DaVinci Birch Log Set
Installation Instructions (sku#94500977)

Page 1 of 22 17602180 — 8/21/20 © Travis Industries, Inc.
Compatibility
All DaVinci Fireplaces
Overview
This log set supplies everything needed to install in all CAT1 fireplaces (2’, 3’, 4’, and 5’, lengths). For CAT2+ fireplaces,
purchase one additional log set kit for every additional 5’ or less of length.
Example:
18’ DaVinci would use four log set kits (3 kits for the first 15’ using the 5’ setup for each, and one additional kit using the 3’
templates and setup).
NOTE: For 2’, 3’, 4’ foot lengths not all of the included logs and stones are used. Unused logs and stones may be discarded.
Table of Contents
Compatibility...........................................................................................................................................................................1
Overview.................................................................................................................................................................................1
PackingList..............................................................................................................................................................................2
Templates...............................................................................................................................................................................3
ToolsRequired........................................................................................................................................................................3
InstallationNotes....................................................................................................................................................................3
2’Fireplace..............................................................................................................................................................................4
2’Fireplace‐PreparingtheMediaTray..............................4
2’Fireplace‐Overview:......................................................4
2’Fireplace‐LogInstallation..............................................5
3’Fireplace..............................................................................................................................................................................8
3’Fireplace‐PreparingtheMediaTray..............................8
3’Fireplace‐Overview:......................................................8
3’Fireplace‐LogInstallation..............................................9
4’Fireplace..............................................................................................................................................................................12
4’Fireplace‐PreparingtheMediaTray..............................12
4’Fireplace‐Overview:......................................................12
4’Fireplace‐LogInstallation..............................................13
5’Fireplace..............................................................................................................................................................................17
5’Fireplace‐PreparingtheMediaTray..............................17
5’Fireplace‐Overview:......................................................17
5’Fireplace‐LogInstallation..............................................18
ReplacementPartNumbers....................................................................................................................................................22



DaVinci Birch Log Set
Installation Instructions (sku#94500977)

Page 2 of 22 17602180 — 8/21/20 © Travis Industries, Inc.
Packing List
Log #1 (1) - Log #2 (1)-
Log #3 (1) - Log #4 (1) -
Log #5 (1) - Log #6 (1) -
Log #7 (1) -
Log #8 (1) -
Log #9 (1) -
Stone #10 (2) -
Stone #13 (2) - Stone #32 (1) -
Stone #35 (1) -
Log Placement Plates (3) -
Log Locating Pins (3) -
Screws #8x1” Tek Wafer
head Phillips (3) -
See “Templates” on the next page.


DaVinci Birch Log Set
Installation Instructions (sku#94500977)

Page 3 of 22 17602180 — 8/21/20 © Travis Industries, Inc.
Templates
2’ Fireplace Template
3’ Fireplace Template
4’ Fireplace Template
5’ Fireplace Template
Tools Required
Screw gun with Phillips Screw Bit
Installation Notes
WARNINGS:
Make sure the gas control valve is OFF and the heater is cool prior to conducting service.
Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved
with this appliance may result in property damage or personal injury.
HINTS:
The fireplace should be in place, with the gas line and vent attached and the firebacks installed (see owner’s
manual for further details).
ORDER OF INSTALLATION:
Place the template/s on the burner.
Secure log placement plates to the media tray.
Remove the template/s.
Dress the burner with crushed glass or rock embers.
Place the logs and stones as shown in this instruction sheet.
Return the fireplace to the proper configuration.
22


DaVinci Birch Log Set
Installation Instructions (sku#94500977)

Page 4 of 22 17602180 — 8/21/20 © Travis Industries, Inc.
2’ Fireplace
2’ Fireplace - Preparing the Media Tray
1. Remove the glass to gain access to the firebox (see manual for details).
2. Place the 2’ Fireplace template on the burner as shown below.
NOTE: The holes in the template rest over the raised cluster of burner holes on each burner.
NOTE: Make sure the “L” and “R” are properly oriented, not reversed (if the letter is formed backward, turn the template
over).
3. Place the log placement plates in the punched out areas in the template that match their shape.
4. Secure the log placement plates to the media tray with the included screws.
5. Remove the template and dress the burner with crushed glass or rock embers (see appliance manual for details).
Do not overtighten the screws when securing the log placement plates to the media tray.
2’ Fireplace - Overview:
Logs used for this installation: #1, #2, #5, #6, #7
Stones used for this installation: #10, #13, #35
2L2R


