Instruction Manual |Recipe Guide
DELUXE COMPACT
COLD PRESS POWER JUICER
# DCSJ255
Dash
Important Safeguards.............................................................................4-6
Parts & Features........................................................................................7-8
Setting Up Your Deluxe Cold Press Power Juicer.............................9-11
Using Your Deluxe Cold Press Power Juicer....................................13-15
Using Your Frozen Attachment................................................................16
Cleaning & Maintenance....................................................................18-20
Tips & Tricks................................................................................................21
Recipes...................................................................................................23-31
Notes .....................................................................................................32-33
Customer Support....................................................................................34
Warranty......................................................................................................35
t
h
e
d
a
s
h
t
e
a
m
!
DELUXE COMPACT
COLD PRESS POWER JUICER
IMPORTANT SAFEGUARDS
IMPORTANT SAFEGUARDS: PLEASE READ AND
SAVE THIS INSTRUCTION AND CARE MANUAL.
When using electrical appliances, basic safety precautions should be followed, including:
• Read all instructions before use.
• Remove all bags and packaging from appliance
before use.
• Never leave appliance unattended when in use.
• Make sure the appliance is cleaned thoroughly
before using.
• Do not use appliance for other than intended use.
For household use only. Do not use outdoors.
• Only use the appliance on a stable, dry surface.
• ATTENTION: This appliance cannot be used with
an external timer or a separate remote control.
• Do not place appliance on or near a hot gas
burner, hot electric burner, or in a heated oven.
• This appliance can be used by persons with
reduced physical, sensory, or mental capabilities
or lack of experience of knowledge, if they have
been given supervision or instruction concerning
use of the appliance in a safe way and understand
the hazards involved.
• This appliance is not a toy. Do not let children use
this appliance. Close supervision is necessary
when any kitchen appliance is used by or near
children.
•
personal injury, do not put cord, plug, or appliance
in or near water or other liquids. The Juicer is NOT
dishwasher safe.
• Do not let the cord touch hot surfaces or hang
over the edge of tables or counters.
• Refrain from using attachments that are not
recommended by the appliance manufacturer,
personal injury.
• Never let the machine work for longer than 20
minutes at a time.
• Unplug the appliance prior to assembly/disassembly,
moving, cleaning, storage, and when not in use.
To unplug, grasp the plug and pull from the outlet.
Never pull from the power cord.
• Do not operate this appliance with a damaged cord,
damaged plug, after the appliance malfunctions,
is dropped, or damaged in any manner. Return
appliance to the nearest authorized service facility for
examination, repair, or adjustment.
• For maintenance other than cleaning, please contact
StoreBound directly at 1-800-898-6970 Monday –
Friday or by email at support@bydash.com.
• StoreBound shall not accept liability for damages
caused by improper use of the appliance.
• Improper use of the appliance can result in property
damage or even in personal injury.
• This appliance has a polarized plug (one blade is
wider than the other). To reduce the risk of electric
plug in any way.
• A short power supply cord is to be provided to
reduce the risk resulting from becoming entangled
in or tripping over a longer cord. An extension
cord may be used if care is exercised in its use. If an
extension cord is used, the marked electrical rating
of the extension cord should be at least as great as
the electrical rating of the appliance. If the appliance
is of the grounded type, the extension cord should
be a grounding 3-wire cord. The extension cord
should be arranged so that it will not drape over the
countertop or tabletop where it can be pulled on by
children or tripped over unintentionally.
GARANTIES IMPORTANTES
Lors de l’utilisation d’appareils électriques, il faut toujours respecter les précautions de sécurité
de base, notamment :
GARANTIES IMPORTANTES: VEUILLEZ LIRE
ET CONSERVER CE MANUEL D’UTILISATION
ET ENTRETIEN
• Lisez toutes les instructions avant utilisation.
• Retirez tout sac ou emballage de l’appareil
avant utilization.
• Ne laissez jamais l’appareil sans surveillance
pendant son utilization.
• Assurez-vous que l’appareil est minutieusement
nettoyé avant utilization.
• N’utilisez pas l’appareil en dehors de son
utilisation prévue. Pour usage ménager
uniquement. Ne l’utilisez pas à l’extérieur.
