Dawlance DWT 1470 PL User manual

FULLY AUTOMATIC WASHING MACHINE
User Manual
DWT 1470 PL

Contents
Before using
Parts name................................................................................................. 1
Cautions..................................................................................................... 2
Installation and adjustment........................................................................ 4
How to use drainpipe................................................................................. 5
Water inlet installation................................................................................ 6
Operation
Preparation before operation..................................................................... 8
Load laundry.......................................................................................... 9
Use of detergent........................................................................................ 9
Control panel instructions.........................................................................10
Operation steps........................................................................................ 12
Maintenance............................................................................................ 13
Troubleshooting....................................................................................... 14
Other functions.........................................................................................16
Drum dimension (Dia x H) 480x360 (mm)
Product dimension (WxDxH) 585x610x970 (mm)
Model
Inlet pressure 0.03 MPa – 0.3MPa
DWT 1470 PL
Rated input power-rated voltage Refer to Specication LABEL
220V~ 50Hz
Water level/water volume (about)
Rated voltage and frequency
Specications
70 Litre

01
Parts name
Before using
Symbol definition
Warni ng symbols
Pa y special atten ti on to the war nin g symb ol s. Th e re may be
se rious risks to body safety or damages to the was hing
machine, if not followed.
Please stop doing the laundry in case of this symbol, otherwise
it will damage the appliance or injure your body.
Forbidden symbols
Accessories
The end connecting to
the appliance
Connector for
water inlet hose
and tap
The end connecting to
water inlet hose connector
Bottom cover
(1pc)
Water inlet hose (1pc)
Water inlet hose connector (1pc)Drainpipe (1pc)
Drainpipe clip (1pc)
Detergent box
Lint lter
Control panel
Inner tub
Pulsator
Body
Base
Power cord
Fixing foot (3pcs)
Back cover
Adjustable footFoot wheel
Balancing
apparatus
Feed valve
Top lid
Top frame
02
Cautions
Do not install the washing machine in bathroom or any other
damp places. Do not wash the machine with water and do not
put wet clothes on the control panel lm.
Do not use water hotter than 50 C.
If the machine is placed on a carpeted oor, please adjust
the feet in order to allow air to circulate freely.
Do not wash raincoat, bike cover, feather dress and such
waterproof laundry as it will cause unusual vibrations during
spinning.
Do not share the same socket with other electric appliances.
Do not use a damaged plug or a loose socket.
Please insert the plug into the power socket with voltage rating
220V A/C.
Always unplug the appliance and turn off the water when
the power is cut, the machine is moving or getting cleaned,
or it is not in use. Do not insert or pull off the plug with wet hands.
Do not bend, stretch, twist, strap, change, press or nip the electric cable. If the electric cable or plug is damaged or the socket
becomes loose, they must be repaired or changed by our appointed repair stations or the professionals of our post-sale service
department to avoid danger. The pin of the plug must remain clean. Please clean it carefully with dry cloth, if it is dirty.
Ventilation holes
at the bottom
Soft item
Before using

03
Any objects such as coins, safety pins, nails, screws, stones or any other hard, sharp materials can cause extensive damage and
must not be placed in the machine.
Before washing, please ensure the tap is open and the inlet hose is installed properly.
It is suggested to use low foam washing powder.
Do not put your hands while the machine is working.
It is dangerous even if the speed is very slow.
Take special care of the children and forbid
them to climb onto the washing machine.
It is dangerous to alter the specications or
attempt to modify this product in any way.
Do not overload the appliance or put any hot
items (such as the kettle with hot water) on the
washing machine.
Garments, which have been in contact with
volatile petroleum products, should not be
washed in the machine.
Keep the appliance away from direct
sunlight and heat sources like the heater.
Benzene
Petroleum
Thinner
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning the use of the appliance by a person
responsible for their safety.
Children should be supervised to ensure that they do not play with
the appliance.
CautionsBefore using
Before using
04
Please install and adjust the machine according to the requirements of the manual.
It is very important for your safety and correct operation.
Unpacking
Unpack the carton and take out the bottom panel.
Open the top lid of washing machine and take out all the accessories.
Remove all wrappers, including the polystyrene base.
You are advised to keep all the packaging for reuse, in case the machine is to be
transported again.
Installation and adjustment
Before using
Installing the bottom cover
Fixing clamp
Scissors
Bottom cover
The base
To x bottom cover, rst cut the clamps on the
cover and insert the cover in slots present at bottom
in the direction mentioned in picture. Place two
screws at the bottom in the present slot to
permanently x it.
Positioning
The distance between the washing machine and the wall should be more than 50mm and the
maximum allowed angle of the shank base of the machine is1 . The slanting or rough ground may
cause unstability or the operation to stop. Please adjust it with the following methods:
Horizontal checking
is in red circle or not. In red circle, it is horizontal.
Adjust the adjustable foot
1.
and twist the adjustable foot.
2. Fasten the nut after adjustment.
3.
is not in red circle,
bubble is in red circle.
Lift up the adjustable foot gently. Now loosen the adjustable nut
repeat the above procedure till the water
Observe, if the water bubble in balancing apparatus
Set the machine at and observe again. If the water bubbleAdjustable
nut
Adjustable
Fasten
foot
LowHigh
Loosen
2o