DaVinci Birch Log Set
Installation Instructions (sku#94500977)

Page 5 of 22 17602180 — 8/21/20 © Travis Industries, Inc.
2’ Fireplace - Log Installation
The logs are fragile, especially after being exposed to heat.
Install Log #1 as shown below. The pin on the leftmost log locating plate inserts into the hole on the bottom of the
log (use the hole indicated below).
NOTE: Make sure the knot in the log is pointing to the left.
Install Log #7 as shown below. Place the hole in the bottom of Log #7 on the right log locating plate (the charred
end of the log should face the left as shown).


DaVinci Birch Log Set
Installation Instructions (sku#94500977)

Page 6 of 22 17602180 — 8/21/20 © Travis Industries, Inc.
2’ Fireplace - Log Installation - continued
Install Log #5 as shown below. Place the wider end of the log #5 on charred portion of Log #1. Log #5 spans the
burner and the thinner, charred end is angled to the right and rests on the media tray.
NOTE:Whenalogplacementrequiresthelogtospantheburner,make
surethepartofthelogabovetheburnerisnotdirectlyabovea
clusterofholes(seeillustrationbelow).

Install one of the included log locating pins into the leftmost hole on the top of log #5 as shown below.


DaVinci Birch Log Set
Installation Instructions (sku#94500977)

Page 7 of 22 17602180 — 8/21/20 © Travis Industries, Inc.
2’ Fireplace - Log Installation - continued
Install Log #6 as shown below. Place the hole in the bottom of Log #6 on the log locating pin installed on Log #5 in
the previous step. The other end of log #6 rests on log #1, just to the left of the knot.
Install stone #35 as shown below. Make sure the stone does not rest over the burner.
Lift the charred left end of log #7 and install stone #13 under it as shown below.
NOTE: The right end of the log will still rest on the media tray.
Install stone #10 as shown below. Make sure the stone does not rest over the burner.
Restsonlog
Restsonpin


DaVinci Birch Log Set
Installation Instructions (sku#94500977)

Page 8 of 22 17602180 — 8/21/20 © Travis Industries, Inc.
3’ Fireplace
3’ Fireplace - Preparing the Media Tray
1. Remove the glass to gain access to the firebox (see manual for details).
2. Place the 3’ Fireplace template on the burner as shown below.
NOTE: 3’ unit uses (2) templates, left and right.
NOTE: The holes in the template rest over the raised cluster of burner holes on each burner.
NOTE: Make sure the “L” and “R” are properly oriented, not reversed (if the letter is displayed backward or upside down,
reposition the template until it is correct).
3. Place the log placement plates in the punched out areas in the template that match their shape.
4. Secure the log placement plates to the media tray with the included screws.
5. Remove the templates and dress the burner with crushed glass or rock embers (see appliance manual for details).
Do not overtighten the screws when securing the log placement plates to the media tray.
3’ Fireplace - Overview:
Logs used for this installation: #1, #2, #4, #6, #7, #9
Stones used for this installation: #10, #13, #13
3L3R


DaVinci Birch Log Set
Installation Instructions (sku#94500977)

Page 9 of 22 17602180 — 8/21/20 © Travis Industries, Inc.
3’ Fireplace - Log Installation
The logs are fragile, especially after being exposed to heat.
Install Log #2 as shown below. The pin on the right log locating plate inserts into the hole on the bottom of the log
(use the hole indicated below).
Install Log #1 as shown below. The pin on the upper left log locating plate inserts into the hole on the bottom of the
log (use the hole indicated below).
Install two of the included log locating pins into the 4
th
hole from the left and the 4
th
hole from the right of the top of
log #2 as shown below.


DaVinci Birch Log Set
Installation Instructions (sku#94500977)

Page 10 of 22 17602180 — 8/21/20 © Travis Industries, Inc.
3’ Fireplace - Log Installation – continued
Install Log #7 as shown below. The pin on the lower left log locating plate inserts into the hole on the bottom of
the log and the charred (right) end of the log rests on the end of log #2.
Install Log #6 as shown below. The log-locating pin on the left of Log #1 inserts into the hole on the bottom of log
#6. Log #6 spans the burner.


