Matrix® PS
Public Safety System
airHost PS | hdHost PS | hd33 PS | Matrix Console PS
INSTALLATION &
COMMISSIONING GUIDE

ii
Copyright © 2018 Dali Wireless Inc. All Rights Reserved.
Printed in Canada.
Dali Wireless is a registered trademark of Dali group of companies, Dali Wireless, Inc.
and Dali Wireless (Canada), Inc.
The Dali Wireless logo is a registered trademark of Dali group of companies, Dali
Wireless, Inc. and Dali Wireless (Canada), Inc.
Matrix® is a registered trademark of Dali group of companies, Dali Wireless, Inc. and
Dali Wireless (Canada), Inc.
hdHost PS™, hd33 PS™and airHost PS™are trademarks of Dali group of companies.
All other trademarks shown are trademarks of their respective owners.
The Matrix is covered by a number of patents in the United States and around the
world.
U.S. Patent www.daliwireless.com/patents
Information in this publication is subject to change without notice. No part of this
publication may be reproduced or transmitted in any form, by photocopy, microfilm,
xerography, or any other means, or incorporated into any information retrieval system,
electronic or mechanical, for any purpose, without the express permission of Dali
Wireless, Inc.
Dali Wireless, Inc.
535 Middlefield Road, Suite 280
Menlo Park, CA 94025
Dali Wireless (Canada), Inc.
8618 Commerce Court
Burnaby, BC, V5A 4N6
Document: DW-MAN-036
Rev 06
Software Version 2.3.0

Dali Matrix PS System Installation and Commissioning Guide| iii
Dali Wireless Proprietary and Confidential | DW-MAN-036 Rev 06
REGULATORY COMPLIANCE
FCC
The following FCC compliance statement applies to the 150 MHz and 450 MHz
frequency bands described in Appendix A.
This device complies with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and
can radiate radio frequency energy, and if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may
cause undesired operation.
Caution
Any changes or modifications not expressly approved by Dali Wireless, Inc. could void
compliance with regulatory rules, and thereby your authority to operate this equipment.
Caution
Do not use this equipment with unauthorized antennas, cables, and/or coupling devices not
conforming with ERP/EIRP and/or indoor-only restrictions.
WARNING. This is NOT a CONSUMER device. It is designed for installation by FCC
LICENSEES and QUALIFIED INSTALLERS. You MUST have a FCC LICENSE or
express consent of an FCC Licensee to operate this device. You MUST register Class
B signal boosters (as defined in 47 CFR 90.219) online at www.fcc.gov/signal-
boosters/registration. Unauthorized use may result in significant forfeiture penalties,
including penalties in excess of $100,000 for each continuing violation.
FCC licensee is required to register the installed Class B devices at
https://signalboosters.fcc.gov/signal-boosters/
This device complies with FCC Part 90.219 as a Class B Signal Booster. The selection and
installation of an antenna must comply with the FCC RF exposure requirements. The FCC
regulation mandates that the ERP of type B signal boosters should not exceed 5 Watt. In addition
there are limitations on radiated intermodulation products and re-radiated noise.

iv | Dali Matrix PS System Installation and Commissioning Guide
Dali Wireless Proprietary and Confidential | DW-MAN-036 Rev 06
The Class B device described in this Installation and Commissioning Guide only has a
composite output power of 33 dBm. With a typical antenna gain of 5 dB and distribution
loss of cable and passive components, it will not exceed the 5 Watt ERP limit. See
Signal Booster Installation Guidelines shown below.
Signal Booster Installation Guidelines
In general, the ERP of the output noise within the pass band should not exceed the level
of -43 dBm in 10 kHz measurement bandwidth. The ERP of the output noise outside of the
passband by more than 1 MHz should not exceed the level of -70 dBm in 10 kHzmeasurement
bandwidth. The ERP of intermodulation products should not exceed -30 dBm in 10 kHz
measurement bandwidth.
The device shall NOT exceed the 5 Watt (37dBm) ERP limit. In order to achieve this 37dBm
ERP limit, the “Maximum Power Output” of the device minus the “Distribution Loss” plus the
“Antenna Gain” MUST be smaller than 37dBm. In other words, once an antenna is selected with
certain gain, installer must calculate the minimum Distribution Loss required not to exceed the
37dBm limit. Distribution Loss is defined as the loss in cables and splitters combiners. The
sections below provides examples on how the minimum “Distribution Loss” is calculated for
different Power Output and Antenna Gain.
Calibration Modes
Units are calibrated for 2 W or 5W depending on the output power required:
Mode A: 2 W
Mode B: 5 W

