Davis Instruments DRIVERIGHT 600 User manual

®
Product # 8156GD, 8156HD, 8156VSS & 8156VF
DR600B Cover D004.fm Page 1 Wednesday, March 26, 2003 9:52 AM

Product Numbers: 8156GD, 8156HD, 8156VSS & 8156VF
Davis Instruments Part Number: 7395.192
DriveRight 600 User’s Guide
Rev. B Manual (March 26, 2003)
© Davis Instruments Corp. 2002-2003. All rights reserved.
This product complies with the essential protection requirements of the EC EMC Directive 89/336/
EC.
DriveRight is a registered trademark of Davis Instruments Corp. Windows is a trademark of Microsoft
Corporation.
One Year Limited Warranty
We warrant our products to be free of defects in material and workmanship for one year from date of origi-
nal purchase. We make every effort to carefully manufacture our products to the highest standards of qual-
ity. Occasionally, however, parts may be missing, defective, or damaged.
If you have a defective part, please call 1-510-732-7814 for authorization before returning the item for repair
or replacement. Upon receiving authorization, return the product to us, shipping charges prepaid. Include
proof of purchase and a written explanation of the problem. During the warranty period, we will, at our
option, either repair or replace the product free of charge.
This warranty does not cover damage due to improper installation or use, negligence, accident, unautho-
rized service, or the incidental or consequential damages beyond the Davis products themselves. Implied
warranties are limited in duration to the life of this limited warranty. Some states do not allow limitations on
how long an implied warranty lasts, or the exclusion or limitation of incidental and consequential damages,
so the above limitations may not apply to you. This warranty gives you specific legal rights. You may have
other rights, which vary from state to state.
FCC Part 15 Class B Registration Warning
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful inter-
ference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the
equipment on and off, the user is encouraged to try to correct the interference by one or more of the follow-
ing measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is con-
nected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved in writing by Davis Instruments may void the user's
authority to operate this equipment.
DR600B Cover D004.fm Page 2 Wednesday, March 26, 2003 9:52 AM

i
TABLE OF CONTENTS
INTRODUCTION TO THE DRIVERIGHT 600 .........................................................1
A Note About the Concept of “Trips“ ...........................................................................1
A Word About Safe Use ..............................................................................................1
DriveRight Vehicle Management Software .................................................................2
USING THE DRIVERIGHT 600 ...........................................................................3
Using the Four Buttons ...............................................................................................3
Changing Units of Measure ........................................................................................3
The Data Screens .......................................................................................................4
The Settings Screens .................................................................................................5
CALIBRATING THE DRIVERIGHT 600 ................................................................6
Calibrating from the Software (VSS & VF Only) .........................................................6
Calibration Using the Speedometer ............................................................................6
Calibration Using the Odometer .................................................................................8
DATA SCREENS ............................................................................................10
Current Readings Screen .........................................................................................10
Driver ID Code Entry & Digital Input Status Screen ..................................................11
Driver ID Code ..........................................................................................................12
Two Digital Inputs .....................................................................................................13
Activity Indicator ........................................................................................................13
Trip Start/End Log Screen ........................................................................................13
Trip Speed and Distance Log Screen .......................................................................14
Trip Acceleration/Deceleration Log Screen ..............................................................15
GPS Latitude and Longitude Position Screens .........................................................16
Odometer Screen .....................................................................................................17
Limits Screen ............................................................................................................17
SETTINGS SCREENS ......................................................................................18
Security Code Screen ...............................................................................................18
Clear Log Screen ......................................................................................................19
Alarm On/Off Screen ................................................................................................20
Calibration Screen ....................................................................................................21
Limit and Unit Settings Screen .................................................................................21
Time Entry ................................................................................................................22
Date Entry .................................................................................................................22
Year Entry .................................................................................................................23

ii
MISCELLANEOUS INFORMATION .....................................................................23
Accident Log .............................................................................................................23
Tamper Log ..............................................................................................................24
Battery Operation ......................................................................................................24
Battery Life ...............................................................................................................26
Display Lamp ............................................................................................................26
Restarting the DriveRight 600 ...................................................................................26
TROUBLESHOOTING GUIDE ...........................................................................27
Contacting Davis Technical Support .........................................................................29
TECHNICAL SPECIFICATIONS .........................................................................30