• N’utilisez l’appareil que sur une surface stable
et sèche.
• ATTENTION : Cet appareil ne peut pas
être utilisé avec une minuterie externe ou
un télécommande.
• Ne placez pas l’appareil sur ou à proximité d’un
brûleur à gaz ou électrique, ou d’un four chaud.
• Cet appareil peut être utilisé par des personnes
dont les capacités physiques, sensorielles
ou mentales sont réduites ou qui manquent
d’expérience et de connaissances, à condition
qu’elles aient reçu une supervision ou des
instructions concernant l’utilisation de l’appareil
en toute sécurité et qu’elles comprennent les
risques encourus.
• Cet appareil n’est pas un jouet. Ne laissez
pas d’enfants utiliser cet appareil. Une étroite
surveillance est nécessaire lorsqu’un appareil est
utilisé par ou à proximité d’enfants.
•
ou de dommages corporels, ne mettez pas le
cordon, la prise ou l’appareil dans ou à proximité
de l’eau ou d’autres liquides. L’extracteur de jus
n’est PAS lavable en machine.
• Ne laissez pas le cordon toucher des surfaces
chaudes ou pendre au niveau des bords de
tables ou de comptoirs.
• Évitez d’utiliser des accessoires qui ne sont pas
recommandés par le fabricant de l’appareil, car
ils pourraient entraîner un feu, une électrocution
ou un dommage corporel.
• Ne laissez jamais la machine fonctionner plus de
20 minutes à la fois.
• Débrancher l’appareil avant montage/
démontage, déplacement, nettoyage ou
et retirez-la de la prise. Ne tirez jamais sur le
cordon d’alimentation.
• N’utilisez pas cet appareil avec un cordon
endommagé, une prise endommagée, ou
si l’appareil est défaillant, s’il est tombé ou
endommagé de quelque façon. Pour toute
inspection, réparation ou ajustement, ramenez
l’appareil au détaillant agréé le plus proche.
• Pour toute question liée à l’entretien autre
que le nettoyage, veuillez contacter
StoreBound directement au 1-800-898-6970
du lundi au vendredi, ou par courriel à
support@bydash.com.
• StoreBound n’est nullement responsable des
dommages causés par une mauvaise utilisation
de l’appareil.
• Une mauvaise utilisation de l’appareil peut
entraîner des dommages matériels ou même
des blessures corporelles.
IMPORTANT SAFEGUARDS
Feed Tube
Cover with Opening
and Sieve
Pusher
Hopper
Axle
Juice Spout
with Stopper
On/Off Switch
Motor Block
Juice Bowl
Auger
parts & features
Frozen Attachment
(See page 14)
Pulp Spout
Back
Silicone
Pressure Valve
important safeguards
GARANTIES IMPORTANTES: VEUILLEZ LIRE
ET CONSERVER CE MANUEL D’UTILISATION
ET ENTRETIEN
•
réduire le risque d’électrocution, cette
Si elle ne s’insère toujours pas, contactez un
• Un cordon d’alimentation court doit être
ou de trébuchement lié aux cordons plus
longs. Une rallonge peut être utilisée à
condition de faire attention. Si une rallonge
est utilisée, la puissance électrique indiquée
sur la rallonge doit être au moins aussi
grande que celle de l’appareil. Si l’appareil
est connecté à la terre, la rallonge doit être
un cordon tripolaire avec prise de terre. La
rallonge doit être disposée de manière à ne
pas reposer sur le comptoir ou sur la table où
elle peut être tirée par un enfant ou source de
trébuchement involontaire.
GARANTIES IMPORTANTES
PA R TS &FEATURES
Cleaning Brush
Pulp Cup Juice Cup
before first use
• Remove all parts from the packaging. Note that the Hopper and Cleaning Brush are
packed on the outside of the protective foam.
• Wash all removable and washable parts, such as the Pusher, Cover, Sieve, Auger, Bowl
and Cups in warm, soapy water. Rinse and dry thoroughly.
Setting Up Your deluxe Cold Press Power Juicer
Position the Juice Bowl on the Motor Block. Make sure the Bowl is mounted properly on
the Axle of the Motor Block (photo B).