How to use drainpipe
Water drainage
The drain hose should drain smoothly
1. The height of the drain hose should be less
than 10cm, otherwise the drainage will not be
smooth and would need a long time to drain. The machine
may stop during working.
2. Do not step on or press the drain hose.
4. Purchase a proper hose, if you need an additional one.
Its diameter should not be less than 30mm and length should
not exceed 1.5m.
A B
3. Cut the drain hose, if it is too long. Cut the front end of the
hose slantingly to make drainage smooth.
How to change the direction of the drainpipe
1. Take off the drainpipe and its clip from the connector.
Put a soft mat on the oor & make the washing machine
front side down. Now, gently
demount the screws on the
back cover with a screwdriver
and take it out. Demount
one screw from the drainpipe connector (on right side of
the washing machine) & loosen it.
3. With proper force, take down the drainpipe gate stopper
the left side of the washing machine. The drainpipe gate
stopper is xed on washing machine base with two
clips. Please see the xing type from the place of
back cover opening.
2. Extrude the drainpipe with proper force
and take out drainpipe hoop (on right of the
washing machine). Loosen the inner
drainpipe.
4. Pull the inner drainpipe to another side.
Please do not make any distortion in the
inner pipe; as per foregoing description,
x inner drainpipe with a drainpipe hoop.
With one screw x drainpipeconnector
and install the drainpipe gate stopper to
another side. Make the washing machine
stand gently and x the back cover with
a screw. Now, install the drainpipe and
drainpipe clip into the drainpipe connector.
Install drainpipe
Set drainpipe clip into the drainpipe to above 2-3cm (from the drainpipe end without pothook).
Now, install the drainpipe into the right drainpipe connector and x the drainpipe
and drainpipe connector with the clip. After that, put the drainpipe clip on the cabinet.
Drainpipe hoop
Drainpipe gate stopper
Drainpipe connector
Drainpipe
Drainpipe clip
(Section sketch map for washing machine right side)
Section sketch map inside washing machine
Section sketch map for washing machine left side
Before using
,
If the additional drain hose is too long,
cut some at A or B point.
05 06
Water inlet installation
>10mm
Lock lever
Inlet hose connector
Slider
Screwdriver
Bolt
Bushing
Before twisting, about 4mm
After twisting, less than 2mm
Nut
Illustration 2 Illustration 3
Illustration 6
Illustration 5
Illustration 4
Tap selection
Suitable tapUnsuitable tap
The front end should be longer than 10mm.
The tap exit end face should be at and smooth, if not, le it to avoid leakage.
Connect the inlet hose connector with the tap
1. Press the lower end of the lock lever and push down the slider. Take off the inlet hose
connector from the inlet hose, see illustration 1.
2. Loosen the four bolts on the inlet hose connector till thetap can be accessed. Then
set the inlet hose connector to the tap, see illustration 2. (If the tap caliber is too large and
could not t the inlet hose end, unscrew the four bolts and take out the bushing. The tap exit
end must be at, otherwise it will leak, see illustration 3).
3. Fasten the four bolts in the inlet hose connector evenly, see illustration 4.
4. Twist the fastening nut as the illustration, see illustration 5.
Remark: Before twisting the nut, the threading should be about 4mm above the upper surface of the nut. After
twisting, the threading becomes less than 2mm above the upper surface of the nut, see illustration 6.
Before using
Inlet hose
Illustration 1