Dali Matrix PS System Installation and Commissioning Guide| v
Dali Wireless Proprietary and Confidential | DW-MAN-036 Rev 06
TYPE 1 CHASSIS
Intermodulation
airHost33 PS Dual Band Uplink
150 MHz Band, Mode B (5 W)
Example
12 dB of minimum distribution loss when 1-Carrier composite power is 37 dBm
hd33 PS Dual Band Downlink
150 MHz Band, Mode A (2 W)
Examples
8 dB of minimum distribution loss when 2-Carrier composite power is 34 dBm

vi | Dali Matrix PS System Installation and Commissioning Guide
Dali Wireless Proprietary and Confidential | DW-MAN-036 Rev 06
150 MHz Band, Mode B (5 W)
Examples
15 dB of minimum distribution loss when 1-Carrier composite power is 37 dBm
450 MHz Band, Mode A (2 W)
Examples
3 dB of minimum distribution loss when 2-Carrier composite power is 34 dBm

Dali Matrix PS System Installation and Commissioning Guide| vii
Dali Wireless Proprietary and Confidential | DW-MAN-036 Rev 06
800 MHz Band, Mode A (2 W)
900 MHz Band, Mode A (2 W)

viii | Dali Matrix PS System Installation and Commissioning Guide
Dali Wireless Proprietary and Confidential | DW-MAN-036 Rev 06
RF Exposure
According to FCC Part 1.1307(b)(1), systems operating under the provisions of this section shall
be operated in a manner that ensure that the public is not exposed to radio frequency energy
level in excess of the Commission’s guidelines. More information on evaluating compliance with
these limits can be found in the FCC's OST/OET Bulletin Number 65, “Evaluating Compliance
with FCC-Specified Guidelines for Human Exposure to Radiofrequency Radiation”.
All maximum Conducted Output Power + Max Antenna Gain (dBi) shown below is less than the
37dBm ERP limit. In real deployment, there will be distribution loss due to cable and splitter
combiners between the output of device and antenna to ensure radiated power is under 37 dBm
ERP limit.
RF Exposure Evaluation Distance Calculation
𝑑 = √ (𝐸𝐼𝑅𝑃/4𝜋𝑆)
Where:
d = Distance to the center of radiation of the antenna (cm) for the allowable Power Density
S = Allowable Power Density Limit (mW/cm2)
EIRP = Equivalent isotropically radiated power (mW) = 10 [TX Power (dBm) + Ant Gain (dBi)/10]
airHost33 PS Dual Band
150 MHz Band, Mode B (5 W)
In the Frequency Range of 30 to 300 MHz, the maximum power density limit for the
occupational/controlled exposures is 1 mW/cm2 for an average time of 6 minutes. In the
Frequency Range of 30 to 300 MHz, the maximum power density limit for the general
population/uncontrolled exposures is 0.2 mW/cm2 for an average time of 30 minutes.
The antenna connected to the product is specific to the deployment. The worst case scenario occurs
when using a high gain antenna. A typical outdoor antenna is shown in the following example:
The highest conducted output power is 37 dBm. To avoid exceeding 37 dBm ERP, the unit output
power can be backed off to 30 dBm. With a donor antenna gain of 7 dBi, the EIRP is 37 dBm.
The maximum power density safe exposure level for general population/uncontrolled exposure of
30 minutes for the frequency of 152 MHz is 0.2 mW/cm2.
Conducted Output
Power (dBm)
Max Antenna
Gain (dBi)
Max EIRP
(mW)
Power Density Limit
Allowed (mW/cm²)
Safe Distance
(cm)

