Daktronics Big Stream 1 User manual

Big Stream 1 Quick Guide
DD4731212
Rev 01
02 December 2020
201 Daktronics Drive
Brookings, SD 57006-5128
www.daktronics.com/support
800.325.8766
Page 1 of 11
This guide explains the setup of a Daktronics “Big Stream 1” system.
This system adds another Digital Media Player (DMP) into an existing
1- or 4-input video control rack. The additional DMP provides an NDI
(Network Device Interface) video output to a compatible customer-
provided streaming device. For more information about setup or
operation of the existing control rack, refer to the documentation
provided with that rack. Refer also to the following YouTube playlist:
https://www.youtube.com/watch?v=vbXFr2aSrnM&list=PL2dNnauPij
WWHWyn9LKphHE0SjkkkwJP3
Site-specic diagrams may also be available; these will take
precedence over any general instructions found in this guide.
Contact the Daktronics Standard Order Project Manager (SOPM) or
Standard Order Project Coordinator (SOPC) to ask if any site-specic
drawings exist for the project.
Equipment Setup
Non-Rack-Mount
Follow the instructions below if the new DMP will not be mounted into
the existing video control rack (for portability/multi-use facilities).
1. Unpack all items and verify everything from the Bill of Materials
(BOM) is included.
2. Locate the DMP unit (part # 0A-1453-7230), and set it in the
desired temporary location (within 25' of the existing control rack).
3. Connect the DMP power cord into an available outlet on the
rack power strip or nearest wall outlet.
4. Connect either the 5' (part # W-1506) or 25' (part # W-4638308)
Cat5 network cable between the left network jack on the DMP to
an open jack on the network router in the rack.
Rack-Mount
Follow the instructions below if the new DMP is to be mounted into
the existing video control rack.
1. Unpack all items and verify everything from the Bill of Materials
(BOM) is included.
2. Locate the DMP unit (part # 0A-1453-7230) and mounting tray.
• 1-input racks require a half-rack
tray (part # EN-2843).
• 4-input racks require a full-rack
tray (part # EN-2842) and a
half-rack ller panel (part # EN-2844).
3. Mount the DMP unit to the appropriate mounting tray using the
rear thumbscrews. For 4-input racks, also install the half-rack ller
panel into the front-right slot of the tray if desired.
4. Remove the front ller panel from the existing rack directly below
the existing player(s) and processor(s), and then install the DMP
tray into the open space using the same screws.
5. Connect the power cord (part # W-1532) between the DMP and
an available outlet on the rack power strip or nearest wall outlet.
6. Connect the 5' Cat5 network cable (part # W-1506) between
the left network jack on the DMP to an open jack on the network
router in the rack.
Note: An Internet
(WAN) connection
into the network
router in the rack is
required to output
the streaming
video online.

Big Stream 1 Quick Guide
DD4731212
Rev 01
02 December 2020
201 Daktronics Drive
Brookings, SD 57006-5128
www.daktronics.com/support
800.325.8766
Page 2 of 11
Cong Proles
The system ships congured with a 720p output by default.
To change the output resolution to 1080p:
1. Open a web browser and go to http://192.168.0.237/#proles to
access the DMP-8000 Cong Proles window.
Note: If asked to enter login credentials, the defaults are
Username: vnet and Password: dakpassv.
2. Select 1080p NDI Ouput.
3. Click Continue when the conrmation message opens.
4. Wait for the player to restart. A green check mark indicates when
the process is completed.
Mapping Content Directory
1. Press the Windows Start button and type in "This PC", then right-
click This PC App and select Map network drive.
Note: For Windows 7, press the Start button, right-click Computer,
and select Map network drive.
2. In the Map Network Drive window, select the next available Drive
letter, and then enter \\D8STREAM-P\Content as the Folder.
Ensure Reconnect at sign-in is checked, and then click Finish.
3. Log in using the following
credentials:
• Username: vnet
• Password: dakpassv
Ensure Remember my
credentials is checked and
then click OK.