07
Water inlet installation
Before using
Connect the inlet hose connector with the inlet hose
Check the connection between inlet hose
connector and the tap
Inlet valve connector
Inlet hose nut
Water absorption cushion
1. Push down the slider and insert the inlet hose into the connector.
2. Hang the lock lever to the inlet hose connector andrelease
the slider till a click sound is heard.
1. Swing the inlet hose gently to conrm if it is fastened.
2. After installation, open the tap and check if it leaks.
3. Do not bend the inlet hose with overstrain.
4. Before each usage, check the connection between
inlet hose connector and the tap. Also, make sure that the
inlet hose is installed properly. Conrm that they are rmly
tted to prevent dropping from improper installation position.
Slider
Lock lever
Connect the inlet hose with the washing machine
1. Do not take off the water absorption cushion. Please
check if the cushion is dropped or damaged before
each use. If it is, contact the seller immediately.
2. Put the inlet hose nut on the inlet valve connector.
3. Fasten the inlet hose nut and swing it gently to make
sure if it is suitable.
1. Close the tap.
2. Press the locking lever, push down the slider, and pull off the
inlet hose. If the machine is used frequently, the connector
of the inlet hose can be kept on the tap to prevent damage to
the xing screw.
Dismantle the inlet hose
Cautions:When installing the washing machine, please use the new hose along with the washing
machine. Old hose cannot be reused.
Lock lever
Inlet hose connector
Slider
08
Preparation before
operationOperation
Preparation before washing
1. Connect the inlet hose and open the tap.
2. This appliance must be earthed. Conrm
the socket is earthed reliably and insert the
power plug. The earth terminal should not
link to the gas pipeline, tap pipeline etc.
3. Put down the drainpipe.
Before washing the laundry, please pay attention to the following:
Make sure if there
are any special
requirements for the
laundry.
Before washing, empty
all the pockets of small
objects, which may
have been left inside
(coins, keys, screws etc.)
as these could damage
the drain pump.
Knot the long band,
fasten the buttons
and close the zippers.
Do not overload the
machine. Load the
laundry loosely
alternating large
items with small ones.
Sort the laundry
according to the type
of fabric, color-fastness
and how dirty it is. Put
thin laundry, woolens
and such prone to wear
and tear laundry into a
washing bag.
A. Make sure the laundry is washable.
B. It is essential to wash new colored items separately when washing forthe rst time. White items
should not be washed with colored items.
C. Please immerge the non-absorbable laundry by hand.
D. Some stains such as fruit, wine, grass, rust etc. are difcult to remove and should be treated
before washing with specic products, which can be found in most household shops. In some
cases, it may help soak the stain before washing with a special pre-soak product or biological
detergent.
E. Overturn the nap fabric and long oss laundry before putting them into the machine.
F. Do not put the laundry polluted by chemicals into the machine directly.
G. Very small items (handkerchiefs, ribbons, socks etc.) should be washed in a washing bag or a pillow case.
Warning: The temperature of the water should be less than 50