Dali Matrix PS System Installation and Commissioning Guide| ix
Dali Wireless Proprietary and Confidential | DW-MAN-036 Rev 06
30
7
5012
0.2
45
As shown above, the minimum safe distance where the MPE limit is reached is 45 cm from the
unit with a 3 dBi antenna and no distribution loss.
If the antenna will be positioned closer to end users than 45 cm, then the installer must calculate
the safe distance for a given installation using the formulas provided.
hd33 PS Dual Band
150 MHz Band, Mode A (2 W)
In the Frequency Range of 30 to 300 MHz, the maximum power density limit for the
occupational/controlled exposures is 1 mW/cm2for an average time of 6 minutes. In the
Frequency Range of 30 to 300 MHz, the maximum power density limit for the general
population/uncontrolled exposures is 0.2 mW/cm2for an average time of 30 minutes.
The antenna connected to the product is specific to the deployment. The worst case scenario
occurs when using a very high gain outdoor/indoor antenna. However a typical indoor antenna is
shown in the following example:
The highest expected output power is 34 dBm at 157.5MHz. For an output level of 34 dBm with
an indoor antenna gain of 3 dBi, the EIRP is 37 dBm.
The maximum power density safe exposure level for general population/uncontrolled exposure of
30 minutes for the frequency of 157.5 MHz is 0.2 mW/cm2.
Conducted Output
Power (dBm)
Max Antenna
Gain (dBi)
Max EIRP
(mW)
Power Density Limit
Allowed (mW/cm²)
Safe Distance
(cm)
34
3
5012
0.2
45
As shown above, the minimum safe distance where the MPE limit is reached is 45 cm from the
unit with a 3 dBi antenna and no distribution loss.
If the antenna will be positioned closer to end users than 45 cm, then the installer must calculate
the safe distance for a given installation using the formulas provided.
150 MHz Band, Mode B (5 W)
In the Frequency Range of 30 to 300 MHz, the maximum power density limit for the
occupational/controlled exposures is 1 mW/cm2for an average time of 6 minutes. In the
Frequency Range of 30 to 300 MHz, the maximum power density limit for the general
population/uncontrolled exposures is 0.2 mW/cm2for an average time of 30 minutes.

x| Dali Matrix PS System Installation and Commissioning Guide
Dali Wireless Proprietary and Confidential | DW-MAN-036 Rev 06
The antenna connected to the product is specific to the deployment. The worst case scenario
occurs when using a very high gain antenna. However a typical indoor antenna is shown in the
following example:
The highest conducted output power is 37 dBm. To avoid exceeding 37 dBm ERP, the unit output
power can be backed off to 34 dBm. With an indoor antenna gain of 3 dBi, the EIRP is 37 dBm.
The maximum power density safe exposure level for general population/uncontrolled exposure of
30 minutes for the frequency of 152 MHz is 0.2 mW/cm2.
Conducted Output
Power (dBm)
Max Antenna
Gain (dBi)
Max EIRP (mW)
Power Density Limit
Allowed (mW/cm²)
Safe Distance
(cm)
34
3
5012
0.2
45
As shown above, the minimum safe distance where the MPE limit is reached is 45 cm from
with a 3 dBi antenna and no distribution loss.
If the antenna will be positioned closer to end users than 45 cm, then the installer must calculate
the safe distance for a given installation using the formulas provided.
450 MHz Band, Mode A (2 W)
In the Frequency Range of 300 to 1500 MHz, the maximum power density limit for the
occupational/controlled exposures is f/300 mW/cm2for an average time of 6 minutes. In the
Frequency Range of 300 to 1500 MHz, the maximum power density limit for the general
population/uncontrolled exposures is f/1500 mW/cm2for an average time of 30 minutes.
The antenna connected to the product is specific to the deployment. The worst case scenario
occurs when using a very high gain indoor/outdoor antenna. However a typical indoor antenna is
shown in the following example:
The highest expected output power is 34 dBm at 481MHz. For an output level of 34 dBm with an
indoor antenna gain of 2 dBi, the EIRP is 36 dBm.
The maximum power density safe exposure level for general population/uncontrolled exposure of
30 minutes for the frequency of 481 MHz is 0.321 mW/cm2.
Conducted Output
Power (dBm)
Max Antenna
Gain (dBi)
Max EIRP
(mW)
Power Density Limit
Allowed (mW/cm²)
Safe Distance
(cm)
34
2
3981
0.321
32
As shown above, the minimum safe distance where the MPE limit is reached is 32 cm from the
unit with a 2 dBi antenna and no distribution loss.

