Danfoss VLT Micro Drive FC 51 Series User manual

Operating Guide
VLT® Micro Drive FC 51
Without RFI filter
drives.danfoss.com

1
1.1
1.2
1.3
1.4
1.5
1.6
2
2.1
2.2
2.3
2.4
3
3.1
3.2
3.3
3.4
3.5
3.5.1
3.5.2
3.5.3
3.5.4
3.5.5
3.6
3.7
3.8
3.9
4
4.1
4.2
4.2.1
4.2.2
5
5.1
Contents
Introduction 5
Purpose of this Operating Guide 5
Trademarks 5
Additional Resources 5
Type Approvals and Certications 5
IT Mains 5
Disposal 5
Safety 6
Safety Symbols 6
Qualied Personnel 6
Safety Precautions 6
Safety Instructions 8
Installation 9
Before Commencing Repair Work 9
Side-by-side Installation 9
Mechanical Dimensions 9
Tightening of Terminals 10
Fuses 10
Branch Circuit Protection 10
Short-circuit Protection 10
Overcurrent Protection 10
Non-UL Compliance 10
Recommendation of Fuses 11
Connecting to Mains and Motor 11
Control Terminals 12
Power Circuit 15
Load Sharing/Brake 15
Programming 17
Local Control Panel (LCP) 17
Programming on Automatic Motor Tuning (AMT) 18
Mode 1 18
Mode 2 18
Parameter Overview 19
Parameter List 19
AQ348848915086en-000101/130R0943 | 3Danfoss A/S © 2020.09
Contents
VLT® Micro Drive FC 51
Operating Guide

6
6.1
7
7.1
7.2
8
8.1
8.2
8.3
8.4
8.5
8.6
8.7
8.8
8.9
8.10
8.11
8.12
9
9.1
9.2
9.3
10
10.1
Troubleshooting 24
Warnings and Alarms 24
Specications 26
Mains Supply 1x200–240 V AC 26
Mains Supply 3x380–480 V AC 26
General Technical Data 29
Protection and Features 29
Mains Supply (L1/L, L2, L3/N) 29
Motor Output (U, V, W) 29
Cable Length and Cross-section 29
Digital Inputs (Pulse/encoder Inputs) 29
Analog Inputs 30
Analog Outputs 30
Control Card, RS485 Serial Communication 30
Control Card, 24 V DC Output 30
Relay Output 30
Control Card, +10 V DC Output 31
Surroundings 31
Special Conditions 32
Derating for Ambient Temperature 32
Derating for Low Air Pressure 32
Derating for Running at Low Speeds 32
Options and Spare Parts 33
Options and Spare Parts 33
AQ348848915086en-000101/130R09434 | Danfoss A/S © 2020.09
Contents
VLT® Micro Drive FC 51
Operating Guide

•
•
•
1 Introduction
1.1 Purpose of this Operating Guide
This Operating Guide provides information for safe installation and commissioning of the product. It is intended for use by qualied
personnel. Read and follow the instructions to use the drive safely and professionally. Pay particular attention to the safety instruc-
tions and general warnings. Always keep this Operating Guide available with the drive.
1.2 Trademarks
VLT®is a registered trademark for Danfoss A/S.
1.3 Additional Resources
Other resources are available to understand advanced drive functions and programming.
The Programming Guide provides greater detail on working with parameters and many application examples.
The Design Guide provides detailed information about capabilities and functionality to design motor control systems.
Instructions for operation with optional equipment and replacement of components.
Supplementary publications and manuals are available at: www.danfoss.com.
1.4 Type Approvals and Certications
1.5 IT Mains
NOTICE
IT MAINS
Installation on isolated mains source, that is IT mains. Maximum supply voltage allowed when connected to mains: 440 V.
As an option, Danfoss oers recommended line lters for improved harmonics performance. See chapter Options and Spare Parts.
1.6 Disposal
Do not dispose of equipment containing electrical components together with domestic waste.
Collect it separately in accordance with local and currently valid legislation.
AQ348848915086en-000101 / 130R0943 | 5Danfoss A/S © 2020.09
Introduction
VLT® Micro Drive FC 51
Operating Guide

