Find the Teledyne Dalsa / Coreco Imaging DS-42-04M30 at our website: Click HERE

4M30
DS-44-04M30
DS-46-04M30
30 fps 2k x2k
CCD Camera
User’s Manual and Reference
Doc #: 03-32-10030
Rev: 04
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4M30 Camera User’s Manual 2
DALSA 03-32-10030-04
© 2002 DALSA. All information provided in this manual is believed to be accurate and reliable. No responsibility is
assumed by DALSA for its use. DALSA reserves the right to make changes to this information without notice.
Reproduction of this manual in whole or in part, by any means, is prohibited without prior permission having been
obtained from DALSA.
AboutDALSA
DALSA is an international high performance semiconductor and electronics company that designs, develops,
manufactures, and markets digital imaging products and solutions, in addition to providing wafer foundry services.
DALSA’s core competencies are in specialized integrated circuit and electronics technology, and highly engineered
semiconductor wafer processing. Products include image sensor components; electronic digital cameras; and
semiconductor wafer foundry services for use in MEMS, power semiconductors, image sensors and mixed signal
CMOS chips.
DALSA is a public company listed on the Toronto Stock Exchange under the symbol “DSA”. Based in Waterloo, On.
Canada, the company has operations in Bromont, PQ; Colorado Springs, CO; Eindhoven, NL; Munich, Germany and
Tokyo, Japan.
All DALSA products are manufactured using the latest state-of-the-art equipment to ensure product reliability.
DALSTAR refers to all DALSA area scan products.
For further information not included in this manual, or for information on DALSA’s extensive line of image sensing
products, please contact us.
DALSA Sales Offices
Waterloo Europe Asia Pacific
605McMurrayRd
Waterloo,ON N2V2E9
Canada
Tel:[phone]
Fax:[phone]
www.dalsa.com
[e-mail]
BreslauerStr.34
D-82194Gröbenzell
(Munich)
Germany
Tel:+49-8142–
46770
Fax:+49 -8142–
467746
www.dalsa.com
[e-mail]
SpaceG1Building,4F
2-40-2Ikebukuro
Toshima-ku,Tokyo171-
0014
Japan
[phone]
(phone)
[phone] (fax)
www.dalsa.com
[email protected]m
DALSA Worldwide Operations
Waterloo Colorado Springs Europe Asia Pacific
605McMurrayRd
Waterloo,ON N2V2E9
Canada
Tel:[phone]
Fax:[phone]
www.dalsa.com
[e-mail]
5055CorporatePlazaDrive
ColoradoSprings,CO 80919
USA
Tel:[phone]
Fax:[phone]
www.dalsa.com
[e-mail]
BreslauerStr.34
D-82194Gröbenzell(Munich)
Germany
Tel:[phone]
Fax:[phone]
www.dalsa.com
[e-mail]
SpaceG1Building,4F
2-40-2Ikebukuro
Toshima-ku,Tokyo171-0014
Japan
[phone] (phone)
[phone] (fax)
www.dalsa.com
[email protected]m
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4M30 Camera User’s Manual 3
DALSA 03-32-10030-04
Contents
ContentsContents
Contents
Introduction tothe 4M30 Camera____________________________________________ 5
1.1CameraHighlights.......................................................................................................................................................5
1.2Image Sensor...............................................................................................................................................................6
1.3Camera PerformanceSpecifications............................................................................................................................7
Camera Hardware Interface________________________________________________ 9
2.1InstallationOverview...................................................................................................................................................9
2.2Input/Output................................................................................................................................................................9
2.3LED StatusIndicators...................................................................................................................................................10
2.4PowerInput.................................................................................................................................................................11
2.5DataOutput.................................................................................................................................................................12
2.6Serial Communication.................................................................................................................................................13
2.7TTL TriggerInput andOutput.....................................................................................................................................15
2.8IntegrationTime..........................................................................................................................................................16
2.9Timing.........................................................................................................................................................................16
Camera Operation ______________________________________________________ 19
3.1How toControltheCamera.........................................................................................................................................19
3.2ADCCommands...........................................................................................................................................................20
3.3Clock Commands..........................................................................................................................................................21