Dali Matrix PS System Installation and Commissioning Guide| xi
Dali Wireless Proprietary and Confidential | DW-MAN-036 Rev 06
If the antenna will be positioned closer to end users than 32 cm, then the installer must calculate
the safe distance for a given installation using the formulas provided.
800 MHz Band, Mode A (2 W)
In the Frequency Range of 300 to 1500 MHz, the maximum power density limit for the
occupational/controlled exposures is f/300 mW/cm2for an average time of 6 minutes.
In the Frequency Range of 300 to 1500 MHz, the maximum power density limit for the general
population/uncontrolled exposures is f/1500 mW/cm2for an average time of 30 minutes.
The antenna connected to the product is specific to the deployment. The worst case scenario
occurs when using a very high gain outdoor/indoor antenna. However a typical indoor antenna is
shown in the following example:
The highest expected output power is 33.6 dBm at 856MHz. For an output level of 33.6 dBm with
an indoor antenna gain of 3 dBi, the EIRP is 36.6 dBm.
The maximum power density safe exposure level for general population/uncontrolled exposure of
30 minutes for the frequency of 856 MHz is 0.571 mW/cm2.
Conducted Output
Power (dBm)
Max Antenna
Gain (dBi)
Max EIRP
(mW)
Power Density Limit
Allowed (mW/cm²)
Safe Distance
(cm)
33.6
3
4571
0. 571
26
As shown above, the minimum safe distance where the MPE limit is reached is 26 cm from
the unit with a 3 dBi antenna and no distribution loss.
If the antenna will be positioned closer to end users than 26 cm, then the installer must calculate
the safe distance for a given installation using the formulas provided.
900 MHz Band, Mode A (2 W)
In the Frequency Range of 300 to 1500 MHz, the maximum power density limit for the
occupational/controlled exposures is f/300 mW/cm2for an average time of 6 minutes.
In the Frequency Range of 300 to 1500 MHz, the maximum power density limit for the general
population/uncontrolled exposures is f/1500 mW/cm2for an average time of 30 minutes.
The antenna connected to the product is specific to the deployment. The worst case scenario
occurs when using a very high gain indoor/outdoor antenna. However a typical indoor antenna is
shown in the following example:

xii | Dali Matrix PS System Installation and Commissioning Guide
Dali Wireless Proprietary and Confidential | DW-MAN-036 Rev 06
The highest expected output power is 33.2 dBm at 937.5MHz. For an output level of 33.2 dBm with
an indoor antenna gain of 3 dBi, the EIRP is 36.2 dBm.
The maximum power density safe exposure level for general population/uncontrolled exposure of
30 minutes for the frequency of 937.5 MHz is 0.625 mW/cm2.
Conducted Output
Power (dBm)
Max Antenna
Gain (dBi)
Max EIRP
(mW)
Power Density Limit
Allowed (mW/cm²)
Safe Distance
(cm)
33.2
3
4169
0. 625
24
As shown above, the minimum safe distance where the MPE limit is reached is 24 cm from
the unit with a 3 dBi antenna and no distribution loss.
If the antenna will be positioned closer to end users than 24 cm, then the installer must calculate
the safe distance for a given installation using the formulas provided.
TYPE 2 CHASSIS
Intermodulation
hd33 PS Quad Band Downlink
450 MHz, 700 MHz, 800 MHz, 900 MHz band, Mode A (2W)
Example: 6 dB of minimum distribution loss when 2-carrier composite power is 33 dBm

