Danfoss VLT AutomationDrive FC 360 User manual

MAKING MODERN LIVING POSSIBLE
Quick Guide
VLT®AutomationDrive FC 360
www.danfoss.com/drives

Safety
WARNING
HIGH VOLTAGE
Frequency converters contain high voltage when
connected to AC mains input power. Installation, start
up, and maintenance should be performed by qualified
personnel only. Failure to perform installation, start up,
and maintenance by qualified personnel could result in
death or serious injury.
WARNING
UNINTENDED START
When the frequency converter is connected to AC mains,
the motor may start at any time. The frequency
converter, motor, and any driven equipment must be in
operational readiness. Failure to be in operational
readiness when the frequency converter is connected to
AC mains could result in death, serious injury,
equipment, or property damage.
WARNING
DISCHARGE TIME
Frequency converters contain DC-link capacitors that can
remain charged even when the frequency converter is
not powered. To avoid electrical hazards, disconnect AC
mains, any permanent magnet type motors, and any
remote DC-link power supplies, including battery
backups, UPS and DC-link connections to other
frequency converters. Wait for the capacitors to fully
discharge before performing any service or repair work.
The amount of wait time is listed in the Discharge Time
table. Failure to wait the specified time after power has
been removed before doing service or repair could result
in death or serious injury.
Voltage [V] Minimum waiting time [minutes]
4 15
380-480 0.37-7.5 kW 11-75 kW
High voltage may be present even when the warning LEDs are
off!
Discharge Time
Symbols
The following symbols are used in this manual.
WARNING
Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury. It may
also be used to alert against unsafe practices.
CAUTION
Indicates a situation that may result in equipment
or property-damage-only accidents.
NOTICE
Indicates highlighted information that should be
regarded with attention to avoid mistakes or operate
equipment at less than optimal performance.
Approval
Safety VLT®AutomationDrive FC 360 Quick Guide
MG06A302 - VLT®is a registered Danfoss trademark

Safety VLT®AutomationDrive FC 360 Quick Guide
MG06A302 - VLT®is a registered Danfoss trademark

Contents
1 Quick Start 3
1.1 Identification and Variants 3
1.2 Hand On/Auto On Mode 4
1.3 Application Selections 4
1.4 Jumper Terminal 12 and 27 7
1.5 Automatic Motor Adaptation (AMA) 7
2 Introduction 8
2.1 Exploded Views 8
2.2 Product Overview 9
2.3 Additional Resources 9
2.4 Frame Sizes and Power Ratings 9
3 Installation 10
3.1 Mechanical Installation 10
3.2 Electrical Installation 11
3.2.1 General Requirements 13
3.2.2 Earth (Grounding) Requirements 13
3.2.2.1 Leakage Current (>3.5 mA) 13
3.2.3 Mains, Motor and Earth Connections 14
3.2.4 Control Wiring 14
3.2.4.1 Access 14
3.2.4.2 Control Terminal Types 15
3.2.4.3 Control Terminal Functions 15
3.2.4.4 Using Screened Control Cables 16
3.3 Serial Communication 16
4 User Interface and Programming 18
4.1 Programming 18
4.1.1 Programming with the Numerical Local Control Panel (LCP 21) 18
4.1.2 LCP 21 18
4.1.3 The Right-Key Function 19
4.2 Quick Menu 19
4.3 Main Menu 21
4.4 PM Motor Setup 22
4.5 Parameter List 23
4.5.1 Main Menu Structure 24
5 Wiring Examples 28
6 Warnings and Alarms 31
Contents VLT®AutomationDrive FC 360 Quick Guide
MG06A302 - VLT®is a registered Danfoss trademark 1

6.1 System Monitoring 31
6.2 Warning and Alarm Types 31
6.2.1 Warnings 31
6.2.2 Alarm Trip vs. Alarm Trip Lock 31
6.3 Warning and Alarm Displays 31
6.4 Warning and Alarm Definitions 32
7 Basic Troubleshooting and FAQs 34
7.1 Start Up and Operation 34
8 Specifications 36
8.1 Power-dependent Specifications 36
8.1.1 Mains Supply 3 x 380-480 V AC 36
8.2 General Technical Data 38
8.3 Fuse Specifications 42
8.3.1 Fuses 42
8.3.2 Recommendations 42
8.3.3 CE Compliance 42
8.4 Connection Tightening Torques 43
Index 44
Contents VLT®AutomationDrive FC 360 Quick Guide
2 MG06A302 - VLT®is a registered Danfoss trademark