3.4ControlRegisterReference..........................................................................................................................................21
3.5ReadingtheCameraType...........................................................................................................................................22
3.6ReadingtheFirmwareRevision..................................................................................................................................22
3.7ResettingtheADCboards(“soft”reset)......................................................................................................................22
3.8ResettingtheCamera(“hard”reset)...........................................................................................................................23
3.9AdjustingGain.............................................................................................................................................................23
3.10AdjustingUserOffset.................................................................................................................................................24
3.11AutomaticOffsetControl(AOC).................................................................................................................................25
3.12No CleanMode..........................................................................................................................................................25
3.13Triggering,Integration,andFrame RateOverview..................................................................................................26
3.14ControllingIntegration(ShutterTime).....................................................................................................................26
3.15ControllingFrameRate.............................................................................................................................................29
Optical and Mechanical Considerations________________________________________ 31
4.1MechanicalInterface....................................................................................................................................................31
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4M30 Camera User’s Manual 4
DALSA 03-32-10030-04
4.2MechanicalTolerances.................................................................................................................................................32
4.3MountingtheCamera..................................................................................................................................................32
Cleaning and Maintenance ________________________________________________ 33
5.1Cleaning.......................................................................................................................................................................33
5.2Maintenance................................................................................................................................................................34
Troubleshooting________________________________________________________ 35
Warranty_____________________________________________________________ 37
7.1LimitedOne-YearWarranty........................................................................................................................................37
Appendix A ___________________________________________________________ 39
LVDS(EIA-644)Reference.................................................................................................................................................39
Index _______________________________________________________________ 43
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4M30 Camera User’s Manual 5
DALSA 03-32-10030-04
1
Introduction to the 4M30
Introduction to the 4M30Introduction to the 4M30
Introduction to the 4M30
Camera
CameraCamera
Camera
1.1 Camera Highlights
Features
• 2048 x 2048 resolution, full-frame CCD architecture
• 30 fps four output, 4x40 MHz data rate
• True 12-bit digitization
• High sensitivity with low dark current
• Progressive scan readout
• Asynchronous image capture, externally triggerable to within 175 ns.
• Programmable operation via RS232, including gain (1x – 10x), offset (±full scale), and
triggering
• 100% fill factor
• DS-44-04M30 is the standard 4M30 camera
• DS-46-04M30 has a sensor with taped on coverglass
Description
The 4M30 digital camera provides high-sensitivity 12-bit images with 2k x 2k spatial resolution at
up to 30 frames per second (fps). The 4M30 is a full frame CCD camera using a progressive scan
CCD to simultaneously achieve outstanding resolution and gray scale characteristics. A square
pixel format and high fill factor provide superior, quantifiable image quality even at low light
levels.
Applications
The 4M30 is an outstanding performer in fast, very high resolution applications. True 12 bit
performance provides up to 4096 distinct gray levels—perfect for applications with large
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4M30 Camera User’s Manual 6
DALSA 03-32-10030-04
interscene light variations. The low-noise, digitized video signal also makes the camera an
excellent choice where low contrast images must be captured in challenging applications.
1.2 Image Sensor
The 4M30 uses DALSA's IA-DA-2048 high-performance full-frame CCD.
