Dannmar M-6 User manual

1
Dannmar Equipment
646 Flinn Avenue
Moorpark, CA 93021
Tel: [phone]
www.dannmar.com
PLEASE READ THE ENTIRE CONTENTS OF THIS MANUAL PRIOR TO INSTALLATION AND OPERATION. BY PROCEEDING WITH LIFT
INSTALLATION AND OPERATION YOU AGREE THAT YOU FULLY UNDERSTAND AND COMPREHEND THE FULL CONTENTS OF THIS
MANUAL. FORWARD THIS MANUAL TO ALL OPERATORS. FAILURE TO OPERATE THIS EQUIPMENT AS DIRECTED MAY CAUSE
INJURY OR DEATH.
Rev B 062018
P/N# 17404004
M-6 USER MANUAL
Rev B 062018
P/N# 17404004
Previoulsy known as
MX6
MJ-GCE
A
N
D
V
A
L
I
D
A
T
E
D
Reference ANSI/ALI ALIOM safety
requirments for installation and service of
automotive lifts before installing lift.
Dannmar
R
EQUIPMENT
MODEL: M-6
PN# 1375685
PORTABLE MID-RISE LIFT
6,000 POUND CAPACITY
©2018 DANNMAR EQUIPMENT. ALL RIGHTS RESERVED.
Patent No. US 8.256.577 B2
Patent No. US 9.150.395 B2

2
TABLE OF CONTENTS
IMPORTANT NOTICE / DEFINITIONS OF HAZARD LEVELS 3
IMPORTANT SAFETY INSTRUCTIONS 4 - 5
OWNER / EMPLOYER RESPONSIBILITIES 6 - 7
INSTALLER / OPERATOR PROTECTIVE EQUIPMENT 7
PARTS INVENTORY / ASSEMBLY DIAGRAM 8 - 9
PARTS BAG CONTENTS / PARTS BOX CONTENTS 10
INSTALLATION INSTRUCTIONS / SELECTING SITE / FLOOR REQUIREMENTS 11
INSTALLING HYDRAULIC CYLINDERS 12
MOUNTING THE HYDRAULIC POWER UNIT 13
SITE LAYOUT 14
INSTALLATION OF POWER DROP ANCHORS 15 - 16
CONNECTING HYDRAULIC LINES 17
HYDRAULIC POWER UNIT SET-UP 17
INSTALLING THE LIFT ARMS 18
INSTALLING THE SAFETY RELEASE LATCH 19
BLEEDING THE CYLINDERS 19
FINAL ADJUSTMENTS / POST INSTALLATION CHECK OFF 19 - 20
OPERATION SAFETY 20
LIFT OPERATION / MAINTENANCE 21
LIFT REMOVAL / RE-INSTALLATION. 22
TROUBLESHOOTING GUIDE 23 - 25
GENERAL DISCLAIMER 26 - 27
LIMITED WARRANTY 28
MAINTENANCE RECORDS 29
OVERALL LIFT SPECIFICATIONS 31

3
IMPORTANT NOTICE
1. Read this manual thoroughly before installing, operating, or maintaining this lift.
2. This lift is designed for indoor use only, and should not be installed in a pit or depression.
3. The oor on which the lift is to be installed must be 4"(101mm) minimum thickness concrete, with a minimum
compressive strength of 3000 psi (20 MPa) and reinforced steel bar.
4. The lifts have specic electrical requirements as described in the Installation Instructions section of this manual.
5. This lift has a minimum ceiling height requirement as described in the Installation Instructions section of this manual.
6. Failure by the owner to provide the recommended shelter, mounting surface, electrical supply, and ceiling height could
result in unsatisfactory lift performance, property damage, or personal injury.
7. Do not attempt to install this lift if you have never been trained on basic automotive lift installation procedures. Reference
ANSI/ALI ALIOM requirements for installation and service of automotive lifts.
8. Never attempt to lift components without proper lifting tools such as forklift or cranes. Stay clear of any moving parts
that can fall and cause injury. These instructions must be followed to insure proper installation and operation of your lift.
9. Dannmar Equipment will assume no liability for loss or damage of any kind, expressed or implied resulting from improper
installation or use of this product.
10. This lift is rated to 6,000-lbs lifting capacity. NEVER EXCEED rated lifting capacity of lift.
11. Qualied person must be consulted for seismic loads and other local or state requirements.
DEFINITIONS OF HAZARD LEVELS
Identify the hazard levels used in this manual with the following denitions and signal words.
Hazards or unsafe practices which could result in severe personal injury or death.
Hazards or unsafe practices which may result in minor personal injury, product or property damage.
Hazards or unsafe practices which may result in minor personal injury, product or property damage.
Lubricate all plastic guide blocks, bearings, and shafts with grease prior to operating the lift. Lubricate all on a weekly basis.
Motors and all electrical components are not sealed against the weather and moisture. Install this lift in a protected indoor
location. Failure by the owner to provide the recommended shelter could result in unsatisfactory lift performance, property
damage, personal injury, and may void the warranty.
BE SAFE: YOUR NEW LIFT WAS DESIGNED AND BUILT WITH SAFETY IN MIND. HOWEVER, YOUR OVERALL
SAFETY CAN BE INCREASED WITH PROPER TRAINING AND THOUGHTFUL OPERATION ON THE PART OF THE
OPERATOR. DO NOT OPERATE OR REPAIR THIS EQUIPMENT WITHOUT READING THIS MANUAL AND THE
IMPORTANT SAFETY INSTRUCTIONS SHOWN INSIDE. KEEP THIS OPERATION MANUAL NEAR THE LIFT AT ALL
TIMES. MAKE SURE THAT ALL USERS READ AND UNDERSTAND THIS MANUAL.

