SimpliFire • SF-WM36, SF-WM58, SF-WM70, SF-WM94 Service Manual • 2040-908 Rev. D • 1/19
SERVICE MANUAL
(Power Cord, Stones, Fan Box, Glass Front, Mounting Bracket, Screen & Flame Rod)
Model: SF-WM36, SF-WM58, SF-WM70, SF-WM94
- Instructions -
CAUTION! Risk of Cuts, Abrasions or Flying Debris.
Wear protective gloves and safety glasses during
installation and service. Sheet metal edges are sharp.
Leave this manual with party responsible for use
and operation.
WARNING: If the information in these
instructions is not followed exactly it
may result in personal injury and/or prop-
erty damage.
NOTICE! DO NOT discard this manual. Important service
and maintenance instructions included.
Tools and Supplies Needed
Before beginning the installation be sure that the following
tools and building supplies are available.
Pliers
Phillips screwdriver
Electric drill and bits (1/4 in.)
Flat blade screwdriver
Replacement Instructions
Power Input Cord Installation
1. Switch the main switch control on the right corner of
the appliance to the OFF position.
2. Unplug the power input cord from the wall receptacle.
3. Locate power input cord connection located on the
lower right corner of the appliance.
4. Remove one screw and metal strain relief bracket.
See Figure 1 (SF-WM36) and Figure 2 (SF-WM58 &
SF-WM70).
5. Unplug cord from appliance.
6. Install new cord on appliance and install metal
strain relief bracket with one screw. See Figure 1
(SF-WM36) and Figure 2 (SF-WM58 & SF-WM70).
7. Plug cord into wall receptacle.
Figure 1 (SF-WM36) Power Input Cord and Strain Relief
Bracket on Lower Right of Appliance
NOTICE! DO NOT discard any hardware while
servicing. It must be reused.
Figure 2 (SF-WM58 & SF-WM70) Power Input Cord and
Strain Relief Bracket on Lower Right of Appliance
WARNING! Risk of Shock! Always unplug the
cord before moving or servicing.

SimpliFire • SF-WM36, SF-WM58, SF-WM70, SF-WM94 Service Manual • 2040-908 Rev. D • 1/192
2
1
Secure with
Screw Here
Figure 3 Attaching Fireplace to Bracket
Faux Stone Installation
Arrange the white and clear faux stones along the inset
window ledge at the front of the rebox. Place clear
stones over LED bulbs and ll remaining gaps with white
stones.
Glass Front Installation
1. Remove Glass Front from appliance. Remove
two retaining screws that connect the mounting
brackets on the glass front to the top corners of
the appliance. Pull gently on the bottom of the glass
panel to disengage the plug connectors on the
bottom corners of the appliance. When the plug
connectors are disengaged, lift up on the glass front
to disengage the hanging brackets from the top
corners of the appliance. Set the glass front aside in
a safe location. See Figure 13.
2. Install glass front as shown in Figure 3. Engage tabs
on rear face of glass with the slots in the top of the
appliance. Install glass front so that the tabs on its
back side engage the slots in the top of the appli-
ance. Once both tabs engage, press rmly against
the bottom face of the glass panel to engage
the bottom connectors.
3. Secure the glass front to the appliance with two
screws (removed in step 1) through the two glass
front mounting brackets on the top of the appliance.
See Figure 3.
Figure 4 Bracket Screws
REMOVE SCREWS REMOVE SCREWS
Screen Installation
1. Switch the main switch control on the right corner of
the appliance to the OFF position.
2. Unplug the power input cord from the wall receptacle.
3. Remove Glass Front. Refer to Glass Front Installa-
tion instructions.
4. Remove four screws, two screws on each side of the
appliance. See Figure 4.
6. Remove the side brackets on the appliance. See
Figure 5.
Right side
slides out
from under
the frame.
Left side lifts
up from the
frame.
Figure 5 Side Bracket Removal
7. Locate the four tabs at the top of the appliance frame
holding the screen into place.
8. Using a at screwdriver, lift tabs into an upright posit-
ion to release the screen. See Figure 6.
Lift Tabs (with
screwdriver
into an upright
position to
release the
screen.
TAB DETAIL
TABS SECURING SCREEN
Figure 6 Side Bracket Removal

