Davey EcoSpa M7000AMP User manual
Please pass these instructions on to the operator of this equipment.
The installation of this product should be carried out by a person knowledgable in
spa pool plumbing requirements following the Installation Instructions provided in
this manual.
WARNING: Failure to follow these instructions and comply with all applicable
codes may cause serious bodily injury and/or property damage.
* Installation and operating instructions are included with the product when purchased new.
They may also be found on our website.
P/N MMAN010-3 supersedes MMAN010-2
AUSTRALIA
Davey Support Centre
6 Lakeview Drive,
Scoresby, Australia 3179
Ph: 1300 367 866
Fax: 1300 369 119
Website: davey.com.au
Davey Water Products Pty Ltd
Member of the GUD Group
ABN 18 066 327 517
NEW ZEALAND
Customer Service Centre
7 Rockridge Avenue,
Penrose, Auckland 1061
Ph: 0800 654 333
Fax: 09 527 7654
Website: daveynz.co.nz
® Davey is a registered trademark of Davey Water Products Pty Ltd.
© Davey Water Products Pty Ltd 2012.
Installation and
Operating Instructions
Salt Water Spa
Sanitisation System
EcoSpa™
2
11
Congratulations! You are now the proud owner of one of the most advanced
Electrolytic Spa Sanitising System in the world. Please read all information in this
instruction book carefully before installing or operating your EcoSpa™ System.
EcoSpa™ utilises low levels of pool salt at 2500ppm. This mild salt water in
conjunction with a small amount of EcoSpa™ activator enables the water to be
electrolysed using a safe and advanced electronic process to sanitise the water in
your spa. EcoSpa™ Systems comprise an advanced ORP controlled power supply
to operate a high quality reverse polarity (low maintenance) electrode enabling you
to choose the level of sanitiser you desire and constantly monitoring and maintaining
the level thereafter. EcoSpa™ is compatible with OzoMatic®Ozone Systems and is
suitable for inground and portable spas.
Contents
Packing List ............................................................................................................... 2
Important Notice ........................................................................................................ 3
Installation Instructions.............................................................................................. 4
Setting and Operating the Eco-SpaTM System......................................................... 6
Eco-SpaTM System Maintenance............................................................................. 7
Trouble Shooting Guide............................................................................................. 8
Davey Water Products Guarantee............................................................................. 9
Packing List
Please ensure your Eco-SpaTM includes the following components – contact your
supplier if unsure:
1 x Control Unit
1 x Electrolytic Cell including barrel unions
1 x Manifold for ORP Sensor Probe and Flow Sensor
1 x ORP Sensor Probe
1 x Flow Sensor/pressure switch
2 x Mounting Screws with wall plugs
1 x 100 gram Eco-SpaTM Bromine Activator Salt
10
3
IMPORTANT NOTICE
FACTORS THAT WILL IMPROVE THE PERFORMANCE & LIFE
OF YOUR SALT WATER BROMINATOR
PLEASE READ THIS BEFORE OPERATING YOUR BROMINATOR
There are THREE main factors that will damage your Brominator and reduce the life of the product.
Please monitor the following factors in accordance with your installation & operating instructions.
1. MAINTAIN OPTIMUM SALT LEVELS:
OPTIMUM SALT LEVEL: 2500ppm
5XQ%URPLQDWRUDWWKH6DOW/HYHOVVWDWHGZLWKLQWKLVGRFXPHQWWRHQVXUH
optimum sanitizer output and cell life.
2SHUDWLQJWKLVGHYLFHDWORZVDOWOHYHOVZLOOGDPDJHWKHFHOODQGUHGXFHLWVOLIH
7KHFRQWUROSDQHOGLVSOD\VUHG/('LQGLFDWRUZDUQLQJVZKHQWKHVDOWOHYHOVDUH
low.
,IQRDFWLRQLVWDNHQWRUHFWLI\WKHVDOWOHYHOVGDPDJHWRWKHFHOOPD\UHVXOW
which will not be covered under warranty.
2. MONITOR & MAINTAIN YOUR BROMINATOR CELL:
7RNHHS\RXUVDOWZDWHU%URPLQDWRULQWKHEHVWSRVVLEOHFRQGLWLRQUHJXODU
monitoring of the electrolytic cell is recommended. The ‘Cell’ is the clear
plastic housing located in the plumbing.
'XULQJWKH%URPLQDWLRQSURFHVVDZKLWHSRZGHU\&DOFLXPVFDOHPD\QDWXUDOO\
build up on the titanium plates in the cell. Monitor the cell to prevent excessive
scale build up. Excessive scale build up will cause
GDPDJHWR\RXUFHOODQGGUDPDWLFDOO\UHGXFHLWVHI¿FLHQF\DQGOLIHVSDQ
5HYHUVH3RODULW\PRGHOVDUHORZPDLQWHQDQFHPRGHOVWKDWPLQLPLVHVFDOH
build up.
,I&DOFLXPVFDOHGRHVEXLOGXSSOHDVHFOHDQWKHFHOOIROORZLQJWKHFOHDQLQJ
instructions provided on page 6.
NEVER: Use concentrated acid to clean your cell.