1
INTRODUCTION TO THE DRIVERIGHT 600
The DriveRight 600, in conjunction with the DriveRight Vehicle Man-
agement Software, provides advanced vehicle safety and use monitor-
ing capabilities as well as comprehensive fleet management
capabilities. This manual explains how to use the DriveRight 600 dis-
play unit to view information.
NOTE: Altering the DriveRight 600’s limits, deleting trip information, and
calibrating the DriveRight 600 require entry of a security code
before changes may be made.
A Note About the Concept of “Trips“
Much of the data stored and displayed by the DriveRight 600 is stored
and displayed by “trip.” For example, you may view the maximum
speed or the time spent driving over the set speed limit during a single
trip. You may page back and forth through all of the trips stored in the
DriveRight 600’s memory.
Stored in the DriveRight 600 is a “trip stop time” which represents the
amount of time for which the vehicle must be stopped before the Driv-
eRight 600 ends the current trip. The default trip stop time is 5 minutes
(this setting may be altered using the DriveRight Vehicle Management
Software). Whenever the vehicle is not in motion for an amount of time
equal to the trip stop time, the DriveRight 600 saves the current trip
data to memory and begins a new trip (this new trip will remain blank
until the vehicle begins moving again).
NOTE: The DriveRight 600 also saves the current trip data whenever a
driver “logs out” (see “Driver ID Code Entry & Digital Input Status
Screen” on page 11).
A Word About Safe Use
It goes without saying that you should never attempt to change the
DriveRight 600 display while you are driving. Safe driving requires
extreme attentiveness. Changing the DriveRight 600 display while
driving may result in dangerous distraction. Only use the unit when
you are not operating your vehicle.
In addition, always warn drivers about the DriveRight 600’s alarms. If
an alarm sounds, a driver who has not been warned may be startled or
get distracted trying to trace the source of the noise. In either case, it
may create a safety concern, so warn drivers in advance.
DR600 UG Rev B D008.fm Page 1 Thursday, April 17, 2003 7:17 AM

2
DriveRight Vehicle Management Software
The DriveRight Vehicle Management Software enables more
detailed tracking of vehicle usage and access to some additional fea-
tures of the DriveRight 600. The following is a list of the DriveRight
600 features which may only be accessed using the software.
❏View information contained in the “accident log”
❏View tamper information
❏Enter or change the odometer reading or the odometer read-
ing’s unit of measure
❏Set login alarm
❏Set trip stop time
❏Download up to 100 authorized driver ID codes.
❏View trip type information
Although you may specify the type of trip using the Driv-
eRight 600 display unit, you must have the software to
view trip type information.
❏Configure GPS
Requires optional DriveRight 600 GPS module, #8157.
DR600 UG Rev B D008.fm Page 2 Thursday, April 17, 2003 7:17 AM