4
IMPORTANT SAFETY INSTRUCTIONS
READ THESE SAFETY INSTRUCTIONS ENTIRELY
Do not attempt to install this lift if you have never been trained on basic automotive lift installation procedures. Never
attempt to lift components without proper lifting tools such as a forklift or crane. Stay clear of any moving parts that can fall
and cause injury.
1. READ ALL INSTRUCTIONS.
2. READ AND UNDERSTAND all safety warning procedures before operating lift.
3. KEEP AREA WELL LIGHTED.
4. WARNING! RISK OF EXPLOSION. This equipment has internal arcing or sparking parts which should not be exposed
to ammable vapors. This machine should not be located in a recessed area or below oor level.
5. KEEP CONTROL HANDLES AND / OR BUTTONS dry, clean and free from grease and oil.
6. CARE MUST BE TAKEN as burns can occur from touching hot parts on the hydraulic unit’s electric motor.
7. DO NOT operate equipment with a damaged power cord or if the equipment has been dropped or damaged until it has
been examined by a qualied service person.
8. DO NOT let the power cord come in contact with hot manifolds or moving fan blades.
9. IF AN EXTENSION CORD IS NECESSARY, a cord with a current rating equal to or more than that of the equipment
should be used. Cords rated for less current than the equipment may overheat. Care should be taken to arrange the
cord so that it will not be tripped over or pulled.
10. ALWAYS UNPLUG EQUIPMENT FROM ELECTRICAL OUTLET WHEN NOT IN USE. Never use the power cord to
pull the power plug from the outlet. Grasp the plug and pull to disconnect.
11. LET EQUIPMENT COOL COMPLETELY BEFORE PUTTING AWAY. Loop power cord loosely around equipment
when storing.
12. TO REDUCE THE RISK OF FIRE, do not operate equipment in the vicinity of open containers of ammable liquids
(i.e., gasoline).
13. ADEQUATE VENTILATION SHOULD BE PROVIDED when working on operating internal combustion engines.
14. KEEP HAIR, LOOSE CLOTHING, FINGERS, AND ALL PARTS OF THE BODY AWAY FROM MOVING PARTS.
15. TO REDUCE THE RISK OF ELECTRIC SHOCK, do not use on wet surfaces or expose to rain.
16. USE ONLY AS DESCRIBED IN THIS MANUAL. Use only manufacturer’s recommended attachments.
17. DO NOT raise vehicle on the lift until installation is completed as instructed in this manual.
18. KEEP HANDS AND FEET CLEAR. Remove hands and feet from any moving parts. Keep feet clear of lift when
lowering. Avoid pinch points.
19. KEEP WORK AREA CLEAN. Cluttered work areas invite injuries.
20. CONSIDER WORK AREA ENVIRONMENT. Do not expose equipment to rain. DO NOT use in damp or wet locations.
Keep area well lighted.

5
21. ONLY TRAINED OPERATORS should operate this lift. All non trained personnel should be kept away from work
area. Never let non trained personnel come in contact with, or operate lift.
22. USE LIFT CORRECTLY. Use lift in the proper manner. Never use lifting adapters other than what is approved by the
manufacturer.
23. DO NOT override self closing lift controls.
24. REMAIN CLEAR of lift when raising or lowering vehicle.
25. CLEAR AREA if vehicle is in danger of falling.
26. ALWAYS ENSURE that the safety locks are engaged before any attempt is made to work on or near vehicle.
27. DRESS PROPERLY. Non skid steel toe footwear is recommended when operating lift.
28. GUARD AGAINST ELECTRIC SHOCK. This lift must be grounded while in use to protect the operator from electric
shock. Never connect the green power cord wire to a live terminal. This is for ground only.
29. DANGER! The power unit used on this lift contains high voltage. Disconnect power at the receptacle before
performing any electrical repairs. Secure plug so that it cannot be accidentally plugged in during service.
30. ALWAYS WEAR SAFETY GLASSES. Everyday eyeglasses only have impact resistant lenses. They are not safey
glasses.
31. MAINTAIN WITH CARE. Keep lift clean for better and safe performance. Follow manual for proper lubrication and
maintenance instructions. Keep control handles and / or buttons dry, clean and free from grease and oil.
32. STAY ALERT. Watch what you are doing. Use common sense. Be aware!
33. CHECK FOR DAMAGED PARTS. Check for alignment of moving parts, breakage of parts or any condition that may
affect its operation. Do not use lift if any component is broken or damaged.
34. NEVER remove safety related components from the lift. Do not use lift if safety related components are damaged or
missing.
NOTE: If attachments, accessories, or conguration modifying components that are located in the load path, affect
operation of the lift, affect the lift electrical listing or affect intended vehicle accommodation are used on this lift
and, if they are not certied for use on this lift, then the certication of this lift shall become null and void. Contact
Dannmar Equipment for information pertaining to certied attachments, accessories, or conguration modifying
components.
SHIPPING DAMAGE CLAIMS: WHEN THIS EQUIPMENT IS SHIPPED, TITLE PASSES TO THE PURCHASER UPON RECEIPT FROM THE CARRIER.
CONSEQUENTLY, CLAIMS FOR THE MATERIAL DAMAGED IN SHIPMENT MUST BE MADE BY THE PURCHASER AGAINST THE TRANSPORTATION
COMPANY AT THE TIME SHIPMENT IS RECEIVED.
When removing the lift from the shipping angles pay close attention as the posts can slide and can cause injury. Prior to
removing the bolts make sure the posts are held securely by a fork lift or some other heavy lifting device.