NEVER: Leave cell in cleaning solution for extended periods of time
NEVER:8VHPHWDOLPSOHPHQWVVFRXUHUVRUEUXVKHVWRFOHDQ\RXUFHOO
3. BALANCED POOL WATER CHEMISTRY:
6DOWOHYHOV0867EHPDLQWDLQHGDWSSPIRURSWLPXPSHUIRUPDQFHDQG
lifespan
&DOFLXP+DUGQHVVOHYHOVMUST be kept to ideal ranges of 200-275ppm (for
Concrete and Tiled Pools) and 100-225ppm (for other surfaces) to prevent
excessive scale build up and damage to equipment
S+OHYHOVMUST be kept to ideal levels to prevent damage to equipment and
pool surfaces and to obtain optimum sanitizer effectiveness (Refer to page 5).
7RWDO$ONDOLQLW\PXVWDOVREHNHSWLQDQLGHDOUDQJH5HIHUWRSDJH
NOTES
4
9
ECO-SPATM INSTALLATION INSTRUCTIONS
(Refer to diagram next page)
1. Please ensure the EcoSpa™ Control Unit is mounted a minimum of 3 metres
away from the spa water and 1.5 metres above ground level. For a portable
VSDWKH(FR6SDXQLWFDQEH¿WWHGRQWKHLQVLGHRIWKHVSDVXUURXQGSOHDVH
ensure easy access.
2. Select mounting point and mark 2 holes 18mm apart. (If the unit is to be
mounted to a brick or concrete wall use a masonry drill bit. Some walls such
DVOLPHVWRQHRUFHPHQWUHQGHUFDQGDPDJHDOXPLQLXPLILQGRXEWVHDOWKHZDOO
EHIRUHPRXQWLQJWKHFRQWUROXQLW'ULOOWKHKROHVDQG¿[VXLWDEOHVFUHZVWR
each hole. Recommended screws are 8 gauge.
+DQJXQLWYLDVORWVLQWKHWRSUHDUVHFWLRQRI(FR6SDXQLW1%7KHDGGLWLRQDO
mounting hole at the base of the EcoSpa™ can be used to help secure the unit.
4. Plug power plug from control unit into a suitable weatherproof power outlet.
(QVXUHDSSURSULDWH5&'VDIHW\GHYLFHLV¿WWHGWRPDLQVSRZHU'RQRWWXUQ
SRZHURQXQWLOLQVWDOODWLRQLVFRPSOHWH:KHQXVHGZLWKFRQWUROOHUSOXJLQWR
R]RQHSRVLWLRQDQGVHWGLSVZLWFKHV+,WR
5. Install Manifold for ORP Sensor Probe and Pressure Switch into spa return
line after the pump.
6. Plumb Electrolytic Cell into spa return line injection housing. Plug Cell
connector into the appropriate receptacle in the bottom of the unit. The Cell can
be installed vertically or horizontally. NOTE: ORP Sensor and pressure switch
0867EHLQVWDOOHGSULRUWRWKH&HOODQGDWOHDVWPP´IURPWKH&HOOLQOHW
preferably further away.
IMPORTANT NOTICE: For installations where manifold is not used, the pressure
switch must be installed at suitable point on spa return. If return does not
KDYHHQRXJKSUHVVXUH¿WWKHSUHVVXUHVZLWFKEHWZHHQSXPSUHWXUQDQG¿OWHU
7KHSUHVVXUHVZLWFKVKRXOGEHWDSSHGLQWRDSRLQWZKHUHWKHSLSHHQWHUVD¿W-
ting to allow a good thread length. Tap size is 1/8” NPT. Take care not to damage
threaded end and use thread tape for a good seal.
)LW2536HQVRU3UREHDWOHDVWPP´EHIRUH&HOO7R ¿W2536HQVRU3UREH
drill hole and tap with a 1/4” BSPF tap. This must be done carefully to ensure a
JRRGWKUHDGHG¿W6FUHZWKH2536HQVRU3UREHLQWRWKHSLSHZRUN1RWHWKDWLWLV
EHVWWR¿WWKH2536HQVRU3UREHLQWRD¿WWLQJHOERZFRXSOLQJHWFWRHQVXUHJRRG
thread length.
7. Connect the pressure switch to the EcoSpa™ Control Unit via the cable
terminated in two insulated pade connectors. Note that the pressure switch is
not waterproof and should not be exposed to the weather.
8. Connect ORP Sensor Probe to socket under EcoSpa™ Control Unit.
* Installation and operating instructions are included with the product when purchased new.
They may also be found on our website.
AUSTRALIA
Davey Support Centre
6 Lakeview Drive,
Scoresby, Australia 3179
Ph: 1300 367 866
Fax: 1300 369 119
Website: davey.com.au
Davey Water Products Pty Ltd
Member of the GUD Group
ABN 18 066 327 517
NEW ZEALAND
Customer Service Centre
7 Rockridge Avenue,
Penrose, Auckland 1061
Ph: 0800 654 333
Fax: 09 527 7654
Website: daveynz.co.nz
® Davey is a registered trademark of Davey Water Products Pty Ltd.
© Davey Water Products Pty Ltd 2012.
Davey®Repair or Replacement Guarantee
In the unlikely event in Australia or New Zealand that this Davey product develops any malfunction
within warranty periods beginning from the date of original purchase due to faulty materials or
manufacture, Davey will at our option repair or replace it for you free of charge, subject to the
conditions below.