Big Stream 1 Quick Guide
DD4731212
Rev 01
02 December 2020
201 Daktronics Drive
Brookings, SD 57006-5128
www.daktronics.com/support
800.325.8766
Page 3 of 11
Show Control Updates
After connecting the new DMP to the router in the rack and ensuring
it powers on, open Display Studio on the Show Control computer.
Add Player into Display Studio
1. Click the Display Studio button in the upper-left corner, and go to
Properties > Service Conguration.
2. Type “D8STREAM-P” in the search bar and click Check.
3. A green check mark will appear when the player is found.
Click Add.
4. The new DMP is added to the database. Click OK to continue.
Add Player Output to Monitor Wall
1. Right-click in the monitor wall and select Properties.
2. In the drop-down list that appears, select D8STREAM-P:Primary.
3. Click the +button to add it to the monitor wall.
4. Drag the edge of the new monitor to resize as needed, and then
click Save.
Create Buttons for Lower Bar
The streaming player is equipped with standard bottom bar and
fullscreen scoreboard content for all of the following sports:
Baseball/Softball, Basketball, Football, Soccer, and Volleyball.
Below is an example of how to create a new button to play a bottom
bar football scoreboard.
1. Select the appropriate Sport tab, right-click in the workspace,
and then click New Button.
2. Name the button “[Sport] BTM BAR SCBD” and ensure DMP-8000
Player Control is selected.
3. Click 2and select D8STREAM-P;Primary/bottombar from the list.
4. Click 3and select Play.
5. Click 4and then click Add.

Big Stream 1 Quick Guide
DD4731212
Rev 01
02 December 2020
201 Daktronics Drive
Brookings, SD 57006-5128
www.daktronics.com/support
800.325.8766
Page 4 of 11
6. Navigate to the “BTM BAR SCBD” VMPF le under the
corresponding sport folder. Select the le, and then click Open.
7. After adding the le to the button, click Save.
8. Press the new button to see the bottom bar content appear in
the monitor wall.
Updating Existing Buttons
Additional scripts will need to be added to existing buttons in order to
play content to both the video board and streaming player.
Additional scripts can similarly be added to the Blank Display,
Full Screen Video, and Scaled Video buttons.
Content Buttons
1. Select the appropriate Sport tab, right-
click the content button to update,
and then select Properties.
2. Click the button at the bottom of the
properties window to add a new script.
3. Ensure DMP-8000 Player Control is selected.
4. Click 2and select D8STREAM-P; Primary/Full Screen Takeover Zone.
5. Click 3and select Play.
6. Click 4and then click Add. Navigate to the specied content le
under the corresponding sport folder and click Open.

Big Stream 1 Quick Guide
DD4731212
Rev 01
02 December 2020
201 Daktronics Drive
Brookings, SD 57006-5128
www.daktronics.com/support
800.325.8766
Page 5 of 11
7. Click the (Select Script Line) button and notice there are now
two script lines shown. Click Save to update the content button.
8. Click the updated button and verify that the content plays on
both players' monitors.
Note: Full Screen Video and Scaled Video buttons can be modied
in a similar manner.
Blank Display
1. Select the appropriate Sport tab, right-click the Blank Display
button, and then select Properties.
2. Click the button at the bottom of the properties window to
add a new script.
3. Ensure DMP-8000 Player Control is selected.
4. Click 2and select every "D8STREAM-P" line except
D8STREAM-P:Primary.
5. Click 3and select Blank Display.
6. Click 4and then click Save.
7. Click the updated button and verify that the content blanks on
both players' monitors.

Big Stream 1 Quick Guide
DD4731212
Rev 01
02 December 2020
201 Daktronics Drive
Brookings, SD 57006-5128
www.daktronics.com/support
800.325.8766
Page 6 of 11
Reusing Existing Content
In general, Daktronics recommends creating new content specically
for streaming using the correct output resolutions (720p = 720 x 1280
or 1080p = 1080 x 1920).
Depending on the size and aspect ratio of existing display content,
it may be possible to reuse the les for streaming. Otherwise, the
content may still need to be recreated. For example, if you have
a small 132 x 176 display with a 4:3 aspect ratio, streaming its
content will not only cause pixelation due to upscaling, it will also be
stretched to t the width, giving it more of a squished appearance:
Before
132 x 176 (4:3)
After
720 x 1280 (16:9)
#8#8
JACOBSJACOBS
MICHELLEMICHELLE
However, if you already have a display with a 16:9 aspect ratio, the
content will better t the aspect ratio of the streaming output. The
content can still become pixelated, depending on how much it
needs to upscale, but this can work if time or resources are limited
before a scheduled event.