1 Quick Start
WARNING
Improper use could result in death, serious injury,
equipment, or property damage. Before installing or
using the equipment, carefully read 1 Safety and 3 Instal-
lation!
1.1 Identification and Variants
Confirm that the equipment matches the requirements
and ordering information by checking power size, voltage
and overload data on the name plate of the frequency
converter.
130BC435.11
CHASSIS/IP20
VLT
MADE BY DANFOSS
IN CHINA
AutomationDrive
www.danfoss.com
R
T/C: FC-360HK37T4E20H2BXCDXXSXXXXAXBX
P/N: 134F2970 S/N: 691950A240
0.37 kW 0.5HP High Overload
IN: 3x380-480V 50/60Hz 1.24/0.99A
OUT: 3x0-Vin 0-500Hz 1.2/1.1A(Tamb. 45 C)
o
1
2
3
CAUTION:
SEE MANUAL
WARNING:
AND LAODSHARING BEFORE SERVICE
STORED CHARGE DO NOT TOUCH UNTIL 4 MIN. AFTER
DISCONNECTION
RISK OF ELECTRIC SHOCK-DUAL SUPPLY DISCONNECT MAINS
Illustration 1.1 Name Plate 1 and 2
1 Typecode
2 Ordering number
3 Specifications
Table 1.1 Legend to Illustration 1.1
1-6: Product Name
7: Overload H: Heavy Duty
Q: Normal Duty1)
8-10: Power Size
0.37-75 kW e.g.
K37: 0.37 kW2)
1K1: 1.1 kW
11K: 11 kW etc.
11-12: Voltage Class T4: 380-480 V three phases
13-15: IP Class E20: IP20
16-17: RFI H2: C3 Class
18: Brake chopper X: No
B: Built-in4)
19: LCP X: No
20: PCB Coating C: 3C3
21: Mains terminals D: Load sharing
29-30: Embedded Fieldbus
AX: No
A0: Profibus3)
AL: Profinet3)
Table 1.2 Type Code: Selection of Different Features and Options
See for options and accessories.
1) Only 11-75 kW for normal duty variants. Fieldbus unavailable for
normal duty.
2) For all power sizes see 2.4 Frame Sizes and Power Ratings
3) Not available yet.
4) 0.37-22 kW with built-in brake chopper. 30-75 kW external brake
chopper only.
130BC437.10
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
F C - 3 6 0 H T 4 E 2 0 H 2 X X C D X X S X X X X A X B X
Q B 0
L
A
A
Illustration 1.2 Typecode String
Quick Start VLT®AutomationDrive FC 360 Quick Guide
MG06A302 - VLT®is a registered Danfoss trademark 3
11

1.2 Hand On/Auto On Mode
After installation (see 3 Installation), there are two simple
ways to start up the frequency converter, Hand On and
Auto On mode. At the first power-up it is in auto on mode.
130BD062.10
DHand
On Reset
Auto
On
OK
On
Warn
Alarm
Illustration 1.3 Location of Hand On, Off/Reset and Auto On
keys on the NLCP
•Press [Hand On] to provide a local start command
to the frequency converter. Press [▲] and [▼] to
increase and decrease speed.
•Press [Off/Reset] to stop the frequency converter.
•Press [Auto On] to control the frequency
converter either via control terminals or serial
communication.
CAUTION
Since the frequency converter is in auto on mode at first
power up, the frequency converter may start the motor
directly.
NOTICE
5-12 Terminal 27 Digital Input has coast inverse as default
setting. Connect terminals 12 and 27 to test Hand On/
Auto On running.
For LCP operation, see 4 User Interface and Programming.
1.3 Application Selections
Use the selections for quick application set-up of the most
common applications by setting 0-16 Application Selections.
When necessary, the selections can be modified for
individual needs. All selections are for Auto On mode.
NOTICE
When an application is selected, relevant parameters are
automatically set. Customer specific configuration of all
parameters based on specific requirements is still
possible.
CAUTION
If any of the applications below are selected, relay 1 will
be set to [Running] and relay 2 will be set to [Alarm]
Application
Pumps, fans, compressors
130BC430.10
+24V 12
DI1 18
DI2 19
DI3 27
DI4 29
DI5 32
DI6 33
DI7 31
COM 20
+10V 50
AI1 53
-+
AI2 54
COM 55
AO1 45
AO2 42
1
2
3
4
5
6
R1
R2
FC 360
Start
Coast inverse
Jog
4-20
mA
Description
For applications where a
value (e.g. pressure,
temperature) must be
kept at a desired level by
sensor feedback
Parameter settings
1-00 (Configuration Mode): [3] Process Close Loop
1-03 (Torque Characteristics): [1] Variable Torque
3-00 (Ref Range): [0] Min- Max
3-15 (Ref Source 1): [0] No Function
4-12 (Motor Low Limit): 30.0 Hz
4-14 (Motor High Limit): 50.0 Hz
5-10 (DI 18 Selection): [8] Start
5-12 (DI 27 Selection): [2] Coast Inverse
5-14 (DI 32 Selection): [14] Jog
5-40 (Relay 1 Selection): Running
5-40 (Relay 2 Selection): Alarm
6-22 (AI 54 Low): 4.0 mA
6-23 (AI 54 High): 20.0 mA
6-29 (AI 54 Mode): [0] Current Mode
6-70 (Term 45 Mode): [0] 0-20 mA
6-71 (AO45): [100] Output freq
6-90 (Term 42 Mode): [0] 0-20 mA
6-91 (AO42): [103] Motor current
7-20 (Process CL feedback source): [2] Analog input 54
Table 1.3 [1] Process Closed Loop
Quick Start VLT®AutomationDrive FC 360 Quick Guide
4 MG06A302 - VLT®is a registered Danfoss trademark
11