3
USING THE DRIVERIGHT 600
This section briefly describes the use of the DriveRight 600 display
unit. The use of the four buttons (PLUS, MINUS, MODE, SET/
CLEAR) and the sequence of data screens and settings screens is
explained. Descriptions of the information and options available from
each screen are explained separately in “Data Screens” starting on
page 10 and “Settings Screens” starting on page 18.
Using the Four Buttons
The DriveRight 600 has four buttons: PLUS, MINUS, MODE, and
SET/CLEAR. The general use of each button is explained briefly
below:
❏PLUS/MINUS
When a digit or segment (e.g., MPH or KPH) is flashing, use
the PLUS and MINUS keys to scroll forward or backward
(respectively) through the available options (usually 0 to 9).
When viewing any logged trip information screen, use the PLUS
and MINUS keys to page forward or backward (respectively)
through the stored trips.
❏SET/CLEAR
When entering codes or setting limits, the flashing digit/seg-
ment indicates what will change if PLUS or MINUS is
pressed. Pressing and releasing SET/CLEAR causes the next
digit/segment to begin flashing.
From the Driver ID Code screen, press and hold SET/CLEAR (for
at least 2 seconds) to “log out.” The driver ID code is reset to 0000.
❏MODE
Press and release MODE to move to the next data or informa-
tion screen.
Press and hold MODE to switch between the group of data screens
and the group of settings screens.
When the unit is in sleep mode, press MODE to “wake” the unit up.
Changing Units of Measure
To change units of measure, press and hold SET/CLEAR for at least 2
seconds while viewing the Current Readings screen. You may also
change units from the Limit and Units Settings screen by pressing
SET/CLEAR until either the km/h or MPH segment is flashing, and
then pressing PLUS to toggle between the two units of measure.
You may change the date display format from the Date Entry screen
and the time display format from the Time Entry screen.
DR600 UG Rev B D008.fm Page 3 Thursday, April 17, 2003 7:17 AM

4
The Data Screens
The data screens enable you to view most of the information stored
by the DriveRight 600. To cycle through the data screens (in the
order shown below), press and release MODE.
NOTE: To view the settings screens, press and hold MODE until the
Security Code Entry screen appears.
NOTE: The GPS Latitude and Longitude screens are not displayed if
the DriveRight console is not connected to a vehicle.
DriveRight 600 Data Screens
D A Y . M O
D A Y . M O
k m / h
SP EE D
A CC E L
G
D I S T A N C E
K m
C U RR E N T
Current Readings
Odometer
K m
Trip Speed and Distance Log
k m / h
SP EE D
O V E R
T I M E
SP EE D
S ec .
D I S T A N C E
K m
L OG
D I S T A N C E
A CC E L
C O U N T
D E C E L
C O U N T
L OG
Trip Acceleration/Deceleration Log
E ND
S T AR T
P M
P M
L OG
Trip Start/End Log
T O T A L
H r .
D A Y . M O
k m / h
A CC E L
G
G
D E C E L
S E TT I N G S
SP
EE D
Limits
GPS Latitude and Longitude
Driver ID Entry
C O D E
D A Y . M O
DR600 UG Rev B D008.fm Page 4 Thursday, April 17, 2003 7:17 AM

5
The Settings Screens
To access the settings screens, press and hold MODE while viewing any
of the data screens. After a few seconds, the Security Code screen will
appear. To cycle through the settings screens (in the order shown below),
press and release MODE.
NOTE: To view the data screens, press and hold MODE until the Current
Readings screen appears.
DriveRight 600 Settings Screens
C O D E
S E TT I N G S
A L AR M
S E TT I N G S
C L E AR L OG
S E TT I N G S
Alarm On/Off
Security Code
Clear Log
A M
S E TT I N G S
D A Y . M O
S E TT I N G S
Y E AR
S E TT I N G S
Date Entry
Year Entry
Time Entry
k m / h
SP EE D
A CC E L
G
G
D E C E L
S E TT I N G S
Limit and Units Settings
k m / h
SP EE D
K m
S E TT I N G S
Calibration
DR600 UG Rev B D008.fm Page 5 Thursday, April 17, 2003 7:17 AM