Davey Guarantee Period
Control Box - Two Years Electrolytic Cell - Three Years ORP Probe - Three Years
Should you experience any difculties with your Davey product, we suggest in the rst instance
that you contact the Davey Dealer from which you purchased the Davey product. Alternatively
you can phone our Customer Service line on 1300 367 866 in Australia, or 0800 654 333 in New
Zealand, or send a written letter to Davey at the address listed below. On receipt of your claim,
Davey will seek to resolve your difculties or, if the product is faulty or defective, advise you on how
to have your Davey product repaired, obtain a replacement or a refund.
Your Davey Guarantee naturally does not cover normal wear or tear, replacement of product
consumables (i.e. mechanical seals, bearings or capacitors), loss or damage resulting from
misuse or negligent handling, improper use for which the product was not designed or advertised,
failure to properly follow the provided installation and operating instructions, failure to carry out
maintenance, corrosive or abrasive water or other liquid, lightning or high voltage spikes, or
unauthorized persons attempting repairs. Where applicable, your Davey product must only be
connected to the voltage shown on the nameplate.
Your Davey Guarantee does not cover freight or any other costs incurred in making a claim.
Please retain your receipt as proof of purchase; you MUST provide evidence of the date of original
purchase when claiming under the Davey Guarantee.
Davey shall not be liable for any loss of prots or any consequential, indirect or special loss,
damage or injury of any kind whatsoever arising directly or indirectly from Davey products. This
limitation does not apply to any liability of Davey for failure to comply with a consumer guarantee
applicable to your Davey product under the Australian or New Zealand legislation and does not
affect any rights or remedies that may be available to you under the Australian or New Zealand
Consumer Legislation.
In Australia, you are entitled to a replacement or refund for a major failure and for compensation for
any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major
failure.
Should your Davey product require repair or service after the guarantee period; contact your
nearest Davey Dealer or phone the Davey Support Centre on the number listed below.
For a complete list of Davey Dealers visit our website (davey.com.au) or call:
8
5
4. If you operate the EcoSpa in hard water (high calcium hardness) your cell
may build up excessive calcium scale. This can be easily removed by cleaning
LW7R FOHDQWKHFHOOWXUQRIIWKHEURPLQDWRUGLVFRQQHFWWKHFHOOOHDGVIURP
control box and unscrew the barrel unions from the plumbing. Add 1 part
+\GURFKORULF$FLGWRSDUWVZDWHULQDVXLWDEOHFRQWDLQHUDQGLPPHUVHWKH
cell in this solution. It should not take more than a few minutes to clean. While
the calcium is dissolving off the cell you will notice bubbles. When the bubbling
VWRSVWKHFHOOLVFOHDQ
$IWHUDIHZ\HDUVLQQRUPDOGRPHVWLFXVH\RXU(FR6SD(OHFWURO\WLFFHOOZLOO
require replacement. Contact your local Eco-Spa dealer for assistance.
TROUBLE SHOOTING GUIDE:
5HG³1R)ORZ´OLJKWLVRQEXWKDVZDWHUÀRZ
3LSHRU&HOOLVSDUWLDOO\EORFNHG
$GMXVWSUHVVXUHVZLWFKVHHDUURZVRQVLGHRISUHVVXUHVZLWFK
– lift lock at back)
2. No display:
0DLQSRZHURXWOHWVZLWFKHGRIIRU¿OWHUSXPSQRWUXQQLQJ
(FR6SD70QRWSOXJJHGLQWRPDLQRXWOHWRUPDLQRXWOHWSRZHURII
(FR6SDQRWSOXJJHGLQWRR]RQHRXWOHW
'LSVZLWFKHV+,QRWVHWUHIHUSDJHSRLQW
:KHQSXPSLVRII,ILQVWDOOHGZLWKDVSDFRQWUROOHUWKLVLVQRUPDO
3. Unsatisfactory Bromine Residuals:
)DXOW\RURXWRIGDWHWHVWNLW
253&RQWUROVHWWRRKLJKRUWRRORZ
2533UREHUHTXLUHVFOHDQLQJRUUHPRYDORIGHEULV
5XQQLQJWLPHVWRRORZRUEDWKHUORDGWRRKLJK
(FR6SD70%URPLQH$FWLYDWRU6DOWQRWDGGHG
WARNING: If Eco-SpaTM probe is disconnected or not properly connected to
control unit then your Eco-SpaTM will continue to produce Bromine and may reach
dangerous levels. Always ensure connections are intact and if cell power light is
continually on or you smell high bromine levels in the Spa turn off the Eco-SpaTM
and check the connections.
9. Add Eco-SpaTM Bromine Activator Salt at the rate of 50 grams per 1000 litres of
water. Add normal pool salt at the rate of 2.5kg per 1000 litres of water. Your
Eco-Spa is now ready to use and enjoy. Please note the Eco-SpaTM must be
SRZHUHGZKHQ¿OWHUSXPSLVUXQQLQJ
10. You must change the spa water regularly and add new Eco-SpaTM Bromine
Activator Salt and Pool Salt. The frequency of water changes will be affected
E\VSDXVHWKHPRUHWKHVSDLVXVHGWKHPRUHIUHTXHQWO\WKHZDWHUFKDQJHV
will be required.
For installations with a Davey Spa Power Controller:
7KHPDQLIROGVKRXOGEHORFDWHGDIWHUWKHVSDFRQWUROOHU
7KH(FR6SDPXVWEHSXUFKDVHGZLWKDVSHFLDO$03FRUGVHW
7KH$03SRZHUSOXJLVFRQQHFWHGWRWKH'DYH\VSDFRQWUROOHUYLDWKHRXWOHW
labelled “Ozone”.