6
SAVE THESE INSTRUCTIONS
OWNER / EMPLOYER RESPONSIBILITIES
• Shall ensure that lift operators are qualied and that they are trained in the safe use and operation of the lift using the
manufacturer’s operating instructions and regional requirements.
• Shall establish procedures to periodically inspect the lift in accordance with the lift manufacturer’s instructions and
regional requirements. The Employer Shall ensure that lift inspectors are qualied and that they are adequately
trained in the inspection of the lift.
• Shall establish procedures to periodically maintain the lift in accordance with the lift manufacturer’s instructions and
regional requirements, Inspection and Maintenance and The Employer Shall ensure that lift maintenance personnel
are qualied and that they are adequately trained in the maintenance of the lift.
• Shall maintain the periodic inspection and maintenance records recommended by the manufacturer and regional
requirements.
• Shall display the lift manufacturer’s operating instructions; ALI/SM 93-1, ALI Lifting it Right safety manual; ALI/ST-10
ALI Safety Tips card; in a conspicuous location in the lift area convenient to the operator.
• Shall not modify the lift in any manner without the prior written consent of the manufacturer or regional requirements.
• Shall provide necessary lockout/ tagout means for energy sources per ANSI Z244.1-1982 (R1993), safety require-
ments for the lockout / tagout of energy sources, before beginning any lift repairs.
INSTALLER / OPERATOR: PLEASE READ THE ENTIRE CONTENTS OF THIS MANUAL PRIOR TO INSTALLATION
AND OPERATION. BY PROCEEDING WITH LIFT INSTALLATION AND OPERATION YOU AGREE THAT YOU FULLY
UNDERSTAND AND COMPREHEND THE FULL CONTENTS OF THIS MANUAL. FORWARD THIS MANUAL TO ALL
OPERATORS. FAILURE TO OPERATE THIS EQUIPMENT AS DIRECTED MAY CAUSE INJURY OR DEATH.
• I have visually inspected the site where the lift is to be installed and veried the concrete to be in good condition and
free of cracks or other defects. I understand that installing a lift on cracked or defective concrete could cause lift failure
resulting in personal injury or death.
• I understand that a level oor is required for proper installation and level lifting.
• I understand that I am responsible if my oor is of questionable slope and that I will be responsible for all charges
related to pouring a new level concrete slab if required and any charges.
• I understand that Dannmar lifts are supplied with concrete fasteners meeting the criteria of the American National
Standard “Automotive Lifts Safety Requirements for Construction, Testing, and Validation” ANSI/ALI ALCTV-2008, and
that I will be responsible for all charges related to any special regional structural and/or seismic anchoring require-
ments specied by any other agencies and / or codes such as the Uniform Building Code (UBC) and / or International
Building Code (IBC).
• I will assume full responsibility for the concrete oor and condition thereof, now or later, where the above equipment
model(s) are to be installed. Failure to follow danger, warning, and caution instructions may lead to serious personal
injury or death to operator or bystander or damage to property.
• I understand that Dannmar lifts are designed to be installed in indoor locations only. Failure to follow installation in-
structions may lead to serious personal injury or death to operator or bystander or damage to property or lift.

7
Failure to follow danger, warning, and caution instructions may lead to serious personal injury or death to operator or
bystander or damage to property.
Please read entire manual prior to installation. Do not operate this machine until you read and understand all the dangers,
warnings and cautions in this manual. For additional copies or further information, contact:
Dannmar Equipment
646 Flinn Ave.
Moorpark, CA 93021
Tel: [phone]
Fax: [phone]
www.dannmar.com
INSTALLER / OPERATOR
PROTECTIVE EQUIPMENT
Personal protective equipment helps makes installation and operation safer, however, it does not take the place of safe
operating practices. Always wear durable work clothing during any installation and/or service activity. Shop aprons or shop
coats may also be worn, however loose fitting clothing should be avoided. Tight fitting leather gloves are recommended
to protect technician hands when handling parts. Sturdy leather work shoes with steel toes and oil resistant soles should
be used by all service personnel to help prevent injury during typical installation and operation activities.
Eye protection is essential during installation and operation activities. Safety glasses with side shields, goggles, or face
shields are acceptable. Back belts provide support during lifting activities and are also helpful in providing worker protec-
tion. Consideration should also be given to the use of hearing protection if service activity is performed in an enclosed
area or if noise levels are high.
FOR TECHNICAL QUESTIONS, CALL [phone]