Figure 1. IA-DA-2048 Image Sensor Block Diagram
Table 1. IA-DA-2048 Sensor Structure
Sensor characteristics
Optical size 24.576mm (H) x 24.576 mm (V)
Chip size 26.860 mm (H) x 26.508 mm (V)
Pixel size 12µm x 12µm
Active pixels 4 * [1024 (H) x 1024 (V)]
Total number of pixels 2096 (H) x 2060 (V)
Optical black pixels Left: 20 Right: 20
Timing pixels Left: 4 Right: 4
Dummy register cells Left: 7 Right: 7
Optical black lines Bottom: 6 Top: 6
Table 2. IA-DA-2048 Sensor Cosmetic Specifications
Specification Grade 02
a) Number of first and last columns excluded 16
b) Number of first and last rows excluded 16
c) Maximum quantity of single pixel blemishes unspecified
d) Maximum quantity of cluster blemishes 75
e) Maximum size of clusters (adjacent pixels) 30
f) Blemish pixel deviation from VFLL* under illumination >10% <45%
Thissectionis not
applicabletopart
numberDS-46-04M30
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4M30 Camera User’s Manual 7
DALSA 03-32-10030-04
Specification Grade 02
g) Blemish pixel deviation from average dark level, measured at dark >20mV
Notes:
*VFLL is defined as the output signal under broadband quartz tungsten halogen light with an
irradiance of 4.08µW/cm2.
1. All sensors are tested in four output mode – 1x gain.
2. Blemish variations are measured over an entire frame of data and counted within the frame
boundaries defined by a) and b).
3. Blemishes are defined as a pixel or group of pixels with an output as defined in f) or g).
4. Clusters are defined as a pixel or group of pixel blemishes, and are allowed, provided they are
smaller or equal to the sizes specified in e).
5. Illuminated blemish analysis done at 70% of VFLL (2.86µW/cm2).
6. Column and row defects not permitted.
7. Better than grade 02 sensors may be available. Please contact DALSA sales if interested.
1.3 Camera Performance Specifications
Table 3: 4M30 Camera Performance Specifications
Physical
Characteristics Units Notes
Resolution H x V pixels 2048x2048
Pixel Size µm 12x12
Pixel Fill Factor %100
Size mm 146x92x14
3
Mass kg 1.3
Power Dissipation W < 24
Lens Mount F mount
Aperture mm 24.6 x 24.6
Operating Ranges Units Min. Max.
Frame Rate Fps 30
Data Rate MHz 4*40 4*40
Data Format LVDS 4*12 bit
Responsivity DN/(nJ/cm2) 24@530nm 4
Operating Temp °C 10 40
+15 Input Voltage V +14.925 +15.075
+5 Input Voltage V+4.975 +5.025
-5 Input Voltage V - 4.975 - 5.025
Nominal Gain Range 1x 10x
Calibration
Conditions Units Setting Min. Max.
Data Rate MHz 4x40 4x40 4x40
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4M30 Camera User’s Manual 8
DALSA 03-32-10030-04
Physical
Characteristics Units Notes
+15 Input Voltage V +15 +14.925 +15.075
+5 Input Voltage V+5 +4.975 +5.025
-5 Input Voltage V - 5 - 4.975 - 5.025
Ambient Temperature °C 25
Gain X 1x
Electro-Optical
Specifications Units Min. Typical Max.
Dynamic Range dB 64.0 67.0 1
Pixel Response Non-
Uniformity %rms 2.0 3.0 2, 4
System Noise DN(rms) 2.1 2.4
Notes:
1. Dynamic Range = 20 * log10[(Counts @ Full Well)/Read Noise]
2. PRNU = [[[STDEV(100 frames @ saturation)/(MEAN @ saturation)]-Dark Offset(in
darkness)]*100
3. System Noise = Read Noise (e-)/Gain (e-/DN) dark measurement
4. Specification not applicable to the DS-45-04M30 due to Lumogen coated sensor
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4M30 Camera User’s Manual 9
DALSA 03-32-10030-04
2
Camera Hardware
Camera HardwareCamera Hardware
Camera Hardware
Interface
InterfaceInterface
Interface
2.1 Installation Overview
In order to set up your camera, you should take these initial steps:
1. Power down all equipment.
2. Following the manufacturer’s instructions, install the frame grabber (if applicable). Be sure to
observe all static precautions.
3. Install any necessary imaging software.
4. Before connecting power to the camera, test all power supplies. Ensure that all the correct voltages
are present at the camera end of the power cable (Refer to the Camera Performance Specifications
on page 7). Power supplies must meet the requirements defined in section 2.4 Power Input.