7KH(FR6SDZLOOWKHQRSHUDWHZKLOHDSXPSLVFLUFXODWLQJZDWHUWKURXJKWKH
system.
Suggested Eco-SpaTM installation diagram follows, other cell installation
FRQ¿JXUDWLRQVDUHSRVVLEOH5HIHU\RXU(FR6SDTM dealer.
ECO-SPATM INSTALLATION VIEW
6
7
SETTING AND OPERATING THE ECO-SPA:
7RVHW\RXU(FR6SD¿UVWHQVXUHWKHS+DQG7RWDO$ONDOLQLW\SSP
are balanced then add bromine whilst the spa is running to reach a level of
4ppm Bromine. Verify this with a reliable test kit or seek the advice of your pool
& spa professional. Please note the above bromine levels are recommended by
Australian Standard AS 3633 for water above 26°C.
2. Once the desired level of bromine is reached turn the ORP Control knob slowly
clockwise or anti-clockwise as required until the ORP Redox LED indicator
indicates “Within Range” (green) and the Cell Power LED turns off. As an
alternative to the above procedure you can set the ORP control to vertical (this
is approximately 650mV) and run the spa until the ORP within range LED is on
and Cell Power is off. Check sanitiser levels and adjust ORP control to suit.
3. If a higher or lower bromine residual is required you can adjust the ORP Control
up or down (this should be done in small increments)
<RXU(FR6SDPXVWKDYHZDWHUÀRZWRRSHUDWH,WLVUHFRPPHQGHGWKDW\RXU
6SD¿OWUDWLRQV\VWHPPXVWUXQIRUDPLQLPXPRIWRKRXUVSHUGD\WRHQDEOH
the EcoSpa™ to maintain the required sanitiser level. Your EcoSpa™ has
a default setting via the controller of 2hrs and 40min run time per day. If the
QXPEHURISHRSOHRUWLPHLQWKH6SDLQFUHDVHVWKHQWKH¿OWUDWLRQWLPHUHTXLUHG
may be greater.
5. If the ORP (Redox) Within Range Green Led is not achieved during your daily
¿OWUDWLRQF\FOH\RXQHHGWRHLWKHULQFUHDVHWKH¿OWUDWLRQWLPHRUIROORZWKHWURXEOH
shooting procedures.
:KLOVWWKHSXPSLVRIIWKHUHZLOOEHQRÀRZDQGWKH5HG³1R)ORZ´/('ZLOOEH
OLW7KLVLVQRUPDOLQWKLVVWDWHWKH2535HGR[/('PD\LQGLFDWH³XQGHU´RU
“within range” or “over”. There is some overlap of the ORP (Redox) LED’s – it
is possible for the “Within Range” and “Over” or “Under” LED’s to be on at the
same time. (Only applicable to spa operations via controllers)
7. The green “Cell Power” LED will only operate when the system is actually
producing santiser.
8. If the Red “Add Salt” LED is on you need to check your spa salt level and add
WRDFKLHYH6DOWOHYHOWRDWOHDVWSSP)RUHDFKNJRIQRUPDOSRROVDOW
added you must add about 20 grams of EcoSpa™ Activator. The EcoSpa™
ORP system is reliant on the use of EcoSpa™ Bromine Activator Salt.
7KH$''6$/7,QGLFDWRULVDOVRDIIHFWHGE\ZDWHUWHPSHUDWXUHDVLV
the unit output. It is designed for operation around 35ºC (95ºF). If the spa
temperature is less then 35ºC you may require more Salt and EcoSpa™
Bromine Activator to turn off the ADD SALT indicator.
9. What is “ORP”? EcoSpa™ uses an ORP Sensor probe to determine whether
or not bromine needs to be produced by your EcoSpa™ to sanitise the spa.
ORP levels are measured in millivolts (mV). The ORP sensor probe does
QRWPHDVXUHWKHDFWXDOEURPLQHOHYHORI\RXUSRRO±UDWKHULWPHDVXUHVWKH
effectiveness of bromine to oxidise and kill biological contaminants.
It is possible for two spas with identical bromine residuals to have very different
ORP levels. This is due to the effectiveness of bromine in a spa being reliant on
RWKHUIDFWRUVVXFKDVS+VWDELOLVHUOHYHOV7RWDO'LVVROYHG6ROLGV7'6
combined bromine levels and temperature.