Application
Local/Remote
130BC431.10
+24V 12
DI1 18
DI2 19
DI3 27
DI4 29
DI5 32
DI6 33
DI7 31
COM 20
+10V 50
AI1 53
-
+
AI2 54
COM 55
AO1 45
AO2 42
1
2
3
4
5
6
R1
R2
FC 360
Start
Coast inverse
Setup select
4-20
mA
Description
For applications
where the speed
reference can be
switched between
local potentiometer
and remote current
signal
Parameter settings Setup 1 Setup 2
0-10 (Active Set-
up)
[9] Multi Set-up [9] Multi Set-up
0-12 (Link Set-up) [20] Linked [20] Linked
1-00 (Configuration
Mode)
[0] Speed Open Loop [0] Speed Open Loop
3-00 (Ref Range) [0] Min- Max [0] Min- Max
3-15 (Ref Source 1) [1] AI 53 [2] AI 54
3-16 (Ref Source 2)
4-12 (Motor Low
Limit)
25.0 Hz 25.0 Hz
4-14 (Motor High
Limit)
50.0 Hz 50.0 Hz
5-10 (DI 18
Selection)
[8] Start [8] Start
5-12 (DI 27
Selection)
[2] Coast Inverse [2] Coast Inverse
5-14 (DI 32
Selection)
[23] Set-up select [23] Set-up select
5-40 (Relay 1
Selection)
Running Running
5-40 (Relay 2
Selection)
Alarm Alarm
6-10 (AI 53 Low) 0.07 V
6-11 (AI 53 High) 10 V
6-19 (AI 53 Mode) [1] Voltage Mode
6-22 (AI 54 Low) 4.0 mA
6-23 (AI 54 High) 20.0 mA
6-29 (AI 54 Mode) [0] Current Mode
6-70 (Term 45
Mode)
[0] 0-20 mA [0] 0-20 mA
6-71 (AO45) [100] Output freq [100] Output freq
6-90 (Term 42
Mode)
[0] 0-20 mA [0] 0-20 mA
6-91 (AO42) [103] Motor current [103] Motor current
Table 1.4 [2] Local/Remote
Application
Conveyors, extruders
130BC432.10
+24V 12
DI1 18
DI2 19
DI3 27
DI4 29
DI5 32
DI6 33
DI7 31
COM 20
+10V 50
AI1 53
AI2 54
COM 55
AO1 45
AO2 42
1
2
3
4
5
6
R1
R2
FC 360
Start
Coast inverse
Description
For running at a stable
speed by a voltage
reference signal.
Parameter settings
1-00 (Configuration Mode): [0] Speed Open Loop
3-00 (Ref Range): [0] Min- Max
3-15 (Ref Source 1): [1] AI 53
4-12 (Motor Low Limit): 25.0 Hz
4-14 (Motor High Limit): 50.0 Hz
5-10 (DI 18 Selection): [8] Start
5-12 (DI 27 Selection): [2] Coast Inverse
5-40 (Relay 1 Selection): Running
5-40 (Relay 2 Selection): Alarm
6-10 (AI 53 Low): 0.07 V
6-11 (AI 53 High): 10 V
6-19 (AI 53 Mode): [1] Voltage Mode
6-70 (Term 45 Mode): [0] 0-20 mA
6-71 (AO45): [100] Output freq
6-90 (Term 42 Mode): [0] 0-20 mA
6-91 (AO42): [103] Motor current
Table 1.5 [3] Speed Open Loop
Quick Start VLT®AutomationDrive FC 360 Quick Guide
MG06A302 - VLT®is a registered Danfoss trademark 5
11

