Danfoss TP4 Operating instructions

1
TP4 / TP5
Electronic Programmable Room Thermostat
User & Installation Instructions
®
Certification Mark

2
Installation Instructions 3-7
User Instructions 8-23
Instrucciones de instalación 24-28
Instrucciones del usuario 29-42
Ïäçãßåò åãêáôÜóôáóçò 43-47
Ïäçãßåò ÷ñÞóçò 48-62
Instrukcja instalacji 63-67
Instrukcja Użytkownika 68-81
Please Note:
This product should only be installed by a qualified
electrician or competent heating installer and should be
in accordance with the current edition of the IEEE wiring
regulations.
INDEX
GB
ES
GR
PL

3
Installation Instructions
Product Specication
Thermostat features TP4 TP5
Power supply 2 x AA/MN1500/LR alkaline cells
24 hour programming 
5/2 day programming 
Memory back-up 1 min for battery change
Switching action of output relay
1 x SPDT,Type 1B
Switch rating of relay contact 6(2)A, 10-264Vac
Temperature range 5-30°C
Dimensions, mm 98 wide, 81 high, 34 deep
Design standard EN60730-2-9
Rated impulse voltage 2.5Kv
Ball hardness test 75°C
Control pollution situation Degree 2
Temperature accuracy ±1°C
Time accuracy ±1 min.
Installation Instructions
GB

4
Installation
 There must be clearances of at least 110mm around the unit.
 Fix at a height of approximately 1.5m from the floor, away from
draughts or heat sources such as radiators, open fires or direct
sunlight.
110mm
minimum
from nearest
obstruction
110mm minimum from
nearest obstruction
60mm fixing
centres
Installation Instructions
GB

5
Wiring
 Cable entry is from behind if fitted to a single gang flush box,
or from above, below or from the left if surface fixed cable is
used.
Installation Instructions
GB

6
!Some existing thermostats wil
have a Neutral wire and/or
Earth wire connected. These are
not required by the TP4/5 and
must NOT be connected to any
TP4/5 terminals. Instead they
should be made electrically safe
and coiled in the recess at the
back of the TP4/5.
Wiring
Installation Instructions
GB

7
Installation Instructions
GB

8
What is a programmable room thermostat?
...an explanation for householders.
A programmable room thermostat is both a programmer and a room thermostat.
A programmer allows you to set ‘On’and‘Off’ time periods to suit your own lifestyle.
A room thermostat works by sensing the air temperature, switching on the heating
when the air temperature falls below the thermostat setting,and switching it off once
this set temperature has been reached.
So, a programmable room thermostat lets you choose what times you want the
heating to be on,and what temperature it should reach while it is on.It will allow you
to select different temperatures in your home at different times of the day (and days
of the week) to meet your particular needs.
Turning a programmable room thermostat to a higher setting will not make the
room heat up any faster. How quickly the room heats up depends on the design of
the heating system,for example,the size of boiler and radiators.
User Instructions
GB

9
Neither does the setting affect how quickly the room cools down. Turning a
programmable room thermostat to a lower setting will result in the room being
controlled at a lower temperature,and saves energy.
The way to set and use your programmable room thermostat is to find the lowest
temperature settings that you are comfortable with at the different times you have
chosen, and then leave it alone to do its job. The best way to do this is to set low
temperatures first, say 18°C, and then turn them up by one degree each day until
you are comfortable with the temperatures.You won’t have to adjust the thermostat
further. Any adjustments above these settings will waste energy and cost you more
money.
If your heating system is a boiler with radiators, there will usually be only one
programmable room thermostat to control the whole house. But you can have
different temperatures in individual rooms by installing thermostatic radiator
valves (TRVs) on individual radiators. If you don’t have TRVs, you should choose
a temperature that is reasonable for the whole house. If you do have TRVs, you
can choose a slightly higher setting to make sure that even the coldest room is
comfortable,then prevent any overheating in other rooms by adjusting the TRVs.
The time on the programmer must be correct. Some types have to be adjusted
in spring and autumn at the changes between Greenwich Mean Time and British
Summer Time.
You may be able to temporarily adjust the heating programme, for example,
‘Override’,‘Advance’or‘Boost’.These are explained in the manufacturer’s instructions.
Programmable room thermostats need a free flow of air to sense the temperature,
so they must not be covered by curtains or blocked by furniture.Nearby electric fires,
televisions,wall or table lamps may prevent the thermostat from working properly.
User Instructions
GB

10
Your programmable room thermostat
TP4 & TP5 room thermostats let you programme up to 6 times
and temperatures at which your heating will come on and go off
each day. With the TP5 you can programme one set of times and
temperatures for weekdays and another set for weekends. They
feature several user overrides including frost protection.
User Instructions
User Instructions
GB