8
PARTS INVENTORY
Be Sure to take complete inventory of parts prior to beginning installation.
ITEM No. PART NUMBER DESCRIPTION QTY CHECK
1 POWER UNIT 1
2 17404004 M6 INSTRUCTION MANUAL 1
3 199825 ALI LIFTING POINT GUIDE (ALI/LP) 1
4 199826 ALI SAFETY MANUAL (ALI-SM) 1
5 199827 ALI SAFETY TIPS CARD (ALI-ST) 1
6SERIAL NUMBER TAG 1
7 199865 DANNMAR M6 DECAL 4
8 199888 ALI SAFETY STICKER SET, 2-POST LIFTS 1
9 199889 ALI OWNER OPERATION STANDARD (ANSI/ALI ALOIM) 1
10 199890 ALI CERTIFICATION STICKER (GOLD) 1
11 17107036 ROUND LIFT PAD ADAPTER ASSEMBLY 4
12 17108041 SHORT LIFT PAD EXTENSION 4
13 17151009 POST ASSEMBLY 2
14 17153014 ARM ASSEMBLY 4
15 17154001 POWER UNIT STAND ASSEMBLY 1
16 17156001 HYD. HOSE ASSEMBLY 10 x 4,520mm 2
17 17156002 HYDRAULIC HOSE ASSEMBLY 10mm x 275mm 1
18 17157026 LIFT HEAD PIN WELDMENT 4
19 17200017 5-8in X 2 HEX HEAD BOLT 10
20 17200028 M8 x 20 HEX HEAD BOLT 4
21 17200067 M8 x 30 HEX HEAD BOLT 4
22 17201010 M8 NYLON LOCK NUT 8
23 17202012 5/8in FLAT WASHER 10
24 17204030 LIFT HEAD PIN WELDMENT RELEASE PIN 4
25 17206014 3-8in NPTF FEMALE x QUICK DISCONNECT FEMALE 2
26 17206016 9-16in SAE ORB x 9-16in JIC, 90DEG ELBOW LONG WITH O-RING 1
27 17206017 9-16in JIC X 3-8in NPTF, 90DEG ELBOW LONG 1
28 17207015 POWER UNIT VIBRATION DAMPENER 1
29 17207033 C-WASHER SHIM 20
30 17207037 HYDRAULIC FLOW DIVIDER 1
31 17207094 7-8in x 3.8125in DROP IN SLEEVE ANCHOR 10
32 17401004 LABEL, SAFETY INSTRUCTIONS STICKER 1
33 17401005 LABEL, SAFETY WARNING STICKER 1
34 17401006 LABEL, CAPACITY WARNING STICKER 1
35 17401007 LABEL, SAFETY LOCK STICKER 2
36 17158151 CE ONLY, ARM FOOT GUARD, LEFT HAND 2
37 17158152 CE ONLY ARM FOOT GUARD, RIGHT HAND 2
M6 ASSEMBLY
17
17156002
HYDRAULIC HOSE ASSEMBLY 10mm x 275mm
1
18
17157026
LIFT HEAD PIN WELDMENT
4
19
17200017
5-8in X 2 HEX HEAD BOLT
10
20
17200028
M8 x 20 HEX HEAD BOLT
4
21
17200067
M8 x 30 HEX HEAD BOLT
4
22
17201010
M8 NYLON LOCK NUT
8
23
17202012
5/8in FLAT WASHER
10
24
17204030
LIFT HEAD PIN WELDMENT RELEASE PIN
4
25
17206014
3-8in NPTF FEMALE x QUICK DISCONNECT FEMALE
2
26
17206016
9-16in SAE ORB x 9-16in JIC, 90DEG ELBOW LONG WITH O-RING
1
27
17206017
9-16in JIC X 3-8in NPTF, 90DEG ELBOW LONG
1
28
17207015
POWER UNIT VIBRATION DAMPENER
1
29
17207033
C-WASHER SHIM
20
30
17207037
HYDRAULIC FLOW DIVIDER
1
31
17207094
7-8in x 3.8125in DROP IN SLEEVE ANCHOR
10
32
17401004
LABEL, SAFETY INSTRUCTIONS STICKER
1
33
17401005
LABEL, SAFETY WARNING STICKER
1
©2018 DANNMAR EQUIPMENT. ALL RIGHTS RESERVED.

9
©2018 DANNMAR EQUIPMENT. ALL RIGHTS RESERVED.

10
PART NUMBER DESCRIPTION QTY CHECK
17200006 M10 x 25 HEX HEAD BOLT 4
17200011 M6 x 40 PAN HEAD MACHINE SCREW 12
17200017 5-8in X 2 HEX HEAD BOLT 10
17200028 M8 x 20 HEX HEAD BOLT 4
17200029 M8 x 55 HEX HEAD BOLT 4
17200067 M8 x 30 HEX HEAD BOLT 4
17200075 M6 x 10 PAN HEAD MACHINE SCREW 4
17201007 M6 NYLON LOCK NUT 12
17201010 M8 NYLON LOCK NUT 12
17202005 M12 FLAT WASHER 4
17202012 5-8in FLAT WASHER 10
17203017 TORSION SPRING, 2.5mm x 25.5mmOD x 17mm 4
17204002 4mm HAIRPIN COTTER 2
17204029 CLEVIS BOLT, 18mm x 85mm 2
17204030 LIFT HEAD PIN WELDMENT RELEASE PIN 4
17206014 3-8in NPTF FEMALE x QUICK DISCONNECT FEMALE 2
17206015 3-8IN NPTF FEMALE x QUICK DISCONNECT MALE 2
17206016 9-16in SAE ORB x 9-16in JIC, 90DEG ELBOW LONG WITH O-RING 1
17206017 9-16in JIC X 3-8in NPTF, 90DEG ELBOW LONG 1
17206018 3-8in NPTF NIPPLE, WITH HEX FLATS 2
17206019 3-8in NPTF 45DEG STREET ELBOW 4
17206020 1-4in NPTF MALE X 3-8in NPTF FEMALE, STRAIGHT EXPANDER 2
17207033 C-WASHER SHIM 20
PLASTIC PARTS BAG CONTENTS
PART NUMBER DESCRIPTION QTY CHECK
17107036 ROUND LIFT PAD ADAPTER ASSEMBLY 4
17108041 SHORT LIFT PAD EXTENSION 4
17156001 HYD. HOSE ASSEMBLY 10 x 4,520mm 2
17156002 HYDRAULIC HOSE ASSEMBLY 10mm x 275mm 1
17157001 HANDLE ASSEMBLY 4
17157025 SAFETY RELEASE ASSEMBLY 2
17157026 LIFT HEAD PIN WELDMENT 4
17158007 HAND CART WHEEL 2
17158010 WHEEL 4
17158141 SAFETY COVER 2
17207015 POWER UNIT VIBRATION DAMPENER 1
PARTS BOX CONTENTS
PART NUMBER DESCRIPTION QTY CHECK
17157027 CE COMPLIANCE KIT 1
17107022 FRAME CRADLE PAD ASSEMBLY 4
17157007 MOTORCYCLE ADAPTER KIT 1
100121 ANCHOR EPOXY KIT 1
17108042 6" LONG LIFT PAD EXTENSION 4
OPTIONAL ACCESSORIES
17157025
SAFETY RELEASE ASSEMBLY
2
17157026
LIFT HEAD PIN WELDMENT
4
17158007
HAND CART WHEEL
2
17158010
WHEEL
4
17158141
SAFETY COVER
2
17207015
POWER UNIT VIBRATION DAMPENER
1
PART NUMBER
DESCRIPTION
QTY
CHECK
17157027
CE COMPLIANCE KIT
1
17107022
FRAME CRADLE PAD ASSEMBLY
4
17157007
MOTORCYCLE ADAPTER KIT
1
100121
ANCHOR EPOXY KIT
1
17108042
6" LONG LIFT PAD EXTENSION
4
OPTIONAL ACCESSORIES
17200067
M8 x 30 HEX HEAD BOLT
4
17200075
M6 x 10 PAN HEAD MACHINE SCREW
4
17201007
M6 NYLON LOCK NUT
12
17201010
M8 NYLON LOCK NUT
12
17202005
M12 FLAT WASHER
4
17202012
5-8in FLAT WASHER
10
17203017
TORSION SPRING, 2.5mm x 25.5mmOD x 17mm
4
17204002
4mm HAIRPIN COTTER
2
17204029
CLEVIS BOLT, 18mm x 85mm
2
17204030
LIFT HEAD PIN WELDMENT RELEASE PIN
4
17206014
3-8in NPTF FEMALE x QUICK DISCONNECT FEMALE
2
17206015
3-8IN NPTF FEMALE x QUICK DISCONNECT MALE
2
17206016
9-16in SAE ORB x 9-16in JIC, 90DEG ELBOW LONG WITH O-RING
1
17206017
9-16in JIC X 3-8in NPTF, 90DEG ELBOW LONG
1
17206018
3-8in NPTF NIPPLE, WITH HEX FLATS
2
17206019
3-8in NPTF 45DEG STREET ELBOW
4
©2018 DANNMAR EQUIPMENT. ALL RIGHTS RESERVED.