Application
Machine tools, texturizers
130BC433.11
+24 V 12
DI1 18
DI2 19
DI3 27
DI4 29
DI5 32A
DI6 33B
DI7 31
COM 20
50
AI1 53
AI2 54
COM 55
AO1 45
AO2 42
1
2
3
4
5
6
R1
R2
FC 360
Start
Coast inverse
+10 V
Description
For precise speed
applications with 24 V
encoder feedback
Parameter settings
1-00 (Configuration Mode): [1] Speed Close Loop
3-00 (Ref Range): [0] Min- Max
3-15 (Ref Source 1): [1] AI 53
3-16 (Ref Source 2): [11] Local Bus Ref
4-12 (Motor Low Limit): 20.0 Hz
4-14 (Motor High Limit): 50.0 Hz
5-10 (DI 18 Selection): [8] Start
5-12 (DI 27Selection): [2] Coast Inverse
5-14 (DI 32 Selection): [82] Encoder input B
5-15 (DI 33 Selection): [81] Encoder input A
5-40 (Relay 1 Selection): Running
5-40 (Relay 2 Selection): Alarm
6-10 (AI 53 Low): 0.07 V
6-11 (AI 53 High): 10 V
6-19 (AI 53 Mode): [1] Voltage Mode
6-70 (Term 45 Mode): [0] 0-20 mA
6-71 (AO45): [100] Output freq
6-90 (Term 42 Mode): [0] 0-20 mA
6-91 (AO42): [103] Motor current
7-00 (Speed PID Feedback Source): [1] 24 V encoder
Table 1.6 [4] Speed Close Loop
Application
Industrial washing
machines, conveyors
130BC434.10
+24V 12
DI1 18
DI2 19
DI3 27
DI4 29
DI5 32
DI6 33
DI7 31
COM 20
+10V 50
AI1 53
AI2 54
COM 55
AO1 45
AO2 42
1
2
3
4
5
6
R1
R2
FC 360
Start
Coast inverse
Pre set ref bit 0
Pre set ref bit 1
Pre set ref bit 2
Description
For applications with
8 different speeds by
digital input. By using
another digital input,
16 speeds are
possible.
Parameter settings
1-00 (Configuration Mode): [0] Speed Open Loop
3-00 (Ref Range): [0] Min- Max
3-15 (Ref Source 1): [0] No Function
4-14 (Motor High Limit): 50.0 Hz
5-10 (DI 18 Selection): [8] Start
5-12 (DI 27 Selection): [2] Coast Inverse
5-13 (DI 29 Selection): [16] Preset ref bit 0
5-14 (DI 32 Selection): [17] Preset ref bit 1
5-15 (DI 23 Selection): [18] Preset ref bit 2
6-70 (Term 45 Mode): [0] 0-20 mA
6-71 (AO45): [100] Output freq
6-90 (Term 42 Mode): [0] 0-20 mA
6-91 (AO42): [103] Motor current
Table 1.7 [5] Multi-speed
NOTICE
For further examples, refer to 5 Wiring Examples.
Quick Start VLT®AutomationDrive FC 360 Quick Guide
6 MG06A302 - VLT®is a registered Danfoss trademark
11

1.4 Jumper Terminal 12 and 27
When using factory default programming values, jumper
wire may be required between terminal 12 and terminal 27
for the frequency converter to operate.
•Digital input terminal 27 is designed to receive an
24 V DC external interlock command. In many
applications, the user wires an external interlock
device to terminal 27
•When no interlock device is used, wire a jumper
between control terminal 12 to terminal 27. This
provides internal 24 V signal on terminal 27
•No signal present prevents the unit from
operating
1.5 Automatic Motor Adaptation (AMA)
Automatic motor adaptation (AMA)
It is highly recommended to run AMA because it measures
the electrical characteristics of the motor to optimize
compatibility between the frequency converter and the
motor under VVCplus mode.
•The frequency converter builds a mathematical
model of the motor for regulating output motor
current thus enhancing motor performance.
•Some motors may be unable to run the complete
version of the test. In that case, select Enable
reduced AMA
•If warnings or alarms occur, see 6 Warnings and
Alarms
•Run this procedure on a cold motor for best
results
To run AMA using the numeric LCP (NLCP)
1. By default parameter setting, connect terminal 12
and 27 before running AMA.
2. Enter the main menu.
3. Go to parameter group 1-** Load and Motor.
4. Press [OK].
5. Set motor parameters using name plate data for
parameter group J1-1-2* Motor Data.
6. Set motor cable length in 1-42 Motor Cable Length
7. Go to 1-29 Automatic Motor Adaptation (AMA).
8. Press [OK].
9. Select [1] Enable complete AMA.
10. Press [OK].
11. The test will run automatically and indicate when
it is complete.
NOTICE
AMA function in FC 360 does not cause the motor
to run and it does not harm the motor.
Quick Start VLT®AutomationDrive FC 360 Quick Guide
MG06A302 - VLT®is a registered Danfoss trademark 7
11