NOTE:Whenalogplacementrequiresthelogtospantheburner,make
surethepartofthelogabovetheburnerisnotdirectlyaboveaclusterof
holes(seeillustrationbelow).


InstallLog#8asshownbelow.Thelog‐locatingpinontherightofLog#2insertsintotheholeonthebottomoflog#8.Log
#8spanstheburnerandanglestotheleft(seebelow).


DaVinci Birch Log Set
Installation Instructions (sku#94500977)

Page 11 of 22 17602180 — 8/21/20 © Travis Industries, Inc.
3’ Fireplace - Log Installation - continued
Install stone #13 as shown below. Slide the stone right until it makes contact with the end of log #7
NOTE: The right end of the log will rest on log# 2.


Install stone #10 as shown below.



Install the other #13 stone as shown below. Make sure the stone does not rest over the burner.



Install log #9 as shown below. The thicker end should be to the right and rest on the media tray. The left end
rests on stone #13




DaVinci Birch Log Set
Installation Instructions (sku#94500977)

Page 12 of 22 17602180 — 8/21/20 © Travis Industries, Inc.
4’ Fireplace
4’ Fireplace - Preparing the Media Tray
1. Remove the glass to gain access to the firebox (see manual for details).
2. Place the 4’ Fireplace templates on the burner as shown below.
NOTE: 4’ unit uses (2) templates, left and right.
NOTE: The holes in the templates rest over the raised cluster of burner holes on each burner.
NOTE: Make sure the “L” and “R” are properly oriented, not reversed (if the letter is displayed backward or upside down,
reposition the template until it is correct).
3. Place the log placement plates in the punched out areas in the template that match their shape.
4. Secure the log placement plates to the media tray with the included screws.
5. Remove the templates and dress the burner with crushed glass or rock embers (see appliance manual for details).
Do not overtighten the screws when securing the log placement plates to the media tray.
4’ Fireplace - Overview:
Logs used for this installation: #1, #2, #3, #5, #6, #9
Stones used for this installation: #10, #13, #13, #32, #35
4L4R


DaVinci Birch Log Set
Installation Instructions (sku#94500977)

Page 13 of 22 17602180 — 8/21/20 © Travis Industries, Inc.
4’ Fireplace - Log Installation
The logs are fragile, especially after being exposed to heat.
Install Log #2 as shown below. The pin on the right log locating plate inserts into the hole on the bottom of the log
(use the hole indicated below).

Install Log #1 as shown below. The pin on the upper left log locating plate inserts into the hole on the bottom of the
log (use the hole indicated below).

Install Log #3as shown below. The log rests on the upper right-hand pin on the media tray and the knot points to
the right.






DaVinci Birch Log Set
Installation Instructions (sku#94500977)

Page 14 of 22 17602180 — 8/21/20 © Travis Industries, Inc.
4’ Fireplace - Log Installation - continued
Install(2)oftheincludedlogplacementpinsintothefarleftholesonbothendsoflog#2



Install(1)oftheincludedlogplacementpinsintotheholesecondfromtherightonlog#1



Install log #8 as shown below. The pin on log #1 inserts into the hole on the bottom of log #8. Log #8 spans the
burner and the right end angles approximately 45° downward and toward the right (see below).



NOTE: When a log placement requires the log to span the burner,
make sure the part of the log above the burner is not directly above
a cluster of holes (see illustration below).
Install Log #5 as shown below. The log-locating pin on the left of Log #2 inserts into the hole on the bottom of log
#5. Log #5 spans the burner and angles upward and to the right (see below).





DaVinci Birch Log Set
Installation Instructions (sku#94500977)

Page 15 of 22 17602180 — 8/21/20 © Travis Industries, Inc.
4’ Fireplace - Log Installation - continued
Installlog#6asshownbelow.Therightpinonlog#2insertsintotheholeonthethickerendoflog#6.Theotherendof
log#6restsontheleftendoflog#3(nopin).Log#6anglestotheleftandspanstheburner.Makesurethelogisnotover
theclusterofholesontheburner.



Installstone#10totheleftoflog#1asshownbelow.