6
CALIBRATING THE DRIVERIGHT 600
You must calibrate the unit before it will report the correct speed,
distance, deceleration, and acceleration. Calibration adjusts the unit
to work properly with your vehicle’s VSS signal or with the vehi-
cle’s differential and tire size.
Calibrating from the Software (VSS & VF Only)
If you have the DriveRight Fleet Management Software or DriveRi-
ght Vehicle Management Software and a VSS or VF DriveRight 600,
you may quickly and accurately calibrate the unit using the soft-
ware, provided you know the pulses per mile used by your vehicle’s
VSS (vehicle speed sensor).
❏Contact your dealer’s service department for the pulses per
mile used by your vehicle’s VSS.
❏Instructions on calibrating the DriveRight 600 using the soft-
ware can be found in the software help.
Calibration Using the Speedometer
In order to calibrate using the speedometer, you must drive steadily
at 40 km/h (25 MPH) and press a button on the DriveRight 600. The
DriveRight 600 bases its calibration on the speed of the vehicle at the
moment of calibration which it assumes to be 40 km/h (25 MPH).
Because of the nature of this calibration procedure, we strongly rec-
ommend that it be performed by two people: one to drive the vehi-
cle and one to operate the DriveRight 600.
NOTE: If you have entered a security code, you will need to enter that
code before the DriveRight 600 will allow access to the calibra-
tion screen.
1. Press and hold MODE to access the settings screens.
2. Press and release MODE until the Calibration screen appears.
The calibration speed (40 or 25) appears at the bottom right of the dis-
play. The uncalibrated speed reading appears at the top of the display,
along with the unit of measure (km/h or MPH). Note that until you
calibrate the DriveRight 600 this speed reading will be inaccurate.
The distance, which appears in the lower left of the display, is not nec-
essary for this calibration procedure
DR600 UG Rev B D008.fm Page 6 Thursday, April 17, 2003 7:17 AM

7
.
Calibration Screen
3. Drive the vehicle until you reach 40 km/h (25 MPH) and keep the
vehicle steady at that speed.
4. Once the vehicle is moving steadily at the calibration speed, press
and hold SET/CLEAR.
The word CAL appears in the top right of the display when you press
SET/CLEAR. This indicates that the unit is in the process of calibrating.
Unit Calibrating
5. Continue to hold SET/CLEAR until the unit beeps and the word
“DONE” appears on the display.
This indicates that the unit has finished calibrating. The speed reading at
the top of the display will also change so that it reads much closer to
your speedometer’s reading.
Unit Finished Calibrating
k m / h
M P H
SP EE D
D
I S T A N C E
M I L E S
K m
S E TT I N G S
Speed Reading
Distance Reading Calibration Speed
k m / h
SP EE D
D
I S T A N C E
K m
S E TT I N G S
Unit Calibrating
k m / h
SP EE D
D
I S T A N C E
K m
S E TT I N G S
Unit Finished Calibrating
DR600 UG Rev B D008.fm Page 7 Thursday, April 17, 2003 7:17 AM

8
6. Once the calibration is complete, drive the vehicle and compare
the vehicle’s speedometer to the DriveRight 600’s speed display.
Be aware that the DriveRight 600 responds to changes in speed faster
than most vehicles’ speedometers. To accurately compare, you must
drive steadily at a speed for a short time.
7. If necessary, “fine tune” the calibration by pressing PLUS or
MINUS.
Each time you press PLUS or MINUS, the DriveRight 600 speed
reading adjusts up or down. Depending on the speed of the vehicle
and the calibration, you may or may not see a change in the speed
reading in the calibration screen each time you press the button.
NOTE: Pressing and holding PLUS or MINUS down
increases the rate at which the DriveRight 600
adjusts the speed reading.
8. Continue to Press PLUS or MINUS until the DriveRight 600’s
speed reading agrees with your vehicle’s speedometer at a variety
of speeds.
9. When finished calibrating, press and hold MODE until you return
to the data screen.
When you finish fine-tuning, press MODE to exit the calibration
screen. All information will be automatically saved. Do not press and
hold SET/CLEAR in an effort to save the fine-tuned calibration! If you
press and hold SET/CLEAR, the unit completely resets the calibration
number.
Calibration Using the Odometer
In order to calibrate using the odometer, you must compare a dis-
tance reading taken from your vehicle’s odometer to the DriveRight
600 and adjust the DriveRight 600 to match the vehicle’s odometer.
Depending on how far you drive in order to calibrate the unit, this
can result in an extremely accurate calibration.
NOTE: We recommend that you drive a minimum of 32km (20 miles)
when calibrating the unit.
Your vehicle’s speedometer and odometer may not be perfectly
linked. If they differ and you calibrate your DriveRight 600 using
the vehicle’s odometer, you may notice a discrepancy between the
DriveRight 600’s speed readings and the vehicle’s speedometer.
1. Obtain a rough calibration, using the speedometer as described in
“Calibration Using the Speedometer” on page 6.
2. Reset your vehicle’s trip meter to zero or make a note of the
odometer reading.
DR600 UG Rev B D008.fm Page 8 Thursday, April 17, 2003 7:17 AM

