INSTALLATION & OPERATION MANUAL
46018-0198 <90-00007>
46018 AUDIBLE
ALARM MODULE
(AAM)
About this Practice:
This practice has been reissued to:
• Incorporate the Addendum into the
practice (-00 option discontinued).
• Replace Fig. 2.
Issue date: January 1998
Reissued Practices: Updated and
new content can be identified by a
banner in the right margin.
UPDATED
Table of Contents
Ordering Information ........................................................................... 2
General Description.............................................................................. 2
Circuit Description ............................................................................... 3
Application Information ....................................................................... 5
Installation............................................................................................ 6
Operation .............................................................................................. 9
Technical Specifications ....................................................................... 9
Warranty ............................................................................................. 10
46018-01
FOUR LEVEL
AUDIBLE
ALARM
A11-56018-01 REV__
OUTPUT
EXT
LEVEL
ADJ

PAGE 2 46018-0198 <90-00007>
NOTE: This section lists the different options available for this product. To order any of the avail-
able options, contact Dantel Inside Sales through our toll-free number, 1-800-432-6835.
OPTION NUMBER FEATURES
A11-46018-01 Audible Alarm Module (AAM)
ORDERING INFORMATION
GENERAL DESCRIPTION
The 46018 Audible Alarm (AAM) provides an audible alarm through the application of a ground to the input. The AAM
has selectable tone frequencies and repetition rates, which
identifies different alarm levels according to priority.
The 46018 Audible Alarm features:
♦Four four-pin inputs.
♦Two eight-position DIP switches for setting module tone fre-
quencies and duty cycles.
♦A strap option which allows selected tone frequencies to be
high or low.
The AAM is a plug-in printed circuit module that fits into any
Dantel 400-type or similar equipment housing. The front panel
includes:
♦Two speakers.
♦Level control jacks.
♦Output test jacks.
The AAM normally functions with the 46019 Summary Alarm
Module in the 460 Alarm and Control System. You can also use
the AAM where you need a ground actuated audible alarm
device for alarm purposes.
The AAM operates on -21 to -56 VDC input power. The AAM
does not accept subassemblies.
UPDATED

46018-0198 <90-00007> PAGE 3
CIRCUIT DESCRIPTION
Fig. 1 shows the 46018 Audible Alarm functional schematic. The circuit consists of:
An Oscillator
The oscillator receives a ground from any one of four inputs;
each of the inputs having four common pins. When grounded, a
voltage comparator enables the oscillator tones.
DIP Switches
The oscillator feeds two separate DIP switches from inputs 1
and 2 or inputs 3 and 4. each switch contains eight manually set
selectors. Activation of input 1 overrides activation of inputs 2, 3
or 4 for alarm priority purposes. Input 1 automatically switches
to the most important alarm levels.
A Function Generator
The frequency tones route to a function generator strapped for a
sawtooth or squarewave (low or high tone) alarm signal configu-
ration.
An Operational Amplifier
The signal routes through an operational amplifier where the
front panel “LEVEL ADJ” potentiometer (R26) adjusts the
signal gain.
Two Panel Speakers
The panel speakers audibly present the generated alarm signal.
A Voltage Regulator
The voltage regulator consists of transistors Q1 and Q2 that
provide a regulated voltage of -20 VDC for the module.

PAGE 4 46018-0198 <90-00007>
35
9
53 11 13 15
1 3 5 7
27 29 31 33 19 21 23 25 37
39
17
- BATT
IC2
IC2
IC2
-20 VDC
OUTPUT
4A 4B
4C 4D
3A 3B
3C 3D
2A 2B
2C 2D
1A 1B
1C 1D
INPUT
4
INPUT
3
INPUT
2
INPUT
1
EXTERNAL
OUTPUT
GROUND
-21 TO -56 VDC VOLTAGE
REGULATOR -20 VDC
S1
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
S2 IC
1
-20 VDC
EXT
TP1
TP2
IC3
IC3
OPERATIONAL
AMPLIFIER
STRAP
OPTIONS
L
H
R26 LEVEL
ADJ.
(R26)
-20 VDC
IC2
CIRCUIT DESCRIPTION
FIG. 1 - FUNCTIONAL SCHEMATIC, 46018