11
INSTALLATION INSTRUCTIONS
TOOLS REQUIRED
IMPORTANT NOTICE
These instructions must be followed to ensure proper installation and operation of your lift. Failure to comply with these
instructions can result in serious bodily harm and void product warranty. Manufacturer will assume no liability for loss or
damage of any kind, expressed or implied resulting from improper installation or use of this product.
STEP 1
SELECTING SITE
BEFORE INSTALLING YOUR NEW LIFT, CHECK THE FOLLOWING:
1. LIFT LOCATION: Always use architects plans when available. Check layout dimension against oor plan
requirements making sure that adequate space is available.
2. OVERHEAD OBSTRUCTIONS: The area where the lift will be located should be free of overhead obstructions such
as heaters, building supports, electrical lines etc.
3. DEFECTIVE FLOOR: Visually inspect the site where the lift is to be installed and check for cracked or defective
concrete.
4. OPERATING TEMPERATURE. Operate lift only between temperatures of 41° - 104° F (5º - 40 º C).
5. Lift is designed for INDOOR INSTALLATION ONLY.
STEP 2
FLOOR REQUIREMENTS
This lift must be installed on a solid level concrete oor minimum 4"(101mm) thick, compressive strength 3000 psi
(20 MPa) with no more than 3 degrees of slope. FAILURE TO DO SO COULD CAUSE PERSONAL INJURY OR
DEATH.
DO NOT install this lift on any asphalt surface or any surface other than concrete.
DO NOT install this lift on expansion seams or on cracked or defective concrete.
DO NOT install this lift on a second / elevated oor without rst consulting building architect.
DO NOT install this lift outdoors.
• Rotary Hammer Drill or Similar
• 7/8"(22mm) Masonry Bit
• Hammer
• 4 Foot Level (1.5 M)
• Open End Wrench Set: Metric
• Socket and Ratchet Set: Metric
• Hex Key / Metric Allen Wrench Set
• Large Crescent Wrench
• Large Phillips Screwdriver
• Chalk Line
• Medium Phillips Screwdriver
• Tape Measure: 25 Foot (7.5 M) Minimum

12
Remove the 6mm allen bolt and install
the cylinder ttings using teon tape.
Asssemble all ttings together, including
quick disconnect, preferably in a vice.
Install tting assembly into cylinder.
S  
STEP 3
INSTALLING HYDRAULIC CYLINDERS
Fig. 1
Fig. 4
Install the column wheels (P/N 17158010) using M8x55 hex head bolts (P/N 17200029) and M8 nylon lock nut
(P/N 17201010) onto each column. Turn the columns over and lay them down with the open side up. Slide the lift head
to the top of the post. Remove the cylinder from the post. S  
Slide the tting assembly through the
access hole located on the backside of the
columns. S  
Slide lift head until it rests rmly on the baseplate. Stand the column up.
1.
2.
4.
3.
Fig. 2
Install the column handles (P/N 17157001) with M10 x 25 hex head bolts (P/N 17200006) and tie bars (P/N 17157003) with
M10x40mm hex bolts (P/N 17200010) and M10 nylon lock nuts (P/N 17201017).
S  
6.
Slide the cylinders through the lift head tube. S  
P/N 17157001
4
P/N 17200006
4
P/N 17201017
4
P/N 17200010
4
P/N 17206015
1
P/N 17206020
1
P/N 17206018
1
P/N 17206019
2
Cylinder
Lift Head
5.
Fig. 5
Fig. 3
Fitting Assembly
Fig. 4
P/N 17200006
4
P/N 17201017
4
P/N 17206015
1
P/N 17206020
P/N 17206020
1
P/N 17206018
1
2
Fig. 5
Fitting Assembly
©2018 DANNMAR EQUIPMENT. ALL RIGHTS RESERVED.