Dali Matrix PS System Installation and Commissioning Guide| xiii
Dali Wireless Proprietary and Confidential | DW-MAN-036 Rev 06
RF Exposure
hd33 PS Quad Band
Band 1: 450 MHz
In the Frequency Range of 300 to 1500 MHz, the maximum power density limit for the
occupational/controlled exposures is f/300 mW/cm2for an average time of 6 minutes.
In the Frequency Range of 300 to 1500 MHz, the maximum power density limit for the general
population/uncontrolled exposures is f/1500 mW/cm2for an average time of 30 minutes.
The antenna connected to the product is specific to the deployment. The worst case scenario
occurs when using a very high gain outdoor/indoor antenna. However a typical indoor antenna is
shown in the following example:
The highest expected output power is 35 dBm at 511.9875MHz. For an output level of 35 dBm with
an indoor antenna gain of 3 dBi, the EIRP is 38 dBm.
The maximum power density safe exposure level for general population/uncontrolled exposure of
30 minutes for the frequency of 511.9875 MHz is 0.341 mW/cm2.
Conducted Output
Power (dBm)
Max Antenna
Gain (dBi)
Max EIRP
(mW)
Power Density Limit
Allowed (mW/cm²)
Safe Distance
(cm)
35
3
6310
0.341
39
As shown above, the minimum safe distance where the MPE limit is reached is 39 cm
from the unit with a 3 dBi antenna and no distribution loss.
The antenna used in the above table is a Galtronics PEAR S5491i with 3dBi gain in the 450 MHz
band.
If the antenna will be positioned closer to end users than 39cm, then the installer must calculate
the safe distance for a given installation using the formulas provided.
Band 2: 700 MHz
In the Frequency Range of 300 to 1500 MHz, the maximum power density limit for the
occupational/controlled exposures is f/300 mW/cm2for an average time of 6 minutes.
In the Frequency Range of 300 to 1500 MHz, the maximum power density limit for the general
population/uncontrolled exposures is f/1500 mW/cm2for an average time of 30 minutes.

xiv | Dali Matrix PS System Installation and Commissioning Guide
Dali Wireless Proprietary and Confidential | DW-MAN-036 Rev 06
The antenna connected to the product is specific to the deployment. The worst case scenario
occurs when using a very high gain outdoor/indoor antenna. However a typical indoor antenna is
shown in the following example:
The highest expected output power is 35.1 dBm at 772MHz. For an output level of 35.1 dBm with
an indoor antenna gain of 2.5 dBi, the EIRP is 37.6 dBm.
The maximum power density safe exposure level for general population/uncontrolled exposure of
30 minutes for the frequency of 772 MHz is 0.515 mW/cm2.
Conducted Output
Power (dBm)
Max Antenna
Gain (dBi)
Max EIRP
(mW)
Power Density Limit
Allowed (mW/cm²)
Safe Distance
(cm)
35.1
2.5
5754
0.515
30
As shown above, the minimum safe distance where the MPE limit is reached is 30 cm from
the unit with a 2.5 dBi antenna and no distribution loss.
The antenna used in the above table is a Galtronics PEAR S5491i with 2.5 dBi gain in the
700 MHz band.
If the antenna will be positioned closer to end users than 30 cm, then the installer must calculate
the safe distance for a given installation using the formulas provided.
Band 3: 800 MHz
In the Frequency Range of 300 to 1500 MHz, the maximum power density limit for the
occupational/controlled exposures is f/300 mW/cm2for an average time of 6 minutes.
In the Frequency Range of 300 to 1500 MHz, the maximum power density limit for the general
population/uncontrolled exposures is f/1500 mW/cm2for an average time of 30 minutes.
The antenna connected to the product is specific to the deployment. The worst case scenario
occurs when using a very high gain outdoor/indoor antenna. However a typical indoor antenna is
shown in the following example:
The highest expected output power is 35.5 dBm at 860.9875MHz. For an output level of 35.5 dBm
with an indoor antenna gain of 3.5 dBi, the EIRP is 39 dBm.
The maximum power density safe exposure level for general population/uncontrolled exposure of
30 minutes for the frequency of 860.9875 MHz is 0.574 mW/cm2.