•
•
•
•
-
-
-
-
2 Safety
2.1 Safety Symbols
The following symbols are used in this manual:
DANGER
Indicates a hazardous situation which, if not avoided, will result in death or serious injury.
WARNING
Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION
Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
NOTICE
Indicates information considered important, but not hazard-related (for example, messages relating to property damage).
2.2 Qualied Personnel
To allow trouble-free and safe operation of the unit, only qualied personnel with proven skills are allowed to transport, store, as-
semble, install, program, commission, maintain, and decommission this equipment.
Persons with proven skills:
Are qualied electrical engineers, or persons who have received training from qualied electrical engineers and are suitably ex-
perienced to operate devices, systems, plant, and machinery in accordance with pertinent laws and regulations.
Are familiar with the basic regulations concerning health and safety/accident prevention.
Have read and understood the safety guidelines given in all manuals provided with the unit, especially the instructions given in
the Operating Guide.
Have good knowledge of the generic and specialist standards applicable to the specic application.
2.3 Safety Precautions
WARNING
HIGH VOLTAGE
AC drives contain high voltage when connected to AC mains input, DC supply, or load sharing. Failure to perform installation,
start-up, and maintenance by qualied personnel can result in death or serious injury.
Only qualied personnel must perform installation, start-up, and maintenance.
WARNING
UNINTENDED START
When the drive is connected to the AC mains, DC supply, or load sharing, the motor may start at any time, causing risk of death,
serious injury, and equipment or property damage. The motor may start by activation of an external switch, a eldbus command,
an input reference signal from the LCP or LOP, via remote operation using MCT 10 Set-up software, or after a cleared fault condi-
tion.
Press [O] on the LCP before programming parameters.
Disconnect the drive from the mains whenever personal safety considerations make it necessary to avoid unintended motor
start.
Check that the drive, motor, and any driven equipment are in operational readiness.
AQ348848915086en-000101 / 130R09436 | Danfoss A/S © 2020.09
Safety
VLT® Micro Drive FC 51
Operating Guide

•
•
•
•
•
-
-
-
-
NOTICE
The [O/Reset] key is not a safety switch. It does not disconnect the drive from mains.
WARNING
DISCHARGE TIME
The drive contains DC-link capacitors, which can remain charged even when the drive is not powered. High voltage can be
present even when the warning indicator lights are o.
Failure to wait the specied time after power has been removed before performing service or repair work could result in death or
serious injury.
Stop the motor.
Disconnect AC mains, permanent magnet type motors, and remote DC-link supplies, including battery back-ups, UPS, and
DC-link connections to other drives.
Wait for the capacitors to discharge fully. The minimum waiting time is specied in the table Discharge time and is also visible
on the nameplate on top of the drive.
Before performing any service or repair work, use an appropriate voltage measuring device to make sure that the capacitors
are fully discharged.
Table 1: Discharge Time
Size
Minimum waiting time (minutes)
M1, M2, and M3
4
M4 and M5
15
Leakage current (>3.5 mA)
Follow national and local codes regarding protective earthing of equipment with a leakage current >3.5 mA. AC drive technology
implies high frequency switching at high power. This generates a leakage current in the ground connection. A fault current in the
drive at the output power terminals might contain a DC component, which can charge the lter capacitors and cause a transient
ground current. The ground leakage current depends on various system congurations including RFI ltering, shielded motor ca-
bles, and drive power.
EN/IEC61800-5-1 (Power Drive System Product Standard) requires special care if the leakage current exceeds 3.5 mA. Reinforce
Grounding in 1 of the following ways:
Grounding wire of at least 10 mm2(8 AWG).
2 separate ground wires both complying with the dimensioning rules.
See EN 60364-5-54 § 543.7 for further information.
Using RCDs
Where residual current devices (RCDs), also known as earth leakage circuit breakers (ELCBs), are used, comply with the following:
Use RCDs of type B that can detect AC and DC currents.
Use RCDs with an inrush delay to prevent faults due to transient ground currents.
Dimension RCDs according to the system conguration and environmental considerations.
Motor thermal protection
Motor overload protection is possible by setting parameter 1-90 Motor Thermal Protection to [4] ETR trip. For the North American
market: Implemented ETR function provides class 20 motor overload protection, in accordance with NEC.
Installation at high altitudes
For altitudes above 2000 m (6562 ft), contact Danfoss regarding PELV.
AQ348848915086en-000101 / 130R0943 | 7Danfoss A/S © 2020.09
Safety
VLT® Micro Drive FC 51
Operating Guide

•
•
•
•
2.4 Safety Instructions
Make sure that the drive is properly grounded.
Do not remove mains connections, motor connections, or other power connections while the drive is connected to power.
Protect users against supply voltage.
Protect the motor against overloading according to national and local regulations.
AQ348848915086en-000101 / 130R09438 | Danfoss A/S © 2020.09
Safety
VLT® Micro Drive FC 51
Operating Guide