2
Make sure the Cold Press Power Juicer is unplugged and the On/Off Switch is turned to
Off prior to assembling (photo A).
B
1
A
PA R TS &FEATURES
Cleaning Brush
Pulp Cup Juice Cup
before first use
• Remove all parts from the packaging. Note that the Hopper and Cleaning Brush are
packed on the outside of the protective foam.
• Wash all removable and washable parts, such as the Pusher, Cover, Sieve, Auger, Bowl
and Cups in warm, soapy water. Rinse and dry thoroughly.
Setting Up Your deluxe Cold Press Power Juicer
Position the Juice Bowl on the Motor Block. Make sure the Bowl is mounted properly on
the Axle of the Motor Block (photo B).
2
Make sure the Cold Press Power Juicer is unplugged and the On/Off Switch is turned to
Off prior to assembling (photo A).
B
1
A
PA R TS &FEATURES
Using Your Compact Cold Pressed Juicer
Position the Cover on the Bowl and twist until the cover clicks shut. Make sure the arrow
on the Cover aligns with the Lock icon on the lid (photo D). Note that the unit will not
power on if the Cover is not locked into place.
4
Setting up Your deluxe Cold Press Power Juicer
(photo C).
CD
3
Setting Up Your deluxe Cold Press Power Juicer
Position one cup under the Juice Spout and one cup under the Pulp Spout. The Juicer is
now ready to use (photo E). The Hopper can be added to the tube of the Cover to hold
more ingredients, if you wish (photo F).
E
5
F
Using Your Compact Cold Pressed Juicer
Position the Cover on the Bowl and twist until the cover clicks shut. Make sure the arrow
on the Cover aligns with the Lock icon on the lid (photo D). Note that the unit will not
power on if the Cover is not locked into place.
4
Setting up Your deluxe Cold Press Power Juicer
(photo C).
CD
3
Setting Up Your deluxe Cold Press Power Juicer
Position one cup under the Juice Spout and one cup under the Pulp Spout. The Juicer is
now ready to use (photo E). The Hopper can be added to the tube of the Cover to hold
more ingredients, if you wish (photo F).
E
5
F
v
e
g
g
i
e
d
e
l
i
g
h
t
j
u
i
c
e
o
n
p
a
g
e
2
3
!
CAUTION: Remove hard pits or seeds prior to pressing to prevent possible
damage to the Auger.
The peel and pits/seeds must be removed from oranges, lemons, grapefruit,
and melons before use.
!
using Your deluxe Cold Press Power Juicer
Before using, make sure that the Juicer is turned Off and plug it in. Position the Cups
underneath the Spouts (photo B). Clean fruit and vegetables you wish to juice. For best
results, cut ingredients into 1-1.5” segments.
2
The On/Off Switch has 3 positions: On (I), Off (O), and Reverse (R) (photo A).
B
1
A
CAUTION: Never use the machine with an empty bowl, always add ingredients.
If the Cover becomes loosened from the Bowl during use, the motor of the
machine will automatically stop to prevent hazards.
while the machine is in use.
Use only the Pusher and NOT spoons, forks, tongs, etc.
Using Your deluxe Cold Press Power Juicer
!
Insert the prepped ingredients into the opening at the top of the Cover. Push the food
down into the bowl using the Pusher (photo D).
TIP:
4
Turn on the On/Off Switch (photo C).
CD
3
using Your deluxe Cold Press Power Juicer
If the machine becomes stuck during use, turn the On/Off Switch to R and hold down the
switch so that the machine runs in the opposite direction (photo E). This could remove
any obstructions. Release the switch to stop the reverse movement.
If this does not work, turn the machine off, remove the plug from the outlet and
reassemble the machine according to the instructions. Then try to start the machine again.
When the Cup is full or when all fruits and vegetables have been squeezed, turn the
On/Off Switch off (photo F) and close the Juice Valve.
NOTE: If the machine overheats, it will turn off automatically. Turn the On/Off Switch to
off and wait 10 minutes, then turn the machine on again. Juice should always be stored
in the refrigerator.
CAUTION: Never let the machine work for longer than 30 minutes at a time.
Do not touch the On/Off Switch with wet hands.
5
6
!
EF
CAUTION: Never use the machine with an empty bowl, always add ingredients.