In general ORP will be affected in the following ways:
Chemical Level ORP Levels
Bromine UP UP
3+UP DOWN
3+DOWN UP
Combined Chlorine & Bromine UP DOWN
Total Dissolved Solids* UP DOWN
Temperature UP UP
10. Please note your EcoSpa™ Cell is a reverse polarity type designed to clean
itself periodically. To clean itself the EcoSpa™ will shut down for a few
minutes and then reverse the polarity of its cell plates. In extreme hard water
you may need to remove and clean the cell using 10 parts water to one part
+\GURFKORULF$FLG
EcoSpaTM SYSTEM MAINTENANCE:
5HJXODUO\FKHFNDQGEDODQFHS+DQG7RWDO$ONDOLQLW\XVLQJDUHOLDEOHWHVWNLWRU
WKHVHUYLFHVRI\RXUORFDOSRRODQGVSDSURIHVVLRQDO$FRUUHFWS+OHYHOPXVW
EHPDLQWDLQHGWRSUHYHQWSUREOHPVVXFKDVEODFNVSRWVWDLQLQJFORXG\ZDWHU
HWF$QLQFRUUHFWS+OHYHOFDQGDPDJHWKHVSD&RUUHFWOHYHOVDUHDVIROORZV
)LEUHJODVVWR2WKHUVSDVWR,I\RXDOORZWKHS+OHYHOWRULVH
WRRUDERYHWKHEURPLQHUHTXLUHGFRXOGEHPXFKPRUHWKDQWKHQRUPDO
DPRXQW7R ORZHUWKHS+OHYHODGGSRRODFLG7RUDLVHWKHS+DGG62',80
%,&$5%21$7(2562'$$6+7RWDO$ONDOLQLW\VKRXOGQRWEHFRQIXVHGZLWK
S+DOWKRXJKWKHWZRDUHFORVHO\UHODWHG7RWDO$ONDOLQLW\GHWHUPLQHVWKHVSHHG
DQGHDVHRIS+FKDQJH,WLVPHDVXUHGLQSSPWKHLGHDOUDQJHLV
SSPRUUHIHUWR\RXUSRROEXLOGHURUSRROVKRSIRUDGYLFH<RXVKRXOGXVH
DWHVWNLWZKLFKLQFOXGHVDWHVWIRU7RWDO$ONDOLQLW\/RZ7RWDO$ONDOLQLW\FDQ
FDXVHXQVWDEOHS+OHYHOVLHDQLQDELOLW\WRNHHSWKHS+FRQVWDQWPD\FDXVH
VWDLQLQJHWFKLQJDQGFRUURVLRQRIPHWDOV+LJK7RWDO$ONDOLQLW\ZLOOFDXVH
FRQVWDQWO\KLJKS+OHYHOV
:HUHFRPPHQGWKDW\RXFRPSOHWHO\GXPSUH¿OODQGUHEDODQFH\RXUVSDZDWHU
on a regular basis. The frequency of this operation will depend on spa usage.
Due to the use of recycling salts in the EcoSpa™ bromination process there
ZLOOQRWEHDEXLOGXSRIFKHPLFDOFDUULHUVRU¿OOHUV+RZHYHUVRPHRUJDQLFDQG
LQRUJDQLFFRQWDPLQDQWVIURPEDWKHUVZLOOEXLOGXSRYHUWLPHUHTXLULQJGXPSLQJ
of the spa water. Don’t forget to add the EcoSpa™ Activator Salt (50 grams
per 1000 litres) and pool salt (2.5kg per 1000 litres).
3. The EcoSpa™ ORP probe does not need to be cleaned when exposed to
normal spa use. It is recommended that the ORP probe be calibrated regularly
and inspected as per normal spa service cycle.
6
7
SETTING AND OPERATING THE ECO-SPA:
7RVHW\RXU(FR6SD¿UVWHQVXUHWKHS+DQG7RWDO$ONDOLQLW\SSP
are balanced then add bromine whilst the spa is running to reach a level of
4ppm Bromine. Verify this with a reliable test kit or seek the advice of your pool
& spa professional. Please note the above bromine levels are recommended by
Australian Standard AS 3633 for water above 26°C.
2. Once the desired level of bromine is reached turn the ORP Control knob slowly
clockwise or anti-clockwise as required until the ORP Redox LED indicator
indicates “Within Range” (green) and the Cell Power LED turns off. As an
alternative to the above procedure you can set the ORP control to vertical (this
is approximately 650mV) and run the spa until the ORP within range LED is on
and Cell Power is off. Check sanitiser levels and adjust ORP control to suit.
3. If a higher or lower bromine residual is required you can adjust the ORP Control
up or down (this should be done in small increments)
<RXU(FR6SDPXVWKDYHZDWHUÀRZWRRSHUDWH,WLVUHFRPPHQGHGWKDW\RXU
6SD¿OWUDWLRQV\VWHPPXVWUXQIRUDPLQLPXPRIWRKRXUVSHUGD\WRHQDEOH
the EcoSpa™ to maintain the required sanitiser level. Your EcoSpa™ has
a default setting via the controller of 2hrs and 40min run time per day. If the
QXPEHURISHRSOHRUWLPHLQWKH6SDLQFUHDVHVWKHQWKH¿OWUDWLRQWLPHUHTXLUHG
may be greater.
5. If the ORP (Redox) Within Range Green Led is not achieved during your daily
¿OWUDWLRQF\FOH\RXQHHGWRHLWKHULQFUHDVHWKH¿OWUDWLRQWLPHRUIROORZWKHWURXEOH
shooting procedures.
:KLOVWWKHSXPSLVRIIWKHUHZLOOEHQRÀRZDQGWKH5HG³1R)ORZ´/('ZLOOEH
OLW7KLVLVQRUPDOLQWKLVVWDWHWKH2535HGR[/('PD\LQGLFDWH³XQGHU´RU
“within range” or “over”. There is some overlap of the ORP (Redox) LED’s – it
is possible for the “Within Range” and “Over” or “Under” LED’s to be on at the
same time. (Only applicable to spa operations via controllers)
7. The green “Cell Power” LED will only operate when the system is actually
producing santiser.