1.
2.
3.
4.
3 Installation
3.1 Before Commencing Repair Work
Procedure
Disconnect the VLT® Micro DriveFC 51 from mains (and external DC supply, if present).
Wait for 4 minutes (M1, M2, and M3) and 15 minutes (M4 and M5) for discharge of the DC-link.
Disconnect the DC bus terminals and the brake terminals (if present).
Remove the motor cable.
3.2 Side-by-side Installation
The drive can be mounted side by side for IP20 rating units and requires 100 mm (3.9 in) clearance above and below for cooling.
Refer to chapter Specications for details on environmental ratings of the drive.
3.3 Mechanical Dimensions
A template for drilling is found on the ap of the packaging.
B
a
Aa A
a A
a A a A
C
CC C C
b
B
b
B
b
B
b
B
b
Ø 7mm
M5
M4
M3
M2
M1
Ø 7mm Ø 5.5mm Ø 4.5mm
e30bb321.11
Ø 4.5mm
Illustration 1: Mechanical Dimensions
Table 2: Mechanical Dimensions
Power [kW (hp)]
Height [mm (in)]
Width [mm (in)]
Depth
[mm (in)](1)
Maxi-
mum
weight
Enclo-
sure
1x200–240
V
3x380–480 V
A
A (including
decoupling
plate)
a
B
b
C
[kg]
M1
0.18–0.75
(0.24–1.0)
0.37–0.75 (0.5–
1.0)
150 (5.9)
205 (8.1)
140.4
(5.5)
70 (2.8)
55 (2.2)
148 (5.8)
1.0
M2
1.5 (2.0)
1.5–2.2 (2.0–
3.0)
176 (6.9)
230 (9.1)
166.4
(6.6)
75 (3.0)
59 (2.3)
168 (6.6)
1.5
M3
2.2 (3.0)
3.0–7.5 (4.0–
10)
239 (9.4)
294 (11.6)
226 (8.9)
90 (3.5)
69 (2.7)
194 (7.6)
2.8
M4
–
11.0–15.0 (15–
20)
292 (11.5)
347.5 (13.7)
272.4
(10.7)
125 (4.9)
97 (3.8)
241 (9.5)
5.6
AQ348848915086en-000101 / 130R0943 | 9Danfoss A/S © 2020.09
Installation
VLT® Micro Drive FC 51
Operating Guide

Power [kW (hp)]
Height [mm (in)]
Width [mm (in)]
Depth
[mm (in)](1)
Maxi-
mum
weight
M5
–
18.5–22.0 (25–
30)
335 (13.2)
387.5 (15.3)
315 (12.4)
165 (6.5)
140 (5.5)
248 (9.8)
9.1
1For LCP with potentiometer, add 7.6 mm (0.3 in).
3.4 Tightening of Terminals
NOTICE
All cabling must comply with national and local regulations on cable cross-sections and ambient temperature. Copper conduc-
tors required, 60–75 °C (140–167 °F) recommended.
Table 3: Tightening of Terminals
Power [kW (hp)]
Torque [Nm (in-lb)]
Enclo-
sure
1x200–240 V
3x380–480 V
Line
Motor
DC connection/
brake
Control termi-
nals
Ground
Relay
M1
0.18–0.75
(0.24–1.0)
0.37–0.75
(0.5–1.0)
0.8 (7.1)
0.7 (6.2)
Spade(1)
0.15 (1.3)
3 (26.6)
0.5 (4.4)
M2
1.5 (2.0)
1.5–2.2 (2.0–3.0)
0.8 (7.1)
0.7 (6.2)
Spade(1)
0.15 (1.3)
3 (26.6)
0.5 (4.4)
M3
2.2 (3.0)
3.0–7.5 (4.0–10)
0.8 (7.1)
0.7 (6.2)
Spade(1)
0.15 (1.3)
3 (26.6)
0.5 (4.4)
M4
–
11.0–15.0 (15–20)
1.3 (11.5)
1.3 (11.5)
1.3 (11.5)
0.15 (1.3)
3 (26.6)
0.5 (4.4)
M5
–
18.5–22.0 (25–30)
1.3 (11.5)
1.3 (11.5)
1.3 (11.5)
0.15 (1.3)
3 (26.6)
0.5 (4.4)
1Spade connectors (6.3 mm (0.25 in) Faston plugs).
3.5 Fuses
3.5.1 Branch Circuit Protection
To prevent re hazards, protect the branch circuits in an installation, switch gear, machines, and so on, against short circuits and
overcurrent. Follow national and local regulations.
3.5.2 Short-circuit Protection
Use the Danfoss recommended fuses to protect service personnel or other equipment if there is an internal failure in the unit or
short circuit on DC-link. If there is a short circuit on the motor or brake output, the drive provides full short-circuit protection.
3.5.3 Overcurrent Protection
To avoid overheating of the cables in the installation, provide overload protection. Always carry out overcurrent protection accord-
ing to national regulations. Fuses must be designed for protection in a circuit capable of supplying a maximum of 100000 Arms
(symmetrical), 480 V maximum.
3.5.4 Non-UL Compliance
If UL/cUL is not to be complied with, use the fuses mentioned in this chapter, which ensure compliance with EN50178/IEC61800-5-1.
If there is a malfunction, not following the fuse recommendation may result in damage to the drive and the installation.
AQ348848915086en-000101 / 130R094310 | Danfoss A/S © 2020.09
Installation
VLT® Micro Drive FC 51
Operating Guide