Big Stream 1 Quick Guide
DD4731212
Rev 01
02 December 2020
201 Daktronics Drive
Brookings, SD 57006-5128
www.daktronics.com/support
800.325.8766
Page 7 of 11
Optional TriCaster Mini Setup
Refer to the instructions below and DWG-4715862 to set up the
optional TriCaster Mini switcher and replay system. For more
information, also refer to the TriCaster User Guide
(http://new.tk/Manual-TC1-V2).
1. Remove the TriCaster Mini, Launchpad Mini, mouse, keyboard,
and power adapters from the travel case. Set up this equipment
– and the TimeWarp device – within 25' of the control rack.
2. Place one 22" ViewSonic monitor at the Replay operator location
and the other 22" ViewSonic monitor at the TriCaster switcher
operator location. Both monitors should be within 6' of the
TriCaster Mini.
3. Make the following connections to the TriCaster Mini:
3a
3g
3c 3e
3f
3b
3d
3h
a. Connect BNC cables from up to four cameras to VIDEO IN 1-4 .
b. Connect the 25' BNC cable (part # W-1971) between a VIDEO
OUT jack and the SDI IN jack on the new DMP in the rack.
c. Connect the 1/8"-to-1/4" adapter into the 1/8" TriCaster
operator monitor audio cable, and then plug the adapter
into the PHONES jack. The other end of the audio cable
connects to the monitor’s AUDIO IN jack.
d. If there is an audio system, connect the 25' 1/4"-to-XLR cable
(part # W-4717001) between the AUDIO OUT L jack and an
available input on the audio mixer.
e. Plug the supplied mouse, keyboard, TimeWarp, and
Launchpad Mini devices into available USB ports.
f. Connect the 25' network cable (part # W-4638308) between
a NETWORK jack and an open jack on the network router in
the control rack.
g. Connect one Mini-DisplayPort-to-DisplayPort adapter into
one 6' DisplayPort cable, and then plug the adapter into
one of the Mini DisplayPort jacks. The other end of the cable
connects to the 22" Replay operator monitor. Repeat this to
also connect the 22" TriCaster operator monitor.
h. Connect the power adapter into the DC IN jack.
4. Plug power cords for all devices (TriCaster Mini, monitors, etc.)
into standard wall outlets.

Big Stream 1 Quick Guide
DD4731212
Rev 01
02 December 2020
201 Daktronics Drive
Brookings, SD 57006-5128
www.daktronics.com/support
800.325.8766
Page 8 of 11
NDI Output to Streaming Device
This section describes an optional method of streaming the NDI
output from the Big Stream DMP via a TriCaster. Other devices/
software may be used instead as long as they accept the NDI video
source. If the streaming device does not accept NDI, the NDI output
must be converted to a video input that the streaming device can
accept using a converter such as the BirdDog NDI Encoder/Decoder.
Note: The streaming device must be connected into an open jack
on the network router in the control rack.
In typical Daktronics video control systems, the TriCaster acts as
a switcher for up to 4 video inputs. For the Big Stream system, the
TriCaster Mini may also function as the streaming device. For more
information about connections to the TriCaster, refer to Page 5.
Capturing the NDI Output
Each monitor on the TriCaster workspace can be congured to show
any input or output. There are multiple virtual inputs that can be set
to the NDI feed from the DMP.
1. Open the TriCaster program and start the desired session.
2. Right click an unused monitor, such as GFX1, and go to Inputs >
INPUT 5.
3. Click the gear icon in the lower-right of the Input 5 monitor to
open the input settings.
a. In the Source drop-down list, select D8STREAM-P and then
NDI-0.
b. Expand the Name/Comment section. Rename Video
to D8STREAM and Button to DMP, and add a descriptive
Comment as desired.
c. Click Close when nished.
Note: If content is playing out of the DMP, it will appear in the
D8STREAM monitor.