2 Introduction
2.1 Exploded Views
130BC439.10
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
03
02
01
05
04
Illustration 2.1 Exploded View J1-J5 (0.37-22 kW), IP20
1NLCP (accessory) 10 2-Pole Relay 2 (0.37-7.5 kW)
3-Pole Relay 2 (11-22 kW)
2 Control cassette 11 Mains terminal
3 RFI switch (screw M3x12 only) 12 Cable strain relief (0.37-2.2 kW: accessory)
4 Removable fan assembly 13 RS-485 com pluggable terminal
5 Grounding clamp (accessory) 14 Fixed I/O terminals
6 Shielded cable grounding clamp and strain relief
(accessory)
15 Fixed I/O terminals
7 Motor terminal (U V W) and brake and load sharing
terminal
16 Terminal cover
8 PE ground 17 Option-B (MCB102/103 accessories)
9 3-Pole relay 1
Table 2.1 Legend to Illustration 2.1
Introduction VLT®AutomationDrive FC 360 Quick Guide
8 MG06A302 - VLT®is a registered Danfoss trademark
22

2.2 Product Overview
A frequency converter is an electronic motor controller
that converts AC mains input into a variable AC waveform
output. The frequency and voltage of the output are
regulated to control the motor speed or torque. The
frequency converter can vary the speed of the motor in
response to system feedback, such as changing
temperature or pressure for controlling fan, compressor, or
pump motors. The frequency converter can also regulate
the motor by responding to remote commands from
external controllers.
In addition, the frequency converter monitors the system
and motor status, issues warnings or alarms for fault
conditions, starts and stops the motor, optimizes energy
efficiency, and offers many more control, monitoring, and
efficiency functions. Operation and monitoring functions
are available as status indications to an outside control
system or serial communication network.
2.3 Additional Resources
Other resources are available to understand advanced
frequency converter functions and programming.
•The Programming Guide provides greater detail
on working with parameters.
•The Design Guide is intended to provide detailed
capabilities and functionality to design motor
control systems.
•Optional equipment is available that may change
some of the procedures described. Be sure to see
the instructions supplied with those options for
specific requirements.
Contact the local Danfoss supplier or go to
www.danfoss.com/Products/Literature/VLT+Technical
+Documentation.htm for downloads.
2.4 Frame Sizes and Power Ratings
Frame size
380-480 V J1 J2 J3 J4 J5 J6 J7
Power size
[kW]
0.37-2.2 3.0-5.5 7.5 11-15 18.5-22 30-45 55-75
Dimensions
[mm]
A
a
D
C
B
b
130BC449.10
Height A 210 272.5 272.5 317.5 410 520 550
Width B 75 90 115 133 150 233 308
Depth C
(with option B) 168 (181) 168 (181) 168 (181) 245 (258) 245 (258) 242 332
Mounting holes
a 198 260 260 297.5 390
b 60 70 90 105 120
Mounting screw M4 M5 M5 M6 M6
Table 2.2 Frames Sizes, Power Ratings and Dimensions
Introduction VLT®AutomationDrive FC 360 Quick Guide
MG06A302 - VLT®is a registered Danfoss trademark 9
22

3 Installation
3.1 Mechanical Installation
Select the best possible operation site by considering:
•Ambient operating temperature
•Installation method
•How to cool the unit
•Position of the frequency converter
•Cable routing
•Power source supplying correct voltage and
necessary current
•Motor current rating within the maximum current
from the frequency converter
•Correct rating of external fuses and circuit
breakers
Cooling and Mounting:
•Top and bottom clearance for air cooling must be
provided, see Table 3.1 for clearance requirements
•Derating for temperatures starting from 45 °C
and elevation 1000 m above sea level must be
considered. See the equipment Design Guide for
detailed information.
Enclosure J1-J5 J6/J7
Clearance above and below the
unit [mm] 100 100-200
Table 3.1 Minimum Airflow Clearance Requirements
•Mount the unit vertically
•IP20 units (but NOT IP21 units) allow side-by-side
installation
•Improper mounting can result in over heating
and reduced performance
•Use the slotted mounting holes on the unit for
wall mounting, when provided
•See 8.4 Connection Tightening Torques for proper
tightening specifications.
Installation VLT®AutomationDrive FC 360 Quick Guide
10 MG06A302 - VLT®is a registered Danfoss trademark
33