09
Load laundry Operation
It is suggested to use low foam washing powder.
For the quantity of the concentrated washing powder, please refer to its manual.
Remarks: Avoid splashing of water and wastage of washing powder. Water level should not be too
high, if the laundry is less.
Withdraw the dispenser box before adding the detergent.
Pour concentrated synthetic washing powder into
the box directly as shown in the left illustration.
For the dosage of washing powder, please refer
below.
It is suggested to use low sud washing powder.
How to use the washing powder
Detergent box
How to use bleach
Fill water to the selected level.
Dilute the bleach in the container
and pour it slowly into the washing
tub.
Do not use bleach for colored or
gured laundries as they are prone
to lose colors.
Do not put bleach in the laundry
directly.
Refer to the manual for the usage
and quantity of the bleach.
Please dissolve powdered bleach
before use.
Use of detergent
Dissolve in the machine directly (not suitable for
preset program)
1. It is suitable for low water level.
2. Add the washing powder and run the machine for
30 seconds to dissolve it completely.
3. Put the laundry in and select suitable water level.
For instant dissolving of the washing powder
1. Prepare warm water about 30 oC in a container.
2. Pour the powder while stirring to fully dissolve it.
The washing powder is more prone to pollute the
laundry than the detergent, therefore, please use
it in proper quantity.
Washing powder with poor quality or not used for a
long period may get blocked. Please clean the
detergent box frequently.
The capacity of washing and spinning of the machine refers
to the largest weight of the standard laundry under dry
conditions.Washing quantity shall be lower than the rated
capacity.
Different thickness, size and type of the laundry will
inuence the actual washing capacity. It is suitable that
the laundry can be turned around normally during washing.
Do not select high water level when the laundry is less.
10
At the start of the program, press WATER LEVEL and PRESET at the same time. This will give you an
option to either select WATER RECYCLE, LOW NOISE, or LOW NOISE-WATER RECYCLE.
If LOW NOISE is selected, then the program’s default setting will be NORMAL and the PROGRAM
button will get locked.
If only RINSE and SPIN are selected, then WATER RECYCLE preset can be chosen.
To set CHILD LOCK press WATER LEVEL and PRESET while the machine is working. To unlock, press
the same buttons again.
Control panel instructions
Mode and meaning of the indicator light
On: Indicates the selected mode.
Flashing: Indicates the program is running.
Additional functions
With DIY program, you can set the spin time.
At the start of the program, the spin time setting
is "7 minutes".
At the start of the program, you can press "SPIN"
to set spin process onlyand press "SPIN" again to
set spin time.
With DIY program, you can set rinse time.
At the start of the program, the rinse time setting is "2 times".
At the start of the program
1. If there is no water in the inner tub, the washing machine is in "FUZZY" condition. At this point, the washing time is
"15 minutes", rinse time is "2 times", spin time is "7 minutes", water level and preset are displayed "--" and the program
is "NORMAL
"(or press “PROGRAM” to select “HEAVY).
If "START/PAUSE" button is pressed, the washing machine
will automatically sense the weight of laundry. It will also set the water level and will adjust the time accordingly.
2. If there is water in the inner tub, the washing machine is not in "FUZZY" condition. At this point, the washing time is
"15 minutes", rinse time is "2 times", spin time is "7 minutes", water level is "7", program is "NORMAL
",
and
digital time displays the time to nish washing.
Put power supply through and press "POWER" button. Now the washing machine is at the start of the program:
With DIY program, you can choose soak function and wash time.
Press "WASH" button for 2 seconds to choose soak function and press for
2 seconds again to cancel soak function.
Under "NORMAL"and "HEAVY" programs, you can choose soak function. The soak is
before wash.
At the start of the program, the wash time is "15 minutes".
Soak (min.)
20
15
12
9
4
3
2
1
Spin (min.)
3
5
7
9
Wash SpinRinse