If the Cover becomes loosened from the Bowl during use, the motor of the
machine will automatically stop to prevent hazards.
while the machine is in use.
Use only the Pusher and NOT spoons, forks, tongs, etc.
Using Your deluxe Cold Press Power Juicer
!
Insert the prepped ingredients into the opening at the top of the Cover. Push the food
down into the bowl using the Pusher (photo D).
TIP:
4
Turn on the On/Off Switch (photo C).
CD
3
using Your deluxe Cold Press Power Juicer
If the machine becomes stuck during use, turn the On/Off Switch to R and hold down the
switch so that the machine runs in the opposite direction (photo E). This could remove
any obstructions. Release the switch to stop the reverse movement.
If this does not work, turn the machine off, remove the plug from the outlet and
reassemble the machine according to the instructions. Then try to start the machine again.
When the Cup is full or when all fruits and vegetables have been squeezed, turn the
On/Off Switch off (photo F) and close the Juice Valve.
NOTE: If the machine overheats, it will turn off automatically. Turn the On/Off Switch to
off and wait 10 minutes, then turn the machine on again. Juice should always be stored
in the refrigerator.
CAUTION: Never let the machine work for longer than 30 minutes at a time.
Do not touch the On/Off Switch with wet hands.
5
6
!
EF
using your frozen attachment
• Look for the to determine which attachment is the Frozen Attachment for frozen treats.
• The Frozen Attachment is perfect for making frozen smoothies and sorbet.
• NOTE: When using the Frozen Attachment, the fruit will come out of the Pulp Spout rather
than the Juice Spout.
• Do not put ice cubes in the Power Juicer.
• If freezing your own fruit for sorbet, cut fruit into 1” cubes before freezing for best results.
• Allow frozen fruit to soften at room temperature for about 5-15 minutes.
• Only juice one piece of fruit at a time when using the Frozen Attachment. For example,
using the Pusher, juice 1 piece of fruit through the Feed Tube until it is entirely processed
and then add another piece of fruit.
• Apply steady pressure when pushing food through the Feed Tube.
Frozen Attachment Juice Attachment
Pulp Spout
Juice Spout
2
Turn the On/Off Switch to off. Close the Juice Valve and remove the Cups. Unplug the
Juicer and allow it to cool completely before cleaning.
Remove the Cover by twisting counterclockwise (photo A) and then lifting. Remove
Auger from Bowl (photo B) and clean underneath. If the Auger is stuck, try rotating and
then removing.
A
1
B
Use the included Cleaning Brush to clean the Sieve properly (photo D). Be careful
when cleaning the Sieve.
CHEF TIP: It is recommended to clean the Sieve with the Cleaning Brush for safety
as the Sieve is sharp.
4
Remove the Juice Bowl (photo C). Empty the Cups and clean the Cover, the Pusher,
Sieve, Bowl, and Auger and Cups under running water.
CD
3
CLeaning &maintenance CLeaning &maintenance
2
Turn the On/Off Switch to off. Close the Juice Valve and remove the Cups. Unplug the
Juicer and allow it to cool completely before cleaning.
Remove the Cover by twisting counterclockwise (photo A) and then lifting. Remove
Auger from Bowl (photo B) and clean underneath. If the Auger is stuck, try rotating and
then removing.
A
1
B
Use the included Cleaning Brush to clean the Sieve properly (photo D). Be careful
when cleaning the Sieve.
CHEF TIP: It is recommended to clean the Sieve with the Cleaning Brush for safety
as the Sieve is sharp.
4
Remove the Juice Bowl (photo C). Empty the Cups and clean the Cover, the Pusher,
Sieve, Bowl, and Auger and Cups under running water.
CD
3
CLeaning &maintenance CLeaning &maintenance
If there is still residue in the mouth of the Spout, you can turn the Juicer Bowl over, open
the Silicone Pressure Valve, and rinse with water (photo F). Then reattach the Silicone
Pressure Valve.
6
Spout (photo E).
E
5
F
DO NOT submerge the Motor Block in water.
DO NOT use harsh metal sponges, as they could damage the machine.
Dry all parts thoroughly after cleaning. Once completely dry, reassemble
(See page 7) and store in a dry place.