3.2 Electrical Installation
This section contains detailed instructions for wiring the frequency converter.
130BC438.12
3 Phase
power
input
Switch Mode
Power Supply
Motor
Analog Output
Interface
(PNP) = Source
(NPN) = Sink
ON=Terminated
OFF=Open
Brake
resistor
91 (L1)
92 (L2)
93 (L3)
PE
50 (+10 V OUT)
53 (A IN)
54 (A IN)
55 (COM A IN)
0/4-20 mA
12 (+24 V OUT)
31 (D IN)
18 (D IN)
20 (COM D IN)
10 V DC
15 mA 100 mA
+ - + -
(U) 96
(V) 97
(W) 98
(PE) 99
(A OUT) 45
(A OUT) 42
(P RS-485) 68
(N RS-485) 69
(COM RS-485) 61
0V
5V
S801
0/4-20 mA
RS-485
RS-485
03
+10 V DC
0/4-20 mA
0-10 V DC
24 V DC
02
01
05
04
240 V AC, 2 A
24 V (NPN)
0 V (PNP)
0 V (PNP)
24 V (NPN)
19 (D IN)
24 V (NPN)
0 V (PNP)
27
24 V
0 V
(D IN/OUT)
0 V (PNP)
24 V (NPN)
(D IN/OUT)
0 V
24 V
29
24 V (NPN)
0 V (PNP)
0 V (PNP)
24 V (NPN)
33 (D IN)
32 (D IN)
95
P 5-00
21
ON
(+UDC) 82
(BR) 81
24 V (NPN)
0 V (PNP)
0-10 V DC
(-UDC) 88
RFI
3)
0 V
240 V AC, 2 A
Relay 1
1)
Relay 2 2)
4)
06
Illustration 3.1 Basic Wiring Schematic Drawing
A=Analog, D=Digital
1) Built-in brake chopper available from 0.37-22 kW
2) Relay 2 is 2-pole for J1-J3 and 3-pole for J4-J7. Relay 2 of J4-J7 with terminals 4, 5 and 6 same NO/NC logic as Relay 1.
3) Dual DC choke in 30-75 kW
4) Switch S801 (bus terminal) can be used to enable termination on the RS-485 port (terminals 68 and 69).
Installation VLT®AutomationDrive FC 360 Quick Guide
MG06A302 - VLT®is a registered Danfoss trademark 11
33

130BD391.11
1
2
3
4
5
6
78
910
Reset Auto
On
Hand
On
OK
Back
Menu
Status Quick
Menu
Main
Menu
PE
U
V
W
L1
L2
L3
PE
Illustration 3.2 Typical Electrical Connection
1PLC 6 Min. 200 mm (7.9 in) between control cables, motor and mains
2 Frequency converter 7 Motor, 3-phase and PE
3 Output contactor (Generally not recommended) 8 Mains, 3-phase and reinforced PE
4 Earth (grounding) rail (PE) 9 Control wiring
5 Cable insulation (stripped) 10 Equalising min. 16 mm2(0.025 in)
Table 3.2 Legend to Illustration 3.2
Installation VLT®AutomationDrive FC 360 Quick Guide
12 MG06A302 - VLT®is a registered Danfoss trademark
33