8. If the Red “Add Salt” LED is on you need to check your spa salt level and add
WRDFKLHYH6DOWOHYHOWRDWOHDVWSSP)RUHDFKNJRIQRUPDOSRROVDOW
added you must add about 20 grams of EcoSpa™ Activator. The EcoSpa™
ORP system is reliant on the use of EcoSpa™ Bromine Activator Salt.
7KH$''6$/7,QGLFDWRULVDOVRDIIHFWHGE\ZDWHUWHPSHUDWXUHDVLV
the unit output. It is designed for operation around 35ºC (95ºF). If the spa
temperature is less then 35ºC you may require more Salt and EcoSpa™
Bromine Activator to turn off the ADD SALT indicator.
9. What is “ORP”? EcoSpa™ uses an ORP Sensor probe to determine whether
or not bromine needs to be produced by your EcoSpa™ to sanitise the spa.
ORP levels are measured in millivolts (mV). The ORP sensor probe does
QRWPHDVXUHWKHDFWXDOEURPLQHOHYHORI\RXUSRRO±UDWKHULWPHDVXUHVWKH
effectiveness of bromine to oxidise and kill biological contaminants.
It is possible for two spas with identical bromine residuals to have very different
ORP levels. This is due to the effectiveness of bromine in a spa being reliant on
RWKHUIDFWRUVVXFKDVS+VWDELOLVHUOHYHOV7RWDO'LVVROYHG6ROLGV7'6
combined bromine levels and temperature.
In general ORP will be affected in the following ways:
Chemical Level ORP Levels
Bromine UP UP
3+UP DOWN
3+DOWN UP
Combined Chlorine & Bromine UP DOWN
Total Dissolved Solids* UP DOWN
Temperature UP UP
10. Please note your EcoSpa™ Cell is a reverse polarity type designed to clean
itself periodically. To clean itself the EcoSpa™ will shut down for a few
minutes and then reverse the polarity of its cell plates. In extreme hard water
you may need to remove and clean the cell using 10 parts water to one part
+\GURFKORULF$FLG
EcoSpaTM SYSTEM MAINTENANCE:
5HJXODUO\FKHFNDQGEDODQFHS+DQG7RWDO$ONDOLQLW\XVLQJDUHOLDEOHWHVWNLWRU
WKHVHUYLFHVRI\RXUORFDOSRRODQGVSDSURIHVVLRQDO$FRUUHFWS+OHYHOPXVW
EHPDLQWDLQHGWRSUHYHQWSUREOHPVVXFKDVEODFNVSRWVWDLQLQJFORXG\ZDWHU
HWF$QLQFRUUHFWS+OHYHOFDQGDPDJHWKHVSD&RUUHFWOHYHOVDUHDVIROORZV
)LEUHJODVVWR2WKHUVSDVWR,I\RXDOORZWKHS+OHYHOWRULVH
WRRUDERYHWKHEURPLQHUHTXLUHGFRXOGEHPXFKPRUHWKDQWKHQRUPDO
DPRXQW7R ORZHUWKHS+OHYHODGGSRRODFLG7RUDLVHWKHS+DGG62',80
%,&$5%21$7(2562'$$6+7RWDO$ONDOLQLW\VKRXOGQRWEHFRQIXVHGZLWK
S+DOWKRXJKWKHWZRDUHFORVHO\UHODWHG7RWDO$ONDOLQLW\GHWHUPLQHVWKHVSHHG
DQGHDVHRIS+FKDQJH,WLVPHDVXUHGLQSSPWKHLGHDOUDQJHLV
SSPRUUHIHUWR\RXUSRROEXLOGHURUSRROVKRSIRUDGYLFH<RXVKRXOGXVH
DWHVWNLWZKLFKLQFOXGHVDWHVWIRU7RWDO$ONDOLQLW\/RZ7RWDO$ONDOLQLW\FDQ
FDXVHXQVWDEOHS+OHYHOVLHDQLQDELOLW\WRNHHSWKHS+FRQVWDQWPD\FDXVH
VWDLQLQJHWFKLQJDQGFRUURVLRQRIPHWDOV+LJK7RWDO$ONDOLQLW\ZLOOFDXVH
FRQVWDQWO\KLJKS+OHYHOV
:HUHFRPPHQGWKDW\RXFRPSOHWHO\GXPSUH¿OODQGUHEDODQFH\RXUVSDZDWHU
on a regular basis. The frequency of this operation will depend on spa usage.
Due to the use of recycling salts in the EcoSpa™ bromination process there
ZLOOQRWEHDEXLOGXSRIFKHPLFDOFDUULHUVRU¿OOHUV+RZHYHUVRPHRUJDQLFDQG
LQRUJDQLFFRQWDPLQDQWVIURPEDWKHUVZLOOEXLOGXSRYHUWLPHUHTXLULQJGXPSLQJ
of the spa water. Don’t forget to add the EcoSpa™ Activator Salt (50 grams
per 1000 litres) and pool salt (2.5kg per 1000 litres).
3. The EcoSpa™ ORP probe does not need to be cleaned when exposed to
normal spa use. It is recommended that the ORP probe be calibrated regularly
and inspected as per normal spa service cycle.