Installstone#13asshownbelow.










DaVinci Birch Log Set
Installation Instructions (sku#94500977)

Page 16 of 22 17602180 — 8/21/20 © Travis Industries, Inc.
4’ Fireplace - Log Installation – continued

Installstone32asshownbelow.






Installstone35asshownbelow.




Installtheotherstone#13asshownbelow.




Installlog#9asshownbelow.Thethickerendoflog#9restsonthemediatrayandtherightendrestsonstone#13.





DaVinci Birch Log Set
Installation Instructions (sku#94500977)

Page 17 of 22 17602180 — 8/21/20 © Travis Industries, Inc.
5’ Fireplace
5’ Fireplace - Preparing the Media Tray
1. Remove the glass to gain access to the firebox (see manual for details).
2. Place the 5’ Fireplace template on the burner as shown below (start with the left end, then rotate the template and use
it for the right end).
NOTE: 5’ unit uses (1) template in two different positions (left & right). Make sure the “L” is closer to you when the
template is on the left side of the burner and the “R” is closer to you when the template is on the right side of the
burner.
NOTE: The holes in the template rest over the raised cluster of burner holes on each burner.
NOTE: Make sure the “L” and “R” are properly oriented, not reversed (if the letter is formed backward, turn the template
over).
3. Place the log placement plates in the punched out areas in the template that match their shape.
NOTE: The right side only uses (1) of the log placement plates. Install the plate only in the furthest right hole in the
template.
4. Secure the log placement plates to the media tray with the included screws.
5. Rotate the template 180° and place it on the other end of the burner (double-check the orientation of the letter in the
lower corner)
6. Secure the remaining log placement plate to the media tray with the included screw.
7. Remove the template and dress the burner with crushed glass or rock embers (see appliance manual for details).
Do not overtighten the screws when securing the log placement plates to the media tray.
Left Side Right Side
5’ Fireplace - Overview:
Logs used for this installation: #1, #2, #3, #4, #5, #6 #7, #8, #9
Stones used for this installation: #10, #10 #13, #13 #32, #35
5R
5L
5L5R


DaVinci Birch Log Set
Installation Instructions (sku#94500977)

Page 18 of 22 17602180 — 8/21/20 © Travis Industries, Inc.
5’ Fireplace - Log Installation
The logs are fragile, especially after being exposed to heat.
Install Log #2 as shown below. The pin on the left log locating plate inserts into the hole on the bottom of the log
(use the hole indicated below).
Install log #1 as shown below. The pin on the upper right log locating plate inserts into the hole on the bottom of
the log (use the hole indicated below).
Install log #7 as shown below. The pin on the upper left log locating plate inserts into the hole on the bottom of
the log. The charred end of log #7 points to the right.
Install (2) of the included log locating pins into the 4
th
hole from the left and the 4
th
hole from the right of the top of
log #2 as shown below.



DaVinci Birch Log Set
Installation Instructions (sku#94500977)

Page 19 of 22 17602180 — 8/21/20 © Travis Industries, Inc.
5’ Fireplace - Log Installation - continued
Install Log #5 as shown below. Place the wider end of the log #5 on charred portion of Log #1. Log #5 spans the
burner and the thinner, charred end is angled to the left and rests on the media tray.



NOTE:Whenalogplacementrequiresthelogtospantheburner,make
surethepartofthelogabovetheburnerisnotdirectlyaboveaclusterof
holes(seeillustrationbelow).

Install log #8 as shown below. The pin on log #2 inserts into the hole on the bottom of log #8. The left end rests
on log #7 (no pin). Log #8 spans the burner (see below).



Install log #3 as shown below. The left pin on log #2 inserts into the hole on the bottom of log #3. The thicker end
of the log rests on the media tray. Log #3 spans the burner and angles to the left (see below). 




DaVinci Birch Log Set
Installation Instructions (sku#94500977)

Page 20 of 22 17602180 — 8/21/20 © Travis Industries, Inc.
5’ Fireplace - Log Installation - continued
Install stone #13 as shown below. Slide the stone to the right until it contacts the left end of log #2.
Install stone #10 as shown below.
Install stone #35 as shown below. Make sure the stone does not obstruct the burner.
Install stone #32 as shown below.
