features on the male and
female connectors. Press
together until a “click” is heard.
Note: If you do not hear a click, the
connection has not been properly
made. Disconnect and retry until a
“click” is heard
Determine the desired
spacing between luminaires.
If additional space is desired
between the luminaires,
continue to Section 3A. Install
the brackets for the remaining
xtures in a straight line,
according to Fig. 1A
Note: If the dovetails will not align,
adjustment to the mounting brackets
or a linking cord may be necessary.
Repeat step 2C until the
desired number of xtures are
connected in a continuous run
(26 fixtures at Maximum).
Center the length of the
xtures within the installed
mounting clips. Press and snap
the xture into the mounting
clips, with the male power
connector facing the power
supply drop.
Plug the power cord into a
120VAC supplied outlet.
(The maximum distance to
the receptacle is determined
by the length of cord
provided.)
Connect the protective cap to
the unused female connector.
Remove the protective lm on
the diffuser. Connect the power
cord to the male connector.
peeling off the film

Lumination® LIB Installation Guide
Continuous Run Installation - Power Linking Cords
3
Select the “linking cord” most
similar in length to the gap
between the two luminaires
without causing strain. Connect
the linking cord to male and
female connectors respectively.
All product and company names are trademarks or registered trademarks of their respective holders. Use of them does not imply any afliation
with or endorsement by them.
2020 Current Lighting Solutions, LLC. All rights reserved. GE and the GE monogram are trademarks of the General
Electric Company and are used under license. Information provided is subject to change without notice. All values are
design or typical values when measured under laborator conditions.
IND 570 | A-1026549 | REV 07/22/20
Questions Web: products.gecurrent.com Phone: [phone]
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired operation. CAN ICES-005 (A) / NMB-005 (A)
Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
A“Snap” the luminaires into the B
correlating mounting brackets,
centering the length of the
xtures within the brackets.
C
DPlug the power cord into a
120VAC supplied outlet.
(The maximum distance to
the receptacle is determined
by the length of cord
provided.)
Connect the protective cap to
the unused female connector.
Remove the protective lm on
the diffuser. Connect the power
cord to the male connector.