11
Preset Programmes
TP4 - Everyday
TP5 - Weekdays (Mon-Fri) TP5 - Weekend (Sat-Sun)
Event Time Temp °C Event Time Temp °C
1 6:30am 20 1 7:00am 20
2 8:30am 16 2 10:00am 16
3 12:30pm 19 3 12:00pm 19
4 1:30pm 16 4 2:00pm 16
5 5:30pm 21 5 5:00pm 21
6 10:30pm 16 6 10:30pm 16
If you want to change any of these settings you can do so by following
the instructions on page 16-17 (TP4) or pages 18-19 (TP5).
First, follow the steps on pages 12-15 to set the correct time and
date.
TheTP4 & TP5 come ready programmed with a set of operating times
and temperatures which often suit most people.
User Instructions
GB

12
Before you start
Slide the battery cover to the left to
reveal the programming buttons.
Press and hold the +,– , & buttons
at the same time, to reset the unit.
This will reinstate the preset
programmes and will set the time
to 12:00 on Monday (MO) and the
temperature to 16°C.
PM
MO
User Instructions
GB

13
Setting the Clock & Day
CLOCK
Press PROG to begin programming.
Use + or - to adjust the TIME (press and
hold to change in 10 min increments).
DAY (TP5 only)
Press PROG again.
Use + or - buttons until correct DAY is
shown (MO = Monday,TU = Tuesday,etc)
Press PROG again to accept the settings.
Remember - you will have to reset
the time when the clocks change in
Spring and Autumn.
MO
i2 00
PM
!
User Instructions
GB

14
If you are happy to use the preset
programmes on page 11, you don’t need
to do anything else.
To accept the factory presets close the front cover and after 2
minutes the presettings will automatically be accepted.
Your unit is now in RUN mode and the heating will come on and
go off at the programmed times.
Running your programme
20
i2 24
pm
MO
User Instructions
GB

15
Please Note
The unit must be programmed in sequence and EVENT times
cannot be programmed out of sequence.
The event 1 time setting can be set at any time of day (normally
in the morning).The time settings for events 2 to 6 can only be
placed between the previous setting and 1.59.
If you want to leave a preset time as it is, simply press PROG to
move on to the next setting.
During programming, if no buttons are pressed for 2 to 3
minutes the unit will automatically return to RUN mode, and the
programme set up to that minute will be active.
If at any time you get confused and need to reset the unit to the
preset programmes,press and hold the + ,– ,  &buttons at
the same time.
Before you change the preset programmes
!
User Instructions
GB

16
Changing the preset programmes - TP4
a) Press PROG twice to show the
1st pre-set time and temperature
(Event 1).
b) Use + or – buttons to adjust the
TIME (press and hold to change in
10 min increments).
c) Use or buttons to adjust the
TEMPERATURE.
d) Press PROG to move to next preset
time & temperature (Event 2).
e) Repeat steps b, c & d for
programming Events 3, 4, 5 & 6.
User Instructions
GB

17
20
i2 24
pm
Press PROG until the colon in the LCD
display starts to flash.
The unit is now in RUN mode and the
heating will come on and go off at the
programmed times
Note: A flame symbol will appear in
the display whenever the thermostat is
calling for heat.
Ensure the TP4 is in RUN mode before
sliding the cover shut.
Please go to page 20.
!
User Instructions
GB

18
For Days 1-5 (weekdays)
a) Press PROG 3 times to show the
1st pre-set time and temperature
(Event 1, MOTUWETHFR). Please
note MOTUWETHFR is the
abbreviation for the days of the
week.
b) Use + or – buttons to adjust the
TIME (press and hold to change in
10 min increments).
c) Use or buttons to adjust the
TEMPERATURE.
d) Press PROG to move to next preset
time & temperature (Event 2,
MOTUWETHFR).
e) Repeat steps b, c & d for
programming Events 3, 4, 5 & 6.
Changing the preset programmes - TP5
20
AM
MOTUWETHFR
User Instructions
GB

19
For Days 6-7 (weekends)
Press PROG to show 1st pre-set
time and temperature (Event 1,
SASU).
Repeat steps b, c and d on previous
page to programme time and
temperature events for the
weekend.
20
7 00
am
5)57
!
Press PROG until the colon in the LCD
display starts to flash.
The unit is now in RUN mode and the
heating will come on and go off at the
programmed times.
Note: A flame symbol will appear in
the display whenever the thermostat is
calling for heat.
Ensure the TP5 is in RUN mode before
sliding the cover shut.
20
i2 24
pm
MO
User Instructions
GB

20
Temporary override of programmed temperature
The override buttons, and , can be used to temporarily override
the events you have programmed.
For example, you may arrive home early and while you normally
have the thermostat set for 16°C,you may require more heat now. By
pressing the up button on the front of the TP5, the set temperature
on the top right of the display begins to increase.
Sometimes you may need to change the way you use your heating
temporarily, i.e.due to unusually cold weather.The TP4 and TP5 have
several user overrides, which can be selected without affecting the
thermostat programming.