3.5.5 Recommendation of Fuses
Table 4: Fuses
FC 51
Maximum fuses non–UL
kW
Type gG
1x200–240 V
0K18–0K37
16A
0K75
25A
1K5
35A
2K2
50A
3x380–480 V
0K37–0K75
10A
1K5
16A
2K2
20A
3K0
40A
4K0
40A
5K5
40A
7K5
40A
11K0
63A
15K0
63A
18K5
80A
22K0
80A
3.6 Connecting to Mains and Motor
The drive is designed to operate all standard 3-phased asynchronous motors.
The drive is designed to accept mains/ motor cables with a maximum cross-section of 4 mm2/10 AWG (M1, M2, and M3), and a
maximum cross-section of 16 mm2/6 AWG (M4 and M5).
AQ348848915086en-000101 / 130R0943 | 11Danfoss A/S © 2020.09
Installation
VLT® Micro Drive FC 51
Operating Guide

•
•
•
•
•
•
•
Use a shielded/armored motor cable to comply with EMC emission specications, and connect this cable to both the decou-
pling plate and the motor metal.
Keep motor cable as short as possible to reduce the noise level and leakage currents.
For further details on mounting of the decoupling plate, see VLT® Micro DriveFC 51 Decoupling Mounting Plate Instructions.
Also see the chapter EMC-correct Electrical Installation in the VLT® Micro DriveFC 51 Design Guide.
Mounting of Ground Cable, Mains, and Motor Wires
e30ba472.10
Illustration 2: Mounting of Ground Cable, Mains, and Motor Wires
Mount the ground wires to PE terminal.
Connect motor to terminals U, V, and W.
Mount mains supply to terminals L1/L, L2, and L3/N (3-phase) or L1/L and L3/N (single-phase) and tighten.
3.7 Control Terminals
All control cable terminals are located underneath the terminal cover in front of the drive. Remove the terminal cover using a screw-
driver.
e30ba477.11
Illustration 3: Removing Terminal Cover
AQ348848915086en-000101 / 130R094312 | Danfoss A/S © 2020.09
Installation
VLT® Micro Drive FC 51
Operating Guide

NOTICE
See the back of the terminal cover for outlines of control terminals and switches.
NOTICE
Do not operate switches with power on the drive.
NOTICE
Set parameter 6-19 Terminal 53 Mode according to Switch 4 position.
Table 5: Settings for S200 Switches 1–4
Switch 1
O=PNP terminals 29(1)
On=NPN terminals 29
Switch 2
O=PNP terminal 18, 19, 27, and 33(1)
On=NPN terminal 18, 19, 27, and 33
Switch 3
No function
Switch 4
O=Terminal 53 0–10 V(1)
On=Terminal 53 0/4-20 mA
1This is the default setting.
e30ba474.10
ON
OFF
1 2 43
PNP/NPN PNP/NPN U/I
Illustration 4: S200 Switches 1–4
The following illustration shows all control terminals of the drive. Applying start (terminal 18) and an analog reference (terminal 53
or 60) make the drive run.
AQ348848915086en-000101 / 130R0943 | 13Danfoss A/S © 2020.09
Installation
VLT® Micro Drive FC 51
Operating Guide

e30ba473.10
Com RS 485
P RS 485
N RS 485
+24 V OUT
A IN
D IN D IN D IN D IN D IN
Start
Reverse
Reset
Jog
Preset bit 0
GND
0/4 - 20 mA Output A OUT
GND
0 -10 V A IN
1K Ohm
+10 V OUT
0/4 - 20 mA Input
+24 V GND GND PNU 5 - 10 PNU 5 - 11 PNU 5 - 12 PNU 5 - 13 PNU 5 - 15 PNU 6 - 9* PNU 6 - 1* PNU 6 - 2* +10 V DC
61 68 69 12 18 19 20 27 29 33
42
50 53 55
60
Illustration 5: Overview of Control Terminals in PNP-conguration with Factory Setting
AQ348848915086en-000101 / 130R094314 | Danfoss A/S © 2020.09
Installation
VLT® Micro Drive FC 51
Operating Guide