11
Operation
After selecting the program, process and water level, press
this button to start.
Press this button to pause the working and press again
to continue.
You can select one program from NORMAL, HEAVY, SOFT, ECO WASH, FAST, WOOL, CHILD,
FOAM CLEAN,TUB CLEAN and AIR DRY.
If you choose "ECO WASH" program, then the wash time is "9 minutes", rinse time is "2",and spin time is
“5 minutes". You can cancel one of the processes (but if you choose "SOAK", the wash time cannot
be cancelled).
If you choose "FAST" program, then the wash time is "9 minutes", rinse time is "1", and spin time is "3 minutes".
You can cancel one of the processes (but if you choose "SOAK", the wash time cannot be cancelled).
At the start of the program
, the process is NORMAL.
To control the washing machine in
working or waiting state.
When washing, the digital timer shows
At the start of the program
, if the machine is in
When trouble is encountered, the digital time
shows trouble code.
Before washing, the digital timer
shows preset time. The unit displayed is HOUR.
If AIR DRY is selected, the digital timer
displays air dry time. The unit displayed is MIN.
the rest time of washing. The unit displayed is MIN.
FUZZY logic, the digital timer shows -- .
At the start of the program, press this button to select preset time from 2-24 hours.
If you want to cancel the preset time, press POWER to put the washing machine in waiting state.
If you need to select air dry, please press "PROGRAM" button to select air dry, then press this
button to set air dry time.
At the start of the program, press WATER LEVEL to select the water level. At this time, the fuzzy logic function is not available.
You can select appropriate water level according to the quantity of your laundry. 1-2 is low water level, 3-6 is
middle water level, and 7-10 is high water level.
Automatically add water: During SOAK, WASH and RINSE processes, if the water level is lower than the setting
water level, the washing machine will pause and will automatically add water to the setting water level.
Normal
Heavy
Soft
Eco Wash
Fast
Wool
Child
Foam Clean
Tub Clean
Air Dry
Water
Level
Additional
Function
Preset/
Air Dry
Program Start/
Pause
Power
Fuzzy logic is present in Normal and Heavy cycles. When you select these cycles, it will take water level and set time
as per the load. However, you may also select water level manually.
During wash or rinse cycle, if you want to add extra water then you have two options:
- Pause program, reselect water level and start machine.
- Press water level button for a few seconds during operation and the machine will continue to take water till the
button is pressed. After you release this button, the machine will start its operation.
12
Start/Pause Button
Use to pause and restart the operation. To change the washing procedure during an operation,
press this button to stop, and again to restart after changing the procedure.
Operation stepsOperation
Power Button
Press this button once to operate. Press it again to turn the power off.
Program Select Button
Each time the button is pressed, the washing programme changes.
Remaining Time, Delay Start Time, Error
Display
Displays the remaining wash time, reserved delay start time, and the error state
if a problem occurs in the washing machine so that you can take action.
Delay Start Time Button
Adjusts delay start time. Max. 24 h.
Water Level Button
The water level is automatically adjusted. However, you can select the water level manually by
pressing this button. The water level button is only active during standby status. The water
level can be selected before the machine starts to run. If you want to change it while the machine
is running, then press START/PAUSE, change the level and press START/PAUSE again.
Displays selected programme’s default water level. Low 1 to 10.
Function Button
With every press of this button, the function changes.

13
MaintenanceOperation
1.Once you have used the machine, you are advised to turn off the water tap. (If necessary, pull out
the inlet hose).
2. Do not keep the water in tub for a long time. When washing is nished, drain it right away.
3. Once you have nished using the machine, you are advised to unplug it.
4. Put the electric cable and the drain hose in order.
5. Wipe the water on the surface and in tub with a soft cloth and keep the top lid open for a while. It
helps prevent mould and stagnant smells from forming inside the appliance.
The machine will stop automatically and the
buzzer will remind you to take out the laundry
or start again.
Once you have nished using the machine,
you are advised to unplug it and turn off the
water tap to avoid unexpected leak or re.
After the end of the programme
Clean the exterior cabinet of the appliance with a
soft cloth. Do not use cleanser or volatile chemical
materials to clean the machine. These will
damage plastic parts and the surface of the machine.
External cleaning
Clean inlet gate
It is possible that the inlet lter net can be blocked
by the dust. Please clean it according to the
following steps:
1. Close the tap and turn on the power switch.
2. Start the washing machine for 5 seconds (let
the water in the inlet hose ow to the tub), and
cut off the power supply.
3. Pull off the inlet hose, remove and clean the
inlet valve and the inlet net, and install again.
Maintenance methods
If the water in the inner tub has possibility to freeze, please do like below:
1. In winter, if the remaining water freezes, it can cause the washing machine trouble.
Please take off the water inlet hose and drain out the water from the hose and inner tub.
2. If the water freezes, please don't operate the washing machine. Put 40oC hot water
in the tub. The hot water should submerge the pulsator. After a few minutes, rotate
the pulsator by hand gently. Now, you can operate the washing machine.
Magic lter cleaning
1. Pull out the magic lter.
2. Open the box and clean it.
3. Close it and reinstall it.
4. Check if the lint block part is in good condition.
press and pull to take the magic lter out.
lint block part (black rubber)
14
Troubleshooting
It does not drain
It does not inlet
Spinning stops and begins to
supply water during spin
program
Press the program button to
select SPIN, but it does not work
The spin is intermittent when
spinning starts
When used for the rst time, some
water ows from the drainpipe
No water supply.
Tap is not open.
Inlet hose is blocked.
Laundry has been overloaded or underloaded or the machine
is not placed on a stable surface.
Before contacting the technicians, please make the following checks:
Control panel has no display
Plug is not inserted tightly.
No electricity in the socket.
Power switch is not turned on.
Power supply is cut off.
Inlet hose leaks
Inlet hose connector (connecting with the tap) is not xed tightly.
Inlet hose and washing machine connector is loose.
Drainpipe is not put down.
Drainpipe is bended or blocked.
Because of the remaining water inside, when the factory did the test.
The top lid is closed when the water is draining.
Balance the laundry to reach to the best spin effect.
PhenomenaPossible reason