13
STEP 4
MOUNTING HYDRAULIC POWER UNIT
Assemble cart as shown in the gures below:
1. After installing the cart wheels, attach the
power unit and rubber power unit dampner
pad to the power unit cart using the (4)
m8x25mm hex bolts and nylon lock nuts.
S  
2. Attach the hydraulic ow divider to the power
unit cart using the (4) m8x30mm hex bolts and
nylon lock nuts supplied. S  
NOTE:
Install ow divider so that when facing it from
the front, the (2) plastic plugs are on the left
and the (1) plastic plug is on the right.*
3. Remove the plastic plug from the
lower left port stamped "IN" on the
ow divider. Install the long 90 degree
3/8 NPT tting to 9/16 JIC. Use teon
tape on pipe thread side only. When
tightening the tting, tighten by hand
rst and then using a wrench turn
approximately 3 turns past hand tight.
S  
4. Remove the plastic plug from the
power unit. Install the long 90 degree
9/16 NPT with o-ring to 9/16 JIC tting.
5 Attach the short power unit hose as
shown. DO NOT use teon tape on the
JIC ttings. S  
NOTE:
*(Flow Divider)
Pay close attention to
which side the bolts
are on. When facing
the ow divider, the
bolt heads should be
on the left side.
The lift will not work
properly if the ow
divider is installed
upside down.
©2018 DANNMAR EQUIPMENT. ALL RIGHTS RESERVED.

14
STEP 5
SITE LAYOUT
1. Determine the location of where the lift will be installed based on the size of vehicles servicing. The dimensions
shown below are rough guidelines. "Dry-t" the vehicles intended to be serviced in the bay by referring to the ALI
Lifting Point Guide for appropriate lift points before nalizing the column spacing.
2. Once a location is determined, use a carpenters chalk line to layout a grid for the post locations. Keep all dimensions
and squareness within 1/8"or malfunctioning of the lift can occur.
3. After the post locations are properly marked, use a chalk or crayon to make an outline of the columns on the oor at
each location using the post base plates as a template.
4. Double check all dimensions and make sure that the layout is perfectly square.
NOTE:
Wide or narrow installation is possible. The lift can be installed at a width that suits the vehicles you will be raising.
You may even choose to install additional anchors at varied column positions for adaptability to multiple vehicle
congurations.
5. Recommended bay dimensions 20'deep and 14'wide.
Sport compacts
105"(2667mm) - 115"(2921mm) Typical
Mid size
110"(2794mm) - 120"(3048mm) Typical
Light duty / sport trucks
115"(2921mm) - 120"(3048mm) Typical
Full size trucks
120"(3048mm) - 135"(3429mm) Typical
Use the edge of the base plate to line up the posts along the chalk line.
Chalk line
Sport compacts
105
"
(2667mm) - 115
"
(2921mm)
Typical
Mid size
©2018 DANNMAR EQUIPMENT. ALL RIGHTS RESERVED.

15
STEP 6
INSTALLATION OF POWER DROP ANCHORS
D
BAC
E
1. Before proceeding, double check location and measurements, make
certain that the base plates of each column are aligned with the chalk/
crayon lines. The concrete must be minimum of 4"(101mm) thick with
a minimum compressive strength of 3000 psi (20 MPa). FOLLOW
PROCEEDURE EXACTLY FOR PROPER FITTING AND ALIGNMENT
OF ANCHORS. (S  
2. Use the squared-up base plate on the column as a guide. Using a
rotary hammer drill with a 7/8" concrete bit, drill out each hole in the
column to the minimum depth of 5". Do not ream the hole or allow the drill
to wobble. When removing the bit be careful not to move the columns.
Having someone secure or stand on the columns can be helpful. Repeat
for all holes on both columns and move the columns out of the way. After
drilling, thoroughly clean hole using a vacuum cleaner or compressed air
and a nylon brush. (S  
3. Set the anchor embedment depth: Fully thread the 5/8"
Setting Tool (sacricial hex bolt) with assembled nut and
washer into the anchor. Set the distance between the top of
the anchor and the bottom of the nut/washer to 5/8".
(S  
4. After setting the nut/spacer, place the anchor into the hole
and hammer downward on the setting tool until the nut and
washer makes contact with the surface of the concrete.
(S  
5. To set the anchor tighten the nut while holding the bolt
head (to assure the anchor does not spin in place) Do not
use an impact wrench for this step. Tighten 3 full turns to
reach an installation torque of 90 ft-lbs.
(S  
NOTE: Always wear safety glasses.
Follow drill manufacturer’s instructions.
Use only solid carbide-tipped drill bits
meeting ANSI B212.15 diameter
standards.
Fig. 11
Fig. 12 Fig. 13 Fig. 14
Fig. 10
Set Tool
Hex Bolt
Spacer
5/8”
(16mm)
—
—
▶
—
Drill hole
a minimum of
5" (127mm) deep.
—
—
▶
▶
—
▶
▶
▶
Anchor ▶
—
6. Once the anchor is set remove the cap screw and clear the
anchor with compressed air to remove any concrete dust from
the threads.
reach an installation torque of 90 ft-lbs.
(S
  
NOTE
: Always wear safety glasses.
Follow drill manufacturer’s instructions.
Use only solid carbide-tipped drill bits
meeting ANSI B212.15 diameter
standards.
Fig. 12
Fig. 13
Fig. 14
Set Tool
Hex Bolt
Spacer
5/8”
5/8”
(16mm)
(16mm)
—
—
▶
—
—
▶
—
▶
▶
—
—
▶
—
▶
▶
—
▶
—
▶
▶
—
▶
—
▶
Anchor
▶
—
—
▶
—
▶
6. Once the anchor is set remove the cap screw and clear the
anchor with compressed air to remove any concrete dust from
the threads.
©2018 DANNMAR EQUIPMENT. ALL RIGHTS RESERVED.