3.8 Power Circuit
e30ba242.18
+ 10 V DC
0-10 V DC -
0/4-20 mA
0/4-20 mA
Analog output
0/4-20 mA
50 (+10 V OUT)
53 (A IN)
60 (A IN)
55 (COM A IN/OUT)
42 (A OUT)
12 (+24 V OUT)
18 (D IN)
19 (D IN)
20 (COM D IN)
27 (D IN)
29 (D IN)
33 (D IN)
ON/I=0-20 mA
OFF/U=0-10 V
S200
S200 ON (NPN)
OFF (PNP)
24 V
0 V
(NPN)
(PNP)
24 V
0 V
(NPN)
(PNP)
24 V
0 V
(NPN)
(PNP)
24 V
0 V
(NPN)
(PNP)
24 V
0 V
(NPN)
(PNP)
RS485
interface (N RS485) 69
(P RS485) 68
(COM RS485) 61
RS485
(PNP) = Source
(NPN) = Sink
S801 0 V
S640 ON = Terminated
OFF = Open
Relay 1
03
02
01
240 V AC, 2 A
Brake
resistor
1)
DC bus
Motor
UDC-
UDC+/BR+
BR-
PE
U
V
W
Switch mode
power supply
10 V DC 24 V DC
5 V
3 phase
power
input
L1/L
L2
L3/N
PE
4
ON
1 2
ON
1 2
ON
Illustration 6: Diagram Showing all Electrical Terminals
1) Brakes (BR+ and BR-) are not applicable for enclosure size M1.
For information about brake resistors, see VLT® Brake Resistor MCE 101 Design Guide.
Improved power factor and EMC performance can be achieved by installing optional Danfoss line lters.
Danfoss power lters can also be used for load sharing. For more information about load sharing, see VLT® Micro DriveFC 51 Load
Sharing application note.
3.9 Load Sharing/Brake
Use 6.3 mm (0.25 in) insulated Faston plugs designed for high voltage for DC (load sharing and brake).
Contact Danfoss or see Load sharing instruction VLT® 5000 for load sharing and VLT® 2800/5000/5000 FLUX/FCD 300 Brake for brake.
Load sharing
Connect terminals -UDC and +UDC/+BR.
Brake
Connect terminals -BR and +UDC/+BR (not applicable for enclosure size M1).
AQ348848915086en-000101 / 130R0943 | 15Danfoss A/S © 2020.09
Installation
VLT® Micro Drive FC 51
Operating Guide

NOTICE
Voltage levels of up to 850 V DC may occur between terminals +UDC/+BR and -UDC. Not short circuit protected.
AQ348848915086en-000101 / 130R094316 | Danfoss A/S © 2020.09
Installation
VLT® Micro Drive FC 51
Operating Guide

-
4 Programming
4.1 Local Control Panel (LCP)
For detailed information on programming, see VLT® Micro DriveFC 51 Programming Guide.
NOTICE
The drive can also be programmed from a PC via RS485 com-port by installing the MCT 10 Set-up Software.
This software can either be ordered using code number 130B1000 or downloaded from the Danfoss web site: www.dan-
foss.com.
e30ba605.13
1
2
3
4
5
6
7
8
9
10
11
12
Status
Quick
Menu
Main
Menu
Menu
On
Warn
Alarm
Hand
On
Off
Reset
Auto
On
Back
OK
Setup 1
Illustration 7: Description of LCP Keys and Display
1
Set-up number
2
Parameter number
3
Motor direction
4
Menu key
5
Indicator lights
6
Operation keys and LED
7
Potentiometer (LCP 12)
8
Navigation keys
9
Selected menu
10
Unit
11
Numeric display
12
Value
Press [Menu] to select 1 of the following menus:
Status
For readouts only.
Quick Menu
For access to Quick Menus 1 and 2.
Main Menu
For access to all parameters.
Navigation keys
[Back]: For moving to the previous step or layer in the navigation structure.
[▵] [▿]: For manoeuvring between parameter groups, parameters, and within parameters.
[OK]: For selecting a parameter and for accepting changes to parameter settings.
AQ348848915086en-000101 / 130R0943 | 17Danfoss A/S © 2020.09
Programming
VLT® Micro Drive FC 51
Operating Guide