9
3. Make sure you have a new trip started on the DriveRight 600 (i.e.,
the distance travelled is 0.
To forcibly start a new trip, log out (see page 14 for details).
4. Drive the vehicle for at least 32 km (20 miles).
The further you drive, the more accurate your calibration.
5. When you finish driving, compare your vehicle’s trip meter reading
to the distance travelled reading on the DriveRight 600.
At this point, what you will need to do is increase or decrease the dis-
tance measured by the DriveRight 600 until it agrees with your vehicle’s
odometer reading. This is accomplished from the calibration screen.
6. Press and hold MODE to access the settings screens.
7. Press and release MODE until the Calibration screen appears.
The distance travelled appears at the lower left of the display. Note that
until you calibrate the DriveRight 600, this distance reading will be inac-
curate. The speed reading and calibration speed, which appear on the
display as well, are not necessary for this calibration procedure.
Calibration Screen
8. Press PLUS or MINUS until the distance reading matches the trip
meter on your vehicle.
Depending on how many miles you drove, you may need to press PLUS
or MINUS several times before the distance reading changes.
NOTE: Pressing and holding PLUS/MINUS down increases the rate at
which the DriveRight 600 adjusts the distance reading.
9. When finished calibrating, press and hold MODE until you return
to the data screen.
Press MODE to exit the calibration screen. All information will be auto-
matically saved. Do not press and hold SET/CLEAR in an effort to save
the fine-tuned calibration! If you press and hold SET/CLEAR, the unit
completely resets the calibration number.
k m / h
M P H
SP EE D
D
I S T A N C E
M I L E S
K m
S E TT I N G S
Speed Reading
Distance Reading Calibration Speed
DR600 UG Rev B D008.fm Page 9 Thursday, April 17, 2003 7:17 AM

10
DATA SCREENS
The following section explains all the information and options avail-
able in the various data screens. In addition to the options listed in
the individual sections below, in every screen you have the follow-
ing two options:
❏Move to the next Data Screen
Press and release MODE.
❏View the Settings Screens
Press and hold MODE.
Current Readings Screen
The current readings screen displays constantly updating (as long as
the car is moving) speed, distance (for the current trip), and acceler-
ation/deceleration readings (acceleration is positive, deceleration is
negative). The current date (or time) is also displayed on this screen.
Current Readings Screen
You have the following options from the Current Readings Screen:
❏Toggle Between Date and Time Display
You may display either the date or the time. To toggle
between the two, press and release SET/CLEAR.
❏Change Units of Measure
To change the units of measure in which data is displayed
from metric to U.S. units (or vice versa), press and hold
SET/CLEAR for approximately 2 seconds. This does not
change the date or time display format.
❏Specify Trip Type
There are four types of trips stored by the DriveRight 600:
Business, Personal, Commute, and Other. The trip type is
stored along with the rest of the trip information and is
automatically saved when information is downloaded
using the software.
k m / h
SP EE D
A CC E L
G
D I S T A N C E
K m
C U RR E N T
Current Speed Date (or Time)
Distance Travelled
on Current Trip
Current Acceleration
(or Deceleration)
D A Y . M O
DR600 UG Rev B D008.fm Page 10 Thursday, April 17, 2003 7:17 AM