3
SimpliFire • SF-WM36, SF-WM58, SF-WM70, SF-WM94 Service Manual • 2040-908 Rev. D • 1/19
7. Remove the screen by lifting a corner and working it
out of the top of the appliance chassis. See Figure 7.
Figure 7 Screen Removal
8. Lift the screen out of the bottom of the appliance.
9. Replace the screen with the replacement screen.
10. Reverse steps of the Screen Replacement Instruct-
ions to secure the screen in the appliance.
11. Install the Glass Front. See the Glass Front Installa-
tion Instructions.
Flame Rod Installation
1. Switch the main switch control on the right corner of
the appliance to the OFF position.
2. Unplug the power input cord from the wall receptacle.
3. Remove Glass Front. Refer to Glass Front Installa-
tion instructions.
4. Remove Screen. Refer to Screen Installation
instructions.
Figure 8 Flame Rod
FLAME ROD
5. Remove screw in the center bracket that is holding
the Flame Rod in place. See Figure 9.
Figure 9 Center Bracket - Flame Rod
REMOVE SCREW
6. Pull out the black rubber end of the Flame Rod
located on the right side of the appliance. See Figure
10.
Figure 10 Black Rubber End of Flame Rod
BLACK RUBBER
END OF FLAME ROD
6. Remove Flame Rod from appliance. See Figure 11.
Figure 11 Remove Flame Rod
7. Replace the Flame Rod with the replacement.
8. Reverse steps of the Flame Rod Installation instruc
tons.
10. Reverse steps of the Screen Replacement Instruct-
ions to secure the screen in the appliance.
11. Install the Glass Front. See the Glass Front Installa-
tion Instructions.

SimpliFire • SF-WM36, SF-WM58, SF-WM70, SF-WM94 Service Manual • 2040-908 Rev. D • 1/194
Figure 14 Fan Box Fasteners
5. Remove four screws that attach fan box to the bottom
of the appliance. As the screws are removed,
support the weight of the module. See Figure 14 and
15.
Figure 15 Support Fan Box while accessing Electrical
Connector
6. Locate and unplug the electrical connector on the
bottom of the appliance. See Figure 16.
Figure 16 Electrical Connector lower right of Appliance
Fan Box Installation
(Not applicable for SF-WM36)
1. Switch the main switch control on the right corner of
the appliance to the OFF position.
2. Unplug the power input cord from the wall receptacle.
3. Locate lighting LED wire harness connector on
bottom of Glass Front. Disconnect it from the
appliance. See Figure 12.
Figure 12 Lighting LED Connection
CAUTION! Glass Front is heavy. Handle with Care.
4. Remove Glass Front from appliance. Remove
two retaining screws that connect the mounting
brackets on the glass front to the top corners of
the appliance. Pull gently on the bottom of the glass
panel to disengage the plug connectors on the
bottom corners of the appliance. When the plug
connectors are disengaged, lift up on the glass front
to disengage the hanging brackets from the top
corners of the appliance. Set the glass front aside in
a safe location. See Figure 13.
2
1
Remove
Screw Here
Figure 12 Removing Front to Fireplace

5
SimpliFire • SF-WM36, SF-WM58, SF-WM70, SF-WM94 Service Manual • 2040-908 Rev. D • 1/19
7. Locate replacement fan box. Plug the electrical
connector into the bottom of the appliance.
8. Locate the fan box to the bottom of the appliance so
that the fastener holes align.
9. Install all four screws between the fan box and the
appliance.
10. Install the glass front on appliance. Engage the tabs
on the two hanging brackets with the slots in the top
corner of the appliance. Push against the bottom
of the Glass Front to engage the plug connectors.
Install the two retainer screws between the Glass
Front mounting brackets and the appliance.
11. Connect the lighting LED harness to the appliance
harness.
Figure 17 (SF-WM36) Mounting Bracket
= Required Mounting Points
Wall Mounting Bracket
The wall mounting bracket must be used to mount the
appliance. This appliance must be mounted to a structur-
al wall capable of bearing a 40 pound load for SFWM36,
85 pound load for SF-WM58, 110 pound load for
SF-WM70, 135 pound load for SF-WM94.
Determine the desired location of the appliance on the
wall. Place the wall mounting bracket in the desired
location. Ensure that the bracket is level. Mark all loca-
tions on the wall that correspond to the required mounting
points in the bracket. See Figure 17 (SF-WM36),
Figure 18 (SF-WM58), Figure 19 (SF-WM70) or Figure
20 (SF-WM94).
Orientate the bracket so that its mounting hooks are
pointing up as shown in Figure 17 (SF-WM36), Figure
18 (SF-WM58), Figure 19 (SF-WM70) or Figure 20
(SFWM94). Fasten the bracket to the wall. The bracket
installation method varies depending on the wall con-
struction
Figure 18 (SF-WM58) Mounting Bracket
16 in. 16 in.
= Required Mounting Points
Note: For non-masonry walls, at least two mounting
points (screws 5x40) must align with a structural
framing member.
Figure 19 (SF-WM70) Mounting Bracket
= Required Mounting Points
Note: For non-masonry walls, at least two mounting
points (screws 5x40) must align with a structural
framing member.
Figure 20 (SF-WM94) Mounting Bracket
= Required Mounting Points
Note: For non-masonry walls, at least two mounting
points (screws 5x40) must align with a structural
framing member.
16 in. 16 in. 16 in.
16 in. 16 in. 16 in. 16 in.