5. Inspect all cables and connectors prior to installation. Do not use damaged cables or
connectors or the camera may be damaged.
6. Connect data, serial interface, and power cables.
7. After connecting cables, apply power to the camera. The POST (power on self test) LED on
the back of the camera should glow green after one second to indicate that the camera is
operating and ready to receive commands.
2.2 Input/Output
The camera provides 12-bit LVDS data and synchronization signals through the data output
connector. Camera functions such as integration time, camera gain and offset are all controllable
by the user via the RS232 serial port. The camera is capable of free running operation or may be
triggered externally via the input TRIGGER IN. TRIGGER OUT allows the synchronization of
shutters or illumination sources in free running or externally triggered modes.
Thisinstallation
overviewassumesyou
havenotinstalledany
system componentsyet.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4M30 Camera User’s Manual 10
DALSA 03-32-10030-04
Figure 2: Camera Inputs/Outputs
2.3 LED Status Indicators
There are four LED's visible on the rear cover of the camera that indicate the camera’s status.
Table 4: LED Functions
LED
Label Color LED “ON” LED “OFF”
ON Green Camera is receiving power No camera power
POST Green Camera Power On Self Test successful Camera failed Power On Self Test
BIN Green Not Operational Not Operational
MODE Green Camera is in an external trigger mode (uses
external signal to trigger image capture) Camera is triggering image capture internally
Channel 2 data output Channel 3 data output
Channel 4 data output
Channel 4 data output
Channel 1 data output
Channel 1 data output
Trigger input & output
Serial port
LED Status indicators
LED Status indicators
Power supply input
Power supply input
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4M30 Camera User’s Manual 11
DALSA 03-32-10030-04
2.4 Power Input
Table 5: Power Connector Pinout
Pin Symbol
1+5V
The camera has the following input power
requirements:
2+5V
3- 5V
4+15V
V
(DC) ±
±±
±%Max
Ripple
mV
A
5NC +15 .0.5 < 50 0.5
6 NC +5 0.5 < 50 3.7
7GND -5 0.5 < 50 0.8
8GND
9+5V
10 - 5V
11 +15V
12 +15V
13 NC
14 GND
15 GND
1
9
15 8
DB15M
(AMP Part # 747236-4
or equivalent)
Note: Performance specifications are not
guaranteed if your power supply does not
meet these requirements.
DALSA offers a linear power supply (with
cables) that meets the 4M30’s requirements
(Universal Power Supply, part number 24-
00001-02, contact DALSA for more
information), but it should not be considered
the only choice. Many high quality supplies
are available from other vendors. DALSA
assumes no responsibility for the use of these
supplies.
When setting up the camera’s power supplies, follow these guidelines:
•Do not connect or disconnect cable while power is on.
•Do not use the shield on a multi-conductor cable for ground.
•Keep leads as short as possible to reduce voltage drop.
•Use high-quality linear supplies to minimize noise.
!
WARNING:Itis extremely
important thatyou apply
theappropriatevoltages to
yourcamera.Incorrect
voltageswilldamagethe
camera.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4M30 Camera User’s Manual 12
DALSA 03-32-10030-04
!
2.5 Data Output
Figure 3 illustrates how the data channel outputs correspond to the image quadrants when using a
standard inverting lens.
Figure 3: Data Channel for each Image Quadrant
The camera back panel output connectors DATA1, DATA 2, DATA 3, and DATA 4 utilize
differential LVDS signals with pin assignments described in Table 6.