Dali Matrix PS System Installation and Commissioning Guide| xv
Dali Wireless Proprietary and Confidential | DW-MAN-036 Rev 06
Conducted Output
Power (dBm)
Max Antenna
Gain (dBi)
Max EIRP
(mW)
Power Density Limit
Allowed (mW/cm²)
Safe Distance
(cm)
35.5
3.5
7943
0.574
34
As shown above, the minimum safe distance where the MPE limit is reached is 34 cm from
the unit with a 3.5 dBi antenna and no distribution loss.
The antenna used in the above table is a Galtronics PEAR S5491i with 3.5 dBi gain in the
800 MHz band.
If the antenna will be positioned closer to end users than 34 cm, then the installer must calculate
the safe distance for a given installation using the formulas provided.
Band 4: 900 MHz
In the Frequency Range of 300 to 1500 MHz, the maximum power density limit for the
occupational/controlled exposures is f/300 mW/cm2for an average time of 6 minutes.
In the Frequency Range of 300 to 1500 MHz, the maximum power density limit for the general
population/uncontrolled exposures is f/1500 mW/cm2for an average time of 30 minutes.
The antenna connected to the product is specific to the deployment. The worst case scenario
occurs when using a very high gain indoor/outdoor antenna. However a typical indoor antenna is
shown in the following example:
The highest expected output power is 34.8 dBm at 935.0125MHz. For an output level of 34.8 dBm
with an indoor antenna gain of 3.5 dBi, the EIRP is 38.3 dBm.
The maximum power density safe exposure level for general population/uncontrolled exposure of
30 minutes for the frequency of 935.0125 MHz is 0.623 mW/cm2.
Conducted Output
Power (dBm)
Max Antenna
Gain (dBi)
Max EIRP (mW)
Power Density Limit
Allowed (mW/cm²)
Safe Distance (cm)
34.8
3.5
6761
0.623
30
As shown above, the minimum safe distance where the MPE limit is reached is 30 cm from
the unit with a 3.5 dBi antenna and no distribution loss.
The antenna used in the above table is a Galtronics PEAR S5491i with 3.5 dBi gain in the
900 MHz band.
If the antenna will be positioned closer to end users than 30 cm, then the installer must calculate
the safe distance for a given installation using the formulas provided.

xvi | Dali Matrix PS System Installation and Commissioning Guide
Dali Wireless Proprietary and Confidential | DW-MAN-036 Rev 06
Disclaimer
Dali Wireless, Inc. assumes no responsibility for errors or omissions that may appear in this
publication. Dali reserves the right to make changes this publication at any time without notice as
part of our continuing effort to improve our products.

Dali Matrix PS System Installation and Commissioning Guide| xvii
Dali Wireless Proprietary and Confidential | DW-MAN-036 Rev 06
CONTENTS
Regulatory Compliance.............................................................................................iii
FCC iii
Signal Booster Installation Guidelines..................................................................iv
TYPE 1 CHASSIS.................................................................................................v
TYPE 2 CHASSIS...............................................................................................xii
Disclaimer..............................................................................................................xvi
Contents..................................................................................................................xvii
Preface...................................................................................................................xxiii
Contacting Dali Customer Service........................................................................xxiii
1Overview........................................................................................................24
1.1 Matrix PS System Architecture....................................................................25
1.2 Public Safety Band Selection.......................................................................26
1.3 hdHost PS Base Station Host Unit...............................................................26
1.4 airHost PS Off-Air Host Unit ........................................................................28
1.5 hd33 PS Remote Radio Unit........................................................................30
1.6 Matrix Console PS.......................................................................................32
PART 1 Installation...................................................................................................33
2Installation Requirements.............................................................................34
2.1 Matrix PS Installation and Commissioning Workflow....................................35
2.2 Documentation Requirements .....................................................................36
2.3 System Level Requirements........................................................................36
2.3.1 Safety Warnings..................................................................................36
2.3.2 Equipment Room Preparation..............................................................38
2.3.3 Rack Specifications and Installation.....................................................38
2.3.4 Fiber Plant...........................................................................................39
2.3.5 Cable Labeling.....................................................................................39
2.3.6 RF Antenna Infrastructure....................................................................40
2.4 Installation Requirements............................................................................41
2.4.1 Tools and Equipment...........................................................................41
2.4.2 Shipping Contents...............................................................................41
2.4.3 Power Supply and Grounding ..............................................................42
2.4.4 Cables.................................................................................................43
3hdHost PS Installation..................................................................................44
3.1 Preparing for Installation..............................................................................44
3.1.1 Power Consumption ............................................................................44