46018-0198 <90-00007> PAGE 5
APPLICATION INFORMATION
Fig. 2 shows a 460 Alarm and Control System configuration showing alarm gathering, reporting, and annunciation using
the 46018 Audible Alarm Module.
FIG. 2 - 460 ALARM AND CONTROL SYSTEM BLOCK DIAGRAM USING 46018 AUDIBLE ALARM MODULE
UPDATED
46001-XX
A
B
C
D
1
4
7
-
2
5
8
0
3
6
9
SP
SETUP
NEXT
F1
F2
DISPLAY MODE ACO
GLB LOC NOR TST
ACK
GLOBAL LOCAL
CRITICAL
MAJOR
MINOR
STATUS
ENTER
DANTEL - 460 STATUS MONITOR
CRI
MAJ
MIN
ACO
ADU
STATUS MONITOR
ALARM OUT
TO HOST
46023-12
MULTI-ALARM
COMBINER
A11-46023-12 REV__
MAC
AAM
46020-00
MULTI-ALARM
PROCESSOR
A1146020-00 REV__
XMT DATA
RESET
MAP
TTL
MASTER PORT
PRINTER PORT
DCP/F
ALARMS IN
46018-01
FOUR LEVEL
AUDIBLE
ALARM
OUTPUT
EXT
LEVEL
ADJ
A11-56018-01 REV__

PAGE 6 46018-0198 <90-00007>
INSTALLATION
Installation consists of setting the straps and switches, wiring the pin connections, installing the module in the equipment
shelf, and checking out the module.
1. Set the strap and switches.
The strap selects the output waveform (sawtooth or square)
which varies the alarm’s audio tone. The option switches select
tone options. Refer to Fig. 3 and Tables A and B.
FIG. 3 - SWITCH AND STRAP LOCATIONS, 46018
CONTINUED . . .
H
18
S1
OPEN
L
18
S2
OPEN

46018-0198 <90-00007> PAGE 7
TABLE A - STRAP OPTIONS, 46018
TABLE B - SWITCH OPTIONS, 46018
2. Wire the pin connections.
Wire the connector into the shelf or housing. Refer to Fig. 4.
3. Install the module in the proper slot in the equipment
shelf.
4. Checkout
To check the operation of the 46018 AA, monitor the unit in a
system:
1. Apply an alarm (ground) at each input being used and observe the
front panel for proper operation. The front panel “LEVEL ADJ”
button (R26) adjusts the audio output level of the two panel speak-
ers.
2. Monitor the audio output at the front panel test points TP-1 and
TP-2. Connect a 600 ohm level meter across the test points.
3. The meter reads -23 dBm to +7 dBm as you vary the “LEVEL
ADJ.” Set the gain for the front panel speaker levels. Refer to
Fig. 5.
4. There is no troubleshooting performed on this module. When it is
determined during checkout that the module has malfunctioned, it
is to be replaced and returned to the factory for repair.
INSTALLATION
WAVE SHAPE
Saw-tooth Wave
Square-wave
STRAP
L
H
TONE OPTION
800 Hz. Pulsating Tone
1025/1800 Hz. Shifting Tone
90/1320 Hz. Shifting Tone
550/1350 Hz. Shifting Tone
Fast Repetition, 1/6 sec. off,
1/3 sec. on
Slow Repetition, 1/2 sec. off,
1 sec. on
60/850 Hz. Shifting Tone
INPUT #1
S2-5, S2-6,
S2-7 all OFF
S2-5 ON
S2-6 ON
S2-7 ON
S2-8 ON
INPUT #2
S2-1, S2-2,
S2-3 all OFF
S2-1 ON
S2-2 ON
S2-3 ON
S2-4 ON
INPUT #3
S1-5, S1-6,
S1-7, S2-8 all OFF
S1-5 ON
S1-6 ON
S1-7 ON
S1-8 OFF
S1-8 ON
INPUT #3
S1-1, S1-2,
S1-3, S2-4 all OFF
S1-1 ON
S1-2 ON
S1-3 ON
S1-4 OFF
S1-4 ON
NOTES:
1. Other than the switch listed (which can be either ON or OFF) the status of all other
switches is assumed to be OFF.
2. The frequencies shown in Table B are approximate. Any combination of S1 and S2 switch status can
result in other tone frequencies being produced.