11
NOTE: Although you may specify the type of trip using the
DriveRight 600 display unit, you must have the soft-
ware to view trip type information.
To change the type of trip, press and hold MINUS. The trip type
screen will appear--do not release MINUS.
Trip Type Screen
As long as you hold MINUS, the DriveRight 600 will cycle through
the letters representing the various trip types: b = Business, P = Per-
sonal, C = Commute, O = Other. Release MINUS when the desired
trip type appears.
NOTE: You may change the trip type anytime during a trip.
Trip type information is saved when the trip ends.
❏Turn Display Lamp On/Off
To turn the DriveRight 600’s display lamp on or off, press
PLUS. You must be viewing the Current Readings Screen, the
Trip Start/End Log screen, the Trip Speed and Distance Log
screen or the Trip Accel/Decel Log screen to turn the display
lamp on and off.
Driver ID Code Entry & Digital Input Status Screen
The Driver ID Code Entry Screen enables you to enter the driver ID
code, displays the status of the two digital inputs, and also includes an
activity indicator for the reed switch (GD and HD models) or VSS
input (VSS and VF models).
Driver ID Code Entry Screen
M I L E S
C O D E
DR600 UG Rev B D008.fm Page 11 Thursday, April 17, 2003 7:17 AM

12
Driver ID Code
When using the DriveRight 600 to monitor the driving of multiple
drivers, assign each driver a unique 4-digit ID code. Before driving
the vehicle, the driver must enter his or her ID code. The DriveRight
600 stores the driver ID code with the rest of the trip information,
which enables you to view information for each individual driver.
In addition, data downloaded by the software is segregated by
driver ID code, enabling detailed tracking of multiple drivers.
The DriveRight Vehicle Management Software allows you to use the
driver ID code to track locations instead when a single driver is
using a vehicle. You may also use the software to turn on an alarm
which will alert the driver when a driver ID (or location ID) has not
been entered.
NOTE: Driver ID code 0000 (four zeros) is used to view information for
the vehicle (all drivers) and should not be assigned to any
driver, unless only a single driver uses the vehicle.
In addition to marking data as belonging to a particular driver, the
driver ID code may be used when viewing information on the dis-
play to filter the information being viewed. To view information for
one specific driver, enter that driver’s ID code in this screen. The
DriveRight 600 display will filter out any data not assigned that
code.
To view all information, regardless of driver ID code, enter the
reserved code: 0000.
You have the following options from the Driver ID Code Entry
Screen:
❏Enter a Driver ID Code
The flashing digit in the code is the active digit. Press and
release PLUS or MINUS to cycle forward or backward
through the available entries for the active digit (0 to 9). To
change the digit which is active, press and release SET/
CLEAR. Each time you press SET/CLEAR, the next digit
become active.
If you have loaded driver ID codes into the DriveRight 600, then
only those codes will be accepted. A “no” will apear on the
screen if a wrong ID code is entered. A code of “0” will still be
accepted.
DR600 UG Rev B D008.fm Page 12 Thursday, April 17, 2003 7:17 AM

13
❏Log Out
To “log out” press and hold SET/CLEAR for 2 seconds, until
the code resets to 0000. As soon as a driver logs out, the cur-
rent trip is ended and data for that trip stored in the DriveRi-
ght 600’s memory. Note that you may not log out when the
vehicle is in motion.
Two Digital Inputs
Two digital inputs allow you to track the operation of lights or other
electrically powered accessories on the vehicle. A typical application
would be to monitor the headlights and the brakes. The screen dis-
plays “1” if the input is on, and “0” if the input is off. The status of the
inputs is stored in the trip log.
Activity Indicator
Primarily useful for troubleshooting the installation, the small “dot”
between the two activity indicators will appear whenever the reed
switch used with the 8156GD and 8156HD models is closed, or when-
ever the VSS input used with the 8156VSS and 8156VF models is high.
The reed switch closes once each time the vehicles drive shaft rotates.
Trip Start/End Log Screen
The Trip Start/End Log Screen shows the start and end time for each
trip currently stored in the DriveRight 600’s memory. To view trip
times for a specific driver, enter that driver’s ID code in the Driver ID
Code Entry screen. To view all trip times for the vehicle, enter ID code
0000.
NOTE: If the end time for a trip is “dashed,” it means that you are view-
ing the current trip, which has not yet ended (unless the unit was
restarted in the middle of a trip).
Trip Start/End Log Screen
Trip Start Time Date
Trip End Time Trip Duration
E ND
S T AR T
P M
P M
L OG
T O T A L
H r .
D A Y . M O
DR600 UG Rev B D008.fm Page 13 Thursday, April 17, 2003 7:17 AM

