Dawlance DW 9200 W FL User manual

Single Tub Washing Machine
DW 9200 W FL
User Manual

How to use
Control Panel
1. Water Inlet
Connect the hose from the water faucet to feed water to the tub.
2. Wash Timer
Used to select the desired time for washing or rinsing.
01
Washer does not start
Rattling and clanking noise
Vibrating noise.
Thumping sound
POSSIBLE CAUSE
1. Washer may not be plugged
in or connection may be loose.
2. House fuse blown or circuit
breaker tripped.
3. Wash timer is not set.
1. Foreign objects such as coins or
safety pins may be in the tub.
2. Belt buckets and metal fasteners are
hitting the washer tub during the washing
cycle.
1. Washer is not levelled and levelling
legs screws may not be securely
tightened.
2. Clothes not evently distributed in tub.
3. Washer may not be installed on a
solid, rm oor.
1. Heavy wash loads may produce a
thumping sound at the beginning.
HOW TO FIX IT
1. Make sure the plug is tightly
pushed into wall outlet.
2. Electrical line is overloaded. Do
not run other appliances when
washer is in use.
3. Electrical lines may be inadequate.
Contact an electrician.
4. Inappropriate house fuse or circuit
breaker is being used. Use only a
15 amp, time delay fuse or circuit breaker.
5. Set the wash timer.
1. Stop machine and check the tub.
2. Call your authorized service agency.
3. To prevent unnecessary noise and
damage to the tub, fasten fasteners and
turn garments inside out.
1. Relevel washer by ajdusting levelling
legs, screw must be tightened.
2. Stop washer and redistribute clothes.
3. Additional oor bracing may be
needed. Contact carpenter to correct
sagging or slopping oor.
1. This is normal.
2. If sound continues stop machine,
redistribute clothes.
Specication
Model No. DW 9200 W FL
Intended use
Type of appliance
Power source
Dimensions (units: mm)
Appliance weight
Rated operating time
Protection against electric shock
Protection against moisture
Standardized water consumption
Household
Single Tub
Refer to specication LABEL
609 x 544 x 1106
20 Kg
Washing: 1 hour operation
Class 1 appliance
Splash-proof appliance
135 (High), 103 (Medium), 72 (Low) (Litres)
Design and specications could be changed without notice.
02

Installation
How to wash
*
*
*
Sort the clothes into groups-white, colorfast, non-colorfast, delicates, lint free, lint producer, etc., and
wash according to the LAUNDRY GUIDE. (See Laundry Guide).
Clothes with worn or torn patches should rst be mended. Empty out all pockets and close all side
fasteners. (pocket, covers, belts, etc). Treat bad stains prior to washing.
Insert power cord plug into the power point and switch on.
1. Set the wash timer knob to position “0”.
2. Select the wash action to the desired position.
3. Open the water faucet and feed water to the water level indicated inside the wash tub.
4. Put detergent and laundry into the wash tub.
5. Set wash time by the wash timer.
Location & Environment
Electrical Connection
*
*
*
*
Do not place the washer in steamy rooms or where the washer is directly exposed to rain.
Moisture may destroy the electrical insulation and cause an electric shock hazard.
Place washer on a sturdy at surface. If the washer is placed on an uneven or weak surface, noise or
vibrations may occur. (Allowable inclination is max. 2 degrees).
Avoid direct sunlight or heating device. As plastic and electrical components are affected by direct
heat. Never place the washer near heater, boilers etc...
Do not place or store the washer below 0OC(32OF) to avoid any damage from freezing.
*
This unit is designed to operate from an adequate supply mentioned at the rating label sticked to the rear
of it.
Caution: If the power cord is damaged, it should be replaced by a repair shop appointed by the
manufacturer, because special purpose tools are required.
Preparation
How to wash
03 04
How to rinse
Laundry guide
Cleaning and maintenance
1. Set the wash action to the desired position.
2. Turn the water tap on.
3. When the rinsing water becomes clear, turns off the water tap.
Washing Time & Wash Action Table
Extremely soiled heavy fabric
Linen, cotton, etc.
Ordinary clothes (underwear, etc.)
Slightly soiled synthetic ber
100% wool, mixed wool knitting, thin synthetic
ber with tags indicating hand washing
10-15 minutes
8-10 minutes
7 minutes
2-5 minutes
2-5 minutes
KIND OF CLOTHING WASHING TIME
At the end of every washing:
Switch off the electricity.
Ensure that timer knob reached back to “0” position.
Wipe off spillage (detergent powder, etc.) and generally wipe over the tub and base with a dry duster.
Step I Remove the overow lter by pulling it
forward.
Step II Wash off the lint stuck on the overow lter
during overowing.
Step III Re-x the overow lter by rst inserting
its bottom section and then pushing the upper
part rmly into the socket.
Note: Cleaning after use will extend the life of your washing machine. Before cleaning
disconnect the power cord from the electrical outlet.
Lint lter
Note: If during washing, some residue or deposits have accumulated in the net, then after
nish washing, remove the lter by rst push down and pull it out.

05
Cleaning of dirt underneath Pulsator & on Drain Strainer
Dirt, Lint etc. may accumulate underneath the pulsator and on a Drain Strainer. Carry out cleaning after
every four to six washes or whenever required, as per following procedure.
Step I After nishing the wash, ll the wash tub upto three quarters with clean lukewarm water.
Step II Set wash action to “STRONG” position.
Step III Operate washer for 10 minutes.
Srep IV Drain out the water.
Note: The above procedure will remove the dirt, lint etc. accumulated underneath the pulsator
and on the drain strainer.
Do not connect to the hot water supply.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliances by a person responsible for their safety. Children should be supervised to
ensure that they do not play with the appliance.
This product should not be disposed with other household wasters. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources.
To return your used device, please use the return and collection system or contact the retailer where the product was
purchased. They can take this product for environment safe.
Points to remember
Cautions
Avoid using excessive amounts of bleach, soap powder of detergent. Use the amount recommended
by the respective manufacturers.
If the machine is installed in areas subject to freeze, ensure that it is completely drained after use.
When washing delicate, clothes e.g., silks, ne nylons, laces etc., it is advisable to place them
in a mesh bag to prevent them from possible damage.
Do not wash lint attracting fabrics with lint producers, e.g., black socks or dark colored
jumpers with white uffy towels, napkins, etc.
Avoid placing a wet load on the control panel.
Do not move machine in left or right direction because wheels are undirectional.
Before you call for service
There may be times when your suspend washing machine requires maintenance. Before calling
for service please check the following points. You may be pleasantly surprised that an apparent
malfunction can be easily rectied as follows.