Big Stream 1 Quick Guide
DD4731212
Rev 01
02 December 2020
201 Daktronics Drive
Brookings, SD 57006-5128
www.daktronics.com/support
800.325.8766
Page 9 of 11
Streaming the NDI Output
1. Click the STREAM/ENCODE button at the top of the screen.
2. Click Source Setup.
MIX 1 is the primary output to the display*. Mix 4 is the replay mix.
MIX 2 will be used for the separate streaming mix.
a. Change MIX 2 Video to M/E 2.
b. Change STREAM 1 Video to MIX 2.
c. Adjust the Audio output source if desired.
3. Click the STREAM 1 gear icon and adjust the encoder settings as
desired. The default settings should work for most applications.
Click OK when nished.
4. Check the streaming platform(s). Hover over and select the
settings gear icon to log in to an account or adjust as needed.
5. Close out of all settings windows when nished.

Big Stream 1 Quick Guide
DD4731212
Rev 01
02 December 2020
201 Daktronics Drive
Brookings, SD 57006-5128
www.daktronics.com/support
800.325.8766
Page 10 of 11
6. Back on the main interface, select DMP on the M/E 2 bar.
Selecting DMP on the M/E 2 bar will make it the active M/E 2
source. The active M/E 2 source is MIX 2, which is the congured
streaming source.
TriCaster Registration
On rst time start-up, the installer may assist in registering the
TriCaster for the end user. This can be done very easily if an internet
connection is available. If not, call NewTek Customer Service:
• (US) 1-800-862-7837
• (Outside US) [phone]
Both the Serial Number (located on the TriCaster unit) and Product ID
(presented during registration) are required to obtain the necessary
Registration Code.
For more information about registration, operation, or troubleshooting
of the TriCaster system, visit www.newtek.com/support/get-support.
For More Information
To learn more about the Daktronics Show Control System software,
consult the Show Control System User Handbook:
• Press the Windows key [ ] and go to All Programs > Daktronics >
Display Studio > Show Control System User Handbook.
• From within Display Studio, press the Display Studio Hub button
and select Help.
Watch the following YouTube video for an introduction to Show
Control: www.youtube.com/watch?v=3Q28olggTGo
For any other questions, comments, or concerns, please contact
Daktronics Support Services:
United States & Canada
Toll Free: 1-800-DAKTRONICS (1-800-325-8766)
Outside the U.S. & Canada
[phone]

THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS DRAWING
ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY
ANY MEANS WITHOUT THE EXPRESS WRITTEN CONSENT OF
DAKTRONICS, INC. OR ITS WHOLLY OWNED SUBSIDIARIES.
COPYRIGHT 2019 DAKTRONICS, INC. (USA)
THIRD ANGLE PROJECTION
BH
REV
TITLE:
PROJECT:
INCHES [MILLIMETERS]
DESIGN:
SCALE:
DIM UNITS:DATE: SHEET
DO NOT SCALE DRAWING
FUNC - TYPE - SIZE
DRAWN: -
JOB NO.
-
SPORTS VIDEO SYSTEMS
KIT; TRICASTER MINI ADVANCED SDI W/ TRAVEL CASE
TKELLEY
28 JULY 20
P1453 F 01 B
NONE
TKELLEY 4715862
00
A-3343
TRICASTER 850 TW
USB
RMT #1
SUPPLIED W/ A-3443
W-4638308
USB
LAUNCHPAD MINI MK3
A-3450
RMT #2
DVI IN
VGA IN VIEWSONIC
22"
VA2251M-LED
A-2430
AUDIO IN
DP IN
GPM #1
DVI IN
VGA IN VIEWSONIC
22"
VA2251M-LED
A-2430
AUDIO IN
DP IN
GPM #2
SDI OUT 1
SDI OUT 2
USB 3.0 1
USB 3.0 2
TRICASTER
MINI
ADVANCED
HD-4 SDI
A-4715564
SDI IN 2
SDI IN 3
SDI IN 4
AUDIO IN L
AUDIO IN R
USB 3.1
NETWORK 1
USB 2.0 1
USB 2.0 2 USB 3.0 4
USB 3.0 3
MINI DP 1
MINI DP 2
MINI DP 3
SDI IN 1
USB-C
MINI DP 4
NETWORK 2
MIC IN
AUD OUT L
AUD OUT R
AUD PHONE
* MINI DP
ADAPTERS
INCLUDED W/
TRICASTER
W-2494
MDP TO DP*
MDP TO DP*
SWT #1
MOUSE
KEYBOARD
TO CONSUMER
AUDIO SYSTEM
SUPPLIED W/ A-3450
***NOTE: THE TRICASTER MINI AND ITS
ACCESSORIES ARE STORED IN A TRAVEL CASE
TO NETWORK
ROUTER
TO DMP-8221
SDI INPUT
TRICASTER EXTENSION KIT EQUIPMENT LIST
PART DESCRIPTION PART NUMBER QUANTITY
22" MONITORS A-2430 2
TIME WARP 850TW REPLAY CONTROLLER A-3343 1
LAUNCHPAD MINI MK3 A-3450 1
TRICASTER MINI ADVANCED SDI A-4715564 1
TRICASTER MINI TRAVEL CASE EN-4715565 1
25' BNC VIDEO CABLE W-1971 1
ADAPTER; 1/4" PLUG TO 1/8" JACK W-2494 1
6' DISPLAYPORT CABLE W-3271379 2
6FT 1/8" TO 1/8" STEREO CABLE W-3511512 1
25FT CAT5E NETWORK CABLE W-4638308 1
25FT 1/4" TRS PLUG TO XLR M CABLE W-4717001 2
INSTALLATION NOTES:
1. REMOVE TRICASTER, MOUSE, KEYBOARD, AND POWER ADAPTER FROM THE TRAVEL CASE.
2. SET UP EQUIPMENT ON COUNTER WITHIN 25' OF VIDEO RACK.
3. CONNECT (2) MINI DISPLAYPORT TO DISPLAYPORT VIDEO ADAPTERS TO THE TRICASTER.
4. CONNECT THE TWO MONITORS WITH THE INCLUDED DISPLAYPORT CABLES.
5. SET THE CONTROLLERS NEAR ONE OF THE MONITORS AND CONNECT THE USB TO THE TRICASTER.
6. CONNECT THE INCLUDED NETWORK CABLE BETWEEN THE TRICASTER AND SITE NETWORK ROUTER.
7. CONNECT THE INCLUDED BNC VIDEO CABLE BETWEEN THE TRICASTER AND THE DMP IN THE VIDEO RACK.
8. REFER TO BIG STREAM QUICK GUIDE FOR SETUP AND OPERATION.
***NOTE: SITE SPECIFIC RISER DIAGRAM(S) TAKE PRECEDENCE
OVER THIS OR ANY OTHER STANDARD DRAWING.
W-3271379
W-3271379
W-3511512
W-4717001
W-1971
P
P
a
a
r
r
t
t
#
#
-
-
D
D
W
W
G
G
-
-
0
0
4
4
7
7
1
1
5
5
8
8
6
6
2
2
V
V
e
e
r
r
s
s
i
i
o
o
n
n
-
-
0
0
0
0
.
.
1
1
D
D
e
e
s
s
c
c
r
r
i
i
p
p
t
t
i
i
o
o
n
n
-
-
N
N
B
B
K
K
I
I
T
T
;
;
T
T
R
R
I
I
C
C
A
A
S
S
T
T
E
E
R
R
M
M
I
I
N
N
I
I
A
A
D
D
V
V
S
S
D
D
I
I
W
W
/
/
T
T
R
R
A
A
V
V
E
E
L
L
C
C
A
A
S
S
E
E
L
L
i
i
f
f
e
e
c
c
y
y
c
c
l
l
e
e
S
S
t
t
a
a
t
t
e
e
-
-
F
F
u
u
l
l
l
l
P
P
r
r
o
o
d
d
u
u
c
c
t
t
i
i
o
o
n
n
L
L
a
a
s
s
t
t
M
M
o
o
d
d
i
i
f
f
i
i
e
e
d
d
B
B
y
y
-
-
t
t
k
k
e
e
l
l
l
l
e
e
y
y
L
L
a
a
s
s
t
t
M
M
o
o
d
d
i
i
f
f
i
i
e
e
d
d
-
-
2
2
0
0
2
2
0
0
-
-
0
0
8
8
-
-
2
2
1
1