14
You have the following option from the Trip Start/End Log Screen:
❏Page Through Stored Trip Information
Press MINUS to page backward through stored trip infor-
mation. Press PLUS to page forward through stored trip
information. Hold the button down to increase the speed at
which the DriveRight 600 pages. When you reach the first
or last stored trip, the DriveRight 600 will no longer page
in that direction.
Trip Speed and Distance Log Screen
The Trip Speed and Distance Log Screen shows the maximum
speed, distance travelled, and amount of time spent driving over the
set speed limit for each trip currently stored in the DriveRight 600’s
memory.
To view trip speed and distance information for a specific driver,
enter that driver’s ID code in the Driver ID Code Entry screen. To
view all trip speed and distance information for the vehicle, enter ID
code 0000.
Trip Speed and Distance Log Screen
You have the following option from the Trip Speed and Distance Log
Screen:
❏Page Through Stored Trip Information
Press MINUS to page backward through stored trip infor-
mation. Press PLUS to page forward through stored trip
information. Hold the button down to increase the speed at
which the DriveRight 600 pages. When you reach the first
or last stored trip, the DriveRight 600 will no longer page
in that direction.
k m / h
SP EE D
O V E R
T I M E
SP EE D
S ec .
D I S T A N C E
K m
L OG
Maximum Speed During Trip Date
Distance Travelled
During Trip
Amount of Time Spent Driving Over
Set Speed Limit During Trip
M A X I M U M
D A Y . M O
DR600 UG Rev B D008.fm Page 14 Thursday, April 17, 2003 7:17 AM

15
Trip Acceleration/Deceleration Log Screen
The Trip Acceleration/Deceleration Log Screen shows the number of
times the set acceleration and deceleration limits were exceeded dur-
ing each trip currently stored in the DriveRight 600’s memory. (Each
time the limit is exceeded, 1 “count” is recorded, regardless of the
amount of time for which the limit was exceeded.)
To view trip acceleration/deceleration information for a specific
driver, enter that driver’s ID code in the Driver ID Code Entry screen.
To view all trip acceleration/deceleration information for the vehicle,
enter ID code 0000.
Trip Acceleration/Deceleration Log Screen
You have the following options from the Trip Acceleration/Deceleration
Log Screen:
❏Page Through Stored Trip Information
Press MINUS to page backward through stored trip informa-
tion. Press PLUS to page forward through stored trip infor-
mation. Hold the button down to increase the speed at which
the DriveRight 600 pages. When you reach the first or last
stored trip, the DriveRight 600 will no longer page in that
direction.
A CC E L
C O U N T
D E C E L
C O U N T
L OG
Date
Number of Times
Deceleration Limit
Exceeded During Trip
Number of Times
Acceleration Limit
Exceeded During Trip
D A Y . M O
DR600 UG Rev B D008.fm Page 15 Thursday, April 17, 2003 7:17 AM

16
GPS Latitude and Longitude Position Screens
The GPS Position Screensalternate between Latitude and Longitude
to show your current position, speed, and direction.
NOTE: The GPS screens are not displayed if the DriveRight is not
connected to a vehicle.
NOTE: The GPS may take up to several minutes to start tracking a
new trip, depending on the overhead obstructions surrounding
the vehicle.
Latitude Screen
Longitude Screen
A “NO” on the Latitude and Longitude screens indicates the GPS
module is not able to track your current position. The last known
position will be displayed.
Not Tracking Indicator
Whole Degrees Latitude Decimal Degrees Latitude
Current Direction GPS Latitude Position Screen
Whole Degrees Decimal Degrees
Current Speed Longitude
N O
Not Tracking
DR600 UG Rev B D008.fm Page 16 Thursday, April 17, 2003 7:17 AM