Connector and Pinout
Table 6: DATA Connector Pinout
Pin Symbol Pin Symbol Pin Symbol Pin Symbol
1D*0+ 16 Reserved 31 NC 46 GND
2 D*0- 17D*7+ 32NC 47NC
3D*1+ 18 D*7- 33 NC 48 NC
4 D*1- 19D*8+ 34NC 49NC
5D*2+ 20 D*8- 35 NC 50 NC
6 D*2- 21D*9+ 36NC 51NC
7D*3+ 22 D*9- 37 NC 52 NC
8 D*3- 23 D*10+ 38 NC 53 Reserved
9D*4+ 24 D*10- 39 NC 54 Reserved
10 D*4- 25 D*11+ 40 NC 55 VSYNC-
11 D*5+ 26 D*11- 41 NC 56 VSYNC+
12 D*5- 27 NC 42 NC 57 HSYNC-
13 D*6+ 28 NC 43 NC 58 HSYNC+
14 D*6- 29 NC 44 NC 59 PIXCLK-
15 Reserved 30 NC 45 GND 60 PIXCLK+
15
1
16
30
45
31
46
60
(Molex Part #
70928-2000
or equivalent)
NC = No Connect. These pins are unused.
WARNING.Care must be taken when connecting data cables to the camera to insure proper
connection and to prevent damage to the connector.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4M30 Camera User’s Manual 13
DALSA 03-32-10030-04
Data Signals
Table 7: Data Signal Definition
Signal Description
D*0+, D*0- Data bit 0 true and complement—Output. (Least significant bit.)
D*1+, D*1- Data bit 1 true and complement—Output.
D*2+, D*2- Data bit 2 true and complement—Output.
D*3-D*10+,- etc. Etc.
D*11+, D*11- Data bit 11 true and complement—Output. (Most significant bit.)
Digitized video data is output from the camera as LVDS differential signals using 4 Molex 60-pin
connectors on the rear panel (labeled “DATA 1 through DATA 4”). The data is synchronous and
is accompanied by a pixel clock and clocking signals.
Data Clocking Signals
Table 8: Clock Signal Descriptions
Signal Description
PIXCLK+,
PIXCLK- Pixel clock true and complement. 40MHz—Output.
Data is valid on the falling edge.
HSYNC+,
HSYNC- Horizontal sync, true and complement—Output.
HSYNC high indicates the camera is outputting a valid line of data.
VSYNC+,
VSYNC- Vertical sync, true and complement—Output.
VSYNC high indicates the camera is outputting a valid frame of data.
2.6 Serial Communication
Connector and Pinout
The serial interface provides control of frame rate, integration time (shuttering), video gain and
offset, external trigger and external integration. For information on how to control these functions,
see Camera Operation, beginning on page 19. The remote interface consists of a two-wire (plus
ground) full duplex RS-232 compatible serial link, used for camera configuration, and two back
panel SMA coax connectors used for external trigger input and output.
IMPORTANT:
Thiscamerausesthe
falling
fallingfalling
falling edge of the pixel
clockto registerdata.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4M30 Camera User’s Manual 14
DALSA 03-32-10030-04
RJ-11
View into female jack
6-position with 4 conductors
RXDTXDGND
The camera uses an RJ-11 telephone-style connector for serial
communications, with four conductors installed in a six-position
connector. Note that both four- and six- conductor plugs may be
used interchangeably with the RJ-11 jack.
IMPORTANT:Both the PC/AT and the camera are configured as
“DTE” (Data Terminal Equipment) devices requiring the TXD
and RXD lines to be swapped when interconnecting the two (note
that pin 4, normally the yellow wire, is not used on the RJ-11.)
That is, the TXD pin represents DATA OUT and the RXD pin
represents DATA IN on both devices, so that one device’s TXD
line must connect to the other device’s RXD line and vice-versa.
Figure 4: 25 Pin Serial Port Connector to Camera RJ-11 Connector
Figure 5: 9 Pin Serial Port Connector to Camera RJ-11 Connector
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4M30 Camera User’s Manual 15
DALSA 03-32-10030-04
!
Serial Communication Settings
Table 9: Serial Port Configuration
Serial Port Configuration
Baud 9600, fixed
Start bits 1
Data bits 8
Stop bits 1
Parity None
The serial interface operates at RS-232 levels with fixed parameters of 9600 baud, 1 start bit, 8
data bits, 1 stop bit, and no parity. The interface uses only three wires, for received data,
transmitted data, and ground. In general writing data must start with a write command byte and be
followed by a data byte. Reading a camera register requires only a single read command byte.