•
•
1.
2.
3.
4.
5.
6.
7.
8.
9.
1.
2.
3.
4.
5.
6.
7.
8.
9.
-
Pressing [OK] for more than 1 s enters Adjust mode. In Adjust mode, it is possible to make fast adjustment by pressing [▵] [▿] com-
bined with [OK].
Press [▵] [▿] to change value. Press [OK] to shift between digits quickly.
To exit Adjust mode, press [OK] more than 1 s again with changes saving or press [Back] without changes saving.
Operation keys
A yellow indicator light above the operation keys indicates the active key.
[Hand On]: Starts the motor and enables control of the drive via the LCP.
[O/Reset]: The motor stops. If in alarm mode, the motor resets.
[Auto On]: The drive is controlled either via control terminals or serial communication.
[Potentiometer] (LCP12): The potentiometer works in 2 ways depending on the mode in which the drive is running.
In auto-on mode, the potentiometer acts as an extra programmable analog input.
In hand-on mode, the potentiometer controls local reference.
4.2 Programming on Automatic Motor Tuning (AMT)
Run AMT to optimize compatibility between the drive and the motor in VVC+mode.
The drive builds a mathematical model of the motor for regulating output motor current thus enhancing motor performance.
Run this procedure on a cold motor for best results. To run AMT, use the numeric LCP (NLCP). There are 2 AMT modes for drives.
NOTICE
In mode 2, the rotor rotates during the AMT progress.
Do not add any load on the motor in this AMT progress.
4.2.1 Mode 1
Procedure
Enter the main menu.
Go to parameter group 1-** Load and Motor.
Press [OK].
Set motor parameters using nameplate data for parameter group 1-2* Motor Data.
Go to parameter 1-29 Automatic Motor Tuning (AMT).
Press [OK].
Select [2] Enable AMT.
Press [OK].
The test runs automatically and indicates when it is complete.
4.2.2 Mode 2
Procedure
Enter the main menu.
Go to parameter group 1-** Load and Motor.
Press [OK].
Set motor parameters using nameplate data for parameter group 1-2* Motor Data.
Go to parameter 1-29 Automatic Motor Tuning (AMT).
Press [OK].
Select [3] Complete AMT with Rotating motor.
Press [OK].
The test runs automatically and indicates when it is complete.
AQ348848915086en-000101 / 130R094318 | Danfoss A/S © 2020.09
Programming
VLT® Micro Drive FC 51
Operating Guide