3.2.1 General Requirements
WARNING
EQUIPMENT HAZARD!
Rotating shafts and electrical equipment can be
hazardous. Extreme care should be taken to protect
against electrical hazards when applying power to the
unit. All electrical work must conform to national and
local electrical codes and installation, start up, and
maintenance should only be performed by trained and
qualified personnel. Failure to follow these guidelines
could result in death or serious injury.
CAUTION
WIRING ISOLATION!
Run input power, motor wiring and control wiring in
three separate metallic conduits or use separated
shielded cable for high frequency noise isolation. Failure
to isolate power, motor and control wiring could result
in less than optimum frequency converter and associated
equipment performance.
Run motor cables from multiple frequency converters
separately. Induced voltage from output motor cables
run together can charge equipment capacitors even with
the equipment turned off and locked out.
•An electronically activated function within the
frequency converter provides overload protection
for the motor. The overload provides Class 20
motor protection. See 6 Warnings and Alarms for
details on the trip function.
Wire Type and Ratings
•All wiring must comply with local and national
regulations regarding cross-section and ambient
temperature requirements.
•Danfoss recommends that all power connections
be made with a minimum 75 °C rated copper
wire.
•See 8 Specifications for recommended wire sizes.
3.2.2 Earth (Grounding) Requirements
WARNING
GROUNDING HAZARD!
For operator safety, it is important to ground the
frequency converter properly by a certified electrical
installer in accordance with national and local electrical
codes as well as instructions contained within this
document. Ground currents are higher than 3.5 mA.
Failure to ground the frequency converter properly could
result in death or serious injury.
•Proper protective grounding for equipment with
ground currents higher than 3.5 mA must be
established, see 3.2.2.1 Leakage Current (>3.5 mA)
•A dedicated ground wire is required for input
power, motor power and control wiring
•Use the clamps provided with the equipment for
proper ground connections
•Do not ground one frequency converter to
another in a “daisy chain” fashion (see
Illustration 3.3)
•Keep the ground wire connections as short as
possible
•Using high-strand wire to reduce electrical noise
is recommended
•Follow motor manufacturer wiring requirements
130BC500.10
FC 1
FC 1
FC 2
FC 2
FC 3
FC 3
PE
PE
Illustration 3.3 Grounding Principle
3.2.2.1 Leakage Current (>3.5 mA)
Follow national and local codes regarding protective
earthing of equipment with a leakage current > 3.5 mA.
The earth leakage current depends on various system
configurations including RFI filtering, screened motor
cables, and frequency converter power.
EN/IEC61800-5-1 (Power Drive System Product Standard)
requires special care if the leakage current exceeds 3.5 mA.
Earth grounding must be reinforced in one of the
following ways:
Installation VLT®AutomationDrive FC 360 Quick Guide
MG06A302 - VLT®is a registered Danfoss trademark 13
33

•Earth ground wire of at least 10 mm2(copper
wire)
•Two separate earth ground wires both complying
with the dimensioning rules
See EN 60364-5-54 § 543.7 for further information.
Using RCDs
Where residual current devices (RCDs), also known as earth
leakage circuit breakers (ELCBs), are used, comply with the
following:
•Use RCDs of type B only which are capable of
detecting AC and DC currents
•Use RCDs with an inrush delay to prevent faults
due to transient earth currents
•Dimension RCDs according to the system configu-
ration and environmental considerations
3.2.3 Mains, Motor and Earth Connections
WARNING
INDUCED VOLTAGE!
Run output motor cables from multiple frequency
converters separately. Induced voltage from output
motor cables run together can charge equipment
capacitors even with the equipment turned off and
locked out. Failure to run output motor cables separately
could result in death or serious injury.
Earthing (grounding) clamps are provided for motor wiring
(see Illustration 3.4).
•Do not install power factor correction capacitors
between the frequency converter and the motor
•Do not wire a starting or pole-changing device
between the frequency converter and the motor
•Follow motor manufacturer wiring requirements
•All frequency converters may be used with an
isolated input source as well as with ground
reference power lines. When supplied from an
isolated mains source (IT mains or floating delta)
or TT/TN-S mains with a grounded leg (grounded
delta), set 14-50 RFI Filter to OFF (size J6-J7) or
remove the RFI screw (J1-J5). When off, the
internal RFI filter capacitors between the chassis
and the intermediate circuit are isolated to avoid
damage to the intermediate circuit and to reduce
earth capacity currents in accordance with IEC
61800-3.
•Do not install switch between the frequency
converter and the motor in IT mains.
130BC501.10
01 02 03 04 05
Illustration 3.4 Mains, Motor and Earth Connections
Illustration 3.4 represents mains input, motor, and earth
grounding for basic frequency converters. Actual configu-
rations vary with unit types and optional equipment.
3.2.4 Control Wiring
3.2.4.1 Access
•Remove access cover plate with a screw driver.
See Illustration 3.5.
130BC504.10
Illustration 3.5 Control Wiring Access for J1-J7 Enclosures
Installation VLT®AutomationDrive FC 360 Quick Guide
14 MG06A302 - VLT®is a registered Danfoss trademark
33