WARNING: Due to initialization sequencing after power-up, no commands should be sent to the
camera for a minimum of 1 second after power up.
Serial Cable Source
The remote interface connector, on the cameras
rear panel, is specified as a low-profile RJ-11
modular connector. The connector is a 6-position
model, but only the center four positions are
populated with contacts. It will mate with either
the 4-position or 6-position cable plugs. This type
of connector typically requires special assembly
tools; complete cable assemblies are available
from suppliers such as Digi-Key:
Digi-Key
701 Brooks Ave. South
Thief River Falls, MN 56701
1-800-344-4539
cable part number:
H2643-14-ND (14 feet)
DALSA provides serial cables in 3 lengths: 10’, 20’ and 50’. Part number CL-31-00004-xx
(where xx refers to the cable length in feet).
2.7 TTL Trigger Input and Output
Connector
The camera uses an SMA connector (labeled TRIGGER IN) to allow the user to provide a standard
TTL signal to control camera integration and readout. The input is high impedance (>10.5K),
allowing the user to terminate at the SMA input as needed. The camera has another SMA
connector (TRIGGER OUT) that provides a standard TTL output which is high whenever the
camera is integrating.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4M30 Camera User’s Manual 16
DALSA 03-32-10030-04
Figure 6: Trigger Timing Description
2.8 Integration Time
The minimum integration time (or shutter time) is 10 µs. As with any full frame imager, the camera
will continue to integrate during read out unless externally shuttered or strobed.
2.9 Timing
The 4M30 pixel clock runs at 40 MHz, so each pixel clock cycle will be 1/40,000,000 or 25ns. The
following diagram and tables describe the correct timing requirements for the 4M30 camera.
Figure 7: 4M30 Timing
VSYNC
Data
HSYNC
PIXEL
CLOCK
123
AB C
CE
DF
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4M30 Camera User’s Manual 17
DALSA 03-32-10030-04
“A” represents the number of falling clock edges from the rising edge of VSYNC to the rising
edge of HSYNC.
“B” represents the number of falling clock edges prior to the first word. (Pre-Scan pixels)
“C” represents the number of words per line.
“D” represents the number of falling clock edges between the last word and the falling edge of
HSYNC. (Post-Scan pixels)
“E” represents the number of falling clock edges between a falling HSYNC and a rising HSYNC.
“F” represents the number of falling clock edges from the falling edge of HSYNC to the falling
edge of VSYNC
Table 10: HSYNC Pixel Timing
Horizontal
Binning Mode A B C D E F
1x 213 18 1024 18 196 2
Table 11: VSYNC Pixel Timing (HSYNC falling edges/VSYNC falling edge)
Vertical
Binning Mode Pre-Scan Lines/Frame Active Lines/Frame Post Scan Lines/Frame
1x 61024 0
IMPORTANT:
Thiscamerausesthe
falling
fallingfalling
falling edgeof thepixel
clocktoregisterdata.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4M30 Camera User’s Manual 18
DALSA 03-32-10030-04
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4M30 Camera User’s Manual 19
DALSA 03-32-10030-04
Serial Port Configuration
Baud 9600, fixed
Start bits 1
Data bits 8
Stop bits 1
Parity None
3
Camera Operation
Camera OperationCamera Operation
Camera Operation
3.1 How to Control the Camera
The 4M30’s RS-232-compatible serial interface allows you to control its configuration and
operation, including:
• Triggering Mode
•FrameRate
• Integration Time
•Gain
• Offset
• Reset
Command Protocol Overview
The camera accepts 8-bit command/value pairs via its
RJ-11 serial port using RS-232 compatible signals.
Camera commands are divided into two basic sets:
• “clock” commands which apply to the electronics
that drive the image sensor. These include clock
generation, frame rate, integration time, and
binning. Clock commands effect the entire
camera, and are not channel specific. A single
command will impact all channels.
• “ADC” commands which apply to the electronics that process and digitize the video. These
include gain and offset. ADC commands are channel specific. Four separate commands must
be issued to change all four channels.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