!
NOTE: ALL parts of the Juicer are dishwasher safe, EXCEPT for the Motor Block.
•
dragon fruit, kiwi and grapes, are not suitable for juicing as they will easily clog the Sieve.
• Fruits and vegetables should be cut into pieces 1-1.5” long before juicing, especially
• Seeds and pits should be removed from fruits like citrus and melon before processing.
• Very seedy fruits like strawberries and raspberries might clog the Sieve. Be sure to go
slowly and limit these types of fruits to small quantities to avoid clogging.
CLeaning &maintenance Tips &Tricks
If there is still residue in the mouth of the Spout, you can turn the Juicer Bowl over, open
the Silicone Pressure Valve, and rinse with water (photo F). Then reattach the Silicone
Pressure Valve.
6
Spout (photo E).
E
5
F
DO NOT submerge the Motor Block in water.
DO NOT use harsh metal sponges, as they could damage the machine.
Dry all parts thoroughly after cleaning. Once completely dry, reassemble
(See page 7) and store in a dry place.
!
NOTE: ALL parts of the Juicer are dishwasher safe, EXCEPT for the Motor Block.
•
dragon fruit, kiwi and grapes, are not suitable for juicing as they will easily clog the Sieve.
• Fruits and vegetables should be cut into pieces 1-1.5” long before juicing, especially
• Seeds and pits should be removed from fruits like citrus and melon before processing.
• Very seedy fruits like strawberries and raspberries might clog the Sieve. Be sure to go
slowly and limit these types of fruits to small quantities to avoid clogging.
CLeaning &maintenance Tips &Tricks
RECIPE
GUIDE
Follow us!
@bydash | recipes, videos, & inspiration
@unprocessyourfood | veg & vegan-friendly meals
2 pineapple rounds
1 inch of ginger
¼ cup of sparkling water
1. Chop up the pineapple and remove the rind from the rounds.
2. Turn the Juicer on. Place pineapple rounds in the Ingredient Tube and use the Pusher to push
the food through the tube.
3. Chop up the ginger and place it in the Ingredient Tube. Use the Pusher to push the ginger
through the Juicer.
4. Now pour the sparkling water through the Juicer, the water will help to get the juice out of the
Juicer. Serve and enjoy!
Maui
wowie
Ingredients:
Directions:
3 inch round of wheatgrass
2 large carrots
½ cup alfalfa sprouts
3 celery stalks
8 spinach leaves
1. Chop up the carrots and celery stalks into 1-1.5” pieces.
2. Turn the Juicer on. Place the ingredients in the Ingredient Tube one after another and use
the Pusher to push them through. Serve and enjoy!
Veggie
delight
Ingredients:
Directions:
2 pineapple rounds
1 inch of ginger
¼ cup of sparkling water
1. Chop up the pineapple and remove the rind from the rounds.
2. Turn the Juicer on. Place pineapple rounds in the Ingredient Tube and use the Pusher to push
the food through the tube.
3. Chop up the ginger and place it in the Ingredient Tube. Use the Pusher to push the ginger
through the Juicer.
4. Now pour the sparkling water through the Juicer, the water will help to get the juice out of the
Juicer. Serve and enjoy!
Maui
wowie
Ingredients:
Directions:
3 inch round of wheatgrass
2 large carrots
½ cup alfalfa sprouts
3 celery stalks
8 spinach leaves
1. Chop up the carrots and celery stalks into 1-1.5” pieces.
2. Turn the Juicer on. Place the ingredients in the Ingredient Tube one after another and use
the Pusher to push them through. Serve and enjoy!
Veggie
delight
Ingredients:
Directions:
1 orange
½ cup of raspberries
3 fresh mint leaves
1. Peel the orange and turn it into slices.
2. Turn the Juicer on. Place the orange pieces into the Ingredient Tube and use the Pusher to push the
food through the tube.
3. Place the raspberries into the Ingredient Tube and use the Pusher to push the fruit through the Juicer.
4. Put the mint leaves into the Ingredient Tube and use the Pusher to push the food through.
Serve and enjoy!
Sunshine
juice
Ingredients:
Directions:
Table of contents
Other Dash Juicer manuals