xviii | Dali Matrix PS System Installation and Commissioning Guide
Dali Wireless Proprietary and Confidential | DW-MAN-036 Rev 06
3.1.2 Rack Mounting Requirements..............................................................45
3.1.3 Warnings.............................................................................................45
3.1.4 Weight.................................................................................................45
3.2 Rack Mounting the hdHost PS.....................................................................46
3.2.1 Installing Cable Management Trays.....................................................48
3.3 Grounding the hdHost PS............................................................................48
3.3.1 Attaching the Chassis Ground..............................................................49
3.3.2 Connecting hdHost PS Ground to Rack Ground...................................50
3.4 Connecting DC Power.................................................................................50
3.4.1 Option 1: Using a DC Power Connector and Cable..............................51
3.4.2 Option 2: Using the Matrix AC/DC Power Supply .................................53
3.5 Verifying Power and Standby Mode.............................................................55
4hdHost PS RF Cabling..................................................................................56
4.1 Connecting Base Station Uplink and Downlink Feeds..................................56
4.1.1 Verifying RF Cable Power and Performance........................................56
4.1.2 Connecting RF Cables to the hdHost PS..............................................57
5airHost PS & Remote Type 1 Chassis Installation.......................................58
5.1 Type 1 Chassis Specifications.....................................................................58
5.2 Preparing for Installation..............................................................................59
5.2.1 Power Consumption ............................................................................59
5.2.2 Warnings.............................................................................................59
5.2.3 Weight.................................................................................................59
5.2.4 Remote Orientation..............................................................................59
5.3 Wall Mounting.............................................................................................60
5.4 Rack Mounting............................................................................................63
5.4.1 Other Rack Mounting Options..............................................................67
5.5 Grounding...................................................................................................68
5.6 Connecting DC Power.................................................................................68
5.6.1 Option 1: Using a DC Power Connector and Cable..............................69
5.6.2 Option 2: Using the Matrix AC/DC Power Supply .................................69
5.7 Verifying Power and Standby Mode.............................................................70
6airHost PS & Remote Type 2 Chassis Installation.......................................72
6.1 Type 2 Chassis Specifications.....................................................................72
6.2 Preparing for Installation..............................................................................73
6.2.1 Power Consumption ............................................................................73
6.2.2 Input Power Requirements...................................................................73
6.2.3 Warnings.............................................................................................73
6.2.4 Weight.................................................................................................73
6.2.5 Remote Orientation..............................................................................73
6.3 Wall or Post Mounting .................................................................................74
6.4 Rack Mounting............................................................................................77
6.5 Grounding...................................................................................................81
6.6 Connecting DC Power.................................................................................82