PAGE 8 46018-0198 <90-00007>
INSTALLATION
56 55
54 53
52 51
50 49
48 47
46 45
44 43
42 41
40 39
38 37
36 35
34 33
32 31
30 29
28 27
26 25
24 23
22 21
20 19
18 17
16 15
14 13
12 11
10 9
87
65
43
21
CIRCUIT SIDE
OF PC BOARD
COMPONENT SIDE
OF PC BOARD
-20 VDC Output
External Output
External Output
-21 to -56 VDC
2D
2C
2B
2A
1D
1C
1B
1A
Ground
4D
4C
4B
4A
3D
3C
3B
3A
}
}
}
}
Input 2
Input 1
Input 4
Input 3
FIG. 4 - PIN DESIGNATIONS, 46018

46018-0198 <90-00007> PAGE 9
OPERATION
There are no specific operating instructions for the 46018 Audible Alarm Module. The unit begins operation with
application of power.
The audible level is user-adjustable from the front panel. Refer
to Fig. 5.
46018-01
FOUR LEVEL
AUDIBLE
ALARM
A11-56018-01 REV__
OUTPUT
EXT
LEVEL
ADJ
TECHNICAL SPECIFICATIONS
DESCRIPTION
Input Voltage Range
Input Current
Idle
Enabled
Heat Dissipation
Idle
Enabled
Speakers
Amplifier Output Level
Temperature Range
Physical Dimensions
Weight
VALUE
-21 to -56 VDC
30.05 mA
57.7 mA
4.99 Btu/Hr.
9.45 Btu/Hr.
250 mW adjustable
+7 dBm adjustable
0° to 60° C.
1.4" x 6.0" x 5.6"
5.75 ounces
FIG. 5 - FRONT PANEL VIEW, 46018

PAGE 10
10 PAGES 46018-0198-PR
LIMITED WARRANTY
The Seller warrants that the standard hardware products sold will be free from defects in material and work-
manship and perform to the Seller’s applicable published specifications for a period of 18 months for hardware,
and 3 months for software, from the date of the original invoice. The liability of the Seller hereunder shall be
limited to replacing or repairing, at its option, any defective products which are returned F.O.B. to the Seller’s
plant, (or, at the Seller’s option, refunding the purchase price of such products). In no case are products to be
returned without first obtaining permission and a customer return authorization number from the Seller. In
no event shall the Seller be liable for any consequential or incidental damages.
Equipment or parts which have been subject to abuse, misuse, accident, alteration, neglect, unauthorized
repair or installation are not covered by warranty. The Seller shall make the final determination as to the
existence and cause of any alleged defect. No warranty is made with respect to custom equipment or products
produced to the Buyer’s specifications except as specifically stated in writing by the Seller in the contract for
such custom equipment.
This warranty is the only warranty made by the Seller with respect to the goods delivered hereunder, and may
be modified or amended only by a written instrument signed by a duly authorized officer of the Seller and
accepted by the Buyer.
Warranty and remedies on products not manufactured by the Seller are in accordance with warranty of the
respective manufacturer. THE SELLER MAKES NO OTHER WARRANTY OF ANY KIND WHATSOEVER,
EXPRESSED OR IMPLIED; AND ALL IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR PUR-
POSE WHICH EXCEEDS THE AFORESAID OBLIGATIONS IS HEREBY DISCLAIMED BY THE SELLER.
INCASE OF DIFFICULTY
If you experience difficulty with this equipment, check the following, as appropriate:
1. Switch settings
2. Signal levels
3. Software configuration
4. Connections between Dantel’s equipment and your equipment.
If there is still a problem, substitute equipment that is known to be good. For additional assistance, call
Dantel’s Technical Field Service Department weekdays, 6 A.M. to 5 P.M. pacific time:
1-800-4DANTEL(1-800-432-6835).
If a thorough checkout shows a piece of equipment has malfunctioned, you may return it to the factory. For
repairs and emergency replacements, obtain a Return Material Authorization (RMA) number from the Cus-
tomer Service Representative at 1-800-4DANTEL (1-800-432-6835).
To ensure expedient processing of your order, provide a purchase order number and shipping and billing
information when requesting an RMA number. Also, when the units are returned to Dantel, include a descrip-
tion of the failure symptoms for each unit returned. Send defective equipment to:
Dantel, Inc. • 2991 North Argyle Avenue • Fresno, California 93727-1388
P.O. Box 55013 • Fresno, CA 93747-5013 Phone [phone] Fax [phone] http://www.dantel.com
WARRANTY