5 Parameter Overview
5.1 Parameter List
Table 6: Parameter List
0-** Operation/Display
0-0* Basic Settings
0-03 Regional Settings
*[0] International
[1] US
0-04 Oper. State at Power-up
(Hand)
[0] Resume
*[1] Forced stop, ref=old
[2] Forced stop, ref=0
0-1* Set-up Handling
0-10 Active Set-up
*[1] Set-up 1
[2] Set-up 2
[9] Multi Set-up
0-11 Edit Set-up
*[1] Set-up 1
[2] Set-up 2
[9] Active Set-up
0-12 Link Set-ups
[0] Not Linked
*[20] Linked
0-31 Custom Readout Min
Scale
0.00–9999.00 * 0.00
0-32 Custom Readout Max
Scale
0.00–9999.00 * 100.0
0-4* LCP Keypad
0-40 [Hand on] Key on LCP
[0] Disabled
*[1] Enabled
0-41 [O / Reset] Key on LCP
[0] Disable All
*[1] Enable All
[2] Enable Reset Only
0-42 [Auto on] Key on LCP
[0] Disabled
*[1] Enabled
0-5* Copy/Save
0-50 LCP Copy
*[0] No copy
[1] All to LCP
[2] All from LCP
[3] Size indep. from LCP
0-51 Set-up Copy
*[0] No copy
[1] Copy from set-up 1
[2] Copy from set-up 2
[9] Copy from Factory set-up
0-6* Password
0-60 (Main) Menu Password
0–999 *0
0-61 Access to Main/Quick
Menu w/o Password
*[0] Full access
[1] LCP:Read Only
[2] LCP:No Access
1-** Load/Motor
1-0* General Settings
1-00 Conguration Mode
*[0] Speed open loop
[3] Process
1-01 Motor Control Principle
[0] U/f
*[1] VVC+
1-03 Torque Characteristics
*[0] Constant torque
[2] Automatic Energy Optim.
1-05 Local Mode Congura-
tion
[0] Speed Open Loop
*[2] As cong in par. 1-00
1-2* Motor Data
1-20 Motor Power [kW] [hp]
[1] 0.09 kW/0.12 hp
[2] 0.12 kW/0.16 hp
[3] 0.18 kW/0.25 hp
[4] 0.25 kW/0.33 hp
[5] 0.37 kW/0.50 hp
[6] 0.55 kW/0.75 hp
[7] 0.75 kW/1.00 hp
[8] 1.10 kW/1.50 hp
[9] 1.50 kW/2.00 hp
[10] 2.20 kW/3.00 hp
[11] 3.00 kW/4.00 hp
[12] 3.70 kW/5.00 hp
[13] 4.00 kW/5.40 hp
[14] 5.50 kW/7.50 hp
[15] 7.50 kW/10.00 hp
[16] 11.00 kW/15.00 hp
[17] 15.00 kW/20.00 hp
[18] 18.50 kW/25.00 hp
[19] 22.00 kW/29.50 hp
[20] 30.00 kW/40.00 hp
1-22 Motor Voltage
50-999 V *230–400 V
1-23 Motor Frequency
20–400 Hz *50 Hz
1-24 Motor Current
0.01–100.00 A *Motortype
dep.
1-25 Motor Nominal Speed
100–9999 rpm *Motortype
dep.
1-29 Automatic Motor Tuning
(AMT)
*[0] O
[2] Enable AMT
[3] Complete AMT with Rotat-
ing motor
1-3* Adv. Motor Data
1-30 Stator Resistance (Rs)
[Ohm] * Dep. on motor data
1-33 Stator Leakage Reac-
tance (X1)
[Ohm] * Dep. on motor data
1-35 Main Reactance (Xh)
[Ohm] * Dep. on motor data
1-5* Load Indep. Setting
1-50 Motor Magnetisation at 0
Speed
0–300% *100%
1-52 Min Speed Norm. Mag-
net. [Hz]
0.0–10.0 Hz *0.0Hz
1-55 U/f Characteristic - U
0-999.9 V
1-56 U/f Characteristic - F
0-400 Hz
1-6* Load Depen. Setting
1-60 Low Speed Load Com-
pensation
0–199% *100%
1-61 High Speed Load Com-
pensation
0–199%*100%
1-62 Slip Compensation
-400–399% *100%
1-63 Slip Compensation Time
Constant
0.05–5.00 s *0.10 s
1-7* Start Adjustments
1-71 Start Delay
0.0–10.0 s *0.0 s
1-72 Start Function
[0] DC hold/delay time
[1] DC brake/delay time
*[2] Coast/delay time
1-73 Flying Start
*[0] Disabled
[1] Enabled
1-8* Stop Adjustments
1-80 Function at Stop
*[0] Coast
[1] DC hold
1-82 Min Speed for Funct. at
Stop [Hz]
0.0–20.0 Hz *0.0 Hz
1-9*Motor Temperature
1-90 Motor Thermal Protec-
tion
*[0] No protection
[1] Thermistor warning
[2] Thermistor trip
[3] Etr warning
[4] Etr trip
1-93 Thermistor Resource
*[0] None
[1] Analog input 53
[6] Digital input 29
2-** Brakes
2-0* DC-Brake
2-00 DC Hold Current
0–150% *50%
2-01 DC Brake Current
0–150% *50%
2-02 DC Braking Time
0.0–60.0 s *10.0 s
2-04 DC Brake Cut In Speed
0.0–400.0 Hz *0.0Hz
2-1* Brake Energy Funct.
2-10 Brake Function
*[0] O
[1] Resistor brake
[2] AC brake
2-11 Brake Resistor (ohm)
Min/Max/default: Powersize
dep.
AQ348848915086en-000101 / 130R0943 | 19Danfoss A/S © 2020.09
Parameter Overview
VLT® Micro Drive FC 51
Operating Guide