Dali Matrix PS System Installation and Commissioning Guide| xix
Dali Wireless Proprietary and Confidential | DW-MAN-036 Rev 06
6.6.1 Option 1: Using a DC Power Connector and Cable..............................82
6.6.2 Option 2: Using the Matrix AC/DC Power Supply .................................83
6.7 Verifying Power and Standby Mode.............................................................85
6.8 Locking the Unit ..........................................................................................87
7airHost PS & Remote RF Cabling.................................................................88
7.1 RF Cabling Requirements...........................................................................88
7.2 Connecting RF Feed Cables: Simplex RF Interface Option for Low Frequency
Bands 89
7.3 Connecting RF Feed Cables: Internal Duplexer/Multiplexer Option ..............90
8Remote Ethernet Cabling..............................................................................91
9Optical Fiber Installation...............................................................................94
9.1 Preparing for Installation..............................................................................94
9.1.1 Safety Overview ..................................................................................94
9.1.2 Installation Requirements.....................................................................95
9.1.3 Testing Requirements..........................................................................95
9.2 Fiber Installation..........................................................................................95
9.3 Fiber Topologies .........................................................................................96
9.3.1 Star Configuration................................................................................96
9.3.2 Daisy Chain Configuration ...................................................................97
9.3.3 Hybrid Configuration............................................................................98
9.4 Connecting Single Mode Fiber.....................................................................98
9.4.1 Optical Fiber Adapter Kit....................................................................100
9.5 Daisy Chaining Hosts and Remotes...........................................................101
10 Matrix Console PS Installation ...................................................................103
10.1 Preparing for Installation............................................................................103
10.1.1 Power Consumption ..........................................................................103
10.1.2 Warnings...........................................................................................103
10.1.3 Firewall Protection.............................................................................104
10.2 Rack Mounting..........................................................................................104
10.3 Connecting Ethernet Cables......................................................................106
10.3.1 Connecting to Multiple Host Units ......................................................107
10.4 Powering on the Unit.................................................................................108
11 Installation Verification...............................................................................109
11.1 Startup LED Sequence..............................................................................110
11.2 Standby LEDs...........................................................................................110
11.2.1 hdHost PS.........................................................................................110
11.2.2 airHost PS & Remotes.......................................................................111
11.3 Troubleshooting LED Alarms.....................................................................113
11.3.1 Alarm LED.........................................................................................113
11.3.2 Power LED........................................................................................113

xx | Dali Matrix PS System Installation and Commissioning Guide
Dali Wireless Proprietary and Confidential | DW-MAN-036 Rev 06
PART 2 System Commissioning............................................................................114
12 IP Network Configuration ...........................................................................115
12.1 About the System Controller......................................................................115
12.2 IP Network Overview.................................................................................115
12.2.1 Customer IP Network.........................................................................116
12.2.2 Matrix IP Network ..............................................................................116
12.2.3 Remote Maintenance Link......................Error! Bookmark not defined.
12.2.4 Ports..................................................................................................117
12.3 Logging Into the EMS................................................................................117
12.3.1 Connecting a Laptop...............................Error! Bookmark not defined.
12.3.2 If Using IPv4 Access...............................Error! Bookmark not defined.
12.3.3 If Using IPv6 Access..........................................................................124
12.3.4 Logging in with the Default Username and Password.........................126
12.3.5 Changing the Password.....................................................................126
12.4 Configuring SNMP.....................................................................................127
12.4.1 Downloading the Dali MIB File...........................................................127
12.4.2 Configuring SNMP Trap Receivers ....................................................128
13 Matrix EMS Overview..................................................................................142
13.1 EMS Terms and Definitions.......................................................................142
13.2 Browser Support and Troubleshooting.......................................................143
13.3 EMS Screens............................................................................................143
13.3.1 System Tree......................................................................................144
13.3.2 Unit and Band Information Views .......................................................145
13.4 Field Descriptions......................................................................................145
13.4.1 Unit Information Fields.......................................................................145
13.4.2 RF Module Fields ..............................................................................147
13.4.3 Optical Port Fields.............................................................................150
13.5 Status Descriptions ...................................................................................151
13.5.1 Unit Status.........................................................................................152
13.5.2 RF Module Status..............................................................................153
13.5.3 Optical Port Status.............................................................................155
13.6 Field and Slider Button Colors...................................................................156
13.7 Activating RF Modules or Optical Ports......................................................156
13.7.1 If an RF Module or Optical Port Cannot Activate ................................158
13.8 Placing RF Modules or Optical Ports in Standby........................................159
14 Host and Remote Configuration.................................................................161
14.1 Configuring the Reference Clock...............................................................161
14.1.1 Selecting the Host Reference Clock...................................................162
14.1.2 Verifying Clock Synchronization.........................................................162
14.2 Verifying Optical Ports...............................................................................163
14.3 Reviewing and Resolving Alarms...............................................................164
14.3.1 Displaying the Alarm Summary..........................................................164
14.3.2 Displaying Alarms by Slot ..................................................................165