8
5
4. If you operate the EcoSpa in hard water (high calcium hardness) your cell
may build up excessive calcium scale. This can be easily removed by cleaning
LW7R FOHDQWKHFHOOWXUQRIIWKHEURPLQDWRUGLVFRQQHFWWKHFHOOOHDGVIURP
control box and unscrew the barrel unions from the plumbing. Add 1 part
+\GURFKORULF$FLGWRSDUWVZDWHULQDVXLWDEOHFRQWDLQHUDQGLPPHUVHWKH
cell in this solution. It should not take more than a few minutes to clean. While
the calcium is dissolving off the cell you will notice bubbles. When the bubbling
VWRSVWKHFHOOLVFOHDQ
$IWHUDIHZ\HDUVLQQRUPDOGRPHVWLFXVH\RXU(FR6SD(OHFWURO\WLFFHOOZLOO
require replacement. Contact your local Eco-Spa dealer for assistance.
TROUBLE SHOOTING GUIDE:
5HG³1R)ORZ´OLJKWLVRQEXWKDVZDWHUÀRZ
3LSHRU&HOOLVSDUWLDOO\EORFNHG
$GMXVWSUHVVXUHVZLWFKVHHDUURZVRQVLGHRISUHVVXUHVZLWFK
– lift lock at back)
2. No display:
0DLQSRZHURXWOHWVZLWFKHGRIIRU¿OWHUSXPSQRWUXQQLQJ
(FR6SD70QRWSOXJJHGLQWRPDLQRXWOHWRUPDLQRXWOHWSRZHURII
(FR6SDQRWSOXJJHGLQWRR]RQHRXWOHW
'LSVZLWFKHV+,QRWVHWUHIHUSDJHSRLQW
:KHQSXPSLVRII,ILQVWDOOHGZLWKDVSDFRQWUROOHUWKLVLVQRUPDO
3. Unsatisfactory Bromine Residuals:
)DXOW\RURXWRIGDWHWHVWNLW
253&RQWUROVHWWRRKLJKRUWRRORZ
2533UREHUHTXLUHVFOHDQLQJRUUHPRYDORIGHEULV
5XQQLQJWLPHVWRRORZRUEDWKHUORDGWRRKLJK
(FR6SD70%URPLQH$FWLYDWRU6DOWQRWDGGHG
WARNING: If Eco-SpaTM probe is disconnected or not properly connected to
control unit then your Eco-SpaTM will continue to produce Bromine and may reach
dangerous levels. Always ensure connections are intact and if cell power light is
continually on or you smell high bromine levels in the Spa turn off the Eco-SpaTM
and check the connections.
9. Add Eco-SpaTM Bromine Activator Salt at the rate of 50 grams per 1000 litres of
water. Add normal pool salt at the rate of 2.5kg per 1000 litres of water. Your
Eco-Spa is now ready to use and enjoy. Please note the Eco-SpaTM must be
SRZHUHGZKHQ¿OWHUSXPSLVUXQQLQJ
10. You must change the spa water regularly and add new Eco-SpaTM Bromine
Activator Salt and Pool Salt. The frequency of water changes will be affected
E\VSDXVHWKHPRUHWKHVSDLVXVHGWKHPRUHIUHTXHQWO\WKHZDWHUFKDQJHV
will be required.
For installations with a Davey Spa Power Controller:
7KHPDQLIROGVKRXOGEHORFDWHGDIWHUWKHVSDFRQWUROOHU
7KH(FR6SDPXVWEHSXUFKDVHGZLWKDVSHFLDO$03FRUGVHW
7KH$03SRZHUSOXJLVFRQQHFWHGWRWKH'DYH\VSDFRQWUROOHUYLDWKHRXWOHW
labelled “Ozone”.
7KH(FR6SDZLOOWKHQRSHUDWHZKLOHDSXPSLVFLUFXODWLQJZDWHUWKURXJKWKH
system.
Suggested Eco-SpaTM installation diagram follows, other cell installation
FRQ¿JXUDWLRQVDUHSRVVLEOH5HIHU\RXU(FR6SDTM dealer.
ECO-SPATM INSTALLATION VIEW
4
9
ECO-SPATM INSTALLATION INSTRUCTIONS
(Refer to diagram next page)
1. Please ensure the EcoSpa™ Control Unit is mounted a minimum of 3 metres
away from the spa water and 1.5 metres above ground level. For a portable
VSDWKH(FR6SDXQLWFDQEH¿WWHGRQWKHLQVLGHRIWKHVSDVXUURXQGSOHDVH
ensure easy access.
2. Select mounting point and mark 2 holes 18mm apart. (If the unit is to be
mounted to a brick or concrete wall use a masonry drill bit. Some walls such
DVOLPHVWRQHRUFHPHQWUHQGHUFDQGDPDJHDOXPLQLXPLILQGRXEWVHDOWKHZDOO
EHIRUHPRXQWLQJWKHFRQWUROXQLW'ULOOWKHKROHVDQG¿[VXLWDEOHVFUHZVWR
each hole. Recommended screws are 8 gauge.
+DQJXQLWYLDVORWVLQWKHWRSUHDUVHFWLRQRI(FR6SDXQLW1%7KHDGGLWLRQDO
mounting hole at the base of the EcoSpa™ can be used to help secure the unit.