3.2.4.2 Control Terminal Types
Illustration 3.6 shows the frequency converter control
terminals. Terminal functions and default settings are
summarized in Table 3.3.
42 45
12
18 19 27 29 31 32 33 20 50 53 54 55
130BC505.12
Illustration 3.6 Control Terminal Locations
See 8.2 General Technical Data for terminal ratings details.
Termi
nal
Param
eter
Default
setting Description
Digital I/O, Pulse I/O, Encoder
12 - +24 V DC
24 V DC supply voltage.
Maximum output current is
100 mA for all 24 V loads.
18 5-10 [8] Start Digital inputs.
19 5-11 [10] Reversing
31 5-16 [0] No operation Digital input, pulse input.
32 5-14 [0] No operation Digital input, 24 V encoder.
33 5-15 [0] No operation
27 5-12
5-30
DI [2] Coast
inverse
DO [0] No
operation
Selectable for either digital
input, digital output or
pulse output. Default
setting is digital input.
29 5-13
5-31
DI [14] Jog
DO [0] No
operation
20 -
Common for digital inputs
and 0 V potential for 24 V
supply.
Analog inputs/outputs
42 6-91 [0] No operation Programmable analog
output. The analog signal
is 0-20 mA or 4-20 mA at a
maximum of 500 Ω. Can
also be configured as
digital outputs
45 6-71 [0] No operation
Termi
nal
Param
eter
Default
setting Description
50 - +10 V DC
10 V DC analog supply
voltage. 15 mA maximum
commonly used for
potentiometer or
thermistor.
53 6-1* Reference Analog input. Selectable
for voltage or current.54 6-2* Feedback
55 - Common for analog input
Serial communication
61 -
Integrated RC-Filter for
cable screen. ONLY for
connecting the screen
when experiencing EMC
problems.
68 (+) 8-3* RS-485 Interface. A control
card switch is provided for
termination resistance.
69 (-) 8-3*
Relays
01, 02,
03 5-40 [0] [0] No operation Form C relay output. These
relays are in various
locations depending upon
the frequency converter
configuration and size.
Usable for AC or DC
voltage and resistive or
inductive loads.
RO2 in J1-J3 enclosure is 2-
pole, only terminals 04 and
05 are available
04, 05,
06 5-40 [1] [0] No operation
Table 3.3 Terminal Descriptions
3.2.4.3 Control Terminal Functions
Frequency converter functions are commanded by
receiving control input signals.
•Each terminal must be programmed for the
function it will be supporting in the parameters
associated with that terminal. See Table 3.3 for
terminals and associated parameters.
•It is important to confirm that the control
terminal is programmed for the correct function.
See 4 User Interface and Programming for details
on accessing parameters and for details on
programming.
•The default terminal programming is intended to
initiate frequency converter functioning in a
typical operational mode.
Installation VLT®AutomationDrive FC 360 Quick Guide
MG06A302 - VLT®is a registered Danfoss trademark 15
33

3.2.4.4 Using Screened Control Cables
Correct screening
The preferred method in most cases is to secure control
and serial communication cables with screening clamps
provided at both ends to ensure best possible high
frequency cable contact.
If the earth potential between the frequency converter and
the PLC is different, electric noise may occur that will
disturb the entire system. Solve this problem by fitting an
equalizing cable as close as possible to the control cable.
Minimum cable cross section: 16 mm2.
1
2
PE
FC
PE
PLC
130BB922.12
PE PE
<10 mm
Illustration 3.7 Screening Clamps at Both Ends
1Min. 16 mm2
2 Equalizing cable
Table 3.4 Legend to Illustration 3.7
50/60 Hz ground loops
With very long control cables, ground loops may occur. To
eliminate ground loops, connect one end of the screen-to-
ground with a 100 nF capacitor (keeping leads short).
100nF
FC
PE PE
PLC
<10 mm
130BB609.12
Illustration 3.8 Connection with a 100 nF Capacitor
Avoid EMC noise on serial communication
This terminal is connected to earth via an internal RC link.
Use twisted-pair cables to reduce interference between
conductors. The recommended method is in Illustration 3.9:
PE
FC
PE
FC
130BB923.12
PE PE
69
68
61
69
68
61
1
2
<10 mm
Illustration 3.9 Twisted-pair Cables
1Min. 16 mm2
2 Equalizing cable
Table 3.5 Legend to Illustration 3.9
Alternatively, the connection to terminal 61 can be
omitted:
PE
FC
PE
FC
130BB924.12
PE PE
69
69
68
68
1
2
<10 mm
Illustration 3.10 Twisted-pair Cables without Terminal 61
1Min. 16 mm2
2 Equalizing cable
Table 3.6 Legend to Illustration 3.10
3.3 Serial Communication
Connect RS-485 serial communication wiring to terminals
(+)68 and (-)69.
•Screened serial communication cable is
recommended
•See 3.2.2 Earth (Grounding) Requirements for
proper grounding
61
68
69
+
130BB489.10
RS-485
Illustration 3.11 Serial Communication Wiring Diagram
Installation VLT®AutomationDrive FC 360 Quick Guide
16 MG06A302 - VLT®is a registered Danfoss trademark
33