15
Settlement
Insert the plug tightly.
Make sure the socket is functioning, else change to another socket.
Press power switch.
Check power supply.
Install the inlet hose again.
Tighten the connector of the machine.
Restart when water supply is resumed.
Open the tap.
Clean the lter according to before “clean inlet gate”.
The machine is adjusting automatically.
Close the top lid.
Normal
Normal
Notes: If there is still a fault after the above checks, please pull out the plug and
contact the seller right away. It is dangerous to repair this product by yourself.
Put down the drainpipe.
Straighten or clean the drainpipe.
Settlement
16
Other functions
1. Give an alarm
4. Child lock function
(1) If you set child lock function, all the buttons will be locked including POWER. If the top lid
is opened while the washing machine is working, the washing will stop and the machine will give an alarm.
But if you close the top lid in 5 seconds, the washing machine will stop the alarm
and continue working. If you do not close the top lid in 5 seconds, the washing machine will
begin draining if there is water in the inner tub. Even closing the top lid now will not work. During
the draining, alarm will be given every 10 seconds. When the water in the inner tub is about
5 cm higher, alarm will be given every 10 minutes (alarm is always given). When the draining
is nished, the washing machine will be in the state of waiting. If the top lid is closed, the washing
machine is unlocked and will start working as per the previous setting.
(2) Once child lock is set and the top lid is opened in 5 seconds during washing or rinse (there is water in
the inner tub), washing machine will drain and give an alarm. If you unlock the function during
draining, the washing machine will add water to setting water level and continue working.
E1
E3
E2
F1
E4
E0
DisplayExplanation Settlement
The top lid is opened
when preset is started. Close the top lid and clear up the alarm.
After draining for 5 minutes,
it still does not reach to
the water level.
Open top lid, according to before
troubleshooting and settlement to
settle it, then close the top lid and
clear up the alarm.
The top lid is open while
spinning.
Close the top lid and clear up the
alarm.
Spin does not balance.
Open the top lid, place the laundry
equally, then close it and clear up
the alarm.
After 40 minutes, the inlet
still does not reach to the
setting water level.
Open top lid, according to before
troubleshooting and settlement to settle
it, then close the top lid and clear up the
alarm.
Water level sensor is
wrong.
Cut the power supply and call the
technicians.
testing system will supervise the running. Once vibration is beyond certain level,
3. Power supply is cut off automatically
to vibrate violently. This machine has imbalance adjustment function and the vibration
During spinning, if the laundry is not placed equally in the tub, it would cause the machine
2. Imbalance adjustment
the adjustment system will start to adjust the imbalance automatically.
5. Water recycle function
If you set water recycle function, after the last rinse is nished, the washing machine will not
drain and spin. The SPIN and WATER RECYCLE indicator light will ash and an alarm will be given.
The washing machine will stop working (if nobody operates, the alarm will be given every 10 minutes and
in 1 hour, power supply will be cut off automatically). When you press START/PAUSE, the WATER RECYCLE
indicator light will turn on and the washing machine will begin to drain and spin. The user can reuse the water.
E5
Child-lock light ashing
synchronously.
The top lid is opened
after setting child-lock.
1) Press the power supply button. If it does not start the program in 10 minutes,
the power supply will be cut off automatically.
2) After the washing is nished, the buzzer will remind, and the power supply
will be cut off automatically.
Close the top lid and clear up the
alarm.

Table of contents
Other Dawlance Washer manuals

Dawlance
Dawlance DWT 9060 EZ User manual

Dawlance
Dawlance DW 6100 W User manual

Dawlance
Dawlance DWT 260 C LVS+ User manual

Dawlance
Dawlance DWT 1166 X ADS+ User manual

Dawlance
Dawlance DW 6550 C User manual

Dawlance
Dawlance DW 5100 DC User manual

Dawlance
Dawlance DW 9200 W FL User manual

Dawlance
Dawlance DWT 255 User manual

Dawlance
Dawlance DW 7500 G User manual

Dawlance
Dawlance DW 9100 G User manual