16
16
A
B
LEVEL
Before operating your lift, check to make sure both “A” and “B” measurements are equal. The lift arms must be level
before operation. If your lift arms are not level, shim the columns as required.
IMPORTANT LEVELING INSTRUCTIONS
7. Install both columns with bolts and washers to anchors, check plumb and measurements as shown below.
8. If shimming is required, insert the shims as necessary under the
base plate so that when the provided 5/8 x 2"anchor bolts are
tightened, the columns will be plumb both side to side and front to
rear. S  
9. With the shims and anchor bolts in place, tighten all 5/8 x 2"anchor
bolts tight to the base plate. DO NOT USE AN IMPACT WRENCH or
the anchors could become compromised.
NOTE:
It will be helpful to mark on or otherwise note the location of shims
used at each drop anchor to assist at time of re-installation.
Inspect all drop-in anchors for proper setting and or damage each time the lift is re-installed. Inspect the concrete for
cracks defects and/or damage. Do not re-install the lift if any of the drop-in anchors are defective or the concrete is
cracked or defective.
It may be necessary to shim the columns to ensure that the columns are plumb. The columns must be plumb and
square or damage or injury may occur when using the lift. Do not exceed 1/8" total shim thickness.
Fig. 15
A
B
LEVEL
©2018 DANNMAR EQUIPMENT. ALL RIGHTS RESERVED.

17
STEP 8
HYDRAULIC POWER UNIT SET UP
STEP 7
CONNECTING HYDRAULIC LINES
Female Quick
Disconnect
Fitting
Using teon tape, install the Female Quick Disconnect ttings
(P/N 17206014) to the opposite end of each hose. S  
Recheck all tting connections to make sure they are properly
tightened before proceeding.
Position the power unit stand at the front or rear of the vehicle.
Connect the Female Quck Disconnect tting to the Male Quick
Disconnect located at the bottom of each column. S  
P/N 17206014
Fig. 16 3/8 NPTF Hose
Fittings
Fig. 18
1. Fill the power unit reservoir with 7 quarts (6.6 L) of AW-32 hydraulic oil or Dexron III or VI automatic transmission
uid. Make sure the funnel used to ll the power unit is clean. After bleeding the cylinders, check the oil level to see if
additional oil is needed to ensure the reservoir is full.
2. The lift should be plugged into a dedicated circuit with a 20 amp circuit breaker. The standard power unit for this lift
is: US: 110V, 60Hz, single phase
CE: 230V, 50Hz, single phase
ALL WIRING MUST BE PERFORMED BY A CERTIFIED ELECTRICIAN ONLY.
RISK OF EXPLOSION
This equipment has internal arcing or parts that may spark and should not be exposed to ammable vapors. The motor
should not be located in a recessed area or below oor level.
• DO NOT run power unit without oil. Damage to pump can occur.
• The power unit must be kept dry. Damage to power unit caused by water or other liquids such as detergents, acid
etc., is not covered under warranty.
• Improper electrical hookup can damage the motor and will not be covered under warranty.
• Motor can not run on 50hz without a physical change in the motor. (US - only)
• Use a separate breaker for each power unit.
• Protect each circuit with a time delay fuse or circuit breaker. (US-only)
1. Using teon tape, thread one end of the 3/8 NPT hose ttings into one of the top ports of the ow divider. Do this
with both hoses. S  
Fig. 17
©2018 DANNMAR EQUIPMENT. ALL RIGHTS RESERVED.

18
STEP 9
INSTALLING THE LIFT ARMS
Fig. 20 Quick Release Pin
1. Place the lift arm assembly on the lift heads. Install the lift head pins (P/N 17157026) into the lift head and through
the holes in the arm assembly. Install the quick release pin into place on the arm pin. S    
P/N 17157026
P/N 17157026
Fig. 21
©2018 DANNMAR EQUIPMENT. ALL RIGHTS RESERVED.
2. Loosen the arm restraint gear ring bolts and adjust the arm restraint gears so that the teeth on the gear ring mesh
smoothly with the teeth on the gears of the arm gear stop. S  
1. Raise the lift high enough so that the arm gear stops. Attempt to automatically engage the restraint gears on the
arms.
3. Tighten the gear ring bolts
4. Verify the operation of the arm gear stops by pulling up on the
key ring of the arm gear stops. Pivot the arms back and forth
and test the operation of the arm gear stops in various positions.
When releasing the arm gear stop, the pin should drop and the
gears should engage. S  
6. Adjust the gear ring on the arm as necessary to ensure smooth
operation and solid engagement of all four arm restraint pins.
Each arm restraint assembly must be inspected and adjusted
as needed before each and every time the lift is operated. Do
not operate the lift if any of the four arm restraint systems are
not functioning properly. Replace any broken components or
components with broken teeth only with authorized or approved
replacement parts.
5. Ensure that the arms do not move when a force of at least
100 pounds is applied laterally to the fully extended arms. If
they move, readjust the arm restraint gear ring and/or tighten
the arm restraint gear ring bolts.
Fig. 22
Arm Restraint Gear
Fig. 23
CE Users: Installing the Arm Foot Guards
1. Install the Foot Guards. They are directional (left/right sided)
and will only t properly on one side or the other.
S  
Fig. 24
Foot Guard
P/N 17158151
17158152