Table 7: Parameter List
2-14 Brake Voltage reduce
0 - Powersize dep.* 0
2-16 AC Brake, Max current
0-150% *100%
2-17 Overvoltage Control
*[0] Disabled
[1] Enabled (not at stop)
[2] Enabled
2-2* Mechanical Brake
2-20 Release Brake Current
0.00–100.0 A *0.00 A
2-22 Activate Brake Speed
[Hz]
0.0–400.0 Hz *0.0 Hz
3-** Reference / Ramps
3-0* Reference Limits
3-00 Reference Range
*[0] Min - Max
[1] -Max - +Max
3-02 Minimum Reference
-4999–4999 *0.000
3-03 Maximum Reference
-4999–4999 *50.00
3-1* References
3-10 Preset Reference
-100.0–100.0% *0.00%
3-11 Jog Speed [Hz]
0.0–400.0 Hz *5.0 Hz
3-12 Catch up/slow Down Val-
ue
0.00–100.0% * 0.00%
3-14 Preset Relative Reference
-100.0–100.0% *0.00%
3-15 Reference Resource 1
[0] No function
*[1] Analog Input 53
[2] Analog input 60
[8] Pulse input 33
[11] Local bus ref
[21] LCP Potentiometer
3-16 Reference Resource 2
[0] No function
[1] Analog in 53
*[2] Analog in 60
[8] Pulse input 33
*[11] Local bus reference
[21] LCP Potentiometer
3-17 Reference Resource 3
[0] No function
[1] Analog Input 53
[2] Analog input 60
[8] Pulse input 33
*[11] Local bus ref
[21] LCP Potentiometer
3-18 Relative Scaling Ref. Re-
source
*[0] No function
[1] Analog Input 53
[2] Analog input 60
[8] Pulse input 33
[11] Local bus ref
[21] LCP Potentiometer
3-4* Ramp 1
3-40 Ramp 1 Type
*[0] Linear
[2] Sine2 ramp
3-41 Ramp 1 Ramp up Time
0.05–3600 s *3.00 s (10.00 s)(1)
3-42 Ramp 1 Ramp Down
Time
0.05–3600 s *3.00s (10.00s)(1)
3-5* Ramp 2
3-50 Ramp 2 Type
*[0] Linear
[2] Sine2 ramp
3-51 Ramp 2 Ramp up Time
0.05–3600 s *3.00s (10.00s)(1)
3-52 Ramp 2 Ramp down
Time
0.05–3600 s *3.00s (10.00s)(1)
3-8* Other Ramps
3-80 Jog Ramp Time
0.05–3600 s *3.00s (10.00s)(1)
3-81 Quick Stop Ramp Time
0.05–3600 s *3.00 s (10.00s)(1)
4-** Limits/Warnings
4-1* Motor Limits
4-10 Motor Speed Direction
*[0] Clockwise If Par. 1-00 is
set to close loop control
[1] CounterClockwise
*[2] Both if Par. 1-00 is set to
open loop control
4-12 Motor Speed Low Limit
[Hz]
0.0–400.0 Hz *0.0 Hz
4-14 Motor Speed High Limit
[Hz]
0.1–400.0 Hz *65.0 Hz
4-16 Torque Limit Motor
Mode
0–400% *150%
4-17 Torque Limit Generator
Mode
0–400% *100%
4-4* Adj. Warnings 2
4-40 Warning Frequency Low
0.00–Value of 4-41 Hz *0.0 Hz
4-41 Warning Frequency High
Value
Value of 4-40–400.0 Hz
*400.00 Hz
4-5* Adj. Warnings
4-50 Warning Current Low
0.00–100.00 A *0.00 A
4-51 Warning Current High
0.0–100.00 A *100.00 A
4-54 Warning Reference Low
-4999.000–Value of 4-55 *
-4999.000
4-55 Warning Reference High
Value of 4-54–4999.000
*4999.000
4-56 Warning Feedback Low
-4999.000–Value of 4-57 *
-4999.000
4-57 Warning Feedback High
Value of 4-56–4999.000
*4999.000
4-58 Missing Motor Phase
Function
[0] O
*[1] On
4-6* Speed Bypass
4-61 Bypass Speed From [Hz]
0.0–400.0 Hz *0.0 Hz
4-63 Bypass Speed To [Hz]
0.0–400.0 Hz *0.0 Hz
5-1* Digital Inputs
5-10 Terminal 18 Digital Input
[0] No function
[1] Reset
[2] Coast inverse
[3] Coast and reset inv.
[4] Quick stop inverse
[5] DC-brake inv.
[6] Stop inv
*[8] Start
[9] Latched start
[10] Reversing
[11] Start reversing
[12] Enable start forward
[13] Enable start reverse
[14] Jog
[16-18] Preset ref bit 0-2
[19] Freeze reference
[20] Freeze output
[21] Speed up
[22] Speed down
[23] Set-up select bit 0
[28] Catch up
[29] Slow down
[34] Ramp bit 0
[60] Counter A (up)
[61] Counter A (down)
[62] Reset counter A
[63] Counter B (up)
[64] Counter B (down)
[65] Reset counter B
5-11 Terminal 19 Digital Input
See par. 5-10. * [10] Reversing
5-12 Terminal 27 Digital Input
See par. 5-10. * [1] Reset
5-13 Terminal 29 Digital Input
See par. 5-10. * [14] Jog
5-15 Terminal 33 Digital Input
See par. 5-10. * [16] Preset ref
bit 0
[26] Precise Stop Inverse
[27] Start, Precise Stop
[32] Pulse Input
5-3* Digital Outputs
5-34 On Delay, Terminal 42
Digital Output
0.00–600.00 s * 0.01 s
5-35 O Delay, Terminal 42
Digital Output
0.00–600.00 s * 0.01 s
5-4* Relays
5-40 Function Relay
*[0] No operation
[1] Control ready
[2] Drive ready
1M4 and M5 only.
AQ348848915086en-000101 / 130R094320 | Danfoss A/S © 2020.09
Parameter Overview
VLT® Micro Drive FC 51
Operating Guide
