Dantel 44093 User manual

CAUTION
•Install or remove modules from the shelf only when the power is off.
If you install a module in the shelf with the power on, the internal
circuitry may suffer damage and the product warranty will be void.
•Remove and install circuit boards only in a static-safe environment
(use antistatic wrist straps, smocks, footwear, etc.).
•Keep circuit boards in their antistatic bags when they are not in use.
•Do not ship or store circuit boards near strong electrostatic, electromag-
netic, magnetic, or radioactive fields.
•For more complete information on electrostatic discharge safety
precautions, refer to BellcoreTM Technical Reference # TR-NWT-000870.
Copyright 1998 by Dantel, Inc. • Dantel is a registered trademark of Dantel, Inc. • ISO 9001 Registered
Printed in the U.S.A.
INSTALLATION & OPERATION MANUAL
44093-0198 <90-00002>
44093
RJ11 MODULE
About this Practice:
This practice has been reissued to:
• Meet ISO 9001 requirements.
Issue date: January 1998
Reissued Practices: Updated and
new content can be identified by a
banner in the right margin.
UPDATED
Table of Contents
Ordering Information ........................................................................... 2
General Description.............................................................................. 2
Circuit Description ............................................................................... 2
Installation............................................................................................ 3
Operation .............................................................................................. 4
Application Information ....................................................................... 4
Technical Specifications ....................................................................... 4
Warranty ............................................................................................... 6

PAGE 2 44093-0198 <90-00002>
ORDERING INFORMATION
NOTE: This section lists the different options available for this product. To order any of the avail-
able options, contact Dantel Inside Sales through our toll-free number, 1-800-432-6835.
OPTION NUMBER FEATURES
A11-44093-00 RJ11 Interface
GENERAL DESCRIPTION
The 44093 RJ11 Module is equipped with two independant
RJ11 connectors which provide the modem connections to
allow an order wire system access to network equipment.
The 44093 module is a plug-in circuit module that fits into any
Dantel 400-type or similiar housing. No power is required for
this module.
CIRCUIT DESCRIPTION
The 44093 has two RJ11 connectors on the front panel. The
six wires from each connector are brought to the edge con-
nector. Refer to Fig. 1 and Table A.
FIG. 1 - FRONT PANEL VIEW
44093
RJ-11
INTERFACE
RJ-11 # 1
RJ-11 # 2
A11-44093-00
REV.
TABLE A - WIRING CHART
FROM
RJ11 #1, pin 1
RJ11 #1, pin 2
RJ11 #1, pin 3
RJ11 #1, pin 4
RJ11 #1, pin 5
RJ11 #1, pin 6
RJ11 #2, pin 1
RJ11 #2, pin 2
RJ11 #2, pin 3
RJ11 #2, pin 4
RJ11 #2, pin 5
RJ11 #2, pin 6
COLOR
Blue
Yellow
Green
Red
Black
White
Blue
Yellow
Green
Red
Black
White
EDGE CONNECTOR PIN
1
2
3
4
5
6
7
8
9
10
11
12

44093-0198 <90-00002> PAGE 3
INSTALLATION
Installation consists of installing the module in the equipment
shelf and connecting your equipment to the RJ11 connector(s).
Refer to Fig. 2.
FIG. 2 - PIN DESIGNATIONS, 44093
56 55
54 53
52 51
50 49
48 47
46 45
44 43
42 41
40 39
38 37
36 35
34 33
32 31
30 29
28 27
26 25
24 23
22 21
20 19
18 17
16 15
14 13
12 11
10 9
87
65
43
21
CIRCUIT SIDE
OF PC BOARD
COMPONENT SIDE
OF PC BOARD
RJ11 #1, Pin 6RJ11 #2, Pin 6
RJ11 #1, Pin 5RJ11 #2, Pin 5
RJ11 #1, Pin 4RJ11 #2, Pin 4
RJ11 #1, Pin 3RJ11 #2, Pin 3
RJ11 #1, Pin 2RJ11 #2, Pin 2
RJ11 #1, Pin 1RJ11 #2, Pin 1

PAGE 4 44093-0198 <90-00002>
OPERATION
The 44093 module is a passive device and, once installed and
connected to your equipment, requires no further attention.
APPLICATION INFORMATION
The 44093 is used, in conjunction with an order wire system,
to allow internet access using the 44022 module as the input
and the 44023 module as the PBX interface.
Access is accompplished by plugging a laptop computer into the
RJ11 connector, dialing the PBX interface to access the network,
and then calling the remote internet phone number.
TECHNICAL SPECIFICATIONS
DESCRIPTION
Connector Type
Wire Size
Physical Dimensions
Weight
Operating Temperature Range
VALUE
RS-232, RJ-11, 6-pin to a 56-pin card edge connector
24 AWG solid
1.4" x 6.0" x 5.6"
6.0 ounces
0° to 55° C.

44093-0198 <90-00002> PAGE 5
NOTES

PAGE 6
6 PAGES 44093-0198 <90-00002>
LIMITED WARRANTY
The Seller warrants that the standard hardware products sold will be free from defects in material and work-
manship and perform to the Seller’s applicable published specifications for a period of 18 months for hardware,
and 3 months for software, from the date of the original invoice. The liability of the Seller hereunder shall be
limited to replacing or repairing, at its option, any defective products which are returned F.O.B. to the Seller’s
plant, (or, at the Seller’s option, refunding the purchase price of such products). In no case are products to be
returned without first obtaining permission and a customer return authorization number from the Seller. In
no event shall the Seller be liable for any consequential or incidental damages.
Equipment or parts which have been subject to abuse, misuse, accident, alteration, neglect, unauthorized
repair or installation are not covered by warranty. The Seller shall make the final determination as to the
existence and cause of any alleged defect. No warranty is made with respect to custom equipment or products
produced to the Buyer’s specifications except as specifically stated in writing by the Seller in the contract for
such custom equipment.
This warranty is the only warranty made by the Seller with respect to the goods delivered hereunder, and may
be modified or amended only by a written instrument signed by a duly authorized officer of the Seller and
accepted by the Buyer.
Warranty and remedies on products not manufactured by the Seller are in accordance with warranty of the
respective manufacturer. THE SELLER MAKES NO OTHER WARRANTY OF ANY KIND WHATSOEVER,
EXPRESSED OR IMPLIED; AND ALL IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR PUR-
POSE WHICH EXCEEDS THE AFORESAID OBLIGATIONS IS HEREBY DISCLAIMED BY THE SELLER.
INCASE OF DIFFICULTY
If you experience difficulty with this equipment, check the following, as appropriate:
1. Switch settings
2. Signal levels
3. Software configuration
4. Connections between Dantel’s equipment and your equipment.
If there is still a problem, substitute equipment that is known to be good. For additional assistance, call
Dantel’s Technical Field Service Department weekdays, 6 A.M. to 5 P.M. pacific time:
1-800-4DANTEL(1-800-432-6835).
If a thorough checkout shows a piece of equipment has malfunctioned, you may return it to the factory. For
repairs and emergency replacements, obtain a Return Material Authorization (RMA) number from the Cus-
tomer Service Representative at 1-800-4DANTEL (1-800-432-6835).
To ensure expedient processing of your order, provide a purchase order number and shipping and billing
information when requesting an RMA number. Also, when the units are returned to Dantel, include a descrip-
tion of the failure symptoms for each unit returned. Send defective equipment to:
Dantel, Inc. • 2991 North Argyle Avenue • Fresno, California 93727-1388
P.O. Box 55013 • Fresno, CA 93747-5013 Phone (209) 292-1111 Fax (209) 292-9355 http://www.dantel.com