4. Plug power plug from control unit into a suitable weatherproof power outlet.
(QVXUHDSSURSULDWH5&'VDIHW\GHYLFHLV¿WWHGWRPDLQVSRZHU'RQRWWXUQ
SRZHURQXQWLOLQVWDOODWLRQLVFRPSOHWH:KHQXVHGZLWKFRQWUROOHUSOXJLQWR
R]RQHSRVLWLRQDQGVHWGLSVZLWFKHV+,WR
5. Install Manifold for ORP Sensor Probe and Pressure Switch into spa return
line after the pump.
6. Plumb Electrolytic Cell into spa return line injection housing. Plug Cell
connector into the appropriate receptacle in the bottom of the unit. The Cell can
be installed vertically or horizontally. NOTE: ORP Sensor and pressure switch
0867EHLQVWDOOHGSULRUWRWKH&HOODQGDWOHDVWPP´IURPWKH&HOOLQOHW
preferably further away.
IMPORTANT NOTICE: For installations where manifold is not used, the pressure
switch must be installed at suitable point on spa return. If return does not
KDYHHQRXJKSUHVVXUH¿WWKHSUHVVXUHVZLWFKEHWZHHQSXPSUHWXUQDQG¿OWHU
7KHSUHVVXUHVZLWFKVKRXOGEHWDSSHGLQWRDSRLQWZKHUHWKHSLSHHQWHUVD¿W-
ting to allow a good thread length. Tap size is 1/8” NPT. Take care not to damage
threaded end and use thread tape for a good seal.
)LW2536HQVRU3UREHDWOHDVWPP´EHIRUH&HOO7R ¿W2536HQVRU3UREH
drill hole and tap with a 1/4” BSPF tap. This must be done carefully to ensure a
JRRGWKUHDGHG¿W6FUHZWKH2536HQVRU3UREHLQWRWKHSLSHZRUN1RWHWKDWLWLV
EHVWWR¿WWKH2536HQVRU3UREHLQWRD¿WWLQJHOERZFRXSOLQJHWFWRHQVXUHJRRG
thread length.
7. Connect the pressure switch to the EcoSpa™ Control Unit via the cable
terminated in two insulated pade connectors. Note that the pressure switch is
not waterproof and should not be exposed to the weather.
8. Connect ORP Sensor Probe to socket under EcoSpa™ Control Unit.
* Installation and operating instructions are included with the product when purchased new.
They may also be found on our website.
AUSTRALIA
Davey Support Centre
6 Lakeview Drive,
Scoresby, Australia 3179
Ph: 1300 367 866
Fax: 1300 369 119
Website: davey.com.au
Davey Water Products Pty Ltd
Member of the GUD Group
ABN 18 066 327 517
NEW ZEALAND
Customer Service Centre
7 Rockridge Avenue,
Penrose, Auckland 1061
Ph: 0800 654 333
Fax: 09 527 7654
Website: daveynz.co.nz
® Davey is a registered trademark of Davey Water Products Pty Ltd.
© Davey Water Products Pty Ltd 2012.
Davey®Repair or Replacement Guarantee
In the unlikely event in Australia or New Zealand that this Davey product develops any malfunction
within warranty periods beginning from the date of original purchase due to faulty materials or
manufacture, Davey will at our option repair or replace it for you free of charge, subject to the
conditions below.
Davey Guarantee Period
Control Box - Two Years Electrolytic Cell - Three Years ORP Probe - Three Years
Should you experience any difculties with your Davey product, we suggest in the rst instance
that you contact the Davey Dealer from which you purchased the Davey product. Alternatively
you can phone our Customer Service line on 1300 367 866 in Australia, or 0800 654 333 in New
Zealand, or send a written letter to Davey at the address listed below. On receipt of your claim,
Davey will seek to resolve your difculties or, if the product is faulty or defective, advise you on how
to have your Davey product repaired, obtain a replacement or a refund.
Your Davey Guarantee naturally does not cover normal wear or tear, replacement of product
consumables (i.e. mechanical seals, bearings or capacitors), loss or damage resulting from
misuse or negligent handling, improper use for which the product was not designed or advertised,
failure to properly follow the provided installation and operating instructions, failure to carry out
maintenance, corrosive or abrasive water or other liquid, lightning or high voltage spikes, or
unauthorized persons attempting repairs. Where applicable, your Davey product must only be
connected to the voltage shown on the nameplate.
Your Davey Guarantee does not cover freight or any other costs incurred in making a claim.
Please retain your receipt as proof of purchase; you MUST provide evidence of the date of original
purchase when claiming under the Davey Guarantee.
Davey shall not be liable for any loss of prots or any consequential, indirect or special loss,
damage or injury of any kind whatsoever arising directly or indirectly from Davey products. This
limitation does not apply to any liability of Davey for failure to comply with a consumer guarantee
applicable to your Davey product under the Australian or New Zealand legislation and does not
affect any rights or remedies that may be available to you under the Australian or New Zealand
Consumer Legislation.
In Australia, you are entitled to a replacement or refund for a major failure and for compensation for
any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major
failure.
Should your Davey product require repair or service after the guarantee period; contact your
nearest Davey Dealer or phone the Davey Support Centre on the number listed below.
For a complete list of Davey Dealers visit our website (davey.com.au) or call:
Rainbow Pool Products
PO Box 2388, Mansfield Qld 4122
Telephone STD 61-7-3849 5385
Facsimile STD 61-7-3849 5384
Email: [email protected]
Web: www.rainbowpoolproducts.com.au
This manual suits for next models
1
Table of contents