19
©2018 DANNMAR EQUIPMENT. ALL RIGHTS RESERVED.
STEP 12
LIFT START UP / FINAL ADJUSTMENTS
DURING THE START-UP PROCEDURE, OBSERVE ALL OPERATING COMPONENTS AND CHECK FOR PROPER
INSTALLATION AND ADJUSTMENT. DO NOT ATTEMPT TO RAISE VEHICLE UNTIL A THOROUGH OPERATIONAL
CHECK HAS BEEN COMPLETED.
1. Apply white lithium grease or equivalent to the inside of the columns where the slide blocks glide.
2. Test the power unit by pressing the push-button switch. Raise the lift a few inches and check all hose connections for
leaks. If the motor gets hot or sounds peculiar, stop and check all electrical connections.
3. Raise the lift to it’s maximum height off the oor until the lift head stops.
4. Lower the lift down below the rst safety stop.
1. With the lift in an elevated position, the hoses connected and the oil reservoir full, loosen the bleeder screws
located at the top of each hydraulic cylinder using an allen wrench. Do not completely remove the bleeder screws.
Watch and listen for trapped air escape the cylinders and uid begins to weep from the screw area. Once steady
uid appears, re-tighten the bleeder screw and cleanup excess oil.
S  
STEP 11
BLEEDING THE CYLINDERS
Bleed Screw
Fig. 19
The lift will move down when bleeding, make sure all equipment, personnel,
hands and feet are clear before starting bleeding procedure.
2. Repeat Bleeding proceedure on opposite cylinder.
3. Press the lowering handle on the power unit until the lift lowers
completely to the oor.
DO NOT use lift if an unlevel lifting condition occurs at the arm pad locations that is greater than 3.5"(89mm). If an
unbalanced condition occurs, follow the bleeding instructions shown on this page or consult Technical Support. The lift
must be re-leveled, shimmed and bled each time the lift is reinstalled. Failure to follow these instructions can result in
serious injury or death.
STEP 10
INSTALLING THE SAFETY RELEASE LATCH
See page 30

20
LIFT OPERATION SAFETY
• NEVER exceed rated capacity of 6,000-lbs.
• Tighten all anchor bolts prior to operation. If anchor
bolts are loose, or any component of the lift is
defective, do not use lift.
• DO NOT remove or disable arm restraints.
• DO NOT block, open or override self-closing lift
controls; they are designed to return to the “Off” or
Neutral position when released.
• ALWAYS inspect all quick connect/disconnect hose
ends before any attempt is made to raise vehicle.
• ALWAYS be sure to have proper overhead
clearance.
• ALWAYS load vehicle on lift carefully. Position
the contact pads according to the vehicle
manufacturer’s recommended lift points. Raise lift
until lift pads contact vehicle. Check pads for secure
contact with the vehicle.
NOTE:
Refer to ALI Quick Reference Guide for all point
recommendations, dangers and safety data.
• ALWAYS remain clear of lift when raising or
lowering vehicles.
• Do NOT use lift if an unlevel lifting condition occurs
that is greater 3.5"(89 mm).
• DO NOT rock the vehicle or remove heavy
components while on the lift that may alter weight
distribution
• ALWAYS ensure Safety Locks are engaged before
any attempt is made to work on or near vehicle.
• NEVER go under raised vehicle if Safety Locks are
WHEN LOWERING THE LIFT PAY CAREFUL
ATTENTION THAT ALL PERSONNEL AND OBJECTS
ARE KEPT CLEAR. ALWAYS KEEP A VISUAL LINE
OF SITE ON THE LIFT AT ALL TIMES. ALWAYS
MAKE SURE THAT ALL LOCKS ARE DISENGAGED.
IF ONE OF THE LOCKS INADVERTENTLY LOCKS
UPON DESCENT THE VEHICLE MAY DISMOUNT
CAUSING PERSONAL INJURY OR DEATH.
• ALWAYS remove tool trays, stands, etc. before
lowering lift.
• ALWAYS release safety locks before attempting to
lower lift.
• ALWAYS move the lift arms to provide an
unobstructed exit before removing vehicle from lift
area.
VISUALLY CONFIRM THAT ALL SAFETY LOCKS
ARE ENGAGED BEFORE ENTERING WORK
AREA. SUSPENSION COMPONENTS USED ON
THIS LIFT ARE INTENDED TO RAISE AND LOWER
LIFT ONLY AND ARE NOT MEANT TO BE LOAD
HOLDING DEVICES. REMAIN CLEAR OF
ELEVATED LIFT UNLESS VISUAL CONFIRMATION
IS MADE THAT SAFETY LOCKS ARE FULLY
ENGAGED AND THE LIFT IS LOWERED ONTO
THE SAFETY LOCKS, REFER TO OPERATION
MANUAL FOR PROPER SAFETY LOCK
PROCEDURES AND/OR FURTHER INSTRUTIONS.
POST INSTALLATION CHECK OFF
Columns are properly leveled
Anchor bolts are tightened
 Electric power supply conrmed
Check for hydraulic leaks
Check oil level
Lubrication of critical components
Check for overhead obstructions
Lift arms are level
Arm restraints properly adjusted
All screws, bolts, and pins are secured
Surrounding area is clear
Operation, maintenance and safety manuals on site
