Danfoss VLT Midi Drive FC 280 User manual

The instructions provide information about installing the VLT
®
Memory Module MCM 102 in VLT
®
Midi Drive FC 280.
The VLT
®
Memory Module MCM 102 is an option for FC 280
frequency converters. A memory module is a component that
stores motor data, rmware, and parameter settings of a
frequency converter. If a frequency converter malfunctions, the
motor data, rmware, and parameter settings on this
frequency converter can be copied to new frequency
converters of the same power size. Copying the settings saves
the time for setting up new frequency converters for the same
applications.
The data and parameter settings on a memory module are
encoded les that are protected from direct viewing.
To access les in a memory module, or transfer les to a
memory module, a memory module programmer is required. It
is not included in this package and must be ordered
separately (ordering number: 134B0792).
1 Memory module
2 Status indicator light
3 Socket for memory module
4 Memory module programmer
5 USB Type-B receptacle
Illustration 1.1 Memory Module and Memory Module Programmer
The memory module can be inserted and removed during
operation of the frequency converter, but it is only active after
a power cycle. The personnel mounting or dismounting the
memory module must be familiar with the safety instructions
and measures described in the VLT
®
Midi Drive FC 280
Operating Instructions.
Items Supplied
Description Ordering number
VLT
®
Memory Module MCM 102 132B0359
Table 1.1 Ordering Numbers
Installation
1. Remove the plastic front cover of the frequency
converter with a screwdriver.
Illustration 1.2 Removing the Front Cover of the Frequency
Converter
Installation Instructions
VLT® Memory Module MCM 102
VLT® Midi Drive FC 280
Danfoss A/S © 02/2016 All rights reserved. MI07H102

2. Open the lid of the memory module container.
Illustration 1.3 Lid Opened
3. Plug in the memory module on the frequency
converter.
Illustration 1.4 Plugging in the Memory Module on the Frequency
Converter
4. Close the lid of the memory module container.
Illustration 1.5 Lid Closed
5. Mount the plastic front cover of the frequency
converter.
Illustration 1.6 Mounting the Front Cover of the Frequency
Converter
6. When the frequency converter powers up, the data
on the frequency converter is stored into the
memory module.
Installation Instructions VLT® Memory Module MCM 102
VLT® Midi Drive FC 280
2 Danfoss A/S © 02/2016 All rights reserved. MI07H102

Installation Instructions VLT® Memory Module MCM 102
VLT® Midi Drive FC 280
MI07H102 Danfoss A/S © 02/2016 All rights reserved. 3