SimpliFire • SF-WM36, SF-WM58, SF-WM70, SF-WM94 Service Manual • 2040-908 Rev. D • 1/196
Wall
Masonry Anchors
Figure 21 (SF-WM36) Masonry Anchor Placement
Figure 25 (SF-WM36) Bracket Attachment
Wall Mount Bracket Installation
The wall mounting bracket can be installed on masonry
walls such as those constructed of brick or concrete,
or to framed walls constructed of wood or steel framing
sheathed with gypsum drywall, wood, etc. The method
used to mount the mounting bracket is different between
masonry walls and framed walls. Refer to the following
sections for more detail on the method applicable to this
installation.
Masonry Wall
• In the marked locations, drill 5/16 in. diameter x 2
in. deep holes. See Figure 21 (SF-WM36), Figure
22 (SF-WM58), Figure 23 (SF-WM70) or Figure 24
(SF-WM94).
• Insert the provided wall anchors into the holes.
• Gently tap the anchors with a hammer until they are
ush with the wall surface.
• With mounting hooks pointed up, attach the bracket
to the masonry anchors with 6 x 50 screws . See
Figure 25 (SF-WM36), Figure 26 (SF-WM58), Figure
27 (SF-WM70) or Figure 28 (SF-WM94).
WARNING! Risk of Damage or Personal Injury! Do
not use supplied masonry anchors on hollow walls,
sheathed with wood, sheetrock, drywall or other materi-
als.
Mounting Hooks
Point Up
Wall
Masonry Anchors
Figure 22 (SF-WM58) Masonry Anchor Placement
Wall
Masonry Anchors
Figure 23 (SF-WM70) Masonry Anchor Placement
Wall
Masonry Anchors
Figure 24 (SF-WM94) Masonry Anchor Placement

7
SimpliFire • SF-WM36, SF-WM58, SF-WM70, SF-WM94 Service Manual • 2040-908 Rev. D • 1/19
Figure 26 (SF-WM58) Bracket Attachment
Mounting Hooks
Point Up
Note: For non-masonry walls,
at least two anchor points
(screws 6x50) must align with
structural framing member.
Figure 27 (SF-WM70) Bracket Attachment
Mounting Hooks
Point Up
Note: For non-masonry walls,
at least four anchor points
(screws 6x50) must align with
structural framing member.
Figure 28 (SF-WM94) Bracket Attachment
Mounting Hooks
Point Up
Note: For non-masonry walls,
at least six anchor points
(screws 6x50) must align with
structural framing member.
Figure 29 3/16 Toggle-Bolt Anchor
WARNING! Risk of Damage or Personal Injury! Al-
lowable pull-out and shear strength are 25% of ultimate
values or less, as required by building authorities.
The wall mounting bracket can be installed on masonry
walls such as those constructed of brick or concrete,
or to framed walls constructed of wood or steel framing
sheathed with gypsum drywall, wood, etc. The method
used to mount the mounting bracket is different between
masonry walls and framed walls. Refer to the following
sections for more detail on the method applicable to this
installation.
Framed Wall
• For each of the marked anchor point locations, de-
termine which points align with a structural framing
member.
• At the points where a wood or metal framing mem-
ber exists, the 6 x 50 screw can be installed directly
into that structural member.
• Every mounting hole that does not align with a
structural framing member, a wall board toggle-bolt
anchor must be used. See Figure 29.
• The toggle-bolt anchors are provided to accomodate
the required anchor points based on the appliance.
Use of toggle bolt anchors requires drywall thickness
of minimum 1/2 in.
• Insert the bolt through the front side of the mounting
bracket and thread the toggle onto it from the rear of
the bracket. See Figure 30.
• Fold the toggle wings  ush against the bolt and
push them through a drilled hole until they expand
open on the other side. See Figure 31.
• Pull back on the bolt and tighten. See Figure 31.
Note: This product cannot be installed on a wall
sheathed with drywall less than 1/2 in. thick, unless
all six anchor points in the mounting bracket align
with structural framing members.

SimpliFire • SF-WM36, SF-WM58, SF-WM70, SF-WM94 Service Manual • 2040-908 Rev. D • 1/198
SimpliFire, a brand of Hearth & Home Technologies
7571 215th Street West, Lakeville, MN 55044
www.hearthnhome.com
Figure 30 Toggle Bolt Installation through Mounting Bracket
Figure 31 Installing Anchors in Hollow Wall
Please contact the SimpliFire customer/technical
support hotline at 877-320-0730 with any questions
or concerns.
